Carrier 40VAM-C8FATEE User manual

Installation
Manual
VRF DX COIL INTERFACE
MODEL NAME
Dx-coil controller
40VAM--C8FATEE
(Terminal block without relay)
40VAMR-C8FATEE
(Terminal block with relay)
Dx-valve kit
40VA010V8-ATEE
40VA020V8-ATEE
For commercial use
1135451001
English
Notice: is committed to continuously improving its products to ensure the highest quality and
reliability standards, and to meet local regulations and market requirements. All features and specications
are subject to change without prior notice.
00_1135451001 Cover.indd 100_1135451001 Cover.indd 1 4/7/2566 BE 09:254/7/2566 BE 09:25

– 1 –
Please read this Installation Manual carefully before installing the Air Conditioner.
• This Manual describes the installation method of the VRF DX COIL INTERFACE.
• For installation of the air handling unit, follow the Installation Manual attached to the air handling unit. (Field supply)
• For installation of the outdoor unit, follow the Installation Manual attached to the outdoor unit.
• Carrier does not take any responsibility on the local design.
ADOPTION OF R410A REFRIGERANT
This Air Conditioner uses R410A an environmentally friendly refrigerant.
Contents
1. Precautions .................................................................................................................. 3
2. Overview....................................................................................................................... 7
3. Accessories................................................................................................................ 13
4. Installation.................................................................................................................. 14
Installation Dx-valve kit (Refrigerant pipe).............................................................. 16
Installation Dx-coil controller (Electrical wiring, DN setting) ................................ 21
5. Test run....................................................................................................................... 41
6. Trouble shooting........................................................................................................ 42
Denition of Protective Gear
• When the VRF DX COIL INTERFACE is to be transported, installed, maintained, repaired or removed, wear
protective gloves and “Safety” work clothing.
• In addition to such normal protective gear, wear the protective gear described below when undertaking the special
work detailed in the following table.
• Failure to wear the proper protective gear is dangerous because you will be more susceptible to injury, burns, electric
shocks and other injuries.
Work undertaken Protective gear to wear
All types of work Protective gloves
“Safety” working clothing
Electrical-related work
Gloves to provide protection from electric shock
Insulating shoes
Clothing to provide protection from electric shock
Work done at heights
(50 cm or more) Helmets for use in industry
Transportation of heavy
objects Shoes with additional protective toe cap
Repair Gloves to provide protection for electricians
01_1135451001 EN edit-1.indd 101_1135451001 EN edit-1.indd 1 4/7/2566 BE 09:254/7/2566 BE 09:25

– 2 –
Warning indications on the Dx-coil interface unit
Warning indication Description
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect all remote
electric power supplies
before servicing.
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect all remote electric power supplies before servicing.
Denition of Qualied Installer or Qualied Service Person
The air conditioner must be installed, maintained, repaired and removed by a qualied installer or qualied service
person. When any of these jobs is to be done, ask a qualied installer or qualied service person to do them. A qualied
installer or qualied service person is an agent who has the qualications and knowledge described in the following
table.
Agent Qualications and knowledge which the agent must have
Qualied installer
• The qualied installer is a person who installs, maintains, relocates and removes the air conditioners
made by Manufacturer. He or she has been trained to install, maintain, relocate and remove the
air conditioners made by Manufacturer or, alternatively, he or she has been instructed in such
operations by an individual or individuals who have been trained and is thus thoroughly acquainted
with the knowledge related to these operations.
• The qualied installer who is allowed to do the electrical work involved in installation, relocation and
removal has the qualications pertaining to this electrical work as stipulated by the local laws and
regulations, and he or she is a person who has been trained in matters relating to electrical work on
the air conditioners made by Manufacturer or, alternatively, he or she has been instructed in such
matters by an individual or individuals who have been trained and is thus thoroughly acquainted
with the knowledge related to this work.
• The qualied installer who is allowed to do the refrigerant handling and piping work involved in
installation, relocation and removal has the qualications pertaining to this refrigerant handling and
piping work as stipulated by the local laws and regulations, and he or she is a person who has been
trained in matters relating to refrigerant handling and piping work on the air conditioners made by
Manufacturer or, alternatively, he or she has been instructed in such matters by an individual or
individuals who have been trained and is thus thoroughly acquainted with the knowledge related to
this work.
• The qualied installer who is allowed to work at heights has been trained in matters relating to
working at heights with the air conditioners made by Manufacturer or, alternatively, he or she has
been instructed in such matters by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to this work.
Qualied service
person
• The qualied service person is a person who installs, repairs, maintains, relocates and removes
the air conditioners made by Manufacturer. He or she has been trained to install, repair, maintain,
relocate and remove the air conditioners made by Manufacturer or, alternatively, he or she has been
instructed in such operations by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to these operations.
• The qualied service person who is allowed to do the electrical work involved in installation, repair,
relocation and removal has the qualications pertaining to this electrical work as stipulated by the
local laws and regulations, and he or she is a person who has been trained in matters relating to
electrical work on the air conditioners made by Manufacturer or, alternatively, he or she has been
instructed in such matters by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to this work.
• The qualied service person who is allowed to do the refrigerant handling and piping work involved
in installation, repair, relocation and removal has the qualications pertaining to this refrigerant
handling and piping work as stipulated by the local laws and regulations, and he or she is a person
who has been trained in matters relating to refrigerant handling and piping work on the air conditioners
made by Manufacturer or, alternatively, he or she has been instructed in such matters by an individual
or individuals who have been trained and is thus thoroughly acquainted with the knowledge related to
this work.
• The qualied service person who is allowed to work at heights has been trained in matters relating
to working at heights with the air conditioners made by Manufacturer or, alternatively, he or she has
been instructed in such matters by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to this work.
01_1135451001 EN edit-1.indd 201_1135451001 EN edit-1.indd 2 4/7/2566 BE 09:254/7/2566 BE 09:25

