Cavecool CCI152DB User manual

Wine Cooler
Instruction Manual
CCI152DB
NOTE: Thank you for your purchase of the wine cooler ！ This
product is used to chill red wine. Our product will create perfect
temperature and humidity environment to store your collection of
wine quietly and peacefully.

Content
Safety instructions & warnings................................................................................ 1-2
Installation........................................................................................................................ 3
Description of the appliance.......................................................................................4-6
Operation......................................................................................................................... 7-9
Troubleshooting..............................................................................................................10
Maintenance and cleaning .......................................................................................... 11
Technical parameters.................................................................................................... 12

EN- 1
Safety instructions & warnings
Your safety is of the utmost importance to our company. Please make sure that
you read this instruction booklet before attempting to install or use the
appliance. If you are unsure of any of the information contained in this booklet,
please contact the Technical Department.
● This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
● Children should be supervised to
ensure that they do not play with
the appliance .
● This appliance is intended for
HOUSEHOLD USE ONLY and not for
commercial or industrial use .
● Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction .
● Do not use mechanical devices or other
means to accelerate the defrosting
process ,
other than those
recommended by the manufacturer.
● Do not damage the refrigerant circuit.
● Do not use electrical appliances inside
the storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
● Make sure that the appliance is
connected to power supply in
accordance with the rating label .
● Use an independent grounded socket
with 10A or higher, do not connect to
transformer or socket with multiple
outlets.
● Make sure socket is grounded properly
and do not modify power cord & plug.
● For safety reasons and to ensure the
optimum functionality of the wine cooler
it’ s important that you connect your
wine cooler using an earth/ground
connection plug and keep the wine
cooler perfectly plumb and level.
● Connect power plug with socket firmly in
case of possible risk of fire.
● Plug should be within reach for easy
disconnection after the appliance
positioned in case of accidents
occurred.
● Do not store or burn gasoline or other
inflammables near the appliance in
case of possible fire.

EN- 2
● Do not store inflammables, explosives,
acid & alkaline liquids etc.in the
compartment of the appliance.
● Do not operate other appliances in the
compartment .
Child Safety
● Do not allow child play inside the
appliance in case of entrapment.
● Do not allow child hang on the door to
play in case of falling of the appliance.
● Do not allow child reach into
compressor compartment or touch
metal components at rear of the
appliance in case of possible injury.
Keep away from water
● Do not spray water on the appliance or
wash the appliance by pouring or filling
water in case of invalid insulation and
possible electric shock.
Be careful of freezing
● Do not touch surface of the liner inside
the compartment, especially with wet
hand, in case of frozen injury while the
appliance is in operation.
Do not open the door for long
periods
● Opening the door for long periods can
cause a significant increase of
the temperature in the compartments
of the appliance.
Modification on the appliance
not allowed
● Do not reconstruct the appliance by
yourself which might cause damages
to the appliance .
Unplug the appliance under
certain conditions
● Unplug the appliance before cleaning &
maintenance .
● Unplug the appliance when power cut
occurred.
Disposal of the appliance
● Please according to local regulations
regarding disposal of the appliance for
its flammable refrigerant and blowing
gas.
● Before you scrap the appliance, please
take off the doors to prevent children
trapped .
● Send the appliance to the designated
disposal location .
Do not damage the power cord
● Do not disconnect the appliance by
pulling power cord rather than pulling
the plug.
● Do not set the appliance above the
power cord or step on the cord
intentionally.
● Put the power cord at right place when
moving the appliance .
When the power cord is damaged
● Do not use damaged power cord, and
get it replaced immediately by
manufacturer service agent or by
qualified electrician .
● If needed, extend the power cord with
cord of 0.75mm2 or bigger by qualified
electrician

EN- 3
Installation
Position
Do not lean the appliance over 45°when moving it to position.
The appliance must be put on flat,firm & dry floor or similar noncombustible pad;
do not use the package foam pad. DON’T PLACE A BUILT-IN
WINECOOLER ONA HEATED SURFACE SUCH AS HEATED FLOORING, AS THIS
WILL AFFECT THE
Do not put the appliance in the wet place.
Do not use the appliance in the frozen place.
Do not use the appliance outdoor in case of sunlight or rain.
The appliance is designed to either build under the counter
or stand alone on the floor.
Demonstration for building under the counter:

