SIMATIC
Bus links
PN/PN coupler
Installation and Operating Manual
06/2010
A5E00717043-04
Preface
Description
1
Assembling
2
Connecting
3
Configuring and
commissioning
4
Functions
5
Operating
6
Diagnostics
7
Technical data
A
Order numbers and
accessories
B
Dimensional drawings
C

Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation for the specific task, in particular its warning notices and
safety instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E00717043-04
Ⓟ 08/2010
Copyright © Siemens AG 2010.
Technical data subject to change

PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 3
Preface
Purpose of manual
This manual provides you with all the information you need to configure, assemble, connect
and commission the PN/PN coupler.
Basic knowledge required
The following knowledge is required in order to understand the manual:
● general knowledge in the area of automation technology
● You will also need to know how to use computers or PC-like equipment (such as
programming devices) under Windows operating systems.
● Knowledge of working with
STEP 7 . This is gained from the Programming with
STEP 7 V5.4 (http://support.automation.siemens.com/WW/view/en/18652056) manual.
Scope of manual
The manual applies to the PN/PN coupler V3.0 with order number 6ES7158-3AD01-0XA0.
This manual contains a description of the components which were valid at the time the
manual was published. We reserve the right to include product information with information
updates for new components and components with a new product status.
Changes compared to the previous version
The following changes have been made in relation to the previous version of this manual,
edition 03/2009:
● Virtual module for dataset transfer.
– Introduction of the module type Storage to identify the module used so far RD READ
and RD WRITE
– Introduction to the module type Publisher
● Doubling of the quantity framework in relation to the previous level, 1024 bytes of inputs
and outputs in sum
● Support for the shared device function
● Support for the media redundancy function
Approvals
see appendix General technical data (Page 81)
CE mark
see appendix General technical data (Page 81)

Preface
PN/PN coupler
4 Installation and Operating Manual, 06/2010, A5E00717043-04
Identification for Australia (C-Tick mark)
see appendix General technical data (Page 81)
Standards
see appendix General technical data (Page 81)
Classification in information landscape
Depending on the hardware used, you will need the following manuals in addition to this one:
● the manual for the IO Controller used. The following details in this manual apply in
particular:
– Configuring and commissioning of a PROFINET IO system
– Description of the IO Controller
● the PROFINET System Description
(http://support.automation.siemens.com/WW/view/en/19292127)
● the Programming Manual From PROFIBUS DP to PROFINET IO
(http://support.automation.siemens.com/WW/view/en/19289930)
Guide
The manual is based on the following subject areas:
● Product overview and description of the PN/PN coupler
● Assembly, connection and commissioning
● Operation and diagnostics
● Appendices
Important terms are explained in the glossary. The index helps you to quickly find all texts
relevant to your keyword.
Recycling and disposal
Given its environmentally-compatible equipment, the PN/PN coupler can be recycled.
Contact a company certified in the disposal of electronic waste to ensure the
environmentally-compatible recycling and disposal of your used device.
Additional support
If you have questions regarding use of the products described in these operating
instructions, and do not find the answers in this document, contact your local Siemens
representative.
Your contact persons are listed in the Internet (http://www.siemens.com/automation/partner).
A guide to the technical documentation for the various SIMATIC products and systems is
available in the Internet (http://www.siemens.com/automation/simatic/portal).
The online catalog and ordering systems are available in the Internet
(http://www.siemens.com/automation/mall).

Preface
PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 5
Training center
We offer the corresponding courses to help you get started with the PN/PN coupler and the
SIMATIC S7 automation system. Please contact your regional training center or the central
training center in D -90327, Nuremberg, Germany.
You will find more information in the Internet (http://www.siemens.com/sitrain).
Service & Support on the Internet
In addition to our documentation, we offer a comprehensive knowledge base on the Internet
(http://www.siemens.com/automation/service&support).
There you will find:
● Our Newsletter, which constantly provides you with the latest information about your
products.
● The right documentation for you using our Service & Support search engine.
● The bulletin board, a worldwide knowledge exchange for users and experts.
● Your local contact for Automation & Drives in our contact database.
● Information about on-site service, repairs, spare parts, and much more is available under
"Repairs, spare parts, and consulting".
See also
Industrial Automation Systems SIMATIC, SIMATIC NET Technical Support, Contacts and
Training (http://support.automation.siemens.com/WW/view/en/19293011)
Support (http://support.automation.siemens.com/WW/view/en/11669702/133300)
From PROFIBUS DP to PROFINET IO
(http://support.automation.siemens.com/WW/view/en/19289930)
PROFINET System Description
(http://support.automation.siemens.com/WW/view/en/19292127)
PN/PN Coupler Bus Links (http://support.automation.siemens.com/WW/view/en/23865436)