– 3 –
1. Precautions
The manufacturer shall not assume any liability for the damage caused by not observing the
description of this manual.
WARNING
General
• Do not modify the products. Do not also disassemble or modify the parts. It may cause a re,
electric shock or injury.
• Before starting to install the Dx-coil interface, read through the Installation Manual carefully,
and follow its instructions to install the Dx-coil interface.
• Only a qualied installer or qualied service person is allowed to do installation work.
Inappropriate installation may result in water leakage, electric shock or re.
• Do not use any refrigerant different from the one specied for complement or replacement.
Otherwise, abnormally high pressure may be generated in the refrigeration cycle, which may
result in a failure or explosion of the product or an injury to your body.
• Before opening the electrical control box cover of the air handling unit or service panel of the
outdoor unit, set the circuit breaker to the OFF position. Failure to set the circuit breaker to
the OFF position may result in electric shocks through contact with the interior parts. Only
a qualied installer (*1) or qualied service person (*1) is allowed to remove the electrical
control box cover of the air handling unit or service panel of the outdoor unit and do the work
required.
• Before carrying out the installation, maintenance, repair or removal work, set the circuit
breaker to the OFF position. Otherwise, electric shocks may result.
• Place a “Work in progress” sign near the circuit breaker while the installation, maintenance,
repair or removal work is being carried out. There is a danger of electric shocks if the circuit
breaker is set to ON by mistake.
• Only a qualied installer (*1) or qualied service person (*1) is allowed to undertake work at
heights using a stand of 50 cm or more.
• Wear protective gloves and safety work clothing during installation, servicing and removal.
• When work is performed at heights, use a ladder which complies with the ISO 14122
standard, and follow the procedure in the ladder’s instructions. Also wear a helmet for use in
industry as protective gear to undertake the work.
• Before working at heights, put a sign in place so that no-one will approach the work location,
before proceeding with the work. Parts and other objects may fall from above, possibly injuring
a person below. While carrying out the work, wear a helmet for protection from falling objects.
• The refrigerant used by this Dx-coil interface is the R410A.
• The Dx-coil interface must be transported in stable condition. If any part of the product is
broken, contact the dealer.
• Do not move or repair any unit by yourself. There is high voltage inside the unit. You may get
electric shock when removing the cover and main unit.
• This appliance is intended to be used by expert or trained users in shops, in light industry, or
for commercial use by lay persons.
• Do not add any other devices without factory advice.
Installation
• Install the air conditioner securely in a location where the base can sustain the weight
adequately. If the strength is not enough, the unit may fall down resulting in injury.
• Follow the instructions in the Installation Manual to install the air conditioner. Failure to follow
these instructions may cause the product to fall down or topple over or give rise to noise,
vibration, water leakage or other trouble.
• Carry out the specied installation work to guard against the possibility of high winds and
earthquake.
If the air conditioner is not installed appropriately, a unit may topple over or fall down,
causing an accident.
01_1135451001 EN edit-1.indd 301_1135451001 EN edit-1.indd 3 4/7/2566 BE 09:254/7/2566 BE 09:25

