Operation Guide 3075
MA0607-EA
About This Manual
•Button operations are indicated using the letters shown
in the illustration.
(Light)
Timekeeping Mode Countdown Alarm Mode Stopwatch Mode Alarm Mode Dual Time Mode
Press .
General Guide
•Press Cto change from mode to mode.
•After you perform an operation in any mode, pressing Creturns to the Timekeeping
Mode.
•If you do not press any button for a few minutes while making settings in any mode
(indicated when settings are flashing), the watch automatically clears the setting
screen (settings stop flashing) and returns to the normal display for the mode you
are in.
•This watch returns to the Timekeeping Mode whenever you hold down the Cbutton
for one or two seconds. If you ever lose track of what mode you are in or what you
should do next, hold down Cto return to normal timekeeping.
•In any mode press Lto illuminate the display.
Seconds
Mode indicator
1/10 second
Timekeeping Mode time
Minutes
Day of week
PM indicator
Month – Day
Vibration
alarm
on indicator
Hour : Minutes Seconds
Timekeeping Mode
To set the time and date
1. Hold down Bwhile in the Timekeeping Mode until the
seconds digits flash on the display because they are
selected.
2. Press Cto change the selection in the following
sequence.
Seconds
Day
Minutes
12/24-Hour Format
Hour
Day of the week Month
3. While the seconds digits are selected (flashing), press Dto reset the seconds to
00. If you press Dwhile the seconds count is in the range of 30 to 59, the seconds
are reset to 00 and 1 is added to the minutes. If the seconds count is in the range
of 00 to 29, the minutes count is unchanged.
4. While any other digits (beside seconds) are selected (flashing), press Dto
increase the number or Ato decrease it. While the 12/24-hour format setting is
selected, press Dor Ato toggle it between 12 and 24. While the day of the week
is selected (flashing), press Dto advance to the next day or Ato return to the
previous day.
•Except for when adjusting the seconds or setting the 12/24-hour format, holding
down a button changes the current selection at high speed.
•When the 12-hour format is selected, the indicator Pappears on the display to
indicate “P.M.” times. There is no indicator for “A.M.” times.
•When the 24-hour format is selected, the indicator 24 appears on the display.
5. After you set the time and date, press Bto return to the Timekeeping Mode.
Illumination
In any mode, press Lto illuminate the display for about two seconds.
•Illumination may be hard to see when viewed under direct sunlight.
•Illumination turns off automatically whenever an alarm sounds.
•Frequent use of illumination runs down the battery.
About the Vibration Alarm
When the Vibration Alarm is turned on, the watch vibrates instead of sounding an
alarm. This lets you use the watch without disturbing others by beeping sounds.
•The Vibration Alarm can be used to replace alarm sounds in the Countdown Alarm,
Stopwatch, and Alarm Modes. The Vibration Alarm ON/OFF setting is applied to all
modes. You cannot make different settings for each mode.
•All explanations in this manual use expressions such as “sounds the alarm” for
alarm operations. When the Vibration Alarm is turned on, these expressions should
be understood to mean “causes the watch to vibrate”.
•Watches with a metal band may produce a noise when a vibration operation is
performed. This is due to vibration of the metal band, and does not indicate
malfunction of the watch.
Countdown Alarm Mode
The countdown alarm can be set within a range of 1
second to 24 hours. When the countdown reaches zero,
an alarm sounds for 10 seconds or until you press any
button.
To set the countdown start time
1. Hold down Bwhile in the Countdown Alarm Mode. The
hours digits flash on the display because they are
selected.
2. Press Cto change the selection in the following
sequence.
Hour Minutes Seconds
3. Press Dto increase the selected number or Ato decrease it. Holding down either
button changes the selection at high speed.
•Press Dand Aat the same time to clear the starting time to 0:00' 00".
•To set the starting value of the countdown time to 24 hours, set 0:00' 00".
