Central Forge 92553 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 22l
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 92553
Specifications
#4 Jack Plane 2" Wide Blade @ 25°
Mini Block Plane 1.3" Wide Blade @ 25°
IMPORTANT SAFETY INFORMATION
1. Secure workpiece with clamps.
2. Properly assemble planer before use.
3. Sharp blade; avoid contact during set up and use.
4. Wear ANSI-approved safety goggles and heavy
duty work gloves during set up and use.
5. Keep work area clean.
6. Observe work area conditions. Do not use
tools in damp or wet locations. Do not expose
to rain. Keep work area well lighted.
7. Dress properly. Do not wear loose clothing or jewelry.
Protective, electrically nonconductive clothes and
non-skid footwear are recommended when working.
Wear restrictive hair covering to contain long hair.
8. Stay alert. Watch what you are doing, use common
sense. Do not operate any tool when you are tired.
9. Take caution as some woods contain preservatives
such as copper chromium arsenate (CCA)
which can be toxic. When working with this
type of wood, extra care should be taken to
avoid inhalation and minimize skin contact.
10. Do not overreach. Keep proper footing
and balance at all times.
11. This product is not a toy. Do not allow
children to play with or near this item.
12. Use as intended only.
13. Inspect before use; do not use if
parts are loose or damaged.
14. Store idle equipment. When not in use, tools must
be stored in a dry location to inhibit rust. Always
lock up tools and keep out of reach of children.
15. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.

Page 3For technical questions, please call 1-888-866-5797.Item 92553
Operation
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
#4 Jack Plane
1. To remove the Blade (1), lift the lever
on Lever Cap Assembly (3) and remove
the Assembly from the Plane.
2. To remove the Chip Breaker from the Blade, remove
the Screw from the bottom of the Blade. You can then
sharpen or adjust the Blade. Replace Chip Breaker
(curved side down) and tighten Screw when finished.
3. To install and adjust the Blade, position it
over the Lever Cap Screw and ensure it is
properly aligned. Replace the Lever Cap
Assembly and tighten the Lever Cap Screw.
4. Adjust the Blade by pressing the Blade
Adjustment Lever (9) from side to side to
adjust the Blade angle. Turn the Adjustment
Screw (8) to adjust the Blade depth.
5. Make sure the workpiece is securely fastened down.
6. Do not force the Plane or press down on it. Move
it forward, taking off a little wood at a time. If the
Plane does not move forward easily, adjust the
Blade as explained in step 2 on previous page.
Note: If the Blade isn’t planing properly, adjust
the Chip Breaker position up or down.
Lever Cap
Assembly (3)
Lever Cap
Screw (4)
Frog
Assembly (5)
Blade
Adjustment
Lever (9)
Adjustment
Knob (8)
Blade (1)
Chip Breaker
Screw (2)
Mini Block Plane
1. To remove the Blade (1), loosen the Adjustment
Screw (4) and remove the Screw Cap (2).
2. You can then sharpen or adjust the Blade.
3. To install and adjust the Blade; position it over the
Plane Body (3) with the Screw Cap on top of it.
4. Turn the Adjustment Nut until the Blade is
held firmly in place in the desired position.
5. Make sure the workpiece is securely fastened down.
6. Do not force the Plane or press down on it. Move
it forward, taking off a little wood at a time. If the
Plane does not move forward easily, adjust the
Blade as explained in step 2 on previous page.
Note: If the Blade isn’t planing properly, loosen the
Adjustment Screw and reposition the Blade up or down.
Screw
Cap (2)
Plane
Body (3)
Adjustment
Screw (4)
Blade (1)

Page 4 For technical questions, please call 1-888-866-5797. Item 92553
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts. Refer to UPC 193175486868.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 5For technical questions, please call 1-888-866-5797.Item 92553
Parts List and Diagram
#4 Jack Plane
Part Description Qty
1 Blade 1
2 Screw 1
3 Lever Cap 1
4 Lever Cap Screw 1
5Frog Assembly 1
6Y Adjusting Lever 1
7 Adjusting Knob 1
8 Adjustment Screw 1
9Blade Adjustment Lever 1
Part Description Qty
10 Screw & Washer For Frog 1
11 Handle 1
12 Knob 1
13 Bolt and Nut for Handle 1
14 Bolt and Nut for Knob 1
15 Screw for Handle Toe 1
16 Plane Body 1
17 Clip & Screw for Frog 1
18 Adjusting Screw for Frog 1

Page 6 For technical questions, please call 1-888-866-5797. Item 92553
Parts List and Diagram
Mini Block Plane
Part Description Qty
1 Blade 1
2 Screw Cap 1
Part Description Qty
3 Plane Body 1
4 Adjustment Screw 1

Page 7For technical questions, please call 1-888-866-5797.Item 92553
Maintenance
General Tool Maintenance
1. During periods of storage, coat the bare
metal surfaces with light oil to inhibit rust.
2. This product should be assembled
and stored in a dry area.
Sharpening The Cutting Blade
1. Use an abrasive stone that is lubricated
with light oil or paraffin.
2. While wearing work gloves, use two hands,
one to grip the cutting blade to maintain the
angle. The other hand should exert an even
pressure just above the cutting edge.
3. Move the cutting blade along the abrasive stone in a
figure-eight motion. Begin on the course side of the
stone and finish sanding on the fine side. Always
keep the blade at the same angle while sharpening.
4. After sharpening the blade there may be a
ragged burr on the cutting edge of the blade.
5. Remove this burr by gently rubbing the flat
side of the blade on a fine abrasive stone.
