Caple WI6225 Manual

WI6225
Caple 60cm 2 Door Wine Cabinet
Technical information

Item Part Code Description Quantity
1DG12-37.1 Refrigerrant valve 1
2DG2-14 Power cord 1
DG7-3.2-BH Condenser fan 1
DG17-145-2 Electric wire 1
4DG19-3 Fan cover 1
DG1-35 Compressor 1
DG12-142 Start Device 1
DG12-143 Overload Protector 1
6DG13-403 Water tank 1
7DG6-19 Transformer 1
8DG3-97-1 PCB board 1
9 DG13-272-1 junction box 1
10 DG14-154-BL Top hinge module (Left) 1
11 DG14-154-BR Top hinge module (Right) 1
12 DG12-44 Evaporator 2
13 DG7-3.1-BH Evaporator fan 2
14 DG22-209 Air duct board 2
15 DG19-1 Fan cover 2
16 DG13-198 Senser cover 2
17 DG8-8 Senser 2
18 DG3-12-W LED Light 2
19 DG13-383 Display holder 2
20 DG20-256 Display panel 2
21 DG13-1.2 Humid box 2
22 M130-001 Gasket 2
23 DG22-3026 Handle 2
24 DG14-116 Door axis 2
25 DG23-170 Door (Right) 1
26 DG23-170 Door (Left) 1
27 DG15-27-2 Wooden shelves C1 2
28 DG15-141 Wooden shelves A15 8
29 DG15-141-1 Wooden shelves A15A 2
DG22-395 Electrical box 2
DG13-353 Sealing stlip 2
31 DG14-167-BR Lower hinge module (Right) 1
32 DG22-88 Support bracket of front legs 1
5
30
WI6225 - Caple 60cm 2 Door Wine Cabinet
3

Item Part Code Description Quantity
WI6225 - Caple 60cm 2 Door Wine Cabinet
33 DG14-167-BL Lower hinge module (Left) 1
34 DG12-91-2 Condenser 1
35 DG13-6.11 Cabinet leg 4
36 DG12-113 Air-circulating pipe 2
37 DG22-80.2 Compressor bracket 1
38 DG14-56 Fan frame(pair) 1
DG22-3021 Decorative frame 1

1
ComputerControlledSynchronousDualTemperature
WinecoolerJG2D1
service manual
Herebelowwelistvariousfaultswhileusingthewinecellar,and themethod ofcheck-up andsolvethesedefaults,
pleasefindtheinformationofthecorrespondentpage.
Statement (Fig.4)showsthereferencefigureFig4
( →6)showsthereferencepage6
Warning:
1. Beforeattemptinganycleaningormaintenance thisunitMUSTbedisconnectedfromtheelectricalsupply,
topreventelectricalshock.
2. Beforeusingtheweldingtorchpleasemakesure thatthere isn tanygasinthecoolingsystems.
3. Beforeusingtheweldingtorchpleasedothenecessaryprotectionwell.Whenservicingthewinecooler
withR600asystems, pleasemakesuretheambient iswell ventilated.
▲Preparationbeforemaintenance
○Tools
1.Plier2.Cross-screwdraver
3.Assistantpipe4.Multimeter
5.Clampamperemeter(5A)6.Electriciron
7.Wireinsulatorstripper8.Pipesealplier
○Equipment
1.Vacuumpump2..Copepipeweldingfacility3.Refrigerantmeter
▲Cooling systemsfault
○Howtodiagnosethefaults (→2)
○Howtomaintainthefaults (→2)
○Howtoremovetheair-ductboards (→3)
○Diagramshowingthefrontsidesolderedjoints .(→5)
○Diagramshowingthebacksidesolderedjoints .(→5)
▲Noiseproblem
○Compressornoise(→6)
○Fannoise (→6)
○Refrigerantjetnoise (→7)
○Capillaryvibrationnoise (→7)
○Oil jamnoise (→7)
▲Evaporatorfreezing.(→8)
▲Theunstableofthewinecoolertemperature .(→8)
▲Thecontrolsystemfault
○Faultfindingbyself-checkmode .. (→8)

