Caple WC6115 User manual

1
Instruction manual for in-column wine cabinet
Model code: WC6115
Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk

2
WARNING
IMPORTANT SAFETY INSTRUCTIONS
aWARNINGa
To reduce the risk of fire, electrical shock,
or injury when using your appliance, follow
these basic precautions:
•Read all instructions before using the Wine cabinet.
•DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or
abandoned appliances are still dangerous . . . even if they will “just sit in the garage a
few days”.
•Before you throw away your old Wine cabinet: Take off the door. Leave the
shelves in place so that children may not easily climb inside.
•Never allow children to operate, play with, or crawl inside the appliance.
•Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
•Do not store or use gasoline or any other flammable vapours and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or
explosion.
•The refrigerant of these appliances are R600a , Flammable and explosive
articles should not be put in or near the cabinet, to avoid the risk of fire or
explosion
-Keep these instructions-
zTo prevent damaging the door gasket, make sure to have the door all the way
opened when pulling shelves out of the rail compartment.
zThe appliance must be positioned so that the plug is accessible. Release the
power cord. Move your cabinet to its final location. Do not move your Cabinet
while loaded with wine. You might distort the body. The wine cellar should be
installed in a suitable place in order to avoid touching the compressor with the
hand.
zIf the supply cord is damaged, it must be replaced by a Caple service agent or a
similarly qualified person in order to avoid a hazard.
PLEASE DON’T TRY TO EXTEND THE ELECTRICAL CABLE IN ANY WAY.

3
INSTALLATION INSTRUCTIONS
¾Before Using Your Wine cabinet
•Remove the exterior and interior packing.
•Before connecting the Wine cabinet to the power source, let it stand upright for
approximately 12 hours. This will reduce the possibility of a malfunction in the cooling
system from handling during transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
•When disposing your appliance, please choose an authorized disposal site.
¾Installation of Your Wine cabinet
•Place your Wine cabinet on a floor that is strong enough to support it when it is fully
loaded. To level your Wine cabinet, adjust the front levelling leg at the bottom of the Wine
cabinet.
•Locate the Wine cabinet away from direct sunlight and sources of heat (stove, heater,
radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may increase
electrical consumption. Extreme cold ambient temperatures may also cause the unit not to
perform properly.
•Avoid locating the unit in moist areas.
•Plug the Wine cabinet into an exclusive, properly installed-grounded wall outlet. Do not
under any circumstances cut or remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed toward a certified
electrician or an authorised Caple service centre.
¾Attention
•Store wine in sealed bottles;
•Do not overload the cabinet;
•Do not open the door unless necessary;
•Do not cover shelves with aluminium foil or any other shelf material which may prevent air
circulation;
•Should the Wine cabinet be stored without use for long periods it is suggested, after a
careful cleaning, to leave the door ajar to allow air to circulate inside the cabinet in order to
avoid possible formations of condensation, mould or odours.

4
OPERATING YOUR WINE CABINET
AND SETTING THE TEMPERATURE CONTROL
Please use the cabinet within an ambient temperature of 5-32 °C. If the ambient
temperature is higher or lower than this, it will cause temperature fluctuations in the
cabinet.
¾Controls
This is the LCD touch control panel.
•“Power”
When the indicator light is on, the power for the machine is on.
•“ ”
This shows the temperature of the internal cabinet.
•“ ” Button
1) Used to raise the temperature by 1°C;
2) Also used to adjust the clock (increase 1 min or 1 hour)
•“ ” Button
•1) Used to reduce the temperature by 1°C;
2) Used to adjust the clock (decrease 1 min or 1 hour)
•“”Button
1) To turn the inner light on/off.
（Press this button, the light is on, and the light is not controlled by door. Press this button
again, the light is off, and the light is controlled by door.）
2) Also used to set up time mode/Light Control mode change.
•“”Button
To turn this appliance on/off.
（Press this button, the power is on. Press this button with 3 seconds again, the power is off.）
•“”
Display Clock .
•“”
Alarm Indicator light.
P o w e r

