COLORpalette™II
USER MANUAL
Chauvet, 3000 N 29th Ct, Hollywood, FL 33020 U.S.A.
[phone] – [phone]
FAX [phone]
www.chauvetlighting.com

TABLE OF CONTENTS
1. BEFORE YOU BEGIN................................................................................................................................ 3
WHAT IS INCLUDED......................................................................................................................................... 3
UNPACKING INSTRUCTIONS............................................................................................................................. 3
AC POWER ................................................................................................................................................... 3
CONTACT US................................................................................................................................................. 3
SAFETY INSTRUCTIONS................................................................................................................................... 4
2. INTRODUCTION ........................................................................................................................................ 5
FEATURES..................................................................................................................................................... 5
DMX CHANNEL SUMMARY (27 CHANNEL MODE) ............................................................................................... 5
DMX CHANNEL SUMMARY (15 CHANNEL MODE) ............................................................................................... 5
DMX CHANNEL SUMMARY (9 CHANNEL MODE) ................................................................................................. 6
DMX CHANNEL SUMMARY (6 CHANNEL MODE) ................................................................................................. 6
PRODUCT OVERVIEW ..................................................................................................................................... 6
3. SETUP........................................................................................................................................................ 7
FUSE REPLACEMENT...................................................................................................................................... 7
FIXTURE LINKING ........................................................................................................................................... 7
Data Cabling........................................................................................................................................... 7
DMX Data Cable............................................................................................................................... 7
Cable Connectors............................................................................................................................. 8
3-Pin to 5-Pin Conversion Chart....................................................................................................... 8
SETTING UP A DMX SERIAL DATA LINK............................................................................................................ 8
MASTER/SLAVE FIXTURE LINKING.................................................................................................................... 9
MOUNTING.................................................................................................................................................... 9
Orientation........................................................................................................................................ 9
Rigging ............................................................................................................................................. 9
4. OPERATING INSTRUCTIONS..................................................................................................................10
NAVIGATING THE CONTROL PANEL .................................................................................................................10
MENU MAP...................................................................................................................................................10
MENU VALUES..............................................................................................................................................11
Menu Functions .....................................................................................................................................11
OPERATION..................................................................................................................................................12
Stand-Alone Mode (Sound-Active, Auto Mode): ....................................................................................12
DMX Mode.............................................................................................................................................12
DMX CHANNEL VALUES................................................................................................................................13
GENERAL TROUBLESHOOTING........................................................................................................................14
TECHNICAL SUPPORT....................................................................................................................................15
5. APPENDIX.................................................................................................................................................15
DMX PRIMER...............................................................................................................................................15
GENERAL MAINTENANCE ...............................................................................................................................16
RETURNS PROCEDURE..................................................................................................................................16
CLAIMS........................................................................................................................................................16
TECHNICAL SPECIFICATIONS ..........................................................................................................................17
COLORpalette 2 User Manual 2 2008-01-10/13:06

1. BEFORE YOU BEGIN
What is included
¾1 x COLORpalette™ 2
¾2 x Flush mount brackets
¾1 x Wall/Truss mounting bracket
¾Power Cord
¾Warranty Card
¾User Manual
Unpacking Instructions
Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that
all parts are present, and have been received in good condition. Notify the shipper immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box
and packing.
AC Power
This fixture has an auto-switching power supply that can accommodate a wide range of input
voltages. The only thing necessary to do before powering on the unit is to make sure the line voltage
you are applying is within the range of accepted voltages. This fixture will accommodate between
100V and 240V AC. All fixtures must be powered directly off a switched circuit and cannot be run off a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer channel is used solely for
a 0% to 100% switch.
Contact Us
World Wide
General Information Chauvet Lighting
3000 North 29th Court
Hollywood, FL 33020
voice: 954.929.1115
fax: [phone]
toll free: 800.762.1084
Technical Support Chauvet Lighting
3000 North 29th Court
Hollywood, FL 33020
voice: 954.929.1115 (Press 4)
fax: [phone] (Attention: Service)
World Wide Web www.chauvetlighting.com
COLORpalette 2 User Manual 3 2008-01-10/13:06

