CBC LC703 User manual

Color Video Camera
Instruction Manual
Models : LC703
LC702
LC701
Before installing, operating or adjusting
this product, please read this instruction
booklet carefully and completely.
www.computarganz.com

2
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This lightning flash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product’s enclo-
sure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral tri-
angle is intended to alert the user to the pres-
ence of important operating and maintenance
(servicing) instructions in the literature accom-
panying the product.
FCC WARNING: This equipment may generate or
use radio frequency energy. Changes or modifications
to this equipment may cause harmful interference
unless the modifications are expressly approved in the
instruction manual. The user could lose the authority
to operate this equipment if an unauthorized change or
modification is made.
REGULATORY INFORMATION: FCC Part 15
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radi-
ate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at his
own expense.
• A suitable conduit entries, knock-outs or glands
shall be provided in the cable entries of this
product in the end user.
• Caution: Danger of explosion if battery is
incorrectly replaced. Replaced only with the same
or equivalent type recommended by the
manufacturer. Dispose of used batteries according
to the manufacturer’s instructions.

3
• Holes in metal, through which insulated wires pass,
shall have smooth well rounded surfaces or shall
be provided with brushings.
Warning: Do not install this equipment in a confined
space such as a bookcase or similar unit.
Warning: Wiring methods shall be in accordance with
the National Electric Code, ANSI/NFPA 70.
Warning: This is a class A product. In a domestic envi-
ronment this product may cause radio interference in
which case the user may be required to take adequate
measures.
Warning: To reduce a risk of fire or electric shock, do
not expose this product to rain or moisture.
Caution: This installation should be made by a
qualified service person and should conform to all local
codes.
Caution: To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel only.
Caution: The apparatus shall not be exposed to water
(dripping or splashing) and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
To disconnect power from the mains, pull out the
mains cord plug. When install the product, ensure
that the plug is easily accessible.
Disposal of your old appliance
1.When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/
EC.
2.All electrical and electronic products should
be disposed of separately from the municipal
waste stream via designated collection facili-
ties appointed by the government or the local
authorities.
3. The correct disposal of your old appliance will
help prevent potential negative consequences
for the environment and human health.
4. For more detailed information about disposal
of your old appliance, please contact your
city office, waste disposal service or the shop
where you purchased the product.
This product is manufactured to comply
with EMC Directive 2004/108/EC and Low
Voltage Directive 2006/95/EC.
European representative :
LG Electronics Service Europe B.V.
Veluwezoom 15, 1327 AE Almere,
The Netherlands (Tel : [phone])

4
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer's instruc-
tions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other appa-
ratus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polar-
ized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the pro-
vided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service person-
nel. Servicing is required when the apparatus
has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or mois-
ture, does not operate normally, or has been
dropped.
Important Safety Instructions

5
Contents
Features..............................6
Cautions for Safe Operation. . . . . . . . . . . . . . .7
Part Names and Functions. . . . . . . . . . . . . . . .8
Connections . . . . . . . . . . . . . . . . . . . . . . . . . .11
Installation of Camera . . . . . . . . . . . . . . . . . .15
MenuOperation.......................16
Focussettings ........................19
Exposuresettings......................22
White Balance setting. . . . . . . . . . . . . . . . . . .26
Day/Night setting . . . . . . . . . . . . . . . . . . . . . .28
Motion Detection setting. . . . . . . . . . . . . . . . .29
Privacy Mask setting . . . . . . . . . . . . . . . . . . .30
3D-DNR setting .......................32
Special menu settings . . . . . . . . . . . . . . . . . .33
Resetsettings.........................39
On Screen Display . . . . . . . . . . . . . . . . . . . . .40
RS-485Protocol.......................43
Specification..........................45

6
Features
This color video camera is designed for use in monitoring system.
High resolution and high sensitivity with a 1/ 4 inch EX-View CCD (Charge Coupled Device).
High magnitude of zoom lens with optical x27, Digital x12 (MAX x324)
Auto Focus
Auto White Balance
Auto exposure with DC Iris control
Day & Night function
WDR(Wide Dynamic Range) is available
Features Chart
This table shows the differences between the models.
Use LC703 is used for the description, operations and details provided in this operating guide.
Models Resolution Sens-Up WDR Day & Night Communication HSBLC
LC703P High Yes Yes Yes RS-485 Yes
LC703N High Yes Yes Yes RS-485 Yes
LC702P High No Yes Yes RS-485 No
LC702N High No Yes Yes RS-485 No
LC701P High Yes No Yes RS-485 Yes
LC701N High Yes No Yes RS-485 Yes
•
•
•
•
•
•
•

7
Power Supply
This camera must be operated DC 12V Certified/Listed,
class 2 power supply only.
Handling of the unit
Be careful not to spill water or other liquids on the unit.
Be cautions not to get combustible or metallic material
inside the body. If used with foreign matter inside, the
camera is liable to fail or to get cause of fire or electric
shock.
• Remove dust or dirt on the surface of the lens with a
blower.
• Use a dry soft cloth to clean the body. If it is very
dirty,use a cloth dampened with a small quantity of
neutral detergent,then wipe dry.
• Avoid the use of volatile solvents such as thinners,al
cohol,benzene,and insecticides.
They may damage the surface finish and/or impair
the operation of the camera.
Operating and storage location
Avoid viewing a very bright object (such as light fittings)
during an extended period. Avoid operating or storing
the unit in the following locations.
• Extremely hot or cold places (operating temperature
-10 °C - 50 °C, however, we recommend that the unit
be used within a temperature range of 0 °C - 45 °C)
• Damp or dust place
• Places exposed to rain
• Places subject to strong vibration
•
Close to generators of powerful electromagnetic radia-
tion such as radio or TV transmitters.
Cautions for Safe Operation

8
Part Names and Functions
 a
 b
aLens mount cap
The cap is installed to protect the lens
mount section. Remove the lens mount cap
before install the camera. (sold separately) .
bCamera installation bracket
The bracket can be fixed at the top or bot-
tom of the camera.

9
 c d e
cPower indicator
Comes on when the power to the camera is on.
dControl buttons
T(TELE) button
When push, picture is telephoto.
N(NEAR) button
In a manual situation, focus get near.
M(MENU) button.
If you want to set up a diverse function, you
can push this button.
W(WIDE) button
When push, picture is wide angle.
F(FAR) button
In a manual situation, focus get far.
H(HOT) button
When you set the DAY/NIGHT mode to EXT,
you can change the Day/Night mode using
this button.
eVideo output connector (BNC type)
Connect this connector to a device such as a VCR
or monitor with a VIDEO IN connector.
•
•
•
•
•
•
Part Names and Functions

10
f g
fPower input terminal
Connect to an external power supply of DC 12V.
gExternal Device Connectors
TRX -/+
Connect to an external controller of RS-485
format.
GND
Common GND.
Alarm Output Terminal (ALARM)
Connect to the alarm input of an external
device.
COM (Common)
OSD/D&N
OSD: Connect the external controller to
control the OSD function manually.
D&N: Connect the external controller to set
the D&N function manually. If you use the
external D&N function, you should set the
DAY/NIGHT option to EXT on the camera
setup menu.
FOCUS/ZOOM
Connect the external controller to control the
Focus and Zoom function manually.
•
•
•
•
•
-
-
•
Part Names and Functions
