MULTIMEDIA PROJECTOR
WUX450 / WX520 / WUX400ST / WX450ST
User Commands

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- -
ii
Table of Contents
Table of Contents ........................................................................................................ ii
1. Overview .................................................................................................................1
2. Communication Specifications.................................................................................2
Communication Specifications.............................................................................................................. 2
Usable Character Codes........................................................................................................................ 3
Communication System (Serial) ........................................................................................................... 4
Communication System (LAN) ............................................................................................................. 4
Command Format.................................................................................................................................. 4
Response Format ................................................................................................................................... 5
Other ...................................................................................................................................................... 7
3. Communication Flow...............................................................................................8
Command Transmission (PC side)........................................................................................................ 8
Command Reception (projector side) .................................................................................................... 8
Command / Response............................................................................................................................. 8
Response Reception Timeout ................................................................................................................ 8
Other ...................................................................................................................................................... 8
4. Command List .........................................................................................................9
5. Guide to command description.............................................................................. 11
EXAMPLE............................................................................................................................................ 11
6. Command Details..................................................................................................13
6AXADJ ............................................................................................................................................... 13
6AXR .................................................................................................................................................... 14
6AXG .................................................................................................................................................... 15
6AXB .................................................................................................................................................... 16
6AXC .................................................................................................................................................... 17
6AXM ................................................................................................................................................... 18
6AXY .................................................................................................................................................... 19
AMBADJ .............................................................................................................................................. 20
AMBLEVEL......................................................................................................................................... 20
AMBTYPE............................................................................................................................................ 21
ASELA1................................................................................................................................................ 21
ASELA2................................................................................................................................................ 22
ASELC.................................................................................................................................................. 22
ASELD ................................................................................................................................................. 23
ASELH ................................................................................................................................................. 23
ASPECT ............................................................................................................................................... 24
AUTOPC .............................................................................................................................................. 24
AUTOSETEXE .................................................................................................................................... 25
AVOL .................................................................................................................................................... 25

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- -
iii
BLANK................................................................................................................................................. 26
BRI ....................................................................................................................................................... 26
COLOR_TEMP .................................................................................................................................... 27
COMVER ............................................................................................................................................. 27
CONT ................................................................................................................................................... 28
DGAMMA ............................................................................................................................................ 28
DZOOM_POS....................................................................................................................................... 29
DZOOM_RAT....................................................................................................................................... 30
ERR ...................................................................................................................................................... 31
FINE_GAMMA_R................................................................................................................................ 32
FINE_GAMMA_G................................................................................................................................ 33
FINE_GAMMA_B................................................................................................................................ 34
FLTWRN .............................................................................................................................................. 35
FREEZE ............................................................................................................................................... 35
GAMMA ............................................................................................................................................... 36
HDMI_IN ............................................................................................................................................. 36
HDMI_OVSCAN.................................................................................................................................. 37
HUE ..................................................................................................................................................... 37
IMAGE ................................................................................................................................................. 38
IMAGEFLIP......................................................................................................................................... 39
INPUT.................................................................................................................................................. 39
KREP.................................................................................................................................................... 40
LAMP ................................................................................................................................................... 40
LAMPCOUNTER ................................................................................................................................ 41
LMPWRN............................................................................................................................................. 41
MAIN.................................................................................................................................................... 42
MEMF .................................................................................................................................................. 43
MEMG.................................................................................................................................................. 43
MEMS .................................................................................................................................................. 44
MUTE................................................................................................................................................... 44
NR ........................................................................................................................................................ 45
POWER ................................................................................................................................................ 46
PRODCODE......................................................................................................................................... 47
RC......................................................................................................................................................... 48
RGBGAIN ............................................................................................................................................ 50
RGBOFFSET ....................................................................................................................................... 50
ROMVER ............................................................................................................................................. 51
SAT....................................................................................................................................................... 51
SAVEIMGPROF................................................................................................................................... 52
SCRNASPECT..................................................................................................................................... 53
SHARP ................................................................................................................................................. 53
SIGNAL_INFO .................................................................................................................................... 54
SIGNALSTATUS ................................................................................................................................. 54
TEMP ................................................................................................................................................... 55
TPTN.................................................................................................................................................... 56
7. Error List................................................................................................................57
8. Error Processing....................................................................................................58

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 1 -
1. Overview
These specifications describe the methods of controlling Projector WUX450 / WX520 / WUX400ST /
WX450ST from PC or other controllers over an RS232C connection or LAN.
Symbol
The following symbols are used in these specifications:
Symbol Description
[ ] Data in [ ] can be omitted.
| Same as OR.

