Casio EV-2500C Troubleshooting guide

R
(without price)
EV-2500C/I/N (KX-618C/I/N)
JUL. 1995
INDEX

— 1 —
CONTENTS
SPECIFICATIONS ......................................................................................... 2
BLOCK DIAGRAM ........................................................................................ 3
CIRCUIT DESCRIPTION ............................................................................... 4
DISASSEMBLY ............................................................................................. 5
DIAL STRINGING DIAGRAM........................................................................ 6
ADJUSTMENT............................................................................................... 7
TROUBLESHOOTING................................................................................. 12
PRINTED CIRCUIT BOARDS ..................................................................... 13
EXPLODED VIEW ....................................................................................... 15
ELECTRICAL PARTS LIST......................................................................... 16
MECHANICAL PARTS LIST ....................................................................... 23
IC AND TRANSISTOR LEAD IDENTIFICATION ........................................ 25
SCHEMATIC DIAGRAMS ........................................................................... 27
WAVEFORMS.............................................................................................. 29

— 2 —
SPECIFICATIONS
Item Specification
1. Reception channels TV— EV-2500C/N: VHF: 2 ~ 12 ch UHF: 21 ~ 69 ch
EV-2500I : VHF: A ~ H2 ch UHF: 21 ~ 69 ch
RADIO— FM: 88~108 MHz AM: 530~1710 KHz
2. Power voltage DC 6.0 V
3. Power consumption Approx. 3.5 W
4. Current consumption Approx. 580 mA
5. Battery life (with alkaline batteries) Approx. 11 hours
Batteries : 3 D size batteries
6. Power supply Car adaptor : CA-K65
AC adaptor : AD-K65, 64
Earphone jack : 3.5ø mini
7. Connection terminals External power jack : 6.0 V DC IN
External antennea jack : 3.5ø mini
Audio / Video jack : 3.5ø
8. Screen size 2.5 inches
9. No. of picture element 61,380 (220 ×279) dots
10. Dimensions 115 (W) ×61.7 (D) ×112 (H) mm
4 1/2(W) ×2 2/5(D) ×4 2/5(H)
11. Weight 360 g excepting batteries
12.7 oz excepting batteries
AC adaptor : AD-K65,64
12. Options Car adaptor : CA-K65
RF connector : CF-13
Antenna matching device : AS-35S

— 3 —
BLOCK DIAGRAM
TV
1— Color tuner: TU200 TEPU5-02
Selects a desired radio wave and changes it to the video IF signal.
2— Video IF amp.: Q200 2SC4238
Amplifies the video IF signal output from tuner TU200 by 10 times (20 dB).
3— Video det./Sound det./FM det./AFT/AGC: IC200 M51348FP
EliminatesthecarrierwaveinthevideoIFsignal,andpicksupthevideosignalandthesoundIFsignal.
Also, the sound signal is picked up from the sound IF signal by FM detection.
4— Audio amp.: IC600 NJM2070M
Sound amplification.
5— Chroma circuit: IC300 IR3P90Y
Generates the tricolor (red, green, and blue) from the video signal.
6— Display control/Auto-tuning control: IC700 MSM6770GS
Controls the display.
7— Tuning voltage generator: IC270 BA10358F
Generates the tuning voltage with the tuning pulse output from 6.
Antenna
1 TU200 2 Q200 3 IC200
7
Tuning
Voltage
Generator
VR600
Volume
Control
4 IC600 Speaker
IC300
IC700
LCD
Chroma
Circuit
Display
Control
Auto-Tuning
Control
5
6
VCC1 (4.5 ± 0.05 V)
VCC2 (4.5 ± 0.05 V)
VCC7 (25.9 ~ 31.3 V)
VCC6 (10.0 ~ 12.0 V)
VEE1 (–8.0 ~ –7.0 V)
VEE2 (–18.4 ~ –16.0 V)
IC270
Power
Supply
Audio
Amp.
IF Amp.Tuner
Video
Sound Det.
FM
AFT Circuit
AGC Circuit
Det

