CDA SA117 Reference manual

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : customer[email protected] W : www.cda.eu
SA117, SA127 and SA227
Single Oven
Manual for Installation, Use and Maintenance

2
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking. Any other use could be dangerous
and may lead to premature failure of the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
User information:
• Ovens become hot during and immediately after use.
•The oven door can become very hot during operation.
•After use, please ensure that the oven switches are in the ‘O’
position.
•Keep children away from the appliance when in use, and
immediately after use.
•Keep the oven door closed whilst grilling.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.

3
Appliance Model
Serial Number
CE Declarations of Conformity:
This oven has been designed, constructed and marketed in
compliance with safety requirements of EEC Directive 2006/95/EEC
(Low voltage) and requirements of EMC Directive 2004/108/EEC.
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to EEC/89/109.4.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.

4
Important
• Read the user instructions carefully before using the oven for the
first time.
•Follow the instructions for first use of the oven.
•Clean the oven regularly.
•Remove spills as soon as they occur.
•Always use oven gloves when removing shelves and trays from the
ovens.
•Do not allow children near the oven when in use.
•Do not allow fat or oils to build up on the oven shelves, grill pan or
oven base.
•Do not place any cooking utensils or plates directly on the oven
base.
•Always grill with the oven door closed.
•Do not grill food containing fat without using the grill pan grid.
•Do not cover the grill pan grid or the oven walls with aluminium foil.
•Do not use the oven tray for roasting.
•Do not perform maintenance or cleaning of the oven without first
switching o the electricity supply. If the oven has recently been
used, allow to cool.
•Do not place hot enamel parts in water. Leave them to cool first.
•Do not allow vinegar, coee, milk, saltwater, lemon or tomato juice
to remain in contact with enamel parts.
•Do not use abrasive cleaners or powders that will scratch the
surface of the enamel.
•Do not attempt to repair the internal workings of your oven.

5
First Use of the Oven
First use
•The metal casing of this appliance has been coated with a
preservative to protect it during transport and storage. This should
be removed during installation by using a non-abrasive stainless
steel cleaner. Always follow the instructions given with the cleaner
being used.
•Before using the oven for the first time we recommend that you
clean the oven with soapy water, rinse carefully and then heat
on each of the below programmes at maximum temperature for
the specified time. A slightly unpleasant smell may be produced,
caused by grease remaining on the oven elements from the
production process.
15 minutes grill. (all models)
60 minutes fan oven.
60 minutes conventional oven (SA117 only)
Please note:
•This oven has been fitted with a cooling fan to achieve maximum
eciency and to maintain low surface temperatures. The cooling

6
fan will switch on automatically when the oven switches on. It is
normal for the cooling fan to run for an hour or more after use,
depending on the duration, temperature and type of cooking
programme used.
•The oven light remains on for every cooking function.
•Do not switch o the oven if you have set a programme for semi-
automatic or automatic cooking as this will cancel the programme
(SA227 only).
Oven Controls and Use
Cooking function knob
To set the function, turn the cooking function knob to the required
function.
Each of the oven functions uses dierent elements within the oven to
oer you the best choice of cooking every time. These are explained
below:
Oven Light
This function switches on the oven light in the oven
cavity.
Please note, the oven light will operate on all functions.
Defrost
Using the fan only this oven function circulates the air
around the oven cavity, speeding up the natural defrost
process (1kg takes approximately one hour, depending
on the type of food).

7
Fan Oven
Using the circular element and the fan with a
temperature between 50°C and 250°C, this cooking
function blows the air into and around the oven cavity.
Temperatures are achieved quicker, reducing or even
removing the need for preheating. Both cooking
temperatures and cooking times can be reduced for a
more energy ecient cooking programme.
Fanned Grill
This function uses the fan to circulate the heat from the
grill element around the food.
The temperature can be set between 50˚C and 250˚C.
Full Grill
This function radiates the heat from the grill element
and the top element.
This fully temperature variable grill is ideal for grilling a
full family meal. It can be set between 50°C and
250°C maximum.
For each grill function please note:
   •Always grill with the oven door closed.
   •Put the grill pan as close to the grill as possible.
   •Do not grill for more than 30 minutes at a time.

