Canon WFT-E7 User manual

INSTRUCTION MANUAL
E
Wireless File Transmitter
for EOS 5D Mark IV
WFT-E7 (Ver.2)
This manual is for the WFT-E7 (Ver.2) installed with firmware version 1.3.0
or later.

2
The transmitter is an accessory for EOS cameras that enables LAN
functions to be used when attached to the camera.
Using the transmitter’s LAN functions enables you to do the following:
Introduction
What You Can Do with the Transmitter
Use EOS Utility to shoot, view, and
download images remotely
FTP Transfer
WFT Server
Linked Shooting
Transfer images to an FTP server
Wirelessly trigger shooting by reciever
cameras linked to a sender camera
Synchronize time between the same
camera models
Use a web browser to shoot, view, and
download images remotely
EOS Utility
Sync the Camera Time

3
To comply with local radio wave regulations, Canon offers five
region-specific versions of the transmitter (A, B, C, D, and E) in
various areas around the world (see separate sheet). For
convenience, the product in this manual is referred to as “WFT-E7
(Ver.2)”, without reference to the versions A, B, C, D, or E.
In this manual, the term “access point” indicates wireless LAN
access points, wireless LAN routers, etc. that relay a LAN
connection.
These instructions should be followed only after setting up your LAN
and FTP server environments. For information about setting up the
environments, refer to the documentation provided with each device
or contact the manufacturer.
Read the Camera Instruction Manual and familiarize yourself with
operating the camera before following the instructions on camera
options.
Icons in this Manual
<6> : Indicates the Main Dial.
<5> : Indicates the Quick Control Dial.
<9> : Indicates the Multi-controller.
<0> : Indicates the Setting button.
* In addition to the above, the icons and symbols used on the camera’s buttons
and displayed on the LCD monitor are also used in this manual when discussing
relevant operations and functionality.
(p.**) : Reference page numbers for more information.
: Warnings to prevent potential problems during operation.
: Supplemental information.
Conventions Used in this Manual

4
Conventions Used in this Manual
Basic Assumptions
All operations explained in this manual assume that the power
switch is set to <1>.
It is assumed that all the menu settings, Custom Functions, etc. are
set to their defaults.
Image transfer, remote shooting, or image viewing requires adequate
knowledge of configuring your LAN and FTP server. Canon cannot provide
support for configuring LANs or FTP servers.
Note that Canon cannot be held liable for any loss or damage to the
transmitter from erroneous network or FTP server settings. In addition,
Canon cannot be held liable for any other loss or damage caused by use of
the transmitter.
When using LAN functions, establish appropriate security at your own risk
and discretion. Canon cannot be held liable for any loss or damage caused
by unauthorized access or other security breaches.

5
Chapter List
Introduction 2
Basic Network Settings 17
Transferring Images to an FTP Server 33
Operating Remotely Using EOS Utility 51
Operating Remotely Using WFT Server 55
Linked Shooting 71
Synchronizing the Camera Time 85
Terminating the Connection and Reconnecting 91
Checking and Operating Connection Settings 95
Troubleshooting Guide 107
Reference 129
1
2
3
4
5
6
7
8
9
10

6
2
1
3
4
Introduction 2
Conventions Used in this Manual..................................................... 3
Chapter List ...................................................................................... 5
Safety Precautions ........................................................................... 8
Nomenclature ................................................................................. 10
Installing and Removing the Battery............................................... 12
Using a Household Power Outlet ................................................... 14
Attaching to the Camera................................................................. 15
Basic Network Settings 17
Preparation..................................................................................... 18
Displaying the Connection Wizard ................................................. 21
Checking the Type of Access Point................................................ 23
Connecting via WPS (PBC Mode).................................................. 24
Connecting via WPS (PIN Mode) ................................................... 25
Connecting to a Detected Network Manually ................................. 27
Setting the IP Address.................................................................... 30
Transferring Images to an FTP Server 33
Configuring FTP Server Connection Settings ................................ 34
Transferring Images Individually..................................................... 39
Batch Transfer ................................................................................ 44
Transferring Images with a Caption................................................ 48
Viewing Transferred Images........................................................... 49
Operating Remotely Using EOS Utility 51
Configuring EOS Utility Connection Settings ................................. 52
Using EOS Utility............................................................................ 54
Operating Remotely Using WFT Server 55
Configuring WFT Server Connection Settings ............................... 56
Displaying WFT Server .................................................................. 58
Viewing Images .............................................................................. 61
Shooting Remotely [Camera control] ............................................. 63
Shooting Remotely [Simple control] ............................................... 68
Using WFT Server in Linked Shooting ........................................... 70
Contents