Safety Instructions
Please read these instructions carefully, which includes important
information about the installation, usage and maintenance of this
product.
•Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Always make sure that you are connecting to the proper voltage, and that the line voltage you are
connecting to is not higher than that stated on the decal or rear panel of the fixture.
•This product is intended for indoor use only!
•To prevent risk of fire or shock, do not expose fixture to rain or moisture. Make sure there are no
flammable materials close to the unit while operating.
•The unit must be installed in a location with adequate ventilation, at least 20in (50cm) from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Always disconnect from power source before servicing or replacing lamp or fuse and be sure to
replace with same lamp source.
•Secure fixture to fastening device using a safety chain. Never carry the fixture solely by its head. Use
its carrying handles.
•Maximum ambient temperature (Ta) is 104°F (40°C). Do not operate fixture at temperatures higher
than this.
•In the event of a serious operating problem, stop using the unit immediately. Never try to repair the
unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•Don’t connect the device to a dimmer pack.
•Make sure the power cord is never crimped or damaged.
•Never disconnect the power cord by pulling or tugging on the cord.
•Avoid direct eye exposure to the light source while it is on.
•Do not daisy chain power to more than 8 units.
Caution! There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact CHAUVET at: 954-929-1115.
COLORpalette 2 User Manual 4 2008-01-10/13:06

2. INTRODUCTION
Features
•6, 9, 15 or 27-channel DMX-512 LED panel
•Operating modes
6-channel: RGB control
9-channel: 2 sections of RGB control
15-channel: 4 sections of RGB control
27-channel: 8 sections of RGB control
•Built-in automated programs via master/slave or DMX
•Built-in sound activated programs via master/slave or DMX
Additional Features
•High-power, 1W (350mA) LEDs
•Additional power output: max 8 units @ 120V (see manual for details)
•Includes brackets for wall or truss mounting
DMX Channel Summary (27 channel mode)
CHANNEL FUNCTION CHANNEL FUNCTION CHANNEL FUNCTION
1 Mode 10 Red 3 19 Red 6
2 Auto Speed 11 Green 3 20 Green 6
3 Strobe 12 Blue 3 21 Blue 6
4 Red 1 13 Red 4 22 Red 7
5 Green 1 14 Green 4 23 Green 7
6 Blue 1 15 Blue 4 24 Blue 7
7 Red 2 16 Red 5 25 Red 8
8 Green 2 17 Green 5 26 Green 8
9 Blue 2 18 Blue 5 27 Blue 8
DMX Channel Summary (15 channel mode)
CHANNEL FUNCTION CHANNEL FUNCTION CHANNEL FUNCTION
1 Mode 6 Blue 1 11 Green 3
2 Auto Speed 7 Red 2 12 Blue 3
3 Strobe 8 Green 2 13 Red 4
4 Red 1 9 Blue 2 14 Green 4
5 Green 1 10 Red 3 15 Blue 4
COLORpalette 2 User Manual 5 2008-01-10/13:06

DMX Channel Summary (9 channel mode)
CHANNEL FUNCTION CHANNEL FUNCTION CHANNEL FUNCTION
1 Mode 4 Red 1 7 Red 2
2 Auto Speed 5 Green 1 8 Green 2
3 Strobe 6 Blue 1 9 Blue 2
DMX Channel Summary (6 channel mode)
CHANNEL FUNCTION CHANNEL FUNCTION CHANNEL FUNCTION
1 Mode 3 Strobe 5 Green 1
2 Auto Speed 4 Red 1 6 Blue 1
Product Overview
Mounting
Bracket
Power
Connector and
Fuse Holder
Sound
Sensitivity
Knob
Up
Button
Mode
Button Mode
Display
DMX
Output
Connector
Enter
Button
DMX Input
Connecto
r
Status
Display Down
Button
COLORpalette 2 User Manual 6 2008-01-10/13:06

3. SETUP
The fuse is located
inside this
compartment.
Remove using a flat
head screwdriver.
Fuse Replacement
With a flat head screwdriver wedge the fuse
holder out of its housing. Remove the damaged
fuse from its holder and replace with exact
same type fuse. Insert the fuse holder back in
its place and reconnect power.
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller
or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The
combined number of channels required by all the fixtures on a serial data link determines the number
of fixtures the data link can support.
Important: Fixtures on a serial data link must be daisy chained in one single line. To comply with the EIA-485
standard no more than 32 devices should be connected on one data link. Connecting more than 32
fixtures on one serial data link without the use of a DMX optically-isolated splitter may result in
deterioration of the digital DMX signal.
Maximum recommended serial data link distance: 500 meters (1640 ft.)
Maximum recommended number of fixtures on a serial data link: 32 fixtures
Data Cabling
To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX
cables directly from a dealer/distributor or construct your own cable. If you choose to create your own
cable please use data-grade cables that can carry a high quality signal and are less prone to
electromagnetic interference.
DMX DATA CABLE
Use a Belden© 9841 or equivalent cable which meets the specifications for EIA RS-485 applications.
Standard microphone cables cannot transmit DMX data reliably over long distances. The cable will
have the following characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor and shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms
Disconnect the power cord before replacing a fuse and always
replace with the same type fuse.
COLORpalette 2 User Manual 7 2008-01-10/13:06

