Childcare PIp 044333 User manual

IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
Pip
High Chair
Model # 044333

2
Check that all safety locks are engaged before placing a child in the high chair.
Always keep child in view while in high chair.
Not recommended for a child under 6 months old.
The tray is not designed to hold the child in the high chair.
Use safety locks and brakes at all times.
Always secure your child in the restraint.Ensure that your child wears a correctly tted and adjusted harness at
all times.
The high chair should only be used in an upright position once the child is capable of reliably and consistantly
sitting upright.
Only use the high chair on a secure level surface.
DO NOT allow children to stand on the seat or footrest or climb into or out of the high chair.
When adjusting the high chair, make sure that parts of your child’s body are clear of any moving parts.
DO NOT carry the high chair with a child in it.
To reduce the risk of injury, position the high chair away from furniture, walls,hot surfaces and liquids,window
covering cords,and electrical cords.Position the high chair away from furniture when the high chair is not being
used at a table with the tray removed.
Periodically check that all parts of the high chair are in good working order.
DO NOT use the high chair if it is damaged or broken.
The weight of the child using this high chair should not exceed 15kgs.
Promptly replace worn out or broken parts.
Apply wheel lock/brakes when not moving the high chair.
Use the high chair on a at,even and horizontal oor. Do not elevate the high chair on any structure or table.
DO NOT use the high chair unless all components are correctly tted and adjusted.
FALLING HAZARD: Prevent your child from climbing on the product.
Be aware of the risk of tilting when your child can push its feet against a table or any other structure.
To avoid injury, keep child away from product when folding or unfolding.
Read all instructions before assembly and use of the high chair. Keep
instructions for future use.
BEFORE ASSEMBLY OF THE HIGH CHAIR, READ AND UNDERSTANDTHE INSTRUCTIONS.
FOLLOW THE MANUFACTURER’S INSTRUCTIONS.
DO NOT LEAVE CHILDREN UNATTENDED.
THE HARNESS MUST ALWAYS BE USED AND CORRECTLY FITTED - MOST INJURIES FROM
HIGHCHAIRS ARE CAUSED BY FALLS.
POSITION THE HIGH CHAIR AWAY FROM SOLID STRUCTURES AND BENCHES TO AVOID INJURIES
CAUSED BY FALLS AND BY ACCESS TO DANGEROUS ITEMS.
DO NOT USE THE HIGH CHAIR UNTIL THE CHILD CAN SIT UP UNAIDED.
BE AWARE OF THE RISK OF OPEN FIRE AND OTHER SOURCES OF STRONG HEAT, SUCH AS ELECTRIC
BAR HEATERS, GAS FIRES ETC. IN THE VICINITY OF THE HIGH CHAIR.
THE PRODUCT IS INTENDED FOR CHILDREN ABLE TO SIT UP UNAIDED AND UP TO 3YEARS OR A
MAXIMUM WEIGHT OF 15KG.
SAFETY PRECAUTIONS
WARNING

3
Due to variations in the style and design of our products, the photographs and illustrations shown in this
instruction manual are generic,therefore product fabrics,colour and design may vary from images shown.
CNP Brands reserves the right to alter product specications without notice as a result of our ongoing
policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Pip High Chair
Congratulations on your purchase of the Pip High
Chair.
This product has been designed and developed with safety,
comfort and functionality in mind. Please take the time to read
this manual carefully before using this product and keep it in a
safe place for future reference.
CONGRATULATIONS

4
ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
InAustralia,contact CNP Brands on 1300 667 137,in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
Seat
(Pre-assembled
with Seat Pad,
Harness,Shoulder
Pads and Leg
Rest)
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
Front Lower Leg
Rear Lower Leg
Left Tray
Mounting Arms
Right Leg
Assembly
(pre-assembled
with tubes)
Left Leg Assembly
(pre-assembled
with tubes)
Tray (Pre-
assembled
with sub-tray)
Right Tray
Mounting Arms

