Casio 2353 Configuration guide

Module No. 2353 2353-1
GENERAL GUIDE
•Press BB
BB
Bto change from mode to mode.
•Some models have a white-on-black display.
•The watch automatically reverts to the Timekeeping Mode if you do not perform any operation in the Data Bank Mode for a few minutes.
•Holding down BB
BB
Bfor a few seconds in any mode returns to the Timekeeping Mode. When you return to the Timekeeping Mode or World Time
Mode, the display contents (timekeeping or calendar) are
the same as what they were when you last exited the mode.
World Time Mode
Timekeeping Mode
Event Reminder Mode
Data Bank Mode Stopwatch Mode
Press AA
AA
A.
TIMEKEEPING MODE
The Home Time indicator appears on the display in the Timekeeping Mode.
Timekeeping Calendar
•Press AA
AA
Ato toggle the lower display between the time (hour, minutes, seconds) and
date (day of the week, month, day).
•Your Home Time city code momentarily appears on the display whenever you enter
the Timekeeping Mode from another mode.
•Pressing CC
CC
Cin the Timekeeping Mode displays your Home Time city code and home
time for about one second.
To set the time and date
1.While in the Timekeeping Mode, hold down AA
AA
Auntil the city code flashes on the
display.
2.Press BB
BB
Bto move the selection (flashing) around the display in the following se-
quence.
City Code DST ON/OFF Seconds
YearMonth
Hour Minutes
12/24-hour format
Day
3.While the seconds setting is selected (flashing), press CC
CC
Cto reset it to 00. If you
press CC
CC
Cwhile the seconds setting is in the range of 30 to 59, the seconds are reset
to 00 and 1 is added to the minutes. If the seconds setting is in the range of 00 to
29, the minutes count is unchanged.
•While the 12H/24H setting is flashing, press CC
CC
Cto toggle between 12-hour and 24-
hour timekeeping.
•While the DST ON/OFF setting is flashing, press CC
CC
Cto toggle daylight saving time
(summer time) on and off.
•While the city code is flashing, press CC
CC
Cto scroll through the available city codes to
select one as your Home Time city.
•While any other setting is selected (flashing), press CC
CC
Cto increase it.
•Holding down CC
CC
Cchanges the setting at high speed.
4.After you set the time and date, press AA
AA
Ato return to the Timekeeping Mode.
•The day of the week is automatically set in accordance with the date.
•The date can be set within the range of January 1, 1995 to December 31, 2039.
•If you do not press any button for a few minutes while a setting is flashing, the
flashing stops and the watch goes back to the Timekeeping Mode automatically.
To set the hands
Pull the crown out. Set the hands by turning the crown in either direction. Push the
crown in on a time signal.
Press AA
AA
A.
Crown
Analog display
Seconds
Hour : Minutes
PM indicator
Home time
indicator
Digital display
Day of week
Month - Day
Month - Day
City Code Search
In the World Time Mode, press CC
CC
Cto scroll through the available city codes. Holding
down CC
CC
Cscrolls at high speed.
•Pressing AA
AA
Ain the World Time Mode displays the current date (day of the week,
month, day) in the currently displayed city code city. The world time indicator also
appears while the date is displayed. Pressing AA
AA
Aagain returns to the city code and
time display.
Selecting Daylight Saving Time (Summer Time)
In the World Time Mode, hold down AA
AA
Afor a few seconds to toggle between daylight
saving time (summer time) and standard time. The DST indicator is on the display
while daylight saving time is turned on.
•The DST setting you make is applied to all World Time Mode cities. You cannot
make separate settings for each city code.
•Note that the display also switches between the current time and current date dis-
play when you hold down AA
AA
Ato change the daylight saving time setting. After mak-
ing your setting, press AA
AA
Aagain to display the information (time or date) you want.
WORLD TIME MODE
The World Time Mode lets you view the current time in any one of 27 time zones (40
cities) around the world.
•You cannot change the time setting in the World Time Mode. The time setting you
make in the Timekeeping Mode is used to calculate the times in the World Time
zones. For daylight saving time (summer time), you must make separate settings
for the Timekeeping Mode and World Time Mode.
