Chauvin Arnoux CA 10141E User manual

Conductivity meter
EN - User’s manual
CA 10141E

2
Information or useful tip.
Battery.
The product is declared recyclable following an analysis of the life cycle in accordance with standard ISO 14040.
Chauvin Arnoux has adopted an Eco-Design approach in order to design this appliance. Analysis of the complete life-
cycle has enabled us to control and optimize the e󰀨ects of the product on the environment. In particular this appliance
exceeds regulation requirements with respect to recycling and reuse.
The CE marking indicates compliance with the European Low Voltage Directive (2014/35/EU), Electromagnetic
Compatibility Directive (2014/30/EU), and Restriction of Hazardous Substances Directive (RoHS, 2011/65/EU and
2015/863/EU)..
The rubbish bin with a line through it indicates that, in the European Union, the product must undergo selective disposal
in compliance with Directive WEEE 2012/19/EU. This equipment must not be treated as household waste.
PRECAUTIONS FOR USE
This instrument is compliant with safety standard IEC/EN 61010-2-030 or BS EN 61010-2-030, for voltages 5V with report to
ground. Failure to observe the safety instructions may result in electric shock, re, explosion, and destruction of the instrument
and of the installations.
■The operator and/or the responsible authority must carefully read and clearly understand the various precautions to be taken in
use. Sound knowledge and a keen awareness of electrical hazards are essential when using this instrument.
■Observe the conditions of use, namely the temperature, the relative humidity, the altitude, the degree of pollution, and the place
of use.
■Do not use the instrument if it seems to be damaged, incomplete, or poorly close.
■Before each use, check the condition of the housing. Any item of which the insulation is deteriorated (even partially) must be set
aside for repair or scrapping.
■All troubleshooting and metrological checks must be done by competent, accredited personnel.
Thank you for purchasing this CA 10141E conductivity meter.
For best results with your instrument:
■read these operating instructions carefully,
■comply with the precautions for use.

3
CONTENTS
1. FIRST USE............................................................................................................................................................................... 4
1.1. Delivery condition ........................................................................................................................................................... 4
1.2. Accessories .................................................................................................................................................................... 4
1.3. Replacement parts ......................................................................................................................................................... 4
1.4. Inserting the batteries ..................................................................................................................................................... 5
2. PRESENTATION OF THE INSTRUMENT............................................................................................................................. 6
2.1. CA 10141E ..................................................................................................................................................................... 6
2.2. Terminal strip .................................................................................................................................................................. 6
2.3. Functions of the instrument ............................................................................................................................................ 7
2.4. Keypad ........................................................................................................................................................................... 7
2.5. Display............................................................................................................................................................................ 8
2.6. Setting the time............................................................................................................................................................... 9
2.7. Prop ................................................................................................................................................................................ 9
3. USE IN STAND-ALONE MODE ........................................................................................................................................... 10
3.1. Calibration .................................................................................................................................................................... 10
3.2. Conductivity measurement .......................................................................................................................................... 16
3.3. Resistivity measurement .............................................................................................................................................. 17
3.4. TDS measurement ....................................................................................................................................................... 18
3.5. Salinity measurement ................................................................................................................................................... 18
3.6. Recording the measurements ...................................................................................................................................... 19
3.7. Analogue outputs.......................................................................................................................................................... 19
3.8. Errors............................................................................................................................................................................ 21
4. USE IN RECORDING MODE ............................................................................................................................................... 22
4.1. Connection ................................................................................................................................................................... 22
4.2. Get Data Logger Transfer software .............................................................................................................................. 22
4.3. USB link........................................................................................................................................................................ 22
4.4. Data Logger Transfer software ..................................................................................................................................... 24
4.5. Other software .............................................................................................................................................................. 26
5. TECHNICAL SPECIFICATIONS.......................................................................................................................................... 27
5.1. Reference conditions.................................................................................................................................................... 27
5.2. Electrical specications ................................................................................................................................................ 27
5.3. Memory......................................................................................................................................................................... 29
5.4. USB .............................................................................................................................................................................. 29
5.5. Power supply ................................................................................................................................................................ 29
5.6. Environmental conditions ............................................................................................................................................. 30
5.7. Mechanical characteristics ........................................................................................................................................... 31
5.8. Compliance with international standards...................................................................................................................... 31
5.9. Electromagnetic compatibility (CEM)............................................................................................................................ 31
6. MAINTENANCE..................................................................................................................................................................... 32
6.1. Cleaning ....................................................................................................................................................................... 32
6.2. Replacement of batteries.............................................................................................................................................. 32
6.3. Serial number ............................................................................................................................................................... 32
6.4. Calibration log............................................................................................................................................................... 33
6.5. Embedded software version ......................................................................................................................................... 33
6.6. Updating the embedded software................................................................................................................................. 33
7. WARRANTY........................................................................................................................................................................... 35
8. APPENDIX 1: NONLINEAR TEMPERATURE CORRECTION OF THE CONDUCTIVITY.............................................. 36
9. APPENDIX 2: SALINITY CALCULATION............................................................................................................................ 37