Preface
PN/PN coupler
6 Installation and Operating Manual, 06/2010, A5E00717043-04

PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 7
Table of contents
Preface ...................................................................................................................................................... 3
1 Description................................................................................................................................................. 9
1.1 Application and function.................................................................................................................9
1.2 View .............................................................................................................................................12
1.3 Properties.....................................................................................................................................13
2 Assembling.............................................................................................................................................. 15
2.1 Assembly rules.............................................................................................................................15
2.2 Assembling the PN/PN coupler....................................................................................................15
2.3 Disassembling the PN/PN coupler...............................................................................................16
2.4 Assembling-color plates...............................................................................................................17
3 Connecting .............................................................................................................................................. 19
3.1 Electrical isolation and grounding ................................................................................................19
3.1.1 Introduction ..................................................................................................................................19
3.1.2 General operating rules and regulations......................................................................................20
3.2 Connections .................................................................................................................................22
3.3 Connecting the power supply.......................................................................................................23
3.4 Connecting PROFINET IO...........................................................................................................25
4 Configuring and commissioning............................................................................................................... 27
4.1 Configuring and commissioning of the PN/PN coupler (overview)..............................................27
4.2 Configuring the PN/PN coupler with STEP 7...............................................................................28
4.2.1 Requirements...............................................................................................................................28
4.2.2 Configuring the PN/PN coupler with STEP 7...............................................................................28
4.2.3 Example: Configuring with STEP 7..............................................................................................31
4.3 Configuration of the PN/PN coupler with another configuring tool ..............................................33
4.4 Parameters...................................................................................................................................34
4.5 Commissioning the PN/PN coupler .............................................................................................35
5 Functions................................................................................................................................................. 37
5.1 Data record transfer from one IO Controller to another IO Controller .........................................37
5.2 Isochronous real-time communication .........................................................................................48
5.3 Prioritized startup .........................................................................................................................49
5.4 Device replacement without removable medium/programming device .......................................50
5.5 SNMP...........................................................................................................................................50
5.6 Shared Device..............................................................................................................................51
5.7 Media redundancy .......................................................................................................................53

Table of contents
PN/PN coupler
8 Installation and Operating Manual, 06/2010, A5E00717043-04
6 Operating................................................................................................................................................. 55
6.1 Response times of the PN/PN coupler ....................................................................................... 55
6.2 SIMATIC Micro Memory Card..................................................................................................... 56
6.3 Updating firmware ....................................................................................................................... 57
6.3.1 Updating firmware via PROFINET IO ......................................................................................... 57
6.3.2 Updating firmware using SIMATIC Micro Memory Card............................................................. 58
6.4 Replacing defective PN/PN coupler............................................................................................ 59
6.5 Reset to factory settings.............................................................................................................. 60
6.6 Identification data ........................................................................................................................ 61
7 Diagnostics .............................................................................................................................................. 63
7.1 Diagnostics via LED displays...................................................................................................... 63
7.2 Diagnostics by user program ...................................................................................................... 66
7.2.1 Manufacturer-specific diagnostics............................................................................................... 66
7.2.2 Interrupts ..................................................................................................................................... 68
7.2.3 Diagnostics readout .................................................................................................................... 69
7.2.4 Example of diagnostics ............................................................................................................... 71
7.2.5 Data validity display .................................................................................................................... 77
7.2.6 Evaluation of the useful data flag................................................................................................ 77
7.2.7 Diagnosis in Shared Device........................................................................................................ 77
7.2.8 STOP of the IO controller and recovery of the IO device ........................................................... 78
A Technical data ......................................................................................................................................... 79
A.1 Technical data for PN/PN coupler (6ES7158-3AD01-0XA0)...................................................... 79
A.2 General technical data ................................................................................................................ 81
A.2.1 Introduction ................................................................................................................................. 81
A.2.2 Standards and approvals ............................................................................................................ 81
A.2.3 Electromagnetic compatibility ..................................................................................................... 84
A.2.4 Transport and storage conditions ............................................................................................... 85
A.2.5 Mechanical and climatic ambient conditions for operation ......................................................... 86
A.2.6 Specifications for insulation tests, safety class and degree of protection................................... 88
A.2.7 Rated voltage .............................................................................................................................. 88
B Order numbers and accessories.............................................................................................................. 89
B.1 Order numbers and accessories................................................................................................. 89
C Dimensional drawings.............................................................................................................................. 91
C.1 PN/PN coupler dimensional drawing ..........................................................................................91
Glossary .................................................................................................................................................. 93
Index...................................................................................................................................................... 101

PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 9
Description 1
1.1 Application and function
Application
The PN/PN coupler is used to link two Ethernet subnets with one another and to exchange
data. That way use data about input or output address areas or datasets can be used. The
maximum size of the transferable input and output data is 1024 bytes. The division into input
and output data is preferable, so that e.g. 800 byte input data and 200 byte output data can
be configured.
As a device, the PN/PN coupler has two PROFINET interfaces, each of which is linked to
one subnet.
In the configuration, two IO Devices are produced from this one PN/PN coupler which means
that there is one IO Device for each station with its own subnet. The other part of PN/PN
coupler in each case is known as the bus node. Once configuring is complete, the two parts
are joined.
,2&RQWUROOHU,2'HYLFH,2'HYLFH
6ZLWFK 6ZLWFK 6ZLWFK
,2&RQWUROOHU
352),1(7,QGXVWULDO(WKHUQHW
3*3131FRXSOHU (76(76 23 66
Figure 1-1 Coupling two PROFINET IO subnets with one PN/PN coupler
Principle of operation
● Data exchange with I/O modules
Through the configured inputs of a slot, the local CPU reads the values that the CPU of
the other subnet writes over the configured outputs of the coupling partner.
Through the configured outputs of a slot, the local CPU writes values that the CPU of the
other subnet receives over the configured inputs of the coupling partner.
● Data record transfer
The module types Publisher und Storage address the DS task through module addresses
during the dataset transfer.

Description
1.1 Application and function
PN/PN coupler
10 Installation and Operating Manual, 06/2010, A5E00717043-04
Application examples for cyclic I/O data exchange between IO Controllers via a PN/PN coupler
,2&RQWUROOHU
352),1(7,QGXVWULDO(WKHUQHW
352),1(7,QGXVWULDO(WKHUQHW
$FFHVVSRLQW
$FFHVV
SRLQW
,2&RQWUROOHU(76ZLWK
,031'3&38
3131&RXSOHU
6
Figure 1-2 Cyclic data exchange between two I/O Controllers via IWLAN
,2FRQWUROOHU
6ZLWFK
6ZLWFK
,2FRQWUROOHU(76
ZLWK
,031'3&38
5HGXQGDQF\
PDQDJHU
5LQJZLWK053
3131&RXSOHU
6
Figure 1-3 Cyclic data exchange between two I/O Controllers via a redundant ring
Configuring
You either configure the PN/PN coupler using STEP 7 or a configuring tool which uses a
GSD file to integrate the PN/PN coupler.
You configure the I/O areas using virtual modules that are inserted from the hardware
catalog in HW Config onto slots of the PN/PN coupler, as real modules.
You select the I/O modules for the PN/PN coupler required for your application with STEP 7
in HW-Config in the hardware catalog. The output data of one side of the PN/PN coupler is
transferred as the input data of the other side and vice versa.
In dataset modules, dataset transfers take place between both PROFINET IO subnets. On
the X1 and X2 page, pairs of mutually fitting dataset module types must be configured on
equal slots, thus RD WRITE STO and RD READ STO or RD WRITE PUB and
RD READ PUB.
The input and output data are used to control the dataset transfer.