– 4 –
• If refrigerant gas has leaked during the installation work, ventilate the room immediately.
If the leaked refrigerant gas comes in contact with re, noxious gas may generate.
• Helmet must be worn to protect your head from falling objects. Especially, when you work
under an inspection opening, helmet must be worn to protect your head from falling objects
from the opening.
Selection of installation location
• When the air conditioner is installed in a small room, provide appropriate measures to ensure
that the concentration of refrigerant leakage occur in the room does not exceed the critical
level.
• Do not install in a location where ammable gas leaks are possible. If the gas leak and
accumulate around the unit, it may ignite and cause a re.
• To transport the Dx-coil interface, wear shoes with additional protective toe caps.
• Do not place any combustion appliance in a place where it is directly exposed to the wind of
air conditioner, otherwise it may cause imperfect combustion.
Refrigerant piping
• Install the refrigerant pipe securely during the installation work before operating the
air conditioner. If the compressor is operated with the valve open and without refrigerant
pipe, the compressor sucks air and the refrigeration cycles is over pressurized, which may
cause a injury.
• After the installation work, conrm that refrigerant gas does not leak. If refrigerant gas leaks
into the room and ows near a re source, such as a cooking range, noxious gas may be
generated.
• When the air conditioner has been installed or relocated, follow the instructions in the
Installation Manual and purge the air completely so that no gases other than the refrigerant
will be mixed in the refrigerating cycle. Failure to purge the air completely may cause the
air conditioner to malfunction.
• Nitrogen gas must be used for the airtight test.
• The charge hose must be connected in such a way that it is not slack.
• Due to the pressure of R410A is higher than that of other refrigerant (ex. R22), be sure to
use the pipe specic for R410A and use the special tool for the pipe processing.
Electrical wiring
• Only a qualied installer (*1) or qualied service person (*1) is allowed to carry out the
electrical work of the air conditioner. Under no circumstances must this work be done by an
unqualied individual since failure to carry out the work properly may result in electric shocks
and/or electrical leaks.
• To connect the electrical wires, repair the electrical parts or undertake other electrical jobs,
wear gloves to provide protection for electricians, insulating shoes and clothing to provide
protection from electric shocks. Failure to wear this protective gear may result in electric
shocks.
• Use wiring that meets the specications in the Installation Manual and the stipulations in the
local regulations and laws. Use of wiring which does not meet the specications may give
rise to electric shocks, electrical leakage, smoking and/or a re.
• Connect earth wire. (Grounding work) Incomplete grounding causes an electric shock.
• Do not connect earth wires to gas pipes, water pipes, and lightning conductor or telephone
earth wires.
• After completing the repair or relocation work, check that the earth wires are connected
properly.
• Install a circuit breaker that meets the specications in the Installation Manual and the
stipulations in the local regulations and laws.
• Install the circuit breaker where it can be easily accessed by the agent.
• When installing the circuit breaker outdoors, install one which is designed to be used
outdoors.
01_1135451001 EN edit-1.indd 401_1135451001 EN edit-1.indd 4 4/7/2566 BE 09:254/7/2566 BE 09:25

– 5 –
• Under no circumstances the power wire must not be extended. Connection trouble in the
places where the wire is extended may give rise to smoking and/or a re.
• Electrical wiring work shall be conducted according to law and regulation in the community
and Installation Manual. Failure to do so may result in electrocution or short circuit.
• Make sure that the circuit breaker is attached. If it is not, the electric shock may be caused.
• Do not use the fuse other than the correct capacity. Use of wire or copper wire may result in
re or malfunction.
• Ensure that the power is the rated voltage and use the circuit special for the Dx-coil interface.
Test run
• Before operating the air conditioner after having completed the work, check that the electrical
control box cover of the air handling unit and service panel of the outdoor unit are closed,
and set the circuit breaker to the ON position. You may receive an electric shock if the power
is turned on without rst conducting these checks.
• If there is any kind of trouble (such as a check display has appeared, smell of burning,
abnormal sounds, the air conditioner fails to cool or heat or water is leaking) has occurred in
the air conditioner, do not touch the air conditioner yourself but set the circuit breaker to the
OFF position, and contact a qualied service person. Take steps to ensure that the power
will not be turned on (by marking “out of service” near the circuit breaker, for instance) until
qualied service person arrives. Continuing to use the air conditioner in the trouble status
may cause mechanical problems to escalate or result in electric shocks or other trouble.
• After the work has nished, use an insulation tester set (500 VMΩ) to check the resistance is
1 MΩ or more between the charge section and the non-charge metal section (Earth section).
If the resistance value is low, a disaster such as a leak or electric shock is caused at user’s
side.
• Upon completion of the installation work, check for refrigerant leaks and check the insulation
resistance and water drainage. Then conduct a test run to check that the air conditioner is
operating properly.
Explanations given to user
• Upon completion of the installation work, tell the user where the circuit breaker is located.
If the user does not know where the circuit breaker is, he or she will not be able to turn it off
in the event that trouble has occurred in the air conditioner.
• After the installation work, follow the Owner’s Manual to explain to the customer how to use
and maintain the unit.
Relocation
• Only a qualied installer (*1) or qualied service person (*1) is allowed to relocate the
air conditioner. It is dangerous for the air conditioner to be relocated by an unqualied
individual since a re, electric shocks, injury, water leakage, noise and/or vibration may
result.
• When carrying out the pump-down work shut down the compressor before disconnecting the
refrigerant pipe. Disconnecting the refrigerant pipe with the service valve left open and the
compressor still operating will cause air or other gas to be sucked in, raising the pressure
inside the refrigeration cycle to an abnormally high level, and possibly resulting in rupture,
injury or other trouble.
Repair • Maintenance
• Request the repair to the distributor that you made your purchase from.
• If there is a defect in the repair, the re, electric shock may be caused.
• Turn off the circuit breaker of the entire system including the AHU and the outdoor unit when
performing the repair or the maintenance.
(*1) Refer to the “Denition of Qualied Installer or Qualied Service Person”.
01_1135451001 EN edit-1.indd 501_1135451001 EN edit-1.indd 5 4/7/2566 BE 09:254/7/2566 BE 09:25