2
○Sensorfault .. (→9)
○Howtoreplacethesensor .. (→10)
○Refrigerantvalvefault .. (→10)
○LEDdisplayfault.. (→11)
○HowtoremovethepartsinsidethecontrolPCBelectricalbox .. (→11)
○ThenameandexplanationofthecontrolPCBand powerPCBboardconnectors (→12)
○HowtoremovethepowerPCBand transformer .. (→13)
○HowtoreplacetheLEDlight .. (→14)
▲Thecontrolsystemfault
○Howtodiagnosethefaults
Itshouldtakeapproximate3hourstoreachthelowestsettingtemperatureof5℃foranemptyunitinboth
zone(assumingambienttemperatureof32 degreescentigradeandcontinuousoperation). If not, checkthecompressor,
cooling fans, controller, and sensors. If all theseareworkingnormally, thereisprobablya coolingsystemfault.
○Howtomaintainthefaults
1. Check the compressor:
Theprocess ofcompress removed:removetheelectricalboxofcompressor→disconnecttheconnectorstothe
compressor→separatethepipejoints→removethecompressor
Theprocess ofevaporatorremoved:removetheshelves→removetheairductboard→separatethepipejoints
→removetheevaporator
If neitherzonescannotrefrigerate,checkthecurrentofthecompressorwithaclampAmperemeter,and the
currentshouldbewithin0.8to2A.If thecurrentnotinthisrange,turnoffandcutofftheexhaust(Fig.4 ,see
point D) and assistant pipe(Fig.4 ,see point A), electrified the wine cooler and check the current
again, check thedischarge pipe of thecompressor at the sametime, if ithas an clear airpressure，
if the electricity is still too high or has not air pressure, it showsthat the compressoris
failed by itself，and you need to replace the compressor. (Noted:Toavoidthecompressorsuckthe
moist,runthecompressornotlongerthan15 minutesaftertheassistantpipeand dischargepipecutoff.)
2 ．Check the cooling systempipe work.
1>.Under theconditionof thecompressorrunning normally,neither zone is not cooling.
and it is possibly that the cooling system pipe leak. The maintain procedure is following.
a. Cut the discharge pipe ofthe compressor.infill 0.8-1Mpa nitrogen via assistant
pipe, and feel the discharge pipe, there should be alittle airflow which means
the capillary is normal, otherwise the capillary is jam.
b .Make sure the capillary is in good condition, join the discharge pipe, infill
0.8-1Mpa nitrogen via the assistantpipe, check all the joints with soap water
if any leak from any of them. Check the back side joints around the compressor
first (Fig.4),if it without any leak check front side joints(Fig.3 ).Before
checking front side joints you needto remove the airduct board(Fig.1 &Fig.2).
c. If there isn’tany leakage can be found,it means two possible:1.the internal
leakage,2.theevaporatoror other part leakage.Internalleak can’tberepaired,
if the part (suchevaporator, condenser)leakage, replace it please.
d. Confirming thecooling system is in good condition, you refill again.

3
2>. Under the compressor is running normally,if only one zone no cooling, the fault
should happen on the part in this zone.(two zones have the same structure, so the
maintain method for them aresame).
a. Check the valve byhearing the sound.turnoffthe winecooler and exchange the
connectors ofthe valve thenpower on, listencarefully you canhear thesnip-snap
sound fromvalve,otherwise thevalveispower offor broken orthePCBfault.
Confirming the PCB is normal, replace the valve. (→8) (Fig.9)
b. If the valve is running normally, it maybe the capillaryjam, please clean it
with nitrogen, you can overhaul it referto above.
c. Replacethe fault spearparts.Confirmingthecoolingsystem isnotjammed, refill
the refrigerant.
3 ．Refill
1>. Usingthevacuumpumpformavacuuminthesystem,viathejointofthelow-pressurepipe
(Fig.4,see point A)，thehigh-pressurepipelineisontheprocess pipeofthefilter。Applythevacuum
pumpforapproximately20 minutes.Until thevacuumislowerthan100Pa. Thensoldertheprocess
pipeofthefilterKeepthethesystemvacuum.
2>. FillCooling systemwithrefrigerantviatheprocess pipe (Fig.4,see point A).Therefrigerant
and quantityPleaserefertotheinstructionatbacklabelofwinecellar.Thensolderthecompressor
process pipeafterthesystemischargedwithrefrigerant.
4 ．Test
Replaceall thecomponentsaftertheproceduresaboveand turntheuniton.Toverifytheeffectiveness
oftherepair,monitortheunit,thecompressorshouldautomaticallystopwhenbothzone1.5℃lower
thansettingtemperaturesand startwheneitherzone2.5℃higherthan setting temperature within
approx3hours(assuminganambienttemperatureof32℃and theunitisempty).
○Howtoremovetheair-ductboards
1>.Pull theshelvestothebottom,circumvolveany sideoftherightand left,and letthesetteroftheshelvego
outofthechannel, and thendrawouttheshelves. (Fig.1)

