Dishwasher
Instruction Manual
DI652

Instruction manual DI6522Please keep this instruction manual for future reference
CONTENTS
Warnings 3
Warranty 8
Product Overview 9
Control Panel 9
Dishwasher Features 12
Prior to Using Your Dishwasher for the First Time 13
Filling the Rinse Aid Dispenser 16
Filling the Detergent Dispenser 18
Preparing and Loading Dishes 19
Loading the Baskets 26
Programming the Dishwasher 28
Maintenance and Cleaning 30
Caring for the Dishwasher 33
Installation Instructions 34
Water Supply and Drain 35
Connection of Drain Hoses 36
Position the Appliance 37
Free Standing Installation 37
Built-In Installation 38
Troubleshooting Tips 42
Error Codes 44
Technical Information 45
Product Fiche 46
Caple Contact Details 48

Instruction manual DI652 3
Please keep this instruction manual for future reference
SAFETY INSTRUCTIONS
Read carefully all the instructions contained in this
manual. It provides you with important information
regarding the safe installation, use and maintenance of
the appliance as well as useful advice for getting the best
out of your dishwasher. Keep this booklet in a safe place
for future reference. After removing the packing, check
that the appliance is not damaged in any way.
Be careful not to leave the packing materials (plastic
sheeting, expanded polystyrene etc.) where children can
get at them, as they can be dangerous.
WARNINGS:
-Installation and repair can only be carried out by a
qualified technician.
-This product is not designed for commercial use, it is a
household appliance only. It is not intended to be
used in:
• Staff kitchen areas in shops, offices and other working
environments.
• Bed and breakfast type environments.
• By clients in hotels, motels and other residential type
environments.
-Packaging material could be dangerous for children.
-This appliance is for indoor household use only.
-To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.

Instruction manual DI6524Please keep this instruction manual for future reference
-This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
-Please unplug before cleaning or performing
maintenance on the appliance.
-Use a slightly moistened soft cloth with mild soap, and
then use a dry cloth to wipe it again.
-This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the risk
of an electric shock by providing a path of less resistance
of electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and a
grounding plug.
-The plug must be plugged into an appropriate outlet
that is installed and earthed in accordance with all local
codes and regulations.
-Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.

Instruction manual DI652 5
Please keep this instruction manual for future reference
-Check with a qualified electrician or Caple service
representative if you are in doubt whether the appliance
is properly grounded.
-Do not modify the plug provided with the appliance,
if it does not fit the outlet.
-Have a proper outlet installed by a qualified electrician.
-Do not abuse, sit on, or stand on the door or dish rack of
the dishwasher.
-Do not operate your dishwasher unless all enclosure
panels are properly in place.
-Open the door very carefully when the dishwasher is
operating, there is a risk of water squirting out.
-Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
-When loading items to be washed:
• Locate sharp items so that they are not likely to
damage the door seal.
• Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points down or
placed in a horizontal position.
-Check that the detergent powder is empty after
completion of the wash cycle.
-Some dishwasher detergents are strongly alkaline. They
can be extremely dangerous if swallowed. Avoid contact
with the skin and eyes and keep children away from the
dishwasher when the door is open.
-Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.

Instruction manual DI6526Please keep this instruction manual for future reference
-For plastic items not marked, check the
manufacturer’s recommendations.
-Use only detergent and rinse additives designed for an
automatic dishwasher.
-Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
-The door should not be left open, since this could
increase the risk of tripping.
-If the supply cord is damaged, it must be replaced by
Caple, its service agent or a similarly qualified person in
order to avoid a hazard.
-During installation, the power supply must not be
excessively or dangerously bent or flattened.
-Do not tamper with controls.
-The appliance is to be connected to the water mains
using new hose sets and that old hose-sets should not
be reused.
-The maximum number of place settings to be washed
is 14.
-The maximum permissible inlet water pressure is 1MPa.
-The minimum permissible inlet water pressure
is 0.04MPa.
-Children should be supervised to ensure that they do not
play with the appliance.
-The dishwasher must not be installed under a hob.

Instruction manual DI652 7
Please keep this instruction manual for future reference
WARNINGS:
-Packaging material could be dangerous for children.
-For disposing of package and the appliance please go
to a recycling centre. Therefore cut off the power supply
cable and make the door closing device unusable.
-Cardboard packaging is manufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
-By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the
environment and human health, which could otherwise
be caused by inappropriate waste handling of
this product.
-For more detailed information about recycling of this
product, please contact your local council office and your
household waste disposal service.
-DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately for
special treatment is necessary.

Instruction manual DI6528Please keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European Directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
WARRANTY:
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date
of purchase, model and serial number (placed on the inside of the appliance storage drawer).
Registration can also be completed online by visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase.
If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.

