Chauvet Freedom Par RGBA User manual

User Manual

Page 2 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
TABLE OF CONTENTS
1. Before You Begin...........................................................................................................6
What Is Included .........................................................................................................................6
Unpacking Instructions................................................................................................................6
Claims.................................................................................................................................................6
Text Conventions ........................................................................................................................6
Symbols......................................................................................................................................6
Disclaimer...................................................................................................................................6
Product at a Glance.....................................................................................................................7
Safety Notes ...............................................................................................................................7
2. Introduction....................................................................................................................8
Overview (Freedom™ Par RGBA)...............................................................................................8
Overview (Freedom™ Par RGBA)...............................................................................................9
Overview (Freedom™ Strip Mini RGBA)....................................................................................10
Dimensions (Freedom™ Par RGBA) .........................................................................................11
Dimensions (Freedom™ Strip Mini RGBA)................................................................................12
3. Setup.............................................................................................................................13
AC Power..................................................................................................................................13
Charging the Battery .................................................................................................................13
Battery Life Indicator .................................................................................................................13
Battery Maintenance..........................................................................................................................13
Fuse Replacement.............................................................................................................................14
Power Linking....................................................................................................................................15
Mounting...................................................................................................................................16
Orientation.........................................................................................................................................16
Rigging..............................................................................................................................................16
4. Operation......................................................................................................................17
Control Panel Operation............................................................................................................17
Menu Map.................................................................................................................................17
Configuration (DMX)..................................................................................................................18
Starting Address ................................................................................................................................18
DMX Personalities..............................................................................................................................18
DMX Channel Modes, Assignments, and Values.......................................................................19
5-CH..................................................................................................................................................19
4-CH..................................................................................................................................................19
Configuration (Standalone)........................................................................................................20
Automatic ACt Mode..........................................................................................................................20
ACt Auto Programs ............................................................................................................................21
Automatic ACtC Mode........................................................................................................................22
ACtC Auto Programs..........................................................................................................................22
IRC (Infrared Remote Control)............................................................................................................23
IRC Operation....................................................................................................................................23
IRC Operation (cont.).........................................................................................................................24
D-Fi™ 2.4 GHz (DMX Mode Auto Sync)..............................................................................................25
D-Fi™ 2.4 GHz (DMX Mode Manual Sync) .........................................................................................26
D-Fi™ 2.4 GHz (IR/Standalone Mode Auto Sync) ...............................................................................27
D-Fi™ 2.4 GHz (IR/Standalone Mode Manual Sync)...........................................................................28
Master/Slave Mode............................................................................................................................29
Master/Slave Runway Effect...............................................................................................................29
5. Technical Information..................................................................................................30
Product Maintenance ................................................................................................................30