4. After you set the countdown start time, press Btwice to return to the Countdown
Alarm Mode.
To use the countdown alarm
1. Press Dwhile in the Countdown Alarm Mode to start the countdown alarm.
2. Press Dagain to stop the countdown alarm.
•You can resume countdown alarm operation by pressing D.
3. Stop the countdown alarm and then press Ato reset the countdown time to its
starting value.
•When the end of the countdown is reached and auto repeat timing is off, the alarm
sounds for 10 seconds or until you stop the alarm by pressing any button.
Countdown timing stops and the countdown time is automatically reset to its starting
value after the alarm stops.
To turn auto repeat timing, the progress indicator and vibration alarm ON/OFF
1. Hold down Bwhile in the Countdown Alarm Mode. The
hours digits flash on the display because they are
selected. Press Bagain to move the flashing to the
auto repeat ON/OFF setting, which is indicated by the
auto repeat on indicator flashing on the display.
2. Press Dor Ato toggle auto repeat on and off.
3. Press Cto move the flashing to the progress indicator
ON/OFF setting, which is indicated by the progress
indicator flashing on the display.
4. Press Dor Ato toggle the progress indicator on and
off.
•Note that the progress indicator appears regardless of
whether you are using the audible alarm tone or
vibrator. Steps 5 and 6 below control whether an
alarm operation produces an audible tone or vibration.
5. Press Cto move the flashing to the vibration alarm
ON/OFF setting, which is indicated by the vibration
alarm on indicator flashing on the display.
6. Press Dor Ato toggle the vibration alarm on and off.
7. Press Bto return to the Countdown Alarm Mode.
•When the end of the countdown is reached while auto repeat is on, the alarm
sounds, but the countdown restarts from the beginning without stopping. You can
stop the countdown by pressing Dand manually reset to the start time by pressing
A.
•If you set a starting time of 10 seconds or less and have auto repeat turned on, the
countdown alarm tone (which normally sounds for 10 seconds) sounds for only one
second.
•When the progress indicator is turned on, the watch beeps as the countdown time
passes the 10, 5, 4, 3, 2, and 1-minute marks, and the 50, 40, 30, 20, 10, 5, 4, 3, 2,
and 1-second marks.
Stopwatch Mode
The Stopwatch Mode lets you measure elapsed time, split
times, and two finishes. The range of the stopwatch is 23
hour, 59 minutes, 59.99 seconds. You can also have an
alarm sound when a target time is reached. The
Stopwatch Mode also features an Auto-Start function.
Seconds
1/100 second
Timekeeping Mode time
Minutes
Mode indicator
Progress indicator
Hours
Vibration alarm on indicator
Auto repeat
on indicator

2
Operation Guide 3075
To measure times with the stopwatch
(a) Elapsed time measurement
Start Stop Re-start Stop Clear
Start Split
(SPL displayed)
Split release Stop Clear
Start Split Stop Split release Clear
(b) Split time measurement
(c) Split time and 1st-2nd place times
First runner
finishes.
Second runner
finishes.
Record time of
first runner.
Record time of
second runner.
About the Auto-Start function
With the Auto-Start function, the watch performs a 5-second countdown. When the
countdown reaches zero, stopwatch operation starts automatically. During the final
three seconds of the countdown, a beeper sounds with each second.
To turn the Auto-Start function on and off
While the display is showing all zeros in the Stopwatch Mode, press Ato toggle it on
and off.
•The A.START indicator appears and 05 is shown while Auto-Start is turned on. The
A.START indicator is not shown and the display shows the Timekeeping Mode time
when Auto-Start is turned off.
About the Target Time function
With the Target Time function, an alarm sounds for 10 seconds whenever the time
being kept by the stopwatch reaches a target time you have preset.
To set the target time, to turn the target time on and off, and to turn the vibration
alarm on and off
1. While the display is showing all zeros in the Stopwatch
Mode, hold down B, and the hour digit of the target
time starts to flash because it is selected.