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 2 -
2. Communication Specifications
Communication Specifications
The projector can be controlled via RS-232C or LAN connection.
PC - Projector connection configuration
RS-232C connection LAN connection
Item Specifications Item Specifications
Connection
system
PC and projector connected on
a "1:1" basis Connection system TCP / IP Connection
Connection
signal line
3-line connection of SD,
RD, and SG
Connection
signal line
Straight when connecting via
network
Connection
cable 9-pin RS-232C Cable (Cross)
Connection
cable LAN Cable
LAN
1000BASE-T
100BASE-TX
10BASE-T
* Signal lines other than the three SD, RD, and SG lines are not used in the projector.
* Loop back its own signals on the PC side as necessary.
PC
プロジェクター
COM PORT SERVICE
PORT
ネットワーク接続
LAN PORT
LAN PORT
RS-232C
クロスｹｰﾌﾞﾙ
PC
Network Connection
RS-232C
crossover cable
PROJECTO
R
SD SD
RD RD
SG SG
送信データ送信データ
受信データ
信号用設置 信号用設置
受信データ
Send Data
Receive Data
Signal Ground
Send Data
Receive Data
Signal Ground

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 3 -
Usable Character Codes
Use ASCII codes in the red and blue areas of below table.
No distinction is made between double-byte characters and single-byte characters. Do not use
double-byte or triple-byte characters. They will all be recognized as single-byte characters.
Uppercase and lowercase alphabet letters are recognized as the same character.
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 NUL SP 0 @ P ` p
1 ! 1 A Q a q
2 " 2 B R b r
3 # 3 C S c s
4 $ 4 D T d t
5 % 5 E U e u
6 & 6 F V f v
7 ' 7 G W g w
8 ( 8 H X h x
9 ) 9 I Y i y
A LF * : J Z j z
B + ; K [ k {
C , < L ¥ l |
D CR - = M ] m }
E . > N ^ n ~
F / ? O _ o
Item Specifications
Delimiters CR(0Dh) 7Bh ～7Eh
Characters usable as delimiters.
General Characters 20h to 60Eh 7Bh to 7Eh
Characters usable in commands.
Invalid Characters Do not use the codes in regions other than the red and blue areas.
If used, it will be processed in the same way as space (20h).
Unrecommeded
characters
Do not use as general rule.
Both upper case and lower case letters can be used in commands, but upper
case should be used in most cases.

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 4 -
Communication System (Serial)
Item Specifications
Communication system RS-232-C Start-stop synchronization Semi-duplex communication
Transmission speed 19.2 Kbps
Character length 8 bits / character
Stop bit 2 bits
Parity None
Command format Variable-length records with terminals as delimiters
Maximum transmission
length Maximum of 256 characters (bytes) including delimiters.
Delimiters CR (0Dh) can be used as delimiter.
Delimiter in the response is CR.
Command code
ASCII codes (20h to 7Eh)
Anything other than the above code and delimiter codes are processed in the
same way as space (20h).
Communication
procedure No procedure
Flow control None
Error control None
Break signal Not supported
Timeout
Tc Between characters: 1s
Tr Between command / response
interval: 15s
* For timeout, see "Communication flow" on page 8.
Communication System (LAN)
Item Specifications
Communication system Uses the TCP / IP protocol. Port: 33336
Command Format
Format
Commands are sent from PC to the projector in the following format:
<command text><delimiter> or
<command text>=(value>(delimiter>
<command text> Character strings consisting of 1 or more alphanumeric letters
<value> Character strings consisting of 1 or more alphanumeric letters
<delimiter> CR(0Dh)
For <command strings> and <value>, see explanation about each command.
Example) When checking the power status (POWER)
PC to PJ
G E T = P O W E R CR
47h 45h 54h 3Dh 50h 4Fh 57h 45h 52h 0Dh