4
1. FIRST USE
1.1. DELIVERY CONDITION
The CA 10141E conductivity meter is delivered in a cardboard with:
■ one protective sheath tted on the instrument,
■four AA or LR6 alkaline batteries,
■one mains-USB adapter,
■one USB to micro USB cable,
■one bilingual quick start guide,
■ one certicate of verication.
1.2. ACCESSORIES
■One conductivity cell.
■One temperature probe (PT1000)
■One standard solution having a conductivity of 1408µS/cm.
■One standard solution having a conductivity of 12,85mS/cm
■One standard solution having a conductivity of 147µS/cm.
■Electrode storage liquid (3 mol/L KCl)
1.3. REPLACEMENT PARTS
■One protective sheath
■One mains-USB adapter
■One USB to micro USB cable
For the accessories and spares, consult our web site:
www.chauvin-arnoux.com

5
1.4. INSERTING THE BATTERIES
■Turn the instrument over.
■ Press the locking tab and lift o󰀨 the battery compartment cover.
■Remove the rubber plug.
■Insert the 4 batteries provided, with the polarities as shown.
■Put the rubber plug back in place.
■Place the two front ends before pushing in the central part.
 



■Put the battery compartment cover back in place; make sure that it is completely and correctly closed.

6
2. PRESENTATION OF THE INSTRUMENT
2.1. CA 10141E
Keypad with 6 keys.
On/O󰀨 key.
Type B micro USB connector protected by a cap.
Backlit LCD display unit.
Protecting sheath.
Terminal strip.
2.2. TERMINAL STRIP
Probe
T°
V t° out
V out
GND
5V MAX
One BNC socket for the measuring probe.
One 3.5 mm jack socket for the temperature sensor.
One yellow 4 mm banana socket for analogue output of the tem-
perature measurement.
One black 4 mm banana socket for the chassis earth of the an-
alogue output.
One red 4 mm banana socket for analogue output of the conduc-
tivity measurement.
CA 10141E
Conductivity Meter
CAL
END
SET
MEM
REC