Instruction manual DI652 9
Please keep this instruction manual for future reference
PRODUCT OVERVIEW
CONTROL PANNEL
USING YOUR DISHWASHER
Control Panel
Operation (Button)
Power
Delay -/+
Function
Press the button to turn on your dishwasher,the screen lights up.
Press the “+”button to add the delay time or press the “-”button
to decrease the delay time, maximum 24 hours delay can be
defined.
Press the button to select a function, corresponding indicator will
be lit.
4
1
3
4
Alt Press the button to select either upper basket or lower basket
loaded, and the response indicators will be lit.
5
2 31
6 87 7 9 10
4 5
Program Press the “ ” or “ ” button to select a program, and the
corresponding indicator will be lit.
2
BUTTON OPERATION
1POWER Press the button to turn on your dishwasher, the screen lights up.
2PROGRAM Press the “ ” or “ ” button to select a program, and the corresponding indicator
will be lit.
3DELAY +/ - Press the “+”button to add the delay time or press the “-”button to decrease the delay
time, maximum 24 hours delay can be defined.
4FUNCTION Press the button to select a function, corresponding indicator will be lit.
5ALT Press the button to select either upper basket or lower basket loaded, and the response
indicators will be lit.
Water Softener
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which
would have a detrimental or adverse effect on the operation of the appliance.
The more minerals there are, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area.
Your local Water Authority can advise you on the hardness of the water in your area.
Adjusting salt consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed
based on the hardness of the water used. This is intended to optimise and customise
the level of salt consumption.
1. Open the door and switch on the appliance
2. P Program “ ”
3. Program
“ ”
4. Without operation in 5 seconds or press the Power button to complete the setup
and exit the setup mode.
;
ress the button for more than 5 seconds to start the water softener
set model within 60 seconds after the appliance was switched on;
Press the button to select the proper set according to your local
environment, the sets will change in the following sequence:
H3->H4->H5->H6->H1->H2->H3;
Please follow the steps below for adjustment in salt consumption.
dH=1.25 Clarke=1.78 fH=0.178mmol/l
°° °
1
The manufactory setting: H3
Contact your local water board for information on the hardness of your water supply.
0 - 5
6 - 11
12 - 17
18 - 22
23 - 34
35 - 55
German
dH
Salt consumption
(gram/cycle)
0 - 9
10 - 20
21 - 30
31 - 40
41 - 60
61 - 98
0 - 6
7 - 14
15 - 21
22 - 28
29 - 42
43 - 69
0 - 0.94
1.0 - 2.0
2.1 - 3.0
3.1 - 4.0
4.1 - 6.0
6.1 - 9.8
H1
H2
H3
H4
H5
H6
0
9
12
20
30
60
French
fH Mmol/l
Water softener level
British
Clarke
WATER HARDNESS
7
Water Softener
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which
would have a detrimental or adverse effect on the operation of the appliance.
The more minerals there are, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area.
Your local Water Authority can advise you on the hardness of the water in your area.
Adjusting salt consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed
based on the hardness of the water used. This is intended to optimise and customise
the level of salt consumption.
1. Open the door and switch on the appliance
2. P Program “ ”
3. Program
“ ”
4. Without operation in 5 seconds or press the Power button to complete the setup
and exit the setup mode.
;
ress the button for more than 5 seconds to start the water softener
set model within 60 seconds after the appliance was switched on;
Press the button to select the proper set according to your local
environment, the sets will change in the following sequence:
H3->H4->H5->H6->H1->H2->H3;
Please follow the steps below for adjustment in salt consumption.
dH=1.25 Clarke=1.78 fH=0.178mmol/l
°° °
1
The manufactory setting: H3
Contact your local water board for information on the hardness of your water supply.
0 - 5
6 - 11
12 - 17
18 - 22
23 - 34
35 - 55
German
dH
Salt consumption
(gram/cycle)
0 - 9
10 - 20
21 - 30
31 - 40
41 - 60
61 - 98
0 - 6
7 - 14
15 - 21
22 - 28
29 - 42
43 - 69
0 - 0.94
1.0 - 2.0
2.1 - 3.0
3.1 - 4.0
4.1 - 6.0
6.1 - 9.8
H1
H2
H3
H4
H5
H6
0
9
12
20
30
60
French
fH Mmol/l
Water softener level
British
Clarke
WATER HARDNESS
7

Instruction manual DI65210 Please keep this instruction manual for future reference
BUTTON OPERATION
6
PROGRAM
INDICATOR
A U TO
For lightly, normally or heavily soiled crockery with or without dried-on food.
HYGIENE With the sanitise option selected, the water temperature is increased to 70˚C for high
temperature sanitisation.
NORMAL
For normally soiled loads, such as pots, plates, glasses and lightly soiled pans.
ECO This is a standard program, and is suitable to clean normally soiled tableware and is the
most efficient program in terms of its combined energy and water consumption for that
type of tableware.
GLASS
For lightly soiled crockery and glass.
90 MIN
For normally soiled loads that need quick wash.
PARTY
For lightly soiled loads, such as glasses, crystal and fine china.
SELF-CLEANING
This program provides an effective cleaning of the dishwasher itself.
7
WARNING
INDICATOR
RINSE AID
If the “ “ indicator is lit, it means the dishwasher is low on dishwasher rinse aid and
requires a refill.
SALT
If the “ ” indicator is lit, it means the dishwasher is low on dishwasher salt and
needs to be refilled.
WATER FAUCET
If the “ ” indicator is lit, it means the water faucet is closed.
8
SCREEN To show the remaining time and delay time, error codes etc.
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “
” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal
Water Faucet
Salt
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
5
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption for
that type of tableware.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
Party
For lightly soiled loads, such as glasses, crystal and fine
china.
Self-Cleaning
This program provides an effective cleaning of the
dishwasher itself.
Program
indicator
6
If the “ ” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
Warning
indicator
7
If the “ ” indicator is lit, it means the water faucet
closed.
Auto
For lightly, normally or heavily soiled crockery with or
without dried-on food.
Hygiene
With the anitize option selected, the water temperature is
increased to 70 ˚C for high temperature sanitization.
s
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Normal

