Case 570T User manual

OPERATOR'SMANUAL
570T
Pit-47574402
IssuedateJune2014
EN

Contents
1GENERALINFORMATION
Foreword...................................................................................1-1
NotetotheOwner..........................................................................1-2
Intendeduse................................................................................1-3
Electro-magneticcompatibility(EMC)......................................................1-5
Productidentication.......................................................................1-6
Componentidentication..................................................................1-10
2SAFETYINFORMATION
Safetyrules.................................................................................2-1
Ecologyandtheenvironment..............................................................2-8
Handsignals................................................................................2-9
Safetysigns...............................................................................2-16
3CONTROLSANDINSTRUMENTS
ACCESSTOOPERATOR'SPLATFORM
Accesstooperator'splatform..........................................................3-1
OPERATOR'SSEAT
Operator'sseat.........................................................................3-4
FORWARDCONTROLS
Frontcontrols...........................................................................3-5
Pedalcontrols..........................................................................3-7
Transmissioncontrols..................................................................3-9
RIGHT-HANDSIDECONTROLS
Righthandsidecontrols...............................................................3-12
INSTRUMENTCLUSTER
Instrumentcluster-Front..............................................................3-14
Instrumentclusterpanel–Side.......................................................3-15
Instrumentcluster.....................................................................3-16
Heating,Ventilation,AirConditioning(HVAC)controls................................3-18
CABCONTROLSANDADJUSTMENTS
Cabandplatform-controlidentication...............................................3-19
LOADERATTACHMENTCONTROLS
Loaderattachmentcontrols...........................................................3-21
Loaderattachment–Operation.......................................................3-22

BACKHOEATTACHMENTCONTROLS
Booms,dippers,andbuckets-Controlidentication..................................3-27
STABILIZERMECHANICALCONTROLS
Left-handstabilizerleft-handcontrollever............................................3-30
Right-handstabilizerright-handcontrollever.........................................3-31
Sliderframecontrolpedal.............................................................3-32
4OPERATINGINSTRUCTIONS
COMMISSIONINGTHEUNIT
Commissioningthemachine...........................................................4-1
Operatingthemachine.................................................................4-2
Roadoperation.........................................................................4-3
Jobsiteoperation.......................................................................4-4
STARTINGTHEUNIT
Startingtheengine.....................................................................4-5
Assistedstarting(Jump-starting).......................................................4-6
Startingtheengine-Atlowtemperatures..............................................4-7
STOPPINGTHEUNIT
Stoppingtheengine....................................................................4-8
MOVINGTHEUNIT
Movingtheunit.........................................................................4-9
2WDor4WD..........................................................................4-11
PARKINGTHEUNIT
Parkingtheunit........................................................................4-12
5TRANSPORTOPERATIONS
ROADTRANSPORT
Requirementsforroadtravel...........................................................5-1
Precautionsforroadtravel.............................................................5-2
PREPARINGFORROADTRANSPORT
Preparingthemachineforroadtravel..................................................5-3
Settingthebackhoeattachmentinroadtravelposition................................5-6
Lockingorunlockingthebackhoeattachment.........................................5-8
SHIPPINGTRANSPORT
Machinetransport(onatrailer).........................................................5-9

RECOVERYTRANSPORT
Towingthemachine...................................................................5-10
6WORKINGOPERATIONS
GENERALINFORMATION
Operatingthemachineincoldweather................................................6-1
Operatingthemachineinhighaltitude.................................................6-2
Operatingthemachineinhightemperatures...........................................6-3
Operatingthemachineinwater........................................................6-4
Liftingthemachine.....................................................................6-5
LOADERATTACHMENT
Organizingthejobsite..............................................................6-6
Transmissiondisconnectbutton....................................................6-7
Operatingtheloaderattachment...................................................6-8
Loaderattachmentsafetystrut....................................................6-11
Loaderbucket–Removal........................................................6-12
Loaderbucket–Install............................................................6-13
BACKHOEATTACHMENT
Backhoeattachment...............................................................6-14
Settingthebackhoeattachmentinworkingposition..............................6-15
Operatingthebackhoeattachment................................................6-16
Fillingthebackhoebucket.........................................................6-17
Movingthemachineforwardswhenworking......................................6-18
Trenching..........................................................................6-19
BackhoebucketRemove..........................................................6-21
BackhoebucketInstall............................................................6-22
Backhoebucket–Diggingangle..................................................6-23
7MAINTENANCE
GENERALINFORMATION
Fluidsandlubricants...................................................................7-1
Fuel.....................................................................................7-2
Fuelstorage............................................................................7-3
Fueltank................................................................................7-4
Hydraulicoil............................................................................7-5
Hydraulicoiltank.......................................................................7-6
Engineoilviscosity.....................................................................7-7
Safetyinstructions......................................................................7-8
Machinesafety.........................................................................7-9
Workhoursandintervals..............................................................7-10
MAINTENANCECHART
MaintenanceChart....................................................................7-11
EVERY10HOURS
Servicebrake..........................................................................7-11

