WineEnthusiast Beverage Center User manual

.1
Wine Enthusiast
Panel Ready Wine Cellars &
Beverage Coolers
(Features and Size May Vary)
PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING AND OPERATING

2
IMPORTANT SAFEGUARDS
When using this appliance, always exercise basic safety precautions,
including the following:
1. Read all of the instructions before using this appliance.
2. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
3. Children should be supervised to ensure that they do not play with the appliance.
4. Use this appliance only for its intended purpose as described in this use and care guide.
5. This appliance must be properly installed in accordance with the installation instructions
before it is used. See grounding instructions in the installation section.
6. Never unplug your appliance by pulling on the power cord. Always grasp the plug firmly
and pull straight out from the outlet.
7. Unplug your appliance before cleaning or before making any repairs. Note: If for any
reason this product requires service, we strongly recommend that a certified technician
performs the service.
8. The SUPPLY CORD cannot be replaced. If the cord is damaged the appliance should be
scrapped.
9. This appliance is designed for free standing installation or can be recessed into
cabinetry.
10. DANGER: RISK OF CHILD ENTRAPMENT. Before you throw away your old
appliance, take off the doors. Leave the shelves in place so that children may not easily
climb inside.
11. Do not operate your appliance in the presence of explosive fumes.
12. Do not store foods in appliance as interior temperature may not be cool enough to
prevent spoilage or may cause bacteria growth.

3
SAVE THESE INSTRUCTIONS
DANGER
Risk of child entrapment.
Before you throw away your old appliance, take off the doors.
Leave the shelves in place so that children may not easily climb inside.
Thank you for using our Wine Enthusiast
product. This easy-to-use manual
will guide you in getting the best use of
your appliance.
Please remember to record the model and
serial number, they are located inside the cabinet
on a label on the bottom right side.
Staple your receipt to your manual.
You will need the receipt to obtain warranty service.
Model number
Serial number
Date of purchase

4
Table of Contents
IMPORTANT SAFEGUARDS .................................................2
Appliance Features and Use ................................................5
Initial Setup ..............................................................5
Temperature Adjustment ...................................................6
Shelving (Type and number of shelves will vary per model) .......................6
Charcoal Filter ............................................................6
Parts and Features ........................................................7
Installation as a Built-In Cellar...............................................8
Reversing the Door Swing ..................................................8
Instructions for Installing a Custom Panel.....................................10
Operating Your Appliance .................................................13
Control Panel Display .....................................................14
Setting the Temperature Control ............................................15
Lock or Unlock the Control Panel ............................................15
Removing the Rolling Shelf.................................................16
Normal Operating Sounds You May Hear......................................17
Technical Data ............................................................18
Proper Appliance Care and Cleaning........................................19
Troubleshooting ...........................................................20
Limited Warranty ........................................................22

5
Electrical Requirement
• Make sure there is a suitable power Outlet (115 volts, 15 amps outlet) with
proper grounding to power the appliance.
• Avoid the use of three plug adapters or cutting off the third grounding in order to
accommodate a two-plug outlet. This is a dangerous practice since it provides no
effective grounding for the appliance and may result in shock hazard.
Install Limitations
• Do not install your appliance in any location not properly insulated or heated e.g.
garage etc. Your appliance was not designed to operate in temperature settings
below 60° Fahrenheit.
• Select a suitable location for the appliance on a hard even surface away from
direct sunlight or heat source (e.g. radiators, baseboard heaters, cooking
appliances etc.). Any floor unevenness should be corrected with the leveling legs
located on the front and rear bottom corners of the appliance.
• This appliance is designed for free standing installation or can be recessed into
cabinetry.
Use of Extension Cords
• Avoid the use of an extension cord because of potential safety hazards under
certain conditions. If it is necessary to use an extension cord, use only a 3-wire
extension cord that has a 3-blade grounding plug and a 3-slot outlet that will
accept the plug. The marked rating of the extension cord must be equal to or
greater than the electrical rating of the appliance.
Appliance Features and Use
Initial Setup
• Before connecting the appliance to the power source, let it stand upright
for approximately 24 hours. This will reduce the possibility of a malfunction in
the cooling system from handling during transportation.