•The seconds count in the World Time Mode is synchronized with the count in the
Timekeeping Mode.
•The 12-hour/24-hour format setting you make in the Timekeeping Mode is applied
to all the times in the World Time Mode.
•See the CITY CODE TABLE for information about city names and GMT differen-
tials.
Press AA
AA
A.
Day of weekWorld time indicatorDST on indicator
EVENT REMINDER MODE
The Event Reminder Mode lets you store up to 10 reminders of past events, each
containing the date (year, month, day) and time (hour, minutes) the event occurred,
and city code that was selected when the event occurred. You can use this feature to
record the date, time, and location (city code) of events as they happen, such as the
start and end of a meeting, how long it takes to drive from one location to another,
etc.
City code
Hour : Minutes
Alternates at
1-second intervals.
Year
Data No.
Month - Day
•The 12-hour/24-hour time format for the Event Reminder Mode is the same as the
one you select in the Timekeeping Mode.
Recording an Event Reminder
In the Timekeeping Mode, hold down CC
CC
Cfor a few seconds until the display flashes.
•The first event you record is stored as Record 1. When you record a second event,
it is stored as Record 1 and the previous event shifts to Record 2. Records are
shifted each time you input a new one. This means that the newest event is always
Record 1. If you have 10 records stored in memory, the oldest one is Record E
(END).
•You can have up to 10 event records in memory at one time. Recording an eleventh
record causes the oldest record in memory (Record E) to be deleted and the other
remaining records to be shifted to make room for the new one.
Viewing Records in Event Reminder Memory
In the Event Reminder Mode, press CC
CC
Cto scroll through records, starting with the
newest one (Record 1).
•Holding down CC
CC
Cscrolls through records at high speed.
•The date of the record, alternates with its city code and time on the display in one-
second intervals.
Deleting an Event Reminder Record
1.Use CC
CC
Cto display the record you want to delete.
2.Hold down AA
AA
Afor a few seconds until CLR stops flashing on the display.
•Releasing AA
AA
Awhile CLR is still flashing cancels the delete procedure without delet-
ing anything.
•The remaining records are shifted accordingly and Record 1 appears after the record
is deleted.

2353-2
DATA BANK MODE
The Data Bank Mode lets you store up to 10 records (data
No.: 1~E), each containing a text of up to 24 characters.
The watch automatically reverts to the Timekeeping Mode
if you leave it in the Data Bank Mode without performing
any operation for a few minutes.
•When you enter the Data Bank Mode, the first record
that appears is the one that was on the display the last
time you exited the mode.
Inputting Data
1.Use CC
CC
Cto scroll to an empty record or to an existing
record whose data you want to replace.
2.Hold down AA
AA
Afor a few seconds until the first data char-
acter starts to flash.
3.Press CC
CC
Cto scroll through characters at the flashing lo-
cation. Holding down CC
CC
Cscrolls at high speed.
•The following shows the scroll cycle when CC
CC
Cis pressed.
(Space) A to Z 0 to 9
•Note that there is no way to back scroll. This means that if you accidentally go past
the character you want, you have to go through the entire forward scroll cycle to get
back to it.
4.When the character you want is displayed, press BB
BB
Bto advance to the next posi-
tion.
•Repeat steps 3 and 4 as many times as necessary to input all of the text.
5.After inputting the text you want, press AA
AA
Ato store it.
•The watch automatically cancels the input operation and returns to the Data Bank
Mode screen if you do not input anything for a few minutes.
Searching for Data Bank Mode Data
In the Data Bank Mode, press CC
CC
Cto scroll through data. Holding down CC
CC
Cscrolls at
high speed.
•When the data text has more than three characters, the text scrolls from right to left
on the screen. The end of the text data is indicated by the symbol .
•Pressing AA
AA
Apauses the right-to-left scrolling of the Data Bank Mode data. Press AA
AA
A
again to resume scrolling.
