24ABC6
Baset16 Air Conditioner
with PuronrRefrigerant
Product Data
the environmentally sound refrigerant
Carrier’s Air Conditioners with Puronrrefrigerant provide a
collection of features unmatched by any other family of
equipment. The 24ABC has been designed utilizing Carrier’s
Puron refrigerant. The environmentally sound refrigerant allows
you to make a responsible decision in the protection of the earth’s
ozone layer.
As an Energy StarrPartner, Carrier Corporation has determined
that this product meets the Energy Starrguidelines for energy
efficiency. Refer to the combination ratings in the Product Data
for system combinations that meet Energy Starrguidelines.
NOTE:Ratings contained in this document are subject to
change at any time. Always refer to the AHRI directory
(www.ahridirectory.org) for the most up--to--date ratings
information.
INDUSTRY LEADING
FEATURES / BENEFITS
Efficiency
S14 -- 16.5 SEER/11.0-- 13.5 EER
SMicrotube Technologytrefrigeration system
SIndoor air quality accessories available
Sound
SSound level as low as 76 dBA
SSound level as low as 74 dBA with accessory sound
blanket
Comfort
SSystem supports EdgerThermidistattor standard
thermostat controls
Reliability
SPuronrrefrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime servce cost.
SScroll compressor
SInternal pressure relief valve
SInternal thermal overload
SFilter drier
SBalanced refrigeration system for maximum reliability
Durability
WeatherArmortprotection package:
SSolid, durable sheet metal construction
SDense wire coil guard available
SBaked--on, complete outer coverage, powder paint
Applications
SLong--line -- up to 250 feet (76.20 m) total equivalent
length, up to 200 feet (60.96 m) condenser above
evaporator, or up to 80 ft. (24.38 m) evaporator above
condenser (See Longline Guide for more information.)
SLow ambient (down to --20_F/--28.9_C)) with
accessory kit

2
MODEL NUMBER NOMENCLATURE
12 3 4 5 6 78 9 10 11 12 13
N N A A A/N N N N A/N A/N A/N N N
24 A B C 6 36 A 0 0 3 0
Product
Series
Product
Family Tier Major Series SEER Cooling Capacity
Grille
Variations Open Open Voltage Series
24=AC A=RES AC B=Base C=Puron 6=16 SEER A=Dense
W=Standard
0=Not
Defined
0=Not
Defined
3=208/230---1 0=
Original
Series
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
This product has been designed and manufactured to
meet Energy Star®criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
STANDARD FEATURES
Feature 18 24 30 36 42 48 49 60
Puron Refrigerant XXXXXXXX
Maximum SEER * 16.0 16.0 16.5 16.5 16.0 16.0 16.0 16.0
Scroll Compressor XXXXXXXX
FieldInstalledFilterDrier XXXXXXXX
Front Seating Service Valves XXXXXXXX
Internal Pressure Relief Valve XXXXXXXX
Internal Thermal Overload XXXXXXXX
Long Line capability XXXXXXXX
Low Ambient capability with Kit XXXXXXXX
* With approved combinations
X=Standard
PHYSICAL DATA
UNIT SIZE --- VOLTAGE, SERIES 18 --- 31 24--- 30 30 --- 30 36 --- 30 42--- 30 48 --- 30 60--- 30
Operating Weight lb (kg) 125
(56.7)
147
(66.5)
153
(69.3)
165
(74.8)
213
(96.4)
231
(104.8)
272
(123.4)
Shipping Weight lb (kg) 154
(69.9)
183
(82.8)
188
(85.2)
204
(92.5)
254
(115.2)
274
(124.3)
310
(140.6)
Compressor Type Scroll
REFRIGERANT Puron®(R---410A)
Control TXV (Puron®Hard Shutoff)
Charge lb (kg) 4.60
(2.09)
6.00
(2.72)
6.81
(3.09)
7.00
(3.18)
8.62
(3.91)
10.50
(4.76)
14.50
(6.58)
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 1881 2614 2614 3223 3810 4046 4046
Motor HP 1/12 1/10 1/10 1/12 1/5 1/4 1/4
Motor RPM 1100 1100 1100 800 800 800 800
COND COIL
Face Area (Sq ft) 11.50 15.10 17.20 17.60 25.15 20.10 30.15
Fins per In. 25 25 25 25 25 20 20
Rows 1 1 1 1 1 2 2
Circuits 3 4 4 4 6 7 8
VALVECONNECT.(In.ID)
Vapor 3/4 3/4 3/4 7/8 7/8 7/8 7/8
Liquid 3/8 3/8 3/8 3/8 3/8 3/8 3/8
REFRIGERANT TUBES (In. OD)
Rated Vapor* 3/4 7/8 1 --- 1 / 8
Max Liquid Line {3/8
* Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
Note: See unit Installation Instruction for proper installation.
{See Liquid Line Sizing For Cooling Only Systems with Puron Refrigerant tables.
24ABC6

3
REFRIGERANT PIPING LENGTH LIMITATIONS
Liquid Line Sizing and Maximum Total Equivalent Lengths{for Cooling Only Systems with PuronrRefrigerant:
The maximum allowable length of a residential split system depends on the liquid line diameter and vertical separation between indoor and
outdoor units.
See Table below for liquid line sizing and maximum lengths :
Maximum Total Equivalent Length
Outdoor Unit BELOW Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/ TXV
AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit BELOW Indoor
Vertical Separation ft (m)
0 --- 5
(0---1.5)
6 --- 1 0
(1.8---3.0)
11---20
(3.4---6.1)
21---30
(6.4---9.1)
31---40
(9.4---12.2)
41---50
(12.5---15.2)
51---60
(15.5---18.3)
61---70
(18.6---21.3)
71---80
(21.6---24.4)
18000
AC with
Puron
3/8
1/4 150 150 125 100 100 75 --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 250* 250* 225* 150
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
24000
AC with
Puron
3/8
1/4 75 75 75 50 50 --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 225* 175 125 100
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
30000
AC with
Puron
3/8
1/4 30 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
5/16 175 225* 200 175 125 100 75 --- --- --- ---
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
36000
AC with
Puron
3/8 5/16 175 150 150 100 100 100 75 --- --- --- ---
3//8 250* 250* 250* 250* 250* 250* 250* 250* 250*
42000
AC with
Puron
3/8 5/16 125 100 100 75 75 50 --- --- --- --- --- ---
3/8 250* 250* 250* 250* 250* 250* 250* 250* 150
48000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 230 160 --- ---
60000
AC with
Puron
3/8 3/8 250* 250* 250* 225* 190 150 110 --- --- --- ---
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
Maximum Total Equivalent Length
Outdoor Unit ABOVE Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/ TXV
AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit ABOVE Indoor
Vertical Separation ft (m)
25
(7.6)
26---50
(7.9---15.2)
51---75
(15.5---22.9)
76---100
(23.2---30.5)
101---125
(30.8---38.1)
126---150
(38.4---45.7)
151---175
(46.0---53.3)
176---200
(53.6---61.0)
18000
AC with
Puron
3/8
1/4 175 250* 250* 250* 250* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
24000
AC with
Puron
3/8
1/4 100 125 175 200 225* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
30000
AC with
Puron
3/8
1/4 30 --- --- --- --- --- --- --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
36000
AC with
Puron
3/8 5/16 225* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
42000
AC with
Puron
3/8 5/16 175 200 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
48000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
60000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
24ABC6

4
REFRIGERANT CHARGE ADJUSTMENTS
Liquid Line Size Puron Charge oz/ft
3/8 0.60
(Factory charge for lineset = 9 oz)
5/16 0.40
1/4 0.27
Units are factory charged for 15 ft (4.6 m) of 3/8” liquid line. The factory charge for 3/8” lineset 9 oz. When using other length or diameter
liquid lines, charge adjustments are required per the chart above.
Charging Formula:
[(Lineset oz/ft x total length) – (factory charge for lineset)] = charge adjustment
Example 1: System has 15 ft of line set using existing 1/4“ liquid line. What charge adjustment is required?
Formula: (.27 oz/ft x 15ft) – (9 oz) = (-4.95) oz.
Net result is to remove 4.95 oz of refrigerant from the system
Example 2: System has 45 ft of existing 5/16” liquid line. What is the charge adjustment?
Formula: (.40 oz/ft. x 45ft) – (9 oz.) = 9 oz.
Net result is to add 9 oz of refrigerant to the system
LONG LINE APPLICATIONS
An application is considered Long Line, when the refrigerant level in the system requires the use of accessories to maintain acceptable
refrigerant management for systems reliability. See Accessory Usage Guideline table for required accessories. Defining a system as long line
depends on the liquid line diameter, actual length of the tubing, and vertical separation between the indoor and outdoor units.
For Air Conditioner systems, the chart below shows when an application is considered Long Line.
AC WITH PURONrREFRIGERANT LONG LINE DESCRIPTION ft (m)
Beyond these lengths, long line accessories are required
Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor
1/4 No accessories needed within allowed
lengths
No accessories needed within allowed
lengths 175 (53.3)
5/16 120 (36.6) 50 (15.2) 120 (36.6)
3/8 80 (24.4) 35 (10.7) 80 (24.4)
Note: SeeLongLineGuidelinefordetails
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line
diameters shown in the chart below are acceptable for AC systems with Puron refrigerant:
Unit
Nominal
Size (Btuh)
Maximum
Liquid Line
Diameters
(In. OD)
Vapor Line
Diameters
(In. OD)
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. (m)
26 --- 50
(7.9---15.2)
51 --- 80
(15.5---24.4)
81 --- 100
(24.7---30.5)
101 --- 125
(30.8---38.1)
126 --- 150
(38.4---45.7)
151 --- 175
(46.0---53.3)
176 --- 200
(53.6---61.0)
201 --- 225
(61.3---68.6)
226 --- 250
(68.9---76.2)
18000
1Stage
AC with
Puron
3/8
1/2 1 2 3 5 6 7 8 9 11
5/8 0 1 1 1 2 2 2 3 3
3/4 0 0 0 0 1 1 1 1 1
24000
1Stage
AC with
Puron
3/8
5/8 0 1 2 2 3 3 4 5 5
3/4 0 0 1 1 1 1 1 2 2
7/8 0 0 0 0 0 1 1 1 1
30000
1Stage
AC with
Puron
3/8
5/8 1 2 3 3 4 5 6 7 8
3/4 0 0 1 1 1 2 2 2 3
7/8 0 0 0 0 1 1 1 1 1
36000
1Stage
AC with
Puron
3/8
5/8 1 2 4 5 6 8 9 10 12
3/4 0 1 1 2 2 3 3 4 4
7/8 0 0 0 1 1 1 1 2 2
42000
1Stage
AC with
Puron
3/8
3/4 0 1 2 2 3 4 4 5 6
7/8 0 0 1 1 1 2 2 2 3
11/8 0 0 0 0 0 0 0 0 0
48000
1Stage
AC with
Puron
3/8
3/4 0 1 2 3 4 5 5 6 7
7/8 0 0 1 1 2 2 2 3 3
11/8 0 0 0 0 0 0 0 1 1
60000
1Stage
AC with
Puron
3/8
3/4 1 2 4 5 6 7 9 10 11
7/8 0 1 2 2 3 4 4 5 5
11/8 0 0 0 1 1 1 1 1 1
Applications in this area may be long line and may have height restrictions. See the Residential Piping and Long Line Guideline.
24ABC6

5
ACCESSORY THERMOSTATS
THERMOSTAT / SUBBASE
PKG. DESCRIPTION
T P --- P R H 0 1 --- A Programmable Thermidistat
T P --- N R H 0 1 --- A Non--- programmable Thermidistat
T P --- P A C 0 1 Performance Series Programmable AC Stat
T P --- N A C 0 1 Performance Series Non--- programmable AC Stat
T C --- P A C 0 1 Comfort Series Programmable AC Stat
T C --- N A C 0 1 Comfort Series Non ---programmable AC Stat
T B --- P A C 0 1 Base Series Programmable AC Stat
T B --- N A C 0 1 Base Series Non---programmable AC Stat
TSTATCCSEN01---B Outdoor Air Temperature Sensor
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXNBP01 Backplate for Non --- Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat
TSTATXXCNV10 Thermostat Conversion Kit (4 to 5 wires) --- 10 Pack
ACCESSORIES
KIT NUMBER DESCRIPTION Size --- Voltage & Series
18 --- 31 24 --- 30 30 --- 30 36--- 30 42 --- 30 48--- 30 60 --- 30
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X
KAATD0101TDR TIME DELAY RELAY X X X X X X X
KSALA0301410 LOW AMBIENT PSW X X X X X X X
KSALA0601AAA{MOTORMASTER 230V X X X X X X X
HC32GE234 MOTOR FAN BALL BEARING X
HC34GE240 MOTOR FAN BALL BEARING X X
HC32GE229 MOTOR FAN BALL BEARING X
HC38GE228 MOTOR FAN BALL BEARING X
HC40GE228 MOTOR FAN BALL BEARING X X
KSAHS1701AAA HARD START (CAP / RELAY) X X X X X X X
KSACY0101AAA CYCLE PROTECTOR X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X
KAACS0201PTC START ASSIST PTC X X X X X X X
KAALS0201LLS LIQUID LINE SOLENOID X X X X X X X
KAAWS0101AAA WINTER START X X X X X X X
KAACH1701AAA CRANKCASE HTR X X X X
KAACH1601AAA CRANKCASE HTR X S S
KSATX0201PUR TXV PURON HSO X X X
KSATX0301PUR TXV PURON HSO X
KSATX0401PUR TXV PURON HSO X
KSATX0501PUR TXV PURON HSO X X
KSASH0601COP SOUND HOOD X X X X
KSASH2101COP SOUND HOOD X X X
KAALP0401PUR LOW PRESSURE SWITCH X X X X X X X
KAAHI0501PUR HIGH PRESSURE SWITCH X X X X X X X
{Required accessories include ball bearing fan motor, compressor start assist (CAP / Relay), crankcase heater, evaporator freeze stat, hard shut---off TXV.
X = Accessory / S --- Standard
24ABC6