4
2>.UseaSetofcross-screwdriverstoremovetheair-ductboardscrews(Note:1~5aretheair-ductboard
screws.A~Darethefanscrews,neednottoremove),and removetheair-ductboard.Beattentiontounplug
theconnectionwirewhenremovingtheair-ductboard.Youcanmoveslowlyasideuntil youcanseethefans
wire, andunplugthefanconnector,and thentakeoutthewholeair-ductboard. ;(Fig.2)
3>.Thepictureafterremovingtheairductboard. (Fig.3)
Fig. 1
Fig. 2

5
○Diagramshowingthefrontsidesolderedjoints(Fig.3)
A:CapillarysolderedjointB:Evaporatorsolderedjoint
○Diagramshowingthebacksidesolderedjoints(Fig.4)
A:CompressorassistantpipesolderedjointedB:Anti-dewpipesolderedjoint
C:RightzonesuctionpipesolderedjointD:Dischargepipesolderedjoint
E:LeftzonesuctionpipesolderedjointF:Condensersolderedjoint
G:FiltersolderedjointH:RightzonecapillarysolderedjointI:
ConnecterpipejointJ:Valvesolderedjoint
K:LeftzonecapillarysolderedjointL:Condensersolderedjoint
Fig. 3
Fig. 4

6
▲Noiseproblem
○Compressornoise
1>. Theworking ofmotorand pistonmotionwillcausenoisewhencompressorworking.Soifnoiseissteady
and notexceeds42dB,it’snormal.If noiseisnotsteadyorveryhigh,it’scompressorfault and itshould
bemaintainedorreplaced.
2>.Ifcompressor’sshockabsorptionrubberishardening ordamaged,orfixingscrewofcompressoristoo
tightorloose,itwillcausenoise.Thesettlementistochangenewshockabsorption rubberoradjust
fixing screws.
○Fannoise
1>.Therunningofthefanmotorwillcausenoisebecausethevanecircumvolveinhighspeedandtheairflow.
Normalfanmotorand airflowshouldnotexceed32 dB.
2>.If thenoiseisextremelybig, theremaybethefan’sfault, thereason isfollowing:
a. Theaxletreeofthefanbroken
b. Thebadbalancebecausethefansabrasion
3>.Thefancanbereplacewithanothersamemodel’sfan, theprocedureisfollowing:
a. Howtoreplacetheevaporatorfan.
Theprocess ofevaporatorfan removed:Removetheshelves→removetheairductboard→disconnecttheconnectors
→removethefancoverremovethefan.
1>.Removetheshelves. (→3)(Fig.1)
2> .Removetheairductboard. See (→3)(Fig.2)
3>.Removescrews（A，B，C，D），thenreplacetheevaporatorfanSee (Fig.2&Fig.5)
b. Howtoreplacethecondenserfan:
1>.Removethescrews(3,4),takeaparttheelectricalbox（A）;(Fig.6)
2>.Pull offtheofthefanconnectoronthepowerPCB. (Fig.13)
3>.Leanbackthecabinet450,orputiton theworkbench,and usea Setofcross-screwdrivertowrest
off thetwoscrews(1,2)ofcompressorbottompenal,andremovethecondenserfantoreplacewithanewone.
(Fig.6&Fig.6.1)
Fig. 5