7
2.3. FUNCTIONS OF THE INSTRUMENT
The CA 10141E is a conductivity meter designed for use in the laboratory. It is used to measure conductivity, resistivity, TDS (total
dissolved solids), salinity, and temperature. It also provides the measurement value and temperature value in the form of a voltage
on the analogue output.
This instrument is easy to use. It has extensive stand-alone capabilities and can be used:
■to calibrate the cell using a standard solution,
■to display temperature measurements in °C or in °F,
■to display the time,
■to record the measurements,
■to communicate with a PC via a USB cable.
The Data Logger Transfer software can be installed on a PC and is used to congure the instruments, to program a recording
session and to recover the recorded measurements.
The instrument can also operate with the Regressi and Graph2D software as long as you have installed the USB interface driver,
available from our website (see § 4.5).
2.4. KEYPAD
The functions indicated above the line on the keys are accessed by a short press.
The functions indicated below the line are accessed by a long press.
To prevent inadvertently switching the instrument on, the On/O󰀨 key requires a long press.
Key Function
■A long press on the key switches the instrument on.
■A second long press on the key switches the instrument o󰀨 when it is on.
■ The instrument cannot be switched o󰀨 while it is recording.
MEM
REC
■A short press on the MEM key records the measurement and the temperature.
■A long press on the REC key starts or stops a manual recording session.
It is not possible to make one-o󰀨 recordings during a recording session.
SET
■A short press on the key is used to choose the quantity to be displayed: conductivity, resistivity, TDS, or
salinity.
■A long press on the SET key lets you view and modify the calculation parameters:
■the temperature unit (°C or °F),
■the temperature correction,
■the reference temperature for the conductivity display (20 or 25°C),
■the TDS (Total Dissolved Solids) factor.
A second long press is used to return to measurement mode.
A short press on the key toggles the backlighting on or o󰀨. Once on, it goes o󰀨 at the end of 30 seconds.
CAL
END
■A short press on the CAL key is used to look up the current calibration and start the calibration procedure for
the cell connected.
■A long press on the END key is used to terminate the calibration procedure in progress.
▲
▼
■ A short press on the ▲ or ▼ key is used to set the temperature in manual mode or choose the parameter to
be modied in SET mode.
■ During the calibration, a long press on the ▲ or ▼ key is used to select the standard solution.

8
REC
MEM
MEM FULL
Ref 20°C Ref 25°C
no cor
cor lin
cor f(T)
SET COR. REF TEMP TDS
CAL SET
MTC
ATC
AM
PM
2.5. DISPLAY
Display of the measurement.
Display of the unit.
Indicates the battery voltage level. When the symbol is empty, the batteries must be replaced.
Indicates that the instrument is connected to a PC via the USB (cable) or that the power adapter is connected.
It ashes when there is data transmission via the USB drive.
P
Indicates that auto-o󰀨 is disabled and the instrument is in permanent mode.
This occurs when:
■parameterizing of the instrument is in progress,
■a calibration is in progress,
■a recording is in progress,
■the instrument is connected via the USB cable,
■ auto o󰀨 is deactivated (see § 4.4.3).
MEM FULL When lit steadily, indicates that the instrument’s memory is full.
When blinking, indicates that the instrument’s memory is 90% full.
Indicates the progress of the measurement. When all segments are lit, the measurement is stable.
When blinking, indicates that the measurement is over or that the calibration has been applied.
REC When lit steadily, indicates that recording is in progress.
When blinking, indicates waiting for the start of a recording session.
MEM Indicates that a measurement is recorded.
SET COR. Indicates adjustment of the temperature correction.
SET REF Indicates the reference temperature selected, 20 or 25°C (68 or 77°F)
SET TEMP Indicates the temperature measurement unit selected.
SET TDS Indicates adjustment of the TDS factor.
no cor
cor lin
cor f(T)
Indicates the type of temperature correction:
■no cor: no correction
■cor lin: linear correction from 1.00 to 7.40%/°C.
■cor f(T): nonlinear correction, exceeding 7.40%/°C
CAL SET Indicates that calibration is in progress.
MTC Indicates that temperature compensation is manual.
ATC Indicates that temperature compensation is automatic.
Ref 20°C
Ref 25°C Indicates the reference temperature, 20 or 25°C (68 or 77°F)
When the measurement exceeds the limits (whether positive or negative), the instrument displays OL.
Display of the temperature.
Display of the time.

9
2.6. SETTING THE TIME
The time of your instrument is set using the Data Logger Transfer software. Refer to §4.4.2
2.7. PROP
To make reading easier, the instrument can be set on its prop.