— 4 —
CP105
R108
270K
R110
270
Q110 2SD1819A-R
Q111
2SD1119-R
C137
R107
D100
MA141K 33K B6800p
C140
CH470p R115
100
6.3 V 220C100
D110
MA3051-L
2.2
BH102K
TM100
Q101
2SD1819A-R
2.2KR113
R105
3.3K
VR100
2K
C105
C145
B1500p
CP106
1
2
9
6
3
4
5
6
7
8
T100
LC12U-35 D158 MA143A R160
68
C146 OPEN
D156 MA141K
D154 MA142WK
D150
MA142WK
D152
MA142WK
L101
100u
CP110
CP111
CP113
CP114
CP115
C110 25 V 10 C112
10SL6R8M
C114 6SL 15M C116 6.3 V 100 C118 16 V 22 C120 35 V 22 R161 33K
VEE2 (-18.4 ~ -16.0 V)
L102
100u
R100
0R00
GND
CP112
1
2
3
VEE1 (-8.0 ~ -7.0 V)
VCC2-1 (4.5 V)
VCC6 (10.0 ~ 12.0 V)
VCC7 (25.9 ~ 31.3 V)
VCC2-2 (4.5 V)
VCC2-3 (4.5 V)
Figure 1
CIRCUIT DESCRIPTION
Name Voltage Function
VCC2-1 4.50 ±0.02 V Main voltage
VCC7 25.9 ~ 31.3 V Tuning voltage
VCC6 10.0 ~ 12.0 V Display voltage
VEE1 –8.0 ~ –7.0 V Display voltage
VEE2 –18.4 ~ –16.0 V Display voltage
Table 1
The power supply consists of a DC-DC converter and the associated circuit and supplies the voltages as shown
in Table 1.
POWER SUPPLY

— 5 —
DISASSEMBLY
1. Remove the battery case.
2. Remove the three screws and the lower case.
3. Remove the three knobs.
4. Remove the screw and resolder the two wires for the speaker.
5. Remove the PCB ass'y.

— 6 —
DIAL STRINGING DIAGRAM
92
10
3
8
4
A5
7
6
Turn the pulley counterclockwise.
Wrap around 4 times.
0.8 mm
Sliding pointer

— 7 —
ADJUSTMENT
TV
Items to Be Adjusted
Item Measuring Instrument
VCC2-1 voltage setting Voltmeter
Video detection coil adjustment TV signal generator, pattern generator, oscilloscope,
low-pass filter
AFT coil adjustment Sweep generator, oscilloscope, voltmeter
Contrast adjustment TV signal generator, pattern generator, oscilloscope
Tint adjustment TV signal generator, pattern generator, oscilloscope
AGC adjustment TV signal generator, pattern generator, IF levelmeter
Vcom adjustment Photo diode, photo sensor amp., bandpass filter, oscilloscope
Free-Running frequency adjustment Frequency counter
RADIO
When the radio is defect, replace the radio PCB unit.
Adjustment and Test Point Locations
Top View
VR100
VR303
T200
T201 VR200
T300
VR300
VR740

— 8 —
VCC2-1 Voltage Setting
Input Input Input Output Output
Connection Point Signal Connection Point
Adjust Result
Adjust to obtain a 4.50 ±0.02 V
reading on the voltmeter.
Voltmeter
VR100 TP1
TP1
16-169
Equipment Connection / Adjustment Procedure
Output
Voltmeter
EV-2500
set
Bottom View
TP7 (CP208)
TP2 (CP201)
TP4 (CP217)
TP3 (CP218)
TP1 (CP113)
TP8 (CP334)
TP5 (CP339)
TP6 (CP322)
IF Pad