5
ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
InAustralia,contact CNP Brands on 1300 667 137,in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
Right
Height Adjuster
Left
Height Adjuster
x 1 x 1
x 4Castors
There are no accessories recommended for use with this Childcare High Chair.
Footrest x 1

6
ASSEMBLY / OPERATING INSTRUCTIONS
To assemble High Chair...
To x the Lower Legs...
1
1
Assemble the Height Adjusters onto the sides of
the Seat Assembly until they“click”into place. The
adjustment buttons should be facing the back of
the chair.
To open the leg assembly, press and hold
button(a) on both sides of frame whilst sliding the
legs outwards.
Release button to lock into place.
With the numbers on the leg facing forward,insert
the leg into the top of the seat height adjusters
until they“click” into place.
Repeat for other leg.
There are seven height adjustment levels.
To adjust the seat up or down,press and hold
the buttons on the seat height adjuster and lift or
lower seat to the desired height.
Release buttons at the desired height to lock into
place.
Lay the high chair on its back.
Please note that each of the four legs has a
spring loaded pin.
Locate the Rear Lower Leg. (The Rear Leg tubes
are longer than those of the Front Lower Leg).
Line up the rear lower leg so that the small hole in
the top of the leg aligns with the pin on the upper
leg.
Slide the lower leg onto the upper leg rmly at
both ends until each of the two spring pins click
into place.
Repeat steps 1d - 1e for the Front Lower Leg.
1a.
1b.
1c.
1d.
1e.
1f.
1g.
1a.
1b.
1c.
1d.
1e.
1f.
a

7
To assemble Castors...
1Whilst the chair is still on the oor, locate one
Castor wheel.
Insert the Castor into one of the castor holes on
the bottom of a lower leg assembly.
Push in until tight.
Repeat steps 1b - 1c for the remaining 3 castor
wheels.
Stand chair upright.
1a.
1b.
1c.
1d.
1e.
ASSEMBLY / OPERATING INSTRUCTIONS
To t Serving Tray...
1Locate oneTray Mounting Arm.(Note these are
marked‘L’and ‘R’to correspond with the ‘L’ and‘R’
marked on the outside of the Seat).
Insert the rear tabs on the Tray Mounting Arm into the
slot in the Seat moulding.
Push down on the front of the Tray Mounting Arm to
secure.
Position the tray at the front of the arms,pull the tray
lever found on the underside of the tray (b),whilst
sliding the tray along with the slot (c)to the position
required.
The tray has three positions as indicated on the arm
rests,release the lever to lock in position.
In the case the tray is not automatically locked onto
the armrests,move the tray slightly until a double click
is heard signalling the tray is securely locked.
This tray also features a removable sub-tray.
Lift the tabs on the side of the sub-tray and lift to remove.
1a.
1b.
1c.
1d.
1e.
1f.
1g.
1h.
Never leave the tray tted in a position in which the warning signs are visible.
WARNING
NOTE! Castor wheels can be locked by pushing down the
locking tab on each wheel. Release these tabs to release brakes.
b
c

8
ASSEMBLY / OPERATING INSTRUCTIONS
1
1
2
The leg rest has 3 adjustable positions.
To adjust,push in leg rest adjustment buttons on
both sides of the leg rest.
Raise or lower to desired position.
Release adjustment buttons to secure.
A ve point harness is provided to restrain your child.
To unfasten the harness pinch (a) and (b) waist strap
prongs and pull the clips clear.
Sliding adjusters are tted on the shoulder straps and
waist straps (c).
To fasten the harness push the waist strap clips into
the buckle until they lock in place.
Sliding adjusters are tted on the shoulder and waist
straps (c).The harness should be carefully adjusted so
that it ts your child comfortably.
1a.
1b.
1c.
1d.
1a.
1b.
1c.
2a.
2b.
To adjust the Legrest...
To use the Harness...
To assemble Footrest...
1Align Footrest with the footrest slot on the leg rest.
Push and hold both adjustment buttons on the
sides of the footrest whilst pushing the footrest into
the desired slot.
1a.
1b.
2The tray can be stored on the back legs of the high
chair.
Align the holes on the rear of the tray with the small
pegs on the back legs.
Push down until secure.
2a.
2b.
2c.
To t Serving Tray...

