Product Data
CA16NA 018---061
Single---Stage Air Conditioner
with PuronrRefrigerant
Carrier’s CA16 has been designed utilizing Carrier’s Puron
refrigerant. The environmentally sound refrigerant allows you to
make a responsible decision in the protection of the earth’s ozone
layer.
This product has been designed and manufactured to meet
Energy Starrcriteria for energy efficiency when matched with
appropriate coil components. Refer to the combination ratings in
the Product Data for system combinations that meet Energy Starr
guidelines.
NOTE:Ratings contained in this document are subject to
change at any time. Always refer to the AHRI directory
(www.ahridirectory.org) for the most up--to--date ratings
information.
INDUSTRY LEADING
FEATURES / BENEFITS
Efficiency
S14 -- 16.5 SEER/11.0-- 13.5 EER
SMicrotube Technologytrefrigeration system
SIndoor air quality accessories available
Sound
SSound level as low as 76 dBA
SSound level as low as 74 dBA with accessory sound
blanket
Comfort
SSystem supports EdgerThermidistattor standard
thermostat controls
Reliability
SPuronrrefrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime servce cost.
SScroll compressor
SInternal pressure relief valve
SInternal thermal overload
SFilter drier
SBalanced refrigeration system for maximum reliability
Durability
WeatherArmortprotection package:
SSolid, durable sheet metal construction
SDense wire coil guard standard
SBaked--on, complete outer coverage, powder paint
Applications
SLong--line -- up to 250 feet (76.20 m) total equivalent
length, up to 200 feet (60.96 m) condenser above
evaporator, or up to 80 ft. (24.38 m) evaporator above
condenser (See Longline Guide for more information.)
SLow ambient (down to --20_F/--28.9_C)) with
accessory kit

2
MODEL NUMBER NOMENCLATURE
CA16 N 018
16 SEER
Air Conditioner
with Puron Refrigerant
Electrical Supply
N--- 208/230---60---1
Nominal Capacity
018 --- 1 --- 1 / 2 To n
024 --- 2 To n s
030 --- 2 --- 1 / 2 To n s
036 --- 3 To n s
042 --- 3 --- 1 / 2 To n s
048 --- 4 To n
060 --- 5 To n
A
A --- P u r o n
B
Variations
A
Series
00G
00G --- V a r i a t i o n s
the environmentally sound refrigerant
This product has been designed and manufactured to
meet Energy Star®criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
STANDARD FEATURES
Feature 18 24 30 36 42 48 / 49 60 / 61
Puron Refrigerant XXXXXXX
Maximum SEER * 16.0 16.0 16.5 16.5 16.0 16.0 16.0
Scroll Compressor XXXXXXX
FieldInstalledFilterDrier XXXXXXX
Front Seating Service Valves XXXXXXX
Internal Pressure Relief Valve XXXXXXX
Internal Thermal Overload XXXXXXX
Long Line capability XXXXXXX
Low Ambient capability with Kit XXXXXXX
Dense Grille XXXXXXX
* With approved combinations
X=Standard
CA16NA

3
REFRIGERANT PIPING LENGTH LIMITATIONS
Liquid Line Sizing and Maximum Total Equivalent Lengths{for Cooling Only Systems with PuronrRefrigerant:
The maximum allowable length of a residential split system depends on the liquid line diameter and vertical separation between indoor and
outdoor units.
See Table below for liquid line sizing and maximum lengths :
Maximum Total Equivalent Length
Outdoor Unit BELOW Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/ TXV
AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit BELOW Indoor
Vertical Separation ft (m)
0 --- 5
(0--- 1.5)
6 --- 1 0
(1.8--- 3.0)
11--- 20
(3.4--- 6.1)
21--- 30
(6.4--- 9.1)
31--- 40
(9.4--- 12.2)
41--- 50
(12.5--- 15.2)
51--- 60
(15.5--- 18.3)
61--- 70
(18.6--- 21.3)
71--- 80
(21.6--- 24.4)
18000
AC with
Puron
3/8
1/4 150 150 125 100 100 75 --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 250* 250* 225* 150
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
24000
AC with
Puron
3/8
1/4 75 75 75 50 50 --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 225* 175 125 100
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
30000
AC with
Puron
3/8
1/4 30 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
5/16 175 225* 200 175 125 100 75 --- --- --- ---
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
36000
AC with
Puron
3/8 5/16 175 150 150 100 100 100 75 --- --- --- ---
3//8 250* 250* 250* 250* 250* 250* 250* 250* 250*
42000
AC with
Puron
3/8 5/16 125 100 100 75 75 50 --- --- --- --- --- ---
3/8 250* 250* 250* 250* 250* 250* 250* 250* 150
48000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 230 160 --- ---
49000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 230 160 --- ---
60000
AC with
Puron
3/8 3/8 250* 250* 250* 225* 190 150 110 --- --- --- ---
61000
AC with
Puron
3/8 3/8 250* 250* 250* 225* 190 150 110 --- --- --- ---
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
Maximum Total Equivalent Length
Outdoor Unit ABOVE Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/ TXV
AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit ABOVE Indoor
Vertical Separation ft (m)
25
(7.6)
26--- 50
(7.9--- 15.2)
51--- 75
(15.5--- 22.9)
76--- 100
(23.2--- 30.5)
101--- 125
(30.8--- 38.1)
126--- 150
(38.4--- 45.7)
151--- 175
(46.0--- 53.3)
176--- 200
(53.6--- 61.0)
18000
AC with
Puron
3/8
1/4 175 250* 250* 250* 250* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
24000
AC with
Puron
3/8
1/4 100 125 175 200 225* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
30000
AC with
Puron
3/8
1/4 30 --- --- --- --- --- --- --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
36000
AC with
Puron
3/8 5/16 225* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
42000
AC with
Puron
3/8
5/16 175 200 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
48000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
49000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
60000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
61000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
CA16NA

4
REFRIGERANT CHARGE ADJUSTMENTS
Liquid Line Size Puron Charge oz/ft
3/8 0.60
(Factory charge for lineset = 9 oz)
5/16 0.40
1/4 0.27
Units are factory charged for 15 ft (4.6 m) of 3/8” liquid line. The factory charge for 3/8” lineset 9 oz. When using other length or diameter
liquid lines, charge adjustments are required per the chart above.
Charging Formula:
[(Lineset oz/ft x total length) – (factory charge for lineset)] = charge adjustment
Example 1: System has 15 ft of line set using existing 1/4“ liquid line. What charge adjustment is required?
Formula: (.27 oz/ft x 15ft) – (9 oz) = (-4.95) oz.
Net result is to remove 4.95 oz of refrigerant from the system
Example 2: System has 45 ft of existing 5/16” liquid line. What is the charge adjustment?
Formula: (.40 oz/ft. x 45ft) – (9 oz.) = 9 oz.
Net result is to add 9 oz of refrigerant to the system
LONG LINE APPLICATIONS
An application is considered Long Line, when the refrigerant level in the system requires the use of accessories to maintain acceptable
refrigerant management for systems reliability. See Accessory Usage Guideline table for required accessories. Defining a system as long line
depends on the liquid line diameter, actual length of the tubing, and vertical separation between the indoor and outdoor units.
For Air Conditioner systems, the chart below shows when an application is considered Long Line.
AC WITH PURONrREFRIGERANT LONG LINE DESCRIPTION ft (m)
Beyond these lengths, long line accessories are required
Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor
1/4 No accessories needed within allowed
lengths
No accessories needed within allowed
lengths 175 (53.3)
5/16 120 (36.6) 50 (15.2) 120 (36.6)
3/8 80 (24.4) 35 (10.7) 80 (24.4)
Note: SeeLongLineGuidelinefordetails
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line
diameters shown in the chart below are acceptable for AC systems with Puron refrigerant:
Unit
Nominal
Size (Btuh)
Maximum
Liquid Line
Diameters
(In. OD)
Vapor Line
Diameters
(In. OD)
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. (m)
26 --- 50
(7.9--- 15.2)
51 --- 80
(15.5--- 24.4)
81 --- 100
(24.7--- 30.5)
101 --- 125
(30.8--- 38.1)
126 --- 150
(38.4--- 45.7)
151 --- 175
(46.0--- 53.3)
176 --- 200
(53.6--- 61.0)
201 --- 225
(61.3--- 68.6)
226 --- 250
(68.9--- 76.2)
18000
1Stage
AC with
Puron
3/8
1/2 1 2 3 5 6 7 8 9 11
5/8 0 1 1 1 2 2 2 3 3
3/4 0 0 0 0 1 1 1 1 1
24000
1Stage
AC with
Puron
3/8
5/8 0 1 2 2 3 3 4 5 5
3/4 0 0 1 1 1 1 1 2 2
7/8 0 0 0 0 0 1 1 1 1
30000
1Stage
AC with
Puron
3/8
5/8 1 2 3 3 4 5 6 7 8
3/4 0 0 1 1 1 2 2 2 3
7/8 0 0 0 0 1 1 1 1 1
36000
1Stage
AC with
Puron
3/8
5/8 1 2 4 5 6 8 9 10 12
3/4 0 1 1 2 2 3 3 4 4
7/8 0 0 0 1 1 1 1 2 2
42000
1Stage
AC with
Puron
3/8
3/4 0 1 2 2 3 4 4 5 6
7/8 0 0 1 1 1 2 2 2 3
11/8 0 0 0 0 0 0 0 0 0
48000,
49000
1Stage
AC with
Puron
3/8
3/4 0 1 2 3 4 5 5 6 7
7/8 0 0 1 1 2 2 2 3 3
11/8 0 0 0 0 0 0 0 1 1
60000,
61000
1Stage
AC with
Puron
3/8
3/4 1 2 4 5 6 7 9 10 11
7/8 0 1 2 2 3 4 4 5 5
11/8 0 0 0 1 1 1 1 1 1
Applications in this area may be long line and may have height restrictions. See the Residential Piping and Long Line Guideline.
CA16NA