7
○Refrigerantjetnoise
Fault:a continuousnoiselikea watersprayfromthecapillary.
Causation:theendofthecapillaryisinthewrongposition,orthereareroughedgesontheendofthe
capillary.
Solution:
1>.Heatthesolderedjointofthecapillary (Fig.3showingApoint),thenremovethecapillaryfromthe
evaporatorand smooththeendwithaneraser. (Caution:donotallowanyparticlesintocapillaryunit).
2>.Replacethecapillaryintotheevaporator,thensolderitbackintothecorrectposition(notexceeding
15mm intheevaporator)and packthejointwithantivibrationcompound.
3>.Vacuumizeandrechargewithrefrigerant. See (→2)
○Capillaryvibrationnoise
Fault:highfrequencyimpactnoiseincapillaryZone. Causedbyeither
Causation:
1>.Thecapillarybeinginserttoo deepintotheevaporator,sowhentherefrigerantisJetting,theendof
vibrating capillarywillhittheinsideoftheevaporator.
2>.Vibrationfromthecapillarytouchingtheinsideofthecabinetorairductboard,thenwhenrefrigerant
isjetting.
Solution:
1>. If thecapillaryisinsertedtoodeep, heatitwiththesolder, solderitagain(Pleasenoted, thedeepinserted
isnotbiggerthan15mm), and vacuumizeitandadd therefrigerant. (→2)
2>.If thecapillarytouchtheinnercabinetortheairductpanel,adjustthepositionofthecapillaryand add
theincablocplastic. (Fig.3)
○Oil jamnoise
Fault:intermittentand deepjetnoisecomingfrominsideofthecapillary.
Causation:Compressoroilflowing intothecoolingsystempipeworkprobablyduetotheunitleaning during
Fig. 6 Fig. 6.1

8
transportation, and theoilformthejettingnoiseinthecapillary.
Solution:Cleanthecoolingsystempipe, andrechargewithrefrigerantsee (→2)
▲Evaporatorfreezing
○Becausethegasketisnotair-proof,orthedoorisnotclosedwell,causemuchwaterfillinthethe
cabinet,andthewatergotfrozenwhenitencounterthecoldair,sometimestheiceistoothick,anditwill
blockthefanorbrokenthefan.
Thesolution:
1>. Replace thedoorgasketorclosethedoorwell.Ifthedoorgasketisslightlynotair-proof,itcanbe
repairedbytheheatdryer.
Aiming atthedistortionofthegasketwiththeheatdryer, andmoveup anddownorrightandleft
until itexpandtothenormalstate.Whenitiscool,checkitwiththedoorclosed,ifthereisany
distortion, dryitagainuntilitfixforthedoor. (Fig.7)
▲Theinstabilityofthewinecoolertemperature
Theunstabletemperatureiscausedbytheevaporatorfanscease,anditcanbecheckbythebelowmethod:When
thecompressorisrunning,thelight “Run”ison,thefanshouldberunning,ifthefanstop,checkwhetherisany
faultinthefanorfanconnection. If thefanisbroken, replaceitwiththefanofthesamemodel. (Fig.5)
▲Thecontrolsystemfault
○Faultfindingbyself-checkmode
Thisserieswinecellarhasacomputerizedcontrollerwithbuiltinself-checkfunction.Startthe
self-checkmodeasfollows:
1>. Press andhold “Setlower”and “Setupper”buttonwithpoweron. 3beepswillsound, andthenthe
controllerwillstarttheself-checkfunction.
2>. Ifeverything isoperatingcorrectly,
a. Noresponsewhenpressingbuttons.
b. LEDdisplay”━━”；
c. Thecompressorworksandthe “RUN”indicatorlightareonall thetime.
d. Thecondenserandevaporatorfansworkatfull speed,thevalveswitcheverythree seconds;
Fig. 7