Instruction manual DI652 11
Please keep this instruction manual for future reference
BUTTON OPERATION
9
FUNCTION
INDICATOR
EXTRA
CLEANING To wash very dirty, hard to clean dishes.
(This can only be used with Hygiene, Normal, ECO, Glass, 90 min).
EXTRA DRYING
To dry dishes more thoroughly. (It can only be used with Hygiene, Normal, ECO, Glass,
90 min)
EXPRESS
Reduce the program time.
(It can only be used with Hygiene, Normal, ECO, Glass, 90 min)
ENERGY SAVE
When you have less plates to wash.
(It can only be used with Normal, ECO, Glass, 90 min )
10
A LT
INDICATOR
UPPER
When you select Upper, only the upper rack nozzle is activated. The lower nozzle will
not operate.
LOWER
When you select Lower, only the lower rack nozzle is activated. The upper nozzle will
not operate.
NOTE:
Indicator Lamp Function:
The Indicator lamp will be lit up during
the washing program, then blink for 5
minutes and turn off at end of
the program.
Function
indicator
9
Energy Save
When you have less plates to wash ,you can choose it.
( It can only be used with Normal, ECO, Glass, 90 min )
6
Upper
Lower
When you select Lower, only the lower rack nozzle is
activated. The upper nozzle will not operate.
When you select Upper, only the upper rack nozzle is
activated. The lower nozzle will not operate.
Alt
indicator
10
Screen
8To show the reminding time and delay time, error codes etc.
Extra Cleaning
To wash very dirty, hard to clean dishes. ( It can only be
used with Hygiene, Normal, ECO, Glass, 90 min )
Extra Drying
To dry dishes more completely. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
Express
Reduce the program time. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
NOTE:
The Indicator lamp will be lit up during
the washing program, then blink for
5 minutes and extinguished on the end
of the program.
Indicator lamp function
Function
indicator
9
Energy Save
When you have less plates to wash ,you can choose it.
( It can only be used with Normal, ECO, Glass, 90 min )
6
Upper
Lower
When you select Lower, only the lower rack nozzle is
activated. The upper nozzle will not operate.
When you select Upper, only the upper rack nozzle is
activated. The lower nozzle will not operate.
Alt
indicator
10
Screen
8To show the reminding time and delay time, error codes etc.
Extra Cleaning
To wash very dirty, hard to clean dishes. ( It can only be
used with Hygiene, Normal, ECO, Glass, 90 min )
Extra Drying
To dry dishes more completely. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
Express
Reduce the program time. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
NOTE:
The Indicator lamp will be lit up during
the washing program, then blink for
5 minutes and extinguished on the end
of the program.
Indicator lamp function
Function
indicator
9
Energy Save
When you have less plates to wash ,you can choose it.
( It can only be used with Normal, ECO, Glass, 90 min )
6
Upper
Lower
When you select Lower, only the lower rack nozzle is
activated. The upper nozzle will not operate.
When you select Upper, only the upper rack nozzle is
activated. The lower nozzle will not operate.
Alt
indicator
10
Screen
8To show the reminding time and delay time, error codes etc.
Extra Cleaning
To wash very dirty, hard to clean dishes. ( It can only be
used with Hygiene, Normal, ECO, Glass, 90 min )
Extra Drying
To dry dishes more completely. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
Express
Reduce the program time. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
NOTE:
The Indicator lamp will be lit up during
the washing program, then blink for
5 minutes and extinguished on the end
of the program.
Indicator lamp function
Function
indicator
9
Energy Save
When you have less plates to wash ,you can choose it.
( It can only be used with Normal, ECO, Glass, 90 min )
6
Upper
Lower
When you select Lower, only the lower rack nozzle is
activated. The upper nozzle will not operate.
When you select Upper, only the upper rack nozzle is
activated. The lower nozzle will not operate.
Alt
indicator
10
Screen
8To show the reminding time and delay time, error codes etc.
Extra Cleaning
To wash very dirty, hard to clean dishes. ( It can only be
used with Hygiene, Normal, ECO, Glass, 90 min )
Extra Drying
To dry dishes more completely. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
Express
Reduce the program time. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
NOTE:
The Indicator lamp will be lit up during
the washing program, then blink for
5 minutes and extinguished on the end
of the program.
Indicator lamp function
Function
indicator
9
Energy Save
When you have less plates to wash ,you can choose it.
( It can only be used with Normal, ECO, Glass, 90 min )
6
Upper
Lower
When you select Lower, only the lower rack nozzle is
activated. The upper nozzle will not operate.
When you select Upper, only the upper rack nozzle is
activated. The lower nozzle will not operate.
Alt
indicator
10
Screen
8To show the reminding time and delay time, error codes etc.
Extra Cleaning
To wash very dirty, hard to clean dishes. ( It can only be
used with Hygiene, Normal, ECO, Glass, 90 min )
Extra Drying
To dry dishes more completely. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
Express
Reduce the program time. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
NOTE:
The Indicator lamp will be lit up during
the washing program, then blink for
5 minutes and extinguished on the end
of the program.
Indicator lamp function
Function
indicator
9
Energy Save
When you have less plates to wash ,you can choose it.
( It can only be used with Normal, ECO, Glass, 90 min )
6
Upper
Lower
When you select Lower, only the lower rack nozzle is
activated. The upper nozzle will not operate.
When you select Upper, only the upper rack nozzle is
activated. The lower nozzle will not operate.
Alt
indicator
10
Screen
8To show the reminding time and delay time, error codes etc.
Extra Cleaning
To wash very dirty, hard to clean dishes. ( It can only be
used with Hygiene, Normal, ECO, Glass, 90 min )
Extra Drying
To dry dishes more completely. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
Express
Reduce the program time. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
NOTE:
The Indicator lamp will be lit up during
the washing program, then blink for
5 minutes and extinguished on the end
of the program.
Indicator lamp function
Function
indicator
9
Energy Save
When you have less plates to wash ,you can choose it.
( It can only be used with Normal, ECO, Glass, 90 min )
6
Upper
Lower
When you select Lower, only the lower rack nozzle is
activated. The upper nozzle will not operate.
When you select Upper, only the upper rack nozzle is
activated. The lower nozzle will not operate.
Alt
indicator
10
Screen
8To show the reminding time and delay time, error codes etc.
Extra Cleaning
To wash very dirty, hard to clean dishes. ( It can only be
used with Hygiene, Normal, ECO, Glass, 90 min )
Extra Drying
To dry dishes more completely. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
Express
Reduce the program time. ( It can only be used with
Hygiene, Normal, ECO, Glass, 90 min )
NOTE:
The Indicator lamp will be lit up during
the washing program, then blink for
5 minutes and extinguished on the end
of the program.
Indicator lamp function

