MULTIMEDIA PROJECTOR
WUX5000 / WUX4000
User Commands
Revision 1

WUX5000 / WUX4000 User Commands
- -
ii
Table of Contents
1. Overview .................................................................................................................1
2. Communication Specifications.................................................................................2
Communication Specifications ................................................................................................................... 2
Usable Character Codes..............................................................................................................................3
Communication System (Serial)................................................................................................................. 4
Communication System (LAN)................................................................................................................... 4
Commands................................................................................................................................................... 5
Response...................................................................................................................................................... 6
Other............................................................................................................................................................ 7
3. Communication Flow...............................................................................................8
Transmission sent....................................................................................................................................... 8
Transmission received................................................................................................................................. 8
Command / Response.................................................................................................................................. 8
Response Reception Timeout...................................................................................................................... 8
Control Mode............................................................................................................................................... 8
Other............................................................................................................................................................ 8
4. Command System...................................................................................................9
5. Command List.......................................................................................................11
6. Details of Commands............................................................................................13
6AXADJ.................................................................................................................................... 14
6AXR-Y ..................................................................................................................................... 15
AMBADJ................................................................................................................................... 16
AMBLEVEL..............................................................................................................................17
AMBTYPE................................................................................................................................ 18
ASPECT.................................................................................................................................... 19
AUTOPC................................................................................................................................... 21
AUTOSETEXE......................................................................................................................... 22
AVOL......................................................................................................................................... 23
BLANK ..................................................................................................................................... 24
BRI............................................................................................................................................ 25
COLOR_TEMP......................................................................................................................... 26
COMVER.................................................................................................................................. 27
CONT........................................................................................................................................ 28
DGAMMA................................................................................................................................. 29
DZOOM_POS............................................................................................................................ 30
DZOOM_RAT............................................................................................................................ 31
ERR........................................................................................................................................... 32
FINE_GAMMA_R .................................................................................................................... 33
FINE_GAMMA_G .................................................................................................................... 34
FINE_GAMMA_B .................................................................................................................... 35

WUX5000 / WUX4000 User Commands
- -
iii
FREEZE.................................................................................................................................... 36
GAMMA.................................................................................................................................... 37
HDMI_IN.................................................................................................................................. 38
HDMI_OVSCAN....................................................................................................................... 39
HUE.......................................................................................................................................... 40
IMAGE...................................................................................................................................... 41
IMAGEFLIP ............................................................................................................................. 43
INPUT....................................................................................................................................... 44
LAMP........................................................................................................................................ 45
LAMPCOUNTER..................................................................................................................... 46
MAIN ........................................................................................................................................ 47
MEMCADJ ............................................................................................................................... 48
MODE....................................................................................................................................... 49
MUTE ....................................................................................................................................... 50
NR............................................................................................................................................. 51
POWER..................................................................................................................................... 52
PRODCODE ............................................................................................................................. 53
RC ............................................................................................................................................. 54
RGBGAIN................................................................................................................................. 56
RGBOFFSET............................................................................................................................ 57
ROMVER.................................................................................................................................. 58
SAT............................................................................................................................................ 59
SAVEIMGPROF ....................................................................................................................... 60
SCRNASPECT.......................................................................................................................... 61
SEL ........................................................................................................................................... 62
SHARP...................................................................................................................................... 63
SIGNAL_INFO......................................................................................................................... 64
SIGNALSTATUS...................................................................................................................... 65
TEMP........................................................................................................................................ 66
7. Error List................................................................................................................67
8. Error Processing....................................................................................................69
9. Other .....................................................................................................................71

WUX5000 / WUX4000 User Commands
- 1 -
1. Overview
These specifications describe the methods of controlling both the Projector WUX5000 and WUX4000
from the PC over an RS-232C connection or LAN.
Virtually all operations possible with the remote control can be controlled from the PC.
The following symbols are used in these specifications:
Symbol Description
△Space(20h) with 0 or more characters, or other separator.
□Space(20h) with 1 or more characters, or other separator.
▽
Separator between parameters.
△, △(comma enclosed in more than 0 space) or
□(1 or more space)
[ ] Data in [ ] can be omitted.
| Same as OR.
：＝ Definition name is on the left side of this mark, and definition description is on the right side.

