Operation Guide 3794
MA0604-EA
About This Manual
•Depending on the model of your watch, display text
appears either as dark figures on a light background or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
•Button operations are indicated using the letters shown
in the illustration.
•Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
General Guide
•Press Bto change from mode to mode.
•In any mode (except when a setting screen is on the display), press Cto illuminate
the face of the watch.
Timekeeping Mode World Time Mode Stopwatch Mode Alarm Mode Hand Setting Mode
Press .
Timekeeping
Use the Timekeeping Mode to set and view a digital display of the current time and
date.
•All of the operations in this section are performed in the Timekeeping Mode, which
you enter by pressing B.
•In the Timekeeping Mode, you can press Ato change the display format as shown
below.
Seconds PM indicator
Day of the Week – Day Hour : Minutes
Digital Time and Date
When setting the digital time, you can also configure settings for summer time
(Daylight Saving Time or DST), your Home City code (the code for the city where you
normally use the watch), and the 12/24-hour format.
•This watch is preset with a number of city codes, each of which represents the time
zone where that city is located. When setting the digital time, it is important that you
select the correct city code for your Home City. If your location is not included in the
preset city codes, select the preset city code that is in the same time zone as your
location.
•Note that all of the times for the World Time Mode city codes are displayed in
accordance with the digital time and date settings you configure in the Timekeeping
Mode.
•After you correctly set your Home City time and date, you can set the watch up for
timekeeping with a different city code simply by changing the Home City code in the
Timekeeping Mode.
To set the digital time and date
1. In the Timekeeping Mode, hold down Cuntil the Home
City code starts to flash, which indicates the setting
screen.
•Though illumination will also turn on when you press
C, keep the button held down until Home City code
flashes.
2. Use Ato select the code you want.
•Make sure you select your Home City code before
changing any other setting.
•For full information on city codes, see the “City Code
Table”.
3. Press Bto move the flashing in the sequence shown below to select the other
settings.
SecondsDSTHome City Code
HourMinutesDay Month Year
12/24-Hour format
Screen To do this:
Change the Home City code
Toggle between Daylight Saving Time ( )
and Standard Time ( )
Toggle between 12-hour ( ) and 24-hour
() timekeeping
Reset the seconds to
Change the hour or minutes
Change the year
Change the month or day
Do this:
Press A(eastward).
Press A.
Press A(+).
4. When the setting you want to change is flashing, use Ato change it as described
below.
•See “Daylight Saving Time (DST) Setting”below for details about the DST setting.
5. Press Cto exit the setting screen.
•Resetting the seconds to while the current count is in the range of 30 to 59
causes the minutes to be increased by 1. In the range of 00 to 29, the seconds are
reset to without changing the minutes.
•With the 12-hour format, the P(PM) indicator appears on the display for times in the
range of noon to 11:59 p.m. and no indicator appears for times in the range of
midnight to 11:59 a.m.
•With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without
any indicator.
•The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all modes.
•The year can be set in the range of 2000 to 2099.
•The watch’s built-in full automatic calendar makes allowances for different month
lengths and leap years. Once you set the date, there should be no reason to change
it except after you have the watch’s batteries replaced.
•The day of the week is automatically displayed in accordance with the date (year,
month, and day) settings.
Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the digital time setting by one hour
from Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To toggle the Timekeeping Mode digital time between DST and Standard Time
1. In the Timekeeping Mode, hold down Cuntil the Home
City code setting start to flash, which indicates the setting
screen.
2. Press Bonce to display the DST setting screen.
3. Press Ato toggle between Daylight Saving Time (
displayed) and Standard Time ( displayed).
4. Press Cto exit the setting screen.
•The DST indicator appears to indicate that Daylight
Saving Time is turned on.
DST indicator
Analog Timekeeping
The analog time of this watch is synchronized with the digital time. The analog time
setting is adjusted automatically whenever you change the digital time.
Note
•The hands for the analog timepiece move to adjust to a new setting whenever any of
the following occurs.
When you change the digital time setting
When you change the Home City code and/or DST setting
•If the analog time does not match the digital time for any reason, use the procedure
described under “To adjust the analog time”to match the analog setting to the digital
setting.
•Whenever you need to adjust both the digital and the analog time settings manually,
make sure you adjust the digital setting first.
•Depending on how much the hands have to move in order to adjust to the digital
time, it may take some time before they stop moving.

2
Operation Guide 3794
To adjust the analog time
1. In the Timekeeping Mode, press Bfour times to enter
the Hand Setting Mode.
2. Hold down Cuntil the current digital time starts to
flash, which indicates the analog setting screen.
When you want to do this:
Move the hand setting forward
20 seconds
Move the hand setting a short way
forward at high speed
Move the hand setting a long way
forward at high speed
Perform this button operation:
•Press A.
•Hold down A.
•Release Awhen the hands reach the setting you
want.
•While holding down Ato move the hands at high
speed, press Bto lock the high-speed hand
movement.
