Carel ir33 platform User manual

1
Integrated Electronic
Microprocessor Controller
Read And Save These Instructions - Page 1 of 3
Programming The Instrument
To Modify The Setpoint
Press and hold the “SET” key for at least 1 second.
2. Use arrow keys ▲▼on temperature
controller to increase (or decrease) the
setpoint.
3. Quickly press and release the “SET” key again.
To Modify Defrost, Differential or Other Parameters
1. Press & hold “Prg” & “SET” keys together
for five (5) seconds; display will flash “0”,
representing password prompt.
2. Confirm by pressing “SET” key.
3. Press ▲or ▼to reach the
category to be modified.
4. Press “SET” to modify this selected parameter.
5. Increase or decrease the value using
the ▲or ▼button respectively.
6. Press the “SET” key to temporarily save the new
value and return to the display of the parameter.
7. Press & hold the “Prg” key for at least 5 seconds
to save changes. This action will also mute the
audible alarm (buzzer) & deactivate the alarm relay.
Warning! Save Your Parameter Settings!
1. To store the new parameter values, PRESS and HOLD the “Prg” key for at least 5 seconds.
2. All modifications made to parameters will be lost if you do NOT press a button within 60 seconds. Should
this “timeout” occur, normal operational settings (prior to modifications being made) will resume.
3. If the instrument is switched off before pressing the “Prg” key, all modifications to parameters will be lost.
Set
Set
▲
aux
Prg
mute
def
▼
Prg
mute
Set
Set
def
▼
Set
▲
aux
▲
aux def
▼
Set
Prg
mute
Structural Concepts Corp., 888 E. Porter Rd · Muskegon, MI 49441
Ph: 231.798.8888 / Fax: [phone] / www.structuralconcepts.com I:\Oper Manuals - PUB\Templates\Carel Controller\Carel Controller IR33.pub
This data derived from Carel Material: ir33 +030220441 - rel. 2.0 - 01.05.2006
How To Change Reading From
Fahrenheit (°F) To Celsius (°C)
1. Press and hold “Prg” and “SET” keys
together for at least 5 seconds; display will
show “0”, representing password prompt.
2. Confirm by pressing “SET” key.
3. Press ▲or ▼until reaching the
parameter “/ 5”.
4. Press “SET” to modify this selected parameter.
5. Press ▲or ▼to change value to desired
setting: “0” for Celsius (°C) or “1” for
Fahrenheit (°F).
6. Press “SET” key to temporarily save the new
value and return to the display of the parameter.
7. Press & hold “Prg” key for at least 5 seconds to
save changes. Note! All values will automatically
convert to new scale. No conversion is required.
Prg
mute
Set
Set
def
▼
▲
aux
Set
▲
aux def
▼
Set
Prg
mute
Set
def
▼
▲
aux
To Activate / Deactivate Auxiliary Output
Press and hold the “aux” key for 1 second.
▲
aux
To Activate Manual Defrost
Press and hold the “def” key for at least 5 seconds.
def
▼To Reset Any Alarms With Manual
Reset
Press and hold the “Prg” and “aux”
key for at least 1 second.
▲
aux
Prg
mute

Integrated Electronic
Microprocessor Controller
Read And Save These Instructions - Page 2 of 3
User Interface - Display
resetalarmsw/manualreset/ reset HACCP alarms / reset temp. monitoring
Summary Table of Alarm and Signals: Display, Buzzer and Relay
Structural Concepts Corp., 888 E. Porter Rd · Muskegon, MI 49441
Ph: 231.798.8888 / Fax: [phone] / www.structuralconcepts.com 2 I:\Oper Manuals - PUB\Templates\Carel Controller\Carel Controller IR33.pub
This data derived from Carel Material: ir33 +030220441 - rel. 2.0 - 01.05.2006

Integrated Electronic
Microprocessor Controller
Read And Save These Instructions - Page 3 of 3
Summary Table of Operating Parameters
CODE PARAMETER UOM* TYPE MINIMUM MAXIMUM DEFAULT
/c1 Calibration of probe 1 °C/°F C -20 20
/c2 Calibration of probe 2 °C/°F C -20 20
St Temperature set point °C/°F F r2 r1
rd Control delta °C/°F F 20 0.1
dl Interval between defrosts hours F 0 250
dt1 End defrost temperature, evaporator °C/°F F -50 200
dP1 Maximum defrost duration, evaporator min F 1 250
d6 Display on hold during defrost - C 0 2
dd Dripping time after defrost min F 0 15
d/1 Display of defrost probe 1 °C/°F F - -
/5 Select Celcius (°C) or Fahrenheit (°F) flag C 0 1
Structural Concepts Corp., 888 E. Porter Rd · Muskegon, MI 49441
Ph: 231.798.8888 / Fax: [phone] / www.structuralconcepts.com 3 I:\Oper Manuals - PUB\Templates\Carel Controller\Carel Controller IR33.pub
This data derived from Carel Material: ir33 +030220441 - rel. 2.0 - 01.05.2006
For Case
Specific
Defaults
See Serial
Label
Located
Near
Electrical
Access
On Your
Case.
For
Additional
Technical
Information
Call
Structural
Concepts
Technical
Service
Dept. at
1(800)
433.9489
* Unit Of Measure
