CONTENTS
Warnings
Uses
Surface mounted installation
Recessed built in installation
Remote control
Maintenance
4
GB

WARNINGS
The appliance is not intended for use by
young children or infirm persons without
supervision. Young children should be
supervised to ensure they do not play
with the appliance.
The extracted air can’t be conveyed
through or into a duct used to let out
fumes from appliances fed by energy
other than electric power (eg. centralized
heating, radiators, water-heaters, etc.).
To evacuate the air outlet, please comply
with the pertaining rules given by
competent authorities.
Provide the room with an adequate aeration
when a cooker hood and appliances fed by
energy other than electric power (gas, oil,
or coal stoves, etc.) are used
simultaneously. The cooker hood, when
evacuating the extracted air, could generate
a negative pressure in the room which can’t
exceed the limit of 0.04 mbar, in order to
avoid the suck of exhausts deriving from
the heat-source. Therefore the room should
be provided with air-intakes to allow a
constant flow of fresh air.
If the rating label in the cooker-hood does
not show the symbol , the appliance is
built in class I° and it needs the earth
connection.
When performing the electrical connections
on the appliance, please make sure that the
current-tap is provided with earth
connection and that voltage values
correspond to those indicated on the label
placed inside the appliance itself.
Before carrying out any cleaning or
maintaining operations, the appliance
needs to be removed from the electric grid.
If the appliance is not provided with a non
separable flexible cable and plug, or
with another device ensuring omnipolar
disconnections from the grid, with an
opening distance between the contacts of at
least 3 mm, then such disconnecting
devices must be supplied within the fixed
installation. 5
If the appliance is endowed with a supply cord
and a plug, the appliance has to be put in a
place where the plug can be reached easily.
The use of materials which can burst into
flames should be avoided in close
proximity of the appliance. When frying,
please pay particular attention to fire risk
due to oil grease. Being highly
inflammable, fried oil is especially
dangerous. Do not use uncovered electric
grills. In order to avoid possible fire
risk, all instructions for grease filter
cleaning and for removing eventual
grease deposits should be strictly
followed.
USES
PANELS OPENING
The grease lters cover panels are opened by
slightly pulling them , as shown in g. 1.
Open the glass panels using both hands and
take them up to full opening.
CONTINUE TO TAKE THE GLASSES UP
WHILE OPENING THEM.
THE APPLIANCE CAN BE INSTALLED IN
BOTH BUILT-IN AND FREE-STANDING
VERSION.
For proper operation, we recommend to
install the appliance at a maximum distance
of 2000 - 2100 mm from the floor.
Before installing the appliance, check that all
the components are not damaged, otherwise
contact your retailer and do not carry out
installation.
Use an air exhaust pipe, whose length does
not exceed 5 meters.
- Limit the number of elbows , since each
elbow reduces the appliance air capacity of
about 1 linear meter. (E.g: if no. 2 x 90°
elbows are used, the piping length shall
not exceed 3 meters).
- Avoid abrupt direction changes.
- Use a 150mm/200mm constant diameter
pipe for the whole length.
- Use a standard approved material pipe.

