Carrier 38ASB Series Dimensions and installation guide

CONTENTS
Safety Considerations 1Complete Electrical Connections 5
Dimensional Drawing 2Start-up 5
Model Identification 2Refrigerant Charging 5 -6
Specifications 3Service and Maintenance 6 -7
Installation 4Wiring Diagram 7-13
Refrigerant Piping 4Trouble-Shooting Guide 14
Piping Connections 5
SAFETY CONSIDERATIONS
Installation and servicing of air conditioning equipment can
be hazardous due to system pressure and electrical
components. Only trained and qualified service personnel
should install, repair or service air conditioning equipment.
Observe precautions in the literature, tags and labels
attached to the unit and other safety codes. Wear safety
glasses and gloves. Use quenching cloth and have fire
extinguisher available for all brazing operations.
RECEIVING
INSPECTION
Check the shipment against shipping list and remove unit
from the carton and take off protective covering. If the unit
has been damaged, file claim with Transportation Company
and notify Carrier immediately.
PROTECTION
Protect unit from damage caused by job site debris. Do
not allow dust, debris and water getinto the unit.
These will damage unit’s component and unit’s
performance will be affected.
38ASB/CCARS240~600 condensing units (Fig. 1) are
shipped individually packed in carton boxes. When cartons
are individually off loaded from truck, do not roll, nor throw,
or drop the carton, to avoid damages to the content. Store
boxes upright as the symbols or the boxes indicate. Do not
stack units more than 2 high.
WARNING
Before installing or servicing system always turn off main
power supply. There may be morethan one disconnect
switch. Electrical shock can cause personal injury.
Concepcion
Carrier
Air conditioning
Company
Philippines
INSTALLATION, START-UP AND
SERVICE INSTRUCTIONS
38ASB/CCARS
24
0
~
60
0
(036~060)
AIR-COOLED CONDENSING UNIT
FIG. 1
38ASB/CCARS240~600
(036~060) Export
1

TABLE 1 –MODEL IDENTIFICATION
STD
(EXPORT)
STD
(EXPORT)
38ASB600DB *
38ASB600DC **
Legend:
* - Model used for 40KMC/GKX, 42GX/AR, 40LX
** - Model used for SlimPack ASBFE600BA
NEW MODEL NUMBER
REMARKS
38ASB
3TR
SERIES
38ASB240BA 38ASB360BAOLD MODEL NUMBER
CCAR
5TR
Single phase supply
volatge
CCARS024EA CCARS036EA CCARS060KA
2TR
38ASB036BA
-
38ASB060BA
-
FIG. 2
38ASB/CCARS024~060 DIMENSIONAL DRAWING
2

TABLE 2 SPECIFICATIONS
240BA 360BA 036BA (Export) 060BA (Export) 600DA/DB 600DC
OPERATINGWEIGHT (kg) 67 80.5 80.5 95 85 85
GROSSWEIGHT (kg) 69.5 83 83 97.5 87.5 87.5
REFRIGERANT Type
Factorycharged(kg) 1.5 2.52 2.52 2.55 2.27 2.50
COMPRESSORS Type
Oil Charged (l) 0.90 1.30 1.30 1.66 1.95 1.95
LRA (A) Nominal 66 91 91 175 139 135
RunningAmps(A)* 12.6 16.8 16.8 26.8 16.7 15.0
Power Supply
CONDENSERFAN Type
Number
BladeDia.(mm)
Speed (rpm)
Drive
FAN MOTOR Type
Power Supply
RunningAmps(A)*
CONDENSERCOIL Rows-Fins/inch 2R-15 3.5R-15
FaceArea(m2)0.379
CONNECTIONS Type
Liquid,(mm)inch.
Suction, (mm) inch.
CONTROLS; PRESSURES SWITCH High Cut Out (psi)
SETTINGS Cut In (psi)
Low Cut Out (psi)
Cut In (psi)
NOMINAL POWER SOURCE V-Ph-Hz
ABSOLUTE MIN. - MAX VOLTAGE (V)
230V-3Ph-60Hz
(19.05)3/4(15.88)5/8
Direct Drive
0.654
230V-1Ph-60Hz
230V-1Ph-60Hz
950
1.7
Flare
550
230V-3Ph-60Hz230V-1Ph-60Hz
Propeller
1
PermanentSplitCapacitor
MODEL 38ASB / CCARS
R-22
Hermetic
180-253
0.536
2.5-15
27?4
67?7
426?20
(9.5)3/8
320?10
3R-15
197-253
LRA : Locked Rotor Amps
?? Data rated to PNS standard at 350C (950F) Ambient, 27.00C / 19.00C (80.60F / 66.20F) Indoor Condition.
FIG. 3 GROUND MOUNTING FIG. 4 WALL MOUNTING
3

