The Christie Mirage WU-L offers high resolution, high pixel density,
high reliability and continuous system calibration for a cost-effective
2D/3D capable, flexible visualization solution.
With WUXGA resolution, this small footprint projection system offers
dual input 3D mode for passive to active conversion that provides
the highest performance 3D video content at 120Hz. The Christie
Mirage WU-L delivers visually stunning 3D for entertainment,
museums and education, scientific research, manufacturing, oil and
gas exploration, stereo simulation training and anything in between.
LED illumination provides precise, life-like vibrant colors and
repeatable performance, with no color wheel artifacts, for years
of virtually maintenance-free display. And, there are no restrictions
for positioning, which results in greater installation flexibility.
With optional lenses, embedded Christie Twist™ II, any orientation
projector placement and industry-leading Christie warranties, service
and support, the Christie Mirage WU-L provides high-performance
and ease of use for 3D users.
LED DLP® reliability with high performance 2D/3D flexibility

Christie Mirage WU-L (125-005106-01)
Image brightness • 600 lumens ANSI ±10% (rated at 75-80% EBU depending on the lens)
contrast • 10,000:1 dynamic; 1,400:1 FOFO; 450:1 ANSI
uniformity • 95% brightness and color uniformity after electronic adjustment
Display
technology
type • Revolutionary solid state projector using a single TI Darkchip 3™ with a solid state
illumination engine (no color wheel) and sealed optics
native resolution • Native 1920 x 1200 (16:10 aspect ratio) WUXGA
Illumination type • RGB LED illumination
estimated life • MTBF of 60,000 hrs on illumination package
Input signals • Native Dual link DVI-D • Dual Input 3D provides up to 120Hz native frame rate
from two frame-locked channels1 • Frame-doubled 3D – Dual link DVI, VGA (HDMI,
Analog BNC and SDI optional)
pixel clock • 330 MHz
scan rates • Horizontal: 15-120kHz • Vertical: 23.97-150Hz (up to 120Hz maximum output)2
Inputs/outputs,
control and
networking
inputs • RS-232 in/out • RS-422 in • Ethernet (10/100) • USB device
• GPIO (RS232 9-pin male connector) • Dual 7-segment status display
• Remote control (with optional wired XLR connection) • Slot 1-2 standard
(populated): two Dual link DVI-D (330 MHz) and VGA (165 MHz)
optional
input modules
• Two standard Dual link DVI input cards (330 MHz), VGA (165 MHz) • Full bandwidth
Analog BNC • Slots 2-4 unpopulated • Dual SD/HD-SDI • Video Decoder3 • Twin HDMI
Lenses4lens mount • Motorized horizontal and vertical lens offset • No shutter required
• No iris required – user programmable illumination parameters (eliminates the need
for a mechanical shutter)
fixed • 0.64:1 WUXGA fixed • 0.75:1 fixed
zoom • 1.2-1.6:1 WUXGA zoom lens
offsets5• 0.64:1 WU (±5% V/±5%H) • 0.75:1 (±100% V/±75%H) • 1.2-1.6:1 (±100% V/±75%H)
Standard accessories • IR remote • Line cord • Two Dual link DVI-D cards • 3D sync cable
Optional accessories • Analog RGBHV BNC input card for analog sources greater than 165 MHz • Dual link DVI
input card • Dual HD-SDI input card • Twin HDMI input card • User kit (includes manual, IR
remote and hard wired cable for the remote) • Rugged Motion Platform user kit available
Enhanced feature sets • Minimum Processing Latency (MPL™) • Christie Twist™ II – advanced warping/
edge-blending hardware technology integrated directly into the projector, includes
warping/blending software • Auto set-up, power up • Menus in eight languages
• Multiple channel memories (for recall memory storage) • Christie ArrayLOC™ –
automatic, continuous management of brightness and color space levels of all
projectors in an array to a common level, in real-time
Power
requirements
operating voltage • 100-240 VAC @ 50/60Hz
operating current • 5.3A
power consumption • 400W maximum (variable, dependant on content)
dissipation • 1364 BTU/hr (variable, dependant on content)
Dimensions size • Projector head module + light module (no lens) (LxWxH): 8.7 x 18.4 x 11.0"
(220 x 467 x 287mm) • Electronics module (LxWxH): 16.5 x 5.5 x 6.7" (420 x 140 x 170mm)
weight • Projector head module + light module (no lens): 32lbs (14.6kg)
• Electronics module: 9.7lbs (4.4kg)
shipping weight • 52lbs (23.6kg)
Noise • 38 dBA at 25°C ambient temperature (without electronics module)
Operating environment • Temperature: 40-95°F (5-35°C) • Humidity: 20-80% non-condensing
Regulatory approvals • Directives (EC) 2002/95/EC (RoHS) • 2002/96/EC (WEEE) • Regulation (EC) No.
1907/2006 (REACH) • CAN/CSA C22.2 No. 60950-1 • UL 60950-1 • IEC 60950-1
• FCC, Part 15, Subpart B, Class A • EN55022/CISPR22 Class A • EN55024/CISPR24
•
Certifications marks (check with Christie for latest update): cULus (Canada & US),
CE (EU), CCC (China), GoST-R (Russia), KC/KCC (Korea), PSE (Japan), C-Tick
(Australia & New Zealand)
Limited warranty • 3 years parts and labor (excluding illumination module)
• Contact an authorized Christie representative for full details of our limited warranty
