Christie Mirage 4K25 User manual

Academia
Aerospace
Automotive
Government
Heavy machinery
Museums
National labs
Oil and gas
Research and development
Sciences and biotechnology
Theme parks
First and only DLP 4K at 120Hz performance
For a quantum leap in image processing, look no
further than the Christie®Mirage 4K. Delivering the
highest DLP®resolution on the market today and
based on Christie’s unique TruLife™electronics this
new platform gives you unprecedented image fidelity,
life-like vibrant colors and up to 35,000 lumens for the
brightest 3D immersive user experience. Additionally
you have the added value of Xenon-based illumination
giving you the most natural color accuracy, uniformity
and stability over time.
Christie TruLife electronics support a video-processing
pipeline of up to 1.2 Gigapixels per second which is
10 times faster than full high-definition bandwidth.
This provides flexibility in supporting various 3D
interconnectivity formats: single sequential 4K
120Hz input, dual interleaved 4K 60Hz signals,
and 4K 60Hz sequential frame-doubled, all three
modes resulting in 120Hz 4K output.
Based on Christie’s superior design, engineering and
manufacturing capabilities, the Mirage 4K product
line provides 24/7 reliability, ease of service and
consistent performance for years of operation.
At Christie we help our customers create and share
the world’s best visual experiences.
Christie Mirage 4K25/4K35

Christie Mirage 4K25 Christie Mirage 4K35
Image brightness • 10,000 center lumens (9000 ANSI lumens) – 2.0kW lamp •18,000 center lumens (16,000 ANSI lumens) – 3.0kW lamp
• 25,000 center lumens (22,500 ANSI lumens) – 3.0kW SD lamp
• 29,000 center lumens (27,000 ANSI lumens) – 4.5kW lamp
• 35,000 center lumens (32,500 ANSI lumens) – 6.0kW lamp
contrast • 2000:1 (full on/off)
Display type • 4K (4096 x 2160) •3-chip 1.38" DMD™ •Supports 4096 x 2160 (24-120Hz) and 3840 x 2160 (24-120Hz) •HDCP compliant
Lamp1type • Xenon bubble
estimated life • 2.0kW lamp CDXL-20 3500 hrs •3.0kW lamp CDXL-30 2500 hrs •3.0kW lamp CDXL-30SD 1500 hrs
• 4.5kW lamp CDXL-45 900 hrs •6.0kW lamp CDXL-60 750 hrs
Input signals 4K resolution,
120Hz frame rate
4 x Twin DisplayPort input card (standard):
•DisplayPort 1.1a via 8 frame-locked L/R 60Hz signals, combined 120Hz output: 4:4:4 8-/10-bit, 4:2:2 8-/10-/12-bit
•DisplayPort 1.1a via 4 frame-locked 120Hz, signals in, 120Hz output: 4:4:4 8-/10-bit, 4:2:2 8-/10-/12-bit via 4 frame-locked 120Hz signals
Optional Twin HDMI input card (4 required) via 8 frame locked L/R 60Hz signals, combined 120Hz output:
•4:4:4 8-/10-bit, 4:2:2 8-/10-/12-bit
Optional Dual Link DVI-D (4 required): via 4 120Hz signals in, 120Hz output; RGB 8-bit
Optional for
60Hz input
120Hz output
frame doubled2
2 x Twin DisplayPort input card (standard): 2 x DisplayPort 1.1a, 60Hz, 4:4:4 8-/10-bit
Optional 2 x or 4 x DVI (Dual Link) Input Card: 60Hz, RGB 8-bit
Optional 4 x 3G HD-SDI: 60Hz, 4:2:2 10-bit
Signal outputs loop-out • Standard Twin DisplayPort input card •Optional Dual 3G HD-SDI input card •Optional Twin HDMI input card
Control and networking • RS-232 •Ethernet (10/100) RJ45 with ChristieNET™ connectivity •Detachable LCD control module