6
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW--- AMBI-
ENT COOLING APPLICATIONS
(Below 55°F/12.8_C)
REQUIRED FOR LONG
LINE
APPLICATIONS*
(Over 80 ft./24.38 m)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within2miles/3.22km)
Ball Bearing Fan Motor Yes{No No
Compressor Start Assist Capacitor and Relay Yes Yes No
Crankcase Heater Yes Yes No
Evaporator Freeze Thermostat Yes No No
H a r d S h u t --- O f f T X V Yes Yes Yes
Liquid Line Solenoid Valve No No No
Motor Master®Control or
L o w --- a m b i e n t P r e s s u r e S w i t c h Yes No No
Support Feet Recommended No Recommended
Winter Start Control Yes No No
* For tubing line sets between 80 and 200 ft. (24.38 and 60.96 m) and/or 20 ft. (6.09 m) vertical differential, refer to Residential Split---System Longline
Application Guideline.
{Required for Low---Ambient Controller (full modulation feature) MotorMasterrControl.
Accessory Description and Usage (Listed Alphabetically)
1. Ball--Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.
Usage Guideline:
Required on all units when MotorMasterris used.
2. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.
Usage Guideline:
Required for reciprocating compressors in the
following applications:
Long line
Low ambient cooling
Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil
Required for single--phase scroll compressors in the
following applications:
Long line
Low ambient cooling
Suggested for all compressors in areas with a history of
low voltage problems.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.
Usage Guideline:
Suggested in installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
5. Cycle Protector
The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5--minute delay
after power to the compressor has been interrupted for any
reason, including power outage, protector control trip, thermostat
jiggling, or normal cycling.
6. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
Required when low ambient kit has been added.
7. Low--Ambient Pressure Switch Kit
A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in
order to maintain head pressure within normal operating limits
(approximately 100 psig to 225 psig). The control will maintain
working head pressure at low--ambient temperatures down to 0_F
(--18_C) when properly installed.
Usage Guideline:
A Low--Ambient Pressure Switch or MotorMasterr
Low--Ambient Controller must be used when cooling operation is
used at outdoor temperatures below 55_F (12.8_C).
8. MotorMasterrLow--Ambient Controller
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C),
it maintains condensing temperature at 100_F±10_F (37.8_C±
5.5_C).
Usage Guideline:
A MotorMasterrLow Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
9. Outdoor Air Temperature Sensor
Designed for use with Carrier Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also
is required to enable special thermostat features such as auxiliary
heat lock out.
Usage Guideline:
Suggested for all Carrier thermostats listed in this
publication.
24ABC6

7
Accessory Description and Usage (Listed Alphabetically) (Continued)
10. Sound Hood
Wraparound sound reducing cover for the compressor. Reduces
the sound level by about 2 dBA.
Usage Guideline:
Suggested when unit is installed closer than 15 ft (4.57 m) to
quiet areas, bedrooms, etc.
Suggested when unit is installed between two houses less
than 10 ft (3.05 m) apart.
11. Support Feet
Four stick--on plastic feet that raise the unit 4 in. (101.6 mm)
above the mounting pad. This allows sand, dirt, and other debris
to be flushed from the unit base, minimizing corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
12. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.
NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Required to achieve ARI ratings in certain equipment
combinations. Refer to combination ratings.
Hard shut off TXV or LLS required in air conditioner
long line applications.
Required for use on all zoning systems.
13. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
NOTE: Most indoor unit controls include this feature. For those
that do not, use the guideline below.
Usage Guideline:
For improved efficiency ratings for certain
combinations of indoor and outdoor units. Refer to
ARI Unitary Directory.
14. Winter Start Control
This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.
24ABC6

8
ELECTRICAL DATA
UNIT SIZE V/PH
OPER VOLTS* COMPR FAN
MCA
MIN WIRE
SIZE{
60°C
MIN WIRE
SIZE{
75°C
MAX
LENGTH
ft. (m)}
60°C
MAX
LENGTH
ft. (m)}
75°C
MAX FUSE**
or CKT BRK
AMPS
MAX MIN LRA RLA FLA
18 --- 31
208/230/1---60 253 197
48.0 9.0 0.50 11.8 14 14 67 (20.4) 64 (19.5) 20
24 --- 30 58.3 13.5 0.75 17.7 14 14 46 (14.0) 43 (13..1) 25
30 --- 30 64.0 12.8 0.75 16.8 14 14 44 (13.4) 41 (12.5) 25
36 --- 30 77.0 14.1 0.50 18.1 12 12 57 (17.4) 54 (16.5) 30
42 --- 30 112.0 17.9 1.20 23.6 10 10 85 (25.9) 81 (24.7) 40
48 --- 30 109.0 19.9 1.20 26.1 10 10 70 (21.3) 67 (20.4) 40
60 --- 30 135.0 21.4 1.20 28.0 810 91 (27.7) 56 (17.1) 40
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{If wire is applied at ambient greater than 30_C, consult table 310---16 of the NEC (NFPA 70). The ampacity of non ---metallic---sheathed cable (NM), trade
name ROMEX, shall be that of 60_C conditions, per the NEC (NFPA 70) Article 336---26. If other than uncoated (no---plated), 60 or 75_C insulation, copper
wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (NFPA 70).
}Length shown is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2007 requirements of ASHRAE Standards 90.1
A--WEIGHTED SOUND POWER LEVEL (dBA)
U n i t S i z e ---
Voltage, Series
Standard
Rating (dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA without tone adjustment)
125 250 500 1000 2000 4000 8000
18 --- 31 76 52.5 59.0 65.5 70.5 64.5 59.0 54.5
24 --- 30 76 57.5 64.0 69.0 71.0 69.0 64.5 60.0
30 --- 30 76 55.0 63.5 68.0 69.5 67.0 63.5 58.5
36 --- 30 76 50.5 59.5 64.5 70.5 62.0 59.5 54.5
42 --- 30 78 52.5 62.0 66.0 73.5 68.0 62.0 55.5
48 --- 30 78 58.0 62.0 65.0 66.5 62.5 59.5 56.5
60 --- 30 78 55.0 62.5 67.5 70.5 65.0 61.0 53.5
NOTE: Tested in accordance with ARI Standard 270---08 (not listed in AHRI).
A--WEIGHTED SOUND POWER LEVEL (dBA) WITH SOUND SHIELD
U n i t S i z e ---
Voltage, Series
Standard
Rating (dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA without tone adjustment)
125 250 500 1000 2000 4000 8000
18 --- 31 74 55.5 59.0 65.0 68.5 63.5 58.0 52.0
24 --- 30 75 58.0 64.0 69.0 70.5 68.5 64.5 59.5
30 --- 30 75 55.5 63.0 68.0 69.0 67.0 63.0 58.5
36 --- 30 74 51.5 58.5 62.0 65.0 61.0 58.0 52.0
42 --- 30 76 53.0 62.0 65.5 72.0 65.0 61.0 54.0
48 --- 30 76 60.0 63.5 65.0 65.5 62.0 58.0 52.5
60 --- 30 75 56.5 62.5 66.5 68.0 63.0 59.5 51.5
NOTE: Tested in accordance with ARI Standard 270---08 (not listed in AHRI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- VOLTAGE, SERIES REQUIRED SUBCOOLING _F(_C)
18 --- 31 10 (5.6)
24 --- 30 10 (5.6)
30 --- 30 10 (5.6)
36 --- 30 10 (5.6)
42 --- 30 9 (5.0)
48 --- 30 10 (5.6)
60 --- 30 9 (5.0)
24ABC6

9
DIMENSIONS -- ENGLISH
B
3"
K
5/16"
L
C3 1/2"
1 7/8"
N
P
M
E
F
G
A
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SERIES ELECTRICAL
CHARACTERISTICS ABCDEFGKLMNP
OPERATING
WEIGHT (lbs)
SHIPPING
WEIGHT (lbs)
SHIPPING
DIMENSIONS (L x W x H)
24ABC618 1 X O O O
24ABC624 0 X O O O 31 3/16" 28 5/16" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 16" 16" 13" 147 183 32 3/8" X 35 1/2" X 32 9/16"
24ABC630 0 X O O O 31 3/16" 32 5/16" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 15 1/2" 16" 14 1/4" 153 188 32 3/8" X 35 1/2" X 35 15/16"
24ABC636 0 X O O O 35" 28 5/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16" 16" 13" 165 204 36 1/8" X 39 5/16" X 32 9/16"
24ABC642 0 X O O O 35" 39 1/8" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16 1/2" 17 1/2" 17 1/2" 213 254 36 1/8" X 39 5/16" X 42 3/4"
24ABC648 0 X O O O 35" 32 5/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17" 17 1/2" 14 1/4" 231 274 36 1/8" X 39 5/16" X 35 15/16"
24ABC660 0 X O O O 35" 45 15/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16 1/2" 17" 16 1/4" 272 310 36 1/8" X 39 5/16" X 49 9/16"
25 3/4" 28 11/16" 3 3/4" 3/4" 4 7/16" 21 1/4" 7 13/16" 2 13/16" 1/2" 13 5/8" 13 1/2" 12 3/4" 125 154 26 7/8" X 30 1/16" X 32 9/16"
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
18 26" X 26"
24,30 31 1/2" X 31 1/2"
36 THRU 60 35" X 35"
AIR DISCHARGE
SQ.
AIR DISCHARGE
AIR IN
VAPOR LINE CONN.
D
3/8"
LIQUID LINE CONN.
AIR IN
AIR IN
AIR IN
3/8" TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
7/8" HOLE
FIELD POWER SUPPLY CONN.
7/8" HOLE WITH 1 1/8" KNOCKOUT
X = YES O = NO
NOTES: 1. ALLOW 24" CLEARANCE TO SERVICE SIDE OF UNIT, 48" ABOVE UNIT, 6" ON ONE SIDE, 12" ON REMAINING SIDE, AND 24" BETWEEN UNITS FOR PROPER AIRFLOW. 2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING MODE IS 55° F, MAX. 125° F. 3. SERIES DESIGNATION IS THE 13TH POSITION OF THE UNIT MODEL NUMBER. 4. CENTER OF GRAVITY . 5. ALL DIMENSIONS ARE IN "INCHES" UNLESS NOTED.
24ABC6

10
DIMENSIONS -- SI
B
76.2
K
8.0
L
C
88.9
47.6
N
P
M
E
F
G
A
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SERIES ELECTRICAL
CHARACTERISTICS ABCDEFGKLMNP
OPERATING
WEIGHT (Kgs)
SHIPPING
WEIGHT (Kgs)
SHIPPING
DIMENSIONS (L x W x H)
24ABC618 1 X O O O
24ABC624 0 X O O O 792.2 719.2 95.2 19.0 166.7 627.1 231.8 71.4 12.7 406.4 406.4 330.2 66.5 82.8 822.3 X 901.7 X 827.1
24ABC630 0 X O O O 792.2 820.8 95.2 19.0 166.7 627.1 231.8 71.4 12.7 393.7 406.4 362.0 69.3 85.2 822.3 X 901.7 X 912.8
24ABC636 0 X O O O 889.0 719.2 98.4 22.2 166.7 722.3 231.8 74.6 15.9 406.4 406.4 330.2 74.8 92.5 917.6 X 998.6 X 827.1
24ABC642 0 X O O O 889.0 993.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 419.1 444.5 444.5 96.4 115.2 917.6 X 998.6 X 1085.8
24ABC648 0 X O O O 889.0 820.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 431.8 444.5 362.0 104.8 124.3 917.6 X 998.6 X 912.8
24ABC660 0 X O O O 889.0 1166.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 419.1 431.8 412.8 123.4 140.6 917.6 X 998.6 X 1258.9
654.0 728.7 95.2 19.0 112.7 539.8 198.4 71.4 12.7 346.1 342.9 323.9 56.7 69.9 682.6 X 763.6 X 827.1
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
18 660.4 X 660.4
24,30 800.1 X 800.1
36 THRU 60 889.0 X 889.0
AIR DISCHARGE
AIR DISCHARGE
SQ.
AIR IN
VAPOR LINE CONN.
D
9.53
LIQUID LINE CONN.
AIR IN
AIR IN
AIR IN
9.53 TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
22.23 HOLE
FIELD POWER SUPPLY CONN.
22.23 HOLE WITH
28.58 KNOCKOUT
X = YES O = NO
NOTES: 1. ALLOW 610.0 CLEARANCE TO SERVICE SIDE OF UNIT, 1219.2 ABOVE UNIT, 152.4 ON ONE SIDE, 304.8 ON REMAINING SIDE, AND 609.6 BETWEEN UNITS FOR PROPER AIRFLOW. 2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING MODE IS 13°C, MAX. 52°C. 3. SERIES DESIGNATION IS THE 10TH POSITION OF THE UNIT MODEL NUMBER. 4. CENTER OF GRAVITY . 5. ALL DIMENSIONS ARE IN "MM" UNLESS NOTED.
24ABC6