5
PHYSICAL DATA
UNIT SIZE --- VOLTAGE, SERIES 1 8 --- A 2 4 --- A 30 --- A 36 --- A 4 2 --- A 48--- A 4 9 --- A 6 0 --- A 6 1 --- A
Operating Weight lb (kg) 125
(56.7)
147
(66.5)
153
(69.3)
165
(74.8)
213
(96.4)
264
(119.7)
231
(104.8)
272
(123.4)
272
(123.4)
Shipping Weight lb (kg) 154
(69.9)
183
(82.8)
188
(85.2)
204
(92.5)
254
(115.2)
317
(143.8)
269
(222.0)
310
(140.6)
310
(140.6)
Compressor Type Scroll
REFRIGERANT Puron®(R ---410A)
Control TXV (Puron®Hard Shutoff)
Charge lb (kg) 4.60
(2.09)
6.00
(2.72)
6.81
(3.09)
7.00
(3.18)
8.62
(3.91)
13.0
(5.90)
9.00
(4.08)
14.50
(6.58)
14.50
(6.58)
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical Vertical
Air Qty (CFM) 1881 2614 2614 3223 3810 4046 4046 4046 4046
Motor HP 1/12 1/10 1/10 1/12 1/5 1/4 1/4 1/4 1/4
Motor RPM 1100 1100 1100 800 800 800 800 800 800
COND COIL
Face Area (Sq ft) 11.50 15.10 17.20 17.60 25.15 25.15 25.15 30.15 30.15
Fins per In. 25 25 25 25 25 20 20 20 20
Rows 1 1 1 1 1 2 1 2 2
Circuits 3 4 4 4 6 7 7 8 8
VALVECONNECT.(In.ID)
Vapor 3/4 3/4 3/4 7/8 7/8 7/8 7/8 7/8 7/8
Liquid 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
REFRIGERANT TUBES (In. OD)
Rated Vapor* 3/4 7/8 1 --- 1 / 8
Max Liquid Line {3/8
* Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
Note: See unit Installation Instruction for proper installation.
{See Liquid Line Sizing For Cooling Only Systems with Puron Refrigerant tables.
ELECTRICAL DATA
UNIT SIZE V/PH
OPER
VOLTS* COMPR FAN
MCA
MIN WIRE
SIZE{
60°C
MIN WIRE
SIZE{
75°C
MAX
LENGTH
ft. (m)}
60°C
MAX
LENGTH
ft. (m)}
75°C
MAX FUSE**
or CKT BRK
AMPS
MAX MIN LRA RLA FLA
1 8 --- A
208/230/1---60 253 197
48.0 9.0 0.50 11.8 14 14 67 (20.4) 64 (19.5) 20
2 4 --- A 58.3 13.5 0.75 17.7 14 14 46 (14.0) 43 (13..1) 25
3 0 --- A 64.0 12.8 0.75 16.8 14 14 44 (13.4) 41 (12.5) 25
3 6 --- A 77.0 14.1 0.50 18.1 12 12 57 (17.4) 54 (16.5) 30
4 2 --- A 112.0 17.9 1.20 23.6 10 10 85 (25.9) 81 (24.7) 40
4 8 --- A 109.0 19.0 1.20 26.1 10 10 70 (21.3) 67 (20.4) 40
4 9 --- A 117.0 21.8 1.20 28.4 10 10 70 (21.3) 67 (20.4) 40
6 0 --- A 135.0 21.4 1.20 28.0 810 91 (27.7) 56 (17.1) 40
6 1 --- A 134.0 25.0 1.20 32.5 810 94 (28.7) 58 (17.7) 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{If wire is applied at ambient greater than 30_C, consult table 310---16 of the NEC (NFPA 70). The ampacity of non ---metallic---sheathed cable (NM), trade
name ROMEX, shall be that of 60_C conditions, per the NEC (NFPA 70) Article 334---80. If other than uncoated (no---plated), 60 or 75_C insulation, copper
wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (NFPA 70).
}Length shown is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m ps
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2007 requirements of ASHRAE Standards 90.1
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- VOLTAGE, SERIES REQUIRED SUBCOOLING _F(_C)
1 8 --- A 10 (5.6)
2 4 --- A 10 (5.6)
3 0 --- A 10 (5.6)
3 6 --- A 10 (5.6)
4 2 --- A 9 (5.0)
4 8 --- A 8 (4.4)
4 9 --- A 9 (5.0)
6 0 --- A 9 (5.0)
6 1 --- A 10 (5.6)
CA16NA

6
A--WEIGHTED SOUND POWER LEVEL (dBA)
U n i t S i z e ---
Voltage, Series
Standard
Rating (dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA without tone adjustment)
125 250 500 1000 2000 4000 8000
1 8 --- A 76 52.5 59.0 65.5 70.5 64.5 59.0 54.5
2 4 --- A 76 57.5 64.0 69.0 71.0 69.0 64.5 60.0
3 0 --- A 76 55.0 63.5 68.0 69.5 67.0 63.5 58.5
3 6 --- A 76 50.5 59.5 64.5 70.5 62.0 59.5 54.5
4 2 --- A 78 52.5 62.0 66.0 73.5 68.0 62.0 55.5
4 8 --- A 78 57.5 61.5 66.0 70.5 65.5 59.5 53.5
4 9 --- A 78 51.5 62.0 67.5 73.5 69.0 64.5 62.0
6 0 --- A 78 55.0 62.5 67.5 70.5 65.0 61.0 53.5
6 1 --- A 78 56.5 63.0 65.5 69.0 67.0 61.5 56.0
NOTE: Tested in accordance with AHRI Standard 270 ---08 (not listed in AHRI).
A--WEIGHTED SOUND POWER LEVEL (dBA) WITH SOUND SHIELD
U n i t S i z e ---
Voltage, Series
Standard
Rating (dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA without tone adjustment)
125 250 500 1000 2000 4000 8000
1 8 --- A 74 55.5 59.0 65.0 68.5 63.5 58.0 52.0
2 4 --- A 75 58.0 64.0 69.0 70.5 68.5 64.5 59.5
3 0 --- A 75 55.5 63.0 68.0 69.0 67.0 63.0 58.5
3 6 --- A 74 51.5 58.5 62.0 65.0 61.0 58.0 52.0
4 2 --- A 76 53.0 62.0 65.5 72.0 65.0 61.0 54.0
4 8 --- A 76 58.5 61.5 66.0 69.0 64.0 58.5 51.0
4 9 --- A 76 53.0 61.5 67.5 72.0 68.0 61.5 59.0
6 0 --- A 75 56.5 62.5 66.5 68.0 63.0 59.5 51.5
6 1 --- A 75 57.0 63.0 65.5 67.0 65.5 59.0 52.5
NOTE: Tested in accordance with AHRI Standard 270 ---08 (not listed in AHRI).
ACCESSORY THERMOSTATS
PART NUMBER PROGRAM GAS ELECTRIC HEAT PUMP HYBRID
HEAT HEAT COOL
Performance
T P --- P R H 01 --- A 7 --- D a y √ √ √ √ 3 2
TP ---PHP01 7 --- D a y √ √ 3 2
T P --- PA C 0 1 7 --- D a y √ √ 1 1
T P --- N R H 0 1 --- A NP √ √ √ √ 3 2
T P --- N H P 0 1 NP √ √ 3 2
T P --- N A C 0 1 NP √ √ 1 1
Comfort
TC ---PHP01 5 --- 2 D a y √ √ 3 2
T C --- PA C 0 1 5 --- 2 D a y √ √ 1 1
T C --- N H P 0 1 NP √ √ 3 2
T C --- N A C 0 1 NP √ √ 1 1
TCSNHP01 NP √ √ 2 1
TCSNAC01 NP √ √ 1 1
Base
TB ---PHP01 5 --- 2 D a y √ √ √ 2 1
T B --- PA C 0 1 5 --- 2 D a y √1 1
T B --- N H P 0 1 NP √ √ √ 2 1
T B --- N A C 0 1 NP 1 1
THERMOSTAT ACCESSORIES
PART NUMBER BRIEF DESCRIPTION THERMOSTATS USED WITH
SYSTXCCRRS01 Indoor Remote Room Temperature Sensor A l l T P --- t h e r m o s t a t s
T P --- E X P 0 1 --- A ExP Computer Programming Accessory TP---P thermostats
TSTATXXCNV10‡ Thermostat Conversion Kit (4 to 5 wire) --- 10 pack All Carrier branded thermostats
T X --- L B P 0 1 LargeDecorativeBackplate T P --- P x x , T P --- N x x , T C --- P x x
T X --- M B P 0 1 Medium Decorative Backplate T C --- N x x , T B --- P x x
T X --- S B P 0 1 Small Decorative Backplate T B --- N x x
TSTATXXSEN01---B* Outdoor Air Temperature Sensor A l l T P --- t h e r m o s t a t s
CA16NA