— 9 —
Video Detection Coil Adjustment
TP2 VR300 TP5
Oscilloscope
* Desolder the IF pad to open.
Contrast Adjustment
TP2 T201 TP4
Adjust to obtain a 1.4 ±0.2 V
reading on the voltmeter.
Confirm that the marker is at
the middle of the S-curve on
the oscilloscope.
* Desolder the IF pad to open.
AFT Coil Adjustment
Pattern
generator
Signal
generator
TP2 T200 TP3
Input Input Input Output Output
Connection Point Signal Connection Point
Adjust Result
* Desolder the IF pad to open.
Voltmeter
Oscilloscope
Sweep
generator
Pattern
generator Signal generator
Input
TP2
CP312 (KILLER)
Oscilloscope
EV-2500
set 10 kohm
Adjust so
that the step
form wave
becomes 2.8
±0.1 Vp-p.
Adjust to obtain the minimum
DC level.
Low-pass filter
Oscilloscope
Input
TP2
EV-2500
set
Output
TP3
Low-pass
filter
Pattern
generator Signal generator Oscilloscope
Sweep
generator EV-2500
set
Input
TP2 Output TP4
Voltmeter
Oscilloscope
Color bar
38.9 MHz
(EV-200C,I,N)
39.5 MHz
(EV-200D)
45 ±3 dBµ
38.9 ±5 MHz
(sweep) marker:
38.9 MHz (EV-200C,I,N)
39.5 ±5 MHz
(sweep) marker:
39.5 MHz (EV-200D)
70 ±3 dBµ
Output
TP5(VC)
Color bar
38.9 MHz
(EV-200C,I,N)
39.5 MHz
(EV-200D)
70 ±3 dBµ
Pattern
generator
Signal
generator
TP1
2.8 ± 0.1 V
P.P

— 10 —
* Desolder the IF pad to open.
BCC Adjustment
Signal
generator
Pattern
generator EV-2500 set Oscilloscope
Input
TP2 Output TP5(VC)
Input Input Input Output Output
Connection Point Signal Connection Point
Adjust Result
Pattern
generator
Signal
generator TP2 T300 Oscilloscope TP5
Adjust T300 so that the
difference
between pulses
A and B is less
than 0.1 V.
AGC Adjustment
Signal
generator
Pattern
generator EV-2500 set IF levelmeter
Input
TP7 Output TP2
* Short the IF pad.
Pattern
generator
TV signal
generator TP7 VR200 IF levelmeter TP2
Color bar
65 ±5 dBµAdjust to obtain a 84 ±2 dBµ
reading on the IF levelmeter.
Vcom Adjustment
EV-2500
set Oscilloscope
Output
TP8
Color bar
38.9 MHz
(EV-200C,I,N)
39.5 MHz
(EV-200D)
70 ±3 dBµ
5.0 ± 0.5 V
-0.5 ± 0.25 V
VR303 Oscilloscope TP8
Adjust VR303 so that the
high level of the square wave
is at -0.5
±0.25 V.
Pulse BPulse A

— 11 —
Vcom Adjustment
* Place a photo diode on the middle of the display plate.
EV-2500
set Photo
diode
ON
OFF
H
M
L
AV-C1
Audio/Video jack
Bandpass
filter
Oscilloscope
Photo sensor amp.
Adjust to obtain the minimum
ripple.
VR303 Photo sensor
amp.
Bandpass filter
Oscilloscope
Free-Running Frequency Adjustment
Frequency
counter
VR740 TP6
Output
TP6
Adjust to obtain a reading of
15.625 ±0.1 kHz.
Adjust Result
Input Input Input Output Output
Connection Point Signal Connection Point
EV-2500
set Frequency
counter

— 12 —
TROUBLESHOOTING
TV
Picture OK but
no sound
Symptom Cause Solution
No power supply Defective power switch (SW100). Replace.
Defective DC-DC converter (T100). Replace.
Defective tuner (TU200). Replace.
Defective Q200. Replace.
Defective IC200. Replace.
Defective IC300. Replace.
Defective IC270. Replace.
Defective IC700. Replace.
Defective F201. Replace.
Defective IC200. Replace.
Defective IC600. Replace.
Defective phone jack (JK600). Replace.
Defective tuner (TU200). Replace.
Defective IC270. Replace.
Defective power switch (SW100). Replace.
No reception of
VHF or UHF
No picture and
no sound
RADIO
When the radio is defect, replace the radio PCB unit.