– 6 –
Selection of installation place
Avoid installation in the following kinds of locations.
• Dx-coil interface is recommended to be installed indoors. Install it in a location where there is
no rain, wind, and direct sunlight.
• Do not install in locations where there is a machine generating high frequency. Failure to do
so may cause a wrong operation or an abnormality.
• Do not install in locations with atmospheres with mist of oil (including machine oil) or dense
vapor, or locations containing salt such as the coast area, or locations with acidic or alkaline
atmospheres, or locations where sulfurizing gas are generated such as areas with hot
springs. Use in inappropriate locations result in malfunctions.
• Do not put any vessel contains the water in the vicinity of the indoor unit (including Dx-coil
controller, Dx-valve kit).
If the water spills and enters into the inside of the unit, the electric insulation deteriorates and
may result in an electric shock.
• Make sure that the air lter is attached on the indoor unit. If it is not, the dust clogs in the
heat exchanger etc. in the air conditioner and may result in water leakage or defrosting.
• Separate the television or radio from the air conditioner or remote controller at least 1 m.
Failure to do so may cause the disturbance of the image, or the noise.
• Do not use for special-purpose (Foods, animals and plants, precision machine, storage of
the artwork etc.).
• Do not use in locations where there is anything that would be compromised by wetness.
The mist or water dew drop may result in damage.
• Do not install in locations where organic solvents are being used.
• Do not install in locations near doors or windows where the air conditioner may come into
contact with high humidity outside air. Condensation may occur as a result.
• Do not install in locations where special sprays are used frequently. The location has an
impact on the insulation of the equipment and may cause the ignition.
• Do not install in locations with high-humidity atmosphere. Doing so may cause condensation
of the equipment, splashing of water from the air outlet side of indoor unit.
Ex. 1) Installation to inside of the ceiling where is high humidity.
2) Installation to inside of the ceiling used for the path of the fresh air intake.
3) Installation to a kitchen.
• In the above cases, additionally attach the heat insulator (grass wool etc.) to all positions of
the air conditioner, which come to contact with the high-humidity atmosphere.
* The guideline of the high-humidity condition is “dew-point temperature: 23°C or higher”,
however, the decision should be made according to the trial operation conducted in each
installation location.
• Install in locations that ensure the sufcient space needed for the service so that the
equipment does not come to contact with the surface of the wall or the ceiling.
• Fix the Dx-coil controller, Dx-valve kit to the stable surface. Failure to do so may cause the
vibration or the noise.
• Do not install the Dx-coil controller, Dx-valve kit to the locations where there is a temperature
difference with the ambient temperature. Failure to do so may result in condensation, rust, or
malfunction. Ex. The sheet metal side surface of the AHU outlet.
• Install the Dx-valve kit to where the noise is no problem due to the Dx-valve kit makes
the refrigerant noise. Also, it may make the refrigerant noise when other indoor units are
operating even if the AHU is stopping like defrosting.
• Do not install in locations with the high temperature or the high-humidity atmosphere of 52°C
or more / RH 80% or more. Also, do not install it in a place where dew condensation occurs
inside the Dx-coil controller.
• When installing the Dx-valve kit and the Dx-coil controller into the Air handling unit, do not
install it where it is exposed to the cooled air of the secondary side of the heat exchanger.
• Do not install in locations where iron or other metal dust is present. If iron or other metal
dust adheres to or collects on the interior of the Dx-coil controller, it may spontaneously
combusted and start a re.
01_1135451001 EN edit-1.indd 601_1135451001 EN edit-1.indd 6 4/7/2566 BE 09:254/7/2566 BE 09:25

– 7 –
2. Overview
Dx-coil controller
VRF Dx-coil interface is the product that is used with connecting the AHU with the DX COIL prepared on-site to the
Carrier VRF outdoor unit.
* 1. DX COIL: Abbreviation of the Direct expansion coil (heat exchanger).
* 2. DDC: Abbreviation of the Direct Digital Controller.
* 3. AHU: Abbreviation of the Air Handling Unit.
For the installation of the air handling unit, refer to the Installation Manual of the air handling unit.
• Dx-coil interface (DDC type use for Supply air temperature or TF type) cannot control the room temperature.
Example of the system conguration
VRF Dx-coil interface can connect to New Carrier band VRF.
In one cycle the outdoor unit and Dx-coil interface shall be one each for the structure.
For the AHU prepared on-site, please design with referring to submittal of AHU.
TA type : Enables to connect 3rd party indoor unit or air handing unit as one of VRF indoor unit.
(Return air temperature control by remote controller setting)
Main application target – Room temperature conditioning
TA
TCJ
TC2 TC1
AHU
Set temp. (Cool)
Room
12:00
(Mon)
°C
27
Dx-coil controller
Remote
controller
Outdoor unit
Dx-valve kit
Remote
controller
Outdoor unit
Dx-valve kit TA
TCJ
TC2 TC1
Set temp. (Cool)
Room
12:00
(Mon)
°C
27
AHU
01_1135451001 EN edit-1.indd 701_1135451001 EN edit-1.indd 7 4/7/2566 BE 09:254/7/2566 BE 09:25