Instruction manual DI65212 Please keep this instruction manual for future reference
DISHWASHER FEATURES
IMPORTANT:
To get the best performance from your dishwasher, read all operating instructions before using it
8
PRODUCT OVERVIEW
To get the best performance from your dishwasher, read all operating instructions
before using it for the first time.
IMPORTANT:
Top spray arm
Dispenser
Lower spray arm Filter
Assembly
Inner pipe
The breakthrough innovative spray arm uses two
separate rotating axes to maximize water spray to all
corners of the dishwasher, ensuring every item receives
an exceptional clean.
360°Water spray system
Salt container
Cutlery Rack Upper spray arm Cup rack
Upper Basket
Lower Basket
8
PRODUCT OVERVIEW
To get the best performance from your dishwasher, read all operating instructions
before using it for the first time.
IMPORTANT:
Top spray arm
Dispenser
Lower spray arm Filter
Assembly
Inner pipe
The breakthrough innovative spray arm uses two
separate rotating axes to maximize water spray to all
corners of the dishwasher, ensuring every item receives
an exceptional clean.
360°Water spray system
Salt container
Cutlery Rack Upper spray arm Cup rack
Upper Basket
Lower Basket
360° WATER SPRAY SYSTEM
The breakthrough innovative spray arm uses two separate rotating
axes to maximise water spray to all corners of the dishwasher,
ensuring every item receives an exceptional clean.

Instruction manual DI652 13
Please keep this instruction manual for future reference
PRIOR TO USING YOUR DISHWASHER FOR THE FIRST TIME:
Before using your dishwasher:
1. Set the water softener
2. Load the salt Into the softener
3. Load the basket
4. Fill the dispenser
WATER SOFTENER
The water softener must be set manually, using the water hardness dial. The water softener is
designed to remove minerals and salts from the water, which would have a detrimental or adverse
effect on the operation of the appliance.
The more minerals there are, the harder your water is. The softener should be adjusted according
to the hardness of the water in your area. Your local Water Authority can advise you on the
hardness of the water in your area.
The hardness of the water varies from place to place. If hard water is used in the dishwasher,
deposits will form on the dishes and utensils.
The appliance is equipped with a special softener that uses a salt container specifically designed to
eliminate lime and minerals from the water.
Loading The Salt Into The Softener
Only use salt specifically designed for dishwashers use!
Every other type of salt not specifically designed for dishwasher use,
especially table salt, will damage the water softener. In case of damages
caused by the use of unsuitable salt the manufacturer does not give any
warranty nor is liable for any damages caused.
Only fill with salt before running a cycle.
This will prevent any grains of salt or salty water, which may have been
spilled, remaining on the bottom of the machine for any period of time,
which may cause corrosion.
WARNING
Always use salt intended for dishwasher use.
The salt container is located beneath the lower basket and should be filled as
explained in the following:
Please check the section 1 “Water Softener” of PART Ⅱ: Special Version,
If you need to set the water softener .
9
If your model does not have any water softener, you may skip this section.
NOTE:
USING YOUR DISHWASHER
Before using your dishwasher :
Inside Outside
1. Set the water softener
2. Loading the salt Into the softener
3. Loading the basket
4. Fill the dispenser

