Checkpoint QUANTUM SMART-1 User manual

[Classification: Protected]
13 April 2021
QUANTUM SMART-1
600-M/6000-L/6000-XL
APPLIANCES
REPLACING LINE CARDS

Check Point Copyright Notice
© 2021 Check Point Software Technologies Ltd.
All rights reserved. This product and related documentation are protected by copyright and distributed
under licensing restricting their use, copying, distribution, and decompilation. No part of this product or
related documentation may be reproduced in any form or by any means without prior written authorization
of Check Point. While every precaution has been taken in the preparation of this book, Check Point
assumes no responsibility for errors or omissions. This publication and features described herein are
subject to change without notice.
RESTRICTED RIGHTS LEGEND:
Use, duplication, or disclosure by the government is subject to restrictions as set forth in subparagraph (c)
(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and FAR
52.227-19.
TRADEMARKS:
Refer to the Copyright page for a list of our trademarks.
Refer to the Third Party copyright notices for a list of relevant copyrights and third-party licenses.

Important Information
Latest Software
We recommend that you install the most recent software release to stay up-to-date with the
latest functional improvements, stability fixes, security enhancements and protection
against new and evolving attacks.
Certifications
For third party independent certification of Check Point products, see the Check Point
Certifications page.
Check Point Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing
Line Cards
For more about this release, see the home page.
Latest Version of this Document in English
Download the latest version of this document in PDF format.
Feedback
Check Point is engaged in a continuous effort to improve its documentation.
Please help us by sending your comments.
Revision History
Date Description
13 April 2021 Updated with Smart-1 600-M models
28 February 2021 First release of this document for Smart-1 6000-L/6000-XL models

Table of Contents
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|4
Table of Contents
Safety Instructions
5
Hardware Components
6
Supported Expansion Line Cards
8
Procedure for Smart-1 600-M Appliances
9
Preparing the Appliance
9
Removing the Riser
10
Removing an Expansion Line Card from the Riser
11
Installing an Expansion Line Card into the Riser
11
Installing the Riser
12
Reassembling the Appliance
12
Procedure for Smart-1 6000-L/6000-XL Appliances
14
Preparing the Appliance
14
Installing an Expansion Line Card into the Riser
16
Removing an Expansion Line Card from the Riser
17
Reassembling the Appliance
18
Replacing a Transceiver
20

Safety Instructions
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|5
Safety Instructions
nLift the appliance with assistance. To avoid injury, do not attempt to lift the appliance by yourself.
nOpening or removing the appliance cover, while the appliance is powered on may expose you to a
risk of electric shock.
nDo not operate the appliance without the cover for more than five minutes. Operating the appliance
without the cover can result in component damage.
nMany repairs may only be done by a certified service technician. Only perform troubleshooting and
simple repairs as authorized in your product documentation, or as directed by the technical support.
nWe recommend that you always use an antistatic mat and antistatic strap on your wrist, while
working on components inside the appliance.
nTo ensure proper operation and cooling, all bays in the appliance and cooling fans must be always
populated with a component or a blank.
For more information, see the Enterprise Products Safety, Environmental, and Regulatory Information
booklet supplied in the original appliance shipping carton.
Best Practice - We recommend that only experienced personnel install or remove
hardware components. Installing or removing components incorrectly can
permanently damage the Security Management Appliance.
Important - Make sure that you are electromagnetically grounded when working with
hardware components of the appliance. ESD (electrostatic discharge) can damage the
appliance.

Hardware Components
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|6
Hardware Components
Smart-1 600-M
Item Description
1 Front panel
2 Riser
3 Rear panel

Hardware Components
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|7
Smart-1 6000-L/6000-XL
Item Description
1 Front panel
2 Riser 1
3 Rear panel

Supported Expansion Line Cards
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|8
Supported Expansion Line Cards
An expansion line card is an add-on card that can be inserted into an expansion slot on riser card to add
enhanced functionality to the appliance through the expansion bus.
These expansion line cards are available for the Smart-1 600-M and Smart-1 6000-L/6000-XL models:
n1 Gb Ethernet
n10 Gb Ethernet
In the Smart-1 600-M appliance, there is 1 available expansion line card slot.
In the Smart-1 6000-L/6000-XL appliances, there are 3 available expansion line card slots.
For a list of supported line cards, see:
https://www.checkpoint.com/downloads/products/smart-1-security-management-platform-datasheet.pdf
Important - On Smart-1 6000-L/6000-XL appliances, do not move the RAID Controller
from the right-most slot to any other slot.