WUX5000 / WUX4000 User Commands
- 2 -
2. Communication Specifications
Communication Specifications
The projector can be controlled via RS-232C or LAN connection.
PC - Projector connection configuration
Item Specifications Item Specifications
Connection
system
PC and projector connected on
a "1:1" basis 
Connection
system TCP / IP Connection
Connection
signal line
3-line connection of SD,
RD, and SG 
Connection
signal line
Straight when connecting via
network
Connection
cable 9-pin RS-232C Cable (Cross) 
Connection
cable LAN Cable
LAN 100BASE-TX / 10BASE-T
Send Data SD SD Send Data
Receive Data RD RD Receive Data

Signal Ground SG SG Signal Ground
* Signal lines other than the three SD, RD, and SG lines are not used in the projector.
* Loop back its own signals on the PC side as necessary.
PC PROJECTOR
Dedicated cable
COM
SERVICE Network
PC
LAN PORT
LAN PORT

WUX5000 / WUX4000 User Commands
- 3 -
Usable Character Codes
Use ASCII codes in the red and blue areas.
No distinction is made between double-byte characters and single-byte characters. Do not use
double-byte or triple-byte characters. They will all be recognized as single-byte characters.
Uppercase and lowercase versions of the same alphabetic characters will be recognized as the same
character (case insensitive).
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 NUL SP 0 @ P ` p 
1 ! 1 A Q a q 
2 " 2 B R b r 
3 # 3 C S c s 
4 $ 4 D T d t 
5 % 5 E U e u 
6 & 6 F V f v 
7 ' 7 G W g w 
8 ( 8 H X h x 
9 ) 9 I Y i y 
A LF * : J Z j z 
B + ; K [ k { 
C , < L ¥ l | 
D CR - = M ] m } 
E . > N ^ n ~ 
F / ? O _ o 
Item Specifications
Delimiters
CR(0Dh), LF(0Ah), null（00h）
Characters usable as delimiters. These characters alone (single characters) or
CR+LF (0D0Ah) can be used as delimiters.
General Characters 20h to 7Eh
Characters usable in commands.
Invalid Characters Do not use the codes in regions other than the red and blue areas.
When I used it, and they are handled in the same way as SP(20h).

WUX5000 / WUX4000 User Commands
- 4 -
Communication System (Serial)
Item Specifications
Communication system RS-232-C Start-stop synchronization Semi-duplex communication
Transmission speed 19.2 Kbps
Character length 8 bits / character
Stop bit 2 bits
Parity None
Transmission format Variable-length records with terminals as delimiters
Maximum transmission
length Maximum of 256 characters (bytes) including delimiters.
Delimiters Delimiters are one of the following: CR, LF, CR+LF, Null (0).
Response delimiters are identical to command delimiters.
Transmission codes
ASCII code (General-purpose characters: 20h to 7Fh)
(Codes other than those above and delimiters are considered “other
separator codes”)
Communication
procedure No procedure
Flow control None
Error control None
Break signal Not supported
Timeout
Tc Between characters: 5s (Timeout between CR and LF is
10ms.)
Tr Between command / response
interval: 15s
* For information about timeouts, refer to “3. Communication Flow” on P. 8.
Communication System (LAN)
Item Specifications
Communication system Uses the TCP / IP protocol. Port: 33336

WUX5000 / WUX4000 User Commands
- 5 -
Commands
Transmissions sent from the PC to the projector.
Transmission format
△<Command character strings> △<Delimiter>
<Command character strings>
Character strings consisting of 0 or more alphanumeric characters.
<Delimiters>
One of CR (0Dh), LF (0Ah), CR+LF (0Dh+0Ah), Null (00h)
Type Possibilities of responses from the projector ■: possible, □: not possible
Type Description Response
Null Commands
Character string
Commands with a command character string length of 0. No command
processing is performed. ■OK

<Null command character string>
:= <Character string with length 0>
□BUSY
■WARN
■ERR


Control command
Character string
Projector control command. The format is shown below. ■OK

<Control command character string>
:= <Control name>[□<Parameter value>]
■BUSY
■WARN
■ERR


Setting command
Character string
Command that sets values for each parameter. The format is shown
below. ■OK

<Setting command character strings>
:= <Parameter name>△=△<Parameter value>
For the definition of <Parameter value>, refer to the parameter
definitions.
■BUSY
■WARN
■ERR


Reference
command
Character string
Requests current value of each parameter. The format is shown below. □OK

<Reference command character string>
:=?△<Parameter name> | GET□<Parameter name>
■BUSY
■WARN
■ERR