7
ACCESSORIES
KIT NUMBER DESCRIPTION Unit Sizes --- Series
1 8 --- A 2 4 --- A 3 0 --- A 3 6 --- A 4 2 --- A 4 8 --- A 4 9 --- A 6 0 --- A 6 1 --- A
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X X X
KAATD0101TDR TIME DELAY RELAY X X X X X X X X X
KSALA0301410 LOW AMBIENT PSW X X X X X X X X X
KSALA0601AAA{MOTORMASTER 230V X X X X X X X X X
HC32GE234 MOTOR FAN BALL BEARING X
HC34GE240 MOTOR FAN BALL BEARING X X
HC32GE229 MOTOR FAN BALL BEARING X
HC38GE228 MOTOR FAN BALL BEARING X
HC40GE228 MOTOR FAN BALL BEARING X X X X
KSAHS1701AAA HARD START (CAP / RELAY) X X X X X X X X X
KSACY0101AAA CYCLE PROTECTOR X X X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X X X
KAACS0201PTC START ASSIST PTC X X X X X X X X X
KAALS0201LLS LIQUID LINE SOLENOID X X X X X X X X X
KAAWS0101AAA WINTER START X X X X X X X X X
KAACH1701AAA CRANKCASE HTR X X X X
KAACH1601AAA CRANKCASE HTR X S S S S
KSATX0201PUR TXV PURON HSO X X X
KSATX0301PUR TXV PURON HSO X
KSATX0401PUR TXV PURON HSO X X
KSATX0501PUR TXV PURON HSO X X X
KSASH0601COP SOUND HOOD X X X X X
KSASH2101COP SOUND HOOD X X X X
KAALP0401PUR LOW PRESSURE SWITCH X X X X X X X X X
KAAHI0501PUR HIGH PRESSURE SWITCH X X X X X X X X X
{Required accessories include ball bearing fan motor, compressor start assist (CAP / Relay), crankcase heater, evaporator freeze stat, hard shut---off TXV.
X = Accessory / S --- Standard
CA16NA

8
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW---AMBI-
ENT COOLING APPLICATIONS
(Below 55°F/12.8_C)
REQUIRED FOR LONG
LINE
APPLICATIONS*
(Over 80 ft./24.38 m)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within2miles/3.22km)
Ball Bearing Fan Motor Yes{No No
Compressor Start Assist Capacitor and Relay Yes Yes No
Crankcase Heater Yes Yes No
Evaporator Freeze Thermostat Yes No No
H a r d S h u t --- O f f T X V Yes Yes Yes
Liquid Line Solenoid Valve No No No
Motor Master®Control or
L o w --- a m b i e n t P r e s s u r e S w i t c h Yes No No
Support Feet Recommended No Recommended
Winter Start Control Yes No No
* For tubing line sets between 80 and 200 ft. (24.38 and 60.96 m) and/or 20 ft. (6.09 m) vertical differential, refer to Residential Split---System Longline
Application Guideline.
{Required for Low ---Ambient Controller (full modulation feature) MotorMasterrControl.
Accessory Description and Usage (Listed Alphabetically)
1. Ball--Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.
Usage Guideline:
Required on all units when MotorMasterris used.
2. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.
Usage Guideline:
Required for reciprocating compressors in the
following applications:
Long line
Low ambient cooling
Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil
Required for single--phase scroll compressors in the
following applications:
Long line
Low ambient cooling
Suggested for all compressors in areas with a history of
low voltage problems.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.
Usage Guideline:
Suggested in installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
5. Cycle Protector
The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5--minute delay
after power to the compressor has been interrupted for any
reason, including power outage, protector control trip, thermostat
jiggling, or normal cycling.
6. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
Required when low ambient kit has been added.
7. Low--Ambient Pressure Switch Kit
A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in
order to maintain head pressure within normal operating limits
(approximately 100 psig to 225 psig). The control will maintain
working head pressure at low--ambient temperatures down to 0_F
(--18_C) when properly installed.
Usage Guideline:
A Low--Ambient Pressure Switch or MotorMasterr
Low--Ambient Controller must be used when cooling operation is
used at outdoor temperatures below 55_F (12.8_C).
8. MotorMasterrLow--Ambient Controller
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C),
it maintains condensing temperature at 100_F±10_F (37.8_C±
5.5_C).
Usage Guideline:
A MotorMasterrLow Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
9. Outdoor Air Temperature Sensor
Designed for use with Carrier Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also
is required to enable special thermostat features such as auxiliary
heat lock out.
Usage Guideline:
Suggested for all Carrier thermostats listed in this
publication.
CA16NA

9
Accessory Description and Usage (Listed Alphabetically) (Continued)
10. Sound Hood
Wraparound sound reducing cover for the compressor. Reduces
the sound level by about 2 dBA.
Usage Guideline:
Suggested when unit is installed closer than 15 ft (4.57 m) to
quiet areas, bedrooms, etc.
Suggested when unit is installed between two houses less
than 10 ft (3.05 m) apart.
11. Support Feet
Four stick--on plastic feet that raise the unit 4 in. (101.6 mm)
above the mounting pad. This allows sand, dirt, and other debris
to be flushed from the unit base, minimizing corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
12. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.
NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Required to achieve AHRI ratings in certain equipment
combinations. Refer to combination ratings.
Hard shut off TXV or LLS required in air conditioner
long line applications.
Required for use on all zoning systems.
13. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
NOTE: Most indoor unit controls include this feature. For those
that do not, use the guideline below.
Usage Guideline:
For improved efficiency ratings for certain
combinations of indoor and outdoor units. Refer to
AHRI Unitary Directory.
14. Winter Start Control
This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.
CA16NA

10
DIMENSIONS -- ENGLISH (18 -- 30)
CA16NA

11
DIMENSIONS -- ENGLISH (36 -- 61)
CA16NA

12
DIMENSIONS -- SI (18 -- 30)
CA16NA

13
DIMENSIONS -- SI (36 -- 61)
CA16NA

14
CLEARANCES
Clearances (various examples)
Wall
6”
(152.4)
24”
(609.6)
Service
Wall
Wall
Wall
12”
(304.8)
12”
(304.8)
18”
(457.2)
24”
(609.6)
Service
6”
(152.4)
12”
(304.8)
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
Service
Note: Numbers in ( ) = mm
18”
(457.2)
18”
(457.2)
12”
(304.8)
IMPORTANT: When installing multiple units in an alcove, roof well, or partially enclosed area, ensure there is adequate ventilation to prevent re--circulation of discharge air.
CA16NA

