Canon Pixma G3110 Series User manual

Para Começar
Leia Informações Importantes e Sobre
Segurança (adendo) primeiro.
Guía de inicio
Lea primero Información de seguridad
e información importante (apéndice).
Getting Started
Read Safety and Important Information
(addendum) rst.

1
2
Instalando a impressora .................................................página 1
Conectando a um computador e smartphone/tablet ......página 4
Como segurar
a impressora
Filmes explicativos
Instalación de la impresora.............................................página 1
Conexión con el ordenador y con el teléfono
inteligente o la tableta.....................................................página 4
Cómo sujetar
la impresora
Películas explicativas
Installing the Printer...........................................................page 1
Connecting with Computer and Smartphone/Tablet..........page 4
How to Hold Printer Explanatory Movies

1
ENGLISH
1. Checking Included Items
□ Safety and Important Information
□ Power cord
□ Setup CD-ROM for Windows PC
□ Getting Started (this manual)
□ Cartridge □ Ink bottle
2. Removing Packing
Materials
1 Remove the packing materials (such as orange
tape) from outside the printer.
2 aOpen the scanning unit / cover.
bRemove the orange tape and the protective
material and discard them.
a
b
3. Installing the Cartridge
1 Open the cartridge locking cover.
2 Take out each cartridge from the package and
remove the label.
3 Remove the protective tape.
Do not touch.
4 Insert the C (color) cartridge on the left and the B
(black) cartridge on the right.
Do not bump it against the
surrounding parts.
5 Close the cartridge locking cover and push it
down.
6 Press down both joint buttons completely.

2
4. Turning on Printer
1 LIFT UP the scanning unit / cover, and then close
it.
a
b
2 Connect the power cord.
Back
Do not connect any cables except the power cord
yet.
3 Press the ON button.
4 Conrm that (Ink icon) and are displayed on
the screen.
If a different screen appears, refer to "If any of the
following screens appear" on page 3 to resolve the
error.
5. Pouring Ink
This product requires careful handling of ink. Ink may
splatter when the ink tanks are lled with ink. If ink gets
on your clothes or belongings, it may not come off.
1 Open the scanning unit / cover.
2 Open the ink tank cover.
3 Grab and remove the tank cap of the ink tank.
4 Hold the ink bottle upright and remove the bottle
cap.
5 Insert the nozzle of the ink bottle into the inlet and
stand the ink bottle upside down.
6 Pour all ink into the ink tank.
Conrm that the ink has been lled to the upper
limit line (A).
(A)

3
ENGLISH
7 Replace the tank cap securely.
8 Close the ink tank cover.
9 Repeat steps 2 to 8 to pour all ink into the
corresponding ink tanks on the right according to
the label.
Conrm that the ink has been lled to the upper
limit line (A).
(A)
10
LIFT UP the scanning unit / cover, and then close
it.
a
b
6. Preparing the Ink System
1 Press the Black button and conrm that (Ink
icon) disappears.
Flashing
Turns off
Ink preparation takes about 5 to 6 minutes.
Proceed to the next page.
The cartridges are not installed correctly.
"3. Installing the Cartridge" on page 1
No cartridges are installed.
"3. Installing the Cartridge" on page 1
The protective materials are not removed.
"2. Removing Packing Materials" on page 1
Ink is not prepared normally.
Press the ON button to restart the printer, and
then see "5. Pouring Ink" on page 2.
Waiting to prepare ink.
" 6. Preparing the Ink System"
If you have not poured ink into the ink tank yet,
see "5. Pouring Ink" on page 2.
For all other cases, refer to the Online Manual.
If any of the following screens
appear
Ink icon
Number or letters

4
7-A. Connecting to Computer
Windows
You need a connection setup for each computer. Proceed with the setup from step 1 for each computer.
1 Start the setup le for either method or method .
Downloading from the Internet
aOpen a web browser ( etc.) on your computer.
bInput the following URL and access the Canon
website.
cSelect Set Up.
dInput the model name of your printer and click OK.
You can select a model name from the list.
eClick Setup.
The procedures for Windows are shown below. If
you are using a computer with an OS other than
Windows, such as a Chrome OS, do the setup
according to the on-screen instructions.
fClick Download and download the setup le.
gExecute the downloaded le.
Proceed to step on the next page to
continue.
From here on, proceed to a step according to
how you use the printer.
• To use the printer by connecting only to
a computer or both to a computer and
smartphone
"7-A. Connecting to Computer"
• To use the printer by connecting only to a
smartphone
"7-B. Connecting to Smartphone" on page 6
To use the printer without connecting to
a computer or smartphone
aPress the Stop button on the printer.
bWait until appears on the screen.
The setup is now complete.