Description
1.1 Application and function
PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 11
Example
The following example shows that both networks of independent of one another. They issue
a unique device name for each PROFINET IO network.
In the following picture this is called device names "subnet 1 and "subnet 2".
3131FRXSOHU
bE\WHV
bE\WHV bE\WHV
bE\WHV
352),1(7,2
QHWZRUN
2XWSXWDUHD
,QSXWDUHD
,QSXWDUHD
2XWSXWDUHD
352),1(7,2
QHWZRUN
'HYLFHQDPH
6XEQHW
'HYLFHQDPH
6XEQHW
; ;
Figure 1-4 Main FC of the PN/PN coupler (example)

Description
1.2 View
PN/PN coupler
12 Installation and Operating Manual, 06/2010, A5E00717043-04
1.2 View
Display elements and interfaces
The following picture shows the PN/PN coupler and its display elements and interfaces:








3131&283/(5
/,1. /,1. /,1. /,1. 5;7; 5;7; 5;7;
5;7;
386+

352),1(7
/$1 /$1
352),1(7
35 353535
; ;
36 36
/ /0 0
'&9
0$& 0$&
$'' $''
%)
6)
07
21
; ;
①PROFINET IO interfaces for subnet 1 (X1) ⑥Status LEDs for PROFINET IO subnet 1 (X1)
②PROFINET IO interfaces for subnet 2 (X2) ⑦Status LEDs for PROFINET IO subnet 2 (X2)
③Status-LEDs for connection of the electrical
supply PS1 / PS2
⑧MAC address for PROFINET IO subnet 1 (X1)
④DC24V electrical supply PS1 / PS2
(X20 / X21)
⑨MAC address for PROFINET IO subnet 2 (X2)
⑤Diagnostics LEDs for PROFINET IO subnet
1 and 2 (X1, X2)
⑩Slot for SIMATIC Micro Memory Card
Figure 1-5 Display elements and interfaces of the PN/PN coupler

Description
1.3 Properties
PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 13
1.3 Properties
Properties
The PN/PN coupler has the following properties:
● Dataset transfer from an IO controller of one side to an IO controler of the other side.
● Data exchange of maximum 1024 bytes input data / output data with preferable division.
● Maximum of 16 input/output ranges for the exchange of data with the following virtual
modules: IN, OUT, IN/OUT, RD WRITE STO, RD READ STO, RD WRITE PUB and
RD READ PUB.
● Electrical isolation between the two PROFINET IO subnets
● Redundant power supply
● Diagnostic interrupts
● ReturnOfSubmodule interrupts
Properties via PROFINET IO
● Both sides: Integrated switch with 2 ports
● Port diagnostics
● Port disabling
● Supported Ethernet services: ping, arp, Net diagnostics (SNMP)/MIB2, LLDP
● Isochronous real-time communication (IRT)
● Prioritized startup
● Device replacement without removable medium/programming device
● Shared Device
● Media redundancy

Description
1.3 Properties
PN/PN coupler
14 Installation and Operating Manual, 06/2010, A5E00717043-04

PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 15
Assembling 2
2.1 Assembly rules
Mounting position
You can mount the PN/PN coupler in any position. Please note that the maximum ambient
temperature for horizontal mounting positions is 60 °C while that for all other positions is
40 °C.
You will find more information on operating conditions in Appendix Technical data (Page 79).
Open component
The PN/PN coupler is an open component. In other words, you may only set it up in
enclosures, cabinets or electrical service rooms. These should only be accessible by means
of a key or a special tool. Only trained or authorized personnel may have access to the
enclosures, cabinets or electrical service rooms.
Technical setup
Mount the PN/PN coupler on a DIN rail (7.5 mm and 15 mm). Ensure a space of 40 mm both
above and below the module for unimpeded assembly.
2.2 Assembling the PN/PN coupler
Components required
● PN/PN coupler
● Mounting rail:
– DIN rail (7.5 mm) or
– DIN rail (15 mm)
The order numbers for the components can be found in Appendix Order numbers and
accessories (Page 89).