EN- 4
Wine bottles could be stored when you feel cooling inside after the appliance operates
around 1 hour.
Description of the appliance
Note: Shelves, door frame, handle and other accessories could be different according
to different models and configuration.All photos in this manual are for reference. The
appliance you buy might not be exactly the same as shown here. Please refer to the
actual product.
Installing the handle and reversing the
door of wine cooler
1. Install handle to the door frame of the appliance.
The handle is delivered in a separated package with screws
together inside the carton.
①Reveal two small holes on the door frame from inner side
by pulling out a bit the door seal ②Aim the handle to the
holes and insert the screws from inside ③Screw them up with screw-driver ④Put
back door seal to cover the screws.
Accessories& name
11. Upper hinge
1. Control panel
2.Housing
10. Door seal
3. Shelf
9. Handle
4. Cover board
8. Door
6. Adjustable foot
7. Lower hinge

EN- 5
2. Reversing the door
Our wine cooler is delivered with the door opening from left to right. To reverse the
opening direction:
Figure 1
Open the door at 90 degrees and keep it steady.
Unscrew the M5*16screws②,dismantle the right upper hinge③,and remove the
door.[Figure 1].
Figure 2
Unscrew the M5*16screws②,dismantle the right lower hinge⑤.[Figure 2]
Figure 3
Remove the germinal lid①.[Figure 3]

EN- 6
Figure 4
Install the germinal lid①.[Figure 4]
Figure 5
Install the right upper hinge ③,and screw tight theM5*16 screws②.[Figure 5]
Figure 6
Turn the door④180 degrees, and insert the right lower hinge⑤,screw tight M5*16
screws②.[Figure 6]Door reversing is finished.

EN- 7
Operation
Start operation
1. Cleaning the compartment
Before power on, clean inside of the appliance and check the drainage pipe in good
connection.（For details, please refer to the “Maintenance and cleaning”）
2. Put the appliance still
Before power on, level the appliance on the firm & dry floor for at least 30 minutes.
3. Power on
The appliance start operation and it will cool down inside after 1 hour, otherwise you
should check the power connection.
Control panel
All keys would be invalid in lock mode. Please unlock first.
ON/OFF
1. Keep pressing the key 3 seconds, power down, goes to stand-by mode.
2. Keep pressing the key again 3 seconds to return back to normal working.
Light
Press the key, turn on or turn off the LED lights inside. In stand-by mode, the key
is invalid.
Zone switch
Press the key to switch between upper zone and lower zone for choosing which
zone to set temperature. Press the key once, the LED display in chosen zone
flash regularly. Press up and down key to set temperature. Press the key again;
switch the zone to set temperature.
UP
Press the key once, LED Display in regular flash showing current set
temperature. Continue pressing to adjust set temperature, one press increase
1℃. Regular flash quit after 5 seconds detecting no press and new set
temperature save. LED display return to show actual temperature inside.

EN- 8
Down
Press the key once, LED Display in regular flash showing current set
temperature. Continue pressing to adjust set temperature, one press reduce 1℃.
Regular flash quit after 5 seconds detecting no press and new set temperature
save. LED display return to show actual temperature inside.
Child Lock（Combination key）
1. Lock：Press both keys at the same time for 3 seconds to lock.
2. Unlock：Press both keys at the same time for 3 seconds to unlock.
Fahrenheit/Celsius display interchange
Switch temperature display between Fahrenheit and Celsius by pressing and holding
the key for 2 seconds.
Attention
1. The ex-factory temperature of this product is 12 ℃, and the corresponding
temperature range needs to be set according to the actual wine.
2. For both upper and lower zone, the cooling temperature could be set from 5-
22℃. And temperature of lower zone could only be set equal to or higher than
that of upper zone.
3. Alarm sound: when the system malfunction occur and alarm sound, press any
key on the control panel to cancel the alarm sound.
4. Error code:
When the temperature sensor of upper zone failure occur, error code displays:
E1 for open circuit; E2 for short circuit.
When the defrost sensor failure occur, error code displays: E3 for open circuit;
E4 for short circuit.
When the temperature sensor of Lower zone failure occur, error code displays:
E5 for open circuit; E6 for short circuit.

EN- 9
Wine storage
The appliance equip with sufficient independent shelf to allow your collection of
wine get mature quietly and peacefully.
5 been wooden shelves loading capacity:57 bottles. (standard Bordeaux with
750ml )
Loading capacity will vary in terms of different way of bottle arrangement or
different bottle sizes.
Each shelf is designed to put on 1 or 2 layers of wine bottles. More than 2 layers of
bottle arrangement on one shelf are not recommended.
Each shelf could pull out partly to store wine bottles easily.
Open the door straight enough before pulling out shelves.
The shelf should be avoided in front of the fan as much as possible to avoid
blocking the air inlet and affecting the cooling efficiency.
If the wine cooler would have no load for a long time, it is recommended to power
it off, clean it carefully,and open the door for ventilation.
Below table is the recommended temperature for wine storing & drinking:
Red Wine
15-18℃
White Wine
9-14℃
Rose wine
10-11℃
Champagne & sparkling wine
5- 8℃