10
3. USE IN STAND-ALONE MODE
■The instrument can operate in two modes:
■the stand-alone mode described in this section,
■the record mode, in which it is controlled by a PC. This mode is described in the next section.
To ensure proper operation of the instrument, always leave the cell connected and the cap on the USB connector.
3.1. CALIBRATION
3.1.1. PARAMETERIZING THE MEASUREMENTS
Before calibrating the cell, you can set various parameters.
1. The unit of temperature (°C or °F)
2. The reference temperature, 20 or 25°C (68 or 77°F). This is the temperature to which the measurement will be referred.
3. The temperature correction used to correct and display the measured conductivity as of the chosen reference temperature.
This is useful because the conductivity of a solution increases with increasing temperature.
■cor lin: linear temperature correction
The measured conductivity is corrected and displayed using the following formula:
Σdisplayed = σT / (1 + α (T - Tref) / 100%)
where: σdisplayed = the conductivity displayed by the instrument.
σ
T= the conductivity measured at temperature T.
α = the linear temperature correction coe󰀩cient.
T = the measured temperature (°C)
Tref = the reference temperature (20 or 25°C)
■Acids: 1 to 1.6%/°C
■Bases: 1.8 to 2.2%/°C
■Salts: 2.2 to 3.0%/°C
■Drinking water: 2.0%/°C
■Ultra-pure water: 5.2%/°C
■no cor: no correction, α = 0%/°C.
■cor f(T): non-linear temperature correction. It is applied automatically above 7.4%/°C. See appendix 1 in §8.
4. TDS factor (f): between 0.40 and 1.00. This is used to calculate TDS (Total Dissolved Solids). It is expressed in mg/l or in ppm.
TDS = σ.f
Where: σ = conductivity on μS/cm
f = TDS factor
■Connect the conductivity cell to the BNC socket on the measuring instrument.
The cell must be a 2-pole cell suitable for the milieu to be measured.
■A long press on the key power up the instrument.
> 2s

11

> 2s
SET
■Long-press the SET key.
■Press the SET key and use the ▲ and ▼ keys to set the
temperature correction.
no cor
SET COR. SET COR.
cor lin
Ref 25°C

SET

SET
A long press scrolls the values faster.
TEMP
SET
■ Choose the temperature unit (°C or °F) using the ▲ and
▼ keys.
SET REF
Ref 25°C

SET

SET
■Press the SET key and choose the reference temperature
(20 or 25°C) using the ▲ and ▼ keys.
■Press the SET key and set the TDS factor (f) to between
0.40 and 1.00 using the ▲ and ▼ keys.
A sustained press on ▲ or ▼ scrolls through the values
faster.
SET TDS

> 2s
SET
■Long-press the SET key to exit from parameterizing the
measurements.
A short press on the SET key takes you back to the choice
of temperature unit.

12
HO
2
■Rinse the cell in deionized water, then dry it. ■Pour the standard solution into a beaker.
■Long-press the key to switch the instrument on.
3.1.2. CHOICE OF STANDARD SOLUTION
The CA 10141E is calibrated for conductivity.
The calibration is done at one point. Choose the solution that lies in the range of interest to you.
Conductivity at 25°C
Conductivity 147 µS/cm 1408 µS/cm 12.85 mS/cm
Resistivity 6.8 kΩ.cm 710 Ω.cm 77.8 Ω.cm
TDS 73,5 mg/l
TDS factor = 0,5
746 mg/l
TDS factor = 0,53
7,45 g/l
TDS factor = 0,58
Salinity - - 7,4 psu
■Immerse the end of the cell in the standard solution.
Take care to completely immerse the sensitive part of the cell in the solution.
Minimum level of immersion.
Sensitive part of the cell.
> 2s

13
To measure the temperature, you can:
■Connect the temperature sensor to the jack socket on the
instrument and immerse it in the solution.
■Plunge the thermometer directly in the solution and perform
manual temperature correction (see § 3.2.1).
The instrument displays the conductivity measurement and the temperature measured, the reference temperature and the time.
ATC = Automatic Temperature Compensation
ATC
cor lin
Ref 20°C

14
3.1.3. CALIBRATION PROCEDURE
Calibration serves to determine the constant of the conductivity cell.
In order to avoid the inuence of the temperature, do the calibration at the temperature at which you will be making measurements.

CAL
END
■With the instrument set to conductivity measurement, press
the CAL key.
The instrument briey displays the current calibration (the
coe󰀩cient of the cell in cm-1).
It then prompts you to choose the calibration set.
ATC
CAL SET
There are six sets available, corresponding to the six international standard conductivity solutions.
Conductivity at 25°C
Calibration set 1 147.0 µS/cm
Calibration set 2 1.408 mS/cm
Calibration set 3 12.85 mS/cm
Calibration set 4 84.0 µS/cm
Calibration set 5 1.413 mS/cm
Calibration set 6 12.88 mS/cm
You can modify these values in the Set.txt le (see § 4.3).
ATC
CAL SET
■ Choose the calibration set by long presses on the ▲ and
▼ keys.
■ Conrm the set by pressing the CAL key.
The instrument displays the measured conductivity and
the temperature.