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 5 -
Response Format
Responses are sent from the projector to PC in the following format:
<Response character string> <Delimiter>
There are multiple response types, each having different <response string> format.
<Response character
string>
Strings consisting of 1 or more alphanumeric letters
First 2 digits are always 1 lowercase alphabet letter and a ":" (colon)
The first character indicates the response type.
Response
type Meaning Example
i Normal response i:OK
g Reference command
response
g:BRI=0
e Error response e:0002 INVALID_COMMAND
<Delimiter> CR(0Dh)
Format varies according to the type, as follows:
Normal response
A response when command is processed normally.
The projector receives the next command only after receiving this response.
Format)
i:OK<delimiter>
Example)
PC to PJ
P O W E R = O N CR
50h 4Fh 57h 45h 52h 3Dh 4Fh 4Eh 0Dh
PJ to PC
i : O K CR
69h 3Ah 4Fh 4Bh 0Dh

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 6 -
Reference command response
A response when reference is made properly for a reference command.
Format)
g:<command string>=<value><delimiter>
<command string> Character strings consisting of 1 or more alphanumeric letters
<value> Character strings consisting of 1 or more alphanumeric letters
Example)
PC to PJ
G E T = P O W E R CR
47h 45h 54h 3Dh 50h 4Fh 57h 45h 52h 0Dh
PJ to PC
g : P O W E R = O N CR
67h 3Ah 50H 4Fh 57h 45h 52h 3Dh 4Fh 4Eh 0Dh
Error response
A response when an error occurred.
Format)
e:<error ID><space><error info string>
<error ID> 4 alphanumeric letters
<space> Space character (20h)
<error info
string>
Character strings consisting of 1 or more
alphanumeric letters
* Refer to “Error List”
Example)
PC to PJ
A U T O P C CR
41h 55h 54h 4Fh 50h 43h 0Dh
PJ to PC
e : 2 0 1 F I N V A L I D _
65h 3Ah 32h 30h 31h 46h 20h 49h 4Eh 56h 41h 4Ch 49h 44h 5Fh
S I G N A L CR
53h 49h 47h 4Eh 41h 4Ch 0Dh

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 7 -
Normal response (BUSY)
This response is sent when a command cannot be received during processing.
Format)
i:BUSY<delimiter>
Example)
PC to PJ
A U T O P C CR
41h 55h 54h 4Fh 50h 43h 0Dh
PJ to PC
i : B U S Y CR
69h 3Ah 42h 55h 53h 59h 0Dh
Other
Command recognition
The receiver (projector) retains incoming characters within a specific Tc, and recognizes the data as
"received command" when delimiter is received.
If the character interval received exceeds the Tc or if a delimiter is not received within 256 characters,
all data already received is lost, and the mode is reset to standby to receive commands again.
Parameter value
Definition of <Parameter value> is as follows:
<Parameter value> <value 1>, <value 2>…,<value ｎ>
<value ｎ> <Numerical value> | <ID> | “<Character string>”
<numerical value>
[<sign>]<decimal numeric string >
The decimal string consists of minimum 1 letter and maximum 5
letters.
Valid value range is -32768 to 32767.
<ID> 1 or more ASCII characters (20h to 60h, 7Bh to 7Eh)
<character string> 0 or more ASCII characters (20h to 60h, 7Bh to 7Eh)

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 8 -
3. Communication Flow
Command Transmission (PC side)
Commands should be sent from PC in a way that each character is sent within the specified Tc
(inter-character timeout)
Command Reception (projector side)
The receiver (projector) retains incoming characters within a specific Tc, and recognizes the data as
"received command" when delimiter is received.
If the character interval received exceeds the Tc or if a delimiter is not received within 256 characters,
all data already received is lost, and the mode is reset to standby to receive commands again.
Command / Response
One response is always returned for each command sent from the PC.
PC Projector
Commands
WithinTr
Response
* The timeout interval between command and response (Tr) is 15 seconds.
Response Reception Timeout
If a response is not received within the Tr (timeout interval between command and response) while
standing by a waiting response after sending a command from the PC, it is deemed to have exceeded
the “response reception timeout.” Please resend the command.
Other
The projector can be communicated as long as it is supplied with AC power, even in standby mode.
The PC side cannot send the next user command before a response for the first command is returned.
If 2 or more user commands are received in a single port, user commands from 2nd one are discarded.
If 2 or more user commands are received in a single port, only 1st command is processed, and a
response is returned when finished.
PC Projector
Command 1
Command 2 Discarded
WithinTr Command 3 Discarded
Response to Command 1
Note: Timeout (Tr) between a command and a response is 15 seconds.
Process executed