WUX5000 / WUX4000 User Commands
- 6 -
Response
Transmissions sent from the Projector to the PC in response to commands from the PC.
Transmission format
<Response character string> <Delimiter>
<Response character string>
Character strings consisting of one or moreASCII characters.
The first two characters are always one lowercase letter and a : (colon).
The first character indicates the response type.
Response
type Meaning Example
i State response i:OKi:BUSY etc.
w Warning w:USER_COMMAND..
e Error e:000B INVALID..
g Reference command response g:AVOL=10
<Delimiter>
Delimiters for commands sent from the PC.
Type
OK response After the processing of each command is completed, a response is sent indicating
that the next command can be received.
<OK response character string>:=i:OK
BUSY response This response is sent when a command cannot be received during processing.Wait
for a few moments, and then try sending the command again.
<BUSY response character string>:=i:BUSY
Example: > IMAGE=STANDARD
< i:BUSY
* Commands are indicated by ">", and responses are indicated by "<".
WARN response This response is sent when warning information is issued.
Note that the command is not executed in this case.
<Warning response character string>:= w:<Warning description>
Example: > IMAGE=STANDARD
< w:USER_COMMAND_VERSION_IS_UPDATED
ERR response An error message is output.
<Error response character string>:= e:<Error code>□<Error message>
* <Error code> is expressed as a four-digit hexadecimal number.
* Refer to “Error List”!
Example: > abcdefg
< e:0002 INVALID_COMMAND
GET response Request response for each parameter.
<GET response character string>:=g<Parameter name>=<Value>
Example: > GET LANG or ? LANG
< g:LANG=JPN

WUX5000 / WUX4000 User Commands
- 7 -
Other
Transmission recognition
On the receiving side (the Projector), the data that is able to be received within the character interval
of Tc is held, and the transmission is considered received when the delimiter is received.
If the character interval received exceeds the Tc or if a delimiter is not received within 256 characters,
all data already received is lost, and the mode is reset to standby to receive commands again.

WUX5000 / WUX4000 User Commands
- 8 -
3. Communication Flow
Transmission sent
At the PC, the transmission is sent within character intervals of Tc (character interval timeout).
Transmission received
At the Projector, the data that is able to be received within the character interval of Tc is held, and the
transmission is considered received when the delimiter is received.
If the character interval received exceeds the Tc or if a delimiter is not received within 256 characters,
all data already received is lost, and the mode is reset to standby to receive commands again.
Command / Response
One response is always returned for each command sent from the PC.
PC Projector
Commands
WithinTr
Response
* The timeout interval between command and response (Tr) is 15 seconds.
Response Reception Timeout
If a response is not received within the Tr (timeout interval between command and response) while
standing by a waiting response after sending a command from the PC, it is deemed to have exceeded
the “response reception timeout.” Please resend the command.
Control Mode
"LOCAL mode" and "REMOTE mode" on previous models (SX50、SX6、SX60、X600、SX7、X700) have
been removed. You do not need to be aware of which mode it is in (no need to use "REMOTE" and
"LOCAL" commands) to send user commands.
Other
If AC power is supplied to the projector, communication is possible regardless of whether the power is
on or off.
The PC side cannot send the next user command before a response for the first command is returned.
If more than 2 user commands arrive at one port, "BAD_SEQUENCE" will be returned in response to
the second user command.
For procedures which return “BAD SEQUENCE”, change the procedure, and do not send the next user
command on the PC side before a response for the first command is returned.

WUX5000 / WUX4000 User Commands
- 9 -
4. Command System

WUX5000 / WUX4000 User Commands
- 10 -

WUX5000 / WUX4000 User Commands
- 11 -
5. Command List
Item Commands Description
1 6AXADJ 6-axis adjustment ON / OFF
2 6AXR-Y 6-axis correction R-Y hue / saturation settings
3 AMBADJ Ambient light correction adjustment ON / OFF
4 AMBLEVEL Ambient light level settings
5 AMBTYPE Ambient light type settings
6 ASPECT Screen settings
7 AUTOPC Auto PC
8 AUTOSETEXE Auto setup
9 AVOL Audio volume adjustment
10 BLANK BLANK function
11 BRI Brightness setting
12 COLOR_TEMP Color temperature setting
13 COMVER User command version inquiry
14 CONT Contrast setting
15 DGAMMA Dynamic gamma
16 DZOOM_POS DZOOM position setting
17 DZOOM_RAT DZOOM ratio setting
18 ERR Error information inquiry
19 FINE_GAMMA_B Fine gamma (B) adjustment
20 FINE_GAMMA_G Fine gamma (G) adjustment
21 FINE_GAMMA_R Fine gamma (R) adjustment
22 FREEZE Freeze status
23 GAMMA Gamma adjustment
24 HDMI_IN HDMI input setting
25 HDMI_OVSCAN HDMI overscan setting
26 HUE Hue setting
27 IMAGE Image mode setting
28 IMAGEFLIP Flip display
29 INPUT Input selection
30 LAMP Lamp output setting
31 LAMPCOUNTER Lamp ON time inquiry
32 MAIN Front panel operation emulation
33 MEMCADJ Memory color adjustment
34 MODE Control mode switch
35 MUTE Mute control