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 3 of 88
6. Technical Specifications..............................................................................................31
Returns.....................................................................................................................................32
Contact Us................................................................................................................................32
1. Antes de Empezar........................................................................................................33
Qué va Incluido.........................................................................................................................33
Instrucciones de Desembalaje...................................................................................................33
Reclamaciones ..................................................................................................................................33
Convenciones de Texto.............................................................................................................33
Símbolos...................................................................................................................................33
Exención de Responsabilidad....................................................................................................33
El Producto de un Vistazo .........................................................................................................34
Notas de Seguridad...................................................................................................................34
2. Introducción .................................................................................................................35
Visión General (Freedom™ Par RGBA).....................................................................................35
Visión General (Freedom™ Par RGBA).....................................................................................36
Visión General (Freedom™ Strip Mini RGBA)............................................................................37
Dimensiones (Freedom™ Par RGBA) .......................................................................................38
Dimensiones (Freedom™ Strip Mini RGBA) ..............................................................................39
3. Instalación ....................................................................................................................40
Corriente Alterna.......................................................................................................................40
Cargar la Batería.......................................................................................................................40
Indicador de Duración de la Batería...........................................................................................40
Mantenimiento de la Batería...............................................................................................................40
Sustitución del Fusible .......................................................................................................................41
Alimentación en Cadena ....................................................................................................................42
Montaje.....................................................................................................................................43
Orientación........................................................................................................................................43
Colocación.........................................................................................................................................43
4. Funcionamiento............................................................................................................44
Funcionamiento del Panel de Control...........................................................................................44
Mapa de Menú..........................................................................................................................44
Configuración (DMX).................................................................................................................45
Dirección de Inicio..............................................................................................................................45
Personalidades DMX..........................................................................................................................45
Modos de Canal, Asignaciones y Valores DMX .........................................................................46
5-CH..................................................................................................................................................46
4-CH..................................................................................................................................................47
Configuración (Independiente)...................................................................................................47
Modo ACt Automático........................................................................................................................47
Programas ACt Auto ..........................................................................................................................48
Modo ACtC Automático......................................................................................................................49
Programas ACtC Auto........................................................................................................................49
IRC (Control Remoto por Infrarrojos) ..................................................................................................50
Funcionamiento del IRC.....................................................................................................................50
Funcionamiento del IRC (cont.) ..........................................................................................................51
D-Fi™ 2.4 GHz (Autosincronización Modo DMX)...................................................................................52
D-Fi™ 2.4 GHz (Sincronización Manual Modo DMX)...........................................................................53
D-Fi™ 2.4 GHz (Autosincronización Modo IR/Independiente).................................................................54
D-Fi™ 2.4 GHz (Sincronización Manual Modo IR/Independiente) ........................................................55
Modo Maestro/Esclavo.......................................................................................................................56
Efecto Runway Maestro/Esclavo ........................................................................................................56
5. Información Técnica ....................................................................................................57
Mantenimiento del Producto......................................................................................................57

Page 4 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
6. Especificaciones Técnicas..........................................................................................58
Devoluciones ............................................................................................................................59
Contacto ...................................................................................................................................59
1. Avant de Commencer...................................................................................................60
Ce qui est Compris....................................................................................................................60
Instructions Relatives au Déballage...........................................................................................60
Réclamations.....................................................................................................................................60
Conventions de Texte................................................................................................................60
Symboles..................................................................................................................................60
Clause de Non Responsabilité...................................................................................................60
Vue d'Ensemble de l'Appareil....................................................................................................61
Consignes de Sécurité ..............................................................................................................61
2. Introduction..................................................................................................................62
Vue d'Ensemble (Freedom™ Par RGBA)..................................................................................62
Vue d'Ensemble (Freedom™ Par RGBA)..................................................................................63
Vue d'Ensemble (Freedom™ Strip Mini RGBA).........................................................................64
Dimensions (Freedom™ Par RGBA) .........................................................................................65
Dimensions (Freedom™ Strip Mini RGBA)................................................................................66
3. Configuration................................................................................................................67
Alimentation CA ........................................................................................................................67
Chargement de la Batterie.........................................................................................................67
Indicateur de Vie de la Batterie..................................................................................................67
Entretien de la Batterie.......................................................................................................................67
Remplacement du Fusible..................................................................................................................68
Connexion Électrique.........................................................................................................................69
Installation.................................................................................................................................70
Orientation.........................................................................................................................................70
Suspension........................................................................................................................................70
4. Fonctionnement ...........................................................................................................72
Fonctionnement du Panneau de Commande.............................................................................72
Tableau du Menu......................................................................................................................72
Configuration (DMX)..................................................................................................................73
Adresse de Départ.............................................................................................................................73
Personnalités DMX............................................................................................................................73
Valeurs, Assignations et Modes de Canaux DMX......................................................................74
5 Canaux............................................................................................................................................74
4 Canaux...........................................................................................................................................75
Configuration (Autonome)..........................................................................................................75
Mode Automatique ACt......................................................................................................................75
Programmes Automatiques ACt..........................................................................................................76
Mode Automatique ACtC....................................................................................................................77
Programmes ACtC Automatiques.......................................................................................................77
IRC (Télécommande à Infrarouge)......................................................................................................78
Fonctionnement de l'IRC....................................................................................................................78
Fonctionnement de l'IRC (suite)..........................................................................................................79
D-Fi™ 2.4 Ghz (Mode DMX Synchronisation Automatique).................................................................80
D-Fi™ 2.4 Ghz (Mode DMX Synchronisation Manuelle).......................................................................81
D-Fi™ 2.4 Ghz (Mode Autonome /Infrarouge Synchronisation Automatique)........................................82
D-Fi™ 2.4 Ghz (Mode Autonome /Infrarouge Synchronisation Manuelle).............................................83
Mode Maître/Esclave..........................................................................................................................84
Effet Piste d'Atterrissage Maître/Esclave.............................................................................................84
5. Informations Techniques.............................................................................................85
Entretien de l'Appareil ...............................................................................................................85