Instruction manual DI65214 Please keep this instruction manual for future reference
ADJUSTING SALT CONSUMPTION:
The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the
hardness of the water used. This is intended to optimise and customise the level of
salt consumption.
Please follow the steps below for adjustment in salt consumption:
1. Open the door and switch on the appliance;
2. Press and hold the Program button “ “ for more than 5 seconds to start the water softener
setting within 60 seconds of the appliance being switched on;
3. Press the program button “ ” to select the proper set according to your local environment,
the sets will change in the following sequence: H3->H4->H5->H6->H1->H2->H3;H3
4. No operation in 5 seconds or pressing the Power button will complete the setup and exit the
setup mode.
Water Softener
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which
would have a detrimental or adverse effect on the operation of the appliance.
The more minerals there are, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area.
Your local Water Authority can advise you on the hardness of the water in your area.
Adjusting salt consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed
based on the hardness of the water used. This is intended to optimise and customise
the level of salt consumption.
1. Open the door and switch on the appliance
2. P Program “ ”
3. Program
“ ”
4. Without operation in 5 seconds or press the Power button to complete the setup
and exit the setup mode.
;
ress the button for more than 5 seconds to start the water softener
set model within 60 seconds after the appliance was switched on;
Press the button to select the proper set according to your local
environment, the sets will change in the following sequence:
H3->H4->H5->H6->H1->H2->H3;
Please follow the steps below for adjustment in salt consumption.
dH=1.25 Clarke=1.78 fH=0.178mmol/l
°° °
1
The manufactory setting: H3
Contact your local water board for information on the hardness of your water supply.
0 - 5
6 - 11
12 - 17
18 - 22
23 - 34
35 - 55
German
dH
Salt consumption
(gram/cycle)
0 - 9
10 - 20
21 - 30
31 - 40
41 - 60
61 - 98
0 - 6
7 - 14
15 - 21
22 - 28
29 - 42
43 - 69
0 - 0.94
1.0 - 2.0
2.1 - 3.0
3.1 - 4.0
4.1 - 6.0
6.1 - 9.8
H1
H2
H3
H4
H5
H6
0
9
12
20
30
60
French
fH Mmol/l
Water softener level
British
Clarke
WATER HARDNESS
7
Water Softener
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which
would have a detrimental or adverse effect on the operation of the appliance.
The more minerals there are, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area.
Your local Water Authority can advise you on the hardness of the water in your area.
Adjusting salt consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed
based on the hardness of the water used. This is intended to optimise and customise
the level of salt consumption.
1. Open the door and switch on the appliance
2. P Program “ ”
3. Program
“ ”
4. Without operation in 5 seconds or press the Power button to complete the setup
and exit the setup mode.
;
ress the button for more than 5 seconds to start the water softener
set model within 60 seconds after the appliance was switched on;
Press the button to select the proper set according to your local
environment, the sets will change in the following sequence:
H3->H4->H5->H6->H1->H2->H3;
Please follow the steps below for adjustment in salt consumption.
dH=1.25 Clarke=1.78 fH=0.178mmol/l
°° °
1
The manufactory setting: H3
Contact your local water board for information on the hardness of your water supply.
0 - 5
6 - 11
12 - 17
18 - 22
23 - 34
35 - 55
German
dH
Salt consumption
(gram/cycle)
0 - 9
10 - 20
21 - 30
31 - 40
41 - 60
61 - 98
0 - 6
7 - 14
15 - 21
22 - 28
29 - 42
43 - 69
0 - 0.94
1.0 - 2.0
2.1 - 3.0
3.1 - 4.0
4.1 - 6.0
6.1 - 9.8
H1
H2
H3
H4
H5
H6
0
9
12
20
30
60
French
fH Mmol/l
Water softener level
British
Clarke
WATER HARDNESS
7
WATER HARDNESS
WATER
SOFTENER LEVEL
SALT
CONSUMPTION
(GRAM/CYCLE)
GERMAN °DH FRENCH °FH BRITISH °CLARKE MMOL/L
0 - 5 0 - 9 0 - 6 0 - 0.94 H1 0
6 - 11 10 - 20 7 - 14 1.0 - 2.0 H2 9
12 - 17 21 - 30 15 - 21 2.1 - 3.0 H3 12
18 - 22 31 - 40 22 - 28 3.1 - 4.0 H4 20
23 - 34 41 - 60 29 - 42 4.1 - 6.0 H5 30
35 - 55 61 - 98 43 - 69 6.1 - 9.8 H6 60
1°dH=1.25 °Clarke=1.78 °fH=0.178mmol/l
The manufactory setting: H3
Contact your local water board for information on the hardness of your water supply.