CAL
END ATC
cor lin
CAL SET
Ref 20°C
It performs the conductivity measurement and indicates its progress.

15
Do not withdraw the cell from the solution until the measurement is over.
To abort the calibration of the cell, long-press the END key before the end of the measurement.
Otherwise, when the measurement is over, the new calibration is applied.
■Press the CAL key. The instrument exits from the calibration procedure and briey displays the cell coe󰀩cient before changing
back to measurement mode.
During the calibrations, the cell coe󰀩cient for a given cell must vary only a little. If you observe a large variation, it may be
necessary to redo the calibration, check the condition of the standard solution (in particular the use-by date), or replace the
cell.
3.1.4. RESTORE THE INITIAL CALIBRATION
Press the CAL key, then the MEM key.

CAL
END

CAL
END

CAL
END

MEM
REC
If you do not want to restore the initial calibration, choose no before pressing the CAL key.
Otherwise, choose YES and press the CAL key. The cell coe󰀩cient returns to 1.000.

16
3.2. CONDUCTIVITY MEASUREMENT
When the calibration is over, the cell is ready to make measurements.
Use a cell suited to the medium to be measured.
Between measurements, the cell must be rinsed, then dried.
For each measurement, wait for the measurement to stabilize and for the temperature to be correctly established.
Conductivity is the capacity of a solution to conduct electric current. It is ions that carry the charges. The more ions the solution
contains, the more current it will conduct.
■Immerse the end of the cell in the solution, making sure that the sensitive part is completely immersed in the solution.
■Measure the temperature of the solution, either with a temperature sensor connected to the instrument’s jack socket or with a
thermometer. In the latter case, perform manual temperature correction.
The instrument displays the measurement at the chosen
reference temperature (20 or 25°C). Wait for it to stabilize
before reading it on the instrument’s display unit.
cor lin
Ref 20°C
MTC
3.2.1. MANUAL TEMPERATURE MEASUREMENT
If you have not connected a temperature sensor, you must correct the temperature manually.
The instrument indicates that the temperature can be modied by displaying MTC next to the temperature.
MTC = Manual Temperature Compensation

17

SET
cor lin
ATC
Ref 20°C
You must then correct the temperature displayed, using the ▲ and ▼ keys, so that it is equal to the measured temperature of the
solution.
The instrument corrects the response of the cell as a function of the temperature.
To calibrate the cell, always correct the temperature rst.
3.3. RESISTIVITY MEASUREMENT
Resistivity is the reciprocal of conductivity.
You must rst calibrate the cell for conductivity and parameterize the measurements (in particular the temperature correction
and the reference temperature) before making resistivity measurements.
■Long-press the key to switch the instrument on.
■Press the key to switch to resistivity measurement.
■Immerse the cell, after it has been rinsed and dried, in the solution to be measured.
■Measure the temperature of the solution, either with a temperature sensor connected to the instrument’s jack socket or with a
thermometer. In the latter case, perform manual temperature correction.
■The instrument displays the measurement at the chosen reference temperature (20 or 25°C). Wait for it to stabilize to read it
on the instrument’s display unit.
The resistivity ranges from 2Ω.cm (σ = 500mS/cm) for a conducting solution to 18mΩ.cm (σ = 55nS/cm) for pure water.
> 2s

18
3.4. TDS MEASUREMENT
The TDS (Total Dissolved Solids) measurement is used to estimate the level of dissolved solids in a solution.
You must rst calibrate the cell for conductivity and parameterize the measurements (in particular the temperature correction,
the reference temperature, and the TDS factor) before making TDS measurements.
■Long-press the key to switch the instrument on.
■Press the key twice to switch to TDS measurement.

