Chauvet Vue II Manual

DMX Mode
This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page 15.
1) Set dipswitches 1-9 to the desired DMX address. For help setting the address, see the
“SETTING THE STARTING ADDRESS” section on the next page.
DMX Channel Values
CHANNEL VALUE FUNCTION
1
000 Ù024
025 Ù049
050 Ù074
075 Ù099
100 Ù124
125 Ù149
150 Ù174
175 Ù199
200 Ù224
225 Ù249
250 Ù255
Control/Operating Mode
Dimmer mode
Stand-alone mode 1 (automatic)
Stand-alone mode 2 (automatic)
Stand-alone mode 3 (automatic)
Stand-alone mode 4 (automatic)
Stand-alone mode 5 (automatic)
Stand-alone mode 6 (automatic)
Stand-alone mode 7 (automatic)
Stand-alone mode 8 (automatic)
Stand-alone mode 9 (automatic)
Stand-alone (sound active)
2
000 Ù255 Red (Dimmer Mode) Dimmer: 0 – 100%
3
000 Ù255 Green (Dimmer Mode) Dimmer: 0 – 100%
4
000 Ù255 Blue (Dimmer Mode) Dimmer: 0 – 100%
5 000 Ù255
Stand-alone Speed (Mode 1-9)
(Slow > Fast)
Strobing Speed (Dimmer Mode)
(Slow > Fast)
6 000 Ù255 Dimmer
Open > Closed (100 – 0%)
Vue™ II User Manual 11 2006-12-13/15:05