7
Contents
10
6
9
7
8
5Linked Shooting 71
Basic Linked Shooting ....................................................................72
Positioning the Cameras.................................................................76
Using the Transmitter with WFT Server .......................................... 78
Synchronizing the Camera Time 85
Preparing for Time Synchronization................................................86
Synchronizing the Time...................................................................87
Terminating the Connection and Reconnecting 91
Terminating the Connection ............................................................92
Reconnecting .................................................................................. 93
Checking and Operating Connection Settings 95
Displaying the Connection Settings Screen....................................96
Changing Settings...........................................................................98
Saving and Loading Settings ........................................................102
Function Settings Screen..............................................................104
Troubleshooting Guide 107
Responding to Error Messages ....................................................108
Wireless Function Notes ...............................................................125
Security ......................................................................................... 127
Checking Network Settings...........................................................128
Reference 129
Creating and Registering Captions ...............................................130
Setting IP Address Manually.........................................................132
Using a Bracket (Sold Separately)................................................134
Specifications ................................................................................ 135
Index .............................................................................................139

8
The following precautions are provided to prevent harm or injury to
yourself and others. Make sure to thoroughly understand and follow
these precautions before using the product.
If you experience any malfunctions, problems, or damage to the
product, contact the nearest Canon Service Center or the dealer
from whom you purchased the product.
Safety Precautions
Warnings: Follow the warnings below. Otherwise, death or
serious injuries may result.
To prevent fire, excessive heat, chemical leakage, explosions, and electrical shock,
follow the safeguards below.
• Do not insert any foreign metallic objects into the electrical contacts of the
equipment, accessories, or connecting cables.
Do not use the equipment where there is flammable gas. There is a risk of explosion
or fire.
If you drop the equipment and the casing breaks open to expose the internal parts,
do not touch the exposed parts. There is a possibility of electrical shock.
Do not disassemble or modify the equipment. High-voltage internal parts may cause
electrical shock.
Do not store the equipment in dusty or humid places. This is to prevent fire or
electrical shock.
Before using the equipment on board airplanes or in hospitals, make sure use is
permitted. Electromagnetic waves emitted by the equipment may interfere with
instrumentation or medical equipment.
Do not hold the camera in the same position for long periods of time. Even if the
camera does not feel too hot, prolonged contact with the same body part may cause
skin redness or blistering due to low-temperature contact burns. Using a tripod is
recommended for people with circulation problems or very sensitive skin, or when
using the camera in very hot places.
Cautions: Follow the cautions below. Otherwise, physical injury
or property damage may result.
Do not leave the equipment in a hot car interior or near high-temperature objects.
The equipment may become hot and cause burns if touched.
Do not leave the product in a low-temperature environment for an extended period of
time. The equipment will become cold and may cause injury when touched.
Do not cover or wrap the transmitter with a cloth. This may trap heat inside, posing a
risk of fire.
Do not use paint thinner, benzene, or other organic solvents to clean the transmitter.
This poses a risk of fire and may be hazardous to your health.