— 13 —
C202
C207 C205
F200
C208
R739
R715
R741
R731
R706
R704
C771
R740
Q760
R716
C746
C751
C773
Q710
R776 R749
R611
R610
R602
C635
R775
C710
C630
R606
R607
R601
R323
R325
Q950
Q951
R951
C512
R950
C930
D156
R160
C146
D154
D158
C145
R110
C137
C105
Q101
C181
Q111
Q110
R115 C140
R107
D100
VR100
R100
TM100
R105
R645 R390
C330
C265
C201
R242
R243
L303
R391
Q390
R392
R301
R330
R300
R326
R328
R515
R535
Q510
Q513
R321
R322
VR303
R318
R327
C327
C324
R316
R312
C319
R320 R319 R317 R315
R310
C306
C314
Q516
R246
L203
C246
C250
R226
R240
R274
T200
T201
TU200
R223
R239
R227
R224
R238
R225
R222
C259
R236
VR200
C247
R214
C511
Q515
L750
L740
C772
618C - L - A
F203
C510
H300
FU100
T300
C310
R302
R309
R305
L300
L302
VR300
C326
C535 C536
R500 C532
L500
C531
D500
R501
R537
D520
C791
R770 C793
C792
L790
C750
L760
L761
C744
R717
C257
R229
R230
R210
C770
VR740
C631
R600
R108
D110
O
B
C304
C340
PRINTED CIRCUIT BOARDS
TV
Top view

— 14 —
CP704
JK200
CP209
SW702
C530
SW700
SW701
CP207
C230
CP208
CP206
CP205
C234
Q201
CP210
R280
R759
CP707 1
CP705
R707
CP703
CN700
CP791
CP790
R771
L204
R276
1
Q272
R275
IC270
C270
C200
R272 R271
C233
R202
C231 CP204
CP203
C232
R209
CP201
CP202
R201
C236C237
Q200
C240
C239
L200 R205
R203
HP200
R211
R212
R204
R241 CP223
C262
C245
C271
C263
C264
C261
CP217 R729
CP726
C760
CP725
CP718
CP724
CP
719
IC200
C243
R208
L201
C242
C248
CP214
CP218 R728
IC700
CP741
R705
CP750
1
R756
CP751
L756
IC701
C770
C781 R760
C725
C210
R732
R734
R737
R733
R736
R738
C774
R750
R751
IC600
C600
CP900
CP700
R757
C788
CP756
CP701
CP792
R701
R703
C786 C787
VR600
VR304
CN900
T950
L950
C925
C603
C606
CP110
CP113
CP111
CP115
L102
D510
D511
C116
C118
C120
L101
C114
C110
D152
R113
T100
C100
CP101
D150
CP106
R161
CP112
CP114
C112
CP105
D180
C329 CP300
C305
C308
JK600
JK100
C390
C342
CP734
C300 C301 C302 C303 C307 R303 R306 C309 R307
JK300
CN510
C339
CP100
C185
SW102
CP102
SW100
HP100
C331
C334
CP334
CP335
C325
CP337
C332
C336
C322 C328
CP327
C335
CP339 C321
CP307
CP310
1
IC300
C317
C315
C312 L301
C320 C318
R311
C313
C311
CP322 CP341
F202
CP213
C249
SW101
R247
R516 L202
Q512
R512R513
R514 Q202
Q750
R270
Q270
R207
C790 R758
CP793
CP706
R727
R761
C927
F201
GY
Q511
Q514
1
R329
R331
C341
TV
Bottom view

