Chauvet LX GO User manual

User Manual
English
EN
Español ES
Français FR

Edition Notes
LX Go™ User Manual Rev. 4
Edition Notes
The LX Go™ User Manual Rev. 4 ML covers the description, safety precautions,
installation, programming, operation, and maintenance of the LX Go™. CHAUVET®
released this edition of the LX Go™ User Manual in February 2013.
Trademarks
CHAUVET® is a registered trademark of CHAUVET & Sons Inc. (d/b/a CHAUVET® or
Chauvet). The CHAUVET® logo in its entirety including the CHAUVET® name and
the
dotted triangle, and all other trademarks in this manual pertaining to services, products,
or marketing statements (example: It’s Green Thinking™) are owne
d or licensed by
CHAUVET®. Any other
product names, logos, brands, company names, and other
trademarks featured or referred to within this document are the property of their
respective trademark holders.
Copyright Notice
CHAUVET® owns the content of this User Manual in its entirety, including but not limited
to pictures, logos, trademarks, and resources.
© Copyright 2013 CHAUVET®. All rights reserved.
Electronically published by CHAUVET® in the United States of America.
Manual Use
CHAUVET® authorizes its customers to download and print this manual for professional
information purposes only. CHAUVET® expressly prohibits the u
sage, copy, storage,
distribution, modification, or printing of this manual or its content for any other purpose
without written consent from CHAUVET®.
Document Printing
For better results, print this document in color, on letter size paper (8.5 x 11 in), double-
sided. If using A4 paper (210 x 297 mm), configure your printer to scale the content
accordingly.
Intended Audience
Any person in charge of installing, operating, and/or maintaining this product should
completely read through the guide that shipped with the product, as well as this manual,
before installing, operating, or maintaining this product.
Disclaimer
CHAUVET® believes that the information contained in this manual is accurate in all
respects. However, CHAUVET® assumes no responsibility for any errors or omissions
in this document. CHAUVET® reserves the right to revise and make changes to the
content of this document without obligation that CHAUVET®
notify any person or
company of such revision or changes. This does not in any way constitute a
commitment by CHAUVET® to make such changes. CHAUVET® may issue a revision
of this manual or a new edition to incorporate such changes.
Document Revision
The LX Go™ User Manual Rev. 4 ML supersedes all previous versions of this manual.
Discard any older versions of this manual you may have, whether in printed or electronic
format, and replace with this version.
Author Date Editor Date
D. Couppe
2/18/13
S. Diaz
2/18/13

Table of Contents
LX Go™ User Manual Rev. 4 ML -i-
Table of Contents
1. Before You Begin ......................................................................................................................................1
What Is Included .................................................................................................................................................... 1
Claims..................................................................................................................................................................................1
Conventions .........................................................................................................................................................................1
Symbols ...............................................................................................................................................................................1
Product at a Glance ............................................................................................................................................... 2
Safety Notes .......................................................................................................................................................... 2
Personal Safety ....................................................................................................................................................................2
Mounting and Rigging...........................................................................................................................................................2
Power and Wiring .................................................................................................................................................................2
Operation .............................................................................................................................................................................2
2. Introduction ...............................................................................................................................................3
Description............................................................................................................................................................. 3
Features ................................................................................................................................................................ 3
Overview................................................................................................................................................................ 3
Dimensions............................................................................................................................................................ 4
3. Setup..........................................................................................................................................................5
AC Power .............................................................................................................................................................. 5
AC Plug................................................................................................................................................................................5
Fuse Replacement................................................................................................................................................................5
DMX Linking .......................................................................................................................................................... 6
DMX Modes..........................................................................................................................................................................6
Mounting................................................................................................................................................................ 6
Orientation............................................................................................................................................................................6
Rigging.................................................................................................................................................................................6
4. Operation ...................................................................................................................................................7
Control Panel Description....................................................................................................................................... 7
Control Options...................................................................................................................................................... 7
Programming ......................................................................................................................................................... 7
DMX Personality...................................................................................................................................................................7
DMX Control.........................................................................................................................................................................7
DMX CAST...........................................................................................................................................................................7
DMX Recording ....................................................................................................................................................................7
Static Color...........................................................................................................................................................................8
Auto Programs......................................................................................................................................................................8
Setup/Play Chase Programs .................................................................................................................................................8
Edit/Play Customs ................................................................................................................................................................8
Set Time...............................................................................................................................................................................8
Set/Play Schedule ................................................................................................................................................................9
Control Panel Lock ...............................................................................................................................................................9
Adjustment Lock...................................................................................................................................................................9
Password .............................................................................................................................................................................9
Program Upload ...................................................................................................................................................................9
Reset ...................................................................................................................................................................................9
IRC (Infrared Remote Control) Operation ..............................................................................................................10
EASYPLAY...........................................................................................................................................................10
Effect Key Programming .....................................................................................................................................................10
Color Key Programming......................................................................................................................................................10
Menu Map.............................................................................................................................................................11
Menu Map (cont.)..................................................................................................................................................12
DMX Values..........................................................................................................................................................13
5. Technical Information .............................................................................................................................14