Procedure for Smart-1 600-M Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|9
Procedure for Smart-1 600-M Appliances
Use the relevant install or replace workflow for your appliance. For each step in the workflow, follow the
instructions as described in the subsequent sections of this guide.
To install a new expansion line card :
1. Prepare the appliance.
2. Remove the riser.
3. Install a new expansion line card into the riser.
4. Install the riser.
5. Reassemble the appliance.
6. Install a transceiver.
To replace an existing expansion line card:
1. Prepare the appliance.
2. Remove the riser.
3. Remove the existing expansion line card from the riser.
4. Install a new expansion line card into the riser.
5. Install the riser.
6. Reassemble the appliance.
7. Install a transceiver.
Preparing the Appliance
1. Make sure to follow the "Safety Instructions" on page5 .
2. Shut down the appliance:
nIn Gaia Portal:
Go to Maintenance >Shut Down, and click Halt.
nIn Gaia Clish:
Run: halt
3. Open the retention strap that secures the power cables to the PSUs.
4. Disconnect the power cables from the AC PSUs.
5. Remove the hook-and-loop straps that hold and secure the system cables, if they interfere with the
PSU removal.
6. Remove the appliance from the rack.
See the Installing the Quantum Smart-1 600-M Telescopic Rails guide.

Procedure for Smart-1 600-M Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|10
7. Put the Electrostatic Discharge (ESD) grounding strap on your wrist and attach the other end to a
grounding point.
8. Remove the appliance cover:
a. Use a 1/4 inch flat head or a Phillips #2 screwdriver to turn the lock counter clockwise to the
unlocked position (1).
b. Open the release latch until the system cover slides back (2).
c. Lift the cover from the system (3).
Removing the Riser
1. Open the blue expansion card riser retention latch located on the appliance (1).
2. Holding the blue touch points (2), lift the expansion card riser from the appliance.
Note - The illustration shows a riser with only the onboard NIC installed.

Procedure for Smart-1 600-M Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|11
Removing an Expansion Line Card from the Riser
1. Disconnect any cables that are connected to the expansion card or riser.
2. Remove the riser.
3. Flip the riser to locate the connectors on the riser.
4. Holding the card by its edges, remove the expansion card from the riser.
5. If you are removing the card permanently, install a filler bracket in the empty expansion card slot.
Important - Do not remove the integrated onboard NIC as warranty will be void.
Important - Install a filler bracket over an empty expansion card slot to maintain
Federal Communications Commission (FCC) certification of the system. The
brackets also keep dust and dirt out of the system and aid in proper cooling and
airflow inside the system. A filler bracket is not supplied when purchasing a pre-
installed appliance.
Installing an Expansion Line Card into the Riser
1. Unpack the expansion line card and prepare it for installation.
2. Remove the riser.
3. If you are installing an expansion line card for the first time, remove the filler bracket from the empty
expansion slot and store it.
4. Locate the expansion line card connector on the riser.
5. Holding the expansion line card by its edges, position the card so that the card connector aligns with
the connector on the riser.

Procedure for Smart-1 600-M Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|12
6. Insert the card connector into the riser connector until the card is firmly seated.
Installing the Riser
1. Open the riser latch.
2. Align the following:
a. Guide on the riser with the guide pin on the system board.
b. Riser connector with the connector on the system board.
3. Lower the riser until the riser is firmly seated in the connector on the system board.
4. Close the riser latch.
Reassembling the Appliance
Make sure that all internal cables are routed correctly and connected, and no tools or extra parts are left
inside the appliance.

Procedure for Smart-1 600-M Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|13
To reassemble the appliance:
1. Align the tabs on the cover with the guide slots on the appliance (1).
2. Close the system cover release latch (2).
3. Using a 1/4 inch flat head or Phillips #2 screwdriver, turn the lock clockwise to the lock position (3).
4. Install the appliances into the rack. See the Smart-1 625 Installing the Telescopic Rails Guide .
5. If you have transceivers for your expansion line cards, install them now. See "Replacing a
Transceiver" on page20 .
If not, install them later.
6. Connect the power cables from the AC PSUs.
7. If you opened the hook-and-loop straps, close them to secure the appliance cables.
8. Press the Power button on the front panel to turn on the Security Management appliance.