— 15 —
EXPLODED VIEW
1
2 3 3
3
348
4
49
13
15
14
56
16
17
49
50
5
47
77
6
10
11
12
47
8
9
6
23
22 50
7
10
24
25-6
25-5
19
48
25
48
25-2
25-1
25-3 25-4
33-2 33
33-1
34
35 48
28
18
21
51
49
27
33-3
26-2
26-1
26
51
26-3
26-4
26-7
26-6
26-5
28-1
28-2
28-3
28-4 31
34 32
28-3
28-2
28-3
30
51
52
39
38
37
36
54 53
43
48 42
41
40
44
45
46
55

ELECTRICAL PARTS LIST
Linear PCB No. 1 FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
Capacitors
C100 2800 9175 Electrolytic capacitor (V) 6.3RC2-220MS 1 20 C
C105 2897 2310 Chip capacitor GR42-6Y5V225Z16PT 1 20 C
C110 2806 9462 Electrolytic capacitor (V) 25RC2-10MS-G10 1 20 C
N C112 2845 5901 OS capacitor 10SL6R8M 1 10 C
C114 2845 5502 OS capacitor 6SL15M 1 10 C
C116 2805 2499 Electrolytic capacitor (V) 6.3RC2-100MS 1 20 C
C118 2828 5542 Electrolytic capacitor (V) 16RC2-22MS 1 20 C
C120 2805 2481 Electrolytic capacitor (V) 35RC2-22MS 1 20 C
C137 2897 0189 Chip capacitor GR40W5R682K50PT 1 20 C
C140 2892 0865 Chip capacitor GR40CH471J50PT 1 20 C
C145 2897 0252 Chip capacitor GR40W5R152K50PT 1 20 C
C181 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C185 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C200 2845 5488 Chip capacitor UMK316B104K-T 1 20 C
C201 2895 0133 Chip tantalum capacitor ECST1EY474R 1 20 C
C202 2800 9182 Electrolytic capacitor 6.3RC2-47MS 1 20 C
C205 2806 9455 Electrolytic capacitor (V) 50RC2-2R2-G9 1 20 C
C207 2845 1596 OS capacitor 6SC15M 1 10 C
C208 2806 9399 Electrolytic capacitor (V) 6.3RC2-47MS-G10 1 20 C
C210 2804 9234 Electrolytic capacitor (V) 16RC310 1 20 C
C230 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C232 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C233 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C234 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C236 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C237 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C239 2897 0245 Chip capacitor GR40CH180J50PT 1 20 C
C240 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C243 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C245 2892 0083 Chip capacitor GR40W5R103K50PT 1 20 C
C246 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C249 2892 0844 Chip capacitor GR42-6Y5V474Z16PT 1 20 C
C250 2892 0237 Chip capacitor GR40W5R222K50PT 1 20 C
C257 2892 0407 Chip capacitor GR40CH270J50PT 1 20 C
C259 2892 0083 Chip capacitor GR40W5R103K50PT 1 20 C
C261 2892 0890 Chip capacitor GR40PH560J50PT 1 20 C
C262 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C263 2892 0890 Chip capacitor GR40PH560J50PT 1 20 C
C264 2892 0474 Chip capacitor GR40CH010C50PT 1 20 C
C265 2892 0237 Chip capacitor GR40W5R222K50PT 1 20 C
C270 2892 0083 Chip capacitor GR40W5R103K50PT 1 20 C
C271 2897 0175 Chip capacitor GR40Y5V473Z50PT 1 20 C
C301 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C302 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C303 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C304 2897 0749 Chip capacitor GR40W5R561K50PT 1 20 C
C305 2800 9182 Electrolytic capacitor 6.3RC2-47MS 1 20 C
C307 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C308 2804 9064 Electrolytic capacitor (V) 16RC2-10 1 20 C
C310 2895 0126 Tantalum capacitor ECST1CY105R 1 20 C
Notes: N – New parts
M – Minimum order/supply quantity
Q – Quantity used per unit
R – Rank — 16 —