INSTALLATION
SELECTION OF MOUNTING POSITION
1) The unit should be installed outdoors.
2) A place where air will not be stagnant.
3) A place where the exhausted air will not be sucked in for
the second time.
4) Allow sufficient space for airflow clearance, wiring,
refrigerant piping and servicing unit. See Fig. 2.
5) Avoid positioning unit in such a manner that water will
pour directly onto the unit.
6) Do not install the unit near a source of heat, steam or
flammable gas.
7) Ducting of the fan inlet or discharge is not permitted.
UNIT MOUNTING
1) MOUNTING ON GROUND –Mount on a solid, level
concrete base. If conditions or local building codes
require unit to be fastened to base, tie down bolts
should be used and fastened through slots provided in
unit’s mounting feet (Fig. 3). Do not install unit directly
on ground.
2) MOUNTING ON AND AGAINST THE WALL –the
bracket is to be locally procured (Fig. 4).
3) MOUNTING ON ROOF–Mount on a level platform or
frame. When multiple unit are installed, the air outlet
side should be opened as shown in Fig. 5.
When installation base is used, secure the required spacing
as per (Fig. 6). Fabricatethe stand so that it will have
sufficient strength.
REFRIGERANT PIPING
Size Refrigerant Lines. Consider length of piping required
between unit and evaporator, amount of liquid lift and
compressor oil return (Table 4).
Run refrigerant tubes as directly as possible, avoiding
unnecessary turns and bends. Condensing unit may be
connected to evaporator sections using field-supplied
tubing of refrigerant grade, correct size and condition.
Suspend refrigerant tubes so they do not transmit
vibration to structure. Also when passing refrigerant
tubes through walls, seal opening so vibration is not
transmitted to structure. Leave some slack in refrigerant
tubes between structure and unit to absorb vibration.
The longer the piping, the lower the cooling capacity of
the unit. See table 3.
TABLE 3 –REDUCTION IN CAPACITY VS
INCREASE IN PIPE LENGTH
MODEL
38ASB /
CCAR 5m 10m 15m 20m 25m 30m
240 0% 1.2% 2.0% 2.8% 3.5% 4.5%
360 / 036 0% 1.6% 2.6% 3.6% 4.6% 5.6%
600 / 060 0% 2.8% 4.8% 6.7% 8.7% 10.2%
PIPING LENGTH (ONE WAY)
As such the following are the operating limits. Refer to
Table 4 and fig. 7.
TABLE 4 –VERTICAL AND HORIZONTAL
SEPARATION BETWEEN INDOOR
AND OUTDOOR UNIT
MODEL MAX. MAX.
38ASB / HEIGHT LENGTH MAX. ALLOWABLEMAX. ALLOWABLE
CCARS024~060 H(m) L(m) PRESSURE DROP TEMPERATURE
(kPa)
LOSS (
0
C)
024 (20)15 25
360 / 036 (20)15 25
600 / 060 (25)15 30
LIQUID LINE
151 5
Note: 1) Values shown are for units operating at 7.20C saturated suction
and 350C entering air.
2) Values in ( ) indicate a case when the outdoor unit is located at
a lower height than the indoor unit.
Do not bury section of line set underground. If any section is buried,
refrigerant may migrate to cooled buried section during extended period of
unit shutdown. This causes refrigerant slugging and possible compressor
damage at start-up.
If either refrigerant tubing or indoor coil is exposed to atmospheric
conditions for longer than 5 minutes, it must be evacuated to 1000 microns
to eliminate contamination and moisture in the system.
FIG. 5 ROOF MOUNTING
FIG. 6 MINIMUM SPACING REQUIREMENT
FIG. 7 MAXIMUM ALLOWABLE PIPING LENGTH
AND ELEVATION DIFFERENCE
4