Lenses fixed • 0.72:1* •1.0:1**
zoom • 1.13-1.31:1*** •1.31-1.63:1 •1.63-2.17:1 •1.98-2.71:1 •2.71-3.89:1 •3.89-5.43:1 •5.43:1-7.69:1***
offsets •
All lenses ±13% Vertical ±4% Horizontal except those noted below
*No offset **1.0:1 fixed lens ±29% Vertical ±9% ***1.13-1.31:1 and 5.43:1-7.69:1 zoom lenses ±56% Vertical ±19%
Accessories standard • Detachable LCD control module •AC line cord for projector head •Christie Twist™ software3
• Detached 7kW low-ripple switch mode lamp ballast
optional • Heat extraction fan kit (required when operating projector) •Rack mount pedestal •Replacement air filter for light engine
• Replacement air filter for liquid cooling radiator •Lamp adapter kit for CDXL-20 •Christie Twist Pro software3•Emitter (standard range)
• Emitter (long range) •Active 3D eyewear •Passive stereoscopic modulator •Passive 3D eyewear
Lens mount type • Tool-free lens insertion system •Boresight adjustable •Motorized horizontal and vertical lens offset
• Motorized zoom and focus adjustment
Power
requirements
projector • Operating voltage: Single phase 200-240 VAC @ 50/60Hz
• Operating current: 23A max @ 200V • Operating current: 7A max @ 200V
ballast •NA • Type: Detached 7kW low-ripple switch mode lamp ballast
• Operating voltage: 3-phase 200-230 VAC @ 50/60Hz
• Operating current: 38A per phase max
• Operating voltage: 3-phase 380-415 VAC @ 50/60Hz
• Operating current: 26A per phase max
Dimensions size • Projector (LxWxH): 51.1 x 25.5 x 19.0"
(1299 x 648 x 480mm) with lens cover
• Projector head (LxWxH): 51.1 x 25.5 x 19" (1298 x 648 x 483mm)
• Ballast (LxWxH): 21 x 18 x 21" (533 x 457 x 533mm)
shipping size • Projector (LxWxH): 60.4 x 36 x 28.5"
(1535 x 914 x 724mm) with lens cover
• Projector head (LxWxH): 60.4 x 36 x 28.5" (1535 x 914 x 724mm)
• Ballast (LxWxH): 28 x 25 x 31.5" (710 x 635 x 800mm)
weight • Projector 273lbs (124kg) • Projector head 251lbs (114kg) •Ballast 89lbs (40.5kg)
shipping weight • Projector 344lbs (156kg) • Projector head 322lbs (146kg) •Ballast 135lbs (62kg)
Operating environment • Operating temperature: 50-95°F (10-35°C) •Humidity (non-condensing): 20-80%
Regulatory This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic
compatibility (EMC): Directives: (EC) 2011/65/EU (RoHS) •2012/19/EU (WEEE) •Regulations: (EC) No. 1907/2006 (REACH)
•CAN/CSA C22.2 No. 60950-1 •UL 60950-1 •IEC 60950-1 •EN 60950 •FCC, Part 15, Subpart B, Class A •ICES/NMB003 (A)
•EN55022/CISPR22 Class A •EN55024/CISPR24
The product is designed to comply to the rules and regulations required for the product to be sold in various regional markets, including:
USA/Canada, EU, Norway, Australia/New Zealand, Kuwait, China, Korea, Japan, Mexico, Ukraine, Russia, South Africa, Saudi Arabia,
Singapore, Brazil, and UAE
Limited
warranty
projector • Three years parts and labor (including light engine)
lamp • Contact an authorized Christie representative for full details of our limited warranty
1Lamp is included, but lamp choice must be specified at the time of order. 2Also compatible with a variety of 24-60Hz 2D formats.
3Christie Twist/Twist Pro warp/blend/scale functionality is included in hardware, but not available until new firmware is released in December 2013.