Table of Contents
-ii- LX Go™ User Manual Rev. 4 ML
Product Maintenance ............................................................................................................................................14
Returns.................................................................................................................................................................14
Technical Specifications........................................................................................................................................15
1. Antes de Empezar ...................................................................................................................................17
Qué va Incluido.....................................................................................................................................................17
Reclamaciones ...................................................................................................................................................................17
Convenciones.....................................................................................................................................................................17
Símbolos ............................................................................................................................................................................17
El Producto de un Vistazo .....................................................................................................................................18
Notas de Seguridad ..............................................................................................................................................18
Seguridad Personal ............................................................................................................................................................18
Montaje e Instalación..........................................................................................................................................................18
Alimentación y Cableado.....................................................................................................................................................18
Funcionamiento..................................................................................................................................................................18
2. Introducción ............................................................................................................................................19
Descripción...........................................................................................................................................................19
Características......................................................................................................................................................19
Vista General ........................................................................................................................................................19
Dimensiones.........................................................................................................................................................20
3. Instalación ...............................................................................................................................................21
Corriente Alterna...................................................................................................................................................21
Enchufe CA........................................................................................................................................................................21
Sustitución del Fusible ........................................................................................................................................................21
Enlace DMX..........................................................................................................................................................22
Modos DMX........................................................................................................................................................................22
Montaje.................................................................................................................................................................22
Orientación.........................................................................................................................................................................22
Colocación .........................................................................................................................................................................22
4. Funcionamiento.......................................................................................................................................23
Descripción del Panel de Control ..........................................................................................................................23
Opciones de Control .............................................................................................................................................23
Programación .......................................................................................................................................................23
Personalidad DMX..............................................................................................................................................................23
Control DMX.......................................................................................................................................................................23
DMX CAST.........................................................................................................................................................................24
Grabación DMX..................................................................................................................................................................24
Color Estático .....................................................................................................................................................................24
Programas Automáticos......................................................................................................................................................24
Configurar/Reproducir Programas de Secuencia..................................................................................................................24
Editar/Reproducir Personalizados .......................................................................................................................................25
Establecer el Tiempo ..........................................................................................................................................................25
Configurar/Ejecutar Agenda ................................................................................................................................................25
Bloqueo del Panel de Control..............................................................................................................................................25
Bloqueo de Ajuste...............................................................................................................................................................25
Contraseña.........................................................................................................................................................................26
Subir el Programa...............................................................................................................................................................26
Reset .................................................................................................................................................................................26
Funcionamiento del IRC (Control Remoto por Infrarrojos)......................................................................................27
EASYPLAY...........................................................................................................................................................27
Programación de Teclas de Efectos ....................................................................................................................................27
Programación de Teclas de Color .......................................................................................................................................27
Mapa de Menú......................................................................................................................................................28
Mapa de Menú (cont.)...........................................................................................................................................29
Valores DMX.........................................................................................................................................................30