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 9 -
4. Command List
Item Commands Setting Reference Description Power mode restriction
SL1 SL3 ST ON
1 6AXADJ Yes Yes 6-axis adjustment ON/OFF - - -
Yes
2 6AXR Yes Yes 6-axix correction R Hue / Saturation /
Brightness - - -
Yes
3 6AXG Yes Yes 6-axix correction G Hue / Saturation /
Brightness - - -
Yes
4 6AXB Yes Yes 6-axix correction B Hue / Saturation /
Brightness - - -
Yes
5 6AXC Yes Yes 6-axix correction C Hue / Saturation /
Brightness - - -
Yes
6 6AXM Yes Yes 6-axix correction M Hue / Saturation /
Brightness - - -
Yes
7 6AXY Yes Yes 6-axix correction Y Hue / Saturation /
Brightness - - -
Yes
8 AMBADJ Yes Yes Ambient light correction adjustment ON/OFF - - - Yes
9 AMBLEVEL Yes Yes Ambient light level settings - - - Yes
10 AMBTYPE Yes Yes Ambient light type settings - - -
Yes
11 ASELA1 Yes Yes Analog PC-1 audio terminal selection - - -
Yes
12 ASELA2 Yes Yes Analog PC-2 audio terminal selection - - -
Yes
13 ASELC Yes Yes Component audio terminal selection - - - Yes
14 ASELD Yes Yes Digital PC audio terminal selection - - - Yes
15 ASELH Yes Yes HDMI audio terminal selection - - - Yes
16 ASPECT Yes Yes Screen settings - - -
Yes
17 AUTOPC Yes - Auto PC - - -
Yes
18 AUTOSETEXE Yes - Auto setup - - -
Yes
19 AVOL Yes Yes Audio volume adjustment - - - Yes
20 BLANK Yes Yes BLANK function - - - Yes
21 BRI Yes Yes Brightness setting - - -
Yes
22 COLOR_TEMP Yes Yes Color temperature setting - - - Yes
23 COMVER - Yes User command version inquiry Yes Yes Yes Yes
24 CONT Yes Yes Contrast setting - - -
Yes
25 DGAMMA Yes Yes Dynamic gamma - - - Yes
26 DZOOM_POS Yes Yes DZOOM position setting - - -
Yes
27 DZOOM_RAT Yes Yes DZOOM ratio setting - - - Yes
28 ERR - Yes Error information inquiry Yes Yes Yes Yes
29 FINE_GAMMA_B Yes Yes Fine gamma (B) adjustment - - -
Yes
30 FINE_GAMMA_G Yes Yes Fine gamma (G) adjustment - - -
Yes
31 FINE_GAMMA_R Yes Yes Fine gamma (R) adjustment - - -
Yes
32 FLTWRN Yes Yes Filter warning indication at startup - - - Yes
33 FREEZE Yes Yes Freeze status - - - Yes
34 GAMMA Yes Yes Gamma adjustment - - - Yes
35 HDMI_IN Yes Yes HDMI input setting - - -
Yes