SET
cor lin
ATC
Ref 25°C
x 2
■Immerse the cell, after it has been rinsed and dried, in the solution to be measured.
■Measure the temperature of the solution, either with a temperature sensor connected to the instrument’s jack socket or with a
thermometer. In the latter case, perform manual temperature correction.
■The instrument displays the measurement at the chosen reference temperature (20 or 25°C). Wait for it to stabilize to read it
on the instrument’s display unit.
3.5. SALINITY MEASUREMENT
The salinity measurement serves to evaluate the salt content of seawater. It is expressed in PSU (Practical Salinity Units).
The conversion from conductivity to salinity is done using the UNESCO formula (PSS-78), for a temperature of the solution rang-
ing from -2 to +35°C. Outside of this temperature range, the instrument displays O.L. The salinity displayed is referred to 15°C.
You must rst calibrate the cell for conductivity and parameterize the measurements (in particular the temperature correction
and the reference temperature) before making salinity measurements.

SET
cor lin
ATC
x 3
> 2s
> 2s

19
■Long-press the key to switch the instrument on.
■Press the key three times to switch to salinity measurement.
■Immerse the cell, after it has been rinsed and dried, in the solution to be measured.
■Measure the temperature of the solution, either with a temperature sensor connected to the instrument’s jack socket or with a
thermometer. In the latter case, perform manual temperature correction.
■The instrument displays the measurement. Wait for it to stabilize.
3.6. RECORDING THE MEASUREMENTS
■A short press on the MEM key records the measurement with the date and time. The MEM symbol is displayed briey.
It is not possible to record a single/an isolated measurement when/while the instrument is (already?) recording.
■A long press on the REC key starts or stops a recording session. The REC symbol remains displayed for the duration of a
recording session. Auto o󰀨 is deactivated (this means that the instrument is in permanent mode) and the Psymbol is dis-
played.
Before starting a recording session, make sure that the battery life is su󰀩cient, or else connect the instrument to an external
power supply on/to a wall outlet using a micro USB cord.
When the memory is 90% full, the MEM FULL symbol blinks. When the memory is full, the MEM FULL symbol stops blinking.
To see the records, you must use a PC and install the Data Logger Transfer software (see § 4).
3.7. ANALOGUE OUTPUTS
The CA 10141E is equipped with 2 analogue outputs (3 x 4 mm banana sockets- red, black and yellow) which supply continuously
a voltage proportional to the measurement value and a voltage proportional to the temperature.
Connect a voltmeter with an input impedance greater than 1 MΩ:
■between the Vout and GND terminals of the instrument for the measurement.
■between the Vt°out and GND terminals of the instrument for the temperature.
V
V
The DC voltage range supplied by the instrument is from 0 to 5 V.
You can choose:
■which measurement values will correspond to the minimum and the maximum.
■which temperature values will correspond to the minimum and the maximum.

20
The PC “sees” the instrument as a USB drive, so you can read its contents.
Use a text editor to open the SetAnalogOutput_Conduc.txt le to see its default contents:
SET OUTPUT_0V_CONDUC 1
SET OUTPUT_5V_CONDUC 200000
SET OUTPUT_0V_TDS 1
SET OUTPUT_5V_TDS 19990000
SET OUTPUT_0V_RES 5
SET OUTPUT_5V_RES 200
SET OUTPUT_0V_SALIN 2
SET OUTPUT_5V_SALIN 42
In the case of conductivity, it corresponds to the output voltage curve (V) according to the conductivity measured:
This conguration is dened in the SetAnalogOutput_Conduc.txt and SetAnalogOutput_T.txt les. To access it, connect the
instrument to a PC using the USB / micro-USB cable.
5
4
3
2
1
V
0 50 100 150 200 µS/cm
You can modify the values, which will then modify the curve.
The conductivity values must be between 0.050 µS/cm and 500,000 µS/cm.
The TDS values must be between 1 mg/l and 200,000 mg/l.
The resistivity values must be between 2 Ω.cm and 19,999,999 MΩ.cm.
The salinity values must be between 2 psu and 42 psu.
The rst value, associated with 0 V, must be less than the second value, associated with 5 V.
Save the le and restart your instrument so that the modications are taken into account.