Parkingbrake..........................................................................7-12
Fusesandlamps......................................................................7-13
Functionalityofcontrolsandlamps....................................................7-15
Drivebelts-Check....................................................................7-16
Engineoillevel-Check...............................................................7-17
Transmissionoillevel-Check.........................................................7-18
Enginecoolantlevel-Check..........................................................7-19
Hydraulicoillevel-Check.............................................................7-20
Fueltanklevel-Check–Level.......................................................7-21
RestrictionIndicator–Check..........................................................7-22
Greasepoints–Lubricate.............................................................7-23
FIRST50HOURS
Engineoilandoillter–Change......................................................7-25
Fan/alternatorbelttension...........................................................7-27
Batteryelectrolytelevel-Check.......................................................7-28
EVERY100HOURS
Wheelsre-torque......................................................................7-29
Hydraulicsystembreather-Clean....................................................7-30
Batterycheck..........................................................................7-31
Frontaxlebreather(4WDOnly)-Clean...............................................7-32
Waterseparatordrain.................................................................7-33
Rearaxledifferentialoil-Check.......................................................7-34
Engineandcabinmountingboltsre-torque...........................................7-35
Frontaxlehuboillevel(4WDonly)–Check..........................................7-36
EVERY250HOURS
Stabilizerwearpadsadjust............................................................7-37
EVERY500HOURS
Engineoilandoillter–Change......................................................7-39
Mudlter-Change....................................................................7-41
Fuellter-Change....................................................................7-42
EVERY1000HOURS
Powershuttletransmission–oilchange...............................................7-43
Transmissionoillter-Replace.......................................................7-44
Transmissionsuctionstrainer-Cleaning..............................................7-45
Hydraulicoillter-Replace...........................................................7-46
Frontaxlehuboil(4WDOnly)-Replace..............................................7-47
Rearaxlehuboil-Replace............................................................7-48
Frontaxledifferentialoil(4WDOnly)-Replace.......................................7-49
Rearaxledifferentialoil-Replace.....................................................7-50
Frontaxle-Hubgreasing2WD.......................................................7-51

EVERY1200HOURS
Checkthefuelinjector.................................................................7-53
EVERY2000HOURS
Brakeoil-Replace....................................................................7-53
Hydraulicoil-Replace................................................................7-54
Enginecoolant-Replace..............................................................7-55
Radiatorandoilcoolern-Cleaning..................................................7-57
ASREQUIRED
Engineairlter........................................................................7-58
Tirespressure-Check................................................................7-60
Radiator-Cleaning....................................................................7-62
Condenser-Cleaning.................................................................7-63
Pollenlter-Cleaning.................................................................7-64
STORAGE
Storingthemachine...............................................................7-65
Shorttermstorage.................................................................7-66
Storingtheengine.................................................................7-67
Batterystorage....................................................................7-68
Takingthemachinebacktoservice...............................................7-69
Removalfromstorage.............................................................7-70
8TROUBLESHOOTING
SYMPTOM(S)
Engine-Troubleshooting.......................................................8-1
Startermotor-Troubleshooting................................................8-3
Alternator-Troubleshooting....................................................8-4
Transmission-Troubleshooting................................................8-5
Axles-Troubleshooting........................................................8-7
SteeringSystem-Troubleshooting............................................8-10
Hydraulicsystems-Troubleshooting..........................................8-11
Loaderattachment-Troubleshooting.........................................8-12
Backhoeattachment-Troubleshooting.......................................8-13
Swing-Troubleshooting.......................................................8-14
Hydraulicpump-Troubleshooting.............................................8-15
Electricalsystems-Troubleshooting..........................................8-16
Heating,ventilation,airconditioning(HVAC)-Troubleshooting...............8-17
9SPECIFICATIONS
Specications...............................................................................9-1
Materialweights–Material...............................................................9-10
Torquechart–Metricnon-angedhardware.............................................9-11
Torquechart–Metricangedhardware..................................................9-12
Identication...............................................................................9-13

