SK651 Single
Pyrolytic Oven
Installation, Use and Maintenance

2
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking, defrosting and reheating foods. Any
other use could be dangerous and may lead to premature failure of
the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
User information:
•Ovens become hot during and immediately after use. Ensure you
do not touch the heating elements located inside the appliance.
•The oven door can become very hot during operation.
•After use, please ensure that the appliance is switched o.
•Keep children away from the appliance when in use, and
immediately after use.
•Keep the oven door closed when in use.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number

3
CE Declarations of Conformity:
This oven has been designed, constructed and marketed in
compliance with safety requirements of EEC Directive 2006/95/EEC
(Low voltage) and requirements of EMC Directive 2004/108/EEC.
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to EEC/89/109.4
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services. Disposing of a household appliance
separately avoids possible negative consequences for the
environment and health. It also enables the constituent materials to
be recovered, saving both energy and resources.
As a reminder of the need to dispose of household appliances
separately, the product is marked with a crossed-out wheeled dustbin.

4
Important
• Do not dismantle any parts without disconnecting the oven from the
mains power supply.
• Do not use the appliance if any part is broken (for example a glass).
Disconnect it from the mains and call CDA Customer Care.
• Before using the oven, it is recommended to run it empty at the
maximum temperature for an hour to remove any smells remaining
from manufacturing processes.
• In all models, leave the door closed when the grill is used.
• The cooling fan may continue to run as long as the oven is hot, even
after it has been switched o.
• During use the appliance becomes very hot; don’t touch the heating
elements inside the oven.
• During the oven operation, the front is heated as well; consequently
keep children clear of the oven, especially during self-cleaning.
• Parents and adults should pay particular attention when using the
product in presence of children.
• Children should be overseen so as to ensure that they don’t play
with the equipment.
• Keep children under age 8 away, unless constantly supervised.
• This appliance is not intended for use by persons (including children
over age 8) with reduced physical sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Children may not perform cleaning and maintenance unsupervised.

5
• In order to avoid damage to the oven enamel coat, do not cover the
oven base with any item (e.g. aluminium foil, pans and the likes).
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean
the oven door glass since they can scratch the surface, which may
result in shattering of the glass.
• Abrasive detergents and steam cleaning equipment should not be
used for cleaning.
• Before performing self-cleaning, take out all accessories (grills,
dishes, pans) to avoid damaging them, remove large cooking
residues and then close the door, ensuring that it is closed properly.
• Ensure the oven is cool and power to the oven has been turned o
before removing the door. Failure to do so could result in electrical
shock or burns.
• Read the user instructions carefully before using the oven for the
first time.
• Follow the instructions for first use of the oven.
• Clean the oven regularly.
• Remove spills as soon as they occur.
• Always use oven gloves when removing shelves and trays from the
oven.
• Do not grill food containing fat without using the grill pan grid.
• Do not cover the grill pan grid or the oven walls with aluminium foil.
• Do not use the oven tray for roasting.
• Do not perform maintenance or cleaning of the oven without first
switching o the electricity supply. If the oven has recently been
used, allow to cool.

6
• Do not place hot enamel parts in water. Leave them to cool first.
• Do not allow vinegar, coee, milk, saltwater, lemon or tomato juice to
remain in contact with enamel parts.
• The oven can require increased ventilation on pyrolytic programmes.
This can be achieved either from an open window or the use of a
fan.
Fig. 1 below shows correct placement of grills.
Fig. 1

7
Fig. 2
Fitting Out Your Appliance
Oven rack positions
The oven racks can be positioned in any one of four pairs of guides at
diering levels. At each level is a pair of supports formed in the side
walls of the oven cavity.
• Always be sure to position the oven racks before turning on the
oven.
• Make sure that the racks are level once they are in position.
• The racks are designed to stop when pulled forward to their limit.
To remove a rack from the oven
1 Pull rack forward.
2 Lift rack up at front and then pull
further forward to remove it.
To replace an oven rack
1 Place rear of rack between rack level
guides.
2 While lifting front of rack, slide rack in
all the way while lowering the front. Fig. 3

8
The Control Panel
Fig. 3
Fig. 4
Temperature control Digital Display Function control
Door lock LED
Time LED
Heating LED
Timer indicator
Temperature LED
Auto timing indicatorAuto cooking indicator
Digital Display in Detail

9
Fig. 5
Function Control Knob in Detail
Defrost
Conventional
oven
Fan with
lower heat
Light
Fan oven
Fanned half
grill
O
Conventional
Eco oven
Half grill
Full grill
Pyrolytic
clean

10
Before First Use
When the oven is connected to the electrical supply the latch
mechanism runs an automatic self-test by locking then unlocking the
oven door. This operation takes about half a minute. The “Door lock
LED” flashes while this test is performed, then turns o when the test
is completed.
The same process is repeated after every interruption to the power
supply.
Clock
The clock must be set after connecting the electrical supply, before
any cooking functions can be used.
The time of day is always displayed in 24 hour format.
Note: The “Time LED” is lit whenever the digital display is showing a
time value.
Setting the clock
In order to set the time of day, the “Function control” knob must first
be in the “O” position.
• Turn the “Temperature control” knob clockwise or anticlockwise and
let it return to its rest position: The hours flash.
• Modify the flashing hours value by turning the “Temperature control”
knob clockwise or anticlockwise, then let it return.
• Push the “Temperature control” knob to set the minutes: The
minutes flash.
• Modify the flashing minutes value by turning the “Temperature
control” knob clockwise or anticlockwise, then let it return.
• After a few seconds the whole time display flashes. Once this
flashing finishes the time is set.

