CDA ECPK91 Installation and operating instructions

www.cda.eu
ECPK91
Extractors
Installation, use and maintenance
Cod:0103091010-00.02

2
Contents
3 Important information
4 Important notes
7 Using your extractor
8 Care and maintenance
9 Changing the charcoal filter
10 Mounting your extractor
11 Ducting
12 Installation
15 Mains electricity connection
16 Electrical information
16 Troubleshooting
17

3
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
Declarations of Conformity:
This appliance has been manufactured to comply with all EU & UK
statutory requirements and complies with all applicable legislation and
the following European Directives:
• The Low Voltage Directive 2014/35/EU
• Electromagnetic Compatibility Directive 2014/30/EU
The product has been marked with the UKCA and CE symbols.
This appliance is marked according to the European directive
2004/104/EC on Waste Electrical and Electronic equipment (WEEE).
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.

4
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
Please note:
•Under no circumstances should the extractor be connected to any
gas ventilation system, flue system or hot air ducting system.
•Do not vent the extractor into an attic or loft space.
•Only house the extractor in rooms with adequate ventilation.
Remember that the extractor is powerful and whatever air is
extracted needs to be replaced.
•Do not tile the extractor in. It should be removable for service or
maintenance.
•Do not use silicone sealant to secure the hood to the wall.
•You must be able to isolate the extractor from the mains electrical
supply after installation.
•This extractor has been designed to be used in a room with a
volume of less than 36m .
•Steam cleaners must not be used when cleaning this appliance.
•The performance of your extractor will vary depending on a number
of factors. These include: type of extraction, length of ducting, room
volume, ventilation available and cleanliness of the filters.

Information and Advice
CAUTION:Accessible parts may become hot when used with cooking
appliances.
In certain circumstances electrical appliance may be a danger hazard.
A) There must be adequate ventilation of the room when the cooker
hood is used at the same time
as appliances burning gas or other fuels.
B)Do not check the status of the filters while the cooker hood is operat-
ing.
C)Do not touch the light bulb within half an hour after appliance has been
use.
D)Do not light a flame under the cooker hood.
E)Avoid opening gasometer when there is no pan on the stove, as it is
damaging for the filters and
a fire hazard.
F)Constantly check food frying to avoid overheated oil splashing and
becoming a fire hazard.
G) Disconnect the electrical plug prior to any maintenance.
H) Regulations concerning the discharge of air have to be fulfilled.
I) When the range hood and appliances supplied with energy Other than
electricity are simultan
ously in operation.The negative pressure in the room must not exceed 4
Pa (4x10-5 bar).
J)If the supply cord is damaged,it must be replaced by the manufacturer,
its service agent or
similarly qualified persons in order to avoid a hazard.
K)This appliance can be used by children aged from 8 years and above
and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowl-
edge if they have been
given supervision or instruction concerning use of the appliance in a safe
way and understand the
hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall
not be made by children unless they are older than 8 and supervised.
5

Information and Advice
L)the range hood is inteded to be installed over a hob having no more
than four hob elements.
M) Indoor use and household use only.
N)When the appliance is not in use and before cleaning, unplug the appli-
ance from the outlet.
O) Attention ! Observe the warning in the instruction sheet concerning
the operation of the
appliance when air is discharged from the room.
P) There is a fire risk if cleaning is not carried out in accordance with the
instructions.
Q) The air must not be discharged into a flue that is used for exhausting
fumes from appliances
burning gas or other fuels (not applicable to appliances that only
discharge the air back into the
room.
I)Children should be supervised to ensure that they do not play with the
appliance.
S)Warning: Failure to install the screws or fixing device in accordance
with these instructions may
result in electrical hazards.
T)The installation height of hood shall not be less than 65cm.
U)The filter screen must be cleaned regularly, otherwise there is a
danger of fire.
V)The installation must be carried out according to the screws and posi-
tions required by the
instructions, which will easily damage the connecting wires.
W)If the supply cord is damaged, it must be replaced by the manufac-
turer, its service agent or
similarly qualified persons in order to avoid a hazard.
6