Linear PCB No. 2 FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
C311 2892 0407 Chip capacitor GR40CH270J50PT 1 20 C
C312 2892 0237 Chip capacitor GR40W5R222K50PT 1 20 C
C313 2897 0217 Chip capacitor GR40W5R153K25PT 1 20 C
C314 2895 0126 Tantalum capacitor ECST1CY105R 1 20 C
C315 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C317 2892 0300 Chip capacitor GR40CH470J50PT 1 20 C
C318 2892 0105 Chip capacitor GR40CH080D50PT 1 20 C
C319 2897 0525 Chip capacitor GR40CH151J50PT 1 20 C
C320 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C321 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C322 2897 0175 Chip capacitor GR40Y5V473Z50PT 1 20 C
C325 2897 0350 Chip capacitor GR40CH160J50PT 1 20 C
C326 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C327 2892 0844 Chip capacitor GR42-6Y5V474Z16PT 1 20 C
C328 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
N C329 2845 5901 OS capacitor 10SL6R8M 1 10 C
C331 2828 5516 Electrolytic capacitor (V) 16RC2-47MS 1 20 C
C332 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
N C334 2806 9511 Chip capacitor 25RC2-4R7MS 1 20 C
C335 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C336 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C339 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C390 2806 9448 Electrolytic capacitor (V) 6.3RC2BP-22 1 20 C
C510 2806 9469 Electrolytic capacitor (V) 6.3RC2-100MS-G10 1 20 C
C530 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C531 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C532 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C535 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C536 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C600 2828 5542 Electrolytic capacitor (V) 16RC2-22MS 1 20 C
C603 2805 2499 Electrolytic capacitor (V) 6.3RC2-100MS 1 20 C
C606 2805 2499 Electrolytic capacitor (V) 6.3RC2-100MS 1 20 C
C630 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C631 2897 0504 Chip capacitor GR40W5R272K50PT 1 20 C
C635 2892 0016 Chip capacitor GR40W5R102K50PT 1 20 C
C710 2895 1897 Tantalum capacitor ECST1DY335R 1 20 C
C725 2897 2177 Chip capacitor TMK316B224K-T 1 20 C
C746 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C750 2892 0040 Chip capacitor GR40Y5V104Z25PT 1 20 C
C751 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C760 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C770 2897 2310 Chip capacitor GR42-6Y5V225Z16PT 1 20 C
C771 2892 0237 Chip capacitor GR40W5R222K50PT 1 20 C
C772 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C773 2897 2310 Chip capacitor GR42-6Y5V225Z16PT 1 20 C
C774 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C781 2897 0112 Chip capacitor GR40W5R562K50PT 1 20 C
C786 2845 5670 Chip capacitor UMK212UJ120J-T 1 20 C
C787 2845 5670 Chip capacitor UMK212UJ120J-T 1 20 C
C788 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C790 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C791 2892 0059 Chip capacitor GR40Y5V103Z50PT 1 20 C
C925 2825 0441 TF capacitor ECQ-V1H473JL 1 20 C
Notes: N – New parts
M – Minimum order/supply quantity
Q – Quantity used per unit
R – Rank — 17 —