8
Temperature knob
•To set the temperature, turn the temperature knob clockwise to the
required temperature.
•Once the oven has reached the required temperature, the
temperature indicator lamp on the control panel will switch o.
•The temperature indicator lamp will light up when the oven
elements are in operation.
Warming Oven
Using heat produced only by the bottom element, this
natural heat is perfect for dough proving and blind-
baking.
Fan Oven
Using the circular element and the fan with a temperature
between 50˚C and 240˚C, this cooking function blows the
air into and around the oven cavity.
Temperatures are achieved quicker, reducing or even
removing the need for preheating.
Both cooking temperatures and cooking times can be
reduced for a more energy ecient cooking programme.
Perfect for cooking various food types simultaneously as
foods are sealed quickly to prevent flavour transfer.

9
Oven functions SA117 SA127 SA227
√
√ √
√
√ √
√ √ √
√ √
√
Conventional Oven
This function uses the upper and lower heating elements
with a temperature between 50˚C and 240˚C.
Natural convection creates a perfect cooking zone in the
centre of the oven, ideal for dark fruit cakes and pastries.

10
Programming the Oven (SA227 Only)
IMPORTANT: THE CLOCK MUST BE SET TO ENABLE THE OVEN
TO WORK.
The alert beep will cut o after seven minutes if it is not switched
o manually.
Setting the clock
The clock is preset to 00:00, and will revert to this after a power
failure.
• With the oven switched o, press and at the same time.
• Select the correct time by pressing the increase and decrease
buttons.
When the correct time is shown on the display, the clock will set
after approximately five seconds delay.
Setting the volume of the beep
•When the current time is shown on the clock display, press and hold
. The beep will sound three times.
• Continue to press until the volume is at the correct level. Each
press of the button will cycle through the options.
123456
buttons
functions
display
field
fig. 1

11
The minute minder
The minute minder can be used when the oven is switched on or o.
It can be set for up to 23 hours and 59 minutes.
To set the minute minder:
•Press .
•Then press and to select the required duration for the minute
minder. When the correct duration shows on the display, the minute
minder will set after approximately five seconds delay.
•A bell symbol will show in the clock display to indicate the minute
minder is on.
•When the countdown is complete, there will be a beep which will
continue for seven minutes. To switch o the beep, press any
button.
•To cancel the timer, press and then and simultaneously.
Please note :
At the end of the countdown, the minute minder will not switch o the
oven. Remember to turn o the oven manually.

12
Programming the Oven (SA227 Only)
The oven can be set for semi-automatic cooking, where the oven
is programmed to switch o at a specific time, and for automatic
cooking, where the oven is set to switch on and o at specific times.
To use the oven, rst press
To set a semi-automatic programme
1. Select the required function and temperature (the oven will switch
on).
2.Press and then press or to select the required duration of
cooking (maximum of 10 hours). The auto symbol will show on the
clock display to indicate a programme has been set.
To set a fully automatic cooking programme, follow step 1 and 2
above, and then:
3.Press . The clock will show the predicted end time (i.e. the
programmed cooking time added on to the current time).
4.Press or to select the required end time for cooking. The
programme symbol will no longer show on the clock display, but
auto will still show. When the cooking programme beings, the
programme symbol will show in the clock display.
To check on the time remaining on the programme, press .
To check on the specified end time, press .
When the cooking time is completed, the programme symbol will no
longer be shown, auto will flash and the timer will beep. To switch

13
o the beep, press any button. Then switch o the oven by turning
the control knobs to the o position and pressing to set the
programmer to manual.
To cancel a programme
Press and simultaneously, or .
Please note :
At the end of a programme, the timer will not switch o the oven.
Remember to turn o the oven manually.
Care and Maintenance
IMPORTANT
Before any maintenance is started involving electrical parts, the
appliance must be disconnected from the power supply.
If the oven has been in use, let the oven cavity and the heating
elements cool down before attempting any maintenance.
The oven exterior
As the oven has a stainless steel or enamel surface, you should use a
nonabrasive cleaner. Any abrasive cleaner (including Cif) will scratch
the surface and could erase the control panel markings. Stainless
steel can be eectively cleaned by simply using a dilute solution of
water and mild detergent and drying to a shine with a clean cloth.
Proprietary stainless steel cleaners are available. We recommend the
CDA E-Cloth available from the CDA Sales Team for cleaning stainless
steel surfaces as this has been designed to prolong the finish of your
appliance.

14
Inside of Oven
The oven should always be cleaned after use when it has cooled
down.
The cavity should be cleaned using a mild detergent solution and
warm water.
Suitable proprietary chemical cleaners may be used after first
consulting with the manufacturers recommendations and testing a
sample on a small area of the oven cavity. Abrasive cleaning agents
or scouring pads/cloths should not be used on the cavity surface.
IMPORTANT:
• Steam cleaners must not be used when cleaning this appliance.
•Once care and maintenance is complete, ensure that all parts are
correctly replaced before using the oven.