Torquechart–Inchnon-angedhardware...............................................9-14
Torquechart–Inchangedhardware....................................................9-15
Identication...............................................................................9-16
Unitsofmeasureandconversion.........................................................9-17
10ACCESSORIES
Loaderbucket.............................................................................10-1
Backhoebuckets..........................................................................10-5

1-GENERALINFORMATION
1-GENERALINFORMATION###_1_###
Foreword
Loaderbackhoes570Thasbeendesignedtoperform
mostoftheearth-movingoperations.Ifyouusethisma-
chinefordutiesinvolvingtheuseofattachments,acces-
sories,orspecialtools,consultyourCASEdealertomake
surethattheadaptationsormodicationscarriedoutare
inconformitywiththemachine’stechnicalspecications
andwithcurrentregulationsonsafety.Anymodications
oradaptationswhicharenotapprovedbythemanufac-
turermayinvalidatethemachine’soriginalconformitywith
safetyrequirements.
PTIL14TLB0009AA1
1-1

1-GENERALINFORMATION
NotetotheOwner
Readthismanualbeforeyoustarttheengineoroperatethemachine.Ifyouneedmoreinformation,contactyour
CASEDealer.
Thismanualcontainsimportantinformationaboutsafeoperation,adjustment,andmaintenanceofyourloaderback-
hoe.Thismanualisdividedintochaptersasoutlinedinthetableofcontents.Refertotheindexattheendofthis
manualforlocatingspecicitemsaboutyourmachine.Theloaderbackhoeconformstocurrentsafetyregulations.
Readthismanualcarefully,payingparticularattentiontotheinstructionsconcerningsafety,operationandmainte-
nancesoastoavoidtheriskofinjurywhileoperatingorservicingthemachine.
NOTE:Allpersonswhowillbeoperatingthismachineshallpossessavalidlocalvehicleoperatingpermitand/orother
applicablelocalageworkpermits.
Themachinehasbeendesignedandmanufacturedaccordingtothestrictestqualitystandards.However,therisk
ofaccidentscanneverbecompletelyexcluded.Thatiswhyitisessentialtoobserveelementarysafetyrulesand
precautions.DONOToperateorpermitanyonetooperateorservicethismachineuntilyouortheotherpersonshave
readandunderstandthesafety,operation,andmaintenanceinstructionsinthismanual.Useonlytrainedoperators
whohavedemonstratedtheabilitytooperateandservicethismachinecorrectlyandsafely.
Theinformationinthismanualisprovidedonthebasisofinformationthatwasavailableatthetimethatthemanual
wasprinted.Settings,procedures,partnumbers,software,andotheritemscanchange.Thesechangescanaffect
theservicethatisgiventothemachine.Ensurethatyouhavethecompleteandmostcurrentinformationfromyour
CASEDealerbeforeyoustartanymachineoperation.
TheOperator'sManualistobestoredinthemanualcompartmentequippedonthismachine.Makesurethismanual
iscompleteandingoodcondition.ConsultyourCASEDealertoobtainadditionalmanuals.
ContactyourCASEDealerforanyfurtherinformationorassistanceaboutyourmachine.YourCASEDealerhas
Companyapprovedserviceparts.YourCASEDealerhastechnicianswithspecialtrainingthatknowthebestmethods
ofrepairandmaintenanceforyourmachine.
1-2

