RECHARGEABLE HEADLIGHT
HL-EL084RC
OK
NO!
ENG 1
WARNING!!!
• Be sure to direct the light beam downward so
approaching car or pedestrian are not dazzled.
• Before your trip, please make sure the light is firmly
mounted to the bracket and it lights up.
• Always pay attention to the remaining battery power
by checking the indicator periodically while using the
light.
CAUTION!
• Keep the light away from children.
•
Mounting the light unit too close to a wireless computer
may adversely affect the reading of the computer.
• In preparation for unexpected shutoff, we recommend
you carry a spare light.
• This product is water-resistant under normal daily
use and can be used in the rain. However, do not
intentionally submerge it in water.
• If the light unit or parts become dirty with mud, etc.,
clean with a soft cloth which is moistened with mild
soap. Never apply paint thinner, benzine or alcohol;
damage will result.
LITHIUM-ION BATTERIES
Cautions on recharging
• Avoid charging in direct sunlight or in a vehicle parked
under direct sunlight, and make sure to charge only
when the ambient temperature is between 41°F and
104 °F (5 and 40°C).
• Before charging, be sure that no dust or other foreign
objects are attached to the USB plug.
• Do not subject the light to vibrations while charging.
• Once charging is complete, be sure to disconnect the
USB plug.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable battery to
deteriorate faster.
Do not place the light inside a vehicle or near a heater.
• If the illumination time is significantly reduced even
after proper charging, the rechargeable battery may
be nearing the end of its service life. Dispose of the
battery as described in “Cautions for disposal”.
Cautions on storage
Cool and dry storage is recommended. For long period
storage, it is important to charge the battery 30 minutes
every 6 months.
Cautions for dispose
When disposing of the light unit, dispose of it
according to local regulations.
HOW TO CHARGE
2HOW TO MOUNT TO A BICYCLE
3
Light unit FlexTight™ bracket
(H-34N)
Before using the light, read this manual
thoroughly and keep it for future
reference.
USB cable
(MICRO USB)
2
1
1 2
1. Mount the bracket to the
handlebar. (Fig.2 – )
2. Insert the light unit into the
bracket until it clicks, and
adjust the beam angle. ( )
(*1)
3. To remove the light unit, pull it
forward while pressing down
on the release button ( , ).
* To readjust the beam angle,
loosen the dial and/or the
screw enough to move the
bracket, and firmly tighten
them after adjustment. (*2)
1
4
5 6
3
Before Initial Use
This unit is shipped with small charge to check the
light. Be sure to charge it before use, according to
the instructions “HOW TO CHARGE” and
“Cautions on recharging”.
CAUTION!:
• Be sure to tighten the dial by hand. If tightened too hard with a tool, the screw thread may be stripped.
• Check the dial and screw (*2) on the bracket periodically, to monitor for any loosening.
• If cutting the strap, be careful of injury from where the strap is cut. (*3)
Indicator
Approx. 4(1A) - 8 (0.5A) h
Charging
Steady
red light
Off Charging is
completed
Standard charging time
Charge jack cover
USB cable
To PC or USB battery charger
1. Connect the light unit to your PC or a commercial USB battery charger using the USB cable. (Fig.1 – ).
The indicator turns red and charging starts.
* When your PC is in sleep state, the unit cannot be charged.
* Use a USB battery charger of 500 mAh (USB2.0) or more.
2. Once charging is complete, disconnect the USB cable and securely attach the charge jack cover.
CAUTION!: Attach the charge jack cover securely to ensure waterproofness.
* Charging and lighting times are approximate values, and will vary by environmental and use conditions.
*3
1
2
2
3
3
Bracket
Dial
Strap Rubber pad
Release
button
Screw
*4 When turning the light on, it lights up in the mode that was used last time. (Mode memory function)
ONOFF
*4 Low
Daytime
HyperConstant
Flashing
High
High
Switch (Indicator)
Press
and hold
Press and hold
Click
Remaining battery capacity :
When the switch is illuminated in red, there is little remaining
battery power. Please charge as soon as possible.
SWITCH OPERATION
Design Pat. Pending
Copyright© 2019 CATEYE Co., Ltd.
HLEL084RC-190603 1
4
46
5
*2
*1
Switch
(Indicator)
*4
Click
Double-click
Double-click

5342730
USB cable
(MICRO USB)
5338827N
FlexTight™ bracket
(H-34N)
5342440
Center fork bracket
(CFB-100)
5341831N
Helmet mount
SPARE/OPTIONAL PARTS SPECIFICATIONS
Light source High-intensity LED x 1
Battery Li-ion 3.6 v 2200 mAh
Charge Micro USB plug
Operating time High : Approx. 2 hours
Low : Approx. 4 hours
Daytime HyperConstant : Approx. 6 hours
Flashing : Approx. 60 hours
* Average runtime at 68˚F (20˚C).
Standard charging time Approx. 4 (1A) – 8 (0.5A) hours
Temperature range Charging : 41˚F – 104˚F (5˚C – 40˚C)
Operating : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times
About 300 times (until the rated capacity drops to 70%)
Dimensions/weight 1-11/32” x 3-15/16” x 1-29/64” (34 x 100 x 37 mm)
/ 4.13 oz (117 g)
* The specifications and design are subject to change without notice.
LIMITED WARRANTY
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials and workmanship for a
period of 2 years from original purchase. If the product fails to work during normal use,
CatEye will repair or replace the defect at no charge. Service must be performed by CatEye
or an authorized retailer. To return the product, pack it carefully and enclose the warranty
certificate (proof of purchase) with instruction for repair. Please write or type your name
and address clearly on the warranty certificate. Insurance, handling and transportation
charges to CatEye shall be borne by person desiring service.
For UK and REPUBLIC OF IRELAND consumers, please return to the place of purchase.
This does not affect your statutory rights.
2-8-25, Kuwazu, Higashi Sumiyoshi-ku,
Osaka 546-0041 Japan
Attn: CATEYE Customer Service Section
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
URL : https://www.cateye.com
CO., LTD.
[For US Customers]
CATEYE AMERICA, INC.
2825 Wilderness Place Suite 1200, Boulder CO
80301-5494 USA
Phone : [phone] Toll Free : 800.5.CATEYE
Fax : [phone] E-mail : [email protected]