6
• Once you have plugged the unit into an electrical outlet, let the unit run for at
least 30 minutes to acclimate before making any adjustments.
Temperature Adjustment
• When the appliance is plugged in for the first time, the LED display will show the
factory preset temperature of 50°F.
• The appliance can be set to accommodate your wine storage requirements. To
set the temperature, press the up or down arrow button to increase or decrease
the temperature setting until the desired temperature is attained. It may take
some time to reach the set temperature.
•The temperature will fluctuate more so when the appliance is empty.
Shelving (Type and number of shelves will vary per model)
Your cabinet was designed to store a maximum number of bottles securely. We
recommend that you observe the tips below to optimize loading:
• Remove tape from shelves once unit is stable and ready for bottle storage.
• Disperse the bottles evenly to avoid concentrating weight in one place. Bottles
must not touch either the back of the cabinet or the step at the bottom. While
your appliance was designed to hold large format bottles, such as Pinot Noir and
Champagne, larger bottles reduce the number of bottles you can fit on a shelf.
• Make sure that the bottles are not all grouped together either at the top or
bottom of the cabinet.
• Only pull out one shelf at a time, never attempt to pull out more than one.
• Maximum weight capacity per shelf is 55 lbs.
•All shelves are full size steel with low profile scalloping to accommodate varying
bottle sizes except the shallow bottom wire shelf.
Charcoal Filter
Charcoal air filters ensure the natural ventilation and humidity control that
encourages wine to mature properly free from damaging odors.
We recommend you replace your filter every year, order part # 268 03 98 99 at
WineEnthusiast.Com.

7
Replacing the Charcoal Filter
Located on the back wall of your appliance, Turn
counterclockwise to unlock, then remove. Replace with a new
filter and turn clockwise to lock in place.
Parts and Features
Dual Zone
Single Zone

8
Installation as a Built-In Cellar
These cut out dimensions show the minimum space required for your appliance to
perform as designed.
Reversing the Door Swing
Before you begin: Tape down shelves to avoid movement during the
process
The door of this appliance can be hung to open on the left or right side. To reverse
the door swing of your cooler and open from the opposite side, please follow the
instructions and diagram below.
1．Open the door and loosen the screws from the support rod of the bottom hinge.

9
2．Remove the door off the upper hinge and take out the support rod.
3. Use a small flat head screwdriver to pry up the plastic cap on the top center
(lock hole) of the door and insert into the bottom center hole.
4. Unscrew the upper hinge and bottom hinge.
5. Pry out the plastic caps at the left side of the cabinet and move them to the
right side.
6. Install the hinge set which are packed as accessories with the instruction
manual to the opposite side.

10
7. Rotate the door 180o so that the top is now the bottom, and install it by
attaching the support rod with screws.
Instructions for Installing a Custom Panel
Your NFINITY Panel Ready Appliance is designed to accept a customer supplied
custom wood panel. The easiest means to attach the panel is by removing the
door, clamping the panel to the door and attaching with screws, then replacing the
door onto the unit.
1. Frame Preparation
-For a Right Hinge opening appliance, cut the panel to the dimensions in the
diagram below. Reverse for a left hinged opening appliance.

11
-Recommended panel thickness is ¾” (19mm) and should not weigh more
than 10 pounds.
-Panel dimensions shown below (in millimeters) are the size to cover the
appliance door. It can be made wider and/or taller to match surrounding
cabinetry, and you will need to make modifications to these instructions.