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 5 of 88
6. Spécificités Techniques...............................................................................................86
Renvois.....................................................................................................................................87
Nous Contacter.........................................................................................................................87

Page 6 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
1.BEFORE YOU BEGIN
What Is
Included
•Freedom™ Par RGBA
or
•Freedom™ Strip Mini RGBA
•Power Cord
•Warranty Card
•User Manual
Unpacking
Instructions
Carefully unpack the product immediately and check the box to make sure all the parts
are in the package and are in good condition.
Claims
If the box or the contents (the product and
included accessories) appear damaged from
shipping, or show signs of mishandling, notify the carrier immediately, not CHAUVET®.
Failure to report damage to the carrier immediately may invalidate your claim. In
addition, keep the box and contents for inspection.
For other issues, such as
missing components or parts, damage not related to shipping,
or concealed damage, file a claim with CHAUVET® within 7 days of delivery.
Text
Conventions
Convention
Meaning
1–512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Symbols
Symbol Meaning
Critical installation, configuration, or operation information. Not
following these instructions may make the product not work, cause
damage to the product, or cause harm to the operator.
Important installation or configuration information. The product
may not function correctly if this information is not used.
Useful information.
Disclaimer
The information and specifications contained in this User Manual
are subject to change
without notice. CHAUVET® assumes no responsibility or liabil
ity for any errors or
omissions, and reserves the right to revise or recreate this manual at any time.
Download the latest version from www.chauvetlighting.com.
© Copyright 2013 CHAUVET®. All rights reserved.
Printed in P.R.C.
Electronically published by CHAUVET® in the United States of America.
Author
Date
Editor
Date
A. Leon 04/11/13 D. Couppe 04/12/13

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 7 of 88
Product at a
Glance
Use on Dimmer
x
Auto Programs
P
Outdoor Use
x
Auto-ranging Power Supply
P
Sound-Activated
P
Replaceable Fuse
P
DMX
P
User-Serviceable
x
Master/Slave
P
Duty Cycle
x
Safety Notes
These notes include important information about the mounting, usage, and maintenance
of this product; read before using the product.
•Always connect the product to a grounded circuit to avoid the risk of electrocution.
•Always disconnect the product from the power source before cleaning or replacing
the fuse.
•Avoid direct eye exposure to the light source while the product is on.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the product from power by pulling or tugging on the cord.
•If mounting the product overhead, always secure to a fastening device using a
safety cable.
•Make sure there are no flammable materials close to the product when operating.
•Do not touch the product’s housing when operating because it may be very hot.
•Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or bottom panel of the product.
•The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not
expose the product to rain or moisture.
•Always install the product in a location with adequate ventilation, at least
20 in (50 cm) from adjacent surfaces.
•Be sure that no ventilation slots on the product’s housing are blocked.
•Never connect the product to a dimmer.
•Make sure to replace the fuse with another of the same type and rating.
•Never carry the product from the power cord or any moving part. Always use the
hanging/mounting bracket.
•The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate the
product at higher temperatures.
•In the event of a serious operating problem, stop using the product immediately.
•Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Contact the nearest authorized technical assistance center.
•This product is not intended for permanent installation.
•Keep this User Manual for future use. If you sell the product to another user, be
sure to give this document to the next owner.
The Freedom™ RGBA series products contain rechargeable batteries. These
batteries contain hazardous chemicals that cannot be discarded with household
waste. Contact your local waste management service for recycling information
when disposing of your product.

