Canon Wireless File Transmitter WFT-E2 II A User manual

Wireless File Transmitter
WFT-E2 II
Instruction Manual for Use With EOS-1D Mark IV
To EOS-1D Mark III or EOS-1Ds Mark III Users
This instruction manual describes the use of the transmitter when connected to the EOS-1D Mark IV.
When using the transmitter with the EOS-1D Mark III or EOS-1Ds Mark III, refer to the PDF
manual in the EOS_1DIII_1DsIII folder.
To comply with local radio wave regulations, Canon offers four region-specific versions of
the transmitter (WFT-E2 IIA, E2 IIB, E2 IIC, and E2 IID) in various areas around the world
(p.8). For convenience, we refer to the product in this manual simply as “the transmitter,”
without reference to versions A, B, C, or D.
E
INSTRUCTION MANUAL
COPY

2
The Wireless File Transmitter WFT-E2 II is an accessory for EOS-1D Mark IV camera. It gives
the camera wireless and wired LAN functionality and adds a USB port, enabling the following
operations.
Introduction
Wireless and Wired LAN Functions
FTP Transfer
EOS Utility
WFT Server
Transfer images to an FTP server
Use a web browser to capture, view,
and download images remotely
Use EOS Utility to capture, view, and
download images remotely
Linked Shooting
Wirelessly trigger shooting by slave
cameras linked to a master camera
COPY

3
Introduction
Functions When Connected via USB
External Media
Record or backup images onto external media
Add the latitude, longitude, altitude, date and time, and
other shooting information to images
GPS
Connected by a USB cable Connected via Bluetooth
COPY

4
These instructions should be followed only after your wireless or wired LAN and FTP server
settings are complete. For details on configuring these settings, refer to the documentation
provided with the respective equipment.
Terms in brackets [ ] indicate button or icon names or other software elements. Brackets
also denote camera menu items.
Page numbers in parentheses indicate where you can find additional information.
Instructions on camera operations should be followed only after you have read the Camera
Instruction Manual and are familiar with operating the camera.
Sections of this manual labeled with the following symbols contain information of the
corresponding nature.
: Warnings to avoid potential problems are labeled with a caution symbol.
: Supplemental information is labeled with a note symbol.
Conventions Used in this Manual
Windows is a trademark or registered trademark of Microsoft Corporation in the United
States and other countries.
Macintosh is a registered trademark of Apple Corporation in the United States and other
countries.
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of the Wi-Fi
Alliance.
WPS as used on camera settings screens and in this manual signifies Wi-Fi Protected
Setup.
UPnP is a trademark of the UPnP Implementers Corporation.
Bluetooth and the Bluetooth logos are trademarks owned by Bluetooth SIG, Inc.
All other corporate and brand names in this manual are trademarks or registered
trademarks of their respective owners.
Using the transmitter for remote image transfer, capture, or viewing requires adequate knowledge of
configuring your wireless or wired LAN and FTP server.
Canon cannot provide support for configuring wireless or wired LANs or FTP servers.
Note that Canon cannot be held liable for any loss or damage to the transmitter from erroneous network
or FTP server settings. In addition, Canon cannot be held liable for any other loss or damage caused by
use of the transmitter.
COPY

5
Chapter List
Introduction 2
Basic Network Settings 15
Transferring Images to an FTP Server 29
Remote Capture Using EOS Utility 43
Remote Capture Using WFT Server 49
Linked Shooting 61
Managing Settings Information 65
Using External Media 71
Using GPS Devices 83
Troubleshooting 91
Reference 109
1
2
3
4
5
6
7
8
9
10
COPY

6
Introduction 2
Conventions Used in this Manual ...................................................................................................... 4
Chapter List........................................................................................................................................ 5
Contents............................................................................................................................................. 6
Areas of Use and Restrictions ........................................................................................................... 8
Safety Warnings............................................................................................................................... 10
Nomenclature................................................................................................................................... 11
Attaching to the Camera .................................................................................................................. 12
Subsequent Organization of This Manual........................................................................................ 13
1Basic Network Settings 15
Getting Ready .................................................................................................................................. 16
Displaying the Connection Wizard ................................................................................................... 17
Selecting the Communication Method and LAN Type ..................................................................... 18
Using the Wizard to Establish a Connection.................................................................................... 21
WPS Connections (PBC Mode) ....................................................................................................... 23
WPS Connections (PIN Mode) ........................................................................................................ 24
Configuring Network Settings .......................................................................................................... 25
2Transferring Images to an FTP Server 29
Configuring FTP Communication Settings....................................................................................... 30
Automatic Image Transfer After Each Shot ..................................................................................... 32
Transferring Images Individually ...................................................................................................... 34
Batch Transfer ................................................................................................................................. 36
Checking Image Transfer History .................................................................................................... 40
Viewing Transferred Images ............................................................................................................ 41
3Remote Capture Using EOS Utility 43
Configuring EOS Utility Communication Settings ............................................................................ 44
Using EOS Utility ............................................................................................................................. 47
4Remote Capture Using WFT Server 49
Configuring WFT Server Communication Settings .......................................................................... 50
Displaying WFT Server .................................................................................................................... 52
Viewing Images................................................................................................................................ 53
Remote Capture [Camera control] ................................................................................................... 55
Remote Capture [Simple control]..................................................................................................... 58
Remote Capture............................................................................................................................... 59
5Linked Shooting 61
Setting Up Linked Shooting ............................................................................................................. 62
Arranging the Slave Cameras.......................................................................................................... 64
Contents
COPY