15
COMBINATION RATINGS
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4583738 CA16NA018****A †CNPV*1917A**+TDR 19,300 12.0 14.5
4583740 CA16NA018****A CAP**1814A** 58CV(A,X)070---12 18,600 13.2 15.5
4583741 CA16NA018****A CAP**1814A** 58PH*045---08 18,800 13.2 16.0
4767711 CA16NA018****A CAP**1814A** 59*P5A040E14**10 18,000 12.7 15.5
4583739 CA16NA018****A CAP**1814A**+TDR 18,700 12.0 14.0
4583743 CA16NA018****A CAP**2414A** 58CV(A,X)070---12 18,900 13.5 16.0
4583744 CA16NA018****A CAP**2414A** 58PH*045---08 19,300 13.7 16.0
4767712 CA16NA018****A CAP**2414A** 59*P5A040E14**10 18,000 13.0 16.0
4583742 CA16NA018****A CAP**2414A**+TDR 19,100 12.2 14.5
4661538 CA16NA018****A CAP**2417A** 58CV(A,X)070---12 18,000 13.0 16.0
4583748 CA16NA018****A CAP**2417A** 58CV(A,X)090---16 19,000 13.7 16.0
4583750 CA16NA018****A CAP**2417A** 58ME(B,C)060---12 19,400 14.0 16.0
4583749 CA16NA018****A CAP**2417A** 58MEB040---12 19,600 14.0 16.0
4583746 CA16NA018****A CAP**2417A** 58MV(B,C)060---14 18,900 13.7 16.0
4661539 CA16NA018****A CAP**2417A** 58PH*045---08 18,000 13.0 16.0
4583747 CA16NA018****A CAP**2417A** 58UVB060---14 18,900 13.7 16.0
4583752 CA16NA018****A CAP**2417A** 58VLR105---12 19,400 13.7 16.0
4583751 CA16NA018****A CAP**2417A** 58VMR105---12 19,100 13.7 16.0
4767713 CA16NA018****A CAP**2417A** 59*N*A060V17**14 18,000 13.2 16.5
4767714 CA16NA018****A CAP**2417A** 59*N*A080V17**14 18,000 13.2 16.5
4767715 CA16NA018****A CAP**2417A** 59*P5A040E14**10 18,000 13.0 16.0
4583754 CA16NA018****A CAP**2417A** OVLAAB036098 19,300 13.7 16.0
4583753 CA16NA018****A CAP**2417A** OVMAAB036098 19,500 13.7 16.0
4583745 CA16NA018****A CAP**2417A**+TDR 19,100 12.2 14.5
4597319 CA16NA018****A CAP**3014A** 58CV(A,X)070---12 18,000 13.0 16.0
4597320 CA16NA018****A CAP**3014A** 58PH*045---08 18,000 13.0 16.0
4767730 CA16NA018****A CAP**3014A** 59*P5A040E14**10 18,000 13.0 16.0
4597318 CA16NA018****A CAP**3014A**+TDR 18,000 12.2 14.5
4597323 CA16NA018****A CAP**3017A** 58CV(A,X)090---16 18,000 13.0 16.0
4597324 CA16NA018****A CAP**3017A** 58MEB040---12 18,000 13.0 16.0
4597325 CA16NA018****A CAP**3017A** 58MEC060---12 18,000 13.0 16.0
4597322 CA16NA018****A CAP**3017A** 58MV(B,C)060---14 18,000 13.0 16.0
4597327 CA16NA018****A CAP**3017A** 58VLR105---12 18,000 13.0 16.0
4597326 CA16NA018****A CAP**3017A** 58VMR105---12 18,000 13.0 16.0
4767731 CA16NA018****A CAP**3017A** 59*N*A060V17**14 18,000 13.2 16.5
4767732 CA16NA018****A CAP**3017A** 59*N*A080V17**14 18,000 13.2 16.5
4767733 CA16NA018****A CAP**3017A** 59*P5A040E14**10 18,000 13.0 16.0
4597321 CA16NA018****A CAP**3017A**+TDR 18,000 12.2 14.5
4597329 CA16NA018****A CAP**3614A** 58CV(A,X)070---12 18,000 13.0 16.0
4597330 CA16NA018****A CAP**3614A** 58PH*045---08 18,000 13.0 16.0
4597328 CA16NA018****A CAP**3614A**+TDR 18,000 12.2 14.5
4597333 CA16NA018****A CAP**3617A** 58CV(A,X)090---16 18,000 13.0 16.0
4597334 CA16NA018****A CAP**3617A** 58MEB040---12 18,000 13.0 16.0
4597335 CA16NA018****A CAP**3617A** 58MEC060---12 18,000 13.0 16.0
4597332 CA16NA018****A CAP**3617A** 58MV(B,C)060---14 18,000 13.0 16.0
4597337 CA16NA018****A CAP**3617A** 58VLR105---12 18,000 13.0 16.0
4597336 CA16NA018****A CAP**3617A** 58VMR105---12 18,000 13.0 16.0
4597331 CA16NA018****A CAP**3617A**+TDR 18,000 12.2 14.5
4597343 CA16NA018****A CAP**3619A** 58CV(A,X)090---16 18,000 13.0 16.0
4597348 CA16NA018****A CAP**3619A** 58HDV040--- ---12 18,000 13.0 16.0
4597349 CA16NA018****A CAP**3619A** 58HDV060--- ---12 18,000 13.0 16.0
4597344 CA16NA018****A CAP**3619A** 58MEB040---12 18,000 13.0 16.0
4597345 CA16NA018****A CAP**3619A** 58MEC060---12 18,000 13.0 16.0
4597342 CA16NA018****A CAP**3619A** 58MV(B,C)060---14 18,000 13.0 16.0
4597347 CA16NA018****A CAP**3619A** 58VLR105---12 18,000 13.0 16.0
4597346 CA16NA018****A CAP**3619A** 58VMR105---12 18,000 13.0 16.0
4597341 CA16NA018****A CAP**3619A**+TDR 18,000 12.2 14.5
4597339 CA16NA018****A CAP**3621A** 58MV(B,C)080---14 18,000 13.0 16.0
4597340 CA16NA018****A CAP**3621A** 58UVB080---14 18,000 13.0 16.0
4597338 CA16NA018****A CAP**3621A**+TDR 18,000 12.2 14.5
4583784 CA16NA018****A CNPH*2417A** 58CV(A,X)070---12 18,900 13.5 16.0
4583785 CA16NA018****A CNPH*2417A** 58CV(A,X)090---16 19,000 13.7 16.0
4583789 CA16NA018****A CNPH*2417A** 58HDV040--- ---12 19,600 13.2 15.5
4583790 CA16NA018****A CNPH*2417A** 58HDV060--- ---12 19,600 13.2 16.0
4583788 CA16NA018****A CNPH*2417A** 58ME(B,C)060---12 19,200 13.7 16.0
4583787 CA16NA018****A CNPH*2417A** 58MEB040---12 19,500 13.7 16.0
4583782 CA16NA018****A CNPH*2417A** 58MV(B,C)060---14 19,000 13.5 16.0
4583783 CA16NA018****A CNPH*2417A** 58MV(B,C)080---14 18,900 13.7 16.0
4583781 CA16NA018****A CNPH*2417A** 58MVB040---14 19,000 13.5 16.0
4583786 CA16NA018****A CNPH*2417A** 58PH*045---08 19,200 13.5 16.0
4583792 CA16NA018****A CNPH*2417A** 58VLR105---12 19,400 13.7 16.0
4583791 CA16NA018****A CNPH*2417A** 58VMR105---12 19,100 13.7 16.0
4767724 CA16NA018****A CNPH*2417A** 59*N*A060V17**14 18,000 13.2 16.5
See notes on page 60
CA16NA

