ECPK9 Extractors
Manual for Installation, Use and Maintenance

Important
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this
product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect
installation or misuse of the appliance or use in a commercial environment.
This appliance is not designed to be used by people (including children) with reduced physical, sensorial or mental
capacity, or who lack experience or knowledge about it, unless they have had supervision or instructions on how to use
the appliance by someone who is responsible for their safety.
Under no circumstances should any external covers be removed for servicing or maintenance except by suitably qualified
personnel.
Appliance information:
Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a
fault with your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity:
This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including Gas
safety, Electrical safety (LVD) and Electromagnetic interference compatibility (EMC).
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC.
At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer
providing appliance recycling services.
Disposing of a household appliance separately avoids possible negative consequences for the environment and health. It
also enables the constituent materials to be recovered, saving both energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin.
Please note:
•Under no circumstances should the extractor be connected to any gas ventilation system, flue system or hot air
ducting system.
• Do not vent the extractor into an attic or loft space.
•Only house the extractor in rooms with adequate ventilation. Remember that the extractor is powerful and
whatever air is extracted needs to be replaced.
•Do not tile the extractor in. It should be removable for service or maintenance.
•Do not use silicone sealant to secure the hood to the wall.
•You must be able to isolate the extractor from the mains electrical supply after installation.
•This extractor has been designed to be used in a room with a volume of less than 36 m3.
•Steam cleaners must not be used when cleaning this appliance.
•The performance of your extractor will vary depending on a number of factors. These include: type of extraction,
length of ducting, room volume, ventilation available and cleanliness of the filters.

Using your Extractor
For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run for
approximately 15 minutes after the end of cooking.
Control Panel
A – Power indicator light
B – Light button
C – Power off button
D – Speed level buttons
To switch the extractor light on or off
• Press button B.
To switch on the extractor or to change the speed at any time when the extractor is running
• Press the relevant D button for the first, second or third speed level as required.
To switch the extractor off
• Press the C button.
Fig. 1

Care and Maintenance
IMPORTANT : DO NOT PERFORM MAINTENANCE
OR CLEANING OF THE EXTRACTOR WITHOUT FIRST
SWITCHING OFF THE ELECTRICITY SUPPLY.
Cleaning
You should use a nonabrasive cleaner. Any abrasive cleaner
(including Cif) will scratch the surface and could erase the
control panel markings.
You can clean your extractor effectively by simply using a
dilute solution of water and mild detergent and drying to a
shine with a clean cloth, for example the CDA E-Cloth.
Cleaning the grease filter
The grease filter should be kept clean to minimise the risk of
fire.
At least once a month you should remove and clean the
grease filter with hot soapy water. You can also wash the
grease filter in a dishwasher, ensuring that you place it in an
upright position to prevent damage from other items in the
dishwasher. After rinsing and drying, replace the filter.
To remove the grease filter, push in the button on the handle
and then pull down on the filter at the front as shown in
figure 2. When you have released it at the front, then you can
pull the filter out completely.
Please note:
Cleaning the grease filter in the dishwasher may lead to
discoloration. This is normal and does not constitute a fault
with the appliance.
Changing the charcoal filter (re-circulating only)
To ensure best performance of your extractor, you should
replace the charcoal filters every four to six months,
depending on use. To attach a new charcoal filter, first
remove the grease filter as described above. Then offer up
the charcoal filter to the side of the motor as shown in figure
3 and turn it clockwise until it locks into place.
Fig. 2
Fig. 3

Changing the Light
DO NOT CHANGE THE LIGHT BULB IMMEDIATELY AFTER USE AS THE BULB WILL BE HOT. ALLOW IT TO
COOL BEFORE REMOVING IT.
Remove the grease filter, unscrew the light bulb and replace the light with the required light bulb as shown below. Finally,
replace the grease filter.
Do not touch bulbs or adjacent areas during or straight after prolonged use of the lights.
The light is designed for use during cooking and not for general room illumination. Extended use of the light can reduce
the life span of the bulb.
Bulb replacement is not covered by the guarantee.
Only use bulbs recommended for your extractor. Do not fit bulbs of a higher power rating. Bulbs of a lower power rating
may be adequate for use, generally last longer and use less energy.
Spare bulbs are available from CDA Customer Care or from your local DIY shop.
ECPK9 50W max halogen 2 pin GU10
Table 1

DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
USE A 3 AMP FUSE
Mains Electricity Connection
THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED
WIRING VIA A DOUBLE POLE SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A 3A FUSE.
We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will
comply with the I.E.E. and local regulations.
The wires in the mains lead of this appliance are coloured in accordance with the
following code:
BLUE = NEUTRAL, BROWN = LIVE.
As the colours of the wires in the mains lead for the appliance may not correspond
with the coloured markings identifying the terminals connecting to the fused spur,
proceed as follows:
•The wire which is coloured blue must be connected to the terminal marked
N (Neutral), or coloured black.
•The wire which is coloured brown must be connected to the terminal marked
L (Live), or coloured red.
•If the mains cable is damaged, it must be replaced by a CDA approved engineer, agent or similarly qualified persons
in order to avoid a hazard.
NOTE: USE A 3A FUSE
Assembly and electrical connection should be carried out by competent personnel.
When installing this product we recommend you seek the help of another individual.
IMPORTANT: THIS APPLIANCE IS A CLASS II APPLIANCE (DOUBLE INSULATED) AND IS NOT INTENDED TO
BE EARTHED. DO NOT FIT AN EARTH LEAD TO THIS EXTRACTOR.
Do not mount the isolation switch behind the chimney section. It is a requirement that you must be able to isolate the
extractor from the mains electrical supply after installation.
This appliance is intended to be connected to the mains electrical supply by means of an isolation switch and fused spur
and is intended to be protected by a 3A fuse. The use of a 13A fuse can cause damage to the internal wiring in the event
of a fault, and may also invalidate the warranty.