7
Contents
6Managing Settings Information 65
Checking Settings ............................................................................................................................ 66
Changing Settings............................................................................................................................ 67
Saving and Loading Settings ........................................................................................................... 69
7Using External Media 71
Connecting External Media.............................................................................................................. 72
Choosing Recording Media When Shooting .................................................................................... 75
Copying Images ............................................................................................................................... 77
Backing Up on External Media......................................................................................................... 78
8Using GPS Devices 83
Connecting GPS Devices with a USB Cable ................................................................................... 84
Connecting GPS Devices via Bluetooth........................................................................................... 87
9Troubleshooting 91
Responding to Error Messages ....................................................................................................... 92
Wireless LAN Notes....................................................................................................................... 106
Checking Network Settings............................................................................................................ 107
10 Reference 109
Creating and Registering Captions ................................................................................................ 110
Specifications................................................................................................................................. 111
Index .............................................................................................................................................. 118
COPY

8
To comply with local radio wave regulations in various areas around the world, Canon offers
four region-specific versions of the transmitter (WFT-E2 IIA, E2 IIB, E2 IIC, and E2 IID) as
described below. Please do not use your model (version) of transmitter in regions it was not
designed for.
For information on other areas where the transmitter can be used, contact Canon Service
Center.
In France, outdoor use is prohibited.
In mainland China, outdoor use requires a permit in some areas.
IEEE 802.11a Restrictions
When IEEE 802.11a wireless networking is used, channels in gray in the following table cannot
be used. These restrictions are established by local regulations, which must be upheld.
The transmitter can be used on channels in blue. Regarding channels in yellow, some
restrictions apply. Refer to the footnotes.
Areas of Use and Restrictions
Model
(Version) Area of Use Wireless LAN Specification and Supported Channels
WFT-E2 IIA United States, Canada, Singapore, and Hong Kong IEEE 802.11a 36 – 64 ch
149 – 165 ch
IEEE 802.11b/g 1 – 11 ch
WFT-E2 IIB
Japan, France, Italy, Germany, United Kingdom, Belgium,
the Netherlands, Luxembourg, Ireland, Denmark, Greece,
Spain, Portugal, Austria, Finland, Sweden, Poland, Hungary,
Romania, Bulgaria, Czech Republic, Slovakia, Slovenia,
Estonia, Latvia, Lithuania, Cyprus, Malta, Iceland, Norway,
Switzerland, Liechtenstein, Australia, New Zealand, Russia,
and Hong Kong
IEEE 802.11a 36 – 64 ch
100 – 140 ch
IEEE 802.11b/g 1 – 13 ch
WFT-E2 IIC Mainland China and Hong Kong IEEE 802.11a 149 – 161 ch
IEEE 802.11b/g 1 – 13 ch
WFT-E2 IID Can be used in all areas noted above IEEE 802.11a Not supported
IEEE 802.11b/g 1 – 11 ch
Wireless LAN
Connection Method Channel
WFT-E2 IIA
Indoors Infrastructure 36 – 48 52 – 64 149 – 165
Ad hoc 36 – 48 52 – 64 149 – 165
Outdoors Infrastructure 36 – 48 52 – 64 149 – 165
Ad hoc 36 – 48 52 – 64 149 – 165
WFT-E2 IIB
Indoors Infrastructure 36 – 48 52 – 64 100 – 140
Ad hoc 36 – 48 52 – 64 100 – 140
Outdoors Infrastructure 36 – 48 52 – 64*J100 – 140
Ad hoc 36 – 48 52 – 64 100 – 140
WFT-E2 IIC 149 – 161*C
*J: In Japan, outdoor use on channels 52 – 64 is prohibited.
*C: In mainland China, outdoor use requires a permit in some areas.
COPY