Editing Data
1.In the Data Bank Mode, use CC
CC
Cto display the record whose data you want to edit.
2.Hold down AA
AA
Afor a few seconds until the first data character starts to flash.
3.Use BB
BB
Bto move the flashing to a character you want to change.
4.Use CC
CC
Cto scroll through available characters until the one you want is displayed.
•Repeat steps 3 and 4 to make the rest of the corrections you want.
5.After everything is the way you want, press AA
AA
Ato store the new data.
Deleting Data Bank Mode Data
1.In the Data Bank Mode, use CC
CC
Cto display the record whose data you want to delete.
2.Hold down AA
AA
Afor a few seconds until the first data character starts to flash.
3.Hold down BB
BB
Band CC
CC
Cat the same time until CLR appears on the screen, indicating
that the data is deleted.
•At this point you could input new data if you want.
4.Press AA
AA
Ato return to Data Bank Mode screen.
Data No.
Data
Elapsed time measurement
Start Stop Re-start Stop Clear
Start Split Split release Stop Clear
Start Split Stop Split release Clear
Split time measurement
Split time and 1st-2nd place times
First runner
finishes. Second runner finishes.
Record time of
first runner.
Record time of
second runner.
STOPWATCH MODE
The Stopwatch Mode lets you measure elapsed time, split
times, and two finishes. The range of the stopwatch is 59
minutes, 59.99 seconds.
1/100 second
Minutes
Seconds
CITY CODE TABLE
GMT City City Other major cities in same time zone
differential Code
–11 PPG PAGO PAGO
–10 HNL HONOLULU PAPEETE
–09 ANC ANCHORAGE NOME
YVR VANCOUVER LAS VEGAS, SEATTLE, DAWSON CITY
–08 SFO
SAN FRANCISCO
LAX LOS ANGELES
–07 DEN DENVER EL PASO, EDMONTON
–06 MEX MEXICO CITY HOUSTON, DALLAS/FORT WORTH,
CHI CHICAGO NEW ORLEANS, WINNIPEG
–05 MIA MIAMI MONTREAL, DETROIT, BOSTON, LIMA,
NYC NEW YORK PANAMA CITY, HAVANA, BOGOTA
–04 CCS CARACAS LA PAZ, SANTIAGO, PORT OF SPAIN
–03 RIO
RIO DE JANEIRO
SAO PAULO, BUENOS AIRES, BRASILIA,
MONTEVIDEO
+00 LON LONDON DUBLIN, LISBON, CASABLANCA,
DAKAR, ABIDJAN
PAR PARIS MADRID, AMSTERDAM, ALGIERS,
+01 MIL MILAN HAMBURG, FRANKFURT, VIENNA,
ROM ROME STOCKHOLM
BER BERLIN
IST ISTANBUL ATHENS, HELSINKI, BEIRUT,
+02 CAI CAIRO DAMASCUS, CAPE TOWN
JRS JERUSALEM
+03 JED JEDDAH MOSCOW, KUWAIT, RIYADH, ADEN,
ADDIS ABABA, NAIROBI
+3.5 THR TEHRAN SHIRAZ
+04 DXB DUBAI ABU DHABI, MUSCAT
+4.5 KBL KABUL
+05 KHI KARACHI
MLE MALE
+5.5 DEL DELHI MUMBAI, CALCUTTA
+06 DAC DHAKA COLOMBO
+6.5 RGN YANGON
+07 BKK BANGKOK JAKARTA, PHNOM PENH, HANOI,
VIENTIANE
+08 SIN SINGAPORE KUALA LUMPUR, BEIJING, TAIPEI,
HKG HONG KONG MANILA, PERTH, ULAANBAATAR
+09 SEL SEOUL PYONGYANG
TYO TOKYO
+9.5 ADL ADELAIDE DARWIN
+10 GUM GUAM MELBOURNE, RABAUL
SYD SYDNEY
+11 NOU NOUMEA PORT VILA
+12 WLG WELLINGTON CHRISTCHURCH, NADI, NAURU ISLAND
* Based on data as of June 1999.