Electrical Information
Mains electrical voltage: 230 – 240Vac
Total rated power consumption:
ECPK9:470W
Troubleshooting
Please note:
Your extractor is equipped with a motor protection device that will switch off the motor to prevent damage from
overheating. This may happen during cooking when most or all of the zones/burners are being used simultaneously, or if
your extractor is installed incorrectly, lower than the recommended height.
This is normal, and the extractor will work again once the motor has cooled sufficiently.
If your extractor is not working:
1. Check that the mains supply has not been switched off.
2. Check that the fuse in the spur has not blown.
Contact CDA Customer Care
A : Customer Care Department, The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : [email protected] W : www.cda.eu

Mounting your Extractor
IMPORTANT:
We recommend that you seek the help of another individual
when installing this product
The minimum ceiling height when used with a gas hob
requiring a clearance of 750mm is 2.52m (or 8’3”). When
used with an electric hob with clearance of 650mm the
minimum ceiling height required is 2.42m (or 8’ 0”)
IMPORTANT:
The extractor is intended to be mounted directly to
the ceiling using fixings appropriate for the ceiling.
Ensure that there is adequate ceiling strength and
supports at the fixing points; if in doubt, consult a
joiner or electrician.
When the extractor is to be installed above an electric hob,
the minimum distance between the hob and extractor must
exceed 600mm (650mm is recommended).
When the extractor is to be installed above a gas hob, the
minimum distance between the hob and extractor must
exceed 700mm (750mm is recommended).
If the instructions provided with your gas hob state that the
required distance between the hob and extractor must be
greater than 700mm, then that is the distance that should be
observed; this is a legal requirement and may lead to your hob
being disconnected from the gas supply and the installation
being reported to RIDDOR (The height should be measured
from the top of the burners).
IN THE ABSENCE OF ANY INSTRUCTIONS SUPPLIED
WITH THE GAS HOB, THE MINIMUM DISTANCE
BETWEEN THE HOB AND EXTRACTOR MUST BE AT
LEAST 760mm.
The width of any hob must not be greater than the width of
the extractor installed above it.
Fig. 4
Electric : 650mm recomended
Gas 750mm recomended
min 536
308

Install your extractor
To Install your extractor, proceed as follows: -
1. Mark and drill holes in the ceiling for the four support
plugs, using either the support section or the dimensions
in fig5. as a guide.
2. Work out the required height of the support section,
as follows: -
Support section height = Ceiling height – (308 + hob
height + clearance required)
Slide the outer section to the required height and fasten
in position using the 8 screws and washers, as shown.
Important: If the exact height required cannot be
obtained, use the next highest position in order to ensure
that the minimum clearance require is exceeded. This is
shown in fig 6.
3. Next, Fit the vent outlet adaptor using 2 screws and fix
the glass canopy to the motor body, as shown in fig 7.
259
259
188
188
X4
Fig. 5
Ø4 x Ø12 x 1.0
Ø3.4 x12
Fig. 6
Ø3.9 x12
Fig. 7

Install your extractor
To Install your extractor, proceed as follows: -
4. Connect the ventilation ducting to the duct pipe in the
ceiling void and proceed to secure the support section
to the ceiling using appropriate fixings. When secured
firmly to the ceiling, slide the decorative chimney
sections over the support.
5. With the help of another individual, introduce the body
of the extractor to the support section. Note that there
are two spring clips which are provided as a safety
measure to prevent the body falling whilst it is being
secured to the support. Secure the body in position using
the four nuts, washers and locking washers, as shown
below in Fig 10.
Note that the ducting pipe should be connected and
secured to the vent outlet adaptor at this stage and
it may be that the pipe needs connecting before the
support and body are assembled together.
Ø6.3 x Ø17 x 3
Ø6 x 70
Fig. 9
Fig. 8
Ø6.4 x Ø11 x 0.7mm
Ø6.4 x Ø12 x 1.6mm
M6
Fig. 10

Install your extractor
To Install your extractor, proceed as follows: -
6. Locate the lower decorative section in position and
slide the upper section up to the ceiling. Using the
supplied screws, fix the chimney sections to the upper
support using the supplied screws (Fig 11)
7. Finally, secure the lower chimney section to the body
using the supplied screws. (Fig 12)
2-Ø3.4 x 10
Fig. 11
2-Ø3.4 x 10
Fig. 12

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T: 01949 862 012 F: 01949 862 003 E: [email protected] W: www.cda.eu
Passionate about style
To contact our Customer Care Department, or for Service,
please contact us on the details below.