Table of Contents
LX Go™ User Manual Rev. 4 ML -iii-
5. Información Técnica ...............................................................................................................................31
Mantenimiento del Producto..................................................................................................................................31
Devoluciones ........................................................................................................................................................31
Especificaciones Técnicas ....................................................................................................................................32
1. Avant de Commencer..............................................................................................................................34
Ce qui est Compris................................................................................................................................................34
Réclamations......................................................................................................................................................................34
Conventions .......................................................................................................................................................................34
Symboles ...........................................................................................................................................................................34
Vue d'ensemble de l'appareil.................................................................................................................................35
Consignes de Sécurité ..........................................................................................................................................35
Sécurité Personnelle...........................................................................................................................................................35
Montage et Suspension ......................................................................................................................................................35
Alimentation et Câblage......................................................................................................................................................35
Fonctionnement..................................................................................................................................................................35
2. Introduction .............................................................................................................................................36
Description............................................................................................................................................................36
Caractéristiques....................................................................................................................................................36
Aperçu..................................................................................................................................................................36
Dimensions...........................................................................................................................................................37
3. Configuration...........................................................................................................................................38
Alimentation CA ....................................................................................................................................................38
Prise CA.............................................................................................................................................................................38
Remplacement du Fusible...................................................................................................................................................38
Raccordement DMX..............................................................................................................................................39
Modes DMX........................................................................................................................................................................39
Installation ............................................................................................................................................................39
Orientation..........................................................................................................................................................................39
Suspension ........................................................................................................................................................................39
4. Fonctionnement ......................................................................................................................................40
Description du Tableau de Commandes................................................................................................................40
Options de Commande .........................................................................................................................................40
Programmation .....................................................................................................................................................40
Personnalités DMX.............................................................................................................................................................40
Commande DMX ................................................................................................................................................................40
CAST DMX.........................................................................................................................................................................40
Enregistrement DMX...........................................................................................................................................................41
Couleur Statique.................................................................................................................................................................41
Programmes Automatiques.................................................................................................................................................41
Configuration et Lecture des Programmes de Chenillards ....................................................................................................41
Modifier et Lire les Programmes Personnalisés....................................................................................................................42
Configurer la Date et l'heure................................................................................................................................................42
Configurer et Lire un Programme Planifié ............................................................................................................................42
Verrouillage du Panneau de Commande .............................................................................................................................42
Verrou d'ajustement............................................................................................................................................................43
Mot de Passe .....................................................................................................................................................................43
Téléchargement du Programme..........................................................................................................................................43
Réinitialisation ....................................................................................................................................................................43
Fonctionnement de la Télécommande à Infrarouge ...............................................................................................44
EASYPLAY...........................................................................................................................................................44
Programmation de la Touche d'effet ....................................................................................................................................45
Programmation de la touche d'couleur.................................................................................................................................45
Tableau du Menu..................................................................................................................................................46
Tableu de Menu (suite) .........................................................................................................................................47

Table of Contents
-iv- LX Go™ User Manual Rev. 4 ML
Valeurs DMX.........................................................................................................................................................48
5. Informations Techniques........................................................................................................................49
Entretien de l'appareil............................................................................................................................................49
Renvois ................................................................................................................................................................49
Spécificités Techniques.........................................................................................................................................50
Contact Us............................................................................................................................................................50

Before You Begin
LX Go™ User Manual Rev. 4 -1-
1. Before You Begin
What Is Included
•LX Go™
•Hanging Bracket
•LX Go™ Infrared Remote Control (IRC)
•Warranty Card
•User Manual
Claims
Carefully unpack the product immediately and check the box to make sure all the parts
are in the package and are in good condition.
If the box or the contents (the product and included accessories) appear damaged from
shipping or show signs of mishandling, notify the carrier immediately, not CHAUVET®.
Failure to r
eport damage to the carrier immediately may invalidate your claim. In
addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping,
or concealed damage, file a claim with CHAUVET® within 7 days of delivery.
Conventions
Convention
Meaning
1~512
A range of values in the text
50/60
A set of mutually exclusive values in the text
<SET>
A button on the product’s control panel
Settings
A product function or a menu option
MENU>Settings
A sequence of menu options
1~10
A range of menu values from which to choose in a menu
Yes/No
A set of two mutually exclusive menu options in a menu
ON
A unique value to be entered or selected in a menu
Symbols
Symbols Meaning
Critical installation, configuration, or operation information.
Failure to comply with this information may cause the product not
to work, damage third-party equipment, or cause harm to the
operator.
Important installation or configuration information. Failure to
comply with this information may keep the product from working.
Useful information.
The term “DMX” used throughout this manual refers to the USITT DMX512-A
digital data transmission protocol.