11
CLEARANCES
Clearances (various examples)
Wall
6”
(152.4)
24”
(609.6)
Service
Wall
Wall
Wall
12”
(304.8)
12”
(304.8)
18”
(457.2)
24”
(609.6)
Service
6”
(152.4)
12”
(304.8)
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
Service
Note: Numbers in ( ) = mm
18”
(457.2)
18”
(457.2)
12”
(304.8)
IMPORTANT: When installing multiple units in an alcove, roof well, or partially enclosed area, ensure there is adequate ventilation to prevent re--circulation of discharge air.
24ABC6

12
COMBINATION RATINGS
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3632294 24ABC618A**31 †CNPV*1917A**+TDR 18,000 12.0 14.5
3630458 24ABC618A**31 CAP**1814A** 58CV(A,X)070---12 18,000 12.5 15.5
3631465 24ABC618A**31 CAP**1814A** 58PH*045 ---08 18,000 13.0 15.5
3631699 24ABC618A**31 CAP**1814A**+TDR 18,000 11.5 13.5
3630459 24ABC618A**31 CAP**2414A** 58CV(A,X)070---12 18,000 13.0 16.0
3631466 24ABC618A**31 CAP**2414A** 58PH*045 ---08 18,000 13.0 16.0
3631700 24ABC618A**31 CAP**2414A**+TDR 18,000 11.5 14.0
3630460 24ABC618A**31 CAP**2417A** 58CV(A,X)070---12 18,000 13.0 16.0
3630520 24ABC618A**31 CAP**2417A** 58CV(A,X)090---16 18,000 13.0 16.0
3630806 24ABC618A**31 CAP**2417A** 58MEB040---12 18,000 13.0 16.0
3630872 24ABC618A**31 CAP**2417A** 58ME(B,C)060---12 18,000 13.0 16.0
3631136 24ABC618A**31 CAP**2417A** 58MV(B,C)060---14 18,000 13.0 16.0
3631467 24ABC618A**31 CAP**2417A** 58PH*045 ---08 18,000 13.0 16.0
3631926 24ABC618A**31 CAP**2417A** 58UVB060---14 18,000 13.0 16.0
3631701 24ABC618A**31 CAP**2417A**+TDR 18,000 11.5 14.0
3631706 24ABC618A**31 CNPF*2418A**+TDR 18,000 11.5 14.0
3630464 24ABC618A**31 CNPH*2417A** 58CV(A,X)070---12 18,000 13.0 16.0
3630522 24ABC618A**31 CNPH*2417A** 58CV(A,X)090---16 18,000 13.0 16.0
3630808 24ABC618A**31 CNPH*2417A** 58MEB040 ---12 18,000 13.0 16.0
3630874 24ABC618A**31 CNPH*2417A** 58ME(B,C)060 ---12 18,000 13.0 16.0
3631138 24ABC618A**31 CNPH*2417A** 58MV(B,C)060 ---14 18,000 13.0 16.0
3631202 24ABC618A**31 CNPH*2417A** 58MV(B,C)080 ---14 18,000 13.0 16.0
3631429 24ABC618A**31 CNPH*2417A** 58MVB040 ---14 18,000 13.0 16.0
3631471 24ABC618A**31 CNPH*2417A** 58PH*045---08 18,000 13.0 16.0
3631928 24ABC618A**31 CNPH*2417A** 58UVB060 ---14 18,000 13.0 16.0
3631992 24ABC618A**31 CNPH*2417A** 58UVB080 ---14 18,000 13.0 16.0
3631705 24ABC618A**31 CNPH*2417A**+TDR 18,000 11.5 14.0
3630461 24ABC618A**31 CNPV*1814A** 58CV(A,X)070---12 18,000 13.0 15.5
3631468 24ABC618A**31 CNPV*1814A** 58PH*045---08 18,000 13.0 15.5
3631702 24ABC618A**31 CNPV*1814A**+TDR 18,000 11.5 14.0
3632247 24ABC618A**31 CNPV*1917A** 58CV(A,X)070---12 18,000 13.0 16.0
3632250 24ABC618A**31 CNPV*1917A** 58CV(A,X)090---16 18,000 13.0 16.0
3632259 24ABC618A**31 CNPV*1917A** 58MEB040---12 18,000 13.0 16.0
3632262 24ABC618A**31 CNPV*1917A** 58ME(B,C)060---12 18,000 13.0 16.0
3632272 24ABC618A**31 CNPV*1917A** 58MV(B,C)060---14 18,000 13.0 16.0
3632285 24ABC618A**31 CNPV*1917A** 58PH*045---08 18,000 13.0 16.0
3632316 24ABC618A**31 CNPV*1917A** 58UVB060---14 18,000 13.0 16.0
3630462 24ABC618A**31 CNPV*2414A** 58CV(A,X)070---12 18,000 13.0 16.0
3631469 24ABC618A**31 CNPV*2414A** 58PH*045---08 18,000 13.0 16.0
3631703 24ABC618A**31 CNPV*2414A**+TDR 18,000 11.5 14.0
3630463 24ABC618A**31 CNPV*2417A** 58CV(A,X)070---12 18,000 13.0 16.0
3630521 24ABC618A**31 CNPV*2417A** 58CV(A,X)090---16 18,000 13.0 16.0
3630807 24ABC618A**31 CNPV*2417A** 58MEB040---12 18,000 13.0 16.0
3630873 24ABC618A**31 CNPV*2417A** 58ME(B,C)060---12 18,000 13.0 16.0
3631137 24ABC618A**31 CNPV*2417A** 58MV(B,C)060---14 18,000 13.0 16.0
3631470 24ABC618A**31 CNPV*2417A** 58PH*045---08 18,000 13.0 16.0
3631927 24ABC618A**31 CNPV*2417A** 58UVB060---14 18,000 13.0 16.0
3631704 24ABC618A**31 CNPV*2417A**+TDR 18,000 11.5 14.0
3630465 24ABC618A**31 CSPH*2412A** 58CV(A,X)070---12 18,000 13.0 16.0
3630523 24ABC618A**31 CSPH*2412A** 58CV(A,X)090---16 18,000 13.0 16.0
3630768 24ABC618A**31 CSPH*2412A** 58HDV040 --- ---12 18,000 13.0 15.5
3630777 24ABC618A**31 CSPH*2412A** 58HDV060 --- ---12 18,000 13.0 15.5
3630809 24ABC618A**31 CSPH*2412A** 58MEB040---12 18,000 13.0 16.0
3630875 24ABC618A**31 CSPH*2412A** 58ME(B,C)060---12 18,000 13.0 16.0
3631139 24ABC618A**31 CSPH*2412A** 58MV(B,C)060 ---14 18,000 13.0 16.0
3631203 24ABC618A**31 CSPH*2412A** 58MV(B,C)080 ---14 18,000 13.0 16.0
3631430 24ABC618A**31 CSPH*2412A** 58MVB040 ---14 18,000 13.0 16.0
3631472 24ABC618A**31 CSPH*2412A** 58PH*045---08 18,000 13.0 16.0
3631929 24ABC618A**31 CSPH*2412A** 58UVB060 ---14 18,000 13.0 16.0
3631993 24ABC618A**31 CSPH*2412A** 58UVB080 ---14 18,000 13.0 16.0
3631707 24ABC618A**31 CSPH*2412A**+TDR 18,000 12.0 14.0
3631720 24ABC618A**31 FE4ANF002+UI 18,000 13.0 16.0
3631750 24ABC618A**31 FF1ENP018 18,000 11.5 14.0
3631751 24ABC618A**31 FF1ENP019 18,000 12.5 15.5
3631752 24ABC618A**31 FF1ENP024 18,000 11.5 14.0
3631754 24ABC618A**31 FF1ENP025 18,000 13.0 16.0
3631800 24ABC618A**31 FV4BNF002 18,000 13.0 16.0
3631816 24ABC618A**31 FV4CNF002 18,000 13.0 16.0
3631857 24ABC618A**31 FX4CNF018 18,000 13.0 15.5
3631858 24ABC618A**31 FX4CNF024 18,000 13.0 16.0
3632311 24ABC618A**31 FX4DNF019 18,000 13.0 16.0
3632312 24ABC618A**31 FX4DNF025 18,000 13.0 16.0
3631887 24ABC618A**31 FY4ANF018 18,000 11.5 14.0
3631888 24ABC618A**31 FY4ANF024 18,000 11.5 13.5
3631725 24ABC624A**30 †CNPV*3117A**+TDR 23,600 12.0 14.5
3630467 24ABC624A**30 CAP**2414A** 58CV(A,X)070---12 22,800 12.5 15.5
3631474 24ABC624A**30 CAP**2414A** 58PH*045 ---08 23,000 12.5 15.5
3631726 24ABC624A**30 CAP**2414A**+TDR 23,000 11.5 14.0
See notes on page 35
24ABC6