9
Areas of Use and Restrictions
The following actions may be punishable under law. Disassembling or modifying the
transmitter, or removing the certification label on it.
Do not use the transmitter near other devices that emit radio waves, such as medical
equipment or electronic devices. The transmitter may interfere with operation of these
devices.
Use the transmitter only with a compatible EOS DIGITAL camera. Using it with incompatible
cameras may cause malfunction, accidents, and other problems not covered under
warranty.
Use the transmitter as a wireless or wired LAN device as described in this instruction
manual. If you use the transmitter for any other purpose, Canon cannot be held liable for
any loss or damage that may occur.
COPY

10
The following precautions are intended to prevent harm to you and others as well as damage to
equipment. Become familiar with the precautions before using the transmitter to ensure correct
and safe operation.
To prevent fire, excessive heat, chemical leakage, or explosion, follow these safety guidelines.
• Do not insert metallic objects between electrical contacts of the transmitter, accessories, or connecting cables.
Do not use the transmitter where there is flammable gas. There is a risk of explosion or fire.
If the transmitter is dropped and internal parts are exposed, do not touch the exposed parts. There is a risk of
electrical shock.
Do not disassemble or modify the transmitter. High-voltage internal parts may cause electrical shock.
Do not store the transmitter in dusty or humid places. There is a risk of fire or electrical shock.
Before using the transmitter on board airplanes or in hospitals, make sure use is permitted. Electromagnetic
waves emitted by the transmitter may interfere with instrumentation or medical equipment.
Do not leave the transmitter inside a vehicle in hot weather or near a heat source. The transmitter may become
hot and cause burns if touched.
Do not cover or wrap the transmitter with a cloth. This may trap heat inside, posing a risk of case deformation or
fire.
Do not use paint thinner, benzene, or other organic solvents to clean the transmitter. This poses a risk of fire and
may be hazardous to your health.
If the product malfunctions, becomes damaged, or requires repair, contact your dealer
or the nearest Canon Service Center.
The transmitter is a precision instrument. Do not drop it or subject it to shock.
The transmitter is not waterproof. Do not use it underwater.
Wipe off any moisture with a clean, dry cloth. If the transmitter has been exposed to salty air,
wipe it with a clean damp cloth after wringing it out to remove excess water.
Never leave the transmitter near any equipment that generates a strong magnetic field,
such as magnets or electric motors.
Do not leave the transmitter in excessive heat, such as in a vehicle in direct sunlight. High
temperature may damage the transmitter.
Do not wipe the transmitter using cleaners containing organic solvents. If the transmitter
becomes difficult to clean, take it to the nearest Canon Service Center.
To avoid corrosion, do not store the transmitter where there are strong chemicals, such as in
darkrooms or chemical labs.
Safety Warnings
Warning Preventing Serious Injury or Death
Caution Preventing Injury or Equipment Damage
Handling Precautions
COPY

11
Nomenclature
USB port
Ethernet
RJ-45 port
Terminal cap
receptacle (Not used with the EOS-1D Mark IV)
<
USB > USB lamp
<
LAN > Network lamp
Port cover
Locking lever
Attachment pin
Tightening
screw
Terminal
External Media Case*1
Waterproof/Dustproof USB Cap*2 Transmitter Case
*1: For storing portable hard disks or other devices.
*2: Attach this cap before connecting the USB cable in rainy weather or under other adverse conditions.
COPY

12
Turn off the camera before attaching the transmitter.
Ensure the camera battery has sufficient charge. If the charge drops below 19%, you
cannot transfer captured images or back them up to external media.
1Open the terminal cover on the camera.
Open the extension system terminal cover and
turn it toward the bottom.
2Move the lever into the release position.
3Attach the transmitter.
Align the attachment pin with the WFT-E2 II/IIA
mounting hole on the camera.
Push the terminal firmly into the camera.
As you push the terminal into the camera, turn the
tightening screw until it stops rotating to attach the
transmitter securely.
4Move the lever into the locked position.
The transmitter is now attached to the camera.
The transmitter will be powered by the camera.
Removal
Turn off the camera.
Push the lever down, into the release position.
Loosen the tightening screw until it spins freely.
Pull the terminal out of the camera.
Attaching to the Camera
COPY

13
Click one of the following chapter titles to view the corresponding page.
Subsequent Organization of This Manual
1 Basic Network Settings (p.15)
2 Transferring Images to an FTP Server (p.29)
3 Remote Capture Using EOS Utility (p.43)
4 Remote Capture Using WFT Server (p.49)
5 Linked Shooting (p.61)
6 Managing Settings Information (p.65)
7 Using External Media (p.71)
8 Using GPS Devices (p.83)
COPY

14
COPY

15
Basic Network Settings
Complete the basic network settings by following transmitter connection
instructions on the camera menu screen.
COPY