16
COMBINATION RATINGS
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4767725 CA16NA018****A CNPH*2417A** 59*N*A080V17**14 18,000 13.2 16.5
4767726 CA16NA018****A CNPH*2417A** 59*P5A040E14**10 18,000 13.0 16.0
4583794 CA16NA018****A CNPH*2417A** OVLAAB036098 19,300 13.5 16.0
4583793 CA16NA018****A CNPH*2417A** OVMAAB036098 19,500 13.5 16.0
4583780 CA16NA018****A CNPH*2417A**+TDR 19,100 12.2 14.5
4767738 CA16NA018****A CNPH*3017A** 59*N*A060V17**14 18,000 13.2 16.5
4767739 CA16NA018****A CNPH*3017A** 59*N*A080V17**14 18,000 13.2 16.5
4767740 CA16NA018****A CNPH*3017A** 59*P5A040E14**10 18,000 13.0 16.0
4583756 CA16NA018****A CNPV*1814A** 58CV(A,X)070---12 18,800 13.5 16.0
4583757 CA16NA018****A CNPV*1814A** 58PH*045---08 19,000 13.5 16.0
4767716 CA16NA018****A CNPV*1814A** 59*P5A040E14**10 18,000 12.7 15.5
4583755 CA16NA018****A CNPV*1814A**+TDR 19,000 12.2 14.5
4661540 CA16NA018****A CNPV*1917A** 58CV(A,X)070---12 18,000 13.0 16.0
4583760 CA16NA018****A CNPV*1917A** 58CV(A,X)090---16 19,100 13.7 16.0
4597350 CA16NA018****A CNPV*1917A** 58HDV040--- ---12 18,600 13.0 16.0
4597351 CA16NA018****A CNPV*1917A** 58HDV060--- ---12 18,000 13.0 16.0
4583762 CA16NA018****A CNPV*1917A** 58ME(B,C)060---12 19,600 14.0 16.0
4583761 CA16NA018****A CNPV*1917A** 58MEB040---12 19,800 14.0 16.0
4583758 CA16NA018****A CNPV*1917A** 58MV(B,C)060---14 19,100 13.7 16.0
4661541 CA16NA018****A CNPV*1917A** 58PH*045---08 18,000 13.0 16.0
4583759 CA16NA018****A CNPV*1917A** 58UVB060---14 19,100 13.7 16.0
4583764 CA16NA018****A CNPV*1917A** 58VLR105---12 19,600 14.0 16.0
4583763 CA16NA018****A CNPV*1917A** 58VMR105---12 19,200 13.7 16.0
4767717 CA16NA018****A CNPV*1917A** 59*N*A060V17**14 18,000 13.2 16.5
4767718 CA16NA018****A CNPV*1917A** 59*N*A080V17**14 18,000 13.2 16.5
4767719 CA16NA018****A CNPV*1917A** 59*P5A040E14**10 18,000 13.0 16.0
4583766 CA16NA018****A CNPV*1917A** OVLAAB036098 19,500 13.7 16.0
4583765 CA16NA018****A CNPV*1917A** OVMAAB036098 19,600 13.7 16.0
4583768 CA16NA018****A CNPV*2414A** 58CV(A,X)070---12 18,900 13.5 16.0
4583769 CA16NA018****A CNPV*2414A** 58PH*045---08 19,200 13.5 16.0
4767720 CA16NA018****A CNPV*2414A** 59*P5A040E14**10 18,000 13.0 16.0
4583767 CA16NA018****A CNPV*2414A**+TDR 19,100 12.2 14.5
4661542 CA16NA018****A CNPV*2417A** 58CV(A,X)070---12 18,000 13.0 16.0
4583773 CA16NA018****A CNPV*2417A** 58CV(A,X)090---16 19,000 13.7 16.0
4597352 CA16NA018****A CNPV*2417A** 58HDV040--- ---12 18,400 13.0 16.0
4597353 CA16NA018****A CNPV*2417A** 58HDV060--- ---12 18,000 13.0 16.0
4583775 CA16NA018****A CNPV*2417A** 58ME(B,C)060---12 19,200 13.7 16.0
4583774 CA16NA018****A CNPV*2417A** 58MEB040---12 19,500 13.7 16.0
4583771 CA16NA018****A CNPV*2417A** 58MV(B,C)060---14 19,000 13.5 16.0
4661543 CA16NA018****A CNPV*2417A** 58PH*045---08 18,000 13.0 16.0
4583772 CA16NA018****A CNPV*2417A** 58UVB060---14 19,000 13.5 16.0
4583777 CA16NA018****A CNPV*2417A** 58VLR105---12 19,400 13.7 16.0
4583776 CA16NA018****A CNPV*2417A** 58VMR105---12 19,100 13.7 16.0
4767721 CA16NA018****A CNPV*2417A** 59*N*A060V17**14 18,000 13.2 16.5
4767722 CA16NA018****A CNPV*2417A** 59*N*A080V17**14 18,000 13.2 16.5
4767723 CA16NA018****A CNPV*2417A** 59*P5A040E14**10 18,000 13.0 16.0
4583779 CA16NA018****A CNPV*2417A** OVLAAB036098 19,300 13.5 16.0
4583778 CA16NA018****A CNPV*2417A** OVMAAB036098 19,500 13.5 16.0
4583770 CA16NA018****A CNPV*2417A**+TDR 19,100 12.2 14.5
4767734 CA16NA018****A CNPV*3014A** 59*P5A040E14**10 18,000 13.0 16.0
4767735 CA16NA018****A CNPV*3017A** 59*N*A060V17**14 18,000 13.2 16.5
4767736 CA16NA018****A CNPV*3017A** 59*N*A080V17**14 18,000 13.2 16.5
4767737 CA16NA018****A CNPV*3017A** 59*P5A040E14**10 18,000 13.0 16.0
4583799 CA16NA018****A CSPH*2412A** 58CV(A,X)070---12 19,100 13.7 16.0
4583800 CA16NA018****A CSPH*2412A** 58CV(A,X)090---16 19,100 13.7 16.0
4583804 CA16NA018****A CSPH*2412A** 58HDV040--- ---12 19,700 13.2 16.0
4583805 CA16NA018****A CSPH*2412A** 58HDV060--- ---12 19,700 13.5 16.0
4583803 CA16NA018****A CSPH*2412A** 58ME(B,C)060---12 19,200 13.7 16.0
4583802 CA16NA018****A CSPH*2412A** 58MEB040---12 19,500 13.7 16.0
4583797 CA16NA018****A CSPH*2412A** 58MV(B,C)060---14 19,100 13.7 16.0
4583798 CA16NA018****A CSPH*2412A** 58MV(B,C)080---14 19,000 13.7 16.0
4583796 CA16NA018****A CSPH*2412A** 58MVB040---14 19,100 13.7 16.0
4583801 CA16NA018****A CSPH*2412A** 58PH*045---08 19,300 13.7 16.0
4583807 CA16NA018****A CSPH*2412A** 58VLR105---12 19,600 13.7 16.0
4583806 CA16NA018****A CSPH*2412A** 58VMR105---12 19,200 13.7 16.0
4767727 CA16NA018****A CSPH*2412A** 59*N*A060V17**14 18,000 13.2 16.5
4767728 CA16NA018****A CSPH*2412A** 59*N*A080V17**14 18,000 13.2 16.5
4767729 CA16NA018****A CSPH*2412A** 59*P5A040E14**10 18,000 13.0 16.0
4583809 CA16NA018****A CSPH*2412A** OVLAAB036098 19,500 13.7 16.0
4583808 CA16NA018****A CSPH*2412A** OVMAAB036098 19,600 13.7 16.0
4583795 CA16NA018****A CSPH*2412A**+TDR 19,300 12.2 14.5
4767741 CA16NA018****A CSPH*3012A** 59*N*A060V17**14 18,000 13.2 16.5
4767742 CA16NA018****A CSPH*3012A** 59*N*A080V17**14 18,000 13.2 16.5
See notes on page 60
CA16NA

17
COMBINATION RATINGS
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4767743 CA16NA018****A CSPH*3012A** 59*P5A040E14**10 18,000 13.0 16.0
4583822 CA16NA018****A FB4CNF018 19,300 13.2 14.5
4583821 CA16NA018****A FB4CNF018+TXV 19,300 13.2 15.5
4583824 CA16NA018****A FB4CNF024 19,300 13.2 14.5
4583823 CA16NA018****A FB4CNF024+TXV 19,300 13.2 15.5
4583826 CA16NA018****A FB4CNF030 19,400 12.5 14.5
4583825 CA16NA018****A FB4CNF030+TXV 19,400 12.5 15.0
4583813 CA16NA018****A FE4ANF002+UI 19,300 14.0 16.0
4583814 CA16NA018****A FF1ENP018 18,800 12.0 14.0
4583815 CA16NA018****A FF1ENP019 19,100 13.2 15.5
4583816 CA16NA018****A FF1ENP024 19,000 12.2 14.5
4583817 CA16NA018****A FF1ENP025 19,400 13.7 16.0
4583818 CA16NA018****A FF1ENP031 19,400 13.5 16.0
4583819 CA16NA018****A FF1ENP037 19,400 13.5 16.0
4583820 CA16NA018****A FV4CNF002 19,300 14.0 16.0
4583812 CA16NA018****A FX4DN(B,F)031 19,500 13.2 16.0
4583810 CA16NA018****A FX4DNF019 19,500 13.7 16.0
4583811 CA16NA018****A FX4DNF025 19,500 13.7 16.0
4583828 CA16NA018****A FY5BNF018 19,300 12.5 14.0
4583827 CA16NA018****A FY5BNF018+TXV 19,300 12.5 14.5
4583830 CA16NA018****A FY5BNF024 19,400 12.5 14.0
4583829 CA16NA018****A FY5BNF024+TXV 19,400 12.5 14.5
4583831 CA16NA024****A †CNPV*3117A**+TDR 24,800 12.0 14.5
4583833 CA16NA024****A CAP**2414A** 58CV(A,X)070---12 24,000 13.2 15.5
4583834 CA16NA024****A CAP**2414A** 58PH*045---08 24,200 13.2 15.5
4767744 CA16NA024****A CAP**2414A** 59*P5A040E14**10 24,000 12.0 14.5
4583832 CA16NA024****A CAP**2414A**+TDR 24,200 12.0 14.0
4663948 CA16NA024****A CAP**2417A** 58CV(A,X)070---12 22,800 12.5 15.5
4583838 CA16NA024****A CAP**2417A** 58CV(A,X)090---16 24,000 13.5 16.0
4583840 CA16NA024****A CAP**2417A** 58ME(B,C)060---12 24,600 13.5 16.0
4583841 CA16NA024****A CAP**2417A** 58ME(B,C)080---12 24,400 13.5 16.0
4583839 CA16NA024****A CAP**2417A** 58MEB040---12 24,400 13.5 16.0
4583836 CA16NA024****A CAP**2417A** 58MV(B,C)060---14 24,200 13.5 16.0
4663949 CA16NA024****A CAP**2417A** 58PH*045---08 23,000 12.5 15.5
4583837 CA16NA024****A CAP**2417A** 58UVB060---14 24,200 13.5 16.0
4583843 CA16NA024****A CAP**2417A** 58VLR105---12 24,200 13.5 16.0
4583842 CA16NA024****A CAP**2417A** 58VMR105---12 24,000 13.2 16.0
4767745 CA16NA024****A CAP**2417A** 59*N*A060V17**14 24,000 12.7 15.5
4767746 CA16NA024****A CAP**2417A** 59*N*A080V17**14 23,800 13.0 16.0
4767747 CA16NA024****A CAP**2417A** 59*P5A040E14**10 24,000 12.0 14.5
4767748 CA16NA024****A CAP**2417A** 59*P5A060E17**14 24,000 13.0 16.0
4583845 CA16NA024****A CAP**2417A** OVLAAB036098 24,200 13.2 15.5
4583844 CA16NA024****A CAP**2417A** OVMAAB036098 24,200 13.2 15.5
4583846 CA16NA024****A CAP**2417A** OVMAAB042112 24,200 13.5 15.5
4583835 CA16NA024****A CAP**2417A**+TDR 24,200 12.0 14.0
4583848 CA16NA024****A CAP**3014A** 58CV(A,X)070---12 24,000 13.2 16.0
4583849 CA16NA024****A CAP**3014A** 58PH*045---08 24,400 13.2 15.5
4767749 CA16NA024****A CAP**3014A** 59*P5A040E14**10 24,000 12.0 14.5
4583847 CA16NA024****A CAP**3014A**+TDR 24,400 12.0 14.0
4663950 CA16NA024****A CAP**3017A** 58CV(A,X)070---12 23,000 13.0 16.0
4583853 CA16NA024****A CAP**3017A** 58CV(A,X)090---16 24,200 13.5 16.0
4583855 CA16NA024****A CAP**3017A** 58ME(B,C)060---12 24,800 13.7 16.0
4583856 CA16NA024****A CAP**3017A** 58ME(B,C)080---12 24,600 13.7 16.0
4583854 CA16NA024****A CAP**3017A** 58MEB040---12 24,800 13.7 16.0
4583851 CA16NA024****A CAP**3017A** 58MV(B,C)060---14 24,400 13.7 16.0
4663951 CA16NA024****A CAP**3017A** 58PH*045---08 23,200 13.0 16.0
4583852 CA16NA024****A CAP**3017A** 58UVB060---14 24,400 13.7 16.0
4583858 CA16NA024****A CAP**3017A** 58VLR105---12 24,400 13.5 16.0
4583857 CA16NA024****A CAP**3017A** 58VMR105---12 24,000 13.5 16.0
4767750 CA16NA024****A CAP**3017A** 59*N*A060V17**14 24,000 13.0 16.0
4767751 CA16NA024****A CAP**3017A** 59*N*A080V17**14 24,000 13.0 16.0
4767752 CA16NA024****A CAP**3017A** 59*P5A040E14**10 24,000 12.0 14.5
4767753 CA16NA024****A CAP**3017A** 59*P5A060E17**14 24,000 13.0 16.0
4583860 CA16NA024****A CAP**3017A** OVLAAB036098 24,400 13.5 16.0
4583859 CA16NA024****A CAP**3017A** OVMAAB036098 24,400 13.2 15.5
4583861 CA16NA024****A CAP**3017A** OVMAAB042112 24,200 13.5 16.0
4583850 CA16NA024****A CAP**3017A**+TDR 24,400 12.0 14.0
4597355 CA16NA024****A CAP**3614A** 58CV(A,X)070---12 24,000 13.0 16.0
4597356 CA16NA024****A CAP**3614A** 58PH*045---08 24,000 13.0 16.0
4767798 CA16NA024****A CAP**3614A** 59*P5A040E14**10 24,000 12.0 14.5
4597354 CA16NA024****A CAP**3614A**+TDR 24,000 11.5 14.0
4597360 CA16NA024****A CAP**3617A** 58CV(A,X)070---12 24,000 13.0 16.0
See notes on page 60
CA16NA