CABLE CONNECTORS
Cabling must have a male XLR connector on one end and a female XLR connector on the other end.
2
1
3OUTPUT
Termination reduces signal errors and
to avoid signal transmission problems
and interference, it is always
advisable to connect a DMX signal
terminator.
1
3
2
Resistance 120
ohm 1/4w between
pin 2 (DMX -) and
pin 3 (DMX +) of
the last fixture.
1
3
2
DMX -
DMX
+
COMMON
DMX connector configuration
INPUT
CAUTION Do not allow contact between the common and the fixture’s chassis ground. Grounding the common
can cause a ground loop, and your fixture may perform erratically. Test cables with an ohm meter to
verify correct polarity and to make sure the pins are not grounded or shorted to the shield or each other.
3-PIN TO 5-PIN CONVERSION CHART
Note! If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter.
CHAUVET Model No: DMX5M, or DMX5F.
The chart below details a proper cable conversion:
3PIN TO 5PIN CONVERSION CHART
Conductor 3 Pin Female (output) 5 Pin Male (Input)
Ground/Shield Pin 1 Pin 1
Data ( - ) signal Pin 2 Pin 2
Data ( + ) signal Pin 3 Pin 3
Do not use Do not use
Do not use Do not use
Setting up a DMX Serial Data Link
1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector
of the controller.
2. Connect the end of the cable coming from the controller which will have a (female) 3 pin connector
to the input connector of the next fixture consisting of a (male) 3 pin connector.
3. Then, proceed to connect from the output as stated above to the input of the following fixture and
so on.
CHAUVET Certified DMX Data Cables
Order Code Description
DMX1.5 DMX Cable 1.5m/4.9ft
DMX4.5 DMX Cable 4.5m/14.8ft
DMX10 DMX Cable 10m/32.8ft
This drawing provides a
general illustration of the
DMX Input/Output panel of
a lighting fixture.
Continue the link
Universal DMX Controller
COLORpalette 2 User Manual 8 2008-01-10/13:06

Master/Slave Fixture Linking
1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector
of the first fixture.
2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin
connector to the input connector of the next fixture consisting of a (male) 3 pin connector. Then,
proceed to connect from the output as stated above to the input of the following fixture and so on.
Often, the setup for Master-Slave
and Standalone operation requires
that the first fixture in the chain be
initialized for this purpose via either
settings in the control panel or DIP-
switches. Secondarily, the fixtures
that follow may also require a slave
setting. Please consult the
“Operating Instructions” section in
this manual for complete instructions
for this type of setup and
configuration.
Mounting
ORIENTATION
This fixture may be mounted in any position provided there is adequate room for ventilation.
RIGGING
Hanging Clamp
It is important never to obstruct the fan or vents pathway. Mount the
fixture using, a suitable “C” or “O” type clamp. Adjust the angle of the
fixture by loosening both knobs and tilting the fixture. After finding the
desired position, retighten both knobs.
•When selecting installation location, take into consideration lamp
replacement access and routine maintenance.
•Safety cables should always be used. Note!
Clamp is sold separatel
y
.
•Never mount in places where the fixture will be exposed to rain, high
humidity, extreme temperature changes or restricted ventilation.
COLORpalette 2 User Manual 9 2008-01-10/13:06

4. OPERATING INSTRUCTIONS
Navigating the Control Panel
Access control panel functions using the four panel buttons located directly underneath the LCD
Display.
Button Function
<MODE> Used to access the menu or to return to a
previous menu option
<UP> Scrolls through menu options in ascending
order
<DOWN> Scrolls through menu options in descending
order
<ENTER> Used to select and store the current menu
or option within a menu
MODE
ENTER
UP
DOWN
The Control Panel LED Display shows the menu items you select from the menu map on page 13.
When a menu function is selected, the display will show immediately the first available option for the
selected menu function. To select a menu item, press <ENTER>.
Press the <MODE> button once to activate the control panel. Pressing the <MODE> button again will
scroll through the different top-level menu options available. Use the <UP> and <DOWN> buttons to
navigate the menu options. Press the <ENTER> button to access the menu function currently
displayed or to enable a menu option. To return to the previous option or menu without changing the
value, press the <MODE> button.
Menu Map
COLORpalette 2 User Manual 10 2008-01-10/13:06