1-GENERALINFORMATION
Intendeduse
Thismachinehasbeenbuiltwiththemostadvancedtechnologyandinaccordancewithrecognizedsafetyrules.The
machinemustbeusedaccordingtoitsintendeduseonly,respectingthesafety,precautionsandoperatinginstruc-
tions.Anyfunctionaldisorders,especiallythoseaffectingthesafetyofthemachine,shouldthereforeberectied
immediately.
WARNING
Avoidinjury!
Usingthemachineforpurposesotherthanorbeyondtheintendeduseisnotallowed;forexample:
-forthetransportationofpersons,
-asaworkingplatform,
-forpullingattachedloads,
-forpullingortransportingloadswithouttheintendedworkingequipment.
Failuretocomplycouldresultindeathorseriousinjury.W1142B
Themanufacturer/suppliercannotbeheldresponsibleforanydamageresultingfromunintendeduse.Theriskin-
volvedinsuchmisuseliesentirelywiththeuser.
NOTE:Forclarity,someguresinthismanualshowthemachinewithprotectionpanelsorcoversremoved.Never
operatethemachinewithanyprotectionpanelsorcoversremoved.
NOTICE:Itisabsolutelyforbiddentotamperwithand/orchangethesettingofanyofthehydraulicsystemvalvesto
avoiddamagingmachinecomponents,withaconsequentriskofpersonalsafety.
Thecurrentoperator’smanualistheuser’sguideforcorrectrun-in,useandmaintenanceofthemachine.Carefully
readthisoperator’smanualandstoreitinthecabforquickreference.Instructionsconcerningsafety,operationand
maintenancehavebeendevelopedtopermitsafeserviceandoperationofthismachine.
IntheeventofqueriesorsuggestionsrelevanttoyourmachinedonothesitatetoaddresstoyourCASEDealer.
CASEDealershavequaliedandtrainedpersonnelatdisposalalongwithoriginalspares,meansandequipment
suitabletocarryoutallnecessarymaintenance.
Anymodicationsoradaptationswhicharenotapprovedbythemanufacturermayinvalidatethemachine’soriginal
conformitywithsafetyrequirements.
NOTICE:Theengineandfuelsystemonyourmachinearedesignedandbuilttogovernmentemissionsstandards.
TamperingbyCASEDealers/customers/operators/usersarestrictlyprohibitedbylaw.Failuretocomplywiththis
prohibitioncouldresultingovernmentnes,reworkcharges,invalidwarranty,legalactionandpossibleconscation
ofthemachineuntilreworktooriginalconditioniscompleted.Engineserviceand/orrepairsmustbecarriedoutbya
certiedtechnicianonly.
Beforeentrustingthismachinetoanoperator,makesurethat:
•Theoperatorisqualiedtooperatethemachinecorrectlyandsafely.
•Theoperatorhasreadandcompletelyunderstoodtheinstructionsgiveninthismanual.
ConsultyourCASEDealertoobtainanyothertechnicalmanualsormanualsinotherlanguages.
YourCASEDealerisatyourdisposalforanyfurtherinformationyoumayneed.
Spareparts
The“non-genuine”sparepartshavenotbeencheckedandauthorizedbythemanufacturer.Theassemblyand/or
useofsuchproductsmayhavenegativeeffectsonthemachinedesignfeaturesandcouldimpairitsoperationsafety.
Themanufacturerisnotliableforanydamagecausedby“non-genuine”sparepartsoraccessories.
Warranty
Thewarrantyapplicableforeachmodel570TBackhoeLoadermanufacturedbyCaseNewHollandConstruction
Equipment(India)Pvt.Ltd.(thecompany)willbeasgivenunder:
1.Eachbackhoeloader(equipment)manufacturedbytheCompany/CASEDealershallbedevoidofdefectsin
materialandworkmanship.
1-3

