Chipolino JUMBO User manual

OWNER’S MANUAL
with Assembly Instructions
Read and understand this entire manual before using!
Please keep this manual for future reference as it contains important information.
Before first time use, charge the battery for at least 4-6 hours.
PLEASE READ THE
INSTRUCTIONS
NO:2
Styles and colors may vary
◎Suitable age for 3+ Years
◎Maximum user weight: 30kg
◎Adult assembly required

On the purchase of your new Ride-On
Suitable age
37-96 months
Load Capacity
Under 30KG
Speed
3-5km/hr
Charge time
8-12 hours
Size of car
108×64×59cm
Battery life
300 recharges
Power way
Charging type
Specification

Number
Name
Quantity
Remark
Two motors
1
Car bucket
1
2
Seat（plastic）/（leather）
1
choose
3
Steering wheel
1
4
Steering wheel trim
1
5
Chimney
1
6
Front wheels
2
7
Rear wheels
2
8
Wheel cap
4
9
Steering iron
1
10
Steering rod
1
11
Rear axle
1
12
Driving motor
2
Left / Right
A
Ø10 nuts
4
Install on the front
and rear axles
B
Ø10 gasket
8-9
C
M4×12 screw
8-9
Seat *2/ Car bucket
*5
D
Ø8 gasket
1
Install on the
Steering wheel
E
Ø8 nuts
1
Install on the
Steering wheel
F
Cotter pin
1
Install on steering
rod
2. Parts List
※ Assembly tools required
Screwdriver
(not included)
Spanner
( included)
M8 spanner
( included)

Parts Diagram

CHOKING HAZARD! NOT suitable for children under 37 months.
●ADULT ASSEMBLY REQUIRED.
Safety
●Keep children within Safe Riding Areas:
Never use in roadway near motor vehicles, on lawn space, on or near
steep inclines or steps swimming pools or other bodies of water;
●Use the toy only on flat surfaces. Such as inside your house, garden or
playground.
●Never use in the dark .A child could encounter unexpected obstacles and
have an accident. Operate the vehicle only in the daytime or a well-lit
area.
●It is prohibited to change the circuit or add other electric parts
●Inspect wires and connections of the vehicle periodically.
●Do not let any child touch the wheels or be near them when the car is
moving.
●This vehicle has adjustable play seat belts. Please instruct children how
to tie the safety belt before using ;guarantee the security.
PREVENT INJURIES AND DEATHS:
●NEVER LEAVE CHILD UNATTENDED.ADULT DIRECT
SUNPERVISION IS REQUIRED.Always keep child in view when
child is in vehicle.
●This toy should be used with caution since skill is required to
avoid falls or collisions causing injury to the user or third parties.
●Protective equipment should be worn.
●Never use in roadways,near cars,on or near steep inclines or
steps,swimming pools or other bodies of water.
●Always wear shoes,always sit on the seat.
●Not to be used in traffic.
●This toy is unsuitable for children under 36 months due to its
maximum speed;Maximum user weight is 35 kgs.
●This toy has no brake.
Rules for Safe Riding

Operation
Turn the car back up
1.Insert Ø10 gasket into the steering rod；
2.Insert the hole of steering iron into the steering rod (either one
can be inserted first );
3.InstallØ10 gasket into the steering rod；
4.Fixed the Cotter pin;
Cotter pin

Operation Instruction

Turn the car back up
1.Put an ø10 gasket into the front axle
2.Install the front wheel；
3.Put another ø10 gasket；
4.Fixed with Ф10 nuts；
5.Install the wheel cap；
6.Put the rear axle in as shown；
7.Install the driving motor into the rear axle, connect the motor
wire plug to the plug at the motor bayonet, snap the motor into the
slot, and plug the wire into the receiver;；
8.Put the driving wheel on the rear axle and make sure the driving
wheel plum blossom snaps into the motor plum blossom slot；
9.Put another ø10 gasket；
10.Fixed withФ10 nuts；
11.Install the wheel cap to the wheel；
Use the same way to install the wheel on the other side(Motor
division: left and right)
Operation Instruction

Operation Instruction
1. Insert the chimney into the slot of the car
body, as shown in the picture;
2. Insert the steering wheel into the steering
rod;
3, Put an Ф gasket;
4, Fixed with Ф8 nuts;
5. Insert the Steering wheel trim into the
steering wheel;
1. Insert the car bucket into the slot of the car body as
shown in the picture; Fixed with M4*12 screws;

1. Insert the seat into the car body;
2. Fixed with M4*12 screws;
Operation Instruction
1. Find the main power wires and insert the plug-in of the wires
into the slot of the receiver.

