Central Park CA8001 User manual

Battery charger
Model: CA8001 / CA8005
GB
KEEP THIS CAREFULLY FOR INSTALLATION INSTRUCTIONS
SAFETY USE
Read the manual to reduce the risk to injuries.
Keep the manual of the device, so that you can consult it later.
This document is an original manual.
Made in China 2021

USER MANUAL
GB
SAVE THIS MANUAL FOR FUTURE REFERENCE2
Product safety
General safety warnings
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious
injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision .
If the supply cord is damaged, It must be replaced by the
manufacturer, its service agent or similarly qualied persons
in order to avoid a hazard.
Additional safety instructions for your Battery Charger
1. Before charging, read the instructions.
2. Do not charge a leaking battery.
3. Do not use chargers for works other than those for which
they are designed.
4. Before charging, ensure your charger is matching the local
AC supply.
5. The charging device must be protected from moisture.
6. Do not use the charging device in the open.
7. Do not short out the contacts of battery or charger.
8. Respect the polarity “+/-“ when charging.
9.Do not open the unit and keep it out of the reach of
children.
10.Do not charge the batteries of other manufactures or ill-
suited models.
11.Ensure that the connection between the battery charger
and battery is correctly positioned and is not obstructed by

USER MANUAL
GB
SAVE THIS MANUAL FOR FUTURE REFERENCE 3
foreign bodies.
12.Keep battery charger’s slots free of foreign objects and
protect against dirt and humidity. Store in a dry and frost-
free place.
13.When charging batteries, ensure that the battery charger
is in a well-ventilated area and away from inammable
materials. Batteries can get hot during charging. Do
not overcharge any batteries. Ensure that batteries and
chargers are not left unsupervised during charging.
14.Do not recharge non-rechargeable batteries, as they can
overheat and break.
15.Longer life and better performance can be obtained if
the battery pack is charged when the air temperature is
between 18OC and 24OC. Do not charge the battery pack
in air temperatures below 0OC, or above 40OC. This is
important as it can prevent serious damage to the battery
pack.
16.Charge only battery pack of the same model provided
by Central Park@and of models recommended by Central
Park@.
Symbols
Read the operator’s manual.
Warning
Double insulation
Positive terminal
Negative terminal
Waste electrical products must not be disposed of with household waste. Please
recycle where facilities exist. Check with your local authorities or retailer for
recycling advice.

USER MANUAL
GB
SAVE THIS MANUAL FOR FUTURE REFERENCE4
T 1.5A Fuse (for CA8001)
T 3A Fuse (for CA8005)
SMPS (Switch mode power supply unit )
SMPS incorporating a short-circuit-proof safety isolating transformer (inherently or
non-inherently )

USER MANUAL
GB
SAVE THIS MANUAL FOR FUTURE REFERENCE 5
Overview
1. Power adapter
2. Connector
Not all the accessories illustrated or described are included in standard delivery.
We recommend that you purchase your accessories from the same store that sold you the tool.
Refer to the accessory packaging for further details. Store personnel can assist you and offer
advice.
Technical data
Model CA8001 for 10075841 (CP-Ro2.0/500) CA8005 for 10075842 (CP-Ro2.0/1000)
Charger voltage 100-240V~ 50/60Hz
Power input 38W 90W
Output voltage 20V 1.5A 20V 3.0A
Battery type Lithium-ion
Charging time (approx.)
2.0Ah 78 mins approx. 42 mins approx.
Machine weight 300 g 590 g
Protection class /II
1
2