13
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3630468 24ABC624A**30 CAP**2417A** 58CV(A,X)070---12 22,800 12.5 15.5
3630525 24ABC624A**30 CAP**2417A** 58CV(A,X)090---16 22,800 13.0 16.0
3630811 24ABC624A**30 CAP**2417A** 58MEB040---12 23,400 13.0 16.0
3630877 24ABC624A**30 CAP**2417A** 58ME(B,C)060---12 23,400 13.0 16.0
3630939 24ABC624A**30 CAP**2417A** 58ME(B,C)080---12 23,200 13.0 16.0
3631141 24ABC624A**30 CAP**2417A** 58MV(B,C)060---14 23,200 13.0 16.0
3631475 24ABC624A**30 CAP**2417A** 58PH*045 ---08 23,000 12.5 15.5
3631931 24ABC624A**30 CAP**2417A** 58UVB060---14 23,200 13.0 16.0
3631727 24ABC624A**30 CAP**2417A**+TDR 23,000 11.5 14.0
3630469 24ABC624A**30 CAP**3014A** 58CV(A,X)070---12 22,800 13.0 16.0
3631476 24ABC624A**30 CAP**3014A** 58PH*045 ---08 23,200 12.5 15.5
3631728 24ABC624A**30 CAP**3014A**+TDR 23,200 11.5 14.0
3630470 24ABC624A**30 CAP**3017A** 58CV(A,X)070---12 23,000 13.0 16.0
3630526 24ABC624A**30 CAP**3017A** 58CV(A,X)090---16 23,000 13.0 16.0
3630812 24ABC624A**30 CAP**3017A** 58MEB040---12 23,600 13.0 16.0
3630878 24ABC624A**30 CAP**3017A** 58ME(B,C)060---12 23,600 13.0 16.0
3630940 24ABC624A**30 CAP**3017A** 58ME(B,C)080---12 23,400 13.0 16.0
3631142 24ABC624A**30 CAP**3017A** 58MV(B,C)060---14 23,200 13.0 16.0
3631477 24ABC624A**30 CAP**3017A** 58PH*045 ---08 23,200 13.0 16.0
3631932 24ABC624A**30 CAP**3017A** 58UVB060---14 23,200 13.0 16.0
3631729 24ABC624A**30 CAP**3017A**+TDR 23,200 11.5 14.0
3630471 24ABC624A**30 CAP**3614A** 58CV(A,X)070---12 23,000 13.0 16.0
3631478 24ABC624A**30 CAP**3614A** 58PH*045 ---08 23,200 13.0 16.0
3631730 24ABC624A**30 CAP**3614A**+TDR 23,200 11.5 14.0
3630472 24ABC624A**30 CAP**3617A** 58CV(A,X)070---12 23,000 13.0 16.0
3630527 24ABC624A**30 CAP**3617A** 58CV(A,X)090---16 23,000 13.0 16.0
3630813 24ABC624A**30 CAP**3617A** 58MEB040---12 23,600 13.0 16.0
3630879 24ABC624A**30 CAP**3617A** 58ME(B,C)060---12 23,800 13.0 16.0
3630941 24ABC624A**30 CAP**3617A** 58ME(B,C)080---12 23,600 13.0 16.0
3631143 24ABC624A**30 CAP**3617A** 58MV(B,C)060---14 23,400 13.0 16.0
3631479 24ABC624A**30 CAP**3617A** 58PH*045 ---08 23,400 13.0 16.0
3631933 24ABC624A**30 CAP**3617A** 58UVB060---14 23,400 13.0 16.0
3631731 24ABC624A**30 CAP**3617A**+TDR 23,200 11.5 14.0
3630769 24ABC624A**30 CAP**3619A** 58HDV040--- ---12 23,400 12.5 15.5
3630778 24ABC624A**30 CAP**3619A** 58HDV060--- ---12 23,600 12.5 15.5
3631733 24ABC624A**30 CAP**3619A**+TDR 23,200 11.5 14.0
3630528 24ABC624A**30 CAP**3621A** 58CV(A,X)090---16 23,000 13.0 16.0
3630595 24ABC624A**30 CAP**3621A** 58CV(A,X)110---20 23,200 13.0 16.0
3630814 24ABC624A**30 CAP**3621A** 58MEB040---12 23,800 13.0 16.0
3630880 24ABC624A**30 CAP**3621A** 58ME(B,C)060---12 23,800 13.0 16.0
3630942 24ABC624A**30 CAP**3621A** 58ME(B,C)080---12 23,600 13.0 16.0
3631144 24ABC624A**30 CAP**3621A** 58MV(B,C)060---14 23,400 13.0 16.0
3631204 24ABC624A**30 CAP**3621A** 58MV(B,C)080---14 23,000 13.0 16.0
3631255 24ABC624A**30 CAP**3621A** 58MV(B,C)080---20 22,800 13.0 16.0
3631319 24ABC624A**30 CAP**3621A** 58MV(B,C)100---20 23,000 13.0 16.0
3631934 24ABC624A**30 CAP**3621A** 58UVB060---14 23,400 13.0 16.0
3631994 24ABC624A**30 CAP**3621A** 58UVB080---14 23,000 13.0 16.0
3632046 24ABC624A**30 CAP**3621A** 58UVB080---20 22,800 13.0 16.0
3632110 24ABC624A**30 CAP**3621A** 58UVB100---20 23,000 13.0 16.0
3631732 24ABC624A**30 CAP**3621A**+TDR 23,200 11.5 14.0
3631743 24ABC624A**30 CNPF*2418A**+TDR 23,000 11.5 14.0
3631744 24ABC624A**30 CNPF*3618A**+TDR 23,200 11.5 14.0
3630478 24ABC624A**30 CNPH*2417A** 58CV(A,X)070---12 22,800 12.5 15.5
3630533 24ABC624A**30 CNPH*2417A** 58CV(A,X)090---16 22,800 13.0 16.0
3630597 24ABC624A**30 CNPH*2417A** 58CV(A,X)110---20 22,800 12.5 15.5
3630666 24ABC624A**30 CNPH*2417A** 58CV(A,X)135---22 22,800 12.5 15.5
3630717 24ABC624A**30 CNPH*2417A** 58CV(A,X)155---22 22,800 12.5 15.5
3630819 24ABC624A**30 CNPH*2417A** 58MEB040 ---12 23,200 13.0 16.0
3630885 24ABC624A**30 CNPH*2417A** 58ME(B,C)060 ---12 23,200 13.0 16.0
3630947 24ABC624A**30 CNPH*2417A** 58ME(B,C)080 ---12 23,000 13.0 16.0
3631149 24ABC624A**30 CNPH*2417A** 58MV(B,C)060 ---14 23,000 12.5 15.5
3631206 24ABC624A**30 CNPH*2417A** 58MV(B,C)080 ---14 22,800 12.5 15.5
3631257 24ABC624A**30 CNPH*2417A** 58MV(B,C)080 ---20 22,600 12.5 15.5
3631321 24ABC624A**30 CNPH*2417A** 58MV(B,C)100 ---20 22,800 12.5 15.5
3631383 24ABC624A**30 CNPH*2417A** 58MV(B,C)120 ---20 23,000 13.0 16.0
3631431 24ABC624A**30 CNPH*2417A** 58MVB040 ---14 22,800 12.5 15.5
3631485 24ABC624A**30 CNPH*2417A** 58PH*045---08 23,000 12.5 15.5
3631939 24ABC624A**30 CNPH*2417A** 58UVB060 ---14 23,000 12.5 15.5
3631996 24ABC624A**30 CNPH*2417A** 58UVB080 ---14 22,800 12.5 15.5
3632048 24ABC624A**30 CNPH*2417A** 58UVB080 ---20 22,600 12.5 15.5
3632112 24ABC624A**30 CNPH*2417A** 58UVB100 ---20 22,800 12.5 15.5
3632174 24ABC624A**30 CNPH*2417A** 58UVB120 ---20 23,000 13.0 16.0
3631740 24ABC624A**30 CNPH*2417A**+TDR 23,000 11.5 14.0
3630479 24ABC624A**30 CNPH*3017A** 58CV(A,X)070---12 23,000 13.0 16.0
3630534 24ABC624A**30 CNPH*3017A** 58CV(A,X)090---16 23,000 13.0 16.0
3630598 24ABC624A**30 CNPH*3017A** 58CV(A,X)110---20 23,000 13.0 16.0
3630667 24ABC624A**30 CNPH*3017A** 58CV(A,X)135---22 23,000 13.0 16.0
3630718 24ABC624A**30 CNPH*3017A** 58CV(A,X)155---22 23,000 13.0 16.0
3630820 24ABC624A**30 CNPH*3017A** 58MEB040 ---12 23,600 13.0 16.0
See notes on page 35
24ABC6

14
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3630886 24ABC624A**30 CNPH*3017A** 58ME(B,C)060 ---12 23,600 13.0 16.0
3630948 24ABC624A**30 CNPH*3017A** 58ME(B,C)080 ---12 23,400 13.0 16.0
3631150 24ABC624A**30 CNPH*3017A** 58MV(B,C)060 ---14 23,200 13.0 16.0
3631207 24ABC624A**30 CNPH*3017A** 58MV(B,C)080 ---14 23,000 13.0 16.0
3631258 24ABC624A**30 CNPH*3017A** 58MV(B,C)080 ---20 22,800 13.0 16.0
3631322 24ABC624A**30 CNPH*3017A** 58MV(B,C)100 ---20 23,000 13.0 16.0
3631384 24ABC624A**30 CNPH*3017A** 58MV(B,C)120 ---20 23,200 13.0 16.0
3631432 24ABC624A**30 CNPH*3017A** 58MVB040 ---14 23,000 13.0 16.0
3631486 24ABC624A**30 CNPH*3017A** 58PH*045---08 23,200 13.0 16.0
3631940 24ABC624A**30 CNPH*3017A** 58UVB060 ---14 23,200 13.0 16.0
3631997 24ABC624A**30 CNPH*3017A** 58UVB080 ---14 23,000 13.0 16.0
3632049 24ABC624A**30 CNPH*3017A** 58UVB080 ---20 22,800 13.0 16.0
3632113 24ABC624A**30 CNPH*3017A** 58UVB100 ---20 23,000 13.0 16.0
3632175 24ABC624A**30 CNPH*3017A** 58UVB120 ---20 23,200 13.0 16.0
3631741 24ABC624A**30 CNPH*3017A**+TDR 23,200 11.5 14.0
3630480 24ABC624A**30 CNPH*3117A** 58CV(A,X)070---12 23,400 13.0 16.0
3630535 24ABC624A**30 CNPH*3117A** 58CV(A,X)090---16 23,400 13.0 16.0
3630599 24ABC624A**30 CNPH*3117A** 58CV(A,X)110---20 23,400 13.0 16.0
3630668 24ABC624A**30 CNPH*3117A** 58CV(A,X)135---22 23,400 13.0 16.0
3630719 24ABC624A**30 CNPH*3117A** 58CV(A,X)155---22 23,400 13.0 16.0
3630821 24ABC624A**30 CNPH*3117A** 58MEB040 ---12 24,000 13.0 16.0
3630887 24ABC624A**30 CNPH*3117A** 58ME(B,C)060 ---12 24,000 13.0 16.0
3630949 24ABC624A**30 CNPH*3117A** 58ME(B,C)080 ---12 24,000 13.0 16.0
3631151 24ABC624A**30 CNPH*3117A** 58MV(B,C)060 ---14 23,800 13.0 16.0
3631208 24ABC624A**30 CNPH*3117A** 58MV(B,C)080 ---14 23,400 13.0 16.0
3631259 24ABC624A**30 CNPH*3117A** 58MV(B,C)080 ---20 23,200 13.0 16.0
3631323 24ABC624A**30 CNPH*3117A** 58MV(B,C)100 ---20 23,400 13.0 16.0
3631385 24ABC624A**30 CNPH*3117A** 58MV(B,C)120 ---20 23,600 13.0 16.0
3631433 24ABC624A**30 CNPH*3117A** 58MVB040 ---14 23,400 13.0 16.0
3631487 24ABC624A**30 CNPH*3117A** 58PH*045---08 23,800 13.0 16.0
3631941 24ABC624A**30 CNPH*3117A** 58UVB060 ---14 23,800 13.0 16.0
3631998 24ABC624A**30 CNPH*3117A** 58UVB080 ---14 23,400 13.0 16.0
3632050 24ABC624A**30 CNPH*3117A** 58UVB080 ---20 23,200 13.0 16.0
3632114 24ABC624A**30 CNPH*3117A** 58UVB100 ---20 23,400 13.0 16.0
3632176 24ABC624A**30 CNPH*3117A** 58UVB120 ---20 23,600 13.0 16.0
3632296 24ABC624A**30 CNPH*3117A**+TDR 23,600 12.0 14.5
3630481 24ABC624A**30 CNPH*3617A** 58CV(A,X)070---12 23,000 13.0 16.0
3630536 24ABC624A**30 CNPH*3617A** 58CV(A,X)090---16 23,000 13.0 16.0
3630600 24ABC624A**30 CNPH*3617A** 58CV(A,X)110---20 23,000 13.0 16.0
3630669 24ABC624A**30 CNPH*3617A** 58CV(A,X)135---22 23,000 13.0 16.0
3630720 24ABC624A**30 CNPH*3617A** 58CV(A,X)155---22 23,000 13.0 16.0
3630822 24ABC624A**30 CNPH*3617A** 58MEB040 ---12 23,600 13.0 16.0
3630888 24ABC624A**30 CNPH*3617A** 58ME(B,C)060 ---12 23,600 13.0 16.0
3630950 24ABC624A**30 CNPH*3617A** 58ME(B,C)080 ---12 23,400 13.0 16.0
3631152 24ABC624A**30 CNPH*3617A** 58MV(B,C)060 ---14 23,200 13.0 16.0
3631209 24ABC624A**30 CNPH*3617A** 58MV(B,C)080 ---14 23,000 13.0 16.0
3631260 24ABC624A**30 CNPH*3617A** 58MV(B,C)080 ---20 22,800 13.0 16.0
3631324 24ABC624A**30 CNPH*3617A** 58MV(B,C)100 ---20 23,000 13.0 16.0
3631386 24ABC624A**30 CNPH*3617A** 58MV(B,C)120 ---20 23,200 13.0 16.0
3631434 24ABC624A**30 CNPH*3617A** 58MVB040 ---14 23,000 13.0 16.0
3631488 24ABC624A**30 CNPH*3617A** 58PH*045---08 23,200 13.0 16.0
3631942 24ABC624A**30 CNPH*3617A** 58UVB060 ---14 23,200 13.0 16.0
3631999 24ABC624A**30 CNPH*3617A** 58UVB080 ---14 23,000 13.0 16.0
3632051 24ABC624A**30 CNPH*3617A** 58UVB080 ---20 22,800 13.0 16.0
3632115 24ABC624A**30 CNPH*3617A** 58UVB100 ---20 23,000 13.0 16.0
3632177 24ABC624A**30 CNPH*3617A** 58UVB120 ---20 23,200 13.0 16.0
3631742 24ABC624A**30 CNPH*3617A**+TDR 23,200 11.5 14.0
3632248 24ABC624A**30 CNPV*1917A** 58CV(A,X)070---12 23,000 13.0 16.0
3632251 24ABC624A**30 CNPV*1917A** 58CV(A,X)090---16 23,000 13.0 16.0
3632260 24ABC624A**30 CNPV*1917A** 58MEB040---12 23,600 13.0 16.0
3632263 24ABC624A**30 CNPV*1917A** 58ME(B,C)060---12 23,600 13.0 16.0
3632273 24ABC624A**30 CNPV*1917A** 58MV(B,C)060---14 23,400 13.0 16.0
3632286 24ABC624A**30 CNPV*1917A** 58PH*045---08 23,200 13.0 16.0
3632317 24ABC624A**30 CNPV*1917A** 58UVB060---14 23,400 13.0 16.0
3632295 24ABC624A**30 CNPV*1917A**+TDR 23,200 11.5 14.0
3630473 24ABC624A**30 CNPV*2414A** 58CV(A,X)070---12 22,800 12.5 15.5
3631480 24ABC624A**30 CNPV*2414A** 58PH*045---08 23,000 12.5 15.5
3631734 24ABC624A**30 CNPV*2414A**+TDR 23,000 11.5 14.0
3630474 24ABC624A**30 CNPV*2417A** 58CV(A,X)070---12 22,800 12.5 15.5
3630529 24ABC624A**30 CNPV*2417A** 58CV(A,X)090---16 22,800 13.0 16.0
3630815 24ABC624A**30 CNPV*2417A** 58MEB040---12 23,200 13.0 16.0
3630881 24ABC624A**30 CNPV*2417A** 58ME(B,C)060---12 23,200 13.0 16.0
3630943 24ABC624A**30 CNPV*2417A** 58ME(B,C)080---12 23,000 13.0 16.0
3631145 24ABC624A**30 CNPV*2417A** 58MV(B,C)060---14 23,000 12.5 15.5
3631481 24ABC624A**30 CNPV*2417A** 58PH*045---08 23,000 12.5 15.5
3631935 24ABC624A**30 CNPV*2417A** 58UVB060---14 23,000 12.5 15.5
3631735 24ABC624A**30 CNPV*2417A**+TDR 23,000 11.5 14.0
3630475 24ABC624A**30 CNPV*3014A** 58CV(A,X)070---12 23,000 13.0 16.0
3631482 24ABC624A**30 CNPV*3014A** 58PH*045---08 23,200 12.5 15.5
See notes on page 35
24ABC6