•To stop the hand movement, press any button.
•Hand movement stops automatically if the hour hand
makes one full (12-hour) revolution or if a daily alarm
or Hourly Time Signal starts to sound.
3. Use Aand Bto adjust the analog setting as described below.
4. Press Cto exit the setting screen.
•The watch will automatically adjust the minute hand slightly to match its internal
second count when you exit the setting screen.
•To return to the Timekeeping Mode, press B.
City code
Current time for the
selected city code
World Time
World Time digitally displays the current time in 48 cities
(29 time zones) around the world.
•All of the operations in this section are performed in the
World Time Mode, which you enter by pressing B.
To view the time in another city
1. In the World Time Mode, press Ato display the
currently selected city code.
2. While the city code is displayed, press Ato scroll
eastwardly through the city codes.
•The city code is displayed for about one second, and
then it is replaced with the current time for that city
code.
•For full information about city codes, see the “City Code
Table”.
•If the current time shown for a city is wrong, it probably means there is a problem
with your Timekeeping Mode time and/or Home City code settings. Go to the
Timekeeping Mode and make the necessary adjustments.
To toggle a city code time between Standard Time and Daylight Saving Time
1. In the World Time Mode, use Ato display the city code
whose Standard Time/Daylight Saving Time setting you
want to change.
2. Hold down Cfor about three seconds to toggle
between Daylight Saving Time (DST indicator
displayed) and Standard Time (DST indicator not
displayed).
DST indicator
•Though illumination will also turn on when you press C, keep the button held down
to toggle between Daylight Saving Time and Standard Time.
•The DST indicator is on the display whenever you display a city code for which
Daylight Saving Time is turned on.
•Note that the DST/Standard Time setting affects only the currently displayed city
code. Other city codes are not affected.
•Note that you cannnot use the World Time Mode to change the DST setting of the
Home City code you currently have selected in the Timekeeping Mode. See “To
toggle the Timekeeping Mode digital time between DST and Standard Time”for
information about turning the Home City code DST setting on and off.
1/100 second
Minutes Seconds
Stopwatch
The stopwatch lets you measure elapsed time.
•The display range of the stopwatch is 59 minutes,
59.99 seconds.
•The stopwatch continues to run, restarting from zero
after it reaches its limit, until you stop it.
•The stopwatch measurement operation continues even
if you exit the Stopwatch Mode.
•All of the operations in this section are performed in the
Stopwatch Mode, which you enter by pressing B.
To measure times with the stopwatch
Elapsed Time
Start Stop Re-start Stop Clear
Hold down
Alarm on indicator
Alarm time
(Hour : Minutes)
Alarm
When the alarm is turned on, the alarm tone sounds when
the alarm time is reached.
You can turn on an Hourly Time Signal that causes the
watch to beep twice every hour on the hour.
•All of the operations in this section are performed in the
Alarm Mode, which you enter by pressing B.
To set an alarm time
1. In the Alarm Mode, hold down Cuntil the hour setting
of the alarm time starts to flash, which indicates the
setting screen.
•Though illumination will also turn on when you press
C, keep the button held down until the hour setting of
the alarm time flashes.
•This operation automatically turns on the alarm.
2. Press Bto move the flashing between the hour and
minute settings.
3. While a setting is flashing, use A(+) to change it.
•When setting the alarm time using the 12-hour format,
take care to set the time correctly as a.m. (no
indicator) or p.m. (Pindicator).
4. Press Cto exit the setting screen.
Alarm Operation
The alarm sounds at the preset time for about 10 seconds, regardless of the mode the
watch is in.
•To stop the alarm tone after it starts to sound, press any button.
To test the alarm
In the Alarm Mode, hold down Ato sound the alarm.
To turn the daily alarm and the Hourly Time Signal on and off
In the Alarm Mode, press Ato cycle through the settings shown below.
Dark figures on a light background
Alarm Off
Signal Off
Alarm On
Signal Off
Alarm Off
Signal On
Alarm On
Signal On
Light figures on a dark background
Alarm Off
Signal Off
Alarm On
Signal Off
Alarm Off
Signal On
Alarm On
Signal On
•The alarm on indicator and the Hourly Time Signal on indicator are shown on the
display in all modes while these functions are turned on.
Illumination
Two LEDs (light-emitting diodes) illuminate the face of the
watch for easy reading in the dark.
Illumination Precautions
•Illumination may be hard to see when viewed under
direct sunlight.
•Illumination automatically turns off whenever an alarm
sounds.
•Frequent use of illumination runs down the batteries.
To illuminate the face of the watch
In any mode (except when a setting screen is on the display), press Cto turn on
illumination.
•When turning on illumination, press Cand immediately release it. If you keep C
held down too long, either of the operations described below will be peformed.
If you hold down CC
CC
Cwhile in the Timekeeping Mode, Alarm Mode, or Hand
Setting Mode
The figures on the display will start to flash, which indicates the setting screen.