WUX5000 / WUX4000 User Commands
- 12 -
Item Commands Description
36 NR Noise reduction
37 POWER This controls the power supply
38 PRODCODE Product information inquiry
39 RC Remote control operation emulate
40 RGBGAIN RGB gain adjustment
41 RGBOFFSET RGB offset adjustment
42 ROMVER ROM version inquiry
43 SAT Color saturation setting
44 SAVEIMGPROF Create user memory
45 SCRNASPECT Screen aspect setting
46 SEL Input signal selection
47 SHARP Sharpness setting
48 SIGNAL_INFO Input signal information inquiry
49 SIGNALSTATUS Signal status inquiry
50 TEMP Temperature sensor value inquiry

WUX5000 / WUX4000 User Commands
- 13 -
6. Details of Commands
Descriptions of each command are provided starting from the next page.
The command descriptions have the format shown below.
Alphabetic command name
This briefly describes the command function.
Format
This indicates the command format.
Environment
This defines the environments that support the command (power supply state, input signal state).
Power*1 Input
OFF ON PM D-RGB A-RGB COMP HDMI None
*2 *3 *4 *5 *5 *5 *5 *5
*1 Power Executable regardless of power supply state when marked by “-“.
*2 OFF "O" if enabled in a power OFF state.
*3 ON "O" if enabled in a power ON state.
*4 PM "O" if enabled while the power management state is in standby state.
*5 Input The command is enabled in states marked by “O”.
The command is executable regardless of input when marked by “-“.
Response
This describes the command response.
Description
This includes the command function, conditions, and notes.
Example
This provides command usage examples.

WUX5000 / WUX4000 User Commands
- 14 -
6AXADJ
6-axis adjustment ON / OFF
Format
6AXADJ=<6-axis adjustment parameter:ID>
GET□6AXADJ / ?△6AXADJ
<6-axis adjustment parameter:ID>
ON This sets the 6-axis adjustment to ON.
OFF This sets the 6-axis adjustment to OFF.
Environment
Power Input
OFF ON PM D-RGB A-RGB COMP HDMI None
X O X -
Response
"i:OK" is returned if the parameter was set properly.
For 'GET 6AXADJ' or '?6AXADJ', current 6-axis adjustment state is returned in
'g:6AXADJ=<6-axis adjustment parameter:ID>'
For details on other responses, refer to the "Error List".
Description
(1) This command is used to select ON or OFF for the 6-axis adjustment.
(2) This command functions in the same way as when "Image adjustments" - "Advanced
adjustments" - "6-axis adjustment" are selected on the menu.
(3) In the case of "6-axis adjustment," set the hue and color saturation of each axis using the
6AXR to Y "6-axis correction R to Y hue / color saturation setting" commands.
(4) This sets the currently selected input signal and image mode.
(5) The current 6-axis adjustment setting can be obtained using the GET command. ("GET
6AXADJ"）
Example
Control
> 6AXADJ=ON The 6-axis adjustment is set to ON.
< i:OK
Reference
> GET 6AXADJ or ?6AXADJ The 6-axis adjustment ON or OFF setting is obtained.
< g:6AXADJ=ON
*Commands are indicated by ">", and responses are indicated by "<".