– 8 –
TF type : The discharge temperature is set by the remote controller to control the capacity.
Main application target – Ventilation
AHU
TF
TCJ
TC2 TC1
TA
Set temp. (Cool)
Room
12:00
(Mon)
C
27
Dx-coil controller
Remote
controller
Outdoor unit
Dx-valve kit
Dx-coil controller
Remote
controller
Outdoor unit
Dx-valve kit
AHU
TF
TCJ
TC2 TC1
TA
Set temp. (Cool)
Room
12:00
(Mon)
C
27
01_1135451001 EN edit-1.indd 801_1135451001 EN edit-1.indd 8 4/7/2566 BE 09:254/7/2566 BE 09:25

– 9 –
DDC type : Direct capacity control of Carrier VRF outdoor unit by analogue input (0-10 V)
Mainly discharge air temperature control linked AHU system.
AHU
TF
TCJ
TC2TC1
DDC
TA
Dx-coil controller Locally procured
Outdoor unit
Dx-valve kit
• Diversity specication
Type 38VT
(communication) (TU2C-LINK or TCC LINK)
TA type 60 - 110%
DDC type 75 - 100%
TF type 80 - 100%
• Two or more AHU below 12 HP combination is available.
• Two or more AHU over 14 HP combination is available.
• Combination AHU below 12 HP with VRF FCU below 10 HP is available.
• Combination AHU over 14 HP with VRF FCU is prohibited.
• For the AHU prepared on-site, please design with referring to submittal of AHU.
Please refer to the design guideline for details.
DX COIL type Normal Split face Interlaced Split Row
Max. connectable
Dx-coil capacity UP to 40 HP Not Available Not Available Not Available
Specication 1 inlet & outlet port
2 or 3 inlet & outlet ports
2 or 3 path ways are
arranged up and down
2 or 3 inlet & outlet ports
2 or 3 path ways are
interlaced
2 or 3 inlet & outlet ports
2 or 3 path ways are
arranged parallels
Dx-coil controller Locally procured
Outdoor unit
Dx-valve kit
AHU
TF
TCJ
TC2TC1
DDC
TA
01_1135451001 EN edit-1.indd 901_1135451001 EN edit-1.indd 9 4/7/2566 BE 09:254/7/2566 BE 09:25

– 10 –
DX COIL type Normal Interlaced, Split face
Type Dx-coil controller Dx-valve kit HEX
number
Dx-coil controller Dx-valve kit HEX
number
Model name 40VAM--C8FATEE
40VAMR-C8FATEE
40VA010V8
-ATEE
40VA020V8
-ATEE
40VAM--C8FATEE
40VAMR-C8FATEE
40VA010V8
-ATEE
40VA020V8
-ATEE
Connectable
Dx-coil
capacity
8 HP 1 1 - 1
10 HP 1 1 - 1
12 HP 1 1 - 1
14 HP 1 - 1 1
16 HP 1 - 1 1 - - - -
2(8+8) 2 - 2
18 HP 1 - 1 1 - - - -
2(8+10) 2 - 2
20 HP 1 - 1 1 - - - -
2(10+10) 2 - 2
22 HP - - - - 2(12+10) 2 - 2
24 HP 1 2 - 1 2(12+12) 2 - 2
3(8+8+8) 3 - 3
26 HP - - - - 3(10+8+8) 3 - 3
28 HP 1 - 2 1 2(14+14) - 2 2
3(10+10+8) 3 - 3
30 HP - - - - 3(10+10+10) 3 - 3
32 HP 1 - 2 1 2(16+16) - 2 2
34 HP - - - - 2(18+16) - 2 2
36 HP 1 - 2 1 2(18+18) - 2 2
38 HP - - - - 2(20+18) - 2 2
40 HP 1 - 2 1 2(20+20) - 2 2
01_1135451001 EN edit-1.indd 1001_1135451001 EN edit-1.indd 10 4/7/2566 BE 09:254/7/2566 BE 09:25