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 10 -
Item Commands Setting Reference Description Power mode restriction
SL1 SL3 ST ON
36 HDMI_OVSCAN Yes Yes HDMI overscan setting - - -
Yes
37 HUE Yes Yes Hue setting - - -
Yes
38 IMAGE Yes Yes Image mode setting - - -
Yes
39 IMAGEFLIP Yes Yes Flip display - - -
Yes
40 INPUT Yes Yes Input selection - - - Yes
41 KREP Yes Yes Key repeat - - -
Yes
42 LAMP Yes Yes Lamp output setting - - -
Yes
43 LAMPCOUNTER - Yes Lamp ON time inquiry Yes Yes Yes Yes
44 LMPWRN Yes Yes Lamp warning indication at startup - - - Yes
45 MAIN Yes - Side control operation emulation Yes Yes Yes Yes
46 MEMF Yes Yes Memory color adjustment (flesh) - - -
Yes
47 MEMS Yes Yes Memory color adjustment (sky) - - - Yes
48 MEMG Yes Yes Memory color adjustment (green) - - - Yes
49 MUTE Yes Yes Mute control - - - Yes
50 NR Yes Yes Noise reduction - - -
Yes
51 POWER Yes Yes This controls the power supply Yes Yes Yes Yes
52 PRODCODE - Yes Product information inquiry Yes Yes Yes Yes
53 RC Yes - Remote control operation emulate Yes Yes Yes Yes
54 RGBGAIN Yes Yes RGB gain adjustment - - - Yes
55 RGBOFFSET Yes Yes RGB offset adjustment - - - Yes
56 ROMVER - Yes ROM version inquiry Yes Yes Yes Yes
57 SAT Yes Yes Color saturation setting - - -
Yes
58 SAVEIMGPROF Yes Yes Create user memory - - -
Yes
59 SCRNASPECT Yes Yes Screen aspect setting - - -
Yes
60 SHARP Yes Yes Sharpness setting - - - Yes
61 SIGNAL_INFO - Yes Input signal information inquiry - - - Yes
62 SIGNALSTATUS - Yes Signal status inquiry - - - Yes
63 TEMP - Yes Temperature sensor value inquiry - - -
Yes
64 TPTN Yes Yes Test pattern - - -
Yes
Note: About "Power mode restriction"
Commands are executable only when the projector is in the mode indicated by "○." Meaning of each mode is
as follows:
SL1: Standby mode when "Network standby setting" is set to "Eco" (for commands sent through LAN)
SL3: Standby mode when "Network standby setting" is set to "Normal" (for commands sent through LAN)
ST: Standby mode (for all commands sent via RS-232C, regardless of the network setting)
ON: Power on status

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 11 -
5. Guide to command description
This section explains how commands are described.
The command descriptions have the format shown below.
EXAMPLE
Summary of the function
Format
Setting Command A command format when a command is sent to the projector to make a setting
for the function.
"-" is shown when there is no setting command.
Example) 6AXADJ=<6-axix adjustment parameter: ID>
Response A response format for the setting command.
"-" is shown when there is no setting command.
Example) i:OK
Reference Command A command format when a command is sent to the projector to refer to the
current setting, status and others for the function.
"-" is shown when there is no reference command.
Example) GET=6AXADJ
Response A response format for a reference command.
"-" is shown when there is no reference command.
Example) g:6AXADJ=<6-axis adjustment parameter: ID>
Note: See "Error list" for any response other than the above.
When parameters exist for the command, a list of parameter is inserted in this position.
Example)
<6-axis adjustment parameter: ID>
Parameter Meaning
ON Valid
OFF Invalid

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 12 -
Environment
This defines the environments that support the command (power supply state, input signal state).
The command is executable when the projector is in the mode indicated by "○" in the table of
corresponding command description page.
Power mode restriction Input *8
LAN *1 RS-232C *6
SL0 SL1 SL3 ON ST ON D-RGB A-RGB COMP HDMI LAN USB None
*2 *3 *4 *5 *7 *5 *8 *8 *8 *8 *8 *8 *8
*1 Power mode restriction/LAN Indicates whether the command coming through LAN is executable.
*2 SL0 Standby mode, and the network function is turned off.
When the network function is turned off, the command is not executable if
coming from LAN, in which case, this should never be “O”.
*3 SL1 "O" if enabled in a power ON state.
*4 SL3 Standby mode, and the network standby setting is set to "Eco."
*5 ON Normal projection status
*6 Power / RS-232C Indicates whether the command coming through RS-232C is executable.
*7 ST Standby mode (includes SL0, SL1 and SL3 altogether, regardless of the
network setting).
*8 Input Indicates whether the command that is depending on input signal is
executable while the power is on.
Remarks
Remarks about the command is inserted when necessary.
Example
Specific example of the command is inserted when necessary.

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 13 -
6. Command Details
6AXADJ
6-axix adjustment / OFF
Format
Setting Command 6AXADJ=<6-axix adjustment parameter: ID>
Response i:OK
Reference Command GET=6AXADJ
Response g:6AXADJ=<6-axix adjustment parameter: ID>
Note: See "Error list" for any response other than the above.
<6-axis adjustment parameter:ID>
Parameter Meaning
OFF Turned off
ON Adjusted
Environment
Power mode restriction Input
LAN RS-232C
SL0 SL1 SL3 ON ST ON D-RGB A-RGB COMP HDMI LAN USB None
No No No Yes No Yes Yes Yes Yes Yes Yes Yes Yes
Remarks
(1) Use "6AXR - Y" command when this is set to "ON" and the corrected 6-axis values need to be
changed.
(2) This sets the currently selected input signal and image mode.