15
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3631736 24ABC624A**30 CNPV*3014A**+TDR 23,200 11.5 14.0
3630476 24ABC624A**30 CNPV*3017A** 58CV(A,X)070---12 23,000 13.0 16.0
3630530 24ABC624A**30 CNPV*3017A** 58CV(A,X)090---16 23,000 13.0 16.0
3630816 24ABC624A**30 CNPV*3017A** 58MEB040---12 23,600 13.0 16.0
3630882 24ABC624A**30 CNPV*3017A** 58ME(B,C)060---12 23,600 13.0 16.0
3630944 24ABC624A**30 CNPV*3017A** 58ME(B,C)080---12 23,400 13.0 16.0
3631146 24ABC624A**30 CNPV*3017A** 58MV(B,C)060---14 23,200 13.0 16.0
3631483 24ABC624A**30 CNPV*3017A** 58PH*045---08 23,200 13.0 16.0
3631936 24ABC624A**30 CNPV*3017A** 58UVB060---14 23,200 13.0 16.0
3631737 24ABC624A**30 CNPV*3017A**+TDR 23,200 11.5 14.0
3630466 24ABC624A**30 CNPV*3117A** 58CV(A,X)070---12 23,400 13.0 16.0
3630524 24ABC624A**30 CNPV*3117A** 58CV(A,X)090---16 23,400 13.0 16.0
3630810 24ABC624A**30 CNPV*3117A** 58MEB040---12 24,000 13.0 16.0
3630876 24ABC624A**30 CNPV*3117A** 58ME(B,C)060---12 24,000 13.0 16.0
3630938 24ABC624A**30 CNPV*3117A** 58ME(B,C)080---12 24,000 13.0 16.0
3631140 24ABC624A**30 CNPV*3117A** 58MV(B,C)060---14 23,800 13.0 16.0
3631473 24ABC624A**30 CNPV*3117A** 58PH*045---08 23,800 13.0 16.0
3631930 24ABC624A**30 CNPV*3117A** 58UVB060---14 23,800 13.0 16.0
3630477 24ABC624A**30 CNPV*3617A** 58CV(A,X)070---12 23,000 13.0 16.0
3630531 24ABC624A**30 CNPV*3617A** 58CV(A,X)090---16 23,000 13.0 16.0
3630817 24ABC624A**30 CNPV*3617A** 58MEB040---12 23,600 13.0 16.0
3630883 24ABC624A**30 CNPV*3617A** 58ME(B,C)060---12 23,600 13.0 16.0
3630945 24ABC624A**30 CNPV*3617A** 58ME(B,C)080---12 23,400 13.0 16.0
3631147 24ABC624A**30 CNPV*3617A** 58MV(B,C)060---14 23,200 13.0 16.0
3631484 24ABC624A**30 CNPV*3617A** 58PH*045---08 23,200 13.0 16.0
3631937 24ABC624A**30 CNPV*3617A** 58UVB060---14 23,200 13.0 16.0
3631738 24ABC624A**30 CNPV*3617A**+TDR 23,200 11.5 14.0
3630532 24ABC624A**30 CNPV*3621A** 58CV(A,X)090---16 23,000 13.0 16.0
3630596 24ABC624A**30 CNPV*3621A** 58CV(A,X)110---20 23,000 13.0 16.0
3630818 24ABC624A**30 CNPV*3621A** 58MEB040---12 23,600 13.0 16.0
3630884 24ABC624A**30 CNPV*3621A** 58ME(B,C)060---12 23,600 13.0 16.0
3630946 24ABC624A**30 CNPV*3621A** 58ME(B,C)080---12 23,400 13.0 16.0
3631148 24ABC624A**30 CNPV*3621A** 58MV(B,C)060---14 23,200 13.0 16.0
3631205 24ABC624A**30 CNPV*3621A** 58MV(B,C)080---14 23,000 13.0 16.0
3631256 24ABC624A**30 CNPV*3621A** 58MV(B,C)080---20 22,800 13.0 16.0
3631320 24ABC624A**30 CNPV*3621A** 58MV(B,C)100---20 23,000 13.0 16.0
3631938 24ABC624A**30 CNPV*3621A** 58UVB060---14 23,200 13.0 16.0
3631995 24ABC624A**30 CNPV*3621A** 58UVB080---14 23,000 13.0 16.0
3632047 24ABC624A**30 CNPV*3621A** 58UVB080---20 22,800 13.0 16.0
3632111 24ABC624A**30 CNPV*3621A** 58UVB100---20 23,000 13.0 16.0
3631739 24ABC624A**30 CNPV*3621A**+TDR 23,200 11.5 14.0
3630770 24ABC624A**30 CSPH*2412A** 58HDV040 --- ---12 23,200 12.8 15.2
3630779 24ABC624A**30 CSPH*2412A** 58HDV060 --- ---12 23,200 12.8 15.2
3631745 24ABC624A**30 CSPH*2412A**+TDR 23,200 11.5 14.0
3630482 24ABC624A**30 CSPH*3012A** 58CV(A,X)070---12 23,000 13.0 16.0
3630537 24ABC624A**30 CSPH*3012A** 58CV(A,X)090---16 23,200 13.0 16.0
3630601 24ABC624A**30 CSPH*3012A** 58CV(A,X)110---20 23,200 13.0 16.0
3630670 24ABC624A**30 CSPH*3012A** 58CV(A,X)135---22 23,200 13.0 16.0
3630721 24ABC624A**30 CSPH*3012A** 58CV(A,X)155---22 23,200 13.0 16.0
3630823 24ABC624A**30 CSPH*3012A** 58MEB040---12 23,600 13.0 16.0
3630889 24ABC624A**30 CSPH*3012A** 58ME(B,C)060---12 23,600 13.0 16.0
3630951 24ABC624A**30 CSPH*3012A** 58ME(B,C)080---12 23,400 13.0 16.0
3631153 24ABC624A**30 CSPH*3012A** 58MV(B,C)060 ---14 23,400 13.0 16.0
3631210 24ABC624A**30 CSPH*3012A** 58MV(B,C)080 ---14 23,000 13.0 16.0
3631261 24ABC624A**30 CSPH*3012A** 58MV(B,C)080 ---20 22,800 13.0 16.0
3631325 24ABC624A**30 CSPH*3012A** 58MV(B,C)100 ---20 23,000 13.0 16.0
3631387 24ABC624A**30 CSPH*3012A** 58MV(B,C)120 ---20 23,200 13.0 16.0
3631435 24ABC624A**30 CSPH*3012A** 58MVB040 ---14 23,000 13.0 16.0
3631489 24ABC624A**30 CSPH*3012A** 58PH*045---08 23,200 13.0 16.0
3631943 24ABC624A**30 CSPH*3012A** 58UVB060 ---14 23,400 13.0 16.0
3632000 24ABC624A**30 CSPH*3012A** 58UVB080 ---14 23,000 13.0 16.0
3632052 24ABC624A**30 CSPH*3012A** 58UVB080 ---20 22,800 13.0 16.0
3632116 24ABC624A**30 CSPH*3012A** 58UVB100 ---20 23,000 13.0 16.0
3632178 24ABC624A**30 CSPH*3012A** 58UVB120 ---20 23,200 13.0 16.0
3631746 24ABC624A**30 CSPH*3012A**+TDR 23,200 11.5 14.0
3630483 24ABC624A**30 CSPH*3612A** 58CV(A,X)070---12 23,400 13.0 16.0
3630538 24ABC624A**30 CSPH*3612A** 58CV(A,X)090---16 23,400 13.0 16.0
3630602 24ABC624A**30 CSPH*3612A** 58CV(A,X)110---20 23,400 13.0 16.0
3630671 24ABC624A**30 CSPH*3612A** 58CV(A,X)135---22 23,400 13.0 16.0
3630722 24ABC624A**30 CSPH*3612A** 58CV(A,X)155---22 23,400 13.0 16.0
3630824 24ABC624A**30 CSPH*3612A** 58MEB040---12 24,000 13.0 16.0
3630890 24ABC624A**30 CSPH*3612A** 58ME(B,C)060---12 24,000 13.0 16.0
3630952 24ABC624A**30 CSPH*3612A** 58ME(B,C)080---12 23,800 13.0 16.0
3631154 24ABC624A**30 CSPH*3612A** 58MV(B,C)060 ---14 23,800 13.0 16.0
3631211 24ABC624A**30 CSPH*3612A** 58MV(B,C)080 ---14 23,400 13.0 16.0
3631262 24ABC624A**30 CSPH*3612A** 58MV(B,C)080 ---20 23,200 13.0 16.0
3631326 24ABC624A**30 CSPH*3612A** 58MV(B,C)100 ---20 23,400 13.0 16.0
3631388 24ABC624A**30 CSPH*3612A** 58MV(B,C)120 ---20 23,600 13.0 16.0
3631436 24ABC624A**30 CSPH*3612A** 58MVB040 ---14 23,400 13.0 16.0
See notes on page 35
24ABC6