9
Safety Precautions
The transmitter is a precision instrument. Do not drop it or subject it to
physical shock.
The transmitter is not waterproof. Do not use it underwater.
Wipe off any moisture with a dry and clean cloth. If the transmitter has been
exposed to salty air, wipe it with a clean, well-wrung wet cloth.
Never leave the transmitter near any equipment that generates a strong
magnetic field, such as magnets or electric motors.
Do not leave the transmitter in excessive heat, such as in a vehicle in direct
sunlight. High temperatures may damage the transmitter.
Do not wipe the transmitter using cleaners containing organic solvents. For
stubborn dirt, take it to the nearest Canon Service Center.
Avoid storing the transmitter where there are chemicals that result in rust
and corrosion such as in a chemical lab.
Handling Precautions

10
LCD panel
* Bluetooth connectivity is not supported on the EOS 5D Mark IV.
Nomenclature
Battery compartment
cover (p.12)
Battery compartment
cover release lever
(p.12)
Power lamp
(p.15)
<
LAN > lamp
LCD panel
Power switch (p.15)
Tripod screw
<a> port (p.15) Ethernet RJ-45 port
Error code number
Wireless signal strength
Battery check
Connection icon
Wired LAN
connection
Bluetooth connection*

11
Nomenclature
Case and other accessories
Interface cables
Strap mounts
Belt holder
Case strap Case for tripod screw
Cap for preventing
cable disconnection
IFC-150AB II
(Approx. 1.5 m / 4.9 ft.)
IFC-40AB II
(Approx. 40 cm / 15.7 in.)
For use with the EOS 5D Mark IV
USB 3.0
(Micro-B)
IFC-150AB
(Approx. 1.5 m / 4.9 ft.)
IFC-25AB
(Approx. 25 cm / 9.8 in.)
For use with cameras equipped with a mini USB 2.0 (Mini-B) terminal
(Not for use with the EOS 5D Mark IV)
USB 2.0
(Mini-B)

12
Use one Battery Pack LP-E6N (or LP-E6) to power the transmitter.
When replacing the transmitter’s battery, be sure to turn the transmitter
off before opening the battery compartment cover.
Also note that the transmitter is not sold with a battery or charger. If you
do not own these accessories, they are available for purchase
separately.
1Open the cover.
Push the lever down and open the
cover.
2Insert the battery.
Insert the end with the battery
contacts.
Insert the battery all the way until it
locks into place.
3Close the cover.
Press the cover up until it clicks into
place.
Installing and Removing the Battery
Installing the Battery

13
Installing and Removing the Battery
The remaining battery level is displayed when you turn the transmitter
on. A blinking battery icon (b) indicates that the battery will be
depleted soon.
1Open the cover.
Push the lever down and open the
cover.
2Remove the battery.
Press the battery lock lever in the
direction of the arrow to unlock, and
then remove the battery.
To prevent a short-circuit, be sure to
always attach the protective cover to
the battery.
Battery Check
Icon zxcm
bn
Level (%) 100 – 70 69 – 50 49 – 20 19 – 10 9 – 1 0
Removing the Battery

14
You can power the transmitter with a household power outlet by using
the DC Coupler DR-E6 and AC Adapter AC-E6N (each sold
separately).
1Insert the DC coupler.
Open the battery compartment cover
and open the DC coupler cord hole
cover.
Insert the DC coupler securely until it
locks and put the cord through the
hole.
Close the cover.
2Connect the DC coupler’s plug.
Connect the DC coupler’s plug and
the AC adapter’s connector securely.
3Connect the power cord.
Connect the power cord as shown in
the illustration.
After using the camera, unplug the
power plug from the power outlet.
Using a Household Power Outlet
DC coupler cord hole
Do not connect or disconnect the power cord or DC coupler while leaving
the transmitter’s power switch set to the <1> position.
Do not connect both the transmitter and camera to a household power
outlet and use them simultaneously. It may cause malfunction to the
nearby electronic devices. For more information, contact your dealer or
nearest Canon Service Center.
AC Adapter Kit ACK-E6 (sold separately) can also be used.