5
¾Setting The Temperature Controls
•The temperature range can be set as low as 4°C or as high as 18°C to suit your specific storage
requirements.
•The factory temperature setting is 12°C , and the time is 12:00.
•When the system enters the temperature set up. Each press once the or button, will
increase or decrease the temperature by 1°C. When the temperature setting reaches the upper
limit 18ºC and lower limit 4ºC, the temperature setting will not increase or lower.
•Press the button keep 3 seconds, the system will enter the time set up. The hour figure will
flash first with each press on the or button, The hour figure will increase or decrease by 1.
After 5 seconds the hour figure will not flash automatically and the minute figure will flash.
With each press on the or button, the minute figure will increase or decrease by 1. After
10 seconds the system will quit the time set up. While in the time set up, pressing the or the
button will not change the temperature
•If you want to know the actual temperature, please press or for 3 seconds, the display
panel will show the actual temperature. After 5 seconds, it will show the set temperature.
•Flashing word= Cabinet Temperature
Steady word = Set Temperature
¾Note:
•If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the Wine cabinet will not
start.
•When you use the Wine cabinet for the first time or restart the Wine cabinet after having been
shut off for a long time, there could be a few degrees variance between the temperature you
select and the one indicated on the LCD readout. This is normal and it is due to the length of
the activation time. Once the wine cabinet has been running for a few hours everything will be
back to normal.
¾Function Instruction
•Temperature Recollection Function
In the event of a power interruption the wine cabinet will remember the previous temperature
settings, and when the power is recovered the temperature will go back the same setting
temperature as power was lost.
•Overtime Open the Door Alarm
When you forget close the door or the door is not closed completely, the alarm will sound after
5 minutes. Please close the door completely to avoid losing cold energy.
•Temperature Alarm
If inner temperature is higher than 23°C, “HI” is shown in display panel, and the alarm will
sound after one continuous hour. It informs that the inner temperature is too high, please
check the reason.
If inner temperature is lower than 0°C, “LO” is shown in display panel and the alarm will sound
with the addition of the malfunction indicator light at the same time.

6
¾Storage diagram
Total: 46 bottles (Max) (for 750 ml Bordeaux bottles)
P o w e r
¾Shelves
•To prevent damaging the door gasket, make sure you have the door fully opened when pulling
shelves out of the rail compartment.
•For easy access to the storage content, you must pull the shelves approximately 1/3 out of the
rail compartment, however this unit was designed with a notch on each sides of the shelf tracks
to prevent bottles from falling.
•When removing any of these shelves out of the rail compartment, the shelf as per the diagram
and simply pull out, or push in the shelf until it sits on the support brackets securely.
P o w e r

7
CAUTION！
Do not store bottles crossways on the interior floor! Otherwise, bottles may fall out when the
appliance door is opened and this may cause injury or material damage.
¾How to change the door opening
This appliance has reversible doors but is delivered with a right hinged door. The left hand
hinge kit comes with the unit (in the box), should you wish to reverse the hinge on your unit.

8
1. Incline the wine cabinet with 45 degrees, take out right lower hinge’s screws with screwdriver
(Fig.1)
2. Level the wine cabinet, Hold the door and take out right upper hinge’s screws with screwdriver.
Then take out the door and rotate 180 degrees (Fig.2 & Fig.3 & Fig.4)
3. Take off the decorated nail from left upper side, then fit the door with screws, fit the decorated
nail to right side of A location. (see Fig.5& Fig.6)
¾Installation specifications for built-in purposes

9
1. After installing the wine cellar into the cabinet, please adjust the limited block (a) close to the
cabinet (b)
2. Please fix the 3 screws through the limited block (a) to fix to the cabinet (b). See the below
picture for reference.
a、Limited block b、Cabinet c、Screw d、Screwdriver