Linear PCB No. 3 FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
C927 2813 3213 Ceramic capacitor DE0405SL270J2K 1 20 C
Connectors
CN510 3501 9331 Connector 5512-05A 1 10 C
CN700 3501 8316 Connector 52559-2090 1 5 C
CN900 3501 1001 Connector W-P7503#11 1 20 C
Diodes
D100 2390 1701 Chip diode MA141K-(TX) 1 20 C
D110 2315 0158 Chip zener diode MA3051-L(TX) 1 10 C
D150 2390 1183 Chip diode MA142WK-(TX) 1 20 C
D152 2390 1183 Chip diode MA142WK-(TX) 1 20 C
D154 2390 1183 Chip diode MA142WK-(TX) 1 20 C
D156 2390 1701 Chip diode MA141K-(TX) 1 20 C
D158 2390 1470 Chip diode MA143A-(TX) 1 20 C
D180 2390 1190 Chip diode ERA15-01Y 1 20 C
D500 2390 2289 Chip diode MA558-(TX) 1 10 C
D510 2370 1134 LED SLB-22MG3FJ 1 20 C
D511 2370 1127 LED SLB-22DU3FH 1 20 C
D520 2390 1183 Chip diode MA142WK-(TX) 1 20 C
Filters
F200 3025 0189 SAW filter SAF38.9MZ60Z 1 1 C
F201 3025 0728 SIF filter SFSL5.5MDB12 1 10 C
F202 3851 1148 Ceramic discriminator CDSL5.5MC30B12 1 10 C
F203 3850 1372 SIF trap TPS5.5MB 1 10 C
Fuse
FU100 3632 0469 Fuse PI-251001(F10) 1 10 C
Oscillator
H300 2590 0252 Crystal oscillator NR-18C 1 1 C
ICs
IC200 2114 1827 Linear IC M51348FP-T1 1 1 B
IC270 2116 0119 OP AMP BA10358F-T1 1 10 C
IC300 2114 3479 Linear IC IR3P96-1 1 1 B
IC600 2114 3689 IC NJM2070D 1 5 B
IC700 2011 8337 LSI MSM6770GS-VK-675-F 1 1 B
IC701 2114 3458 IC S-81230SG-QB-T1 1 10 C
Jacks
JK100 3501 6755 Jack HEC3600-010120 1 10 C
JK200 3501 9324 Jack HSJ1501-010020 1 5 C
JK300 3501 3773 Jack HSJ6063-01-410 1 5 C
JK600 3501 5439 Jack HSJ1456-01-210 1 20 C
Inductors and Coil
L101 3840 2374 Inductor EL0405SKI-101K-2 1 10 C
L102 3840 2374 Inductor EL0405SKI-101K-2 1 10 C
L200 3013 1393 Chip inductor LK2125-R82K-TP 1 20 C
L202 3013 1904 Chip inductor LK2125-150K-TP 1 20 C
L203 2792 0110 Chip jumper ERJ-6GEY0R00V 1 20 C
L204 3013 0868 Chip inductor BLM21A05PT 1 20 C
L300 3013 1092 Chip inductor NLC322522-470K-TP 1 20 C
L301 3013 1204 Chip inductor MLF2012C330K-TP 1 20 C
L302 3013 1092 Chip inductor NLC322522-470K-TP 1 20 C
L303 3013 1092 Chip inductor NLC322522-470K-TP 1 20 C
L500 3013 1897 Chip inductor LK2125-R56K-TP 1 20 C
L740 3013 1043 Chip inductor NLC322522-101K-TP 1 20 C
L750 3013 1043 Chip inductor NLC322522-101K-TP 1 20 C
Notes: N – New parts
M – Minimum order/supply quantity
Q – Quantity used per unit
R – Rank — 18 —