16
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3631490 24ABC624A**30 CSPH*3612A** 58PH*045---08 23,600 13.0 16.0
3631944 24ABC624A**30 CSPH*3612A** 58UVB060 ---14 23,800 13.0 16.0
3632001 24ABC624A**30 CSPH*3612A** 58UVB080 ---14 23,400 13.0 16.0
3632053 24ABC624A**30 CSPH*3612A** 58UVB080 ---20 23,200 13.0 16.0
3632117 24ABC624A**30 CSPH*3612A** 58UVB100 ---20 23,400 13.0 16.0
3632179 24ABC624A**30 CSPH*3612A** 58UVB120 ---20 23,600 13.0 16.0
3631747 24ABC624A**30 CSPH*3612A**+TDR 23,600 11.5 14.5
3631708 24ABC624A**30 FE4AN(B,F)003+UI 23,200 13.0 16.0
3631721 24ABC624A**30 FE4ANF002+UI 23,200 13.0 16.0
3631753 24ABC624A**30 FF1ENP024 22,800 11.5 13.5
3631755 24ABC624A**30 FF1ENP025 23,200 12.5 15.0
3631756 24ABC624A**30 FF1ENP030 22,800 11.5 13.5
3631758 24ABC624A**30 FF1ENP031 23,200 12.5 15.0
3631760 24ABC624A**30 FF1ENP036 23,000 11.0 13.5
3631763 24ABC624A**30 FF1ENP037 23,400 12.5 15.5
3631766 24ABC624A**30 FV4BN(B,F)003 23,200 13.0 16.0
3631801 24ABC624A**30 FV4BNF002 23,200 13.0 16.0
3631804 24ABC624A**30 FV4CN(B,F)003 23,200 13.0 16.0
3631817 24ABC624A**30 FV4CNF002 23,200 13.0 16.0
3631845 24ABC624A**30 FX4CN(B,F)036 23,200 12.0 14.5
3631859 24ABC624A**30 FX4CNF024 23,200 12.5 15.0
3631860 24ABC624A**30 FX4CNF030 23,400 13.0 16.0
3632298 24ABC624A**30 FX4DN(B,F)031 23,600 12.5 15.5
3632313 24ABC624A**30 FX4DNF025 23,400 13.0 16.0
3631889 24ABC624A**30 FY4ANF024 22,800 11.5 14.0
3631890 24ABC624A**30 FY4ANF030 23,000 12.0 14.5
3631892 24ABC624A**30 FY4ANF036 23,000 11.0 13.5
3631772 24ABC630A**30 †CNPV*3117A**+TDR 28,600 12.0 14.5
3630485 24ABC630A**30 CAP**3014A** 58CV(A,X)070---12 27,600 13.0 15.2
3631773 24ABC630A**30 CAP**3014A**+TDR 28,000 12.0 14.0
3630486 24ABC630A**30 CAP**3017A** 58CV(A,X)070---12 27,800 12.5 15.5
3630540 24ABC630A**30 CAP**3017A** 58CV(A,X)090---16 27,800 13.0 16.0
3630826 24ABC630A**30 CAP**3017A** 58MEB040---12 28,200 13.0 16.0
3630892 24ABC630A**30 CAP**3017A** 58ME(B,C)060---12 28,200 13.0 15.5
3630954 24ABC630A**30 CAP**3017A** 58ME(B,C)080---12 28,000 13.0 16.0
3631001 24ABC630A**30 CAP**3017A** 58ME(B,C)080---16 28,200 13.0 15.5
3631156 24ABC630A**30 CAP**3017A** 58MV(B,C)060---14 28,000 13.0 15.5
3631504 24ABC630A**30 CAP**3017A** 58PH*070 ---16 28,000 12.5 15.0
3631946 24ABC630A**30 CAP**3017A** 58UVB060---14 28,000 13.0 15.5
3631774 24ABC630A**30 CAP**3017A**+TDR 28,000 12.0 14.0
3630487 24ABC630A**30 CAP**3614A** 58CV(A,X)070---12 27,800 12.5 15.5
3631775 24ABC630A**30 CAP**3614A**+TDR 28,000 12.0 14.0
3630488 24ABC630A**30 CAP**3617A** 58CV(A,X)070---12 27,800 12.5 15.5
3630541 24ABC630A**30 CAP**3617A** 58CV(A,X)090---16 27,800 13.0 16.0
3630827 24ABC630A**30 CAP**3617A** 58MEB040---12 28,200 13.0 16.0
3630893 24ABC630A**30 CAP**3617A** 58ME(B,C)060---12 28,200 13.0 16.0
3630955 24ABC630A**30 CAP**3617A** 58ME(B,C)080---12 28,200 13.0 16.0
3631002 24ABC630A**30 CAP**3617A** 58ME(B,C)080---16 28,400 13.0 16.0
3631157 24ABC630A**30 CAP**3617A** 58MV(B,C)060---14 28,000 13.0 16.0
3631505 24ABC630A**30 CAP**3617A** 58PH*070 ---16 28,000 12.5 15.2
3631947 24ABC630A**30 CAP**3617A** 58UVB060---14 28,000 13.0 16.0
3631776 24ABC630A**30 CAP**3617A**+TDR 28,000 12.0 14.0
3630771 24ABC630A**30 CAP**3619A** 58HDV040--- ---12 28,000 12.5 15.0
3630780 24ABC630A**30 CAP**3619A** 58HDV060--- ---12 28,200 12.5 15.2
3631780 24ABC630A**30 CAP**3619A**+TDR 28,000 11.5 14.0
3630542 24ABC630A**30 CAP**3621A** 58CV(A,X)090---16 27,800 13.0 16.0
3630603 24ABC630A**30 CAP**3621A** 58CV(A,X)110---20 27,800 13.0 16.0
3630828 24ABC630A**30 CAP**3621A** 58MEB040---12 28,200 13.0 16.0
3630894 24ABC630A**30 CAP**3621A** 58ME(B,C)060---12 28,200 13.0 16.0
3630956 24ABC630A**30 CAP**3621A** 58ME(B,C)080---12 28,200 13.0 16.0
3631003 24ABC630A**30 CAP**3621A** 58ME(B,C)080---16 28,400 13.0 16.0
3631158 24ABC630A**30 CAP**3621A** 58MV(B,C)060---14 28,200 13.0 16.0
3631212 24ABC630A**30 CAP**3621A** 58MV(B,C)080---14 27,600 13.0 16.0
3631263 24ABC630A**30 CAP**3621A** 58MV(B,C)080---20 27,800 13.0 16.0
3631327 24ABC630A**30 CAP**3621A** 58MV(B,C)100---20 27,600 13.0 15.5
3631506 24ABC630A**30 CAP**3621A** 58PH*070 ---16 28,000 13.0 15.2
3631550 24ABC630A**30 CAP**3621A** 58PH*090 ---16 28,200 13.0 16.0
3631948 24ABC630A**30 CAP**3621A** 58UVB060---14 28,200 13.0 16.0
3632002 24ABC630A**30 CAP**3621A** 58UVB080---14 27,600 13.0 16.0
3632054 24ABC630A**30 CAP**3621A** 58UVB080---20 27,800 13.0 16.0
3632118 24ABC630A**30 CAP**3621A** 58UVB100---20 27,600 13.0 15.5
3631777 24ABC630A**30 CAP**3621A**+TDR 28,000 12.0 14.0
3630543 24ABC630A**30 CAP**4221A** 58CV(A,X)090---16 28,000 13.0 16.0
3630604 24ABC630A**30 CAP**4221A** 58CV(A,X)110---20 28,000 13.0 16.0
3630829 24ABC630A**30 CAP**4221A** 58MEB040---12 28,400 13.0 16.0
3630895 24ABC630A**30 CAP**4221A** 58ME(B,C)060---12 28,600 13.0 16.0
3630957 24ABC630A**30 CAP**4221A** 58ME(B,C)080---12 28,400 13.0 16.0
3631004 24ABC630A**30 CAP**4221A** 58ME(B,C)080---16 28,600 13.0 16.0
See notes on page 35
24ABC6

17
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3631159 24ABC630A**30 CAP**4221A** 58MV(B,C)060---14 28,200 13.0 16.0
3631213 24ABC630A**30 CAP**4221A** 58MV(B,C)080---14 28,000 13.0 16.0
3631264 24ABC630A**30 CAP**4221A** 58MV(B,C)080---20 28,000 13.0 16.0
3631328 24ABC630A**30 CAP**4221A** 58MV(B,C)100---20 27,800 13.0 16.0
3631507 24ABC630A**30 CAP**4221A** 58PH*070 ---16 28,200 12.5 15.5
3631551 24ABC630A**30 CAP**4221A** 58PH*090 ---16 28,400 13.0 16.0
3631949 24ABC630A**30 CAP**4221A** 58UVB060---14 28,200 13.0 16.0
3632003 24ABC630A**30 CAP**4221A** 58UVB080---14 28,000 13.0 16.0
3632055 24ABC630A**30 CAP**4221A** 58UVB080---20 28,000 13.0 16.0
3632119 24ABC630A**30 CAP**4221A** 58UVB100---20 27,800 13.0 16.0
3631778 24ABC630A**30 CAP**4221A**+TDR 28,200 11.5 14.0
3630605 24ABC630A**30 CAP**4224A** 58CV(A,X)110---20 28,200 13.0 16.0
3630672 24ABC630A**30 CAP**4224A** 58CV(A,X)135---22 28,200 13.0 16.0
3630723 24ABC630A**30 CAP**4224A** 58CV(A,X)155---22 28,200 13.0 16.0
3631214 24ABC630A**30 CAP**4224A** 58MV(B,C)080---14 28,000 13.0 16.0
3631265 24ABC630A**30 CAP**4224A** 58MV(B,C)080---20 28,000 13.0 16.0
3631329 24ABC630A**30 CAP**4224A** 58MV(B,C)100---20 27,800 13.0 16.0
3631389 24ABC630A**30 CAP**4224A** 58MV(B,C)120---20 28,000 13.0 16.0
3631437 24ABC630A**30 CAP**4224A** 58MVB040---14 28,000 13.0 16.0
3631552 24ABC630A**30 CAP**4224A** 58PH*090 ---16 28,400 13.0 16.0
3632004 24ABC630A**30 CAP**4224A** 58UVB080---14 28,000 13.0 16.0
3632056 24ABC630A**30 CAP**4224A** 58UVB080---20 28,000 13.0 16.0
3632120 24ABC630A**30 CAP**4224A** 58UVB100---20 27,800 13.0 16.0
3632180 24ABC630A**30 CAP**4224A** 58UVB120---20 28,000 13.0 16.0
3631779 24ABC630A**30 CAP**4224A**+TDR 28,200 11.5 14.0
3631790 24ABC630A**30 CNPF*3618A**+TDR 28,000 11.5 13.5
3630493 24ABC630A**30 CNPH*3017A** 58CV(A,X)070---12 27,800 12.5 15.5
3630549 24ABC630A**30 CNPH*3017A** 58CV(A,X)090---16 27,800 13.0 15.5
3630608 24ABC630A**30 CNPH*3017A** 58CV(A,X)110---20 27,800 13.0 15.5
3630673 24ABC630A**30 CNPH*3017A** 58CV(A,X)135---22 27,800 13.0 16.0
3630724 24ABC630A**30 CNPH*3017A** 58CV(A,X)155---22 27,800 13.0 16.0
3630835 24ABC630A**30 CNPH*3017A** 58MEB040 ---12 28,200 13.0 16.0
3630901 24ABC630A**30 CNPH*3017A** 58ME(B,C)060 ---12 28,200 13.0 15.5
3630963 24ABC630A**30 CNPH*3017A** 58ME(B,C)080 ---12 28,000 13.0 16.0
3631010 24ABC630A**30 CNPH*3017A** 58ME(B,C)080 ---16 28,200 13.0 15.5
3631165 24ABC630A**30 CNPH*3017A** 58MV(B,C)060 ---14 28,000 13.0 15.5
3631217 24ABC630A**30 CNPH*3017A** 58MV(B,C)080 ---14 27,600 12.5 15.5
3631268 24ABC630A**30 CNPH*3017A** 58MV(B,C)080 ---20 27,800 12.5 15.5
3631332 24ABC630A**30 CNPH*3017A** 58MV(B,C)100 ---20 27,600 12.5 15.5
3631390 24ABC630A**30 CNPH*3017A** 58MV(B,C)120 ---20 27,800 13.0 16.0
3631438 24ABC630A**30 CNPH*3017A** 58MVB040 ---14 27,800 12.5 15.5
3631513 24ABC630A**30 CNPH*3017A** 58PH*070---16 28,000 12.5 15.0
3631555 24ABC630A**30 CNPH*3017A** 58PH*090---16 28,000 12.5 15.5
3631955 24ABC630A**30 CNPH*3017A** 58UVB060 ---14 28,000 13.0 15.5
3632008 24ABC630A**30 CNPH*3017A** 58UVB080 ---14 27,600 12.5 15.5
3632059 24ABC630A**30 CNPH*3017A** 58UVB080 ---20 27,800 12.5 15.5
3632123 24ABC630A**30 CNPH*3017A** 58UVB100 ---20 27,600 12.5 15.5
3632181 24ABC630A**30 CNPH*3017A** 58UVB120 ---20 27,800 13.0 16.0
3631787 24ABC630A**30 CNPH*3017A**+TDR 28,000 12.0 14.0
3630494 24ABC630A**30 CNPH*3117A** 58CV(A,X)070---12 28,400 13.0 16.0
3630550 24ABC630A**30 CNPH*3117A** 58CV(A,X)090---16 28,400 13.0 16.0
3630609 24ABC630A**30 CNPH*3117A** 58CV(A,X)110---20 28,400 13.0 16.0
3630674 24ABC630A**30 CNPH*3117A** 58CV(A,X)135---22 28,400 13.0 16.0
3630725 24ABC630A**30 CNPH*3117A** 58CV(A,X)155---22 28,400 13.0 16.0
3630836 24ABC630A**30 CNPH*3117A** 58MEB040 ---12 28,800 13.0 16.0
3630902 24ABC630A**30 CNPH*3117A** 58ME(B,C)060 ---12 28,800 13.0 16.0
3630964 24ABC630A**30 CNPH*3117A** 58ME(B,C)080 ---12 28,800 13.0 16.0
3631011 24ABC630A**30 CNPH*3117A** 58ME(B,C)080 ---16 29,000 13.0 16.0
3631166 24ABC630A**30 CNPH*3117A** 58MV(B,C)060 ---14 28,600 13.0 16.0
3631218 24ABC630A**30 CNPH*3117A** 58MV(B,C)080 ---14 28,200 13.0 16.0
3631269 24ABC630A**30 CNPH*3117A** 58MV(B,C)080 ---20 28,400 13.0 16.0
3631333 24ABC630A**30 CNPH*3117A** 58MV(B,C)100 ---20 28,200 13.0 16.0
3631391 24ABC630A**30 CNPH*3117A** 58MV(B,C)120 ---20 28,400 13.0 16.0
3631439 24ABC630A**30 CNPH*3117A** 58MVB040 ---14 28,400 13.0 16.0
3631514 24ABC630A**30 CNPH*3117A** 58PH*070---16 28,600 13.0 16.0
3631556 24ABC630A**30 CNPH*3117A** 58PH*090---16 28,600 13.0 16.0
3631956 24ABC630A**30 CNPH*3117A** 58UVB060 ---14 28,600 13.0 16.0
3632009 24ABC630A**30 CNPH*3117A** 58UVB080 ---14 28,200 13.0 16.0
3632060 24ABC630A**30 CNPH*3117A** 58UVB080 ---20 28,400 13.0 16.0
3632124 24ABC630A**30 CNPH*3117A** 58UVB100 ---20 28,200 13.0 16.0
3632182 24ABC630A**30 CNPH*3117A** 58UVB120 ---20 28,400 13.0 16.0
3632297 24ABC630A**30 CNPH*3117A**+TDR 28,600 12.0 14.0
3630495 24ABC630A**30 CNPH*3617A** 58CV(A,X)070---12 27,800 12.5 15.5
3630551 24ABC630A**30 CNPH*3617A** 58CV(A,X)090---16 27,800 13.0 15.5
3630610 24ABC630A**30 CNPH*3617A** 58CV(A,X)110---20 27,800 13.0 15.5
3630675 24ABC630A**30 CNPH*3617A** 58CV(A,X)135---22 27,800 13.0 16.0
3630726 24ABC630A**30 CNPH*3617A** 58CV(A,X)155---22 27,800 13.0 16.0
3630837 24ABC630A**30 CNPH*3617A** 58MEB040 ---12 28,200 13.0 16.0
3630903 24ABC630A**30 CNPH*3617A** 58ME(B,C)060 ---12 28,200 13.0 15.5
See notes on page 35
24ABC6