9
To use the Harness...
ASSEMBLY / OPERATING INSTRUCTIONS
To remove Seat Cushion...
1
2
Slide metal rings from harness end.
Feed the harness straps through the slots in seat
and seat cushion on the back and under the
seat (a) and remove the harness.
Release the seat cushion on either side of the arm
rests by pulling the press studs from the inner armrests
(b).
Lift the cover off the seat (c).
Retting the seat cushion is a reversal of this procedure.
When retting the harness ensure the butteries on the
ends of the harness straps are opened out correctly
(d) and ret metal rings.
1a.
1b.
2a.
2b.
2c.
2d.
3
To remove harness remove metal rings from harness
end,atten the buttery ends and pass through the
slots in the seat (e).
To ret the straps atten the buttery ends,pass the
ends through the slots in the seat (e), then open the
buttery ends (d) and ret metal rings.
3a.
3b.
CAUTION! The harness must be used at all times and be
correctly adjusted. Most injuries from high chairs are caused by
falls.
a
e
d
a
a
d
c
b
To adjust Seat Height and Recline...
1To adjust the height of the seat push in both of
the height adjusting locks (a) and simultaneously
raise or lower the seat,releasing both of the locks
at the required height.
1a.
NOTE! Do not adjust the height of the seat whilst the child is
seated in the chair.
a

10
ASSEMBLY / OPERATING INSTRUCTIONS
To fold High Chair...
1For a more compact fold,t the tray to the back of
the high chair.
To fold push in both of the height adjuster locks
(a) and simultaneously lower the seat of the high
chair to position 7,press in both of the release
latches (b) on the side legs and slide the rear
legs forward.
Check the high chair is correctly folded in its
locked position before leaving to stand free.
1a.
1b.
1c.
ab
2To adjust the angle of the seat,lift the plastic lever
(b) (found on the back of the seat assembly)
and
position as required,releasing the mechanism to
secure into place.
2a.
IMPORTANT! If the height adjustment becomes difcult after a
period of use and as part of the regular maintenance routine,
DO NOT use spray lubricants, simply wipe clean after use.
b
To adjust Seat Height and Recline...

11
HOW TO CARE FOR YOUR CHILDCARE HIGH CHAIR
Cleaning
Maintenance
This product has been designed and developed with safety,comfort
and functionality in mind. Please take the time to read this manual
carefully before using this product and keep it in a safe place for
future reference.
To ensure the long-lasting use of your high chair, wipe down with a
damp cloth and use a mild soap solution if necessary. Do not use
abrasive cleaners.Always store product in a clean dry place.
Always check parts regularly for tightness of screws, nuts and other
fasteners – tighten or replace if required.To maintain the safety of your
high chair, seek prompt repairs for bent, torn, worn or broken parts.
Use only those parts and accessories approved by CNP Brands.
If you have any difculties in assembling the high chair, please
contact our Service Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Warranty
For all warranty terms and conditions, please visit cnpbrands.com.au

Distributed in Australia by CNP Brands
82 Maribyrnong Street, Footscray,VIC, 3011
Customer Service 1300 667 137
W: www.cnpbrands.com.au
E: [e-mail]
F: www.facebook.com/CNPBrands
I: @cnp_baby
Distributed in New Zealand by Wainhouse
Distribution
2-6 Argyle St, Morningside,
PO Box 41-014,
St Lukes,Auckland, New Zealand
Customer Service: 0800 567 5000
E: [e-mail]