Before You Begin
-2- LX Go™ User Manual Rev. 4
Product at a Glance
Use on Dimmer

Auto Programs

Outdoor Use

Auto-Ranging Power
Supply

Sound Activated

Replaceable Fuse

DMX

User Serviceable

Master/Slave

Duty Cycle

Safety Notes
Read all the following Safety Notes before working with this product. These notes
include important information about the installation, usage, and maintenance of this
product.
This product contains no user-serviceable parts. Any reference to servicing in
this User Manual will only apply to properly trained CHAUVET® certified
technicians. Do not open the housing or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this
product.
Personal Safety
•Always disconnect this product from its power source before servicing.
•Always connect this product to a grounded circuit to avoid the risk of electrocution.
Mounting and
Rigging
•This product is for indoor use only! To prevent risk of fire or shock, do not expose
this product to rain or moisture.
•Make sure there are no flammable materials close to this product while it is
operating.
•When hanging this product, always secure to a fastening device using a safety
cable (included).
Power and Wiring
•Always make sure you are connecting this product to the proper voltage in
accordance with the specifications in this manual or on the product’s specification
label.
•Never connect this product to a dimmer pack or rheostat.
•Never disconnect this product by pulling or tugging on the power cable.
Operation
•Do not operate this product if you see damage on the housing or cables. Have the
damaged parts replaced by an authorized technician at once.
•Do not cover the ventilation slots when operating to avoid internal overheating.
•The maximum ambient temperature is 104° F (40° C). Do not operate this product
at a higher temperature.
•In case of a serious operating problem, stop using this product immediately!
In the unlikely event that your CHAUVET® product may require service, contact
CHAUVET® Technical Support.

Introduction
LX Go™ User Manual Rev. 4 -3-
2. Introduction
Description
The LX Go™ is a DMX controller product. This product is intended to be used for control
over other DMX compatible products. The LX Go™ gives the user the ability
to record,
playback, and program custom and static looks using DMX.
Features
•Rugged and compact DMX recorder and playback device
•Record and playback up to 12 hours of cues on 1 universe of DMX
•Trigger cues and pre-programmed effects with included LX Go™ Infrared Remote
Control (IRC)
•Schedule playback for specific times on specific days of the week
•Locking 5-pin DMX in/out and IEC connector
Overview
Control
Panel
Mounting
Bracket
IRC
Receiver

Introduction
-4- LX Go™ User Manual Rev. 4
Dimensions

Setup
LX Go™ User Manual Rev. 4 -5-
3. Setup
AC Power
Each LX Go™ has an auto-ranging power supply that works with an input voltage range
of 100~240 VAC, 50/60 Hz. To determine the power requirements for each LX Go™
,
refer to the label affixed to the product. You can also refer to the Technical Specifications
chart in this manual.
The listed current rating indicates the maximum current draw during normal operation.
For more information, you may download Sizing Circuit Breakers from the CHAUVET
®
website: www.chauvetpro.com.
Always connect this product to a protected circuit with an appropriate electrical
ground to avoid the risk of electrocution or fire.
Never connect this product to a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0 to 100% switch.
AC Plug
The LX Go™ comes with a power input cord terminated with an IEC connector on one
end and an Edison plug on the other end (U.S. market). If the power input
cord that
came with your product has no plug or you need to change the Edison plug, use the
table below as a guide to wire the new plug.
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live
Black
Brown
Yellow or Brass
AC Neutral
White
Blue
Silver
AC Ground
Green/Yellow
Green/Yellow
Green
Make sure to disconnect the product’s power cord before replacing a blown fuse.
Always replace with a fuse of the same type and rating.
Fuse Replacement
1. Disconnect the product from the power outlet.
2. Using a flat-head screwdriver, wedge the tip into the slot of the fuse holder.
3. Pry the safety cap out of the housing to pull out the installed fuse.
4. Remove the blown fuse from the safety cap and replace with a fuse of the exact
same type and rating (T 500mA, 250 V).
5. Insert the fuse holder back in place and reconnect the power.
Installed fuse
(held by plastic clip)
Spare fuse
(inside safety cap)
Safety cap