12
2. Remove the Door from the Appliance
-Follow steps 1 and 2 (only) in the section above Reversing the Door
Swing, save all the components.
-Pull off the rubber door seal to expose the screw holes.
3. Installing a Custom Handle
-If you are using your own custom handle, not supplied, then you should
attach the handle to the custom panel using countersunk screws.
-If you are using the handle provided proceed to the next step.
4. Clamp the Custom Panel to the Door Frame
-Be sure to align the panel with the top of the door frame.
-Center the panel along the width (side to side).
5. Attaching the Panel and Handle
-It is best to drill ½” pilot holes before attaching the door, this will help to
prevent the wood from splitting.
NOTE: BE CAFEFUL NOT TO DRILL THROUGH THE FRONT OF THE
WOOD PANEL
-Fasten the wood panel (A) using the 6 washers and screws, screwing
through the holes from the inside of the door through the gasket channel.
-NOTE: BEFORE YOU DRILL THE HOLES FOR THE HANDLE RE-CHECK
THEIR LOCATION, REFER TO THE DIAGRAM BELOW.
-Drill the handle holes (ONLY) through the wood.
-Attach the handle (B) using the long screws and washers provided.

13
6. Re-Install the Door
-Remove all clamps from the door frame.
-Replace the door gasket into the channel, pressing very firmly to re-install, it
might take some effort.
-Re-install the door onto the appliance following in reverse the procedures for
step 2 then step 1 in the section Reversing the Door Swing.
Operating Your Appliance
Each appliance includes an operating panel on the front of the unit. This operating
panel includes several features to operate and control the temperature.
Single Zone
Dual Zone
Display Icons

14
Control Panel Display
The control panel has a ‘sleep mode’ feature to hide the control buttons and display digits.
Gently touching the POWER button will cause all the control buttons to darken (hide), then
gently touching any of the controls will wake up and illuminate all of the buttons.
You also have the option of turning off the display temperature digits when the control
panel goes to sleep, with the control panel locked, holding the LIGHT button for 3 seconds
will cause the display temperature digits to darken (hide) in sleep mode. Holding the
LIGHT icon again for 3 seconds will reverse this feature.
Power: Turns the Appliance System ON and OFF (Hold for 3 sec.)
Touch Lightly to Activate ‘Sleep Mode’
Lighting: Turns the Interior Light ON and OFF (3-Stage)
Control Panel Lock: Single Zone –Press Both POWER AND LIGHT for 3 Seconds
to Lock or Unlock the Control Panel
Dual Zone –Press the LOCK Icon for 3 Seconds to Lock or
Unlock the Control Panel
Display Window: Displays Set and Actual Temperature
Temp. Up: Increases Set Temperature
Temp. Down: Decreases Set Temperature
Temp Up & Down: Pressing Simultaneously when Controls are Locked Alters the
Temperature Display to Fahrenheit or Celsius
Zone Select: Dual Zone Only –Press to Select Upper Zone (Left digits) or
Lower Zone (Right Digits) when Setting the Temperatures

15
Before You Start
The appliance should be placed in a location where the ambient temperature is between
60-80°Fahrenheit. If the ambient temperature is above or below this range, the
performance of the unit may be affected. For example, placing your unit in extreme cold
or hot conditions may cause interior temperatures to fluctuate.
Setting the Temperature Control
NOTE: The temperature readout shows the actual cellar temperature, it will
temporarily show the set temperature while making adjustments then reverts back
after 5 seconds.
1. Make sure power cord is connected to a properly grounded outlet.
2. Turn power ON.
3. Dual Zone Models: Use the Zone Select button to select the Upper or
Lower zone. Upper zone must be set 4°F colder than lower zone.
4. Set the desired temperature by pushing the Temp UP or DOWN button.
5. Temperatures increase or decrease 1°F with each push of the UP or
DOWN button.
NOTE: Temperatures may fluctuate depending on whether the interior light is ON
or OFF and depending on the position of the bottles.
Lock or Unlock the Control Panel
To LOCK the control panel:
1. Single Zone: simultaneously press the POWER and LIGHT buttons for 3
seconds.
Dual Zone: press and hold the LOCK button for 3 seconds.
2. The control panel will beep and the LOCK icon will illuminate
To UNLOCK the control panel:
1. Touch the control panel to wake it up from sleep mode
2. Single Zone: simultaneously press the POWER and LIGHT buttons for 3
seconds.
Dual Zone: press and hold the LOCK button for 3 seconds.
3. The control panel will beep and the LOCK icon will darken