9
e. Theswitchcontrolsthelightfunctionsnormally.
3>．If theabovea~epointislineinthesituation,and everycomponentsofthemachineisnormal;ifthereis
any different,and firstlychecktheabnormalcomponentsand theirconnectionwire.If theconnectionistight,
replacethecomponents.If thereplacementfail,itcanbejudgedascontrolPCB’sfault,pleasereplaceitwith
thesamemodule. (Fig.10 &Fig.11)
4>．Unplugtheplugtoexittheself-examinationsystem.
○Sensorfault
1>．Afterturningonthepower,iftheLEDdisplayshowsthetemperatureissimilarwiththeambient
temperature,itisnormal,ifabnormal,pleaseremovetheelectricalbox, (Fig.10 &Fig.11)(→9),
checkthesensorinsert “X7”or“X8”whetherreliable. If theinsertisreliable, itisthesensor’s
fault,replacethesensorwiththesamemodule.
2>．TheLEDdisplayshowsE7,and itistheleftzone’ssensor opencircuit fault,checktheconnection
wireandthemainboardwhetheropencircuit,ifnot,replacethesensorwiththesamemodule.
See(Fig.8.)
3>．TheLEDdisplayshowsE8,and itistheleftzone’ssensor shortcircuit fault,checktheconnection
wireand themainboardwhethershortcircuit,ifnot,replacethesensorwiththesamemodule.
See(Fig.8.)
4>．TheLEDdisplayshowsE1,and itistherightzone’ssensor opencircuit fault, checktheconnection
wireandthemainboardwhetheropencircuit, ifnot, replacethesensorwiththesamemodule. See(Fig.8.)
5>．TheLEDdisplayshowsE2,and itistherightzone’ssensor shortcircuit fault, checktheconnection
wireand themainboardwhethershortcircuit,ifnot,replacethesensorwiththesamemodule.
See(Fig.8.)
6>．TheLEDdisplayshowsHI,and itisthehightemperatureprotectionindication.Afterrunning 10
hourswithpower,iftheinnertemperatureover230C.theLEDdisplayHI.WhentheHIshowsfor
anhour,thentheHItwinkling,buzzerthealarm.And aftertheHIiscontinuoustotwinklefor20
minutesmore, thecompressorwillstopworking, and it needtobecutoffpowertostopthealarm.
Thereasonandthesolutionofthisphenomenaisasfollowing.
A. If theleftand therightsidebothshowHI,thereasonisrefrigerantleakagecausethecooling
fault.Findtheleakagepoint, and welditagain, vacuumizeandrefill. (→2)
B. If any zoneshowsHI, thereasonisasfollowing
a.Becausethecapillaryisblocked, notcooling, pleasedoastheabovemethod. (→2)
b.Therefrigeratorvalvedamageandcannotbeswitch,causenotcooling,replacewiththenew
one.(Fig.9)
c.Theevaporatorfando notmove, rapairit.(Fig. 5)
7>．TheLEDdisplayshowsLO,itisthelowtemperatureprotectionindication.Theprincipleiswhen
thetemperatureofthecabinetislowerthan0℃,thesystemstartup lowtemperatureprotection
function,and nowtheLEDdisplayshowsLO,and thebuzzeralarm,themachineisforcedtostop,
soastoprotectthewinefromdamage.Whenthetemperatureofthecabinetishigherthan0℃,the
protectionwilldismiss automatically, and theLEDdisplayshowtheactualtemperature.
Note:theLOusuallyappearwhenthetemperaturesetbetween4~6℃,ifthetemperaturesethigher
than6℃,LOappear,and itisabnormal,theresolution ischeckwhetherthereisany voltageoutlet
therefrigerantvalve, ifno, changethecontrolboard.

10
○Howtoreplacethesensor
Theprocess ofsensorremoved:removetheshelves→removetheairductboard→disconnecttheconnectors→
removethesensorcover→removethesensor
Thesensorarefixontheairductboard(twozonearesame)
A. Removetheshelves. (→3)(Fig.1)
B. Removetheairductboard. See (→4)(Fig.2)
C.Pushand thenpull outthetwoplasticnails(1,2),thesensorcover(3) comeloose,disconnectthe
connector(5) ofthesensor, and replaceit(4). (Fig.8)
○Refrigerantvalvefault
Theprocess ofvalveremoved:removethecoverofthevalve→disconnecttheconnectors→disjointhe
solderedjoints→removevalve
1>．If thetemperatureofeitherzoneofleftand rightisnormal,and anotherzoneisnotcooling,orover
lowtemperature,(lowerthanthetemperaturepreset3℃),oronezoneisnotcoolingtheotherzone
isovercold, pleasechecktherefrigerantvalve.
2>．Turnoffthepower,exchangethetwopolesoftherefrigerantvalve,and turnonthepoweragain,
pleasepayattentiontothesoundsnip-snap,ortherefrigerantvalveoutoff powerorruins.Replace
thesamemodule’srefrigerantvalvewhenconfirmingthePCBboardisnormal.
3>．Howtoreplacetherefrigerantvalve:
A. Useweldingfacilitytoheatthe3weldingpointH,K,J,and thentakeofftherefrigerant
valve. (Fig. 9)
B.Usethecross screwdrivertowresttherefrigerantweldingscrew1(totally2pcs,anotherisn’t
showinthepicture.）; (Fig.9)
C.Replacewiththenewrefrigerantvalve,andvacuumizeit,and refillrefrigerant,completethe
replacement.
Fig.8