Menu Values
MENU VALUE FUNCTION
A
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
016
017
018
019
020
021
022
023
024
Red (static)
Green (static)
Blue (static)
Yellow (static)
Magenta (static)
Cyan (static)
White (static)
Auto/Sound Mode 1
Auto/Sound Mode 2
Auto/Sound Mode 3
Auto/Sound Mode 4
Auto/Sound Mode 5
Auto/Sound Mode 6
Auto/Sound Mode 7
Auto/Sound Mode 8
Auto/Sound Mode 9
Auto/Sound Mode 10
Auto/Sound Mode 11
Auto/Sound Mode 12
Auto/Sound Mode 13
Auto/Sound Mode 14
Auto/Sound Mode 15
Auto Mode 1
Auto/Sound Mode 16
F 000
000 Ù099
100
Strobe (Static Colors Only)
Solid On
Strobe (Slow > Fast)
Sound-active Strobing
P
000
001 Ù099
100
Auto Run Delay (Auto/Sound Modes Only)
Never Auto run
Time Delay (Long > Short)
No Delay
Menu Functions
MENU
OPTION DESCRIPTION
Auto Mode – Stand-alone: Sets the fixture to Master status for
Master-Slave operation and the built in programs will be
triggered by the sound. No data link is required; all fixtures
can be set to this mode for Stand-alone operation.
DMX: The fixture will be controlled by a DMX signal coming from
a DMX controller. The starting address must be selected, and
can be set using the up and down buttons.
Strobe Mode: Sets the fixture to strobe the selected color.
This setting is only available when the unit is set to display
a static color in standalone mode (A001-A007).
Auto Run Delay: If the unit does not trigger with sound within
a certain time period, it can automatically enter auto mode.
This setting controls the time delay before entering auto mode.
Note that auto mode is cancelled as soon as the unit triggers
with sound.
COLORpalette 2 User Manual 11 2008-01-10/13:06

Operation
Stand-Alone Mode (Sound-Active, Auto Mode):
This mode allows a single unit to run to the beat of the music, or the unit will auto change in Auto
Mode.
1) Press the <MODE> button.
2) Use the <UP> and <DOWN> buttons to locate the desired program (A001 – A024). Some
programs are static, and some can trigger to sound. See the Menu Values section on the
previous page for a complete list of programs.
3) Each program has settings which can be configured by pressing <ENTER> while the program is
displayed. Press <ENTER> while the program is displayed. Scroll through to the desired setting
and press <MODE>. See the Menu Values section on the previous page for a complete list of
settings.
3) Use the audio sensitivity knob on the back of the unit to make the unit more or less sensitive in
Sound-Active mode. Turning the knob counterclockwise decreases the sensitivity; turning the
knob clockwise increases the sensitivity.
Master/Slave Mode (Master Sound, Master Auto):
This mode will allow you to link up to 32 units together without a controller.
1) Use standard DMX cables to daisy chain your units together via the DMX connector on the rear
of the units. For longer cable runs we suggest a terminator at the last fixture. For more
information about terminators, see page 8.
2) Determine which fixture will be the master. Connect a DMX cable from the DMX output
connector of the master to the DMX input connector of another COLORpaIette™ 2.
3) Continue connecting the slaves together with DMX cables
4) Press the <MODE> button on the master.
5) Use the <UP> and <DOWN> buttons to locate the desired program (A001 – A024). Some
programs are static, and some can trigger to sound. See the Menu Values section on the
previous page for a complete list of programs.
6) Each program has settings which can be configured by pressing <ENTER> while the program is
displayed. Press <ENTER> while the program is displayed. Scroll through to the desired setting
and press <MODE>. See the Menu Values section on the previous page for a complete list of
settings.
7) Use the audio sensitivity knob on the back of the unit to make the unit more or less sensitive in
Sound-Active mode. Turning the knob counterclockwise decreases the sensitivity; turning the
knob clockwise increases the sensitivity.
DMX Mode This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page 15.
1) Press the <MODE> button.
2) Use the <UP> and <DOWN> buttons until is displayed, and press <ENTER>.
Note: The “d” will disappear after pressing the enter button. This is to indicate that you are in DMX
mode, and can now change the DMX address.
3) Use the <UP> and <DOWN> buttons to select the desired DMX address.
4) Press the <MODE> button to store the address.
COLORpalette 2 User Manual 12 2008-01-10/13:06