EN- 10
Troubleshooting
The appliance makes lots
of noise?
⚫Please adjust the front foot, keep the appliance
leveling.
⚫Please keep the appliance a bit space from walls.
Liquid flowing sound
inside the cabinet?
⚫It is normal because of the refrigerant working
inside.
The appliance does not
start?
⚫Make sure the appliance is connected to the power
properly.
⚫Make sure switch on the power.
⚫The compressor re-starts after 5 minutes for a
power cut.
Compressor runs
continuously?
⚫If no cold is being produced, call the after-sale
service.
Door does not seal
tightly?
⚫After long time use, the door seal might get stiff &
distorted partially.
1. Heat the door seal with hot-wind blower or hot
towel.
2. The door seal get softened and close the door.
The appliance does not
cool sufficiently?
⚫Please adjust temperature setting.
⚫Keep the appliance away from sunlight or heat.
⚫Please do not open the door frequently.
Unpleasant smells inside
cabinet?
⚫A little bit plastic smell for newly-buy appliance is
normal and will disappear after a short time.
⚫Clean the compartment and ventilate it for a few
hours.
Condensate on the glass
door?
⚫Please do not open the door frequently or for a
long time.
⚫Please do not set the temperature too low.
⚫High ambient temperature and humidity would
cause condensate.
The light is not working?
⚫Check the power supply first.
⚫Call the retailer’s after-sale service if the light is
broken.

EN- 11
Maintenance and cleaning
Cleaning
➢Disconnect the appliance before cleaning.
➢Clean the appliance with soft cloth or sponge by water.
➢Do not use organic solvents, alkaline detergent, boiling water, washing powder or
acid liquid etc.
➢Do not flush the compartment of the appliance.
➢Clean regularly surfaces that can come in contact with accessible drainage
systems.
The below items will damage the surface of wine cooler:
Power cut
Most power cuts could be resolved within a short time. To protect your wines during a
power cut, avoid opening the door as much as possible. During very long power cuts,
take the necessary measures to protect your wine.
Out of service for long time
Remove all bottles from the appliance, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the appliance.
If the appliance is disconnected or if there is a power cut, you must wait at
least five minutes before re-starting.
Moving the appliance
➢Cut off the power supply and unplug the
appliance.
➢Remove all bottles from the appliance.
➢When moving the appliance, do not lean the
appliance over 45°.

EN- 12
Technical parameters
Product model
CCI152DB
Voltage/frequency
220-240V~/50Hz
Refrigerant/weight
R600a/32g
Effective volume
143L
Loading capacity
57 bottles
Net weight
42kg
Unit dimension
(WxDxH)
590X563X885
Packing dimension
(WxDxH)
650X650X945
Remarks：
1. The Net weight includes shelves and the Unit dimension is without handle on the
door.
2. The manufacturer reserves all the rights to change the above parameters without
prior notice. Please refer to the nameplate of your appliance.
3. Loading capacity will vary in terms of different way of bottle arrangement or
different bottle sizes (standard Bordeaux with 750ml is applied here).

Vinkøleskab
Betjeningsvejledning
CCI152DB
NOTE: Tak for dit køb af dette vinkøleskab. Dette produkt
benyttes til at køle vin. Vores produkt skaber den perfekte
temperatur og luftfugtighed til at opbevare din vinsamling i.

Indhold
Sikkerhed og advarsler ............................................................................................... 1-2
Installation........................................................................................................................ 3
Beskrivelse af apparatet ...............................................................................................4-6
Betjening.......................................................................................................................... 7-9
Problemløsning................................................................................................................ 10
Vedligeholdelse og rengøring .................................................................................. 11
Tekniske specifikationer.............................................................................................. 12