10
CARE AND MAINTENANCE
¾Cleaning Your Wine cabinet
•Turn off the power, unplug the appliance, and remove all items including shelves and rack.
•Wash the inside surfaces with a warm water and baking soda solution. The solution should
be about 2 tablespoons of baking soda to a quart of water.
•Wash the shelves with a mild detergent solution.
•Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe
dry with a clean soft cloth.
¾Power Failure
•Most power failures are corrected within a few hours and should not affect the temperature of
your appliance if you minimize the number of times the door is opened. If the power is going
to be off for a longer period of time, you need to take the proper steps to protect your
contents.
¾Vacation Time
•Short vacations: Leave the Wine cabinet operating during vacations of less than three weeks.
•Long vacations: If the appliance will not be used for several months, remove all items and turn
off the appliance. Clean and dry the interior thoroughly. To prevent odour and mould growth,
leave the door open slightly: blocking it open if necessary.
¾Moving Your Wine cabinet
•Remove all items.
•Securely tape down all loose items (shelves) inside your appliance.
•Wind the adjustable leg up to the base to avoid damage.
•Tape the door shut.
•Be sure the appliance stays secure in the upright position during transportation. Also
protect outside of appliance with a blanket, or similar item.
¾Energy Saving Tips
•The Wine cabinet should be located in the coolest area of the room, away from heat
producing appliances, and out of the direct sunlight.

11
PROBLEMS WITH YOUR WINE CABINET?
You can solve many common Wine cabinet problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before calling the
servicer.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Wine cabinet does not operate. Not plugged in.
The appliance is turned off.
The circuit breaker tripped or a blown fuse.
Wine cabinet is not cold enough. Check the temperature control setting.
External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Turns on and off frequently. The room temperature is hotter than normal.
A large amount of contents has been added
to the Wine cabinet.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door
g
asket does not seal properl
y
.
The light does not work. Not plugged in.
The circuit breaker tripped or a blown fuse.
The bulb has burned out.
The light button is “OFF”.
Vibrations. Check to assure that the Wine cabinet is
level.
The Wine cabinet seems to make too much
noise.
The rattling noise may come from the flow of
the refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in
your Wine cabinet.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The Wine cabinet is not level.
The door will not close properly. The Wine cabinet is not level.
The door was reversed and not properly
installed.
The gasket is dirty.
The shelves are out of position.

12
DEFROSTING/CONDENSATION
Your wine cellar is designed with an “Auto-cycle” defrost system. When the RUN cycle is OFF, the
refrigerated surface of the wine cellar (interior rear wall) defrosts automatically. The defrost water is
channelled into a drain pan which is located at the back of the wine cellar next to the compressor
from where it evaporates.
HUMIDITY MAINTENANCE SYSTEM
The wine cellar is equipped with a system for maintaining the correct level of humidity. If humidity
is too low, insert the small plastic reservoir on to the top shelf. Fill this reservoir 3/4 full with water.
Check the water level occasionally and refill as necessary.
RECOMMENDED TEMPERATURE SETTINGS
For storing ALL TYPES OF WINES 12 oc to 14 oc
RECOMMENDED DRINKING TEMPERATURE
Champagne NV, Sparkling 6 oc
Champagne Vintage 10 oc
Dry White Semillon, Sauvignon Blanc 8 oc
Dry White Gewürztraminer, Riesling 10 oc
Dry White Chardonnay 10 oc
Vintage Chardonnay 14 oc
Sweet White Sauternes Monbazillac, Late Harvest ice wine 10 oc
Sweet whites vintage Sauternes 14 oc
Beaujolais 13 oc
Red Pinot Noir 16 oc
Vintage Pinot Noir red 18 oc
Red Cabernet, Merlot, French, Australian, New Zealand, Chilean,
Argentinean, Italian, Spanish, Californian 18 oc
Red Grenache, Syrah 16 oc