– 11 –
DX COIL type Interlaced, Split face Interlaced, Split face
Type Dx-coil controller Dx-valve kit
HEX
number
Dx-coil controller Dx-valve kit
HEX
number
Model name
40VAM--C8FATEE
40VAMR-C8FATEE
40VA010V8
-ATEE
40VA020V8
-ATEE
40VAM--C8FATEE
40VAMR-C8FATEE
40VA010V8
-ATEE
40VA020V8
-ATEE
Connectable
Dx-coil
capacity
42 HP - - - - 3(14+14+14) - 3 3
44 HP - - - - 3(16+14+14) - 3 3
46 HP - - - - 3(16+16+14) - 3 3
48 HP 2(24+24) 4 - 2 3(16+16+16) - 3 3
50 HP - - - - 3(18+16+16) - 3 3
52 HP - - - - 3(18+18+16) - 3 3
54 HP - - - - 3(18+18+18) - 3 3
56 HP 2(28+28) - - - 3(20+18+18) - 3 3
4 2 4(14+14+14+14) - 4 4
58 HP - - - - 3(20+20+18) - 3 3
60 HP - - - - 3(20+20+20) - 3 3
62 HP - - - - 4(16+16+16+14) - 4 4
64 HP 2(32+32) - 4 2 4(16+16+16+16) - 4 4
66 HP - - - - 4(18+16+16+16) - 4 4
68 HP - - - - 4(18+18+16+16) - 4 4
70 HP - - - - 4(18+18+18+16) - 4 4
72 HP 2(36+36) - 4 2 4(18+18+18+18) - 4 4
74 HP - - - - 4(20+18+18+18) - 4 4
76 HP - - - - 4(20+20+18+18) - 4 4
78 HP - - - - 4(20+20+20+18) - 4 4
80 HP 2(40+40) - 4 2 4(20+20+20+20) - 4 4
82 HP - - - - 5(18+16+16+16+16) - 5 5
84 HP 3(28+28+28) - - - 5(18+18+16+16+16) - 6 5
6 3
6(14+14+14+14+14+14) - 6 6
86 HP - - - - 5(18+18+18+16+16) - 5 5
88 HP - - - - 5(18+18+18+18+16) - 5 5
90 HP - - - - 5(18+18+18+18+18) - 5 5
92 HP - - - - 5(20+18+18+18+18) - 5 5
94 HP - - - - 5(20+20+18+18+18) - 5 5
96 HP 3(32+32+32) - - - 5(20+20+20+18+18) - 5 5
6 3
6(16+16+16+16+16+16) - 6 6
98 HP - - - - 5(20+20+20+20+18) - 5 5
100 HP - - - - 5(20+20+20+20+20) - 5 5
102 HP - - - - 6(18+18+18+16+16+16) - 6 6
104 HP - - - - 6(18+18+18+18+16+16) - 6 6
106 HP - - - - 6(18+18+18+18+18+16) - 6 6
108 HP 3(36+36+36) - 6 3 6(18+18+18+18+18+18) - 6 6
110 HP - - - - 6(20+18+18+18+18+18) - 6 6
112 HP - - - - 6(20+20+18+18+18+18) - 6 6
114 HP - - - - 6(20+20+20+18+18+18) - 6 6
116 HP - - - - 6(20+20+20+20+18+18) - 6 6
118 HP - - - - 6(20+20+20+20+20+18) - 6 6
120 HP 3(40+40+40) - 6 3 6(20+20+20+20+20+20) - 6 6
01_1135451001 EN edit-1.indd 1101_1135451001 EN edit-1.indd 11 4/7/2566 BE 09:254/7/2566 BE 09:25

– 12 –
Settings for each type (TA, TF, DDC)
Set with the SW501 switch on the control P.C. board MCC-1777.
SW501
LED
LED
TA type: Set all SW501 to OFF.
Turn off Bit3 of SW501.
SW501
ON
OFF 1 2 3 4
TF type: Turn on only Bit2 of SW501.
Turn off Bit3 of SW501.
SW501
ON
OFF 1 2 3 4
DDC type (0 - 10 V) Stepped Control: Turn on only Bit3 of SW501. (Refer to AI3 / AI3 for details)
SW501
ON
OFF 1 2 3 4
DDC type (0 - 10 V) Linear Control: Turn on Bit3 and Bit4 of SW501. (Refer to AI3 / AI3 for details)
SW501
ON
OFF 1 2 3 4
LED position and details
D505D504D503D501
P.C. board LED Meaning of lighting
D501 MCU power supply Lights when the power is turned on
D503 Main bus communication Flashes every 5 seconds.
With central control: lighting and ashing every 5 seconds.
D504 Sub bus communication Flashes every 5 seconds.
Group: lighting and ashing every 5 seconds.
D505 Mod bus communication When connected to Modbus, it lights up every 5 seconds.
D403 Sub bus power supply Sub bus lights while power is being supplied.
D403
01_1135451001 EN edit-1.indd 1201_1135451001 EN edit-1.indd 12 4/7/2566 BE 09:254/7/2566 BE 09:25

– 13 –
3. Accessories
3-1. Dx-coil controller 40VAM--C8FATEE, 40VAMR-C8FATEE
No. Item Q’ty Shape
1TA sensor
(Length: 7.5 m, Connector color: Yellow) 1
2TC1 sensor
(Length: 7.5 m, Connector color: Brown) 1
3TC2 sensor
(Length: 7.5 m, Connector color: Black) 1
4TCJ sensor
(Length: 7.5 m, Connector color: Red) 1
5TF sensor
(Length: 7.5 m, Connector color: Green) 1
6Sensor holder (TC1)
(O.D. 6.35 mm, Length: 26 mm) 1
7 Sensor clip (TC1) 1
8Sensor holder (TC2, TCJ)
(O.D. 8 mm, Length: 26 mm) 2
9 Sensor clip (TC2, TCJ) 2
There are no accessories for the sensor holders for the TA sensor and TF sensor.
No. 6, 7, 8 and 9 are also included in the Dx-valve kit. Please use either one.
3-2. Dx-valve kit 40VA010V8-ATEE, 40VA020V8-ATEE
No. Item Q’ty Shape
1Sensor holder (TC1)
(O.D. 6.35 mm, Length: 26 mm) 1
2 Sensor clip (TC1) 1
3Sensor holder (TC2, TCJ)
(O.D. 8 mm, Length: 26 mm) 2
4 Sensor clip (TC2, TCJ) 2
5Heat insulation
(O.D. 40 mm, Length: 210 mm) 2
6Cable tie
(Length: 152 mm) 1
There are no accessories for the sensor holders for the TA sensor and TF sensor.
01_1135451001 EN edit-1.indd 1301_1135451001 EN edit-1.indd 13 4/7/2566 BE 09:254/7/2566 BE 09:25