1. Power button: turn on or off the power;
2. Forward/backward switch: control the moving direction, forward
or backward;Stop switch in the middle;
3. Foot switch: step on the switch, the car moves, release and the car
will brake slowly;
4. Central control panel;
5. Car bucket switch: control bucket to rise or fall;
6. Charging hole: the charger can be connected to charge the
car(please read the instructions carefully before charging );
Operation Instruction

Central control panel：
1.Power display: Clearly see the battery power, in order to charge；
the smaller the number, the lower the voltage. Please charge in time;
2.Last song/Volume decrease：Change songs, and long press will decrease
volume；
3.Play or stop switch;
4.Next song//Volume increase: Change songs, and long press will
increase volume；
5.Mode switch: press to switch mode/music mode/radio mode/bluetooth
mode;
6.MP3：the data cable can be connected to other devices and play music;
7.USB: need connect your USB device；
Function Instruction

Operation Manual : For the first time to use (Or Replace the battery)Need
to frequency bind
Take out the remote control,lift the battery compartment door on the
back of the controller and insert two AAA batteries. install the battery
Long press on the frequency key 2-4 seconds, Low speed LED light
flashing
Turn on the power of the car, Low speed LED light keep flashing to
long lighting, then frequency bind succeed
If the frequency bind failed (Low speed LED light flashing) , remove
the battery and repeat steps 1~3
remote control without operation after 10 seconds, indication light
will off into power saving mode
Button Description: △forward ▽backward ◁turn left ▷turn right
S: Speed , P: emergency brake, Press it and the running function
will fail, press again, it release
NOTE:1.non-rechargeable batteries are not to be recharged，
2.different type of batteries or new and used batteries are not to
be mixed ，
3batteries are not to be inserted with the correct polarity，
4exhausted batteries are not to be removed from the toy，
5the supply terminals are not to be short-circuited
、
WARNING!
Only allow adult to use
remote control,can not
let the children touch
Use the Remote Control

13. Charge
1.Insert the charger jack into the charging hole of the car.
2.Plug the charger plug into the stable matching AC power supply as shown
in the picture.
ATTENTION: Only an adult can charge and recharge the battery!

14. Charging
ONLY AN ADULT CAN CHARGE AND RECHARGE THE
BATTERY!
WARNING!
PREVENT FIRE AND ELECTRIC SHOCK:
-Use the only rechargeable battery and charger supplied with your vehicle. NEVER
substitute the battery or charger with another brand. Using another battery or
charger may cause a fire or explosion.
- Do not use the battery or charger for any other product. Overheating, fire or
explosion could occur.
- NEVER modify the electric circuit system.. Tampering with the electric system may
cause a shock, fire or explosion or my permanently damage the system.
- Do not allow direct contact between battery terminals. Fire or explosion can
occur.
- Do not allow any type of liquid on the battery or its components.
- Explosive gasses are created during charging. Do not charge near or flammable
materials. Charge the battery in a well-ventilated area ONLY.
-rechargeable batteries are only to be charged under adult supervision
rechargeable batteries are to be removed from the toy before being charged
Must confirm before using that following work which is already finished:
Important! Before using the vehicle for the first time, the battery needs to be charged for 4 to 6
hours , no more than 15hours. Only an adult can charge and recharge the battery.
Check all the screws, cap nuts and protective coverings regularly and tighten as required.
Rules for Safe Riding
Keep Children within safe riding areas:
Never use in roadway, near motor vehicles, on lawn space , on or near steep inclines or steps
swimming pools or other bodies of water;
Use the toy only on flat surfaces. Such as inside your house, garden or playground
Never use in the dark . A child could encounter unexpected obstacles and have an
accident. Operate the vehicles only in the daytime or well-lit area.
It is prohibited to change the circuit or add other electric parts.
Inspect wires and connections of the vehicle periodically
Do not let any child touch the wheels or be near them when the car is moving.

