Service Bulletin
Issued by Canon Europa N.V. Large Format Printer
Hardware
Location:
Platen & Guide Unit
Subject:
Change of plastic sheet in the Tube Guide Unit
Detail:
1. Outline
To prevent the plastic sheet on the TUBE GUIDE UNIT to peel off or to be lifted at the edge, its material has been
changed.
2. Contents
Peeling off/lifting of the edge of the plastic sheet on the TUBE GUIDE UNIT might cause the sheet to touch the
carriage unit, resulting in a hardware error, 03130031-2F26 (carriage inoperable).
Model:
iPF650/655
iPF750/755
Ref No.:
LFP-441
(SIH-10014E)
Date:
July, 2010

LFP-441
(2/4)
To prevent this, the material of the plastic sheet as well as its production process has been changed.

LFP-441
(3/4)
3. Field measure
If the hardware error “03130031-2F26” occurs repeatedly, check the TUBE GUIDE UNIT. If there is a peeling off/
lifting of the plastic sheet, replace the TUBE GUIDE UNIT by following the procedure below.
a. For the iPF750/755
(1) Remove the operation panel, upper left cover, upper cover, and rear upper cover. (For details, see Section 4.3.4,
External covers in Chapter 4, Disassembly/Reassembly in Service Manual of the iPF 750 series.)
(2)Remove 6 screws, and remove the TUBE GUIDE UNIT.

LFP-441
(4/4)
b. For the iPF650/655
(1) Remove the operation panel, upper left cover, upper cover, and rear upper cover. (For details, see Section 4.3.4,
External covers in Chapter 4, Disassembly/Reassembly in Service Manual of the iPF 650 series.)
(2) Remove 4 screws, and remove the TUBE GUIDE UNIT.
* Pictures are omitted because the disassembly procedure is the same as that of the iPF750/755.
4. Parts:
5. Serial numbers for switching-over:
iPF750 EUR 2983B003AA: AAAC3991 or later
iPF755 EUR 3432B003AA: AAAJ1503 or later
iPF650 EUR 2990B003AA: AAAR0944 or later
iPF655 EUR 3433B003AA: AAAX0270 or later
