True Day/Night Vandal-Resistant 27x PTZ Dome
PT127N- T
www.computarganz.com
Features:
• 550 TVL
• 27 Optical Zoom / 12 Digital Zoom
• True Day/Night (retractable IR cut filter)
• 127 preset positions
• 4 pattern, 8 swing, 8 group functions
• Fast maximum panning speed (360˚/sec)
• Endless 360˚/sec pan rotation
• 24 VAC power input
• Pelco P & D Protocol
• Wall Mount & sunshield included
• IP66 Rated for all weather conditions
PT127N-XT:Layout 2 3/9/10 7:04 PM Page 1

www.computarganz.com
PT127N- T True Day/Night Vandal-Resistant 27x PTZ Dome
Features
All specifications are subject to change without notice.
New York: 55 M ll Drive Comm ck, NY 11725 • Tel: [phone] • [phone] • F x: [phone]
C liforni : 20521 E rl Street Torr nce, CA 90503 • Tel: [phone] • [phone] • F x: [phone]
www.comput rg nz.com © 2010 CBC (AMERICA) Corp. All Rights Reserved. 03/10
Model PT127N-XT
Video Signal Format NTSC
Image Sensor 1/4'' Super HAD Color CCD
Horizontal Resolution/ Pixels 550 TVL Color / 680 TVL B/W (768 x 494)
Video Signal-to-Noise 50 dB (AGC ff)
Zoom Range 27x ptical Zoom, 12x Digital Zoom
F-Stop / Focal Length F1.6 ~ 2.9 / f = 3.5 ~ 94.5mm
Angle of View H : 55.5° (Wide) ~ 2.24° (Tele) / V : 42.5° (Wide ) ~ 1.79° (Tele)
Zoom Speed 1.8 sec (Wide to Tele)
Minimum Illuminance 0.4 Lux (Color) / 0. 02 Lux (B/W), 50 IRE / F1.6
Day & Night Settings Auto / Day / Night (ICR)
Focus Settings Auto / Manual / Semi-Auto
Iris Settings Auto / Manual
Shutter Speed 1/256 ~ 1/120000 sec
AGC Settings Low / Middle / High / Manual / ff
White Balance Auto / Manual (Red, Blue Gain Adjustable. 1800°K~10500°K)
BLC BLC / HLC / ff
SSNR Low / Middle / High / ff
Privacy Zone 8 Masks, Spherical Coordinate
Sta ilization N / FF
Movement Range Pan 360° (Endless)
Tilt 90°
Speed
Preset 360°/sec.
Jog 0.05 ~ 360°/sec. (Proportional to Zoom)
Swing 1~ 180°/sec.
Presets 127 Presets (Label, Independent Camera Parameter Setting)
Patterns 4 Patterns [1200 Commands (Approx. 5 Minute) / Pattern]
Swings 8 Swings
Groups 8 Groups (Max. 20 Actions with the combination of Preset, Pattern and Swing)
Other Pan/Tilt Functions Auto Flip, Auto Parking, Power Up Action
Protocol Options Pelco-D, Pelco-P Selectable
Communication RS-485
OSD English, Menu / PTZ information etc
Alarm Input 3 Inputs
Alarm Outputs 1 utput, Relay utput, Max. Load DC24V 1A / ACe125V 0.5A
Fan Always N
Heater peration Start from Internal Temperature 50°F / 10°C
Operation Temperature -22°F ~ 122°F / -30°C ~ 50°C
Rated Power AC 24V/1.5A
Material
Dome Polycarbonate
Internal Polycarbonate, ABS
External Aluminum
Dimensions 7.3” Ø x 7.6” (H) / 7.8” Ø x 7.6” (H) with sunshield
Dimensions with Wall Mount 11.5” Ø x 11” (H)
Weight Approx. 8.4 lbs. / 3.8 Kg