USER MANUAL
GB
SAVE THIS MANUAL FOR FUTURE REFERENCE6
CHARGING PROCEDURE
NOTE: Before using the charger, read the instruction book carefully.
HOW TO USE YOUR CHARGER
1. Plug charger directly into an electrical outlet. DO NOT ABUSE THE CORD. Never carry charger by
cord. Do not disconnect the charger from the outlet by pulling it by the cord.
2. CAUTION: To reduce the risk of re, electrical shock, or personal injury do not attempt to use this
charger with any other product.
Likewise, do not attempt to charge the mower with any other charger.
3. Do not operate a damaged charger. Replace damaged cords or charger immediately at an authorized
Central Park@service depot.
4. Do not charge in wet locations. Do not charge mower when temperature is above 104°F (40°C) or
below 41°F (5°C).
5. Keep the mower and charger away from water, heat sources, (such as radiators, heaters, stoves...etc.)
ames, or chemicals. Be careful not to damage the charger cord, by keeping cord away from sharp
edges.
CONNECTING THE CHARGING STATION
1. When connecting the charging base’s power cord to the adapter, align the notch on the power cord (b)
with the groove on the adapter (a).
2. Connect the charger’s power cord to a wall socket. It is preferable to use an earth-fault breaker as
recommended.
ab
C) CHARGING A DISCHARGED BATTERY
When Central Park@is new or has been stored for a long period, the battery will not be charged and needs
to be charged before starting.
1) Place Central Park@in the working area.
2) Press on/off button to start. Press HOME then OK to send Central Park@back to the charging base.
3) The charging base green light will be ashing, Central Park@will begin to charge.

USER MANUAL
GB
SAVE THIS MANUAL FOR FUTURE REFERENCE 7
ab
MAINTENANCE
Remove the plug from the socket before carrying out any adjustment, servicing or
maintenance.
Your charger requires no additional lubrication or maintenance. Never use water or chemical
cleaners to clean your charger. Wipe clean with a dry cloth. Always store your charger in a dry
place.
ENVIRONMENTAL PROTECTION
Waste electrical products must not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authorities or retailer for recycling advice.

USER MANUAL
GB
SAVE THIS MANUAL FOR FUTURE REFERENCE8
Warranty
Maxeda DIY BV within the warranty guarantees that the product is free from defects in material and
workmanship under normal use, if installation and maintenance instructions are followed, and normal
storage (storage means the condition where the product is not used for the intended purpose).
The warranty period begins on the date of retail purchase by the original end-use buyer. For different
products and components of products are subject to different warranty periods. On (the pack) you
purchased the product can be found in the applicable guarantee.
Exclusions
This warranty does not cover:
(a) wear, corrosion, discoloration and deterioration due to normal use and storage,
(b) damage due to incorrect and / or improper maintenance,
(c) damage caused to the product external causes such as re, water (vapor, liquid, ice),
misapplication, fall, neglect, misuse (including but not limited to use in violation of the Maxeda DIY
Ltd instructions) or abuse.
(d) supplies and replaceable parts including batteries (one year warranty) and batteries.
When invoking the guarantee, the product (or part) and the original purchase receipt must be
submitted.

USER MANUAL
GB
SAVE THIS MANUAL FOR FUTURE REFERENCE 9
CE Declaration of Conformity
We
Maxeda DIY B.V.
22954, 1100 DL Amsterdam Zuidoost
Netherlands
hereby declare that the following:
Product: Battery charger
Type of Product: CA8001 & CA8005
Trademark: Central Park
satises the requirement of the Council Directives:
- Low Voltage Directives 2014/35/EU
- Directives of Electromagnetic Compatibility 2014/30/EU
- Restriction of the use of certain hazardous substances in electrical and electronic equipment
2011/65/EU&(EU)2015/863
and conforms to the standards :
EN 60335-1
EN 60335-2-29
EN 62233
EN 55014-1
EN 55014-2
EN IEC 61000-3-2
EN 61000-3-3
EN 61558-1
EN 61558-2-16
Date of issue: 2021-11-15 Year of CE marking: 2021
Signature: Chief Executive Ofcer
G. Colleau
Manufacturer
Maxeda DIY B.V.
Postbus 22954,
1100 DL Amsterdam Zuidoost.
Netherlands
www.diymaxeda.com