If this happens, press Cagain to exit the setting screen.
If you hold down CC
CC
Cwhile in the World Time Mode
The DST setting will toggle between Standard Time and Daylight Saving Time,
which will affect the current time setting.
If this happens, hold down Cagain to toggle setting back to its original setting (if
necessary).

3
Operation Guide 3794
MUTE indicator
Reference
This section contains more detailed and technical information about watch operation.
It also contains important precautions and notes about the various features and
functions of this watch.
Button Operation Tone
The button operation tone sounds any time you press one
of the watch’s buttons. You can turn the button operation
tone on or off as desired.
•Even if you turn off the button operation tone, the alarm,
and Hourly Time Signal all operate normally.
To turn the button operation tone on and off
In any mode (except when a setting screen is on the
display), hold down Bto toggle the button operation tone
on (MUTE indicator not displayed) and off (MUTE
indicator displayed).
•Since Cis also the mode change button, holding it down to turn the button
operation tone on or off also causes the watch’s current mode to change.
•The MUTE indicator is displayed in all modes when the button operation tone is
turned off.
Auto Return Features
•If you leave the watch in the Alarm Mode or Hand Setting Mode for two or three
minutes without performing any operation, it automatically changes to the
Timekeeping Mode.
•If you leave a screen with flashing digits on the display for two or three minutes
without performing any operation, the watch automatically saves any settings you
have made up to that point and exits the setting screen.
Scrolling
The Ais used in various modes and setting screens to scroll through data on the
display. In most cases, holding down the button during a scroll operation scrolls at
high speed.
Initial Screens
When you enter the World Time, the data you were viewing when you last exited the
mode appears first.
World Time
•The seconds count of the World Time is synchronized with the seconds count of the
Timekeeping Mode.
•All World Time Mode times are calculated from the current Home City time in the
Timekeeping Mode using UTC time differential values.
•The UTC differential is a value that indicates the time difference between a
reference point in Greenwich, England and the time zone where a city is located.
•The letters “UTC”is the abbreviation for “Coordinated Universal Time”, which is the
world-wide scientific standard of timekeeping. It is based upon carefully maintained
atomic (cesium) clocks that keep time accurately to within microseconds. Leap
seconds are added or subtracted as necessary to keep UTC in sync with the Earth’s
rotation.
City City UTC Other major cities in same time zone
Code Differential
Pago Pago
Honolulu
Anchorage
Vancouver
San Francisco
Los Angeles
Denver
Mexico City
Chicago
Miami
New York
Caracas
St. Johns
Rio De Janeiro
Praia
Lisbon
London
Barcelona
Paris
Milan
Rome
Berlin
Athens
Johannesburg
Istanbul
Cairo
Jerusalem
Moscow
Jeddah
Tehran
Dubai
Kabul
Karachi
Male
Delhi
Dhaka
Yangon
Bangkok
Singapore
Hong Kong
Beijing
Seoul
Tokyo
Adelaide
Guam
Sydney
Noumea
Wellington
–11.0
–10.0
–09.0
–08.0
–07.0
–06.0
–05.0
–04.0
–03.5
–03.0
–01.0
+00.0
+01.0
+02.0
+03.0
+03.5
+04.0
+04.5
+05.0
+05.5
+06.0
+06.5
+07.0
+08.0
+09.0
+09.5
+10.0
+11.0
+12.0
Papeete
Nome
Las Vegas, Seattle/Tacoma, Dawson City
El Paso, Edmonton
Winnipeg, Houston, Dallas/Fort Worth, New Orleans
Montreal, Detroit, Boston, Panama City, Havana, Lima,
Bogota
La Paz, Santiago, Port Of Spain
Sao Paulo, Buenos Aires, Brasilia, Montevideo
Dublin, Casablanca, Dakar, Abidjan
Amsterdam, Algiers, Hamburg, Frankfurt, Vienna,
Stockholm, Madrid
Helsinki, Beirut, Damascus, Cape Town
Kuwait, Riyadh, Aden, Addis Ababa, Nairobi
Shiraz
Abu Dhabi, Muscat
Mumbai, Kolkata
Colombo
Jakarta, Phnom Penh, Hanoi, Vientiane
Kuala Lumpur, Taipei, Manila, Perth, Ulaanbaatar
Pyongyang
Darwin
Melbourne, Rabaul
Port Vila
Christchurch, Nadi, Nauru Island
PPG
HNL
ANC
YVR
SFO
LAX
DEN
MEX
CHI
MIA
NYC
CCS
YYT
RIO
RAI
LIS
LON
BCN
PAR
MIL
ROM
BER
ATH
JNB
IST
CAI
JRS
MOW
JED
THR
DXB
KBL
KHI
MLE
DEL
DAC
RGN
BKK
SIN
HKG
BJS
SEL
TYO
ADL
GUM
SYD
NOU
WLG
*Based on data as of June 2005.
City Code Table