18
COMBINATION RATINGS
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4597361 CA16NA024****A CAP**3617A** 58CV(A,X)090---16 24,000 13.0 16.0
4597363 CA16NA024****A CAP**3617A** 58MEB040---12 24,000 13.0 16.0
4597364 CA16NA024****A CAP**3617A** 58MEC060---12 24,000 13.0 16.0
4597365 CA16NA024****A CAP**3617A** 58MEC080---12 24,000 13.0 16.0
4597358 CA16NA024****A CAP**3617A** 58MV(B,C)060---14 24,000 13.0 16.0
4597362 CA16NA024****A CAP**3617A** 58PH*045---08 24,000 13.0 16.0
4597359 CA16NA024****A CAP**3617A** 58UVB060---14 24,000 13.0 16.0
4597367 CA16NA024****A CAP**3617A** 58VLR105---12 24,000 13.0 16.0
4597366 CA16NA024****A CAP**3617A** 58VMR105---12 24,000 13.0 16.0
4767799 CA16NA024****A CAP**3617A** 59*N*A060V17**14 24,000 13.0 16.0
4767800 CA16NA024****A CAP**3617A** 59*N*A080V17**14 24,000 13.0 16.0
4767801 CA16NA024****A CAP**3617A** 59*P5A040E14**10 24,000 12.5 15.0
4767802 CA16NA024****A CAP**3617A** 59*P5A060E17**14 24,000 13.0 16.0
4597357 CA16NA024****A CAP**3617A**+TDR 24,000 11.5 14.0
4597385 CA16NA024****A CAP**3619A** 58HDV040--- ---12 24,000 13.0 16.0
4597386 CA16NA024****A CAP**3619A** 58HDV060--- ---12 24,000 13.0 16.0
4767807 CA16NA024****A CAP**3619A** 59*N*A060V17**14 24,000 13.0 16.0
4767808 CA16NA024****A CAP**3619A** 59*N*A080V17**14 24,000 13.0 16.0
4767809 CA16NA024****A CAP**3619A** 59*N*A100V21**20 24,000 13.0 16.0
4767810 CA16NA024****A CAP**3619A** 59*P5A060E17**14 24,000 13.0 16.0
4597384 CA16NA024****A CAP**3619A**+TDR 24,000 11.5 14.0
4597377 CA16NA024****A CAP**3621A** 58CV(A,X)090---16 24,000 13.0 16.0
4597378 CA16NA024****A CAP**3621A** 58CV(A,X)110---20 24,000 13.0 16.0
4597379 CA16NA024****A CAP**3621A** 58MEB040---12 24,000 13.0 16.0
4597380 CA16NA024****A CAP**3621A** 58MEC060---12 24,000 13.0 16.0
4597381 CA16NA024****A CAP**3621A** 58MEC080---12 24,000 13.0 16.0
4597369 CA16NA024****A CAP**3621A** 58MV(B,C)060---14 24,000 13.0 16.0
4597370 CA16NA024****A CAP**3621A** 58MV(B,C)080---14 24,000 13.0 16.0
4597371 CA16NA024****A CAP**3621A** 58MV(B,C)080---20 24,000 13.0 16.0
4597372 CA16NA024****A CAP**3621A** 58MV(B,C)100---20 24,000 13.0 16.0
4597373 CA16NA024****A CAP**3621A** 58UVB060---14 24,000 13.0 16.0
4597374 CA16NA024****A CAP**3621A** 58UVB080---14 24,000 13.0 16.0
4597375 CA16NA024****A CAP**3621A** 58UVB080---20 24,000 13.0 16.0
4597376 CA16NA024****A CAP**3621A** 58UVB100---20 24,000 13.0 16.0
4597383 CA16NA024****A CAP**3621A** 58VLR105---12 24,000 13.0 16.0
4597382 CA16NA024****A CAP**3621A** 58VMR105---12 24,000 13.0 16.0
4767803 CA16NA024****A CAP**3621A** 59*N*A060V17**14 24,000 13.0 16.0
4767804 CA16NA024****A CAP**3621A** 59*N*A080V17**14 24,000 13.0 16.0
4767805 CA16NA024****A CAP**3621A** 59*N*A100V21**20 24,000 13.0 16.0
4767806 CA16NA024****A CAP**3621A** 59*P5A060E17**14 24,000 13.0 16.0
4597368 CA16NA024****A CAP**3621A**+TDR 24,000 11.5 14.0
4597394 CA16NA024****A CAP**4221A** 58CV(A,X)110---20 24,000 13.0 16.0
4597388 CA16NA024****A CAP**4221A** 58MV(B,C)080---14 24,000 13.0 16.0
4597389 CA16NA024****A CAP**4221A** 58MV(B,C)080---20 24,000 13.0 16.0
4597390 CA16NA024****A CAP**4221A** 58MV(B,C)100---20 24,000 13.0 16.0
4597391 CA16NA024****A CAP**4221A** 58UVB080---14 24,000 13.0 16.0
4597392 CA16NA024****A CAP**4221A** 58UVB080---20 24,000 13.0 16.0
4597393 CA16NA024****A CAP**4221A** 58UVB100---20 24,000 13.0 16.0
4597387 CA16NA024****A CAP**4221A**+TDR 24,000 12.0 14.5
4597399 CA16NA024****A CAP**4224A** 58CV(A,X)135---22 24,000 13.0 16.0
4597400 CA16NA024****A CAP**4224A** 58CV(A,X)155---22 24,000 13.0 16.0
4597397 CA16NA024****A CAP**4224A** 58MV(B,C)120---20 24,000 13.0 16.0
4597396 CA16NA024****A CAP**4224A** 58MVB040---14 24,000 13.0 16.0
4597398 CA16NA024****A CAP**4224A** 58UVB120---20 24,000 13.0 16.0
4597395 CA16NA024****A CAP**4224A**+TDR 24,000 12.0 14.5
4583910 CA16NA024****A CNPH*2417A** 58CV(A,X)070---12 24,000 13.2 15.5
4583911 CA16NA024****A CNPH*2417A** 58CV(A,X)090---16 24,000 13.2 16.0
4583912 CA16NA024****A CNPH*2417A** 58CV(A,X)110---20 24,000 13.2 15.5
4583913 CA16NA024****A CNPH*2417A** 58CV(A,X)135---22 24,000 13.2 15.5
4583914 CA16NA024****A CNPH*2417A** 58CV(A,X)155---22 24,000 13.2 15.5
4583919 CA16NA024****A CNPH*2417A** 58HDV040--- ---12 24,200 13.0 15.5
4583920 CA16NA024****A CNPH*2417A** 58HDV060--- ---12 24,200 13.0 15.5
4583921 CA16NA024****A CNPH*2417A** 58HDV080--- ---20 24,600 13.2 15.5
4583922 CA16NA024****A CNPH*2417A** 58HDV100--- ---20 24,400 13.2 15.5
4583917 CA16NA024****A CNPH*2417A** 58ME(B,C)060---12 24,400 13.2 16.0
4583918 CA16NA024****A CNPH*2417A** 58ME(B,C)080---12 24,200 13.2 16.0
4583916 CA16NA024****A CNPH*2417A** 58MEB040---12 24,400 13.2 16.0
4583905 CA16NA024****A CNPH*2417A** 58MV(B,C)060---14 24,200 13.2 15.5
4583906 CA16NA024****A CNPH*2417A** 58MV(B,C)080---14 24,000 13.2 15.5
4583907 CA16NA024****A CNPH*2417A** 58MV(B,C)080---20 23,800 13.2 15.5
4583908 CA16NA024****A CNPH*2417A** 58MV(B,C)100---20 24,000 13.2 15.5
4583909 CA16NA024****A CNPH*2417A** 58MV(B,C)120---20 24,200 13.2 16.0
4583904 CA16NA024****A CNPH*2417A** 58MVB040---14 24,000 13.2 15.5
See notes on page 60
CA16NA