Page 8 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
2.INTRODUCTION
Overview (Freedom™ Par RGBA)
Front Panel View
On/Off Switch
Battery Life Indicator
Power/Signal
Indicator Lights
Microphone
LED Display/
Control Panel
D-Fi™ AUTO
Sync/Clear Button

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 9 of 88
Overview (Freedom™ Par RGBA)
Safety Loop
Master/Slave Link Output
DMX In
DMX Out
Fuse Holder
Power In
Power Out
Back Panel View

Page 10 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
Overview (Freedom™ Strip Mini RGBA)
Back Panel View
Safety Loop
Antenna
Battery Life Indicator
Microphone
On/Off Switch
LED Display
and
Control Panel
D-Fi™ AUTO
Sync/Clear Button
Fuse Holder
Power In
Power Out
Master/Slave Link Output
DMX In
DMX Out
Power/Signal
Indicator Lights

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 11 of 88
Dimensions (Freedom™ Par RGBA)
8.5 in
215 mm
9.3 in
236 mm
8.8 in
223 mm

Page 12 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
Dimensions (Freedom™ Strip Mini RGBA)
8.3 in
210 mm
20.0 in
510 mm
3.0 in
78 mm

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 13 of 88
3.SETUP
AC Power
The Freedom™ RGBA series has an auto-
ranging power supply and it can work with an
input voltage range of 100~240 VAC, 50/60 Hz.
To determine the product’s power requirements (circuit breaker, power outlet, and
wiring), use the current value listed on the label affixed to the product’s bottom panel, or
refer to the product’s specifications chart. The listed current rating indicates the
product’s average current draw under normal conditions.
Always connect the product to a protected circuit (circuit breaker or fuse). Make
sure the product has an appropriate electrical ground to avoid the risk of
electrocution or fire.
Never connect the product to
a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0–100% switch.
Charging the
Battery
The Freedom™ RGBA series comes with a non-user-serviceable lithium-
ion battery for
cable-free operation.
To charge the Freedom™ RGBA
series battery, plug in the power cord at any time
before, during, or after operation. To charge the battery before or after operation with all
the LEDs off, leave the power switch in the Off position.
Battery Life
Indicator
The
battery life indicator located on the product displays the remaining amount of
internal battery life. Use the chart below to find out how much battery life remains per
charge cycle. The light to the far right flashes during charging.
The Freedom™ RGBA
series battery should be charged 24 hours prior to initial
use for optimal battery life.
Battery
Maintenance
To keep the battery in optimal operating condition, store the product in a cool, dry place
and charge at least once every 30 days when not in use.
Avoid exposure to extreme temperatures. If the product is exposed to extreme cold or
hot temperatures, warm up/cool down the product before use and before charging.
Run-Time Table
Maximum Run Time Recharge Time
Up to 8 hours 6 hours

Page 14 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
Fuse
Replacement
Disconnect the product from power before replacing the fuse.
1. Disconnect the product from power.
2. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
3. Pry the fuse holder out of the housing.
4. Remove the blown fuse from the holder.
5. Replace with a fuse of the exact same type and rating.
6. Insert the fuse holder back in place and reconnect power.
A spare fuse is not included; however, the safety cap has room for a spare.
Always replace a blown fuse with one of the same type and rating.
Installed fuse
(held by plastic clip)
Spare fuse holder
(inside safety cap)
Safety cap

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 15 of 88
Power Linking
The product provides power linking via the IEC outlet located in the back of the unit.
Power Linking
Diagram
You can power link up to 16 Freedom™ Par RGBA unit
s on 120 VAC or up
to 25 Freedom™ Par RGBA units on 230 VAC.
You can power link up to 16 Freedom™ Strip Mini RGBA
units on 120 VAC or up
to 25 Freedom™ Strip Mini RGBA units on 230 VAC.
Note: Battery charging speed slows down during power linking.
The power linking diagram shown above corresponds to the North American
version of the product ONLY! If using the product
in other markets, you must
consult with the local CHAUVET® distributor as power linking connectors and
requirements may differ in your country or region.
1st Product
2nd Product
3rd Product
Additional
Products