15
When connecting the transmitter to the camera, always use one of the
interface cables included with the transmitter.
1Turn off both the transmitter and
camera.
2Attach the transmitter’s
<a> port cap.
Attach the cap for preventing cable
disconnection.
3Connect the transmitter and
camera.
For the interface cable, use either
IFC-40AB II or IFC-150AB II.
Attach the cable protector to the
camera and run the cable through the
clamp.
For cable protector instructions, refer
to the camera instruction manual.
4Turn on both the transmitter and
camera.
The transmitter’s <3> lamp will
light and <D> will be displayed on
the transmitter’s LCD panel.
Attaching to the Camera
GPS
WFT
CAMERA

16
Attaching to the Camera
Connect the transmitter to the camera using IFC-150AB II.
Example of Using the Case and Strap
Before disconnecting the cable, turn off both the transmitter and camera.
If you turn on/off the transmitter or connect/disconnect the interface
cable during Live View shooting or movie shooting, Live View shooting or
movie shooting will stop.
If wireless functions are in use, noise may be recorded regardless of the
use of the built-in microphone(s) or an external microphone. It is
recommended that you do not use wireless functions when shooting
movies.
If the transmitter’s <3> lamp blinks, it means that the transmitter and
camera are not properly connected. Check the connection.

17
1
Basic Network Settings
Complete the basic network settings by using the menu
screen on the camera’s LCD monitor.

18
[FTP trans.]
You can transfer captured images to an FTP server.
Images can be automatically transferred as you shoot them, or you
can select images to be transferred later.
Computer Operating Systems
Use of [FTP trans.] requires that one of the following operating
systems be installed on a computer. In addition, the computer must
be set up as an FTP server in advance.
• Windows 10 (ver. 1607 or later)
• Windows 8.1, Windows 8.1 Pro
For instructions on setting up a computer as an FTP server, refer to
the documentation provided with each device or contact the
manufacturer.
Preparation

19
Preparation
[EOSUtility]
You can perform remote shooting over a LAN using EOS Utility
(EOS software).
In addition to remote shooting, almost all EOS Utility camera
operations are supported, because this option utilizes a LAN instead
of an interface cable.
Requires a computer with EOS Utility (EOS software) installed.
[WFTserver]
You can perform advanced remote shooting or view images stored
in the camera by connecting to the transmitter from a web browser
on a computer, smartphone, or other device, as easily as accessing
a Web site.
Browsers
The following operating systems and web browsers have been
confirmed to be compatible with the transmitter. Depending on your
environment, operation may differ.
Windows 8.1, Windows 7: Google Chrome Ver. 44
Windows 8.1, Windows 7: Internet Explorer 11
OS X (operating system version 10.10): Safari Ver. 8.0
iOS (operating system version 8.4): Safari
Android (operating system version 4.4): Google Chrome
* Operation on the above operating systems and web browsers cannot be
guaranteed for all the terminals.
* Not available unless the web browser is set to allow cookies.
* Not available unless the web browser is set to use JavaScript.
* Movies cannot be played back unless the web browser supports HTML 5.

20
Preparation
[LinkedShot]
You can perform linked shooting using multiple compatible cameras
with WFT series transmitters attached. This feature lets you link up
to 10 reciever cameras to the sender camera on which you will
release the shutter. Note that there will be a slight delay after you
release the sender camera shutter before the reciever cameras
shoot. Movie shooting is not supported.
For subsequent operations, see page 71.
[Sync time between cameras]
You can set the sender camera time on up to 10 reciever cameras.
Note that even after synchronization, there will be a margin of error
between sender and reciever camera times.
Set up multiple cameras of the same camera model with WFT-E7
series transmitters attached.
For subsequent operations, see page 85.
When connecting using an access point, connect the target device to
the access point in advance.
Connecting Using an Access Point
Transfer of Movies over Wireless LAN
Because of the large size of individual movie files, wireless LAN file
transmission takes some time. Set up an environment where each device
can achieve stable communication with the access point and the transmitter
by referring to the information on page 125.
