Chipolino DINO User manual

This product is produced in conformity with the
Toy Safety Directive 2009/48/EC of the European parliament and the council,
Regulation for essential requirements and assessment of the compliance of
toys and the applicable European standards. The National Legislation and
the applicable European standards.
IMPORTANT! KEEP THIS MANUAL FOR FUTURE REFERENCE!
INSTRUCTION MANUAL FOR USE OF
KID’S BALANCE TOY ON WHEELS
„DINO ”

1
TO GUARANTEE THE SAFE USE OF THIS PRODUCT, FOLLOW THE
WARNINGS, GUIDELINES AND RECOMMENDATIONS IN THIS MANUAL:
CAUTION! USE ONLY UNDER DIRECT ADULT SUPERVISION AND WITH A COMPANION –
DANGER OF FALLING!
CAUTION! THIS TOY HAS NO BRAKES!
CAUTION! TO BE USED ONLY BY CHILDREN OLDER THAN 1.5 YEARS!
CAUTION! THE TOY IS NOT SUITABLE FOR CHILDREN UNDER 1.5 YEARS AND MAXIMUM
CHILD WEIGHT 25 kg.
CAUTION! DO NOT OVERLOAD! NOT TO BE USED BY CHILDREN MORE THAN 25 kg.
CAUTION! BEFORE USING THE TOY, TEACH THE CHILD THE CORRECT USAGE AND SAFETY
RULES.
CAUTION! THE CHILD MUST WEAR A HELMET, KNEE AND ELBOW PROTECTORS AND
SHOES WHEN USING THE TOY!
CAUTION! USE THE TOY ONLY FOR ITS PURPOSE!
CAUTION! USE THE TOY ONLY DURING THE DAY AND ON EVEN SECURED PLAYGROUNDS
AT A SAFE DISTANCE FROM STREETS AND ROAD LANES FOR VEHICLES.
CAUTION! KEEP AWAY FROM FIRE AND OTHER SOURCES OF STRONG HEAT!
ONLY an adult should assemble the TOY!
DO NOT let children under 3 years near the TOY before you have assembled it, to avoid their access
to small and disassembled parts!
This TOY is intended for ONLY one child!
DO NOT allow children to push the toy!
This TOY is NOT suitable for running or skating!
DO NOT use the TOY if some parts are damaged or missing.
DO NOT allow the child to stand on the seat to avoid injuries!
Child must wear shoes while riding the TOY!
DO NOT put additional strings or accessories to the TOY to avoid risk of su󰀨ocation!
DO NOT leave items or luggage on the handle bar to avoid risk of balance disturbance.
DO NOT put items or heavy objects on the TOY during transportation and storing to avoid damage
of the construction.
DO NOT move the TOY by pulling it with another transport means!
DO NOT let the child playing with the TOY or other children near it to touch the wheels or put items
inside them!
Keep away from rivers, pools, stairs and hurdles!
DO NOT make changes or modications to the TOY construction! If necessary, contact the retailer
or an authorized service for advice and repair.
DO NOT use spare parts or other components, which are not provided by the producer!
The producer revokes all responsibility in case spare parts have been used, which are di󰀨erent from
the original ones or recommended by the producer.
 Keep the nylon package away from children to avoid risk of su󰀨ocation!
IMPORTANT! MAJOR WARNINGS!

2
PRODUCT FEATURES
MAIN PARTS
The TOY is intended for children older than 1.5 years with weight not more than 25 kg.
KIDS BALANCE TOY ON WHEELS is a bicycle without pedals, which develops in your child sense
of orientation and speed in a safe way. This creates a feeling of balance and safety because the child’s
feet are in contact with the ground at all times. While riding the bike, the child learns to balance and
exercises di󰀨erent moves (turn left and right), learns to control speed depending on its abilities.
1 2 3
4
5
678910
1Saddle - 1 pc 6Screw set – 1 pc
2Handle stem cover - 1 pc 7Scrrew set – 1 pc
3Handle bar – 1 pc 8Handle bar screw – 1 pc
4Frame – 1 pc 9Wheel axle – 2 pcs
5Fork – 1 pc 10 EVA Wheels – 2 pcs
Please make sure all parts are available in the package.