Instruction manual DI652 15
Please keep this instruction manual for future reference
The salt container is located beneath the lower basket and should be filled as explained in
the following:
WARNING:
ONLY USE SALT SPECIFICALLY DESIGNED FOR DISHWASHERS USE:
Every other type of salt not specifically designed for dishwasher use, especially table salt,
will damage the water softener. In case of damages caused by the use of unsuitable salt the
manufacturer does not give any warranty nor is liable for any damages caused.
WARNING:
ONLY FILL WITH SALT BEFORE RUNNING A CYCLE
This will prevent any grains of salt or salty water, which may have been spilled, remaining on the
bottom of the machine for any period of time, which may cause corrosion.
Please follow the steps below for adding dishwasher salt:
1. Remove the lower basket and unscrew the reservoir cap.
2. Place the end of the funnel (supplied) into the hole and pour in about 1.5kg of
dishwasher salt.
3. Fill the salt container to its maximum limit with water, it is normal for a small amount of water
to come out of the salt container.
4. After filling the container, screw back the cap tightly. The salt warning light will turn off after
the salt container has been filled with salt.
5. Immediately after filling the salt container, a washing program should be started (we suggest
to use a short program). Otherwise the filter system, pump or other important parts of the
machine may be damaged by salty water. This is out of warranty.
10
1. Remove the lower basket and unscrew the reservoir cap.
2. Place the end of the funnel (supplied) into the hole and pour in about 1.5kg of
dishwasher salt.
3. Fill the salt container to its maximum limit with water, It is normal for a small
amount of water to come out of the salt container.
4. After filling the container, screw back the cap tightly.
5. The salt warning light will stop being after the salt container has been filled with salt.
6. Immediately after filling the salt into the salt container, a washing program should
be started (We suggest to use a short program). Otherwise the filter system, pump
or other important parts of the machine may be damaged by salty water. This is
out of warranty.
NOTE:
The salt container must only be refilled when the salt warning light ( ) in the
control panel comes on. Depending on how well the salt dissolves, the salt
warning light may still be on even though the salt container is filled.
If there is no salt warning light in the control panel (for some Models), you can
estimate when to fill the salt into the softener by the cycles that the dishwasher
has run.
If salt has spilled, run a soak or quick program to remove it.
Please follow the steps below for adding dishwasher salt:
LOADING THE SALT INTO THE SOFTENER
NOTE:
If your model does not have any water softener, you may skip this section.
Always use salt intended for dishwasher use.

Instruction manual DI65216 Please keep this instruction manual for future reference
FILLING THE RINSE AID DISPENSER
The rinse aid is released during the final rinse to prevent water from forming droplets on your
dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the
dishes. Your dishwasher is designed to use liquid rinse aids.
WARNING:
ONLY USE BRANDED RINSE AID FOR YOUR DISHWASHER. NEVER FILL THE RINSE
AID DISPENSER WITH ANY OTHER SUBSTANCES (E.G. DISHWASHER CLEANING
AGENT, LIQUID DETERGENT). THIS WILL DAMAGE THE APPLIANCE.
WHEN TO REFILL THE RINSE AID
The regularity of the dispenser needing to be refilled depends on how often dishes are washed
and the rinse aid setting used.
»The Low Rinse Aid indicator ( ) will be lit when more rinse aid is needed.
»Do not overfill the rinse aid dispenser.
The rinse aid is released during the final rinse to prevent water from forming droplets
on your dishes, which can leave spots and streaks. It also improves drying by allowing
water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
WARNING
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser
with any other substances (e.g. Dishwasher cleaning agent, liquid detergent).
This would damage the appliance.
Function Of The Rinse Aid And Detergent
11
Function of detergent
The chemical ingredients that compose the detergent are necessary to remove, crush and
dispense all dirt out of the dishwasher. Most of the commercial quality detergents are
suitable for this purpose.
WARNING
Proper Use of Detergent
Use only detergent specifically made for dishwashers use. Keep your detergent
fresh and dry.
Don't put powdered detergent into the dispenser until you are ready to wash
dishes.
Dishwasher detergent is corrosive!Keep dishwasher
detergent out of the reach of children.
When to refill the rinse aid
The regularity of the dispenser needing to be refilled depends on how often dishes are
washed and the rinse aid setting used.
The Low Rinse Aid indicator ( ) will be lit when more rinse aid is needed.
Do not overfill the rinse aid dispenser.
NOTE:
»The salt container must only be refilled when the salt warning light ( ) in the control panel
comes on. Depending on how well the salt dissolves, the salt warning light may still be on
even though the salt container is filled.
If there is no salt warning light in the control panel (for some Models), you can estimate when
to fill the salt into the softener by the cycles that the dishwasher has run.
»If salt has spilled, run a soak or quick program to remove it.
10
1. Remove the lower basket and unscrew the reservoir cap.
2. Place the end of the funnel (supplied) into the hole and pour in about 1.5kg of
dishwasher salt.
3. Fill the salt container to its maximum limit with water, It is normal for a small
amount of water to come out of the salt container.
4. After filling the container, screw back the cap tightly.
5. The salt warning light will stop being after the salt container has been filled with salt.
6. Immediately after filling the salt into the salt container, a washing program should
be started (We suggest to use a short program). Otherwise the filter system, pump
or other important parts of the machine may be damaged by salty water. This is
out of warranty.
NOTE:
The salt container must only be refilled when the salt warning light ( ) in the
control panel comes on. Depending on how well the salt dissolves, the salt
warning light may still be on even though the salt container is filled.
If there is no salt warning light in the control panel (for some Models), you can
estimate when to fill the salt into the softener by the cycles that the dishwasher
has run.
If salt has spilled, run a soak or quick program to remove it.
Please follow the steps below for adding dishwasher salt:

Instruction manual DI652 17
Please keep this instruction manual for future reference
ADJUSTING THE RINSE AID RESERVOIR
To achieve a better drying performance with limited rinse aid, the dishwasher is designed to adjust
the consumption by user. Follow the below steps:
1. Open the door, power on the dishwasher by plugging in.
2. Within 60 seconds of step 1, press and hold the Program “ ” button for more than 5
seconds, and then press the Delay “ + ” button to enter the set model, the rinse aid indication
blinks as 1Hz frequency.
3. Press the Program “ ” button to select the proper set according to your using habits, the
sets will change in the following sequence: D1->D2->D3->D4->D5->D1. The higher the
number, the more rinse aid the dishwasher uses.
4. No operation in 5 seconds or pressing the Power button will exit the set model.
Water Softener
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which
would have a detrimental or adverse effect on the operation of the appliance.
The more minerals there are, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area.
Your local Water Authority can advise you on the hardness of the water in your area.
Adjusting salt consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed
based on the hardness of the water used. This is intended to optimise and customise
the level of salt consumption.
1. Open the door and switch on the appliance
2. P Program “ ”
3. Program
“ ”
4. Without operation in 5 seconds or press the Power button to complete the setup
and exit the setup mode.
;
ress the button for more than 5 seconds to start the water softener
set model within 60 seconds after the appliance was switched on;
Press the button to select the proper set according to your local
environment, the sets will change in the following sequence:
H3->H4->H5->H6->H1->H2->H3;
Please follow the steps below for adjustment in salt consumption.
dH=1.25 Clarke=1.78 fH=0.178mmol/l
°° °
1
The manufactory setting: H3
Contact your local water board for information on the hardness of your water supply.
0 - 5
6 - 11
12 - 17
18 - 22
23 - 34
35 - 55
German
dH
Salt consumption
(gram/cycle)
0 - 9
10 - 20
21 - 30
31 - 40
41 - 60
61 - 98
0 - 6
7 - 14
15 - 21
22 - 28
29 - 42
43 - 69
0 - 0.94
1.0 - 2.0
2.1 - 3.0
3.1 - 4.0
4.1 - 6.0
6.1 - 9.8
H1
H2
H3
H4
H5
H6
0
9
12
20
30
60
French
fH Mmol/l
Water softener level
British
Clarke
WATER HARDNESS
7
Water Softener
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which
would have a detrimental or adverse effect on the operation of the appliance.
The more minerals there are, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area.
Your local Water Authority can advise you on the hardness of the water in your area.
Adjusting salt consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed
based on the hardness of the water used. This is intended to optimise and customise
the level of salt consumption.
1. Open the door and switch on the appliance
2. P Program “ ”
3. Program
“ ”
4. Without operation in 5 seconds or press the Power button to complete the setup
and exit the setup mode.
;
ress the button for more than 5 seconds to start the water softener
set model within 60 seconds after the appliance was switched on;
Press the button to select the proper set according to your local
environment, the sets will change in the following sequence:
H3->H4->H5->H6->H1->H2->H3;
Please follow the steps below for adjustment in salt consumption.
dH=1.25 Clarke=1.78 fH=0.178mmol/l
°° °
1
The manufactory setting: H3
Contact your local water board for information on the hardness of your water supply.
0 - 5
6 - 11
12 - 17
18 - 22
23 - 34
35 - 55
German
dH
Salt consumption
(gram/cycle)
0 - 9
10 - 20
21 - 30
31 - 40
41 - 60
61 - 98
0 - 6
7 - 14
15 - 21
22 - 28
29 - 42
43 - 69
0 - 0.94
1.0 - 2.0
2.1 - 3.0
3.1 - 4.0
4.1 - 6.0
6.1 - 9.8
H1
H2
H3
H4
H5
H6
0
9
12
20
30
60
French
fH Mmol/l
Water softener level
British
Clarke
WATER HARDNESS
7
12
Adjusting the rinse aid reservoir
To achieve a better drying performance with limited rinse aid, the dishwasher is
designed to adjust the consumption by user. Follow the below steps.
1. Open the door, power on the dishwasher by plugging in;
2. Within 60 seconds after step 1, press the Program “ ” button more than
5 seconds, and then press the Delay “ + ” button to enter the set model,
the rinse aid indication blinks as 1Hz frequency.
3. Press the Program “ ” button to select the proper set according to your
using habits, the sets will change in the following sequence:
D1->D2->D3->D4->D5->D1. The higher the number, the more rinse aid the
dishwasher uses.
4. Without operation in 5 seconds or press the Power button to exit the set model,
the set success.
Filling The Rinse Aid Reservoir
3Close the cap once full.
1
2
Remove the rinse reservoir cap by
lifting up the handle .
Pour the rinse aid into the dispenser, being
careful not to overfill.
FILLING THE RINSE AID DISPENSER