19
COMBINATION RATINGS
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4583915 CA16NA024****A CNPH*2417A** 58PH*045---08 24,000 13.2 15.5
4583924 CA16NA024****A CNPH*2417A** 58VLR105---12 24,200 13.2 16.0
4583923 CA16NA024****A CNPH*2417A** 58VMR105---12 24,000 13.2 15.5
4767768 CA16NA024****A CNPH*2417A** 59*N*A060V17**14 24,000 12.7 15.5
4767769 CA16NA024****A CNPH*2417A** 59*N*A080V17**14 23,800 12.7 15.5
4767770 CA16NA024****A CNPH*2417A** 59*N*A100V21**20 24,000 13.0 16.0
4767771 CA16NA024****A CNPH*2417A** 59*N*A120V24**22 24,000 13.0 16.0
4767772 CA16NA024****A CNPH*2417A** 59*P5A040E14**10 24,000 12.0 14.5
4767773 CA16NA024****A CNPH*2417A** 59*P5A060E17**14 24,000 12.7 15.5
4583926 CA16NA024****A CNPH*2417A** OVLAAB036098 24,200 13.2 15.5
4583925 CA16NA024****A CNPH*2417A** OVMAAB036098 24,200 13.0 15.5
4583927 CA16NA024****A CNPH*2417A** OVMAAB042112 24,200 13.2 16.0
4583903 CA16NA024****A CNPH*2417A**+TDR 24,200 12.0 14.0
4583935 CA16NA024****A CNPH*3017A** 58CV(A,X)070---12 24,200 13.5 16.0
4583936 CA16NA024****A CNPH*3017A** 58CV(A,X)090---16 24,200 13.5 16.0
4583937 CA16NA024****A CNPH*3017A** 58CV(A,X)110---20 24,200 13.5 16.0
4583938 CA16NA024****A CNPH*3017A** 58CV(A,X)135---22 24,200 13.5 16.0
4583939 CA16NA024****A CNPH*3017A** 58CV(A,X)155---22 24,200 13.5 16.0
4583944 CA16NA024****A CNPH*3017A** 58HDV040--- ---12 24,400 13.2 15.5
4583945 CA16NA024****A CNPH*3017A** 58HDV060--- ---12 24,800 13.2 15.5
4583946 CA16NA024****A CNPH*3017A** 58HDV080--- ---20 25,200 13.5 16.0
4583947 CA16NA024****A CNPH*3017A** 58HDV100--- ---20 25,000 13.5 16.0
4583942 CA16NA024****A CNPH*3017A** 58ME(B,C)060---12 24,800 13.7 16.0
4583943 CA16NA024****A CNPH*3017A** 58ME(B,C)080---12 24,600 13.7 16.0
4583941 CA16NA024****A CNPH*3017A** 58MEB040---12 24,800 13.7 16.0
4583930 CA16NA024****A CNPH*3017A** 58MV(B,C)060---14 24,400 13.5 16.0
4583931 CA16NA024****A CNPH*3017A** 58MV(B,C)080---14 24,200 13.5 16.0
4583932 CA16NA024****A CNPH*3017A** 58MV(B,C)080---20 24,000 13.5 16.0
4583933 CA16NA024****A CNPH*3017A** 58MV(B,C)100---20 24,200 13.5 16.0
4583934 CA16NA024****A CNPH*3017A** 58MV(B,C)120---20 24,400 13.5 16.0
4583929 CA16NA024****A CNPH*3017A** 58MVB040---14 24,200 13.5 16.0
4583940 CA16NA024****A CNPH*3017A** 58PH*045---08 24,400 13.2 16.0
4583949 CA16NA024****A CNPH*3017A** 58VLR105---12 24,400 13.5 16.0
4583948 CA16NA024****A CNPH*3017A** 58VMR105---12 24,200 13.5 16.0
4767774 CA16NA024****A CNPH*3017A** 59*N*A060V17**14 24,000 13.0 16.0
4767775 CA16NA024****A CNPH*3017A** 59*N*A080V17**14 24,000 13.0 16.0
4767776 CA16NA024****A CNPH*3017A** 59*N*A100V21**20 24,000 13.0 16.0
4767777 CA16NA024****A CNPH*3017A** 59*N*A120V24**22 24,000 13.0 16.0
4767778 CA16NA024****A CNPH*3017A** 59*P5A040E14**10 24,000 12.0 14.5
4767779 CA16NA024****A CNPH*3017A** 59*P5A060E17**14 24,000 13.0 16.0
4583951 CA16NA024****A CNPH*3017A** OVLAAB036098 24,400 13.5 16.0
4583950 CA16NA024****A CNPH*3017A** OVMAAB036098 24,400 13.2 16.0
4583952 CA16NA024****A CNPH*3017A** OVMAAB042112 24,400 13.5 16.0
4583928 CA16NA024****A CNPH*3017A**+TDR 24,400 12.2 14.0
4583960 CA16NA024****A CNPH*3117A** 58CV(A,X)070---12 24,600 13.7 16.0
4583961 CA16NA024****A CNPH*3117A** 58CV(A,X)090---16 24,600 13.7 16.0
4583962 CA16NA024****A CNPH*3117A** 58CV(A,X)110---20 24,600 13.7 16.0
4583963 CA16NA024****A CNPH*3117A** 58CV(A,X)135---22 24,600 13.7 16.0
4583964 CA16NA024****A CNPH*3117A** 58CV(A,X)155---22 24,600 13.7 16.0
4583969 CA16NA024****A CNPH*3117A** 58HDV040--- ---12 25,000 13.5 16.0
4583970 CA16NA024****A CNPH*3117A** 58HDV060--- ---12 25,200 13.5 16.0
4583971 CA16NA024****A CNPH*3117A** 58HDV080--- ---20 25,600 13.7 16.0
4583972 CA16NA024****A CNPH*3117A** 58HDV100--- ---20 25,600 13.7 16.0
4583967 CA16NA024****A CNPH*3117A** 58ME(B,C)060---12 25,400 14.0 16.0
4583968 CA16NA024****A CNPH*3117A** 58ME(B,C)080---12 25,200 14.0 16.0
4583966 CA16NA024****A CNPH*3117A** 58MEB040---12 25,200 14.0 16.0
4583955 CA16NA024****A CNPH*3117A** 58MV(B,C)060---14 25,000 13.7 16.0
4583956 CA16NA024****A CNPH*3117A** 58MV(B,C)080---14 24,600 13.7 16.0
4583957 CA16NA024****A CNPH*3117A** 58MV(B,C)080---20 24,400 13.7 16.0
4583958 CA16NA024****A CNPH*3117A** 58MV(B,C)100---20 24,600 13.7 16.0
4583959 CA16NA024****A CNPH*3117A** 58MV(B,C)120---20 24,800 13.7 16.0
4583954 CA16NA024****A CNPH*3117A** 58MVB040---14 24,600 13.7 16.0
4583965 CA16NA024****A CNPH*3117A** 58PH*045---08 25,000 13.7 16.0
4583974 CA16NA024****A CNPH*3117A** 58VLR105---12 24,800 13.7 16.0
4583973 CA16NA024****A CNPH*3117A** 58VMR105---12 24,600 13.7 16.0
4767780 CA16NA024****A CNPH*3117A** 59*N*A060V17**14 24,000 13.0 16.0
4767781 CA16NA024****A CNPH*3117A** 59*N*A080V17**14 24,000 13.2 16.5
4767782 CA16NA024****A CNPH*3117A** 59*N*A100V21**20 24,000 13.2 16.5
4767783 CA16NA024****A CNPH*3117A** 59*N*A120V24**22 24,000 13.2 16.5
4767784 CA16NA024****A CNPH*3117A** 59*P5A040E14**10 24,000 12.5 15.2
4767785 CA16NA024****A CNPH*3117A** 59*P5A060E17**14 24,000 13.2 16.5
4583976 CA16NA024****A CNPH*3117A** OVLAAB036098 24,800 13.7 16.0
4583975 CA16NA024****A CNPH*3117A** OVMAAB036098 24,800 13.7 16.0
See notes on page 60
CA16NA