15
Changing the Oven
Lamp
Before any maintenance is started
involving electrical parts, the
appliance must be disconnected from
the power supply.
If the oven has been in use, let the
oven cavity and the heating elements
cool down before attempting any
maintenance.
Changing the bulb (g. 2)
Unscrew the protective cover. We
recommend that you wash and dry the
glass cover at this point.
Carefully remove the old bulb and
insert the new bulb suitable for high
temperatures (300ºC) having the
following specifications: 230-240V,
50Hz, 25W, G9 fitting.
Refit the protective cover.
fig. 2

16
IMPORTANT
Never use screwdrivers or other utensils to remove the
light cover. This could damage the enamel of the oven or the lamp
holder. Remove only by hand.
Never replace the bulb with bare hands as contamination from your
ngers can cause premature failure. Always use a clean cloth or
gloves.
Please note:
The bulb replacement is not covered by your guarantee.
Installation
Important
If the oven is being installed into a built under oven housing unit
ensure that the front rail at the top of the unit is not installed as it
could restrict ventilation.
Ensure that air can flow freely around the housing area. If the oven
is being installed into a fully enclosed built-under oven housing unit
it may be necessary to cut a small slot in the top of the plinth fitted
under the unit. Cut a section 400mm wide and a minimum of 15mm
high to allow air to pass under the unit. Alternatively cut a section 400
x450mm in the base of the carcass as indicated.
Failure to allow adequate ventilation to the appliance may result in
overheating or damage to adjacent units and could invalidate the
warranty.
This appliance is type X installation.

17
Dimensions
Height (mm)
Width (mm)
Depth (mm)
Oven
595
595
563.5
Housing
600
560
560 (min)
fig. 3
600
600
595
595
595 542
554
21.5
40
560
600
The walls of the kitchen units must be
able to withstand temperatures of 75˚C
above ambient (typically this is between
90˚C and 100˚C).
When correctly installed ensure
that there is a gap of 4mm minimum
between the sides of the oven and
adjacent furniture doors.
Lift the oven carefully into position
on the shelf, taking care NOT to lift it
by the door handle. If you lower the
oven door, you will see 4 screw holes,
2 on each side of the oven. The oven
should then be secured to the housing
by fitting screws into these holes.
Remember the housing should not be
free standing but be secured to the wall and/or adjacent fittings.
How to install your oven
You will need the following housing area fit your oven correctly.
The oven is designed to fit into a cabinet of 600mm width. The
oven can be built in or built under the kitchen units, but you must
ensure that it is properly ventilated. In the diagram the built-in oven
is ventilated by means of a space at the top of the kitchen cabinet.
There are many other methods of ventilating your oven - consult a
qualified engineer for advice.

18
Oven Door
Removing the Oven Door
The oven door can easily be removed
as follows:
•Open the door to the full extent (fig.
4).
•Open the lever A completely on the
left and right hinges (fig. 5).
•Hold the door as shown in fig. 8.
•Gently close the door (fig. 6) until left
and right hinge levers A are hooked
to part B of the door (fig. 5).
•Withdraw the hinge hooks from their
location following arrow C (fig. 7).
•Rest the door on a soft surface.
•To replace the door, repeat the above
steps in reverse order.
fig. 4
fig. 6
fig. 7
B
A
fig. 5
C
fig. 8
A
B
C

19
Electricity Supply to
Your Oven
Warning! this appliance must be
earthed.
This appliance must be connected by
a competent person, using fixed wiring
via a double pole switched fused spur
outlet, protected by a 13A fuse.
We recommend that the appliance is connected by a qualified
electrician, who is a member of the N.I.C.E.I.C. and who will comply
with the I.E.T and local regulations. The wires in the mains lead are
coloured in accordance with the following code:
GREEN AND YELLOW = EARTH BLUE = NEUTRAL BROWN =
LIVE.
As the colours of the wires in the mains lead for the appliance may
not correspond with the coloured markings identifying the terminals in
your spur box, proceed as follows:
1. The wire which is coloured green and yellow must be connected to
the terminal marked E (Earth) or coloured Green.
2. The wire which is coloured blue must be connected to the terminal
marked N (Neutral) or coloured Black.
3. The wire which is coloured brown must be connected to the
terminal marked L (Live) or coloured Red.
DOUBLE POLE
SWITCHED
FUSE SPUR OUTLET
13A

Please contact our Customer Care Department for Service on the details below
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : [email protected] W : www.cda.eu
