CHINT AX-5 User manual

AX-5 auxiliary contact is mainly used in the circuit of AC 50/60Hz,
rated heating current 6A, rated voltage AC 415V or DC 130V;
assembled with NL1, it is used for distant circuit breaker on/off
signal indication.
Conforming standard: GB/T 14048.5 , IEC 60947-5-1, accredited
through CE certification.
AX-5
Auxiliary Contact 6. overall and mounting Dimensions (mm)
RCCB
RCCB
A
P-064
P-063 Modular DIN Rail Products Modular DIN Rail Products
3. Main Parameters and Technical Performance
1. Scope of Application
2. Model and Meanings
Design No
Auxiliary contact
3.1 Rated working current under different rated voltages
AC-12: AC415V/3A, AC240V/6A
DC-12: DC130V/1A, DC48V/2A, DC24V/6A
3.2 Life
The working life of auxiliary contact is not lower than 10,000 operations.
4. Main Parameters and Technical Performance
4.1Ambient temperature:-35 ºC ~+70 ºC
4.2 The atmosphere condition:≤95%
4.3 Pollution degree: II
4.4 Altitude: ≤2000m
Figure 1 wiring diagram
5. Product assembly and installation
5.1 AX-5 auxiliary contact is a kind of accessories, and can only function after being assembled with the NL1. The assembly and disassembly
diagrams are shown below.
Plate
Figure 2
5.2 Remove left cover plate of circuit breaker
Figure 3
7. Ordering information
7.2 Types and names of product, for example， AX-5 auxiliary contact.
7.2 Quantity on order，for example，50u nits.
7.3 Example for ordering: AX-5 auxiliary contact, 50units