3
Tools needed: Hex key (included in the set).
ASSEMBLY AND USE GUIDE
CAUTION! FOLLOW EXACTLY THE GUIDELINES AND SEQUENCE OF ASSEMBLY AND USE,
WHICH YOU WILL FIND IN THE TEXT AND FIGURES.
CAUTION! CHECK FIXING IS SECURE AFTER COMPLETING EACH OPERATION!
CAUTION! TIGHTEN THE BRACKETS WELL. IF THEY ARE LOOSE, THE PRODUCT MAY FALL
APART AND THE CHILD MAY BE INJURED.
CAUTION! Adjust the height of the saddle by following the security tag on the post (the mark must not
be visible).
CAUTION! The toy must be used with increased caution, because it requires balance skills. In this way,
you will avoid falling or collisions, which may injure the child or third persons.
1. FORK ASSEMBLY
Insert the fork into the front tube of frame. Place the handle stem cover. Insert the handle bar into the
tube of fork and x with screw.
CAUTION! Make sure that screw is tighten and handle bar is strongly xed to fork and frame!
2. REAR WHEEL ASSEMBLY
Insert the axis into the opening on wheel, then the wheel between rear tubes of frame and x with the
screws at both sides.
3. FRONT WHEEL ASSEMBLY
Insert the axis into the opening on other wheel, then the wheel between the tubes of fork and x with
the screws at both sides.
4. SADDLE ASSEMBLY
First loosen the bracket of the saddle the with hex key to be able to adjust the position of saddle tube to
frame slot. Set the saddle in suitable for child position, so that its front part to be located above the frame
tube without being aside. Fix the height of saddle by tightening the screw at bracket with the hex key.
CAUTION! Adjust the height of the saddle by obeying the markings for the depth (markings must be visible).
5. SADDLE HEIGH ADJUSTMENT
Untighten the screw with hex key, adjust the saddle up or down until required position by obeying the
markings for the allowed depth. Tighten back the screw.
CAUTION! Make sure that saddle is strongly xed in suitable height!
CAUTION! Toy must be used with high attention, as it requires balance skills. This way you will avoid
falling or impacts that can lead to injuries of child and/or other people.

4
The child must be comfortably seated, not leaning forward to the handle bar and its feet must be in full
contact with the ground
IMPORTANT! For beginners we recommend initially to use the lowest position of the seat!
FOR MORE SAFETY WHEN THE CHILD USES THE TOY, IT SHOULD WEAR A HELMET, KNEE
AND ELBOW PROTECTORS AND SHOES!
The helmet must be steady on the head, not tilted back or in position in
which it does not protect the forehead.
CHOOSING THE OPTIMAL POSITION OF THE SEAT
HELMET, KNEE AND ELBOW PROTECTORS, AND SHOES
frame
fork
screw
screw
screw
screw
axle for wheel
axle for wheel
wheel
wheel
saddle
bracket
screw
screw
handle
stem cover
saddle
tube
1
2
3
4
handle bar

5
CARE AND MAINTENANCE
Periodically check the good working order of all parts.
Do not wet the TOY. Clean with a soft damp towel and a neutral liquid soap.
Do not use aggressive detergents containing abrasive particles, ammonia, bleach or spirit.
Regularly oil the moving parts.
Do not use on sandy surfaces.
Do not store the TOY in areas with hot air or close to heat sources, because it will deform.
 Store the TOY in a clean and dry place. Do not subject to direct environmental inuence – sun, rain,
moisture or harsh temperature changes!
Always dry the TOY or let it dry before storing or using it again. Mildew may appear if you store the
product moist.
In case of problems related to the normal exploitation, contact the authorized service for advice or
repair.
Materials used: plastic and metal.