11
Before using the oven for the first time we recommend that you clean
it with soapy water, rinse carefully and then heat on the fan oven
setting at maximum temperature for 30 minutes. A slightly unpleasant
smell may be produced, caused by grease remaining on the oven
elements from the production process.
General Settings & Use
Note: The “Temperature LED” is lit whenever the digital display is
showing a temperature (always °C).
To turn the oven on
Turn the “Function control” knob to the required programme.
The display will briefly show “On” then show the temperature preset
for the programme and cooking will start immediately.
To change the temperature, turn the “Temperature control” knob
clockwise or anticlockwise until the required temperature shows on
the display.
The “Heating LED” will flash on the display whilst the oven heats
up. Once the oven has reached the required temperature, the oven
will give five sets of three beeps and the “Heating LED” will light
continuously.

12
To turn the oven o
Turn the “Function control” knob to the “O” position, the oven gives
three short beeps and the word ”O” appears briefly on the display.
The functions available on the “Function control” knob are:
Oven light
The oven light may be turned on by turning the “Function control”
knob to the “Oven light” position.
Alternatively, the oven light will turn on automatically when a cooking
programme is selected: it stays o during pyrolytic cleaning.
Defrost
Turn the “Function control” knob to the “Defrost” position.
The defrost programme uses the the fan to circulate air for defrosting.
This is not a cooking programme.
The display shows “Def”.
Conventional oven
Turn the “Function control” knob to the “Conventional oven” position.
The cooking temperature defaults to 210°C and can be set between
50-250°C in 5˚C increments by turning the “Temperature control”
knob. After setting, the temperature can be changed at any time by
turning the “Temperature control” knob again.

13
Conventional Eco oven
Turn the “Function control” knob to the “Conventional Eco oven”
position. In this setting, the oven cooling fan only comes on when
the oven is hot, saving some electricity. The cooking temperature
defaults to 190°C and can be set between 50-250°C in 5˚C increments
by turning the “Temperature control” knob. After setting, the
temperature can be changed at any time by turning the “Temperature
control” knob again.
Fan oven
Turn the “Function control” knob to the “Fan oven” position. The fan
oven programme allows you to cook and brown foods just as you
would in a traditional oven. The cooking temperature defaults to
190°C and can be set between 50-250°C in 5˚C increments by turning
the “Temperature control” knob. After setting, the temperature can be
changed at any time by turning the “Temperature control” knob again.
Fan with lower heat
Turn the “Function control” knob to the “Fan with lower heat” position.
The fan with lower heat programme uses the fan element to enhance
the heat from the bottom element to create an ideal environment
for cooking pizzas. The cooking temperature defaults to 190°C
and can be set between 50-250°C in 5˚C increments by turning the
“Temperature control” knob. After setting, the temperature can be
changed at any time by turning the “Temperature control” knob again.

14
Fanned half grill
Turn the “Function control” knob to the “Fanned half grill” position.
The fanned half grill programme uses the grill element for grilling
and the fan to help circulate heat around the food. The cooking
temperature defaults to 230°C and can be set between 50-250°C
in 5˚C increments by turning the “Temperature control” knob. After
setting, the temperature can be changed at any time by turning the
“Temperature control” knob again.
Half grill
Turn the “Function control” knob to the “Half grill” position. The half
grill programme uses just the centre grill element to provide top heat
for grilling or browning foods.
The rack should be placed in as high a position as possible to bring
the food close to the element. The food needs to be turned over
during cooking to ensure both sides are cooked.
The grill should be preheated for approximately two minutes before
starting to cook.
The cooking temperature defaults to 230°C and can be set between
50-250°C in 5˚C increments by turning the “Temperature control”
knob. After setting, the temperature can be changed at any time by
turning the “Temperature control” knob again.

15
Full Grill
Turn the “Function control” knob to the “Full grill” position. The full
grill programme uses the centre and outer grill elements to provide
top heat for grilling or browning foods.
The rack should be placed in as high a position as possible to bring
the food close to the elements. The food needs to be turned over
during cooking to ensure both sides are cooked.
The grill should be preheated for approximately two minutes before
starting to cook.
The cooking temperature defaults to 230°C and can be set between
50-250°C in 5˚C increments by turning the “Temperature control”
knob. After setting, the temperature can be changed at any time by
turning the “Temperature control” knob again.
Pyrolytic clean
This oven can clean itself by a process known as pyrolysis, heating
the cavity to a temperature of approximately 475˚C. This will burn o
the residue from spattering and spillages caused by cooking.
Pyrolytic programmes should be used when the oven smokes during
preheating or cooking or if the oven smells even when cold. It is not
necessary to run a pyrolytic programme after every use of the oven.
Do not wait until the oven is coated in grease to run a pyrolytic
programme.
The smoke produced by pyrolysis is broken down by passing through
a catalser.