11
○LEDdisplayfault
Thisfaultcausedbyleddisplayerbroken，justchangeitwillbeOK. (Fig.10 &Fig.11)
○HowtoremovethepartsinsidethecontrolPCBelectricalbox(notice,themainPCBisinstallinginthe
electricalboxinrightzone)
Theprocess ofmainPCBremoved:removeall theshelvesinrightzone→takeaparttheelectricalboxinright
zone→disconnectall connectors→removethemainPCB
Theprocess ofdisplayPCB removed:removetheshelves→takeaparttheinnerelectricalbox→disconnectall
connectors→(ifnecessaryremovethemainPCB) →disconnecttheribbon cable→removethedisplay
PCB
1>．Removetheshelves ;(Fig.1)
2>．Screwthetwoboltsoutfromtheelectricalbox（3，4），halfloosethetwobolts(1，2）whichinthe
frontofthebox，pull theelectricalboxout (Fig.10 )
3>．Theexplodedrawing ofreplacedelectricalboxisbelow; (Fig.11)
Fig. 9
Fig. 10

12
4>．Unplugall theconnecters,thenpress theheadofeachofthefourplasticstuds(4)onebyone,and
moveup-wardthecontrolboard,removethecontrolboard,and replaceitwiththenewmodule.
See。(Fig. 11)
5>．ReplacetheLEDdisplayboard. Unplugthefour4displaycoverfastenersondisplayboardsupporter
（8）asperarrowheaddirection,and thenremovethedisplayboard,and itstwoconnectorsfrom
bothsides, Replacethedisplayboard. See (Fig. 11&Fig. 12)
○ThenameandexplanationofthemainPCBboardconnectors(Fig. 12)
X7:Torightzonesensor(yellow)
X8:Toleftzonesensor(white)
X9:Torightzonefan(yellow)
X3:Toleftzonefan(white)
X11、X12:ToleftzonedisplayPCB
X13、X14:TorightzonedisplayPCB
X15:ToLEDlight(red)
X16:TopowerPCB
Fig. 11
Fig. 12

13
○ThenameandexplanationofthepowerPCB (Fig. 13)
1.ToPTCheater(white)
2.Totransformerprimary(L)
3.Totransformerprimary(N)
4.TothemainpowerN
5.TothemainpowerL
6.Tothecompressor
7.Tothevalve
8.TothemainPCB(white)
9.Tothecondenserfan(Red)
10.Tothetransformersecondary
○HowtoremovethepowerPCBand transformer
Theprocess ofpowerPCB removed:removetheelectricalbox→disconnectall connectors→removethepower
PCB
Theprocessoftransformerremoved:removetheelectricalbox→disconnectthetransformerconnectors→remove
Fig. 13
Fig. 14

14
thetransformer
1>．Removethe2screws(1)；(Fig.14)
2>．Removetheelectricalbox；(Fig.14)
3>．Unplugall theconnecters,thenpress theheadofeachofthefourplasticscrews（4），moveup-ward
thepowerPCB（A），thenreplacea newone. (Fig.14)(ViewK)
4>．Plugall theconnecters;（Fig.13）
5>．Removethe2screws（B）andtransformer, thenreplacea newtransformer.(Fig.14)
○HowtoreplacetheLEDlight
Theprocess ofLEDlightremoved:removeall shelveinthezone→takeaparttheinnerelectricalbox→disconnect
lightconnector→(ifnecessaryremovethemainPCB) →removetheLEDlight
1>.FollowtheremovingmethodstoremovethePCBboard; (Fig.10 &Fig.11)
2>.ThenyouwillseetheLEDlightisdividedinto3parts,thenpullouttheline(1)followthearrowhead’s
heading;(Fig.15)
3>.Pull outfastenersoftheLEDinstalledboard (B) followthe ViewK pointl，atthetimepeakup theLED
lightboard(A)，thenchangetheLEDlightboard.
REV.C
Fig. 15