6
SURFACE MOUNTED
INSTALLATION
Take the product out of the packaging and
place it on a suitable surface: we suggest to
use a soft material, such as a sponge or a
cloth.
Open the glass panel, as shown in Fig. 1,
and remove the grease filters.
BEFORE INSTALLATION, IN ORDER TO AVOID
ANY POSSIBLE DAMAGE TO THE GLASSES,
WE RECOMMEND TO REMOVE THEM BY
UNSCREWING THE EIGHT SCREWS SHOWN IN
FIG. 10. ELECTRICALLY DISCONNECT THE
LED BARS, BY USING THE SPECIFIC BIPOLAR
ACTUATOR, AND REFIT THE GLASSES AND
THE ELECTRIC WIRING ONCE
INSTALLATION IS COMPLETED.
Drill the holes on the ceiling, as shown in Fig.
2, insert the plastic plugs into the holes made,
and then x the ceiling brackets, as shown in
Fig. 3. The brackets, which being telescopic
can be adjusted in height, shall be secured at
their minimum extension.
Bring the hood close to the brackets
previously fixed and connect the appliance
to the supply mains.
RECESSED BUILT IN
INSTALLATION
Take the product out of the packaging and place
it on a suitable surface: we suggest to use a soft
material, such as a sponge or a cloth.
Open the glass panel, rotating it as shown in Fig.
1, and remove the grease filters.
BEFORE INSTALLATION, IN ORDER TO AVOID
ANY POSSIBLE DAMAGE TO THE GLASSES,
WE RECOMMEND TO REMOVE THEM BY
UNSCREWING THE EIGHT SCREWS SHOWN IN FIG.
10. ELECTRICALLY DISCONNECT THE LED BARS,
BY USING THE SPECIFIC BIPOLAR ACTUATOR,
AND REFIT THE GLASSES AND THE ELECTRIC
WIRING ONCE INSTALLATION IS COMPLETED.
In the built-in installation, the stainless steel
external cover is not necessary (Fig. 5).
A recess shall be created , where the appliance
will be placed, which shall have a 730 mm X
450 mm rectangular opening and depth ranging
from 110mm to 190 mm.
INSTALL THE HOOD ON THE CEILING,
CONNECT THE CANAL SYSTEM FOR THE
AIR OUTLET, SET THE ELECTRICAL
CONNECTION AND THEN COMPLETE THE
PLASTER BOARD STRUCTURE.
Secure the hood to the ceiling, by using
the screws supplied, as shown in Fig. 4.
The recess shall be provided with a socket and a
round pipe of 150mm diameter, or a similar
section, for the air outlet.
Drill the holes on the ceiling, as shown in Fig. 2,
insert the plastic plugs into the holes made, and
then fix the ceiling brackets as shown in Fig. 3.
The ceiling brackets are telescopic, so their
height can be adjusted at 80 mm between the
ceiling and the hood.
You can choose one of the three air outlets
shown in Fig. 6: fit the air outlet plastic flange
in the desired outlet; the remaining outlets shall
be closed with the specific metal caps, as shown
in fig. 6.
Bring the hood close to the brackets previously
fixed and then connect the appliance to the
supply mains.
Secure the hood to the ceiling, by using the
screws supplied, as shown in Fig. 4.

7
WORKING
RC001
RADIO CONTROL
Radio control used for the remote operation
of ducted cooker hoods.
TECHNICAL DATA
- Alkaline battery powered: 12 V mod. 23 A
- Operating frequency: 433.92 Mhz
- Combinations: 32.768
- Max. consumption: 25 mA
- Operating temperature: -20 ÷ + 55 °C
- Dimensions: 120 x 45 x 15 mm.
OPERATING DESCRIPTION
The transmitter is equipped with 5 buttons
for cooker hood management, as specied
below:
: Light ON/OFF command.
: Motor ON (speed level 1) / OFF command.
: Reduce speed.
: Increase speed.
: 10-minute timer.
The set suction speed is indicated by the LED
in the suction perimeter channel.
To each color generated by the LED, it
corresponds a specific speed, as shown
below: First speed WHITE
Second speed BLUE
Third speed DARK BLUE
Fourth speed RED
DIMMABLE LIGHTS FUNCTION
This function provides for lights dimmability,
ranging from 20% to 100% , by continuously
pressing the light key on the remote control.
Functions are the following:
- Hood light off - Press the light key - on at
100%.
- Light on at 100% - Press the light key - off.
- Light on at 100% - Continuously press the
light key - Brightness reduction.
- Releasing the key during reduction or
increase, the light keeps the luminous
intensity reached.
- Light on dimmed - Continuously press the
light key - Brightness is inverted if compared
to the previous function.
INITIAL OPERATING CONDITION
The manufacturer supplies the radio control
unit ready to be used with codes preset in the
Factory.
OPERATION MODE
Standard conguration:
Standard configuration requires all
“cooker hoods – radio control - system” to
be provided with the same transmission
code. In the event two cooker hoods radio
control system are installed in the same
room or nearby, each system may affect the
operation of the another. Therefore, the
code of one radio control system must be
changed.
Generating a new transmission code:
The radio control system is provided with
preset codes. Should new codes be
required, proceed as follows: Press
simultaneously buttons:

WARNIING
The battery should be replaced every year
to guarantee the optimal range of the
transmitter.
To replace the exhausted battery, take
the plastic lid off, remove the battery and
replace it with a new one, observing the
correct battery polarities.
Used batteries should be discarded in
special collection bins.
The below product:
RC001 Radio Control
complies with the specications set out in
the R&TTE Directive 99/5/EC.
WARNING
Any adjustments or modications which
have not been expressly approved by the
holder of the legal conformity certicate
may invalidate the user’s rights relating to
the operation of the device.
Rev. 0 26/08/14
The products are endowed with an electronic
device which allows the automatic switching
off after 4 hours working from the last
operation.
8
for two seconds. When LEDs light on,
press buttons:
(within 5 seconds). LEDs flashing 3 times
indicate the procedure is completed.
WARNING! This operation deletes
permanently the preset codes.
Learning the new transmission code:
Once the transmission code is changed in
the radio control unit, the electronic central
unit of the cooker hood must be made to
set the new code in the following way:
Press the main power-off button of the
hood (fig. 11) and then restore power to the
electronic control unit. Within the next 15
seconds, press the Light Button to
synchronise the central unit with the code.
Reset of the Factory configuration:
To restore the Factory configuration, follow
the procedure described below: press
simultaneously buttons:
for 2 seconds. When LEDs light on, press
buttons:
(within 5 seconds). LEDs flashing 6 times
indicate the procedure is completed.
WARNING! This operation deletes
permanently the preset codes.
Emergency button:
In the event that the radio control does not
work, use the emergency button to switch
the appliance o. After any necessary repairs
have been performed, reset the emergency
button.

An accurate maintenance guarantees good
functioning and long-lasting performance.
Particular care is due to the grease filter. The
grease filter is fixed through magnets, therefore it
is sufficient to insert a hand tool or the tip of a
knife in the dedicated opening and push
upwards in order to pull the filter out of its place.
See Fig. 8 In order to remove the filter from the
hood, unhook the two security cables opening
their snap hooks, The active charcoal filter has to
be removed after the extraction of the grease filter
by pushing the specific handle (fig.9.To reinsert
the grease filter after the cleaning, just perform the
opposite operation.
The grease filter can be cleaned by hand washing
or in dishwashers.
The active charcoal filter used in these hoods can
be washed and re-used for up to a maximum 3
years. We recommend that these are replaced
during this period.
To purchase replacement charcoal filters please
visit www.caple.co.uk or call 0117 938 1900.
To wash the charcoal filters, wash by hand with
warm water or in the dishwasher, and then bake
in the oven at 90 degrees for 1 hour.
To clean the appliance itself tepid water and
neutral detergents are recommended, while
abrasive products must be avoided.
The power-supply cable must be replaced by
authorised qualified staff only.
9
MAINTENANCE
TIMING
As a result of the new EU65 “Energy label” and
EU66 “ Ecodesign” regulations issued by the
European Commission, which came into force
as from January 1st, 2015 , our products have
been adapted to comply with these new
requirements.
All of the models complying with the energy
label requirements, are equipped with new
electronics including a timer device for
suction speeds control, when the air capacity
exceeds 650m³/h.
Internal motor models, with maximum air
capacity higher than 650m³/h, are
equipped with a timer device that
automatically switches the suction speed
from 4th to 3rd speed, after 5 minutes
operation.
External motor models are equipped with
remote motors that , as for internal motor
versions, include a timer device that switches
down the suction speed when it exceeds 650
mᵌ/h. (See External Motors Instructions )
Remote motors, whose air capacity exceeds
650m³/h at both 4th and 3rd speed , will
have the following by default timer control
functions: The suction speed is automatically
switched from 4th to 2nd speed, after 6
minutes operation.
If the appliance is working at 3rd speed, it is
automatically switched to 2nd speed, after 7
minutes operation. Operation speeds can
also be changed during operation.
The energy consumption of the appliance in
standby mode is lower than 0.5W.

10
1
4
56
2
3

11
78
9 10
11

90001966967 - GM 02/17
90000280099 - GM 02/17
Bristol
BS11 8DW
t: 0117 938 7420
e: [email protected]
www.caple.co.uk
Please keep this instruction manual for future reference
Caple Service
Fourth Way
Avonmouth