20
COMBINATION RATINGS
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4583977 CA16NA024****A CNPH*3117A** OVMAAB042112 24,800 13.7 16.0
4583953 CA16NA024****A CNPH*3117A**+TDR 24,800 12.2 14.5
4597435 CA16NA024****A CNPH*3617A** 58CV(A,X)070---12 24,000 13.0 16.0
4597436 CA16NA024****A CNPH*3617A** 58CV(A,X)090---16 24,000 13.0 16.0
4597437 CA16NA024****A CNPH*3617A** 58CV(A,X)110---20 24,000 13.0 16.0
4597438 CA16NA024****A CNPH*3617A** 58CV(A,X)135---22 24,000 13.0 16.0
4597439 CA16NA024****A CNPH*3617A** 58CV(A,X)155---22 24,000 13.0 16.0
4597441 CA16NA024****A CNPH*3617A** 58MEB040---12 24,000 13.0 16.0
4597442 CA16NA024****A CNPH*3617A** 58MEC060---12 24,000 13.0 16.0
4597443 CA16NA024****A CNPH*3617A** 58MEC080---12 24,000 13.0 16.0
4597430 CA16NA024****A CNPH*3617A** 58MV(B,C)060---14 24,000 13.0 16.0
4597431 CA16NA024****A CNPH*3617A** 58MV(B,C)080---14 24,000 13.0 16.0
4597432 CA16NA024****A CNPH*3617A** 58MV(B,C)080---20 24,000 13.0 16.0
4597433 CA16NA024****A CNPH*3617A** 58MV(B,C)100---20 24,000 13.0 16.0
4597434 CA16NA024****A CNPH*3617A** 58MV(B,C)120---20 24,000 13.0 16.0
4597429 CA16NA024****A CNPH*3617A** 58MVB040---14 24,000 13.0 16.0
4661555 CA16NA024****A CNPH*3617A** 58PH*045---08 23,200 13.0 16.0
4597440 CA16NA024****A CNPH*3617A** 58PH*070---16 24,000 12.5 15.5
4597445 CA16NA024****A CNPH*3617A** 58VLR105---12 24,000 13.0 16.0
4597444 CA16NA024****A CNPH*3617A** 58VMR105---12 24,000 13.0 16.0
4767819 CA16NA024****A CNPH*3617A** 59*N*A060V17**14 24,000 13.0 16.0
4767820 CA16NA024****A CNPH*3617A** 59*N*A080V17**14 24,000 13.0 16.0
4767821 CA16NA024****A CNPH*3617A** 59*N*A100V21**20 24,000 13.0 16.0
4767822 CA16NA024****A CNPH*3617A** 59*N*A120V24**22 24,000 13.0 16.0
4767823 CA16NA024****A CNPH*3617A** 59*P5A040E14**10 24,000 12.0 14.5
4767824 CA16NA024****A CNPH*3617A** 59*P5A060E17**14 24,000 13.0 16.0
4597428 CA16NA024****A CNPH*3617A**+TDR 24,000 11.5 14.0
4661551 CA16NA024****A CNPV*1917A** 58CV(A,X)070---12 23,000 13.0 16.0
4661552 CA16NA024****A CNPV*1917A** 58CV(A,X)090---16 23,000 13.0 16.0
4661549 CA16NA024****A CNPV*1917A** 58MV(B,C)060---14 23,400 13.0 16.0
4661553 CA16NA024****A CNPV*1917A** 58PH*045---08 23,200 13.0 16.0
4661550 CA16NA024****A CNPV*1917A** 58UVB060---14 23,400 13.0 16.0
4661548 CA16NA024****A CNPV*1917A**+TDR 23,200 11.5 14.0
4583863 CA16NA024****A CNPV*2414A** 58CV(A,X)070---12 24,000 13.2 15.5
4583864 CA16NA024****A CNPV*2414A** 58PH*045---08 24,000 13.2 15.5
4767754 CA16NA024****A CNPV*2414A** 59*P5A040E14**10 24,000 12.0 14.5
4583862 CA16NA024****A CNPV*2414A**+TDR 24,200 12.0 14.0
4661544 CA16NA024****A CNPV*2417A** 58CV(A,X)070---12 22,800 12.5 15.5
4583868 CA16NA024****A CNPV*2417A** 58CV(A,X)090---16 24,000 13.2 16.0
4597466 CA16NA024****A CNPV*2417A** 58HDV040--- ---12 24,000 12.5 15.5
4597467 CA16NA024****A CNPV*2417A** 58HDV060--- ---12 24,000 12.5 15.5
4583870 CA16NA024****A CNPV*2417A** 58ME(B,C)060---12 24,400 13.2 16.0
4583871 CA16NA024****A CNPV*2417A** 58ME(B,C)080---12 24,200 13.2 16.0
4583869 CA16NA024****A CNPV*2417A** 58MEB040---12 24,400 13.2 16.0
4583866 CA16NA024****A CNPV*2417A** 58MV(B,C)060---14 24,200 13.2 15.5
4597464 CA16NA024****A CNPV*2417A** 58PH*045---08 24,000 12.5 15.5
4583867 CA16NA024****A CNPV*2417A** 58UVB060---14 24,200 13.2 15.5
4583873 CA16NA024****A CNPV*2417A** 58VLR105---12 24,200 13.2 16.0
4583872 CA16NA024****A CNPV*2417A** 58VMR105---12 24,000 13.2 15.5
4767755 CA16NA024****A CNPV*2417A** 59*N*A060V17**14 24,000 12.7 15.5
4767756 CA16NA024****A CNPV*2417A** 59*N*A080V17**14 23,800 12.7 15.5
4767757 CA16NA024****A CNPV*2417A** 59*P5A040E14**10 24,000 12.0 14.5
4767758 CA16NA024****A CNPV*2417A** 59*P5A060E17**14 24,000 12.7 15.5
4583875 CA16NA024****A CNPV*2417A** OVLAAB036098 24,200 13.2 15.5
4583874 CA16NA024****A CNPV*2417A** OVMAAB036098 24,200 13.0 15.5
4583876 CA16NA024****A CNPV*2417A** OVMAAB042112 24,200 13.2 16.0
4583865 CA16NA024****A CNPV*2417A**+TDR 24,200 12.0 14.0
4583878 CA16NA024****A CNPV*3014A** 58CV(A,X)070---12 24,000 13.2 16.0
4583879 CA16NA024****A CNPV*3014A** 58PH*045---08 24,200 13.2 15.5
4767759 CA16NA024****A CNPV*3014A** 59*P5A040E14**10 24,000 12.0 14.5
4583877 CA16NA024****A CNPV*3014A**+TDR 24,400 12.2 14.0
4661545 CA16NA024****A CNPV*3017A** 58CV(A,X)070---12 23,000 13.0 16.0
4583883 CA16NA024****A CNPV*3017A** 58CV(A,X)090---16 24,200 13.5 16.0
4597468 CA16NA024****A CNPV*3017A** 58HDV040--- ---12 24,000 12.5 15.5
4597469 CA16NA024****A CNPV*3017A** 58HDV060--- ---12 24,000 13.0 15.5
4583885 CA16NA024****A CNPV*3017A** 58ME(B,C)060---12 24,800 13.7 16.0
4583886 CA16NA024****A CNPV*3017A** 58ME(B,C)080---12 24,600 13.7 16.0
4583884 CA16NA024****A CNPV*3017A** 58MEB040---12 24,800 13.7 16.0
4583881 CA16NA024****A CNPV*3017A** 58MV(B,C)060---14 24,400 13.5 16.0
4597465 CA16NA024****A CNPV*3017A** 58PH*045---08 24,000 13.0 16.0
4583882 CA16NA024****A CNPV*3017A** 58UVB060---14 24,400 13.5 16.0
4583888 CA16NA024****A CNPV*3017A** 58VLR105---12 24,400 13.5 16.0
4583887 CA16NA024****A CNPV*3017A** 58VMR105---12 24,200 13.5 16.0
See notes on page 60
CA16NA