Setup
-6- LX Go™ User Manual Rev. 4
DMX Linking
You can link the LX Go™ to a DMX controller using a standard DMX serial connection. If
using other DMX compatible products with the LX Go™
, you can control each
individually with a single DMX controller.
DMX Modes
The LX Go™ uses the standard DMX data connection for the 3, 4, and 5 channel DMX
modes.
•Refer to the Introduction chapter for a brief description of these modes.
•Refer to the Operation chapter to learn how to configure the LX Go™
to work in these
modes.
•The DMX Values
section will provide you with detailed information regarding the DMX
modes.
If you are not familiar with or need more information about DMX standards or the
DMX cables needed to link this product to
a DMX controller, download the DMX
Primer from the CHAUVET® website:
www.chauvetpro.com.
Mounting
Before mounting this product, read and follow the Safety Notes in this manual.
Orientation
Always mount this product in a safe position and make sure there is adequate room for
ventilation, configuration, and maintenance.
Rigging
The LX Go™ includes a bracket that connects to the body of the product CHAUVET®
recommends using the following general guidelines when mounting this product.
•When selecting an installation location, consider easy access to this product for
operation, programming adjustments, and routine maintenance.
•Make sure to mount this product away from any flammable material as indicated in
the Safety Notes.
•Never mount in places where rain, high humidity, extreme temperature changes, or
restricted ventilation may affect the product.
•If hanging this product, make sure that the mounting location can support the
product’s weight. Refer to the Technical Specifications chart for the weight-bearing
requirements of this product.
•When hanging this product, always secure to a fastening device using a safety cable
(included).
Procedure
The LX Go™ comes with a mounting bracket to which you can attach mounting clamps
for hanging.
You may also use the bracket to mount it to almost any surface using
screws. Make sure all hardware and surfaces are capable of supporting the product’
s
weight. You will have to use at least 1 mounting point per product.
Product Mounting Diagram
Floor Mounting
Overhead Mounting
Clamp
Mounting
Screws

Operation
LX Go™ User Manual Rev. 4 -7-
4. Operation
Control Panel
Description
Button Function
<MENU>
Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently
selected value in to the current function
<UP>
Navigates upward through the menu list and increases the
numeric value when in a function
<DOWN>
Navigates downward through the menu list and decreases the
numeric value when in a function
Control Options
You can set the LX Go™ start address in the 001~512 DMX range.
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main
level and a variable number of programming levels for each option.
•To go to the desired main level, press <MENU> repeatedly until the option shows on
the display. Press <ENTER> to select. This will take you to the first programming
level for that option.
•To select an option or value within the current programming level, press <UP> or
<DOWN> until the option shows on the display. Press <ENTER> to select. In this
case, if there is another programming level, you will see that first option, or you will
see the selected value.
•Press <MENU> repeatedly to exit to the previous main level.
DMX Personality
This setting allows you to choose a particular DMX personality.
1. Go to the SETTINGS > PERSON level.
2. Select the desired personality (RGB, RGBW, or RGBWA).
•See the DMX Values section for the highest starting address you can select for
each personality.
•Make sure that the starting addresses on the various products do not overlap
due to the new personality setting.
DMX Control
In this mode, each product will respond to a unique starting address from the DMX
controller. All products with the same starting address will respond in unison.
1. Select a DMX personality as shown in DMX Personality.
2. Set the starting address:
a. Go to SETTINGS > ADDRESS level.
b. Select the starting address (001~512).
DMX CAST
In this mode, the LX Go™ can record up to 12 hours of continuous DMX programming
data from another DMX controller and play it back from the control panel, scheduled
playback mode, or IRC.
DMX Cast Recording
This setting allows you to record up to 12 hours of DMX programming on a single
universe.
1. Go to Edit > DMXCAST > RECORD PASSWORD level.
2. Enter the master access password as shown in Password.
3. Press <ENTER> or move channel 1 on the DMX controller to a value between
011~099, to start recording. “DMXCAST RECEIVING” will be displayed.
4. Press <ENTER> again or move channel 1 on the DMX controller to a value between
201~255, to end recording. “DMXCAST STOP” will be displayed.
DMX Cast Playback
1. Go to PLAY > DMXCAST > level.
2. Press <ENTER>