18
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3630965 24ABC630A**30 CNPH*3617A** 58ME(B,C)080 ---12 28,000 13.0 16.0
3631012 24ABC630A**30 CNPH*3617A** 58ME(B,C)080 ---16 28,200 13.0 15.5
3631167 24ABC630A**30 CNPH*3617A** 58MV(B,C)060 ---14 28,000 13.0 15.5
3631219 24ABC630A**30 CNPH*3617A** 58MV(B,C)080 ---14 27,600 12.5 15.5
3631270 24ABC630A**30 CNPH*3617A** 58MV(B,C)080 ---20 27,800 12.5 15.5
3631334 24ABC630A**30 CNPH*3617A** 58MV(B,C)100 ---20 27,600 12.5 15.5
3631392 24ABC630A**30 CNPH*3617A** 58MV(B,C)120 ---20 27,800 13.0 16.0
3631440 24ABC630A**30 CNPH*3617A** 58MVB040 ---14 27,800 12.5 15.5
3631515 24ABC630A**30 CNPH*3617A** 58PH*070---16 28,000 12.5 15.0
3631557 24ABC630A**30 CNPH*3617A** 58PH*090---16 28,000 12.5 15.5
3631957 24ABC630A**30 CNPH*3617A** 58UVB060 ---14 28,000 13.0 15.5
3632010 24ABC630A**30 CNPH*3617A** 58UVB080 ---14 27,600 12.5 15.5
3632061 24ABC630A**30 CNPH*3617A** 58UVB080 ---20 27,800 12.5 15.5
3632125 24ABC630A**30 CNPH*3617A** 58UVB100 ---20 27,600 12.5 15.5
3632183 24ABC630A**30 CNPH*3617A** 58UVB120 ---20 27,800 13.0 16.0
3631788 24ABC630A**30 CNPH*3617A**+TDR 28,000 12.0 14.0
3630496 24ABC630A**30 CNPH*4221A** 58CV(A,X)070---12 28,000 13.0 15.5
3630552 24ABC630A**30 CNPH*4221A** 58CV(A,X)090---16 28,000 13.0 16.0
3630611 24ABC630A**30 CNPH*4221A** 58CV(A,X)110---20 28,200 13.0 16.0
3630676 24ABC630A**30 CNPH*4221A** 58CV(A,X)135---22 28,200 13.0 16.0
3630727 24ABC630A**30 CNPH*4221A** 58CV(A,X)155---22 28,200 13.0 16.0
3630838 24ABC630A**30 CNPH*4221A** 58MEB040 ---12 28,400 13.0 16.0
3630904 24ABC630A**30 CNPH*4221A** 58ME(B,C)060 ---12 28,400 13.0 16.0
3630966 24ABC630A**30 CNPH*4221A** 58ME(B,C)080 ---12 28,400 13.0 16.0
3631013 24ABC630A**30 CNPH*4221A** 58ME(B,C)080 ---16 28,600 13.0 16.0
3631168 24ABC630A**30 CNPH*4221A** 58MV(B,C)060 ---14 28,200 13.0 16.0
3631220 24ABC630A**30 CNPH*4221A** 58MV(B,C)080 ---14 28,000 13.0 15.5
3631271 24ABC630A**30 CNPH*4221A** 58MV(B,C)080 ---20 28,000 13.0 16.0
3631335 24ABC630A**30 CNPH*4221A** 58MV(B,C)100 ---20 27,800 13.0 15.5
3631393 24ABC630A**30 CNPH*4221A** 58MV(B,C)120 ---20 28,200 13.0 16.0
3631441 24ABC630A**30 CNPH*4221A** 58MVB040 ---14 28,000 13.0 15.5
3631516 24ABC630A**30 CNPH*4221A** 58PH*070---16 28,200 12.5 15.5
3631558 24ABC630A**30 CNPH*4221A** 58PH*090---16 28,400 13.0 16.0
3631958 24ABC630A**30 CNPH*4221A** 58UVB060 ---14 28,200 13.0 16.0
3632011 24ABC630A**30 CNPH*4221A** 58UVB080 ---14 28,000 13.0 15.5
3632062 24ABC630A**30 CNPH*4221A** 58UVB080 ---20 28,000 13.0 16.0
3632126 24ABC630A**30 CNPH*4221A** 58UVB100 ---20 27,800 13.0 15.5
3632184 24ABC630A**30 CNPH*4221A** 58UVB120 ---20 28,200 13.0 16.0
3631789 24ABC630A**30 CNPH*4221A**+TDR 28,200 11.5 14.0
3630489 24ABC630A**30 CNPV*3014A** 58CV(A,X)070---12 27,800 12.5 15.0
3631781 24ABC630A**30 CNPV*3014A**+TDR 28,000 12.0 14.0
3630490 24ABC630A**30 CNPV*3017A** 58CV(A,X)070---12 27,800 12.5 15.5
3630544 24ABC630A**30 CNPV*3017A** 58CV(A,X)090---16 27,800 13.0 15.5
3630830 24ABC630A**30 CNPV*3017A** 58MEB040---12 28,200 13.0 16.0
3630896 24ABC630A**30 CNPV*3017A** 58ME(B,C)060---12 28,200 13.0 15.5
3630958 24ABC630A**30 CNPV*3017A** 58ME(B,C)080---12 28,000 13.0 16.0
3631005 24ABC630A**30 CNPV*3017A** 58ME(B,C)080---16 28,200 13.0 15.5
3631160 24ABC630A**30 CNPV*3017A** 58MV(B,C)060---14 28,000 13.0 15.5
3631508 24ABC630A**30 CNPV*3017A** 58PH*070---16 28,000 12.5 15.0
3631950 24ABC630A**30 CNPV*3017A** 58UVB060---14 28,000 13.0 15.5
3631782 24ABC630A**30 CNPV*3017A**+TDR 28,000 12.0 14.0
3630484 24ABC630A**30 CNPV*3117A** 58CV(A,X)070---12 28,400 13.0 16.0
3630539 24ABC630A**30 CNPV*3117A** 58CV(A,X)090---16 28,400 13.0 16.0
3630825 24ABC630A**30 CNPV*3117A** 58MEB040---12 28,800 13.0 16.0
3630891 24ABC630A**30 CNPV*3117A** 58ME(B,C)060---12 28,800 13.0 16.0
3630953 24ABC630A**30 CNPV*3117A** 58ME(B,C)080---12 28,800 13.0 16.0
3631000 24ABC630A**30 CNPV*3117A** 58ME(B,C)080---16 29,000 13.0 16.0
3631155 24ABC630A**30 CNPV*3117A** 58MV(B,C)060---14 28,600 13.0 16.0
3631503 24ABC630A**30 CNPV*3117A** 58PH*070---16 28,600 13.0 16.0
3631945 24ABC630A**30 CNPV*3117A** 58UVB060---14 28,600 13.0 16.0
3630491 24ABC630A**30 CNPV*3617A** 58CV(A,X)070---12 27,800 12.5 15.5
3630545 24ABC630A**30 CNPV*3617A** 58CV(A,X)090---16 27,800 13.0 15.5
3630831 24ABC630A**30 CNPV*3617A** 58MEB040---12 28,200 13.0 16.0
3630897 24ABC630A**30 CNPV*3617A** 58ME(B,C)060---12 28,200 13.0 15.5
3630959 24ABC630A**30 CNPV*3617A** 58ME(B,C)080---12 28,000 13.0 16.0
3631006 24ABC630A**30 CNPV*3617A** 58ME(B,C)080---16 28,200 13.0 15.5
3631161 24ABC630A**30 CNPV*3617A** 58MV(B,C)060---14 28,000 13.0 15.5
3631509 24ABC630A**30 CNPV*3617A** 58PH*070---16 28,000 12.5 15.0
3631951 24ABC630A**30 CNPV*3617A** 58UVB060---14 28,000 13.0 15.5
3631783 24ABC630A**30 CNPV*3617A**+TDR 28,000 12.0 14.0
3630546 24ABC630A**30 CNPV*3621A** 58CV(A,X)090---16 27,800 13.0 16.0
3630606 24ABC630A**30 CNPV*3621A** 58CV(A,X)110---20 27,800 13.0 15.5
3630832 24ABC630A**30 CNPV*3621A** 58MEB040---12 28,200 13.0 16.0
3630898 24ABC630A**30 CNPV*3621A** 58ME(B,C)060---12 28,200 13.0 15.5
3630960 24ABC630A**30 CNPV*3621A** 58ME(B,C)080---12 28,000 13.0 16.0
3631007 24ABC630A**30 CNPV*3621A** 58ME(B,C)080---16 28,200 13.0 15.5
3631162 24ABC630A**30 CNPV*3621A** 58MV(B,C)060---14 28,000 13.0 15.5
3631215 24ABC630A**30 CNPV*3621A** 58MV(B,C)080---14 27,600 12.5 15.5
3631266 24ABC630A**30 CNPV*3621A** 58MV(B,C)080---20 27,800 12.5 15.5
See notes on page 35
24ABC6