1-GENERALINFORMATION
2.AllgoodswillbewarrantedagainstdefectivematerialandworkmanshipforaperiodofTwelvemonthsor2000h
ofoperation,whicheverisearlierfromthedateofcommissioning.
3.TheCompany's/CASEDealer'sliabilitywillbelimitedtotherepairorreplacementofthepartswhichareproved
defectivewithintheaforesaidwarrantyperiodinnormaloperation,properuseandservicewhenownedbythe
originalbuyeronly.
4.Thewarrantywillnotcoverelectricalitems,FMRadio,speakers,rubberitemssuchasdampers,seals,O-rings
andconsumablesliketoothpointsandlterelements.
5.Thewarrantywillnotcovernormalwearandtear,failuresduetoimproperoperation,poormaintenanceand/or
improperhandlingoftheequipment.
6.Thewarrantywillnotcoveranydamagescausedwhiletheequipmentisinstorageorundertransitduringthe
periodofthewarranty.
7.Theabovewarrantywillbe,ineachinstanceonthewarrantiesextendedtotheCompany/CASEDealerbyhis
suppliers,incaseofsuchbought-outitemsaselectricmotors,alternators,tires&tubesandbatteries.
8.UndernocircumstanceswhatsoevershalltheCompany/CASEDealerberesponsiblefordefectsinquality,Work-
manshiporperformancebeyondtheguaranteeofCompany's/CASEDealer'ssuppliersinrespectofsuchitems.
9.TheCompany's/CASEDealer'sliabilitywillbelimitedtotherepair/replacementofthedefectivePartsandwill
notcoveranydirectorindirectlossessufferedonthisaccountandnoclaimforconsequentialdamageswillbe
entertained.
10.Thewarrantyshallnotcoverthecostofremovaland/orrettingofanyPartstotheequipment.
11.Thewarrantyshallalsonotcovertheexpensesorpackingandfreightinconnectionwithreplacementmadeto
thebuyerandthecostforthesameshallbebornebythebuyer.
12.AllreplacementsuppliedunderthiswarrantywillbeonthebasisoftheCASEDealer'soption,subjecttoavail-
abilityofrequiredimportlicenseorcustomsclearancepermitwhereverapplicable.
13.AllpartsfoundtobedefectiveandreplacedbytheCompany/CASEDealershallbecomeitsproperty.Inevery
instance,itshallbethebuyer'sresponsibilitytosendthefailedpartsdulypackedtotheauthorizedCASEDealer
onfreightpaidbasis.Incaseofdefault,nowarrantyshallbepaidforthepartscoveredtherein.
14.ItshallbeobligatoryonthepartofthebuyertouseonlygenuineCaseNewHollandConstructionEquipment
spareparts,recommendedhydraulicoil,transmissionoil,greaseandlubricants,etc.further,itshallalsobe
obligatorytoassemblepartsinaccordancewiththeguidelinesgivenbytheCompany/CASEDealer.
15.Non-conformanceoftheaboveshallautomaticallyandirrevocablyvoidthewarranty.
16.PleaserefertotheauthorizedCASEDealerregardingfreeservicesavailable.Strictadherencetotheinstructions
giventhereinisnecessary.
17.NOWARRANTYisapplicableforaccidentsandfailurescausedduetonegligenceofthemachineoperator.
18.Thecompanyreservestherighttomakechangesindesignorimprovementsatanytimewithoutincurringany
obligationstoincorporatesuchchangesorimprovementsonmachinepreviouslysuppliedbythecompany.
NOTE:Eachmachineissuppliedcompletewithacopyofthismanual.Descriptionsandillustrationsprovidedherein
arenotbinding.Themanufacturer,providedthatthebasiccharacteristicsofmachinetypesdescribedandshown
inthismanualremainthesame,reservestherighttochangecomponents,partsandaccessoriessuppliedwithout
anycommitmenttotimelyupdatethispublication,andthisanytimeitdeemsitconvenientforimprovementpurposes
orduetocommercialormanufacturingrequirements.Forexactinformation,pleaseconsultyourCASEDealeror
contactthemanufacturer’sbranchofces,whoremainatyourdisposalforfurtherhelp.
1-4

1-GENERALINFORMATION
Electro-magneticcompatibility(EMC)
Interferencemayariseasaresultofadd‐onequipmentthatmaynotnecessarilymeettherequiredstandards.As
suchinterferencecanresultinseriousmalfunctionoftheunitand/orcreateunsafesituations,youmustobserve
thefollowing:
•Themaximumpowerofemissionequipment(radio,telephones,etc.)mustnotexceedthelimitsimposedbythe
nationalauthoritiesofthecountrywhereyouusethemachine
•Theelectro‐magneticeldgeneratedbytheadd‐onsystemshouldnotexceed24V/matanytimeandatanylo-
cationintheproximityofelectroniccomponents
•Theadd‐onequipmentmustnotinterferewiththefunctioningoftheonboardelectronics
FailuretocomplywiththeseruleswillrendertheCASECONSTRUCTIONwarrantynullandvoid.
1-5