Operation
-8- LX Go™ User Manual Rev. 4
Static Color
The Static Color mode allows for permanent RGBWA color mixing without a DMX
controller.
1. Go to the PLAY > STATIC level.
2. Select the desired color (RED, GREEN, BLUE, WHITE, or AMBER).
3. Select the desired color value (000~255).
4. Repeat for the other colors.
5. Select the desired intensity (DIMMER).
6. Select the desired value (000~255)
7. Select STROBE.
8. Select the desired frequency (000~255).
Be sure the starting address of both the LX Go™ and the first unit in line are the
same when running in STATIC mode.
Auto Programs
Auto programs allow for dynamic RGBWA color mixing without a DMX controller.
1. Go to PLAY > AUTO level.
2. Select the desired auto program (AUTO 01~10).
3. Select auto program speed (SPEED 00~20)
Setup/Play Chase
Programs
Chase programs allow for RGBWA color chasing between various products without a
DMX controller.
1. Go to SETTINGS > CHASE RANGE level.
2. Select the number of products that are going to be involved in the chase (000~100)
3. Go to PLAY > CHASE.
4. Select the desired chase program (CHASE 01~18).
5. Select chase program speed (
SPEED -20~20
)
You cannot edit any of the auto or chase programs. However, you can edit the
custom programs.
Edit/Play Customs
This setting allows the programming of up to 20 scenes for each of the 5 customizable
programs.
1. Go to the EDIT > CUSTOM level.
2. Select the desired custom program to edit (CUSTOM 1~5).
3. Select the desired step (STEP 01~20).
4. Select the desired color or effect (RED, GREEN, BLUE, STROBE, STEP TIME, or
FADE TIME).
5. Select the color, strobe, or time value (000~255).
6. Return to the step (STEP 01~20) level.
7. Repeat the settings of colors and effects for the other steps.
8. Go to the PLAY > CUSTOM.
9. Select desired custom program (CUSTOM 1~5).
10. Select custom program speed (
SPEED 00~20
).
Set Time
This option saves the time and day to your LX Go™.
1. Go to SETTINGS > CLOCK > EDIT TIME level.
2. Enter Day (MONDAY~SUNDAY)
3. Enter Time (00:00).
To view the settings without making any changes.
Go to
SETTINGS > CLOCK > VIEW TIME
level.

Operation
LX Go™ User Manual Rev. 4 -9-
Set/Play Schedule
This setting allows you to set a date and time for the product to run automatically.
1. Go to EDIT > SCHEDULE level.
2. Select TASK (1~10).
a. Select DATE.
b. Enter Day (MONDAY~SUNDAY) or (EVERYDAY).
c. Enter START TIME (00:00).
d. Enter END TIME (00:00).
e. Select RUN.
f. Enter program to run (AUTO 01~10, CHASE 01~18, CUSTOM 1~5, or
DMXCAST).
3. Go to
PLAY > SCHEDULE
level to start. (
PLAYING SCHEDULE
) will display.
Control Panel Lock
This setting enables you to activate or disable the control panel lock, which keeps non-
authorized personnel from changing the product’s settings.
1. Go to SETTINGS > KEY level.
2. Select
ON
or
OFF
.
Adjustment Lock
This setting allows you to lock the EDIT and/or SPEED settings.
1. Go to SETTINGS > ALLOW SPEED or SETTINGS > ALLOW EDIT level.
2. Select YES to activate or NO to disable.
a. When PASSWORD shows, enter the master access password as shown in
Password.
When the control panel lock is active, the product will prompt you to enter the
password after 30 seconds of control panel inactivity or after turning on the
product.
Password
After being prompted to enter the password:
Press
<UP>, <DOWN>, <UP>, <DOWN>, <ENTER>
.
The Password is fixed by default and cannot be changed.
Program Upload
This option allows you to copy the custom programs of one LX Go™ onto other LX Go™
by using the Master/Slave mode.
1. Configure and connect the products in a Master/Slave arrangement, where the
master product has the custom programs you want to transfer to the slave products.
2. From the master product, go to the SETTINGS > UPLOAD level.
3. Select UPLOAD.
4. When PASSWORD shows, enter the master access password as shown in
Password.
5. Wait for the upload process to finish.
DO NOT upload the data from a LX Go™ to a different product. The other product
may become inoperative.
Reset
This setting gives you 3 options to reset the LX Go™ to the default values.
1. Go to the SETTINGS > RESET level.
2. Select RESET CUSTOM,RESET SCHEDULE, or RESET ALL.
3. When PASSWORD shows, Enter the master access password as described in
Password.
4. Wait for the reset process to finish.