7
Using your Extractor
For best performance, you should switch on the extractor 15 minutes
before starting to cook and leave it to run for approximately 15
minutes after the end of cooking.
Control Panel
B - Speed level buttons
C - Light button
• Press button “C”.
To switch on the extractor or to change the speed at any time
when the extractor is running
• Press the relevant “B” button for the first, second or third speed
level as required.
• Press the “A” button.
Fig. 1 A B C

8

9
Cleaning the grease filter
The grease filters should be kept clean to minimise the risk of fire.
At least once a month you should remove and clean the grease
filters with hot soapy water. You can also wash the grease filters in a
dishwasher, ensuring that you place it in an upright position to prevent
damage from other items in the dishwasher. After rinsing and drying,
replace the filters.
To remove the grease filters, pull open the handle on the grease
filter. It will release at the handle side. Then lower the grease filter to
remove it completely (fig. 2). To replace the grease filter, repeat the
steps in reverse.
Please note:
Cleaning the grease filters in the dishwasher may lead to
discolouration. This is normal and does not constitute a fault with the
appliance.
Changing the charcoal filter (re-circulating only)
To ensure best performance of your extractor, you should replace the
charcoal filters every four to six months, depending on use.
T
Adsorption the carbon filter to the body of the range hood, paying
attention to the center installation of the carbon filter.
o attach a new charcoal filter, first remove the grease filters as
Then according to the position shown in Figure 3,

10
Changing the light
This appliance is fitted with energy saving LED lighting that has a
considerably longer life expectancy than traditional filament bulbs.
These are not user-replaceable in the unlikely event of a failure.
Do not touch bulbs or adjacent areas during or straight after
prolonged use of the lights. The light is designed for use during
cooking and not for general room illumination. Extended use of the
light can reduce the life span of the bulb.
Mounting your extractor
If the instructions provided with your gas hob state that the required
distance between the hob and extractor must be greater than
700mm, then that is the distance that should be observed; this is a
legal requirement and may lead to your hob being disconnected from
the gas supply and the installation being reported under RIDDOR (The
height should be measured from the top of the burners).
IN THE ABSENCE OF ANY INSTRUCTIONS SUPPLIED WITH THE
GAS HOB, THE MINIMUM DISTANCE BETWEEN THE HOB AND
EXTRACTOR MUST BE AT LEAST 760mm.
Replaceable (LED only) light
source by a professional
LED LED
In case of malfunction of the illumination system contact the
technical service.
When the extractor is to be installed above an electric hob, the
minimum distance between the hob and extractor must exceed
600mm for ceramic and solid plate hobs and 550mm for induction
Hobs.
When the extractor is to be installed above a gas hob, the minimum
distance between the hob and extractor must exceed 650mm.

11
The width of any hob must not be greater than the width of the
extractor installed above it.
Ducting and ventilation
For best performance and lowest noise output, we recommend the
use of 150mm ducting. You can also use 120mm ducting but this will
reduce performance. In general, the less ducting you use (i.e. distance
follows:
•4 metres with 1 x 90° bend.
•3 metres with 2 x 90° bends.
•2 metres with 3 x 90° bends.
Longer ducting can be used but the performance of the extractor will
likely be reduced.
Please note: Ducting components and ducting kits are optional
accessories and have to be ordered, they are not automatically
supplied with the hood. Use of ducting less than 150mm in diameter
extractor.

12
Installation
Note
•We recommend that you seek the
help of another individual when
installing this product. Always wear
adequate PPE (Personal Protective
Equipment).
•The fixings supplied are suitable
for most installations. It is the
responsibility of the installer to
ensure that the fixings are suitable
for the ceiling type in the property.
Installation steps
1. Firstly, fix the vent outlet to the
extractor body using four screws, as
shown in fig 5.
2. Using the supplied template, mark
the positions of the ceiling mounting
screws and the cut-out for the
ducting pipe, if required.
Fix four suitable wall plugs into the
holes and proceed to assemble the
extractor, as described in fig 6.
3.To determine the overall height of
Fig. 5
Fig. 6
Fig. 4
B - clearance required
Gas: 650mm recommended.
Electric: 600/550mm recommended.
A - burner height
Extractor height
floor
ceiling