1-GENERALINFORMATION
Productidentication
VINplatelocation
TheVINplateislocatedontherighthandsideofthechas-
sisframe.
PTIL14TLB0010BA1
1-6

1-GENERALINFORMATION
Engineidenticationplate
Theengineidenticationplateisonthetappetcover.
PTIL12TLB0006BA2
Transmissionidenticationplate
Thetransmissionidenticationplateisontherighthand
sideoftheoilsump.
PTIL12TLB0007AA3
1-7

1-GENERALINFORMATION
Frontaxle(4WDifapplicable)identicationplate
Thefrontaxleidenticationplateislocatedonrighthand
sideofdifferential.
PTIL12TLB0009AA4
Rearaxleidenticationplate
Therearaxleidenticationplateislocatedonlefthand
sideofdifferential.
PTIL12TLB0010AA5
Compressoridenticationplate
Thecompressoridenticationplateislocatednearthetop
mountingpointofthecompressor.
PTIL14TLB0051AA6
1-8

1-GENERALINFORMATION
ROPSidenticationplate
TheROPSidenticationplateislocatedontherighthand
sideB-pillarofthecabin.
PTIL14TLB0052AA7
Operator'sManualstorageonthemachine
TheOperator’sManualshouldalwaysbeinthemachine.
Thereisaprovisionmadeonthebacksideoftheopera-
tor’sseattostorethemanual.Pressthelock(A)toopen
thestorageaccessdoor(1).
PTIL14TLB0049AB8
Machineorientation
Theorientationisexplainedconsideringthattheoperator
isfacingthesteeringwheel.
1.Front
2.Rear
3.Right
4.Left
PTIL12TLB0003AB9
1-9

1-GENERALINFORMATION
Componentidentication
PTIL14TLB0011GB1
1.Loaderbucket(withBDBiftted)8.Boom
2.Loaderarm9.Dipperarm
3.Frontwheelhub10.Backhoebucket(withextendahoeiftted)
4.Fueltank11.Stabilizer
5.Rearwheelhub12.Hydraulictank
6.Windshield13.Sideshiftframe
7.Enginehood
1-10

2-SAFETYINFORMATION
2-SAFETYINFORMATION###_2_###
Safetyrules
Throughoutthismanualandonmachinesafetysigns,youwillndthesignalwordsDANGER,WARNING,andCAU-
TIONfollowedbyspecialinstructions.Theseprecautionsareintendedforthepersonalsafetyofyouandthose
workingwithyou.
Readandunderstandallthesafetymessagesinthismanualbeforeyouoperateorservicethemachine.
DANGERindicatesahazardoussituationthat,ifnotavoided,willresultindeathorseriousinjury.Thecolor
associatedwithDANGERisRED.
WARNINGindicatesahazardoussituationthat,ifnotavoided,couldresultindeathorseriousinjury.Thecolor
associatedwithWARNINGisORANGE.
CAUTIONindicatesahazardoussituationthat,ifnotavoided,couldresultinminorormoderateinjury.Thecolor
associatedwithCAUTIONisYELLOW.
Failuretofollowdanger,warning,andcautionmessagescouldresultindeathorseriousinjury.
Machinesafety
NOTICE:Noticeindicatesasituationthat,ifnotavoided,couldresultinmachinedamageorpropertydamage.The
colorassociatedwithNoticeisBLUE.
ThroughoutthismanualyouwillndthesignalwordNoticefollowedbyspecialinstructionstopreventmachinedam-
ageorpropertydamage.ThewordNoticeisusedtoaddresspracticesnotrelatedtopersonalsafety.
Information
NOTE:Noteindicatesadditionalinformationthatclariessteps,procedures,orotherinformationinthismanual.
ThroughoutthismanualyouwillndthewordNotefollowedbyadditionalinformationaboutastep,procedure,or
otherinformationinthemanual.ThewordNoteisnotintendedtoaddresspersonalsafetyorpropertydamage.
Generalsafetyrules
Usecautionwhenyouoperatethemachineonslopes.Raisedequipment,fulltanksandotherloadswillchangethe
centerofgravityofthemachine.Themachinecantiporrolloverwhennearditchesandembankmentsoruneven
surfaces.
Neverpermitanyoneotherthantheoperatortorideonthemachine.
Neveroperatethemachineundertheinuenceofalcoholordrugs,orwhileyouareotherwiseimpaired.
Whendiggingorusingground-engagingattachments,beawareofburiedcables.Contactlocalutilitiestodetermine
thelocationsofservices.
Payattentiontooverheadpowerlinesandhangingobstacles.Highvoltagelinesmayrequiresignicantclearance
forsafety.
Hydraulicoilordieselfuelleakingunderpressurecanpenetratetheskin,causingseriousinjuryorinfection.
•DONOTuseyourhandtocheckforleaks.Useapieceofcardboardorpaper.
•Stoptheengine,removethekey,andrelievethepressurebeforeyouconnectordisconnectuidlines.
•Makesurethatallcomponentsareingoodcondition.Tightenallconnectionsbeforeyoustarttheengineorpres-
surizethesystem.
•Ifhydraulicuidordieselfuelpenetratestheskin,seekmedicalattentionimmediately.
•Continuouslongtermcontactwithhydraulicuidmaycauseskincancer.Avoidlongtermcontactandwashthe
skinpromptlywithsoapandwater.
2-1