16
Please note: Before any pyrolytic programme, remove all shelves,
trays and other accessories from the oven and clean up any major
spills to avoid the risk of fire or excessive smoke.
Do not hang towels or cloths on the oven handle during pyrolysis.
Turn the “Function control” knob to the “Pyrolytic clean” position.
The programme immediately locks the door and starts the cooling
fan at a slow setting; the cooling fan speed increases to its maximum
when the oven heat builds up.
The digital display shows “P1:30”, the preset time of one hour and
thirty minutes. Also the “Auto timing indicator” is activated. The
“Door lock” LED shows the status of the door lock at any time:
O: Door unlocked
Flashing: Door being locked / unlocked
Full on: Door locked
The time for pyrolysis defaults to 90 minutes and can be set between
60-180 minutes in 15 minute increments .
To change the time, after setting the “Function control” knob:
• Press the “Temperature control” knob twice; the display shows the
time in minutes.
• Turn the “Temperature control” knob clockwise or anticlockwise to
select the time required.
• Approximately ten seconds after releasing the “Temperature control”
knob the display reverts to hours and minutes and stops flashing.

17
• It is now set at the revised time.
When the pyrolytic clean finishes the display shows “P---” and the
“Auto timing indicator” flashes.
• The display is cleared when the “Function control” knob is turned to
the o position.
• The door remains locked until the inside of the oven drops below
the safety threshold.
When the oven is cool:
• Disconnect the appliance from the power supply.
• Use a damp cloth to remove the white ashes from within the oven.
The oven is ready for use once the power supply is reconnected.

18
Timer and Minute Minder
Timer functions are selected by pressing the “Temperature control”
knob. This switches the digital display between them:-
Clock function: The display shows the current time.
Minute minder function: The display shows a countdown time until
the oven beeps.
Duration function: The display alternates between the word “dur”
and the setting for cooking duration.
End function: The display alternates between the word “End” and
the setting for the cooking end time.
Note: if the “Temperature control” knob is not touched for
approximately ten seconds the display will revert back to showing the
current time.
Programming the oven
Any timer functions required should be set after the relevant
cooking programme has been set.
Timer - Cooking time
• Press the “Temperature control” knob twice: The display then shows
the word “dur”.
• Turn the “Temperature control” knob clockwise or anticlockwise to
select the time required. This defaults to 30 minutes and can be set
to any time in the range 0-240 minutes.
• After approximately fifteen seconds the display reverts back to

19
showing the current time. The “Auto timing indicator” and the
“Auto cooking indicator” illuminate.
• The timer is now set.
• At the end of the set time, the oven switches o and the beeper
sounds.
• The beeper can be silenced by briefly turning the “Temperature
control” knob clockwise or anticlockwise, then letting it return to its
rest position.
Timer - End time
• Press the “Temperature control” knob three times: The display then
shows the word “End” alternating with the current time (the end time
defaults to the current time).
• Turn the “Temperature control” knob clockwise or anticlockwise and
let it return to its rest position: The hours flash.
• Modify the flashing hours value by turning the “Temperature control”
knob clockwise or anticlockwise, then let it return.
• Push the Temperature control” knob to switch to setting the minutes:
The minutes flash.
• Modify the flashing minutes value by turning the “Temperature
control” knob clockwise or anticlockwise, then let it return.
• After approximately fifteen seconds the display reverts back to
showing the current time. The “Auto timing indicator” and the
“Auto cooking indicator” illuminate.
• The timer is now set.
• The cooking time automatically updates in line with this.
• At the end of the set time, the oven switches o and the beeper
sounds.

20
• The beeper can be silenced by briefly turning the “Temperature
control” knob clockwise or anticlockwise, then letting it return to its
rest position.
Programming delayed cooking
This is achieved by programming an end time (when you want the
food ready) and also programming a cooking time (as the recipe).
Minute minder
The minute minder is a timer that is independent of the function of
the oven; it times and sounds a beep but does not aect any oven
functions. This is useful for timing actions that are unrelated to this
appliance, for example timing eggs on the hob.
• Press the “Temperature control” knob once: The display then shows
“---”.
• Turn the “Temperature control” knob clockwise or anticlockwise to
select the time required. This defaults to 30 minutes and can be set
to any time in the range 0-240 minutes.
• After approximately fifteen seconds the display reverts back to
showing the current time. The “Timer indicator” illuminates.
• The minute minder is now set.
• At the end of the set time, the beeper sounds.
• The beeper can be silenced by briefly turning the “Temperature
control” knob clockwise or anticlockwise, then letting it return to its
rest position.