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 14 -
6AXR
6-axis adjustment (red), hue/saturation/brightness
Format
Setting Command 6AXR=<R hue:Number>,<R saturation:Number>,
<R brightness:Number>
Response i:OK
Reference Command GET=6AXR
Response g:6AXR=<R hue:Number>,<R saturation:Number>,
<R brightness:Number>
Note: See "Error list" for any response other than the above.
<R hue:Number> is within -20 to 20
<R saturation:Number> is within -20 to 20
<R brightness:Number> is within -20 to 20
Environment
Power mode restriction Input
LAN RS-232C
SL0 SL1 SL3 ON ST ON D-RGB A-RGB COMP HDMI LAN USB None
No No No Yes No Yes Yes Yes Yes Yes Yes Yes Yes
Remarks
(1) When 6-axix adjustment is turned on, these settings are shown over the displayed image.
However, the settings can be changed regardless of whether 6-axis adjustment is turned on or
not.
(2) This sets the currently selected input signal and image mode.

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 15 -
6AXG
6-axis adjustment (green), hue/saturation/brightness
Format
Setting Command 6AXG=<G hue:Number>,<G saturation:Number>,
<G brightness:Number>
Response i:OK
Reference Command GET=6AXG
Response g:6AXG=<G hue:Number>,<G saturation:Number>,
<G brightness:Number>
Note: See "Error list" for any response other than the above.
<G hue:Number> is within -20 to 20
<G saturation:Number> is within -20 to 20
<G brightness:Number> is within -20 to 20
Environment
Power mode restriction Input
LAN RS-232C
SL0 SL1 SL3 ON ST ON D-RGB A-RGB COMP HDMI LAN USB None
No No No Yes No Yes Yes Yes Yes Yes Yes Yes Yes
Remarks
(1) When 6-axix adjustment is turned on, these settings are shown over the displayed image.
However, the settings can be changed regardless of whether 6-axis adjustment is turned on or
not.
(2) This sets the currently selected input signal and image mode.

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 16 -
6AXB
6-axis adjustment (blue), hue/saturation/brightness
Format
Setting Command 6AXB=<B hue:Number>,<B saturation:Number>,
<B brightness:Number>
Response i:OK
Reference Command GET=6AXB
Response g:6AXB=<B hue:Number>,<B saturation:Number>,
<B brightness:Number>
Note: See "Error list" for any response other than the above.
<B hue:Number> is within -20 to 20
<B saturation:Number> is within -20 to 20
<B brightness:Number> is within -20 to 20
Environment
Power mode restriction Input
LAN RS-232C
SL0 SL1 SL3 ON ST ON D-RGB A-RGB COMP HDMI LAN USB None
No No No Yes No Yes Yes Yes Yes Yes Yes Yes Yes
Remarks
(1) When 6-axix adjustment is turned on, these settings are shown over the displayed image.
However, the settings can be changed regardless of whether 6-axis adjustment is turned on or
not.
(2) This sets the currently selected input signal and image mode.

WUX450 / WX520 / WUX400ST / WX450ST User Commands
- 17 -
6AXC
6-axis adjustment (cyan), hue/saturation/brightness
Format
Setting Command 6AXC=<C hue:Number>,<C saturation:Number>,
<C brightness:Number>
Response i:OK
Reference Command GET=6AXC
Response g:6AXC=<C hue:Number>,<C saturation:Number>,
<C brightness:Number>
Note: See "Error list" for any response other than the above.
<C hue:Number> is within -20 to 20
<C saturation:Number> is within -20 to 20
<C brightness:Number> is within -20 to 20
Environment
Power mode restriction Input
LAN RS-232C
SL0 SL1 SL3 ON ST ON D-RGB A-RGB COMP HDMI LAN USB None
No No No Yes No Yes Yes Yes Yes Yes Yes Yes Yes
Remarks
(1) When 6-axix adjustment is turned on, these settings are shown over the displayed image.
However, the settings can be changed regardless of whether 6-axis adjustment is turned on or
not.
(2) This sets the currently selected input signal and image mode.
