Canon ColorPass-Z7400 User manual

Please read this guide before operating this equipment.
After you finish reading this guide, store it in a safe place for future reference. ENG
Configuration Guide
Configuration Guide
-Z7400

Configuration Guide
ColorPASS-Z7400

This manual is part of a set of ColorPASS-Z7400
™
documentation that includes the
following manuals for users and system administrators:
• The Quick Start Guide summarizes the steps for configuring the ColorPASS-Z7400
and printing. It also describes how to access the Acrobat PDF files on the User
Documentation CD.
• The User Software Installation Guide describes how to install software from the
User Software CD to enable users to print to the ColorPASS-Z7400, and also
describes setting up printing connections to the ColorPASS-Z7400.
• The Configuration Guide explains basic configuration and administration of the
ColorPASS-Z7400 for the supported platforms and network environments. It also
includes guidelines for setting up UNIX, Windows NT 4.0/2000/Server 2003, and
Novell NetWare servers to provide printing services to users.
• The Printing Guide describes the printing and scanning features of the
ColorPASS-Z7400 for users who send jobs from their computers.
• The Color Guide provides information on managing the color output of the
ColorPASS-Z7400. It explains how to calibrate your copier and take advantage of
the ColorWise
®
color management system, as well as features in ColorWise Pro
Tools
™
.
• The Fiery Color Reference addresses concepts and issues associated with managing
color output of the ColorPASS-Z7400 and outlines key workflow scenarios. In
addition, it offers information on printing color documents from popular
Microsoft Windows and Apple Mac OS applications.
• The Job Management Guide explains the functions of the job management utilities,
including Command WorkStation
™
, Command WorkStation LE
™
, and DocBuilder
Pro
™
, and how you can use them to monitor and control jobs on the
ColorPASS-Z7400. This manual is intended for an operator or administrator, or a
user with the necessary access privileges, who monitors and manages job flow,
performs color calibration, and troubleshoots problems that may arise.
• Release Notes provide last-minute product information and workarounds for some of
the problems you may encounter.
About the
Documentation
