imagePROGRAF
PRODUCTION
LARGE-FORMAT PRINTING

Built for high-quality imaging and
exceptional performance, the
iPF9400S printer achieves maximum
productivity—including 60" borderless
prints—in the most demanding
color environments. An excellent
solution for commercial photography,
advertisements, retail signage, and
proofs, this printer produces fine details
and bold color at high speeds while
minimizing the total cost of operation.
Introducing the 60" iPF9400S
large-format printer
Extremely versatile printing solution ideal for commercial
photography, production, proofing, and signage.
FEATURES
•8-color LUCIA EX ink set, formulated for sophisticated
photographic expression with its brilliant range of vibrant
colors, smooth gradations, and incredibly fine details.
•A new multi-sensor has been incorporated into this
model for improved density detection accuracy
over the previous printer.
•A new feature has been added to give users the ability to
easily create gallery wrap prints for framing.
•Fast and Economy Modes produce high-speed output
that helps lower per-print costs.
•Accounting Manager feature tracks and calculates
printing costs to help minimize waste and maximize
profits.
•250GB hard drive makes it simple to handle multiple
complex jobs, especially in shared printer environments.
•Media Configuration Tool allows users to input media
profiles, including those for third-party media.

ADVANTAGES
The 60" iPF9400S printer features advanced printing technologies that deliver consistent,
high-quality imaging while increasing overall productivity.
MAXIMUM PRODUCTIVITY
By distributing eight colors through a 12-channel
print-head, this iPF printer achieves blazing
speeds and high production performance,
without sacrificing image quality. The sub-ink
tank system allows for on-the-fly ink replacement
to help ensure long, uninterrupted print runs.
Finally, with the ability of borderless printing
up to 60", trimming and off-line finishing
requirements are reduced.
LOW COST OF OPERATION
To minimize your per-print cost, Canon’s Fast Print
mode produces 1200 x 1200 dpi output while
reducing ink consumption by 10% to 20%.* For
quick check plots, utilize the Fast Print mode with
the Economy Printing option to help reduce total
ink consumption by approximately 50%* on select
media. And, the Accounting Manager feature
accurately tracks job data and calculates printing
costs to help manage expenses.
HIGH-QUALITY IMAGING
Produce vibrant colors and expressive tones with
Canon’s 8-color LUCIA EX ink set. This ink set
has better scratch resistance, reduced bronzing,
and a 20% wider color gamut than the previous
generation of ink. The new printer includes an
upgraded, built-in multi-sensor designed to
offer even more precise calibration and color
matching. For high-precision imaging, two
advanced one-inch print-heads output a superfine
4pl ink droplet at up to a full 2400 x 1200 dpi
resolution to reproduce details with exceptional
accuracy and clarity.
VERSATILITY
To streamline your workflow, Canon’s Media
Configuration Tool opens the door to a wider
selection of media options, allowing users to
input custom profiles. With built-in calibration,
ensure color consistency on profiled media and
create a stable, predictable printing platform
for color reproduction. The Microsoft®Office
Plug-in (PC only) and the gallery wrap feature
give users the tools to create and output
impressive, large-format gallery wraps as
well as signs and banners.
Canon’s fastest graphic arts printers, the
S-Series, deliver the performance and versatility
you need to produce profitable, high-quality
output in less time.
With four lines of imagePROGRAF solutions
available, Canon has the answer for your large-
format needs.
imagePROGRAF
© Jim DiVitale 2012
*Compared to Standard mode.