Operation
-10- LX Go™ User Manual Rev. 4
LX Go™ IRC
(Infrared Remote
Control) Operation
The LX Go™ IRC will only operate in EASYPLAY mode on the LX Go™.
EASYPLAY
The LX Go™ allows control of some attributes via an IRC remote. The LX Go™ can be
programmed so that effect and color buttons on the remote will control playback while in
“EASYPLAY” mode.
Effect Key
Programming
This setting allows you to program the effect keys on the IRC remote.
1. Go to EDIT > EASYPLAY level.
2. Select a key to program (EFFECTKEY 1~6).
3. Enter program to run (AUTO 01~10, CHASE 01~18, CUSTOM 1~5, or DMXCAST).
4. Repeat steps 2 and 3 for other keys.
5. Go to PLAY > EASYPLAY level to start. (PLAYING EASYPLAY) will display.
6. Press the corresponding effect key to confirm programming.
Color Key
Programming
This setting allows you to program the color keys on the IRC remote.
1. Go to EDIT > EASYPLAY level.
2. Select a key to program (COLORKEY 1~6)
3. Select a color or effect (RED, GREEN, BLUE, or STROBE).
4. Select the value (000~255).
5. Repeat steps 2 through 4 for other keys.
6. Go to PLAY > EASYPLAY level to start. (PLAYING EASYPLAY) will display.
7. Press the corresponding color key to confirm programming.
Static
Play
On/Off
Red
+/-
Green
+/-
Blue
+/-
Strobe
+/-
Color
Key
Control
Effect
Key
Control
Speed
Control
Intensity
Control

Operation
LX Go™ User Manual Rev. 4 -11-
Menu Map
Main Level Programming Levels Description
PLAY
STATIC
RED
000~255
Combine Red, Green, Blue, White, and
Amber
to make a custom color
GREEN
BLUE
WHITE
AMBER
DIMMER
Selects the overall intensity
STROBE
Selects the strobe frequency (00~20 Hz)
AUTO
AUTO
(01~10)
SPEED
(00~20)
Choose from 10 automatic programs
CHASE
CHASE
(01~18)
SPEED
(-20~20)
Choose from 18 chase programs
CUSTOM
CUSTOM
(1~5)
SPEED
(00~20)
Choose from 5 customizable programs
DMXCAST
PLAYING DMXCAST
Selects DMXCAST Mode
EASYPLAY
PLAYING EASYPLAY
Selects EASYPLAY Mode
SCHEDULE
PLAYING SCHEDULE
Selects Schedule Mode
SETTINGS
ADDRESS
001~512
Sets the DMX starting Address
PERSON
RGB
3-Channel: RGB
RGBW
4-Channel: RGBW
RGBWA
5-Channel: RGBWA
CHASE RANGE 000~100
Select the amount of products for Chase
Modes.
KEY
ON
Turns the password on or off
OFF
ALLOW SPEED
YES
Enable/Disable speed lockout
NO
ALLOW EDIT
YES
Enable/Disable edit lockout
NO
RESET
RESET CUSTOM
PASSWORD
(****)
Defaults custom programs to factory default
RESET
SCHEDULE
Defaults Scheduled programs to factory default
RESET ALL
Defaults all settings to factory default
CLOCK
VIEW TIME
(DAY)
00:00
Views current time/day set in the product
EDIT TIME
Edits current time/day set in the product
UPLOAD YES
PASSWORD
(****)
Uploads all settings to other LX Go™
NO