PIPING CONNECTIONS
Complete all installation and piping work required for indoor and
outdoor units. If brazing is required pass nitrogen or other inert gas
through piping to prevent formation of cooper oxide. Unit contains R-
22 charge, do not open Schreader valve at this time. Leak test field
piping by pressure method.
PIPING INSULATION
No refrigerant control device is shipped with the unit except 024
model. It is already installed in matching Fan coil units,check
carefully the indoor unit.Insulate suction line adequately (Fig. 8)
COMPLETE ELECTRICAL CONNECTIONS
POWER –Unit is factory wired for voltage shown on name plate.
Provide adequate fused disconnect switch within sign of unit, readily
accessible, but out of reach children.
Provide for locking switch open (OFF) is advisable to prevent power
from being turned on while unit is being serviced.
Route power wires through opening in unit side panel and connect in
unit control box (fig. 9). Unit must be grounded.
CONTROL CIRCUIT WIRING
Refer to wiring diagram for field supplied wiring details.
See Fig. 11 & 12.
Note: -Operation of unit on improper line voltage constitutes
abuse and could affect Carrier Warranty. Do not install
unit in system where voltage may fluctuate above or below
permissible limits.
START-UP
PRELIMINARY CHECKS:
1) Check that all internal wiring connections are tight and all
barriers, covers and panels are in place.
2) Field electrical power source must agree with unit name
plate rating.
3) All service valves must be opened.
START SYTEM
1. Check that field disconnect is closed.
2. Set room thermostat to below room temperature, and unit
compressor will start after 3minutes delay o.
3. Check back pressure when compressor runs. Add charge to
keep back pressure at approximately 448kPa (65 PSIG).
REFRIGERANT CHARGING
IMPORTANT
For accurate system performance, charge by superheat method
as shown in table 5 and 6.
To check and adjust charge, follow the following procedures:-
1) Operate unit for a minimum of 15 minutes before checking
charge.
2) Measure suction pressure by attaching a gauge to suction
line service port.
3) Measure suction line temperature by attaching a service
thermometer to unit suction line near suction valve.
Insulate thermometer for accurate readings.
4) Measure outdoor coil air inlet dry-bulb temperature with a
second thermometer.
5) Measure indoor coil air inlet wet-bulb temperature with a
sling psychrometer.
6) Refer to table 5. Find air temperature entering outdoor coil
& wet-bulb temperature entering indoor coil. At this
intersection, note the superheat.
7) Refer to table 6 . Find superheat temperature and suction
pressure, note suction line temperature.
FIG. 8 PIPING INSULATION
CAUTION
THE CONTROL VOLTAGE FROM THE FAN COIL UNIT
MUST BE OF 230V. DO NOT CONNECT THE POWER
SUPPLY TO THE SIGNAL
FIG. 9 POWER WIRES TO THE SIDE OF UNIT
CAUTION
TO PREVENT PERSONAL INJURY, WEAR SAFETY
GLASSES AND GLOVES WHEN HANDLING
REFRIGERANT. DO NOT OVERCHARGED SYSTEM.
THIS CAN CAUSE COMPRESSOR FLOODING.
NOTE:
Model 240 need
to insulate both Suction
and liquid pipes
5