DK- 1
Sikkerhed og advarsler
Din sikkerhed er yderst vigtig for vores firma. Venligst læs denne vejledning
inden du tager apparatet i brug. Skulle du være tvivl om nogle informationer i
denne vejledning, venligst kontakt os.
● Dette apparat kan benyttes af børn over
8 år og af personer med nedsatte
fysiske, sensoriske eller mentale evner
eller manglende erfaring og viden, hvis
de er under opsyn eller er blevet
instrueret i sikker brug af apparatet og
forstår de farer, som anvendelse af
apparatet indebærer. Børn må ikke lege
med apparatet. Rengøring og
vedligeholdelse må ikke udføres af børn
uden opsyn.
● Dette apparat bør ikke betjenes af børn.
Børn må ikke lege med apparatet, da der
kan fare forbundet.
● Dette apparater beregnet til brug i
privatehjem og ikke til professional eller
industrielt brug.
● Hold ventilations åbninger frie på
apparatet og udluftning fri ved
indbygning.
● Brug ikke mekaniske apparater eller andre
redskaber for at gøre afrimning og
optøning hurtigere
● Ødelæg ikke kølerør og lignende.
● Benyt ikke elektriske apparater inden i
skabet.
● Apparatet må kun tilsluttes
strøm i.h.t. til rating label på
siden eller bagsiden af
apparatet.
● Tilslut apparatet til 220-240 V / 50 Hz
vekselstrøm via en korrekt installeret
stikkontakt med jordforbindelse.
Stikkontakten skal være sikret med en
10 -13 A sikring. Vinkøleskabet leveres
med en såkaldt Schuko stikprop som er
standarden i de fleste lande i Europa.
Dette er et 2-benet stikprop med
sidejord.
● Mange danske hjem har en stikkontakt
med dansk jord (3 ben). I de tilfælde
skal du tilkøbe en adapter hos din
forhandler, som nemt klikkes på.
● Alternativt skal du eller en autoriseret
elinstallatør skifte stikproppen til den
danske 3-benede stikprop som du
ligeledes kan købe hos din forhandler.
● Make sure socket is grounded properly
and do not modify power cord & plug.
● Stikket bør være nemt
tilgængeligt itilfælde
nødstop.
● Opbevar ikke benzin, brandbare væsker,
og lignende indeni eller i nærheden af
apparatet.

DK- 2
Børne sikkerhed
● Tillad ikke børn at lege inden i skabet,
da de kan blive spærret inde.
● Tillad ikke børn at lege med eller
hænge på døren, da skabet kan
vælte.
● Tillad ikke børn at røre ved
kompressor eller andre ting under
skabet pga. fare.
Vinkøleskabet tåler ikke vand
● Sprøjt eller hæld ikke vand I skabet, da
det kan kortslutte.
Pas på fryseskader
● Rør ikke ved de indvendige flader med
våde hænder, da det kan give fryse
skader.
Åben ikke døren I længere tid
● Hvis døren er åben i lang tid vil det
påvirke skabet køleevne.
Modificer ikke skabet
● Sluk for strømmen og træk stikket ud
før rengøring og vedligehold.
Sluk for strømmen og trækstikket
ud hvis:
● Sluk for strømmen og træk stikket ud før
rengøring og vedligehold.
● Træk stikket ud i tilfælde af strømsvigt i
huset eller området.
Bortskaffelse af apparatet
● Afskaffes I henhold til lokale
bestemmelser vedrørende bortskaffelse
af apparatet for dets brændbare
kølemiddel og blæsegas.
● Før du smider apparatet ud, bør døren
afmonteres, så børn ikke leger med
apparatet.
● Skal afleveres på den nærmeste
genbrugs plads.
Lav ikke skader på ledningen
● Træk ikke stikket ud ved at hive i
ledningen, men kun ved at trække
stikket ud.
● Stil ikke apparatet oven på
ledningen.
● Rul ledningen sammen når skabet flyttes
for at undgå skader.
Hvis ledningen er skadet
● Brug ikke ledningen hvis den er skadet,
få en ny monteret af autoriseret montør.
● Hvis det er nøsvendigt at forlænge
strømledningen benyttes en ledning på
0,75 mm2 eller større af en kvalificeret
elektriker.

DK- 3
Installation
Position
ved flytning af apparatet bør det ikke vippes over 45°.
Apparatet skal placers på et plant, fast og tørt gulv eller et lignende ikke
brændbart underlaga. PLACER IKKE APPARATET PÅ EN OVERFLADE MED
GULVVARME DA DET VIL PÅVIRKE KØLEEVNEN.
Placer ikke apparatet I et fugtigt rum.
Placer ikke apparatet I et rum der ikke er frost frit.
Placer ikke apparatet udendørs.
Dette vinkøleskab er designet til indbygning.
Se nedenstående for indbygning:

DK- 4
Vinflasker kan opbevares i skabet, så snart du kan mærke køling I skabet, efter ca. 1
time.
Beskrivelse af apparatet
Note: Hylder, dør ramme, håndtag og andre dele kan være forskellige på forskellige
modeller. Alle foto og tegninger i denne manual er kun for reference.
Installation af dørhåndtag og vending af
dør
1. Monter håntaget på dør rammen.
Håndtaget følger med i en separate pakke med skruer og
ligger I skabet..
①Ved at trække et lille stykke af gummilisten fri, kan man se
2 småskrue huller i dørrammen ②Sæt skruerne i hullerne
indefra og monter håndtaget på ydersiden af døren ③Stram
skruerne med en skruetrækker ④Sæt gummilisten på plads
igen.
Tilbehør & navn
11. Øverste hængsel
1. Kontrol panel
2.Kabinet
10. Gummiliste
3. Hylde
9. Håndtag
4. Dæksel
8. Dør
6. Justerbare fødder
7. Nederste hængsel