Operation
-12- LX Go™ User Manual Rev. 4
Menu Map (cont.)
Main Level Programming Levels Description
EDIT
CUSTOM CUSTOM
(1~5)
STEP
(01~20)
RED
000~255
Combine Red, Green, and Blue to generate
custom color.
GREEN
BLUE
STROBE
Select a strobe frequency
STEP
TIME
Defines step duration
FADE
TIME
Defines fade duration
SCHEDULE TASK
(01~10)
RUN
AUTO
(01~10)
Run an auto program via schedule mode
CHASE
(01~18)
Run a chase program via schedule mode
CUSTOM
(01~05)
Run a custom program via schedule mode
DMXCAST
Run a pre-recorded DMX program via
schedule mode
DATE
MONDAY~
SUNDAY
Assigns the day a scheduled program will run
EVERYDAY
Sets scheduled program to run everyday
START TIME
00:00
Sets start time to run program
END TIME
Sets end time to run program
EASYPLAY
EFFECTKEY
(1~6)
AUTO
(01~10)
Assigns auto program to a selected effect key
on IRC
CHASE
(01~18)
Assigns chase program to a selected effect key
on IRC
CUSTOM
(1~5)
Assigns custom program to a selected effect
key on IRC
DMXCAST
Assigns DMXCAST program to a selected
effect key on IRC
COLORKEY
(1~6)
RED
000~255
Combine Red, Green, Blue, and Strobe to
generate custom color effect and assign it to a
color key on IRC.
GREEN
BLUE
STROBE
DMXCAST RECORD
PASSWORD
(****)
WAIT Enable/disable DMX recording

Operation
LX Go™ User Manual Rev. 4 -13-
DMX Values
RGB
Channel Function Value Percent/Setting
1
Red
000 255
0~100%
2
Green
000 255
0~100%
3
Blue
000 255
0~100%
RGBW
Channel
Function
Value
Percent/Setting
1
Red
000 255
0~100%
2
Green
000 255
0~100%
3
Blue
000 255
0~100%
4
White
000 255
0~100%
RGBWA
Channel
Function
Value
Percent/Setting
1
Red
000 255
0~100%
2
Green
000 255
0~100%
3
Blue
000 255
0~100%
4
White
000 255
0~100%
5
Amber
000 255
0~100%

Technical Information
-14- LX Go™ User Manual Rev. 4
5. Technical Information
Product
Maintenance
To maintain optimum performance and minimize wear, you should clean this product
frequently. Usage and environment are contributing factors in determining the cleaning
frequency.
As a rule, clean this product at least twice a month. Dust build-
up reduces light output
performance and can cause overheating. This can lead to reduced light source life and
increased mechanical wear.
To clean your product:
•Unplug the product from power.
•Wait until the product has cooled.
•Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on
the external vents and accessible internal components.
•Clean all external surfaces with a mild solution of non-ammonia glass cleaner or
isopropyl alcohol.
•Apply the solution directly to a soft, lint-free cotton cloth or a lens cleaning tissue.
•Wipe any dirt or grime to the outside edges of the lens surface.
•Gently polish the lens surfaces until they are free of haze and lint.
Always dry the external surfaces thoroughly and carefully after cleaning them.
Returns
You must send the product prepaid, in the original box, and with the original packing and
accessories. CHAUVET® will not issue call tags.
Call CHAUVET®
and request a Return Merchandise Authorization (RMA) number
before shipping the product. Be prepared to provide the model number, serial number,
and a brief description of the cause(s) for the return.
Clearly label the package with an RMA number. CHAUVET®
will refuse any product
returned without an RMA number.
DO NOT write the RMA number directly on the box. Instead, write it on a properly
affixed label.
Once you have received the RMA number, include the following information on a piece
of paper inside the box:
•Your name
•Your address
•Your phone number
•The RMA number
•A brief description of the problem(s)
Be sure to pack the product
properly. Any shipping damage resulting from inadequate
packaging will be the customer’s responsibility. FedEx packing or double-boxing
are
recommended.
CHAUVET® reserves the right to use its own discretion to repair or replace
returned product(s).