19
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3631330 24ABC630A**30 CNPV*3621A** 58MV(B,C)100---20 27,600 12.5 15.5
3631510 24ABC630A**30 CNPV*3621A** 58PH*070---16 28,000 12.5 15.0
3631553 24ABC630A**30 CNPV*3621A** 58PH*090---16 28,000 12.5 15.5
3631952 24ABC630A**30 CNPV*3621A** 58UVB060---14 28,000 13.0 15.5
3632005 24ABC630A**30 CNPV*3621A** 58UVB080---14 27,600 12.5 15.5
3632057 24ABC630A**30 CNPV*3621A** 58UVB080---20 27,800 12.5 15.5
3632121 24ABC630A**30 CNPV*3621A** 58UVB100---20 27,600 12.5 15.5
3631784 24ABC630A**30 CNPV*3621A**+TDR 28,000 12.0 14.0
3630492 24ABC630A**30 CNPV*4217A** 58CV(A,X)070---12 28,200 13.0 16.0
3630547 24ABC630A**30 CNPV*4217A** 58CV(A,X)090---16 28,200 13.0 16.0
3630833 24ABC630A**30 CNPV*4217A** 58MEB040---12 28,600 13.0 16.0
3630899 24ABC630A**30 CNPV*4217A** 58ME(B,C)060---12 28,600 13.0 16.0
3630961 24ABC630A**30 CNPV*4217A** 58ME(B,C)080---12 28,600 13.0 16.0
3631008 24ABC630A**30 CNPV*4217A** 58ME(B,C)080---16 28,800 13.0 16.0
3631163 24ABC630A**30 CNPV*4217A** 58MV(B,C)060---14 28,400 13.0 16.0
3631511 24ABC630A**30 CNPV*4217A** 58PH*070---16 28,400 13.0 15.5
3631953 24ABC630A**30 CNPV*4217A** 58UVB060---14 28,400 13.0 16.0
3631785 24ABC630A**30 CNPV*4217A**+TDR 28,400 11.5 14.0
3630548 24ABC630A**30 CNPV*4221A** 58CV(A,X)090---16 28,000 13.0 16.0
3630607 24ABC630A**30 CNPV*4221A** 58CV(A,X)110---20 28,200 13.0 16.0
3630834 24ABC630A**30 CNPV*4221A** 58MEB040---12 28,400 13.0 16.0
3630900 24ABC630A**30 CNPV*4221A** 58ME(B,C)060---12 28,400 13.0 16.0
3630962 24ABC630A**30 CNPV*4221A** 58ME(B,C)080---12 28,400 13.0 16.0
3631009 24ABC630A**30 CNPV*4221A** 58ME(B,C)080---16 28,600 13.0 16.0
3631164 24ABC630A**30 CNPV*4221A** 58MV(B,C)060---14 28,200 13.0 16.0
3631216 24ABC630A**30 CNPV*4221A** 58MV(B,C)080---14 28,000 13.0 15.5
3631267 24ABC630A**30 CNPV*4221A** 58MV(B,C)080---20 28,000 13.0 16.0
3631331 24ABC630A**30 CNPV*4221A** 58MV(B,C)100---20 27,800 13.0 15.5
3631512 24ABC630A**30 CNPV*4221A** 58PH*070---16 28,200 12.5 15.5
3631554 24ABC630A**30 CNPV*4221A** 58PH*090---16 28,400 13.0 16.0
3631954 24ABC630A**30 CNPV*4221A** 58UVB060---14 28,200 13.0 16.0
3632007 24ABC630A**30 CNPV*4221A** 58UVB080---14 28,000 13.0 15.5
3632058 24ABC630A**30 CNPV*4221A** 58UVB080---20 28,000 13.0 16.0
3632122 24ABC630A**30 CNPV*4221A** 58UVB100---20 27,800 13.0 15.5
3631786 24ABC630A**30 CNPV*4221A**+TDR 28,200 11.5 14.0
3630497 24ABC630A**30 CSPH*3012A** 58CV(A,X)070---12 27,800 12.5 15.5
3630553 24ABC630A**30 CSPH*3012A** 58CV(A,X)090---16 28,000 13.0 15.5
3630612 24ABC630A**30 CSPH*3012A** 58CV(A,X)110---20 28,000 13.0 15.5
3630677 24ABC630A**30 CSPH*3012A** 58CV(A,X)135---22 28,000 13.0 15.5
3630728 24ABC630A**30 CSPH*3012A** 58CV(A,X)155---22 28,000 13.0 16.0
3630772 24ABC630A**30 CSPH*3012A** 58HDV040 --- ---12 27,800 12.5 14.5
3630781 24ABC630A**30 CSPH*3012A** 58HDV060 --- ---12 28,000 12.5 15.0
3630839 24ABC630A**30 CSPH*3012A** 58MEB040---12 28,200 13.0 16.0
3630905 24ABC630A**30 CSPH*3012A** 58ME(B,C)060---12 28,200 13.0 15.5
3630967 24ABC630A**30 CSPH*3012A** 58ME(B,C)080---12 28,200 13.0 15.5
3631014 24ABC630A**30 CSPH*3012A** 58ME(B,C)080---16 28,200 13.0 15.5
3631169 24ABC630A**30 CSPH*3012A** 58MV(B,C)060 ---14 28,000 13.0 15.5
3631221 24ABC630A**30 CSPH*3012A** 58MV(B,C)080 ---14 27,800 12.5 15.5
3631272 24ABC630A**30 CSPH*3012A** 58MV(B,C)080 ---20 28,000 12.5 15.5
3631336 24ABC630A**30 CSPH*3012A** 58MV(B,C)100 ---20 27,600 12.5 15.5
3631394 24ABC630A**30 CSPH*3012A** 58MV(B,C)120 ---20 28,000 13.0 15.5
3631442 24ABC630A**30 CSPH*3012A** 58MVB040 ---14 27,800 12.5 15.0
3631517 24ABC630A**30 CSPH*3012A** 58PH*070---16 28,000 12.5 15.0
3631559 24ABC630A**30 CSPH*3012A** 58PH*090---16 28,000 12.5 15.5
3631959 24ABC630A**30 CSPH*3012A** 58UVB060 ---14 28,000 13.0 15.5
3632012 24ABC630A**30 CSPH*3012A** 58UVB080 ---14 27,800 12.5 15.5
3632063 24ABC630A**30 CSPH*3012A** 58UVB080 ---20 28,000 12.5 15.5
3632127 24ABC630A**30 CSPH*3012A** 58UVB100 ---20 27,600 12.5 15.5
3632185 24ABC630A**30 CSPH*3012A** 58UVB120 ---20 28,000 13.0 15.5
3631791 24ABC630A**30 CSPH*3012A**+TDR 28,200 11.5 14.0
3630498 24ABC630A**30 CSPH*3612A** 58CV(A,X)070---12 28,200 13.0 16.0
3630554 24ABC630A**30 CSPH*3612A** 58CV(A,X)090---16 28,400 13.0 16.0
3630613 24ABC630A**30 CSPH*3612A** 58CV(A,X)110---20 28,400 13.0 16.0
3630678 24ABC630A**30 CSPH*3612A** 58CV(A,X)135---22 28,400 13.0 16.0
3630729 24ABC630A**30 CSPH*3612A** 58CV(A,X)155---22 28,400 13.0 16.0
3630773 24ABC630A**30 CSPH*3612A** 58HDV040 --- ---12 28,400 12.5 15.0
3630782 24ABC630A**30 CSPH*3612A** 58HDV060 --- ---12 28,600 12.5 15.0
3630840 24ABC630A**30 CSPH*3612A** 58MEB040---12 28,800 13.0 16.0
3630906 24ABC630A**30 CSPH*3612A** 58ME(B,C)060---12 28,800 13.0 16.0
3630968 24ABC630A**30 CSPH*3612A** 58ME(B,C)080---12 28,600 13.0 16.0
3631015 24ABC630A**30 CSPH*3612A** 58ME(B,C)080---16 28,800 13.0 16.0
3631170 24ABC630A**30 CSPH*3612A** 58MV(B,C)060 ---14 28,400 13.0 16.0
3631222 24ABC630A**30 CSPH*3612A** 58MV(B,C)080 ---14 28,200 13.0 16.0
3631273 24ABC630A**30 CSPH*3612A** 58MV(B,C)080 ---20 28,400 13.0 16.0
3631337 24ABC630A**30 CSPH*3612A** 58MV(B,C)100 ---20 28,200 13.0 16.0
3631395 24ABC630A**30 CSPH*3612A** 58MV(B,C)120 ---20 28,400 13.0 16.0
3631443 24ABC630A**30 CSPH*3612A** 58MVB040 ---14 28,200 13.0 16.0
3631518 24ABC630A**30 CSPH*3612A** 58PH*070---16 28,600 13.0 15.5
3631560 24ABC630A**30 CSPH*3612A** 58PH*090---16 28,600 13.0 16.0
See notes on page 35
24ABC6

20
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3631960 24ABC630A**30 CSPH*3612A** 58UVB060 ---14 28,400 13.0 16.0
3632013 24ABC630A**30 CSPH*3612A** 58UVB080 ---14 28,200 13.0 16.0
3632064 24ABC630A**30 CSPH*3612A** 58UVB080 ---20 28,400 13.0 16.0
3632128 24ABC630A**30 CSPH*3612A** 58UVB100 ---20 28,200 13.0 16.0
3632186 24ABC630A**30 CSPH*3612A** 58UVB120 ---20 28,400 13.0 16.0
3631792 24ABC630A**30 CSPH*3612A**+TDR 28,600 12.0 14.0
3630499 24ABC630A**30 CSPH*4212A** 58CV(A,X)070---12 28,400 13.0 16.0
3630555 24ABC630A**30 CSPH*4212A** 58CV(A,X)090---16 28,400 13.0 16.0
3630614 24ABC630A**30 CSPH*4212A** 58CV(A,X)110---20 28,600 13.0 16.0
3630679 24ABC630A**30 CSPH*4212A** 58CV(A,X)135---22 28,600 13.0 16.0
3630730 24ABC630A**30 CSPH*4212A** 58CV(A,X)155---22 28,600 13.0 16.0
3630841 24ABC630A**30 CSPH*4212A** 58MEB040---12 29,000 13.0 16.0
3630907 24ABC630A**30 CSPH*4212A** 58ME(B,C)060---12 29,000 13.0 16.0
3630969 24ABC630A**30 CSPH*4212A** 58ME(B,C)080---12 28,800 13.0 16.0
3631016 24ABC630A**30 CSPH*4212A** 58ME(B,C)080---16 29,000 13.0 16.0
3631171 24ABC630A**30 CSPH*4212A** 58MV(B,C)060 ---14 28,600 13.0 16.0
3631223 24ABC630A**30 CSPH*4212A** 58MV(B,C)080 ---14 28,400 13.0 16.0
3631274 24ABC630A**30 CSPH*4212A** 58MV(B,C)080 ---20 28,400 13.0 16.0
3631338 24ABC630A**30 CSPH*4212A** 58MV(B,C)100 ---20 28,200 13.0 16.0
3631396 24ABC630A**30 CSPH*4212A** 58MV(B,C)120 ---20 28,600 13.0 16.0
3631444 24ABC630A**30 CSPH*4212A** 58MVB040 ---14 28,400 13.0 16.0
3631519 24ABC630A**30 CSPH*4212A** 58PH*070---16 28,600 13.0 16.0
3631561 24ABC630A**30 CSPH*4212A** 58PH*090---16 28,800 13.0 16.0
3631961 24ABC630A**30 CSPH*4212A** 58UVB060 ---14 28,600 13.0 16.0
3632014 24ABC630A**30 CSPH*4212A** 58UVB080 ---14 28,400 13.0 16.0
3632065 24ABC630A**30 CSPH*4212A** 58UVB080 ---20 28,400 13.0 16.0
3632129 24ABC630A**30 CSPH*4212A** 58UVB100 ---20 28,200 13.0 16.0
3632187 24ABC630A**30 CSPH*4212A** 58UVB120 ---20 28,600 13.0 16.0
3631793 24ABC630A**30 CSPH*4212A**+TDR 28,600 12.0 14.0
3631709 24ABC630A**30 FE4AN(B,F)003+UI 28,200 13.0 16.0
3631712 24ABC630A**30 FE4AN(B,F)005+UI 28,800 13.0 16.5
3631722 24ABC630A**30 FE4ANF002+UI 28,000 13.0 16.0
3631724 24ABC630A**30 FE5ANB004+UI 29,000 13.0 16.5
3631757 24ABC630A**30 FF1ENP030 27,600 12.0 14.0
3631759 24ABC630A**30 FF1ENP031 28,200 12.5 15.0
3631761 24ABC630A**30 FF1ENP036 28,000 12.0 14.0
3631764 24ABC630A**30 FF1ENP037 28,200 12.5 15.0
3631767 24ABC630A**30 FV4BN(B,F)003 28,200 13.0 16.0
3631770 24ABC630A**30 FV4BN(B,F)005 28,800 13.0 16.0
3631802 24ABC630A**30 FV4BNF002 28,000 13.0 16.0
3631805 24ABC630A**30 FV4CN(B,F)003 28,200 13.0 16.0
3631808 24ABC630A**30 FV4CN(B,F)005 28,800 13.0 16.0
3631818 24ABC630A**30 FV4CNF002 28,000 13.0 16.0
3631846 24ABC630A**30 FX4CN(B,F)036 28,200 12.5 15.0
3631848 24ABC630A**30 FX4CN(B,F)042 28,400 12.0 14.0
3631861 24ABC630A**30 FX4CNF030 28,200 12.5 15.0
3632299 24ABC630A**30 FX4DN(B,F)031 28,400 13.0 15.5
3632300 24ABC630A**30 FX4DN(B,F)037 28,800 13.0 16.0
3631891 24ABC630A**30 FY4ANF030 27,800 11.5 14.0
3631893 24ABC630A**30 FY4ANF036 28,000 11.5 13.5
3631895 24ABC630A**30 FY4ANF042 28,200 11.5 13.5
3631820 24ABC636A**30 †CNPV*3717A**+TDR 34,400 12.0 14.5
3630501 24ABC636A**30 CAP**3614A** 58CV(A,X)070---12 32,800 12.0 15.0
3631492 24ABC636A**30 CAP**3614A** 58PH*045 ---08 32,600 11.5 14.0
3631821 24ABC636A**30 CAP**3614A**+TDR 32,800 11.5 14.0
3630502 24ABC636A**30 CAP**3617A** 58CV(A,X)070---12 32,800 12.0 15.0
3630557 24ABC636A**30 CAP**3617A** 58CV(A,X)090---16 33,000 12.5 15.5
3630843 24ABC636A**30 CAP**3617A** 58MEB040---12 33,200 12.5 15.5
3630909 24ABC636A**30 CAP**3617A** 58ME(B,C)060---12 33,200 12.5 15.0
3630971 24ABC636A**30 CAP**3617A** 58ME(B,C)080---12 33,000 12.5 15.0
3631018 24ABC636A**30 CAP**3617A** 58ME(B,C)080---16 33,200 12.5 15.0
3631173 24ABC636A**30 CAP**3617A** 58MV(B,C)060---14 33,000 12.5 15.0
3631493 24ABC636A**30 CAP**3617A** 58PH*045 ---08 32,800 12.0 14.5
3631521 24ABC636A**30 CAP**3617A** 58PH*070 ---16 33,000 12.0 15.0
3631963 24ABC636A**30 CAP**3617A** 58UVB060---14 33,000 12.5 15.0
3631822 24ABC636A**30 CAP**3617A**+TDR 33,000 11.5 14.0
3630774 24ABC636A**30 CAP**3619A** 58HDV040--- ---12 32,800 11.5 14.5
3630783 24ABC636A**30 CAP**3619A** 58HDV060--- ---12 33,000 12.0 14.5
3631829 24ABC636A**30 CAP**3619A**+TDR 33,000 11.5 14.0
3630558 24ABC636A**30 CAP**3621A** 58CV(A,X)090---16 33,000 12.5 15.5
3630615 24ABC636A**30 CAP**3621A** 58CV(A,X)110---20 33,000 12.5 15.5
3630844 24ABC636A**30 CAP**3621A** 58MEB040---12 33,200 12.5 15.5
3630910 24ABC636A**30 CAP**3621A** 58ME(B,C)060---12 33,400 12.5 15.5
3630972 24ABC636A**30 CAP**3621A** 58ME(B,C)080---12 33,200 12.5 15.5
3631019 24ABC636A**30 CAP**3621A** 58ME(B,C)080---16 33,200 12.5 15.0
3631058 24ABC636A**30 CAP**3621A** 58ME(B,C)100---20 33,200 13.0 16.0
3631174 24ABC636A**30 CAP**3621A** 58MV(B,C)060---14 33,000 12.5 15.5
3631224 24ABC636A**30 CAP**3621A** 58MV(B,C)080---14 33,000 12.0 15.0
See notes on page 35
24ABC6