REFRIGERANT CHARGING (cont)
8) If unit has higher suction line temperature than charted
temperature add refrigerant until charted temperature is
reached.
9) If unit has lower suction line temperature than charted
temperature, bleed refrigerant until charted temperature is
reached.
10) If air temperature entering outdoor coil or pressure at
suction line charge to new suction line temperature
indicated on chart.
11) This procedure is valid independent of indoor air quantity.
SERVICE AND MAINTENACE
CLEANING COIL –Coil should be washed out with water or blow
out with compressed air. The draw thru design causes dirt and
debris to built up on the outside of the coils. Clean coil as follows:-
1) Turn off unit power.
2) Using a water hose or other suitable equipment, flush coil from
the inside to remove dirt (see Fig. 10). Be sure to flush all dirt
and debris from drain holes in base of unit. Fan motor is water
proof but it is more safe to cover or wrap motor shell with
plastic sheet (or plastic bag) to prevent water from getting
inside.
Clean coil semi-annually or as required. Fins are not continuous
through coil sections. Dirt and debris may pass between the row of
fins and become trapped between the row of fins and restrict
condenser air flow. Use a flashlight to determine if dirt or debris has
collected between coil section.
LUBRICATION
Fan motor is permanently sealed lubricated bearings. Do not oil.
Compressor is supplied charged with oil. Replace oil when lost.
See table 2 for oil recharge quantity.
CAUTION
BEFORE PE
RFORMING RECOMMENDED MAINTENANCE
AND SERVICE, BE SURE UNIT MAIN POWER SWITCH IS
TURNED OFF. FAILURE TO DO SO MAY RESULT IN
ELECTRIC SHOCK OR INJURY FROM ROTATING FAN
BLADE.
FIG
. 10 CLEANING COIL WITH WATER
FIG. 11 38ASB240BA, 360 &
036 /
060
(export models
)
WIRING
PE720113
6

PE740132
FIG. 12 38ASB600DC WIRING DIAGRAM
FIG. 13 38ASB600DB WIRING DIAGRAM
PE740133
NOTE:
FOR OTHER 38ASB WIRING DIAGRAM NOT SHOWN HERE, PLEASE REQUEST COPIES FROM CCAC ENGINEERING DEPARTMENT.
7