Instruction manual DI65218 Please keep this instruction manual for future reference
13
2
1
Please choose an open way according
to the actual situation.
1. Open the cap by sliding the release
catch.
2. Open the cap by pressing down the
release catch.
Add detergent into the larger cavity (A) for the main wash cycle.
For better cleaning result, especially if you have very dirt items, pour a small amount of detergent
onto the door. The additional detergent will activate during the
pre-wash phase.
3
Close the flap by sliding it to the
front and then pressing it down.
A
Sliding it to the right
B
Filling The Detergent Dispenser
NOTE:
Be aware that depending on the soiling of water, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.
Open the cap by pressing
down the reslease catch.
13
2
1
Please choose an open way according
to the actual situation.
1. Open the cap by sliding the release
catch.
2. Open the cap by pressing down the
release catch.
Add detergent into the larger cavity (A) for the main wash cycle.
For better cleaning result, especially if you have very dirt items, pour a small amount of detergent
onto the door. The additional detergent will activate during the
pre-wash phase.
3
Close the flap by sliding it to the
front and then pressing it down.
A
Sliding it to the right
B
Filling The Detergent Dispenser
NOTE:
Be aware that depending on the soiling of water, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.
13
2
1
Please choose an open way according
to the actual situation.
1. Open the cap by sliding the release
catch.
2. Open the cap by pressing down the
release catch.
Add detergent into the larger cavity (A) for the main wash cycle.
For better cleaning result, especially if you have very dirt items, pour a small amount of detergent
onto the door. The additional detergent will activate during the
pre-wash phase.
3
Close the flap by sliding it to the
front and then pressing it down.
A
Sliding it to the right
B
Filling The Detergent Dispenser
NOTE:
Be aware that depending on the soiling of water, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.
FILLING THE DETERGENT DISPENSER
FUNCTION OF DETERGENT
The chemical ingredients that compose the detergent are necessary to remove, crush and dispense
all dirt out of the dishwasher. Most of the commercial quality detergents are suitable for
this purpose.
PROPER USE OF DETERGENT
»Use only detergent specifically made for dishwasher use. Keep your detergent fresh and dry.
»Don’t put powdered detergent into the dispenser until you are ready to wash dishes.
FILLING THE DETERGENT DISPENSER
Close the flap by sliding it to the
front and then pressing it down.
Add detergent into the larger cavity (A)
for the main wash cycle.
For better cleaning result, especially if
you have very dirty items, pour a small
amount of detergent onto the door (B).
The additional detergent will activate
during the pre-wash phase.

Instruction manual DI652 19
Please keep this instruction manual for future reference
NOTE:
Depending on how dirty the items are will affect how much detergent to use. Please observe the
manufacturers recommendations found on the detergent packing.
WARNING:
Dishwasher detergent is corrosive.
Keep dishwasher detergent out of the reach of children.
PREPARING AND LOADING DISHES
»Consider buying utensils which are identified as dishwasher-proof.
»For particular items, select a program with the lowest possible temperature. To prevent
damage, do not take glass and cutlery out of the dishwasher immediately after the programme
has ended.
THE FOLLOWING CUTLERY DISHES ARE NOT SUITABLE:
»Cutlery with wooden, horn china or mother-of-pearl handles
»Plastic items that are not heat resistant
»Older cutlery with glued parts that are not temperature resistant Bonded cutlery items
or dishes
»Pewter or cooper items
»Crystal glass
»Steel items subject to rusting
»Wooden platters
»Items made from synthetic fibres
ARE OF LIMITED SUSTAINABILITY:
»Some types of glasses can become dull after a large number of washes
»Silver and aluminium parts have a tendency to discolour during washing
»Glazed patterns may fade if machine washed

Instruction manual DI65220 Please keep this instruction manual for future reference
RECOMMENDATIONS FOR LOADING THE DISHWASHER
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans. It is not
necessary to rinse the dishes under running water.
For best performance of the dishwasher, follow these loading guidelines.
(FEATURES AND APPEARANCE OF BASKETS AND CUTLERY BASKETS MAY VARY
FROM YOUR MODEL.)
Place objects in the dishwasher in following way:
»Items such as cups, glasses, pots/pans, etc. are faced downwards.
»Curved items, or ones with recesses, should be loaded aslant so that water can run off.
»All utensils are stacked securely and can not tip over.
»All utensils are placed in the way that the spray arms can rotate freely during washing.
»Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
»Dishes and items of cutlery must not lie inside one another, or cover each other. To avoid
damage, glasses should not touch one another.
»The upper basket is designed to hold more delicate and lighter dishware such as glasses,
coffee and tea cups.
»Long bladed knives stored in an upright position are a potential hazard.
»Long and / or sharp items of cutlery such as carving knives must be positioned horizontally in
the upper basket.
»Please do not overload your dishwasher. This is important for good results and for reasonable
consumption of energy.
NOTE:
Very small items should not be washed in the dishwasher as they could easily fall out of
the basket.
REMOVING THE DISHES
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first, followed by the upper basket.
WARNING:
ITEMS WILL BE HOT.
To prevent damage, do not take glass and cutlery out of the
dishwasher for around 15 minutes after the program has ended.
Items such as cups, glasses, pots/pans, etc. are faced downwards.
Curved items, or ones with recesses, should be loaded aslant so that water can run
off.
All utensils are stacked securely and can not tip over.
All utensils are placed in the way that the spray arms can rotate freely during
washing.
Load hollow items such as cups, glasses, pans etc. With the opening facing
downwards so that water cannot collect in the container or a deep base.
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage, glasses should not touch one another.
The upper basket is designed to hold more delicate and lighter dishware such as
glasses, coffee and tea cups.
Long bladed knives stored in an upright position are a potential hazard!
Long and / or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
NOTE:
Very small items should not be washed in the dishwasher as they could easily fall
out of the basket.
To prevent water dripping from the upper basket into the lower basket, we
recommend that you empty the lower basket upper basket. first, followed by the
Removing the dishes
WARNING
Items will be hot! To prevent damage, do not take glass and
cutlery out of the dishwasher for around 15 minutes after the
program has ended.
9
Recommendations for loading the dishwasher
Scrape off any large amounts of leftover food. Soften remnants of burnt food in
pans. It is not necessary to rinse the dishes under running water.
For best performance of the dishwasher, follow these loading guidelines.
Place objects in the dishwasher in following way:
(Features and appearance of baskets and cutlery baskets may vary from
your model.)