Page 16 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
Mounting
Before mounting the product, read and follow the safety recommendations of the
Safety
Notes.
Orientation
The Freedom™ RGBA series products may be mounted in any position; however, make
sure adequate ventilation is provided.
Rigging
•Before deciding on a location, always make sure there is easy access to the product
for maintenance and programming.
•Make sure that the structure or surface onto which you are mounting the product
can support the product’s weight (see the Technical Specifications).
•When mounting the product overhead, always use a safety cable.
Mount the
product securely to a rigging point, such as an elevated platform or a truss.
•When rigging the product onto a truss, you should use a mounting clamp of
appropriate weight capacity.
•When power linking multiple products, you must always consider the length of the
power linking cable and mount the products close enough for the cable to reach.
•The bracket adjustment knobs allow for directional adjustment when aiming the
product to the desired angle. Only loosen or tighten the bracket knobs manually.
Using tools could damage the knobs.
•The mounting brackets on the Freedom™ Strip Mini RGBA also serve as floor
supports/allow for surface mounting. When mounting the product
on the floor, make
sure that the product and cables are away from people and vehicles.
Mounting Diagram
Tilt Angle
Adjustment Knob
Mounting Bracket
Bracket Adjustment Knob
Bracket Adjustment Knob
Mounting Brackets

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 17 of 88
4.OPERATION
Control Panel
Operation
To access the control panel functions, use the four buttons surrounding the display.
Button Function
<MODE> Selects an operation mode or backs out of the current menu option
<UP> Scrolls up the list of options or selects a higher value
<DOWN> Scrolls down the list of options or selects a lower value
<ENTER> Activates a menu option or a selected value
Menu Map
Mode Programming Steps Description
SYS
SdAd
001
–
508
Set DMX address
d-CH 4CH Turn on 4-channel DMX mode
5CH Turn on 5-channel DMX mode
S-tr
tA.S t-AU Automatically select transmit
frequency (for IR use)
t.CH t001–
t016 Manually select transmit frequency
(for IR use)
drA.S dr.AU Automatically select receive
frequency (for DMX use)
dr.CH dr.01–
dr.16 Manually select receive frequency
(for DMX use)
dtA.S dt.AU Automatically select transmit
frequency (for DMX use)
dt.CH dt.01–
dt.16 Manually select transmit frequency
(for DMX use)
d-SL SL.00–SL.32 Set sound sensitivity (DMX mode)
SAAd Reset software
ACt
(extra levels not
available in all
programs)
A001–A022
A024–A026
P.000–P.100 Run speed (slow to fast)
F.000–F.100 Flash speed (slow to fast)
SL.00–SL.32 Sound sensitivity (Automatic mode)
A023 Only
P.000–P.100 Red (only available in A023)
F.000–F.100 Green (only available in A023)
C.000–C.100 Blue (only available in A023)
Y.000–Y.100 Amber (only available in A023)
SL.00–SL.32 Sound sensitivity (Automatic mode)
ACtC
(extra levels not
available in all
programs)
AC01–AC12
AC14
P.000–P.100 Run speed (slow to fast)
F.000–F.100 Flash speed (slow to fast)
SL.00–SL.32 Sound sensitivity (Automatic mode)
AC13 Only
P.000–P.100 Red (only available in AC13)
F.000–F.100 Green (only available in AC13)
C.000–C.100 Blue (only available in AC13)
SL.00–SL.32 Sound sensitivity (Automatic mode)
SLAv rA.S r-AU Automatically select receive
frequency (for IR use)
r-St r001–r016 Manually select receive frequency
(for IR use)
S-Ir Infrared connection with IRC
(Infrared Remote Control) only