DMX Channel Values
CHANNEL VALUE FUNCTION
1
000 Ù019
020 Ù039
040 Ù059
060 Ù079
080 Ù089
090 Ù099
100 Ù109
110 Ù119
120 Ù129
130 Ù139
140 Ù149
150 Ù159
160 Ù169
170 Ù179
180 Ù189
190 Ù199
200 Ù209
210 Ù219
220 Ù229
230 Ù239
240 Ù255
Control/Operating Mode
27 Channel Mode
15 Channel Mode
9 Channel Mode
6 Channel Mode
Auto/Sound Mode 1
Auto/Sound Mode 2
Auto/Sound Mode 3
Auto/Sound Mode 4
Auto/Sound Mode 5
Auto/Sound Mode 6
Auto/Sound Mode 7
Auto/Sound Mode 8
Auto/Sound Mode 9
Auto/Sound Mode 10
Auto/Sound Mode 11
Auto/Sound Mode 12
Auto/Sound Mode 13
Auto/Sound Mode 14
Auto/Sound Mode 15
Auto Mode 1
Auto/Sound Mode 16
2 000 Ù255 Auto Mode Speed (Slow > Fast)
3
000 Ù002
003 Ù249
250 Ù255
Strobe
No Strobe
Strobe (Slow > Fast)
Sound-active
4 000 Ù255 Red 1 (0 – 100%)
5 000 Ù255 Green 1 (0 – 100%)
6 000 Ù255 Blue 1 (0 – 100%)
7* 000 Ù255 Red 2 (0 – 100%)
8* 000 Ù255 Green 2 (0 – 100%)
9* 000 Ù255 Blue 2 (0 – 100%)
10* 000 Ù255 Red 3 (0 – 100%)
11* 000 Ù255 Green 3 (0 – 100%)
12* 000 Ù255 Blue 3 (0 – 100%)
13* 000 Ù255 Red 4 (0 – 100%)
14* 000 Ù255 Green 4 (0 – 100%)
15* 000 Ù255 Blue 4 (0 – 100%)
16* 000 Ù255 Red 5 (0 – 100%)
17* 000 Ù255 Green 5 (0 – 100%)
18* 000 Ù255 Blue 5 (0 – 100%)
19* 000 Ù255 Red 6 (0 – 100%)
20* 000 Ù255 Green 6 (0 – 100%)
21* 000 Ù255 Blue 6 (0 – 100%)
22* 000 Ù255 Red 7 (0 – 100%)
23* 000 Ù255 Green 7 (0 – 100%)
24* 000 Ù255 Blue 7 (0 – 100%)
25* 000 Ù255 Red 8 (0 – 100%)
26* 000 Ù255 Green 8 (0 – 100%)
27* 000 Ù255 Blue 8 (0 – 100%)
*If applicable.
COLORpalette 2 User Manual 13 2008-01-10/13:06

General Troubleshooting
Applies to
Symptom Solution(s)
Lights Foggers
& Snow Controllers Dimmers & Chaser
Auto shut off Check fan thermal switch reset 9
Beam is very dim or
not bright Clean optical system or replace lamp Check 220/110v switch for proper setting 9
Breaker/Fuse keeps
blowing Check total load placed on device 9
Chase is too slow Check users manual for speed adjustment 999
Device has no power Check for power on Mains.
Check device’s fuse. (internal and/or external) 999
Fixture is not
responding Check DMX Dip switch settings for correct addressing Check DMX cables
Check polarity switch settings
9
Fixture is on but
there is no
movement to the
audio
Make sure you have the correct audio mode on the
control switches. If audio provided via ¼” jack, make
sure a live audio signal exists
Adjust sound sensitivity knob
999
Lamps cuts off
sporadically Possible bad lamp or fixture is overheating. Lamp may be at end of its life. 9
Light will not come
on after power failure Some discharge lamps require a cooling off period before the electronics in the fixture can kick start it
again, wait 5 to 10 minutes before powering up
9
Loss of signal Use only DMX cables
Install terminator
Note: Keep DMX cables separated from power cables
or black lights.
9999
Moves slow Check 220/110v switch for proper setting 9
No flash Re-install bulb, may have shifted in shipping 9
No laser output Bounce mirror motor may have shifted during shipping,
readjust 9
No light output Check slip ring & brushes for contact
Install bulb
Call service technician
9
Relay will not work Check reset switch
Check cable connections 9
Remote does not
work Make sure connector is firmly connected to device 99
Stand alone mode All Chauvet lighting fixtures featuring stand-alone
functions do not require additional settings, simply
power the fixture and it will automatically enter into this
mode
9
If you still have a problem after trying the above solutions, please contact CHAUVET Technical
Support at the location on the next page.
COLORpalette 2 User Manual 14 2008-01-10/13:06