Assembling
2.3 Disassembling the PN/PN coupler
PN/PN coupler
16 Installation and Operating Manual, 06/2010, A5E00717043-04
Assembling PN/PN coupler on DIN rail
1. Assemble the DIN rail such that there is enough space to assemble and heat the
modules (at least 40 mm above and below the modules). If you want to swap the
SIMATIC Micro Memory Card once the PN/PN coupler is assembled, you will have to
leave additional space for this.
2. Fit the PN/PN coupler in the DIN rail and swing it down.
3. Wire the PN/PN coupler as described in Chapter Connecting (Page 19).
Note
If the assembly base is a grounded metal plate or a grounded equipment mounting plate,
then you must ensure a low-ohm connection between the DIN rail and base. E.g. with
painted or anodized metals, use a suitable contacting agent or contact washers.
2.3 Disassembling the PN/PN coupler
Disassembling the PN/PN coupler
1. Switch off the PN/PN coupler's power supply.
2. Loosen the connections and bus connectors on the PN/PN coupler.
3. Use a screwdriver to push down the slide valve on the underneath of the PN/PN coupler.
4. With the slide valve still pressed down, swing the PN/PN coupler out of the mounting rail.

Assembling
2.4 Assembling-color plates
PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 17
2.4 Assembling-color plates
Introduction
The color-coding plates allow you to individually color code the PROFINET IO interfaces in
accordance with company and national regulations. The color-coding plates are available in
white, red, yellow, yellow-green, brown, blue and turquoise. You can provide every
PROFINET IO interface on the PN/PN coupler with a color-coding plate.
The color-coding plates are positioned on the bottom right of each PROFINET IO interface.
Required tool
Screwdriver 3.5 mm blade width
Assembling color-coding plates
1. Use the screwdriver to push the spigot of the color-coding plate into the opening provided
for this in the PN/PN coupler.
2. Secure the color-coding plate as described below.
3. Bend the star-shaped support up by approx. 30° to 40°.
4. Detach the color-coding plate by moving the support this way and that.
Disassembling color-coding plates
Use a screwdriver to lever the color-coding plates from their supports.
See also
Order numbers and accessories (Page 89)

Assembling
2.4 Assembling-color plates
PN/PN coupler
18 Installation and Operating Manual, 06/2010, A5E00717043-04

PN/PN coupler
Installation and Operating Manual, 06/2010, A5E00717043-04 19
Connecting 3
3.1 Electrical isolation and grounding
3.1.1 Introduction
Redundant 24 V DC power supply
You can connect the PN/PN coupler to two independent 24 V DC power supplies. Only one
24 V DC power supply is ever active at any one time. If one power supply fails, the other
automatically becomes active. During parameterization, you identify which power supplies
(PS1, PS2 or both) are connected and are to be diagnosed. You need only connect up one
24 V DC power supply to operate the PN/PN coupler.
Properties of the PN/PN coupler
● Both PROFINET IO subnets are electrically isolated from one another.
● Both PROFINET IO subnets are electrically isolated from the 24 V DC power supply.
● Both 24 V DC power supplies are electrically isolated from one another.
● The PROFINET IO subnet to X1 and the logic of the PN/PN coupler are electrically
linked.
Ungrounded incoming supply
Non-grounded operation of the PN/PN coupler is possible with a 24 V DC power supply.
See also
Parameters (Page 34)

Connecting
3.1 Electrical isolation and grounding
PN/PN coupler
20 Installation and Operating Manual, 06/2010, A5E00717043-04
3.1.2 General operating rules and regulations
Introduction
If they are part of plants or systems the modules described require adherence to specific
rules and regulations depending on the application.
The most important rules, which you must observe for safe integration into a plant or system,
are listed below.
Specific application
Please observe the safety and accident prevention regulations applying to specific
applications (e.g. machine protection guidelines).
EMERGENCY STOP equipment
EMERGENCY STOP devices according to IEC 6204 (coincides with VDE 113) must remain
effective during all operating modes of the plant or system.
System startup after certain events
The table below identifies situations you must pay attention to when the system starts up
after the occurrence of certain events.
When ... ...
starting up after a voltage dip or
power failure,
starting up after bus communication
has been interrupted,
no dangerous operating states may occur. If necessary
actuate an EMERGENCY-STOP!
starting up after unlocking the
emergency stop device,
starting up without the IO Controller
activating the IO Devices,
the start up must always be controlled and defined.
