Childcare Coda Citrino 044270-382 User manual

IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
Coda
High Chair “Citrino”
Model # 044270-382

Check that all parts are engaged before placing a child in the high chair.
Always keep child in view while in high chair.
Not recommended for a child under 6mths old.
The tray is not designed to hold the child in the high chair.
ALWAYS secure your child in the restraint.Ensure that your child wears a correctly tted and adjusted harness at all times.
Only use the high chair on a secure level surface.Use the high chair on a at,even and horizontal oor.
DO NOT elevate the high chair on any structure or table.
DO NOT allow children to stand on the seat or footrest or climb into or out of the high chair.
When adjusting the tray,make sure that parts of your child’s body are clear of any moving parts.
DO NOT carry the high chair with a child in it.
To reduce the risk of injury, position the high chair away from furniture, walls, hot surfaces and liquids,window covering
cords,and electrical cords.
Position the high chair away from furniture when the high chair is not being used at a table with the tray removed.
Periodically check that all parts of the high chair are in good working order.
DO NOT use the high chair if it is damaged or broken.
The weight of the child using this high chair should not exceed 17kgs.
Promptly replace worn out or broken parts.
Please seek repair and DO NOT use high chair if it is not working correctly.
Read all instructions before assembly and use of the high chair. Keep
instructions for future use.
BEFORE ASSEMBLINGTHIS HIGH CHAIR, READ AND UNDERSTANDTHE INSTRUCTIONS.
Follow the manufacturer’s instructions
Do not leave children unattended.
The harness must always be used and correctly tted - most injuries from high chairs are
caused by falls.
Position the high chair away from solid structures and benches to avoid injuries caused by
falls and by access to dangerous items.
Be aware of the risk of an open re and other sources of strong heat in the vicinity of the
high chair.
Do not use the high chair until the child can sit up unaided.
Do not use high chair unless all components are correctly tted and adjusted.
Stop using this high chair if any part of the high chair is broken,torn or missing.
KEEP INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE.
SAFETY PRECAUTIONS
WARNING

Follow the manufacturer’s instructions.
Age Group:under 36 months
Not recommended for a child under 12 months of age.
DO NOT leave children unattended.
The harness must always be used and correctly tted - most injuries from toddler chairs are caused by falls.
Position the chair away from solid structures to avoid injuries caused by falls and by access to dangerous items.
DO NOT overload the chair.
DO NOT use on an inclined surface.Use the low chair mode on a at,even and horizontal oor.
DO NOT elevate the chair on any structure or table.
Be aware of the risk of open re and other sources of strong heat,such as electric bar heaters,gas res etc.In
the vicinity of the toddler chair.
Periodically check that all parts of the chair are in good working order.
DO NOT use the low chair mode if it is damaged or broken.
DO NOT use the low chair mode unless all components are correctly tted and adjusted.
Read all instructions before assembly and use of the low chair mode.
Keep instructions for future use.
SAFETY PRECAUTIONS

Due to variations in the style and design of our products, the photographs and illustrations shown in this
instruction manual are generic,therefore product fabrics,colour and design may vary from images shown.
CNP Brands reserves the right to alter product specications without notice as a result of our ongoing
policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Coda High Chair
Congratulations on your purchase of the Coda High
Chair“Citrino”
This product has been designed and developed with safety,
comfort and functionality in mind. Please take the time to read
this manual carefully before using this product and keep it in a
safe place for future reference.
CONGRATULATIONS

ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
InAustralia,contact CNP Brands on 1300 667 137,in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
Seat frame with
liner and
harness pre-
assembled
Bottom leg
x 1
x 4
x 2
x 1
x 2
x 1
x 2
x 4
x 1
Front upper leg
with pre-drilled
holes
Feeding tray
with sub-tray
attached
Rear upper leg
Footrest
Bolts (for footrest
assembly)
Screws (pre-
assembled to
feet caps)
Phillips head
screwdriver
required
(not supplied)
There are no accessories recommended for use with this Childcare Coda High Chair.

ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Front Upper Legs and Footrest...
1
2
3
4
Locate the two front upper legs.
Ensure they are the legs that have the pre-drilled holes
in the front of them.
Line up the screw and the hole and turn
clockwise until the leg is rm.
Ensure that the pre-drilled holes are facing the
front.
Repeat for opposite side.
Locating the pre-drilled holes in the front upper leg,line
up the footrest with the holes.
Insert supplied bolts and tighten with a Phillips
head screwdriver (not supplied).
Repeat for opposite side.
1a.
1b.
2a.
2b.
2c.
3a.
4a.
4b.
IMPORTANT! Do not over-tighten.
IMPORTANT! Do not over-tighten.

ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Rear Upper Legs...
To assemble Bottom Legs...
1
2
1
2
Locate the two rear upper legs.
Line up the screw and the hole and turn clockwise
until the leg is rm.
Repeat for opposite side.
The chair should resemble the image as shown.
Locate the four bottom legs.
Line up the screw and the hole and turn clockwise
until the leg is rm.
Repeat for remaining three legs.
Rotate the feet located at the end of the bottom legs.
Ensure the feet are rotated to sit ush to the surface
before use of the high chair.
1a.
1b.
1c.
2a.
1a.
1b.
2a.
2b..
IMPORTANT! Do not over-tighten.
IMPORTANT! Do not over-tighten.

ASSEMBLY / OPERATING INSTRUCTIONS
To convert to Toddler Seat...
1
2
3
4
5
The high chair can also be converted into a low
chair toddler seat version.
Unscrew the four bottom legs from the four upper
legs.
Using the screwdriver (not supplied) remove all
four plastic feet from the high chair legs.
Push the plastic feet directly onto the four upper
legs.
Secure with screws
Ensure the feet are rotated to sit ush to the
surface before use of the high chair.
This toddler seat can be
used with or without the
footrest and feeding tray
depending on the size of
your child.
1a.
1b.
2a.
3a.
4a.
4b.
5a.

ASSEMBLY / OPERATING INSTRUCTIONS
4Simply pull the lever towards you whilst holding the
chair rmly with the other hand and slide tray towards
you until removed.
4a.
To attach and adjust Feeding Tray...
1
2
3
To attach tray; align the tray with the arm rests,pull
lever underneath the front of the plastic tray while
sliding tray along armrests to desired position.
Release lever.
To adjust tray; Pull lever underneath the front of
the tray and slide forward or backward to desired
position.
The tray features a sub-tray, which is easily removed by
locating the lip and lifting up.
To remove the plastic tray,locate the level under the
front of the tray,as shown in the image.
1a.
1b.
1c.
2a.
3a.
NOTE! The plastic tray can be adjusted to three positions

ASSEMBLY / OPERATING INSTRUCTIONS
Harness Restraints...
1
2
3
To secure child in harness,
push buckle (a) and (b)
into the buckle housing
(c) until the buckle prongs
snap into position.
Carefully adjust the
harness by pulling the
slider (d) until the desired
t is achieved in the lap,
shoulder (e)and crotch (f)
strap.
To release the buckle,
squeeze the top and
bottom prongs until it
disengages.
(a) Buckle prong
(b) Buckle prong
(c) Buckle housing
(d) Slider
(e) Shoulder strap
(f) Crotch strap
1a.
2a.
3a.
a b
c
d
e e
f
d

HOW TO CARE FOR YOUR CHILDCARE HIGH CHAIR
Cleaning
Maintenance
This product has been designed and developed with safety, comfort
and functionality in mind. Please take the time to read this manual
carefully before using this product and keep it in a safe place for
future reference.
To ensure the long-lasting use of your high chair, wipe down with a
damp cloth and use a mild soap solution if necessary. Do not use
abrasive cleaners.Always store product in a clean dry place.
Always check parts regularly for tightness of screws, nuts and other
fasteners – tighten or replace if required.To maintain the safety of your
high chair, seek prompt repairs for bent, torn, worn or broken parts.
Use only those parts and accessories approved by CNP Brands.
If you have any difculties in assembling the high chair, please
contact our Service Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