Page 18 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
Starting Address
When selecting a starting DMX address, always consider the
number of DMX channels
the selected DMX mode uses. If you
choose a starting address that is too high, you could
restrict access to some of the product’s channels.
The Freedom™ RGBA series uses up to 5 DMX channels in its 5-CH
DMX mode, which
defines the highest configurable address to 508.
If unfamiliar with DMX, download the DMX Primer from www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MODE>repeatedly until SYS,ACt, ACtC,SLAv,or S-Ir shows on the
display.
2. Use <UP> or <DOWN> to select SYS.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select SdAd.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select the starting address.
7. Press <ENTER>.
DMX
Personalities
The Freedom™ RGBA series has 2 DMX personalities. One is a basic 4-channel
personality, and the other is a more advanced 5-channel personality.
To select either the 4- or 5-channel personality, do the following:
1. Press <MODE> repeatedly until SYS,ACt,ACtC,SLAv,or S-Ir shows on the
display.
2. Use <UP> or <DOWN> to select SYS.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select d-CH.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select either 4CH (4-channel mode) or
5CH (5-channel mode).
7. Press <ENTER>.

Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4 Page 19 of 88
DMX Channel Modes, Assignments, and Values
5-CH
Channel Function Value CH.2 CH.3 CH.4 CH.5
1
Blackout
000 ó008
Flash speed
000 ó249
Sound-Active
250 ó255
Red
009 ó017
Green
018
ó
026
Blue
027 ó035
Amber
036 ó044
Red + Green
045 ó053
Red + Blue
054 ó062
Red + Amber
063 ó071
Green + Blue
072 ó080
Blue + Amber
081 ó089
Red + Green +
Blue
090 ó098
Green + Amber
099 ó107
Red + Green +
Amber
108 ó116
Red + Blue +
Amber
117 ó125
Green + Blue +
Amber
126 ó134
Red + Green +
Blue + Amber
135 ó143
Color Change 1
144 ó152
Run speed
Automatic
000 ó127
Sound-Active
128 ó255
Color Change 2
153 ó161
Color Chase 1
162 ó170
Color Chase 2
171 ó179
Color Chase 3
180 ó188
Color Chase 4
189 ó197
Color Change 3
198
ó
206
RGBA Mode 207 ó215
Red
(0–100%)
000
ó
255
Green
(0–100%)
000
ó
255
Blue
(0–100%)
000
ó
255
Amber
(0–100%)
000
ó
255
Color Snap 216 ó224
Snap speed
000 ó255
Color Fade 225 ó233
Fade speed
000 ó255
Auto Run
(Sound-Active
only) 234 ó255
Run speed
Automatic
000 ó127
Sound-Active
128 ó255
Note: The sound sensitivity settings in ACt and ACtC modes have an effect on the sound sensitivity span in
DMX mode. For optimal sound sensitivity in DMX mode, first be sure to adjust both ACt and ACtC sound
sensitivity settings according to your environment.
•CH.2 must be within operating values for Auto Run to function.
•If the Freedom™ RGBA series product is in Sound-Active mode and there is no
sound for 6 seconds, the product will default back to an automatic program. Turn
the sound sensitivity down to 128 to avoid this.
4-CH Channel Function Value Percent
1
Red
000 ó255
0–100%
2
Green
000 ó255
0–100%
3
Blue
000 ó255
0–100%
4
Amber
000 ó255
0–100%

Page 20 of 88 Freedom™ Par RGBA and Strip Mini RGBA User Manual Rev. 4
Configuration
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
Never connect a product that is operating in any standalone mode
(Static, Automatic, or Sound)
to a DMX string connected to a DMX controller.
Product
s in standalone mode may transmit DMX signals that could interfere with
the DMX signals from the controller.
Automatic ACt
Mode
To enable the Automatic ACt mode, do the following:
1. Press <MODE> repeatedly until SYS,ACt,ACtC,SLAv,or S-Ir shows on the
display.
2. Use <UP> or <DOWN> to select ACt.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to choose your desired program (A001–A026).
5. Press <ENTER>.
Certain programs will have additional functionality. To find these options, press
<ENTER> after selecting an auto program. Then press <UP> or <DOWN> to choose the
desired setting. Not every program will feature additional functions.
Function Description
F.000–F.100 Flash speed (slow to fast)
SL.00–SL.32 Sound sensitivity (Automatic mode)
P.000–P.100 Run speed (slow to fast)
C.000–C.100 Blue
Y.000–Y.100 Amber