16
The connection instructions help you follow the steps to connect the transmitter to an existing
wireless or wired LAN.
To connect to a wireless LAN, prepare the wireless LAN terminal (wireless LAN access point or
wireless LAN adapter) and computer in advance so that they are ready for you to connect the
transmitter to the wireless network. When configuring the basic network settings, bring the
transmitter within 3 m / 9.8 ft. of the wireless LAN terminal.
To connect to a wired LAN, use a LAN cable to connect the transmitter and computer. Set the
transmitter for connection to the wired network.
Wireless Transmission of Movie
Individual movie files are large, and wireless file transmission takes some time. When setting
up an environment for stable transmission to the wireless LAN terminal, refer to the information
on page 106.
Set up two or more EOS-1D Mark IV cameras with attached transmitters.
Getting Ready
[FTP trans.], [EOSUtility], [WFTserver]
[LinkedShot]
COPY

17
This section describes the process of following the connection instructions. If an error is
displayed, refer to “Troubleshooting” in Chapter 9 (p.91) and check the settings.
Pressing the shutter button or other camera controls during configuration by the connection
instructions will close the connection instructions. Do not press the shutter button or other
controls until configuration is finished.
On the [5] tab, set [Auto power off] to [Off]. If auto power off is activated, the connection
instructions will be closed during the configuration process.
1Turn the camera on.
2Display the transmitter menu.
On the camera, press the <7> button.
On the [7] tab, select [WFT settings] and press
<0>. [WFT settings] is added to the tab after
you attach the transmitter.
3Select [Connection wizard].
XThe [Select communication method] screen is
displayed.
XThe <
LAN > lamp starts blinking.
Displaying the Connection Wizard
COPY

18
Turn the <5> dial to select the communication
method, and then press <0>.
Select [OK] and press <0> to go to the next
screen.
• FTP trans.
Choose this option to transfer captured images to an FTP server.
Images can be automatically transferred as you shoot them, or you can select images to be
transfered later.
Computer Operating Systems
Operation via [FTP trans.] requires that Windows Vista (Business, Enterprise, or Ultimate
Edition for 32- or 64-bit systems), Windows XP Professional, Windows 2000, or Mac OS X
10.4 or 10.5 be installed on your computer. In addition, the computer must be set up as an
FTP server in advance.
For instructions on setting up your computer as an FTP server, refer to the computer
documentation.
Windows Vista Home Premium and Home Basic Edition as well as Windows XP Home
Edition cannot be used because FTP server functionality is not supported.
• EOSUtility
Choose this option for remote capture over a wireless or wired LAN using the EOS Utility
software included with your camera.
In addition to remote capture, all camera operations in EOS Utility are supported. With this
option, a wireless or wired network is used instead of the USB cable.
Requires a computer with EOS Utility (included with EOS-1D Mark IV cameras) installed.
Selecting the Communication Method and LAN Type
Selecting the Communication Method
COPY

19
Selecting the Communication Method and LAN Type
• WFTserver
Choose this option for remote capture over a wireless or wired LAN with the transmitter acting
as a server.
Additionally, images on a memory card in the camera can be viewed and downloaded to a
computer.
The camera can be accessed like browsing a webpage, by users at up to three computers.
Computer Operating Systems
Any computer with a web browser can be used, regardless of the operating system.
Even devices other than computers can be used, if they feature a web browser. However, if
the web browser does not support JavaScript, WFT Server functions will be limited. Also
note that devices with limited performance may display images more slowly, and
downloading images to these devices may not be possible.
• LinkedShot
Choose this option for linked shooting with multiple EOS-1D Mark IV cameras attached with
transmitters. Up to 10 slave cameras can be linked to the master camera on which you will
release the shutter. Note that there will be a slight delay after you release the master camera
shutter before the slave cameras shoot. Movie shooting is not supported.
For further instructions on [LinkedShot], refer to page 61 of this manual.
COPY

20
Selecting the Communication Method and LAN Type
For [LinkedShot] instructions, refer to page 61. Note that no information about
[LinkedShot] is given in this chapter.
Turn the <5> dial to select the type of LAN, and
then press <0>.
Select [OK] and press <0> to go to the next
screen.
Wireless LAN
The [Wireless LAN setup method] screen is
displayed.
[Connect with wizard]: See p.21
[WPS (PBC mode)]: See p.23
[WPS (PIN mode)]: See p.24
Select [WPS (PBC mode)] or [WPS (PIN mode)]
when using a wireless LAN terminal compatible with
Wi-Fi Protected Setup (WPS).
Wired LAN
The [Network] settings screen is displayed. If you have selected a wired network, refer to page
25, “Configuring Network Settings.”
Use a Category 5 or higher STP LAN cable. (STP: Shielded Twisted Pair)
Selecting the LAN Type
COPY