2-SAFETYINFORMATION
Keepclearofmovingparts.Looseclothing,jewelry,watches,longhair,andotherlooseorhangingitemscanbecome
entangledinmovingparts.
Wearprotectiveequipmentwhenappropriate.
DONOTattempttoremovematerialfromanypartofthemachinewhileitisbeingoperatedorwhilecomponentsare
inmotion.
Makesurethatallguardsandshieldsareingoodconditionandproperlyinstalledbeforeyouoperatethemachine.
Neveroperatethemachinewithshieldsremoved.Alwayscloseaccessdoorsorpanelsbeforeyouoperatethema-
chine.
Dirtyorslipperysteps,ladders,walkways,andplatformscancausefalls.Makesurethesesurfacesremaincleanand
clearofdebris.
Apersonorpetwithintheoperatingareaofamachinecanbestruckorcrushedbythemachineoritsequipment.DO
NOTallowanyonetoentertheworkarea.
Raisedequipmentand/orloadscanfallunexpectedlyandcrushpersonsunderneath.Neverallowanyonetoenter
theareaunderneathraisedequipmentduringoperation.
Neveroperatetheengineinenclosedspacesasharmfulexhaustgasesmaybuildup.
Beforeyoustartthemachine,besurethatallcontrolsareinneutralorparklockposition.
Starttheengineonlyfromtheoperator’sseat.Ifyoubypassthesafetystartswitch,theenginecanstartwiththe
transmissioningear.Donotconnectorshortacrossterminalsonthestartersolenoid.Attachjumpercablesas
describedinthemanual.Startingingearmaycausedeathorseriousinjury.
Alwayskeepwindows,mirrors,alllighting,andSlow-MovingVehicle(SMV)emblemcleantoprovidethebestpossible
visibilitywhileyouoperatethemachine.
Operatecontrolsonlywhenseatedintheoperator’sseat,exceptforthosecontrolsexpresslyintendedforusefrom
otherlocations.
Beforeyouleavethemachine:
1.Parkthemachineonarm,levelsurface.
2.Putallcontrolsinneutralorparklockposition.
3.Engagetheparkingbrake.Usewheelchocksifrequired.
4.Lowerallhydraulicequipment-Implements,header,etc.
5.Turnofftheengineandremovethekey.
When,duetoexceptionalcircumstances,youwoulddecidetokeeptheenginerunningafteryouleavethe
operator’sstation,thenyoumustfollowtheseprecautions:
1.Bringtheenginetolowidlespeed.
2.Disengagealldrivesystems.
3.WARNING
Somecomponentsmaycontinuetorundownafterdisengagingdrivesystems.
Makesurealldrivesystemsarefullydisengaged.
Failuretocomplycouldresultindeathorseriousinjury.W0113A
Shiftthetransmissionintoneutral.
4.Applytheparkingbrake.
Generalmaintenancesafety
Keeptheareausedforservicingthemachinecleananddry.Cleanupspilleduids.
Servicethemachineonarm,levelsurface.
2-2