– 14 –
External dimensions and Installation space
Be sure to install the controller, valve kit in the indoor. Failure to do so may cause the frost formation, rust, or malfunction.
40VAM--C8FATEE, 40VAMR-C8FATEE
330
30015
30360
420
15
122
43 20
34 52 52 55 52 52
4-Ø6.0 Mounting hole
Earth screw
Terminal block (3p)
(Power supply)
Clamp
(For power supply)
Clamp (5 piece)
Bushing (6 piece)
Ø34
Power supply
Output
Input
Valve kit
Sensor
Remote controller
inter-unit
The bushing does not
have a slit at the time of
shipment. Please add a slit
at the time of construction
and let the wiring pass
through.
Note)
• This product is designed for the indoor installation.
• If the temperature sensor is short, use the Optional Sensor 40VA10-S8FATEE.
(Temperature sensor with 10 m wiring length)
MCC-1777
(Unit: mm)
Sensor connection port
(Local connecting)
Sensor (TC1, TC2, TCJ, TA, TF)
(accessory)
Terminal block
There are two types.
• Installation space and maintenance space.
Upper side when installed.
500 or more
200 or more
30 or more
30 or more
30 or more
Wall
Wall
Wall
Floor
Passing Temperature
sensor leads, through
a clamp lter.
(TA, TC2, TF, TCJ, TC1)
 Terminal block type classication table.
40VAM--C8FATEE
(Terminal block without relay)
Terminal block (38P)
40VAMR-C8FATEE
(Terminal block with relay)
Terminal block (32P)
Terminal block (6P with relay)
4. Installation
01_1135451001 EN edit-1.indd 1401_1135451001 EN edit-1.indd 14 4/7/2566 BE 09:254/7/2566 BE 09:25

– 15 –
40VA010V8-ATEE, 40VA020V8-ATEE
Note)
This product is designed for the indoor installation.
Model A (Pipe)
40VA010V8-ATEE Ø12.7
40VA020V8-ATEE Ø15.88
Refrigerant pipe connection port
(Liquid pipe / Outdoor unit side)
209
17915
240 70
36099
A A
186
138
45
49
95
99
80
Connection cable
(Factory wiring)
4-Ø6.0 Mounting hole
PMV motor
Refrigerant pipe connection port
(Liquid pipe / Air Handing unit side)
(Unit: mm)
Terminal block (5p)
Connection cable
(Local wiring)
Cable tie (Accessories No.6)
Wire clamp
When xing the connection
cable with a cable tie, allow
a margin for the connection
cable on the terminal block
side.
Pass the connection cable
through the wire clamp and
x it with a cable tie.
• Installation space and maintenance space.
Upper side when installed.
30 or more
30 or more
500 or more
Floor
30 or more
300 or more
Wall
Wall
Wall
01_1135451001 EN edit-1.indd 1501_1135451001 EN edit-1.indd 15 4/7/2566 BE 09:254/7/2566 BE 09:25