Procedure for Smart-1 6000-L/6000-XL Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|14
Procedure for Smart-1 6000-L/6000-XL
Appliances
Use the relevant install or replace workflow for your appliance. For each step in the workflow, follow the
instructions as described in the subsequent sections of this guide.
To install a new expansion line card:
1. Prepare the appliance.
2. Install a new expansion line card into the riser.
We recommend that you populate the bottom-most slot first.
3. Reassemble the appliance.
4. Install a transceiver.
To replace an existing expansion line card:
1. Prepare the appliance.
2. Remove the existing expansion line card from the riser.
3. Install a new expansion line card into the riser.
4. Reassemble the appliance.
5. Install a transceiver.
Preparing the Appliance
To prepare the appliance:
1. Make sure to follow the "Safety Instructions" on page5 .
2. Shut down the appliance:
nIn Gaia Portal:
Go to Maintenance >Shut Down, and click Halt
nIn Gaia Clish:
Run: halt
3. Open the retention strap that secures the power cables to the PSUs.
4. If AC PSUs are installed in the appliance:
Disconnect the power cables from the AC PSUs.
5. If DC PSUs are installed in the appliance:
Disconnect the safety ground wires from the DC PSUs.

Procedure for Smart-1 6000-L/6000-XL Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|15
Disconnect the DC power connectors from the DC PSUs.
6. Remove the hook-and-loop straps that hold and secure the system cables, if they interfere with the
PSU removal.
7. Remove any other attached cables, if necessary.
8. Remove the appliance from the rack.
See the booklet for illustrated installation procedures.
9. Put the Electrostatic Discharge (ESD) grounding strap on your wrist and attach the other end to a
grounding point.
10. Remove the appliance cover:
a. Use a flat or a Phillips head screwdriver to rotate the latch release lock counter-clockwise to
the unlocked position.
b. Lift the latch.
c. Slide the cover back.
The tabs on the cover should disengage from the guide slots on the appliance.
d. Hold the cover on both sides and lift the cover away from the appliance.
Item Description
1 Latch release lock
2 Latch
3 Cover

Procedure for Smart-1 6000-L/6000-XL Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|16
Installing an Expansion Line Card into the Riser
1. Unpack the expansion line card and prepare it for installation.
2. If applicable, lift/pull the expansion line card latch and remove the filler bracket.
3. Hold the card by its edges, and align the card edge connector with the expansion line card connector
on the riser.
4. Insert the card edge connector firmly into the expansion line card connector until the card is fully
seated.
5. Close/push the expansion line card latch.
Best Practice - We recommend that you populate the bottom-most slot first.

Procedure for Smart-1 6000-L/6000-XL Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|17
Removing an Expansion Line Card from the
Riser
1. If applicable, lift the expansion line card latch(es) out of the slot.
2. Hold the expansion line card by its edges, and pull the card until the card edge connector
disengages from the expansion line card connector on the riser.
Note - If you do not immediately install a replacement expansion line card when a line card fails,
leave the failed line card in place to ensure proper appliance cooling until the new line card is
installed.

Procedure for Smart-1 6000-L/6000-XL Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|18
Reassembling the Appliance
To reassemble the appliance:
1. Install the cover:
a. Make sure all internal cables are routed correctly and connected, and no tools or extra parts
are left inside the system.
b. Align the tabs on the cover with the guide slots on the appliance.
c. Push the latch down.
d. Slide the cover forward.
The tabs on the cover should engage with the guide slots on the appliance.
The latch should lock into place.
e. Use a flat or Phillips head screwdriver to rotate the latch release lock clockwise to the locked
position.
Item Description
1 Latch release lock
2 Latch
3 Cover
2. Install the appliance into the rack.
See the Installing the Quantum Smart-1 6000-L/6000-XL Telescopic Rails booklet for illustrated
installation procedures.

Procedure for Smart-1 6000-L/6000-XL Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|19
3. If you have transceivers for your expansion line cards, install them now.
See "Replacing a Transceiver" on the next page .
If not, install them later.
4. If AC PSUs are installed in the appliance:
Connect the power cables from the AC PSUs.
5. If DC PSUs are installed in the appliance:
Connect the safety ground wires from the DC PSUs.
Connect the DC power connectors from the DC PSUs.
6. If you opened the hook-and-loop straps, close them to secure the system cables.
7. Make a loop and secure the power cables to the PSUs using the retention strap.
8. Press the Power button on the front panel to turn on the Security Management Appliance.

Procedure for Smart-1 6000-L/6000-XL Appliances
Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|20
Replacing a Transceiver
If your expansion line card contains removable transceivers, you can install and replace these
transceivers.
For a list of supported transceivers, see:
https://www.checkpoint.com/downloads/products/smart-1-security-management-platform-datasheet.pdf
Item Description
1 Expansion line card with fiber optic ports
2 Transceiver
3 Transceiver latch
To install a transceiver:
1. Push the transceiver into an expansion line card port until it snaps into position.
2. Turn the transceiver latch lever up to lock into the expansion line card.
3. Connect the fiber optic cable to the transceiver.
To remove a transceiver:
1. Disconnect the fiber optic cables from the transceiver.
2. Pull the latch lever down to release the transceiver.
3. Gently, pull the transceiver out of the expansion line card.