2. Press Cto change the selection in the following
sequence.
Hour Minutes Seconds
3. Press Dto increase the selected number or Ato
decrease it. Holding down either button changes the
selection at high speed.
•Press Dand Aat the same time to clear the setting
to 0:00' 00".
4. Press Bto move the flashing to the target time ON/
OFF setting, which is indicated by the target time on
indicator flashing on the display.
5. Press Dor Ato toggle the target time on and off.
•Note that the target time on indicator appears regardless of whether you are using
the audible alarm tone or vibrator. Steps 6 and 7 below control whether an alarm
operation produces an audible tone or vibration.
6. Press Cto move the flashing to the vibration alarm ON/OFF setting, which is
indicated by the vibration alarm on indicator flashing on the display.
7. Press Dor Ato toggle the vibration alarm on and off.
8. Press Bto return to the Stopwatch Mode.
Important!
The alarm will not sound if you do not turn on the target time.
•Press B, Cor Lto stop the alarm after it starts to sound.
Seconds
Minutes
Hours
Target time on indicator
Vibration alarm on indicator
Alarm Mode
When the Daily Alarm is turned on, an alarm operation
(20-second tone or 10-second vibration) is performed at
the preset time each day. Press any button to stop the
alarm after it starts to sound. When the Hourly Time
Signal is on, the watch beeps every hour on the hour.
To set the alarm time
1. Hold down Buntil the hour digits start to flash on the
display. The hour digits flash because they are
selected.
•This operation will switch the Daily Alarm on
automatically.
2. Press Cto change the selection in the following
sequence.
Hour Minutes
3. Press Dto increase the selected digits and Ato decrease them. Holding down
either button changes the selection at high speed.
•The format (12-hour and 24-hour) of the alarm time matches the format you select
for normal timekeeping.
•When setting the alarm time using the 12-hour format, take care to set the time
correctly as morning (no indicator) or afternoon (P).
4. After you set the alarm time, press Bto return to the Alarm Mode.
To turn the daily alarm on and off, to turn the Hourly Time Signal on and off, and
to turn the vibration alarm on and off
Press Awhile in the Alarm Mode to change the status in the following sequence.
Both ONHourly Time
Signal Only
Daily Alarm
Only
Both OFF
Daily Alarm
Only
Hourly Time
Signal Only
Vibration ON
(no sound)
Both ON
Dual Time Mode
The Dual Time Mode lets you keep track of the time in
another time zone. You can also select the timekeeping
format (12-hour or 24-hour) separately from the
Timekeeping Mode.
•In the Dual Time Mode, the seconds count is
synchronized with the seconds count of the
Timekeeping Mode.
•In the Dual Time Mode, press Ato toggle between the
12-hour and 24-hour formats.
Hour : Minutes Seconds
Mode indicator
Timekeeping Mode time
Timekeeping
Mode time
Alarm time
(Hour : Minutes)
Hourly time signal
on indicator
Alarm on indicator
Mode indicator
•The alarm on indicator (AL), the Hourly Time Signal on indicator (SIG) and vibration
on indicator (VIB) are shown on the display in all modes while these functions are
turned on.
To test the alarm sound
Hold down Awhile in the Alarm Mode to sound the alarm.
The Vibration Alarm is activated while the VIB is on the display. Otherwise, the
Vibration Alarm is not activated and an audible tone sounds for alarms.
•Note that pressing Aalso changes the alarm and the Hourly Time Signal ON/OFF
settings.
To set the Dual Time
1. Hold down Bwhile in the Dual Time Mode. The hour digits flash on the display
because they are selected.
2. Press Cto change the selection in the following sequence.
Hour Minutes
3. Press Dto increase the selected digits and Ato decrease them. Holding down
either button changes the selection at high speed.
4. After you set the time, press Bto return to the Dual Time Mode.