WUX5000 / WUX4000 User Commands
- 15 -
6AXR-Y
6-axis correction R-Y hue / saturation settings
Format
6AXR=<R hue:Number>▽<R saturation:Number>▽<R brightness:Number>
6AXG=<G hue:Number>▽<G saturation:Number>▽<G brightness:Number>
6AXB=<B hue:Number>▽<B saturation:Number>▽<B brightness:Number>
6AXC=<C hue:Number>▽<C saturation:Number>▽<C brightness:Number>
6AXM=<M hue:Number>▽<M saturation:Number>▽<M brightness:Number>
6AXY=<Y hue:Number>▽<Y saturation:Number>▽<Y brightness:Number>
GET□6AXR / ?△6AXR
GET□6AXG / ?△6AXG
GET□6AXB / ?△6AXB
GET□6AXC / ?△6AXC
GET□6AXM / ?△6AXM
GET□6AXY / ?△6AXY
Setting values for <R/G/B/C/M/Yhue:Number> are -20 to 20.
Setting values for <R/G/B/C/M/Y saturation:Number> are -20 to 20.
Setting values for <R/G/B/C/M/Y brightness:Number> are -20 to 20.
Environment
Power Input
OFF ON PM D-RGB A-RGB COMP HDMI None
X O X -
Response
"i:OK" is returned if the parameter was set properly.
For 'GET 6AX*' or '?6AX*', current 6-axis correction R-Y hue/saturation/brightness settings are
returned as
'g:6AX*=<*hue: Number>,<*saturation:Number>,<*brightness:Number>'
For details on other responses, refer to the "Error List".
Description
(1) This sets the 6-axis correction of the hue and color saturation for R to Y.
(2) This command functions in the same way as when "Image adjustments" - "Advanced
adjustments" - "6-axis color adjustment" are selected on the menu.
(3) If numerical parameters are outside the range, "e:0801 INVALID_VALUE" is returned.
(4) These commands take effect when they have been set to valid using the 6-axis adjustment
command (6AXADJ), and they can be set separately.
(5) This sets the currently selected input signal and image mode.
(6) The current 6-axis color correction can be obtained using the GET command. ("GET
6AXR/G/B/C/M/Y")
Example
Setting
> 6AXR=-8, 5, 3 The R hue is set to –8, the color saturation is set to 5, and the brightness is set to 3.
< i:OK
Reference
> GET 6AXR or ?6AXR This retrieves the R hue, color saturation, and brightness.
< g:6AXR=12, -8, 4
* Commands are indicated by ">", and responses are indicated by "<".

WUX5000 / WUX4000 User Commands
- 16 -
AMBADJ
Ambient light correction adjustment ON / OFF
Format
AMBADJ=<Ambient light correction adjustment parameter:ID>
GET□AMBADJ / ?△AMBADJ
<Ambient light correction adjustment parameter:ID>
ON This sets the ambient light correction adjustment to ON.
OFF This sets the ambient light correction adjustment to OFF.
Environment
Power Input
OFF ON PM D-RGB A-RGB COMP HDMI None
X O X -
Response
"i:OK" is returned if ON / OFF of ambient light correction adjustment was set properly.
For 'GET AMBADJ' or '?AMBADJ', current ambient light correction adjustment setting is returned as
'g:AMBADJ=<Ambient light correction adjustment parameter:ID>'
For details on other responses, refer to the "Error List".
Description
(1) This command is used to select ON or OFF for the ambient light correction adjustment.
(2) This command functions in the same way as when "Image adjustment" - "Advanced
adjustment" - "Ambient light" are selected on the menu.
(3) In the case of "Ambient light correction adjustment", set the level using AMB_LEVEL of
"Ambient light level" command, and set the type using AMB_TYPE of "Ambient light type"
command.
(4) This sets the currently selected input signal and image mode.
(5) The current ambient light correction adjustment setting can be obtained using the GET
command. ("GET AMBADJ")
Example
Control
> AMBADJ=ON The ambient light correction adjustment is set to ON.
< i:OK
Reference
> GET AMBADJ or ?AMBADJ The ambient light correction adjustment ON or OFF setting is obtained.
< g:AMBADJ=ON
* Commands are indicated by ">", and responses are indicated by "<".

WUX5000 / WUX4000 User Commands
- 17 -
AMBLEVEL
Ambient light level settings
Format
AMBLEVEL=<Ambient light level settings parameter:ID>
GET□AMBLEVEL / ?△AMBLEVEL
<Ambient light level settings parameter:ID>
WEAK This sets the ambient light level to WEAK.
MIDDLE This sets the ambient light level to MIDDLE.
STRONG This sets the ambient light level to STRONG.
Environment
Power Input
OFF ON PM D-RGB A-RGB COMP HDMI None
X O X -
Response
"i:OK" is returned if ambient light level was set properly.
For 'GET AMBLEVEL' or '?AMBLEVEL', current ambient light level is returned as
'g:AMBLEVEL=<ambient light level settings parameter:ID>'
For details on other responses, refer to the "Error List".
Description
(1) This sets the ambient light level.
(2) This command functions in the same way as when "Image adjustment" - "Advanced
adjustment" - "Ambient light" - "Level" are selected on the menu.
(3) This sets the currently selected input signal and image mode.
(4) The current ambient light level setting can be obtained using the GET command. ("GET
AMBLEVEL")
Example
Setting
> AMBLEVEL=MIDDLE This sets the ambient light level to MIDDLE.
< i:OK
Reference
> GET AMBLEVEL or ?AMBLEVEL This retrieves the ambient light level.
< g:AMBLEVEL=MIDDLE
* Commands are indicated by ">", and responses are indicated by "<".