– 16 –
Installation Dx-valve kit (Refrigerant pipe)
By the refrigerant circuit diagram, braze the sensor holder of TC1, TC2, TCJ of the valve kit and the accessory. Refer to the
below table for the pipe diameter and the pipe length to use.
Item TA type TF, DDC type
Main pipe equivalent length Same as piping length restriction of outdoor unit
Total piping length (real length) 200 m 120 m (100 m)
Furthest equivalent pipe length L(real length) 130 m (120 m) 100 m
Furthest equivalent pipe length from the 1st branch 40 m -
Furthest equivalent pipe length between outdoor unit Same as piping length
restriction of outdoor unit -
Max, real length of pipes connected to indoor units 20 m -
Maximum equivalent between branching section 30 m -
Max.
Height
Difference
Outdoor unit - Indoor unit (Upper outdoor unit) H1
40 m or the outdoor unit
spec. Whichever is shorter
of outdoor unit.
40 m
Outdoor unit - Indoor unit
(Lower outdoor unit) H1
H2 > 3 m
H2 ≤ 3 m
Indoor unit - Indoor unit (Upper outdoor unit) H2 -
Indoor unit - Indoor unit (Lower outdoor unit) H2 -
Dx-valve kit and connection of the pipe
• Be sure to cool the strainer and PMV valve body using a wet cloth so that the body temperature does not exceed
120°C while brazing.
• For the connection pipe, it may vibrate during the defrosting operation. Carry out the installation work so that the
connection pipe does not break after a long-term use.
Sensor holders
• To ensure reliable operation, all Sensor holders must be tted by brazing.
• Be careful of that the brazing material does not enter into the sensor holder when attaching the TC1, TC2 and TCJ
sensor holder.
TC1 sensor
• Install it in the collecting part of the gas header.
TC2 sensor
• Install it in the between the liquid pipe distributor and the PMV.
(TC2 sensor is attached to the refrigerant cycle of AHU.)
TCJ sensor
• Install it in the pass where the temperature of the capillary tube is the lowest.
• Keep a distance of 50 mm ± 25 mm from the end plate.
TA, TF sensor
• Install the TA, TF sensor where the better of air ow.
• The TA sensor must be located in the Return Air position, prior to mixing with any fresh air.
• Install the TF sensor in a place where the discharge air temperature is uniform.
If the TC1, TC2, or TCJ sensor are easy to be subjected to the surrounding thermal effect, cover them with the heat
insulator material, and x them with the xing band.
If the lead wires of various sensors are left over, protect them from the effects of external force, heat, and water, and x
them with a xing band. If the lead wires of various sensors do not reach, use the Optional Sensor 40VA010-S8FATEE
(Temperature sensor with 10 m wiring length).
45°
Gas pipe
TC1 sensor holder
Attachment gure
Sensor holder
Taping
Taping
Valve kit
Heat insulator
Braze the TC1 sensor on the location of the lower
side 45° to detect the stable temperature.
After brazing the pipe, wrap the attached heat insulator and x
it with a tape.
01_1135451001 EN edit-1.indd 1601_1135451001 EN edit-1.indd 16 4/7/2566 BE 09:254/7/2566 BE 09:25

– 17 –
TC1, TC2 and TCJ sensor position on DX COIL
Dx-valve kit: 1 set DX COIL type: Normal
AHU
Gas pipe
Header
Capillary Tube
PMV: Pulse
Motor Valve
Dx-valve kit
Distributor TCJ Ø6 mm
(Brazing)
Max. 5 m
TC2 Ø6 mm
(Brazing)
TC1 Ø4 mm
(Brazing)
50 mm ± 25 mm from the end plate
Strainer
Brazing
Heat insulator
Liquid pipe
DX COIL
Example TA / TF*1 sensor position
1. Fresh Air Only
AHU
Fresh
Air
TA sensor
position
Dx coil Fan Supply
TF sensor
position
Supply
Air
2. Outdoor Air (Fresh Air) mixed with Return Air
AHU
Fresh
Air
Return
Air
TA sensor
position
Dx coil Fan Supply
TF sensor
position
Supply
Air
3. Outdoor Air (Fresh Air) mixed with Return Air by Heat Recovery Exchanger
Fresh Air
Return
Air
TA sensor
position
Heat Recovery
Exchanger
Exhaust Air
Fan Return AHU
Dx coil Fan Supply
Supply
Air
TF sensor
position
*1: TF sensor can only be used with XCT8.
01_1135451001 EN edit-1.indd 1701_1135451001 EN edit-1.indd 17 4/7/2566 BE 09:254/7/2566 BE 09:25

– 18 –
Refrigerant circuit diagram
(2)
(3)
(2)
(2)
(3)
Valve kit: 2 sets DX COIL type: Normal
Valve kit: 1 set DX COIL type: Normal
(1) Gas pipe
(1) Gas pipe
Header
Header
Capillary Tube
PMV: Pulse
Motor Valve
PMV: Pulse
Motor Valve
PMV: Pulse
Motor Valve
Y-joint (A)
Distributor
Distributor
Strainer
Strainer
Strainer
Brazing
Brazing
Brazing
Heat insulator
Heat insulator
Heat insulator
(2) Liquid pipe
(2) Liquid pipe
(2) Liquid pipe
DX COIL
DX COIL
Y-joint (B)
Max. 5 m
Valve kit
Valve kit
Valve kit
01_1135451001 EN edit-1.indd 1801_1135451001 EN edit-1.indd 18 4/7/2566 BE 09:254/7/2566 BE 09:25

– 19 –
Valve kit: 3 sets DX COIL type: Interlaced, Split face
(3)
(2)
(2)
(2)
(1) Gas pipe
Header
Header
Header
Capillary Tube
Valve kit
Valve kit
Valve kit
Capillary Tube
Capillary Tube
PMV: Pulse
Motor Valve
PMV: Pulse
Motor Valve
PMV: Pulse
Motor Valve
Distributor
Y-joint (A)
Y-joint (A)
Distributor
Distributor
Strainer
Strainer
Strainer
Brazing
Brazing
Brazing
Heat insulator
Heat insulator
Heat insulator
(2) Liquid pipe
(2) Liquid pipe
(2) Liquid pipe
DX COIL
DX COIL
DX COIL
Y-joint (B)
Y-joint (B)
01_1135451001 EN edit-1.indd 1901_1135451001 EN edit-1.indd 19 4/7/2566 BE 09:254/7/2566 BE 09:25
