AL-LEN™Ground Coffee Dispenser
Operator Manual
Model A
Grindmaster-Cecilware
4003 Collins Lane, Louisville, KY 40245 USA
Phone: [phone] Toll Free: 800.695.4500
Fax: [phone]
Web: gmcw.com Email: [e-mail]
Unpacking...................................................2
Cleaning Instructions..................................2
Adjustments................................................2
Thank you for purchasing this quality Ground Coffee Dispenser. For your safety and the safety of others,
read all warnings and the operator’s manual before installing or using the product. Properly instruct all
operators. Keep training records. For future reference, record serial number here:
Table of Contents
©2016 Grindmaster-Cecilware
Printed in USA
0516 Form # CW-342-01
Part # 390-00089
Grindmaster-Cecilware provides the
industry’s BEST warranty. Visit gmcw.com
for warranty terms and conditions.
Model A

2 Cecilware®AL-LEN™ Ground Coffee Dispenser
1. Remove thumb screws and top cover. 2. Lift dispense handle up and pull straight out.
Disassemble
1. Remove the two knurled screws on the front of
dispenser.
2. Lift up on pull knob shaft and remove the plate
assembly.
3. Remove hopper cover. Pull lock spring knob out
located on backside of dispenser. At the same
time, lift hopper up from the rear.
4. Remove slide assembly and trap door.
Cleaning
1. Hand wash in mild soap and warm water.
2. Rinse and dry thoroughly before re-assembling.
To reassemble
1. Place trap door in position.
2. Place slide into hopper assembly.
3. Place hopper in dispenser cabinet by holding
hopper higher in the back so the groove on
front side of hopper can slide into position on
cabinet.
4. Press hopper down firmly on back of cabinet.
Pull lock spring knob out so lock spring can snap
into location. You should be able to hear the
lock click.
5. Place pull rod in slot located on the slide and
replace the two front panel screws.
6. Cabinet can be cleaned with a mild soap and a
damp cloth. AVOID excess water.
Carefully lift unit out of shipping container, and inspect
immediately for shipping damage. Your Ground Coffee
Dispenser was shipped in a carton designed to give it
maximum protection. It was thoroughly inspected
before leaving the factory. File any claims for shipping
damage or irregularities directly with the carrier.
Adjustments
Cleaning Instructions
3. Pull the knob on the back of
the dispenser.
Tilt the hopper forward. Pull assembly straight up.
Unpacking

AL-LEN™ Ground Coffee Dispenser Cecilware®3
Adjustments (continued)
4. Turn knurled knob until desired quantity is displayed on the hopper
gauge.
5. Replace hopper assembly.
6. Replace hopper dispense pull handle making sure slot in shaft fits
into “U” shaped slot in hopper assembly.
7. Replace thumb screws.
8. Set brew basket stop for size brew baskets being used. There are three basic sizes for the brew baskets:
7-½ inches, 7 inches, and 6 inches. This dispenser is set for a 7 inch brew basket. If you’re using a different
size of brew basket, remove the two screws holding the brew basket stop and move stop to the location
corresponding to your brew basket size.
If you need help, call Grindmaster-Cecilware Technical Service Department, [phone] or [phone] (USA
& Canada only) (Monday through Friday 8 AM - 6 PM EST). Please have the model and serial number ready so
that accurate information can be given.
Prior authorization must be obtained from Grindmaster- Cecilware for all warranty claims.
Grindmaster-Cecilware provides the industry’s BEST warranty. Visit gmcw.com for warranty terms and
conditions.