5
ENGLISH
Using Setup CD-ROM (Windows Only)
aLoad the Setup CD-ROM in your computer.
■ When using Windows 10 or Windows 8.1:
bWhen the following message appears on the right
side of your computer screen, click it.
cIf the following screen appears, click Run
Msetup4.exe.
dIf the User Account Control dialog box appears,
click Yes.
When This Message Does Not Appear (or Has
Disappeared)
1. Click File Explorer on the taskbar.
or
2. Click This PC on the left side of the opened window.
3. Double-click the CD-ROM icon on the right side of
the window.
If the contents of the CD-ROM appear, double-click
Msetup4.exe.
4. Proceed to step d.
■ When using Windows 7:
b When the AutoPlay screen appears, click Run
Msetup4.exe.
c If the User Account Control dialog box appears,
click Continue.
When AutoPlay Screen Does Not Appear
1. Click Computer from the start menu.
2. Double-click the CD-ROM icon on the right side of
the opened window.
If the contents of the CD-ROM appear, double-click
Msetup4.exe.
Proceed to step to continue.
2 Click Start Setup.If the following screen appears, click Exit.
Follow the on-screen
instructions to proceed
with the setup.
The setup is complete when appears on the printer's screen. You can print from your
computer.

6
7-B. Connecting to Smartphone
iOS
Android
You need a connection setup for each smartphone. Proceed with the setup from step 1 for each smartphone.
Preparation
• Turn on Wi-Fi on your smartphone.
• If you have a wireless router, connect your smartphone to the wireless router you want to connect to the printer.
* For operations, refer to manuals of your smartphone and the wireless router or contact those manufacturers.
1 Install the application software Canon PRINT Inkjet/SELPHY in your smartphone.
: Search "Canon PRINT" in App Store.
: Search "Canon PRINT" in Google Play.
Or access the Canon website by scanning the QR code.
* You may not connect your smartphone to the Internet wirelessly during connecting the printer to the smartphone directly.
In that case, you may be charged depending on the contract with your service provider.
* Up to 5 devices can be connected to the printer via wireless LAN connection directly.
2 Check the display on the printer.
The screen turns off when no operation is made for about 10 minutes. Press one of the buttons on the operation
panel (except for the ON button) to display the screen.
■ If any of the following screens appear:
• If appears, the printer is connected to a network.
• If appears, the printer cannot communicate by wireless LAN connection. For details,
access "http://ij.start.canon" to see Frequently Asked Questions.
■ If the following screen appears:
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
cMake sure that the following screen appears.
The connection with your smartphone is
now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading
Paper" on page 8.
Rotating Flashing
Proceed to .
Proceed to .

7
ENGLISH
Troubleshooting
Printer is not found from your smartphone.
aPress and hold the Direct button on the printer for about 2 seconds
until the icon starts to ash on the screen.
bReturn to the operation of your smartphone.
Procedures below vary depending on iOS or Android. Select your operating system and proceed to its
procedure.
aTap Settings on your smartphone's home screen,
and tap Canon_ij_XXXX in the Wi-Fi settings.
If Canon_ij_XXXX does not appear on the list, see
"Troubleshooting" below to operate the printer, and
then repeat step a.
bTap the installed application software.
cFollow the on-screen instructions to register the
printer.
Follow the on-screen instructions to proceed
with the setup.
If you select Auto Select Conn. Method
(recommended) on the connection method
selecting screen, the appropriate connection
method is selected automatically depending on
your environment.
dMake sure that the following screen appears.
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
If a message saying "Printer is not registered.
Perform printer setup?" does not appear, see
"Troubleshooting" below to operate the printer, and
then wait for a while until the message appears.
Follow the on-screen instructions to proceed
with the setup.
The appropriate connection method is selected
depending on your environment.
cMake sure that the following screen appears.
The connection with your smartphone is now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading Paper" on page 8.

8
1 Open the paper support.
2 Slide the right paper guide to the end.
3 aLoad paper with the print side facing up.
bSlide the right paper guide to align it with the
side of the paper stack.
a
b
4 aPull out the paper output tray.
bOpen the output tray extension.
a
b
Loading Paper
Transporting Your Printer
Check that both joint buttons are pressed down
completely to avoid ink leaks.
Pack the printer in a plastic bag in case ink leaks.
• Pack the printer in a sturdy box so that it is placed
with its bottom facing down, using sufcient protective
material to ensure safe transport.
• Do not tilt the printer. Ink may leak.
• Please handle with care and ensure the box remains
at and NOT turned upside down or on its side, as the
printer may be damaged and ink in the printer may
leak.
• When a shipping agent is handling transport of the
printer, have its box marked "THIS SIDE UP" to keep
the printer with its bottom facing down. Mark also with
"FRAGILE" or "HANDLE WITH CARE".
When relocating the printer, make sure of the following. Refer to the Online Manual for details.