Print-Heads
PF-05 (2)
Technology
FINE (Full-photolithography Ink-jet Nozzle Engineering)
Print Resolution (Max.)
Up to 2400 x 1200 dpi
Ink Type
LUCIA EX Ink (Pigment-based)
Ink Tank
PFI-306 (330ml): BK, MBK, C, M, Y, PC, PM, GY
PFI-706 (700ml): BK, MBK, C, M, Y, PC, PM, GY
Colors
Cyan, Photo Cyan, Magenta, Photo Magenta,
Yellow, Black, Matte Black, Gray
Ink Tank Shipped with Printer
8 Colors (Full 330ml Each Color)
Hard Disk Capacity
250GB
Printer Memory
640MB
Media Feed
Front-loading Roll Feed: One Roll, Front Output
Front-loading Manual Feed: One Sheet, Front
Output
Media Width
Cut Sheet: 8" – 60"
Roll Feed: 10" – 60"
Minimum Media Length
8" (203mm)
Maximum Print Length
Manual Feed: 63" (1.6m)
Roll Feed: 59' (18m)*
Borderless Printing Widths (Roll Media Only)
10"/14"/17"/24"/36"/42"/44"/50"/60"
B2 [20.28"(565mm)]/ A1 [23.38"(594mm)]/
A0 (33.11"/841mm)/ B0 [40.55"(1030mm)]
Printer Stand
Standard
Media Thickness
0.07mm - 0.8mm (2.8mil - 31.4mil)
Media Core Sizes
2" or 3" Core (with Supplied Adapter)
Printable Margins
Manual Feed (Top/Front)
Leading and Left/Right Edges: 0.20"(5mm)
Trailing Edge: 0.90" (23mm)
Roll Feed
All Sides: 0.20" (5mm) or 0“ for
Borderless
Maximum Media Roll Outer Diameter
5.9" (150mm)
Bundled Software
Printing Software
Canon Printer Driver, Print Plug-in for Photoshop,**
Print Plug-in for DPP,*** Printer Driver Extra Kit
(Free Layout, imageRUNNER®Linking Function),
Print Plug-in for Microsoft Office (PC only)
Applications
PosterArtist Lite (PC only)
Utilities
imagePROGRAF Status Monitor (Windows®), Print
Monitor (Macintosh®), Media Configuration Tool,
Remote UI, Accounting Manager (PC only), CMCC
Printer Language
GARO (Canon Proprietary)
Operating System
Windows XP (32/64-bit), Server 2003 (32/64-bit),
Server 2008 (32/64-bit), Windows Vista (32/64-bit),
Windows 7 (32/64-bit); Macintosh OS X 10.5.8 –
10.7.x
Interface
Standard
USB 2.0 High-Speed
10/100/1000Base-T/TX
Acoustic Noise
Operation 68dB or Less
Power Supply
AC 100-240V (50-60Hz)
Power Consumption
Maximum: 190W or Less
Standby (100-120V): 6W or Less
Power Off: .5W or Less (compliant with executive order)
Certifications
UL, FCC Class B, ENERGY STAR®
Operational Environment
Temperature: 59 – 86 F° (15 – 30 C°)
Relative Humidity: 10 – 80% (No Condensation)
Dimensions with Stand (H x W x D)
45.0" x 90.5" x 30.2"
Weight
Approx. 355 lb.
User-Replaceable Items
Print-Head (PF-05)
Maintenance Cartridge (MC-08)
Durable Rotary Media Cutter (CT-06)
Options
Roll Holder Set RH2-63
BU-01 Basket
PosterArtist (PC only)
* The maximum printable length varies depending on the
application, OS, and RIP used. The maximum printable
length from Canon Printer Driver is 50 feet.
** For Adobe®Photoshop®CS3 (32bit), CS4, CS5 running on
Windows XP/Server 2003/Server 2008/Windows Vista/
Windows 7 or Macintosh OS X10.4.11-10.6.
*** For Digital Photo Professional version 2.1 or later running
on Windows XP/Server 2003/Server 2008/Windows
Vista/Windows 7 or Macintosh OS X10.4.11-10.6.
 For imagePROGRAF Printer Driver. For printing from
PostScript applications such as Adobe Illustrator®or
QuarkXPress®, please use a PostScript compatible RIP
package. For a list of Canon recommended RIP packages,
please consult with Canon Alliance and Industry Market
program list of RIP vendors.