Technical Support
Address: Service Dept.
3000 N 29th Ct, Hollywood, FL 33020 (U.S.A.)
Support (Email): [email protected]
Telephone: [phone] - (Press 4)
Fax: [phone] - (Attention: Service)
Website: http://www.chauvetlighting.com
5. APPENDIX
DMX Primer
There are 512 channels in a DMX-512 connection. Channels may be assigned in any manner. A
fixture capable of receiving DMX 512 will require one or a number of sequential channels. The user
must assign a starting address on the fixture that indicates the first channel reserved in the controller.
There are many different types of DMX controllable fixtures and they all may vary in the total number
of channels required. Choosing a start address should be planned in advance. Channels should
never overlap. If they do, this will result in erratic operation of the fixtures whose starting address is
set incorrectly. You can however, control multiple fixtures of the same type using the same starting
address as long as the intended result is that of unison movement or operation. In other words, the
fixtures will be slaved together and all respond exactly the same.
DMX fixtures are designed to receive data through a serial Daisy Chain. A Daisy Chain connection is
where the DATA OUT of one fixture connects to the DATA IN of the next fixture. The order in which
the fixtures are connected is not important and has no effect on how a controller communicates to
each fixture. Use an order that provides for the easiest and most direct cabling. Connect fixtures
using shielded two conductor twisted pair cable with three pin XLR male to female connectors. The
shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET
carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’)
COLORpalette 2 User Manual 15 2008-01-10/13:06

General Maintenance
To maintain optimum performance and minimize wear fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining frequency. As a general rule, fixtures should
be cleaned at least twice a month. Dust build up reduces light output performance and can cause
overheating. Be sure to power off fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass when the fixture is cold with a
mild solution of glass cleaner or Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply
solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical
surfaces until they are free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s
optics. Clean with soft cloth using normal glass cleaning fluid. - Always dry the parts carefully. - Clean
the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
Returns Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products
returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause
for the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate
packaging is the customer’s responsibility. CHAUVET reserves the right to use its own discretion to
repair or replace product(s). As a suggestion, proper UPS packing or double-boxing is always a safe
method to use.
Note: If you are given an RA #, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) The RA #
5) A brief description of the symptoms
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other claim
for items such as missing component/part, damage not related to shipping, and concealed damage,
must be made within seven (7) days of receiving merchandise.
COLORpalette 2 User Manual 16 2008-01-10/13:06

COLORpalette 2 User Manual 17 2008-01-10/13:06
Technical Specifications
WEIGHT & DIMENSIONS
Length........................................................................................................................... 18.5 in (470 mm)
Width .............................................................................................................................. 7.8 in (198 mm)
Height................................................................................................................................3.5 in (89 mm)
Weight ..............................................................................................................................8.4 lbs (3.8 kg)
POWER
Autoswitching Power Supply...................................................................................100 – 240V 50/60Hz
Fuse.................................................................................................20mm Glass 3.15A 250V Fast Blow
Power Consumption 120V 60Hz ........................................................................... 58W (0.6A) operating
Inrush Power ....................................................................................................................................... 2A
Power Factor.....................................................................................................................................0.75
LIGHT SOURCE
LED..........................................................................................48 (16 red, 16 green, 16 blue) 50,000hrs
PHOTO OPTIC
Beam Angle...............................................................................................................................21° x 18°
Field Angle.................................................................................................................................45° x 44°
Illuminance at 1m ......................................................................................................................4,121 lux
THERMAL
Maximum ambient temperature...........................................................................................104°F (40°C)
CONTROL & PROGRAMMING
Data input................................................................................................locking 3-pin XLR male socket
Data output...........................................................................................locking 3-pin XLR female socket
Data pin configuration ..............................................................................pin 1 shield, pin 2 (-), pin 3 (+)
Protocols........................................................................................................................DMX-512 USITT
DMX Channels ..........................................................................................................................27/15/9/6
WARRANTY INFORMATION
Warranty..............................................................................................................2-year limited warranty