TABLE 5
Superheat Charging Table
(Superheat Entering Suction Service Valve)
50 52 54 56 58 60 62 64 66 68 70 72 74 76
55 9 12 14 17 20 23 26 29 32 35 37 40 42 45
60 7 10 12 15 18 21 24 27 30 33 35 38 40 43
65 -- 6 10 13 16 19 21 24 27 30 33 36 38 41
70 -- -- 7 10 13 16 19 21 24 27 30 33 36 39
75 -- -- -- 6 9 12 15 18 21 24 28 31 34 37
80 -- -- -- -- 5 8 12 15 18 21 25 28 31 35
85 -- -- -- -- -- -- 8 11 15 19 22 26 30 33
90 -- -- -- -- -- -- 5 9 13 16 20 24 27 31
95 -- -- -- -- -- -- -- 6 10 14 18 22 25 29
100 -- -- -- -- -- -- -- -- 812 15 20 23 27
105 -- -- -- -- -- -- -- -- 5 9 13 17 22 26
110 -- -- -- -- -- -- -- -- -- 611 15 20 25
115 -- -- -- -- -- -- -- -- -- -- 814 18 23
OUTDOOR
TEMP (0F) INDOOR COIL ENTERING AIR (0F) WET-BULB
-Do not attempt to charge system under these conditions of
refrigerant slugging may occur.
TABLE 6
Required Suction Tube Temperature (0F)
(Entering Suction Service Valve)
61.5 64.2 67.1 70.0 73.0 76.0 79.2 82.4 85.7
0 35 37 39 41 43 45 47 49 51
2 37 39 41 43 45 47 49 51 53
4 39 41 43 45 47 49 51 53 55
6 41 43 45 47 49 51 53 55 57
8 43 45 47 49 51 53 55 57 59
10 45 47 49 51 53 55 57 59 61
12 47 49 51 53 55 57 59 61 63
14 49 51 53 55 57 59 61 63 65
16 51 53 55 57 59 61 63 65 67
18 53 55 57 59 61 63 65 67 69
20 55 57 59 61 63 65 67 69 71
22 57 59 61 63 65 67 69 71 73
24 59 61 63 65 67 69 71 73 75
26 61 63 65 67 69 71 73 75 77
28 63 65 67 69 71 73 75 77 79
30 65 67 69 71 73 75 77 79 81
32 67 69 71 73 75 77 79 81 83
34 69 71 73 75 77 79 81 83 85
36 71 73 75 77 79 81 83 85 87
38 73 75 77 79 81 83 85 87 89
40 75 77 79 81 83 85 87 89 91
SUPERHEAT
TEMP (0F) SUCTION PRESSURE AT SERVICE PORT (psig)
Superheat Charging Table
(Superheat Entering Suction Service Valve)
10 11.1 12.2 13.3 14.4 15.6 16.7 17.8 18.9 20 21.1 22.2 23.3 24.4
12.8 56.7 7.8 9.4 11.1 12.8 14.4 16.1 17.8 19.4 20.6 22.2 23.3 25
15.5 3.9 5.6 6.7 8.3 10 11.7 13.3 15 16.7 18.3 19.4 21.1 22.2 23.9
18.3 -- 3.3 5.8 7.2 8.9 10.6 11.7 13.3 15 16.7 18.3 20 21.1 22.8
21.1 -- -- 3.9 5.6 7.2 8.9 10.6 11.7 13.3 15 16.7 18.3 20 21.7
23.9 -- -- -- 3.3 56.7 8.3 10 11.7 13.3 15.6 17.2 18.9 20.6
26.7 -- -- -- -- 2.8 4.4 6.7 8.3 10 11.7 13.9 15.6 17.2 19.4
29.4 -- -- -- -- -- -- 4.4 6.1 8.3 10.6 12.2 14.4 16.7 18.3
32.2 -- -- -- -- -- -- 2.8 57.2 8.9 11.1 13.3 15 17.2
36.0 -- -- -- -- -- -- -- 4.4 5.6 7.8 10 12.2 13.9 16.1
37.8 -- -- -- -- -- -- -- -- 3.3 6.7 8.3 11.1 12.8 15
40.6 -- -- -- -- -- -- -- -- 2.8 57.2 9.40 12.2 14.4
43.3 -- -- -- -- -- -- -- -- -- 3.3 6.1 8.3 11.1 13.9
46.1 -- -- -- -- -- -- -- -- -- -- 4.4 7.8 10 12.8
OUTDOOR
TEMP (0C) INDOOR COIL ENTERING AIR (0C) WET-BULB
-Do not attempt to charge system under these conditions or
refrigerant slugging may occur.
Required Suction Tube Temperature (0C)
(Entering Suction Service Valve)
424 443 463 483 503 524 546 568 591
01.7 2.8 3.9 56.1 7.2 8.3 9.4 10.6
1.1 2.8 3.9 56.1 7.2 8.3 9.4 10.6 11.7
2.2 3.9 56.1 7.2 8.3 9.4 10.6 11.7 12.8
3.3 56.1 7.2 8.3 9.4 10.6 11.7 12.8 13.9
4.4 6.1 7.2 8.3 9.4 10.6 11.7 12.8 13.9 15
5.6 7.2 8.3 9.4 10.6 11.7 12.8 13.9 15 16.1
6.7 8.3 9.4 10.6 11.7 12.8 13.9 15 16.1 17.2
7.8 9.4 10.6 11.7 12.8 13.9 15 16.1 17.2 18.3
8.9 10.6 11.7 12.8 13.9 15 16.1 17.2 18.3 19.4
10.0 11.7 12.8 13.9 15 16.1 17.2 18.3 19.4 20.6
11.1 12.8 13.9 15 16.1 17.2 18.3 19.4 20.6 21.7
12.2 13.9 15 16.1 17.2 18.3 19.4 20.6 21.7 22.8
13.3 15 16.1 17.2 18.3 19.4 20.6 21.7 22.8 23.9
14.4 16.1 17.2 18.3 19.4 20.6 21.7 22.8 23.9 25
15.6 17.2 18.3 19.4 20.6 21.7 22.8 23.9 25 26.1
16.7 18.3 19.4 20.6 21.7 22.8 23.9 25 26.1 27.2
17.8 19.4 20.6 21.7 22.8 23.9 25 26.1 27.2 28.3
18.9 20.6 21.7 22.8 23.9 25 26.1 27.2 28.3 29.4
20.0 21.7 22.8 23.9 25 26.1 27.2 28.3 29.4 30.6
21.2 22.8 23.9 25 26.1 27.2 28.3 29.4 30.6 31.7
22.2 23.9 25 26.1 27.2 28.3 29.4 30.6 31.7 32.8
SUPERHEAT
TEMP (0K) SUCTION PRESSURE AT SERVICE PORT (KPaG)
8