13
the chimney section, use the
calculation shown on this page for
your extractor (also refer to fig 4):
A = Height of gas hob burner or electric
hotplate height from the kitchen
floor
B = Clearance required:
Gas hobs 650mm recommended
Electric hobs:
Ceramic hobs and solid plate 600mm
recommended;
Induction hobs 550mm recommended.
A+B is the required height of the body
of the extractor above the floor.
Next we need to calculate the required
height of the extractor.
Whole extractor height = ceiling height -
height above floor (A+B).
4. Assemble the chimney sections 1, 2
on the diagram fig 7, using the
supplied fixing screws and fix to the
chimney body. Measure the height
of the chimney and ensure that it is
equal or less than the height
calculated in step 3. (When the
extractor is mounted the height
between the hob and extractor must Fig. 9
Fig. 8
Fig. 7
1 – slide rail
2 – top mounting frame
2
1

14
be at least the minimum height specified).
5. Place the chimney section over the body assembly, as shown in fig
8.
6. With the help of another individual, raise the whole assembly to the
ceiling and fix securely in place using four screws appropriate for
the wall plugs inserted in step 2. Ensure that the supporting ceiling
is strong enough to take the weight before releasing the extractor.
7. Connect the ducting to the extractor vent outlet, securing it in place
with a cable tie, duct tape or other suitable means.
8. Finally, raise the inner section of the chimney to the ceiling and
secure in place using the two small screws supplied
9. Note that the electrical connection to the extractor should not be
located inside the boundaries of the chimney. This is especially
important if the extractor is to be used as a recycling device.
There should be an isolation switch so that the extractor can be
disconnected from the mains electrical supply after installation.
The metal casing of this appliance has been coated with a
preservative to protect it during transport and storage. This should
be removed during installation by using a non-abrasive stainless
steel cleaner. Always follow the instructions given with the cleaner
being used.

15
Mains Electricity Connection
THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY
BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE
POLE SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A
3A FUSE.
We recommend that the appliance is
connected by a qualified electrician,
who is a member of the N.I.C.E.I.C. and
who will comply with the I.E.E. and local
regulations.
The wires in the mains lead of this
appliance are coloured in accordance
with the following code:
BLUE = NEUTRAL, BROWN = LIVE, GREEN+YELLOW = EARTH
As the colours of the wires in the mains lead for the appliance may
not correspond with the coloured markings identifying the terminals
connecting to the fused spur, proceed as follows:
•The wire which is coloured blue must be connected to the terminal
marked N (Neutral), or coloured black.
•The wire which is coloured brown must be connected to the
terminal marked L (Live), or coloured red.
•The wire which is coloured green and yellow must be connected
to the terminal marked E (Earth) or coloured green or green and
yellow.
DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
USE A 3 AMP FUSE

16

17
E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the
right to change specifications without prior notice.
Attribute Symbol Units
19KPCEnoitacifitnedIledoM
Annual Energy Consumption AECHood
63.7 kWh
Time increase factor f 1.7
y FDEHood 8.4
x EEIHood 89.7
Point
QBEP 224.3 m3/h
Point
PBEP 126.0 Pa
Maximum airflow QMAX 387.4 m3/h
Measured electric power at Best WBEP 93.3 W
Nominal lighting power WL W
Average illumination of the lighting
system on the cooking surface
EMiddle Lux
Measured power consumption in
standby
PSNA W
mode
PO0.0 W
Sound power level LWA 61.0 dBA
y GFEHood 69.7 (D) %
ELycneiciffepmaL Hood
Energy Efficiency Information
Value
%91 (A)
8
730

www.cda.eu
Customer Care Department. The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY
T: 01949 862 012 F: 01949 862 003 E: customer[email protected]
For service or queries relating to your product please contact:
The Customer Care Department on 01949 862 012 or email customer[email protected]
For more information please contact:
The Sales Department on 01949 862 010 or email [email protected]