Protector
This product is equipped with self-reset protector, when overloaded or improper use, self-reset
protector will automatically cut off the power supply for 15-20 seconds, and then restart. The
self reset protector of the car is installed under the seat.
TO avoid losing power,follow these guidelines:
Do not overload the vehicle,maximum 30KGS.
Do not tow anything behind the Vehicle.
Do not immerse water or other liquids in electrical components,such as wiring,batteries,etc
Do not tamper with the electric system.replacement must be conducted by professionals or under
the guidance of technicians.
BATTERY REPLACEMENT AND DISPOSAL
Check the charger's wires, plugs, housing and other components before use. Stop using the
charger when damage is found until it is repaired.
After a period of time, lubricate the parts of the vehicle with a small amount of lubricating
oil to prevent wear and rust.
Vehicles should be placed far away from fire sources and avoid long-term illumination. Keep
it flat and facing upwards, not upside down or tilted; in wet weather, parked indoors or covered
with waterproof cloth.
Vehicles should be kept away from hot objects such as stoves and heaters. Plastic parts may
melt. When charging, keep away from inflammable materials to prevent fire.
After use, please charge in time, charging must be adult operation. If you don't have to charge
the battery for a long time, then charge it at least once a month to extend the battery life.
Wipe the vehicle with dry soft cloth. Non-waxy furniture polishing material can also be used
instead of soft cloth to wipe plastic parts to achieve surface finish effect. Do not use
chemical solvents to wipe plastic parts of toys. Do not use soap and water to clean vehicles.
Do not drive in rainy or snowy weather. Water can damage motors, electrical systems and
batteries.
When you stop using or placing the product, please cut off the power supply of the product
and dial all switches to the stop or close position.
Please do not use fuse that is not in conformity with the specifications of this product.
Do not alter the structure and circuit system of the product without authorization. Maintenance
work must be carried out under the guidance of professional or technical personnel.
15. rotector

Checkpoint
Elimination method
1.Is the protector of the vehicle disconnected?
2.Does the foot switch connect well?
3.Is the welding line on the motor terminal
good?
4.Is the connector of the motor lead properly
connected?
5.Is it turning the Disconnect the plug-in of
the motor and directly connect it to the
battery?
Yes， cut off the power for 15-20 seconds and then
restart No，next
NO，fix the foot switch；Yes，next
NO，Weld the terminal wire well；Yes，next
No，Plug in plug-ins；Yes，next
NO，Change motor；Yes，Driving circuit boards need
professional maintenance, contact agents or
distributors
1.Check whether the battery voltage is normal.
2.Will the motor (Gearbox) directly connect to the
battery and speed up？
NO，charge；yes，next
Yes，Drive circuit board failure, contact agent or dealer
1.Is the battery plug-in loose?
2.Does the charger feel any slight heat
when charging?
Yes，Lock battery plug in；No，next
No，Maybe the charger is broken. Replace the
charger
Driving.no sound
and light
1.Is the acoustooptic
switch good?
2.Check whether the
line and plug-ins from
battery to vehicle are
good.
No，change button；Yes，next
No，plug in the plug-in and connect the
broken line
Wheels do not
move.
1.Is the drive
rotating?
2.Check gear box,
gear at all levels
are damaged.
Yes，Land the wheel；No，next
Yes，Change a new gearbox
The vehicle is
moving, it stops.
1. Does the rider
weigh more than 30
kilograms?
2.Is it driving in
rough terrain?
3.Check that the
horizontal wheel can
turn itself?
Yes，normal；No,next
Yes，normal；The vehicle should run on the
cement road No，next
No，remove wheel and wheel fault
16. Troubleshooting Guide

The above troubleshooting method, when the user is not
available, please contact agents or distributors.
This product is only suitable for sale and use in the
Chinese market.
The illustrations used in this specification are intended
to illustrate the operation method and product structure of
the product. If there is a small difference between the
physical object and the illustrations, the physical object
shall prevail.
In order to improve the quality of the product, we may
change part of the structure and appearance of the product
without notice. Please understand.
The packaging contains important information and must be
kept.
Remote control
vehicles do not
respond
1.Does the brake
function start?
2.Is remote control
electrified?
3.Is the receiver
wiring harness
loose?
Yes ， Press the brake key to relieve the brake
function; No，normal
Yes，try again;No，Check whether the battery is out
of power and whether the installation is in place.
Yes，remove the row,reinstall;No，normal
