Chipolino MOTO User manual

This product is produced in accordance with Toy
safety Directive 2009/48/EC of the European Parliament and the Council, the
standards applicable for this toy and the regulations of national legislation.
IMPORTANT! RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE!
INSTRUCTION MANUAL
FOR TOY RIDE ON CAR
MODEL „MOTO”

1
IMPORTANT! WARNINGS!
• CAUTION! NEVER LEAVE THE CHILD UNATTENDED!
• CAUTION! THIS TOY HAS NO BRAKE!
• CAUTION! THIS TOY IS NOT SUITABLE FOR CHILDREN UNDER 1.5 YEARS AND WEIGHT
MORE THAN 20kg. DO NOT OVERLOAD!
• CAUTION! THIS PRODUCT IS NOT A TRANSPORT MEANS!
• CAUTION! DO NOT USE ON ROAD LANES!
• CAUTION! KEEP AWAY FROM FIRE!
• CAUTION! BEFORE USE, CHECK THE GOOD WORKING ORDER AND FIXING OF ALL PARTS.
• Use for a child over 1.5 years of age!
• Not to be used by two children simultaneously!
• Adult assembly only!
• The child must wear shoes at all times when using the toy! It is advisable to use helmet and protectors.
• Use only during the day and in places with good lighting.
• Do not let children touch the wheels or stand close to them while the ride on car is moving!
• Iftherearestickersgoingo󰀨,youmuststickthembackorremovethemtoavoidchildrenswallowing
them!
• Donotusetheproductifyoundanymissingordamagedparts!
• Do not use spare parts or other components, which are not supplied by the producer! The producer
 revokesallresponsibilityincasepartsdi󰀨erentfromtheoriginaloneshavebeenused.
• Donotmakechangesormodicationstotheconstruction!Ifnecessary,contacttheretaileroran
authorized service center for advice and repair.
• Use the product only for its purpose!
• Do not allow presence of children under 1,5 years before assembly of the product is complete,
to avoid access to small or loose parts!
• Donottiestringsoraccessoriestotheproductinordertoavoidtheriskofsu󰀨ocation.
• Use only on even playgrounds and at a safe distance from streets or road lanes for vehicles!
• Do not use the product near stairs, escalators, protrusions, swimming pools etc.!
• Keepnylonpackagesawayfromchildrentoavoidriskofsu󰀨ocation!
TO GUARANTEE THE SAFE USE OF THIS PRODUCT FOLLOW
THE WARNINGS, GUIDELINES AND RECOMMENDATIONS IN THIS MANUAL!
• Do not allow children to access or play with the batteries!
• Use only batteries of the designated type and power.
• Donotusebatteriesofdi󰀨erenttypes.
• Do not mix new with used batteries.
• Follow the designated polarity in the battery compartment.
• Remove damaged or worn out batteries.
• Remove the batteries when the product will not be used for long time.
• Donotthrowthebatteriesinopenre.Donottakethebatteriestopieces.
CAUTION! Waste from depleted or unusable batteries must be disposed of separately. It is forbidden
tothrowthemoutincontainersforhouseholdwaste.Disposeofthebatteriesonlyatthespecied
places.
IMPORTANT! WARNINGS AND GUIDELINES FOR BATTERY USE

2
MAIN PARTS
Handlebar
Seat
Rear wheels
Front wheels
Body
Handlebar release
button
Please check that the described parts are available.
• The toy is intended for a child over 1.5 years of age and weighing up to 20 kg!
• When the child is sitting in it, the ride on car is propelled by the child’s feet.
• Music and light
• Batteries,3pcs,typeАА/1,5V.Batteriesarenotincludedintheset.
MAIN FEATURES OF THE PRODUCT
Part name Photo Qty Part name Photo Qty
Body with
rear wheels 1 pc Screw for the seat ø4*х2 1 pc
Handlebar 1 pc Lock pin 2бр.
Wheel cover 2 pcs Front axle 1 pc
Seat 1 pc Front wheel 2 pcs
Washer 2 pcs

3
1. ASSEMBLY OF FRONT WHEELS
1-1 – Insert the front axle in the opening in the car body and attach the front wheel on the axle.
1-2 – Place the washer on the axle.
1-3 – Insert the lock pin as shown in the picture.
1-4 – Attach the wheel cover with pressure as shown.
IMPORTANT! When attaching the wheel cover, its pins must match the openings in the wheel.
Install the other front wheel following the same actions.
2. ASSEMBLY OF HANDLEBAR
Insert the handlebar in the car body and press. You will hear a click and the button of the handlebar will
showfromthehole.Thehandlebarisxed.
To remove the handlebar, push the button and pull it out.
3. ASSEMBLY OF SEAT
Note:Beforeinstallingtheseat,youmustrstplacethebatteries,asshowninpoint4–„PLACINGTHE
BATTERIES“.
3-1 – Place the seat on the car body.
3-2 – Press the seat down.
3-3 – Fix the seat with the screw.
4. PLACING THE BATTERIES.
The batteries compartment is located under the seat.
Tousethefunctionsmusicandlight,youmustplace3pcsbatteriestypeАА/1,5V:
1. Unscrew the cover using a screwdriver.
2.Place3pcsbatteriestypeАА/1,5Vinthebatteriescompartment,followingthebatteriespolarity.
3. Put the cover back and tighten it with a screwdriver.
5. FUNCTIONS – music and light
Press the ON/OFF button, then press the music and light button.  Each time you press the button,
the melody will change.
WARNING! Follow exactly the instructions and sequences for assembly and using the product from the
belowgures.
WARNING!Checkthesecurityofxingafterperforminganyoperation!
Required tools for performing some operations: screwdriver (not included).
The toy assembly operations and functions are described below from 1 to 5. Use the descriptions below
along with the illustration bearing the same number.
ASSEMBLY UNSTRUCTIONS AND FUNCTIONS
ASSEMBLY

4
1-1
1-3 1-4
1-2
2
front wheel
press
“click“
removal
button
front axle
lock pin
wheel cover
washer

4
5
3-1 3-2 3-3
5
screw
ON/OFF
button Music/light
button
screw
x the screw
screw
Socket cover for batteries Battery slot
Necessary batteries: 3pcs type AA/1,5V (LR6)
screw

6
CARE AND MAINTENANCE INSTRUCTIONS
Regularly check the plastic parts of the ride on car for any cracks or damage.
Regularly oil the moving parts.
Clean the toy by using a damp soft towel or sponge and a mild soap. Do not pour water on the toy.
Do not clean with aggressive detergents containing abrasive particles, ammonia, bleach or spirit.
Store the product in a clean and dry place, without moisture and at a safe distance from heat
 sources!Donotsubjecttodirectenvironmentale󰀨ect–sun,rain,moistureorharshtemperature
changes!
Do not use the product on muddy, sandy or gravel covered terrains, which can damage the moving
parts.
ROCMO02хххх/P02

CHIPOLINO LTD., 1 Goliamokonarsko Shosse Str, Plovdiv, BULGARIA
www.chipolino.com