16
Removing the Rolling Shelf
1. Remove all bottles.
2. Pull out the shelf as far as possible.
3. Hold one of the telescopic rails with one hand, with the other hand gently lift
the front of the shelf from the front tab, then push backward to unlock from
the rear hook.
4. Repeat with the other side
Temperature Settings for Serving Wine
Although optimal storage temperature is generally regarded to be 53-57°F,
different varietals of wine require different service temperature settings. The
recommended temperature ranges for serving different varietals of wine are listed
below. Your appliance will indicate when you have set the Upper/Lower zones to
the below temperature ranges.
Red Wines: 60-66°F
White Wines 45-52°F
Sparkling Wines 40-45°F

17
Interior Light
• To complement the look of your wine collection, 3 stage lighting has been built
into the appliance. Simply push the "Light" button once (1X) for 100%, twice (2X)
for 50% and thrice (3X) for OFF. For maximum energy efficiency, leave light off
when not viewing your collection.
Normal Operating Sounds You May Hear
• Boiling water, gurgling sounds or slight vibrations that are the result of the
refrigerant circulating through the cooling coils.
• The thermostat control will click when it cycles on and off.

18
Technical Data
Model
Beverage Center
Single Zone
Dual Zone*
Installation
Free-Standing or Built-In
Power
115V~60Hz
Total Volume
5.12 Cu. Ft.
Current
1.6A
Start-Up Amps
7.3A
Running Amps
1.6A
Refrigerant
R600a –0.88 oz.
Protection
Class
I
Climate Class
T
Ambient
Temperature
60 - 80°F
Temperature
Control Range*
36°F to 68°F
41°F to 72°F
Upper Zone:
41°F to 54°F
Lower Zone:
54°F to 66°F
Net Wt. LBS.
128
132
141
*Upper zone must be set 4°F colder than lower zone.

19
Proper Appliance Care and Cleaning
Cleaning and Maintenance
Warning: To avoid electric shock always unplug your appliance before cleaning.
Ignoring this warning may result in death or injury.
Caution: Before using cleaning products, always read and follow manufacturer’s
instructions and warnings to avoid personal injury or product damage.
General: • Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed
with 2 cups of warm water or use one part borax for ten parts water
(about one cup per gallon). Use sponge or soft cloth, dampened with
the cleaning solution, to wipe down your appliance.
• Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,
concentrated detergents, solvents or metal scouring pads. Some of
these chemicals may dissolve, damage and/or discolor your appliance.
Mold on the interior
Microscopic mold spores are naturally occurring and present in the
ambient air. When mold gets in your appliance it may grow within the
humid environment. Removal can be completed with mild solutions of
commonly available products such as Borax, vinegar, or baking soda.
Door Gaskets:
• Clean door gaskets every three months according to general
instructions. Gaskets must be kept clean and pliable to assure a
proper seal.
• Petroleum jelly applied lightly on the hinge side of gaskets will keep
the gasket pliable and assure a good seal.

20
Power Interruptions
• Occasionally there may be power interruptions due to thunderstorms
or other causes. Remove the power cord from AC outlet when a power
outage occurs. When power has been restored, wait 3 to 5 minutes
then re-plug the power cord to AC outlet.
Vacation and Moving Care
• For long vacations or absences, unplug the appliance and clean the
appliance and door gaskets according to "General cleaning" section.
Leave doors open, so air can circulate inside.
• Always move the appliance vertically. Do not move with the unit
lying down, as possible damage to the sealed system could occur.
Note: After moving, wait for 24 hours before plugging in the
appliance.
Troubleshooting
Many common issues with your appliance can be easily solved. Try the troubleshooting
tips below if you experience any problems.
Appliance Does Not Operate:
• Check if appliance is plugged in.
• Check if there is power in the AC outlet, by checking the circuit
breaker.
Wine appears too warm:
• Frequent door openings.
• Allow time for recently added wine to reach desired temperature.
• Check gaskets for proper seal.
• Clean condenser coils.
• Adjust temperature control to colder setting.