FIG. 14 SCHEMATI
C SYSTEM WIRING DIAGRAM
38ASB240BA MATCHED WITH 42PGA026
38ASB240BA MATCHED WITH 42AR
024
/ 42GX024
38ASB360BA MATCHED WITH 42AR036 / 42GX040
9

38ASB240BA MAT
CHED WITH 40GKX / KMC024
38ASB360BA MATCHED WITH 40GKX / KMC036
FIG. 15 SCHEMATIC SYSTEM WIRING DIAGRAM
38ASB360BA MATCHED WITH ASBFM360BA
10

FIG. 16 SCHEMATIC SYSTEM WIRING DI
AGRAM
38ASB360BA MATCHED WITH 40LX040
38ASB600DC MATCHED WITH 42AR / 42GX060
1
1

38ASB600DC MATCHED WITH 40
GKX
/
KMC060
38ASB600DB MATCHED WITH 4
0
LX060
1
2

38ASB600DC MATCHED WITH ASBF
E
600BA
1
3

TROUBLE-SHOOTING CHART –COOLING CYCLE
NO COOLING OR
IN-SUFFICIENT
COOLING
COMPRESSOR RUNS
BUT CYCLES ON
INTERNAL OVERLOAD
COMPRESSOR
WILL NOT RUN
CONTACTOR OPEN
FAULTY POWER
SUPPLY
OPEN C
ONTROL
CIRCUIT
DEFECTIVE TIME
DELAY
CONTACTOR OR
COIL DEFECTIVE
LOOSE ELECTRICAL
CONNECTION
INTERNAL
OVERLOAD OPEN
OPEN DISCHARGE
LINE
PRESSURE SWITCH
CONTACTOR
CLOSED
COMPRESSOR
POWER
SUPPLY OPEN
LOSE LEADS
AT COMPRESSOR
OPEN SHORTED OR
GROUNDED
COMPRESSOR
MOTOR WINDINGS
COMPRESSOR
STUCK
COMPRESSOR
INTERNAL
PROTECTION OPEN
OUTDOOR FAN
STOPPED OR CYLING
COOLING
OUTDOOR AIR
RESTRICTED OR
RECIRCULATING
RESTRICTED
DISCHARGE LINE
OVERCHARGE OR
NONCONDENSABLES
IN SYSTEM
LOW REFRIGERANT
CHARGE
LINE VOLTAGE
TO HIGH OR LOW
COMPRESSOR
BEARINGS
HIGH SUPERHEAT
LOOSE LEAD AT
FAN MOTOR
MOTOR DEFECTIVE
INCORRECT
OUTDOORFANMOTOR
CAPACITOR
COMPRESSOR RUNS
BUT INSUFFICIENT
COOLING
LOW SUCTION
PRESSURE
HIGH SUCTION
LOW HEAD
PRESSURE
HIGH SUCTION
LOW SUPERHEAT
DIRTY AIR FILTERS
DUCT RESTRICTED
DAMPERS PARTY
CLOSED
INDOOR COIL
FROSTED
SLIGHTLY LOW OR
REFRIGERANT
LIQUID LINE SLIGHTLY
RESTRICTED
METERING DEVICE
RESTRICTED
INCORRECT
METERING DEVICE
INDOOR COIL
STRAINER
RESTRICTED
DEFECTIVE
COMPRESSOR
VALVE
INTERNAL
PRESSURE
RELIEF OPEN
INCORRECT
METERING DEVICE
UNIT OVERCHARGED
1
4

Concepcion Carrier Air Conditioning Company
Km. 20 East Service Road, South Superhighway,
Alabang, Muntinlupa City
Tel. No. (63)2 850 1367
Fax No. (63)2 809 9979
Website: www.carrier.com.ph
Manufacturer reserve the right to discontinue, or charge at any time, specifications or designs without notice and without incurring obligations
Form 38ASB/CCARS024~060-1IOM
Replaces: NEW
Concepcion
Carrier
Air conditioning
Company
Philippines
1
5