Linear PCB No. 4 FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
L756 3013 1911 Chip inductor LK2125-330K-TP 1 20 C
L760 3013 1848 Chip inductor BK2125HS601-T 1 20 C
L761 3013 1848 Chip inductor BK2125HS601-T 1 20 C
L790 3013 1848 Chip inductor BK2125HS601-T 1 20 C
L950 3013 0756 Choke coil RCH-875-101K 1 5 C
Lamp
N LA900 3851 1596 Fluorescent lamp HMES48B25W64C-X 11 C
Transistors
Q101 2253 0133 Chip transistor 2SD1819A-R(TX) 1 20 C
Q110 2253 0133 Chip transistor 2SD1819A-R(TX) 1 20 C
Q111 2253 0308 Chip transistor 2SD1119-R(TX) 1 10 C
Q200 2252 0707 Chip transistor 2SC4238-(TX) 1 20 C
Q201 2259 1645 Digital transistor DTA144EUWT106 1 20 C
Q202 2259 1645 Digital transistor DTA144EUWT106 1 20 C
Q270 2259 1435 Digital transistor DTC144EUWT106 1 20 C
Q272 2259 1834 Digital transistor DTA143TUWT106 1 20 C
Q390 2251 0189 Chip transistor 2SB1218A-R(TX) 1 20 C
Q510 2259 1645 Digital transistor DTA144EUWT106 1 20 C
Q511 2259 2142 Digital transistor DTA123EUWT106 1 20 C
Q512 2253 0133 Chip transistor 2SD1819A-R(TX) 1 20 C
Q513 2253 0133 Chip transistor 2SD1819A-R(TX) 1 20 C
Q514 2210 8026 Chip transistor 2SB709A-R(TX) 1 20 C
Q516 2259 1631 Digital transistor DTA114TUWT106 1 20 C
Q710 2253 0133 Chip transistor 2SD1819A-R(TX) 1 20 C
Q750 2251 0189 Chip transistor 2SB1218A-R(TX) 1 20 C
Q760 2251 0189 Chip transistor 2SB1218A-R(TX) 1 20 C
Q950 2253 0308 Chip transistor 2SD1119-R(TX) 1 10 C
Q951 2253 0308 Chip transistor 2SD1119-R(TX) 1 10 C
Resistors
R100 2792 0110 Chip jumper ERJ-6GEY0R00V 1 20 C
R105 2791 0742 Chip resistor ERJ-6GEYJ332V 1 20 C
R107 2791 0607 Chip resistor ERJ-6GEYJ333V 1 20 C
R108 2791 1919 Chip resistor ERJ-6GEYJ274V 1 20 C
R110 2791 1131 Chip resistor ERJ-6GEYJ271V 1 20 C
R113 2791 0720 Chip resistor ERJ-6GEYJ222V 1 20 C
R115 2791 0572 Chip resistor ERJ-6GEYJ101V 1 20 C
R160 2791 1692 Chip resistor ERJ-6GEYJ680V 1 20 C
R161 2791 0607 Chip resistor ERJ-6GEYJ333V 1 20 C
R201 2791 2117 Chip resistor ERJ-6GEYJ820V 1 20 C
R202 2791 2095 Chip resistor ERJ-6GEYJ682V 1 20 C
R203 2791 0720 Chip resistor ERJ-6GEYJ222V 1 20 C
R204 2791 0831 Chip resistor ERJ-6GEYJ681V 1 20 C
R205 2791 0688 Chip resistor ERJ-6GEYJ220V 1 20 C
R207 2791 1161 Chip resistor ERJ-6GEYJ151V 1 20 C
R208 2791 0734 Chip resistor ERJ-6GEYJ272V 1 20 C
R209 2791 0313 Chip resistor ERJ-6GEYJ103V 1 20 C
R210 2791 0305 Chip resistor ERJ-6GEYJ472V 1 20 C
R211 2791 0777 Chip resistor ERJ-6GEYJ104V 1 20 C
R212 2791 0720 Chip resistor ERJ-6GEYJ222V 1 20 C
R214 2791 1390 Chip resistor ERJ-6GEYJ473V 1 20 C
R222 2791 0696 Chip resistor ERJ-6GEYJ470V 1 20 C
R223 2791 2044 Chip resistor ERJ-6GEYJ124V 1 20 C
R224 2791 2176 Chip resistor ERJ-6GEYJ471V 1 20 C
Notes: N – New parts
M – Minimum order/supply quantity
Q – Quantity used per unit
R – Rank — 19 —
