CIRCUIT DESIGN TB-CDT-TX-01 User manual

OG_TB-CDT-01_v12e 1Circuit Design, Inc
OPERATION GUIDE
TEST board for CDT modules
TB-CDT-TX-01 / TB-CDT-RX-01
Operation Guide
Version 1.2 (Sept. 2022)
CIRCUIT DESIGN, INC.,
7557-1 Hotaka, Azumino-city
Nagano 399-8303 JAPAN
Tel: + [phone]
Fax: + [phone]
e-mail: [email protected]
http://www.circuitdesign.jp

OG_TB-CDT-01_v12e 2Circuit Design, Inc
OPERATION GUIDE
CONTENTS
GENERAL DESCRIPTION & FEATURES ........................................2
TB-CDT-TX-01 / TB-CDT-RX-01 BOARD OPERATION....................3
ATTACHING BATTERY HOLDER……………………………............. 4
MODULE INSERTION WITHANTENNA………………………………5
ID REGISTRATION………………………………………………………6
RECIEVER MODE SETTING………………………………………… ..7
CONNECTION FOR EXTERNAL DEVICE…………………………… 8
DIMENSIONS………………………………………………………….... 9
CIRCUIT DIAGRAM ........................................................................10
CAUTIONS & WARNINGS……………………………………............12
REVISION HISTORY ......................................................................13
GENERAL DESCRIPTION & FEATURES
General description
The test boards will save your time and effort for evaluation of the radio modules CDT-TX-01
with CDT-RX-01 or CDT-TX-02M-R with CDT-RX-02M-R / CDT-RX-03M. Communication range
can be tested easily by checking the LEDs on the decoder board TB-CDT-RX-01.
TB-CDT-TX-01 and TB-CDT-RX-01 do not include the RF modules. Please make sure to order
them if needed.
Features
6-push buttons and output LEDs.
Dip switch for receiver mode setting.

OG_TB-CDT-01_v12e 3Circuit Design, Inc
OPERATION GUIDE
TB-CDT-TX-01 / TB-CDT-RX-01 BOARD OPERATION
Power Supply
TB-CDT-TX-01 3V (2 x 1.5 AAA battery)
TB-CDT-RX-01 4.5V (3 x 1.5V AAA battery)
Main Switch
Power ON/OFF
Receive setting switch
M1/M2/SET
ID registration
Registers transmitter ID in receiver.
LED1-6 output indicator
Turns on when corresponding switch pressed on TX board.
SW1-6
When pressed, corresponding LED lights on RX board.
M1 and M2 indicator LED
9 pin output interface
Allows connection to external output devices.

OG_TB-CDT-01_v12e 4Circuit Design, Inc
OPERATION GUIDE
ATTACHING BATTERY HOLDER
TB-CDT-TX-01
Attach the battery holder to the underside of the board and solder into position.
TB-CDT-RX-01
Attach the battery holder as shown below:
+
-
-
+
+
-
Board underside
Output pins
Solder
Battery holder
Solder
Solder
Solder
Antenna
Antenna
Battery holder
Board underside
-
+
+
-
Solder

OG_TB-CDT-01_v12e 5Circuit Design, Inc
OPERATION GUIDE
MODULE INSERTION WITH ANTENNA
TB-CDT-TX-01
TB-CDT-RX-01
CDT-RX-xx
Antenna socket
CDT-TX-xx
Antenna socket

OG_TB-CDT-01_v12e 6Circuit Design, Inc
OPERATION GUIDE
ID REGISTRATION
Please refer to the module’s manual for method of ID registration.
ID Registration mode switch setting
M1
M2
SET
OFF
OFF
ON
ID Erase mode switch setting
M1
M2
SET
ON
OFF
ON
ID all Erase mode switch setting
M1
M2
SET
OFF
ON
ON
OFF = OPEN
ON = GND
If receiver and transmitter IDs do not match, then receiver will not respond to transmitter signal.
CDT-RX-xx
M1 M2 SET
ON - OFF

OG_TB-CDT-01_v12e 7Circuit Design, Inc
OPERATION GUIDE
RECIEVER MODE SETTING
Receiver module
operation
Mode Setting
M1
M2
SET
One shot
OFF
OFF
OFF
Toggle
ON
OFF
OFF
Switching
OFF
ON
OFF
Continuous
ON
ON
OFF
OFF = OPEN
ON = GND
In normal operation, SET is always in the OFF position.
Make sure to set the mode before activating power.

OG_TB-CDT-01_v12e 8Circuit Design, Inc
OPERATION GUIDE
CONNECTION FOR EXTERNAL DEVICE
The RX board allows connection to output devices, eg. external LEDs, relays. Outputs 1-6 switches to
ground when output is activated. Starting from the left, the pins are labelled as follows.
G
Ground
S
Permanent live
+
Live when board ON
1
Outputs (switched to ground)
2
3
4
5
6
CDT-RX-xx
M1 M2 SET
ON - OFF

OG_TB-CDT-01_v12e 9Circuit Design, Inc
OPERATION GUIDE
DIMENSIONS
11

OG_TB-CDT-01_v12e 10 Circuit Design, Inc
OPERATION GUIDE
CIRCUIT DIAGRAM

OG_TB-CDT-01_v12e 11 Circuit Design, Inc
OPERATION GUIDE

OG_TB-CDT-01_v12e 12 Circuit Design, Inc
OPERATION GUIDE
Cautions
As the product communicates using electronic radio waves, there are cases where transmission will be
temporarily cut off due to the surrounding environment and method of usage. The manufacturer is exempt from
all responsibility relating to resulting harm to personnel or equipment and other secondary damage.
Do not use the equipment within the vicinity of devices that may malfunction as a result of electronic radio waves
from the product.
The manufacturer is exempt from all responsibility relating to secondary damage resulting from the operation,
performance and reliability of equipment connected to the product.
Communication performance will be affected by the surrounding environment, so communication tests should be
carried out before actual use.
Ensure that the power supply for the product is within the specified rating. Short circuits and reverse connections
may result in overheating and damage and must be avoided at all costs.
Ensure that the power supply has been switched off before attempting any wiring work.
The case is connected to the GND terminal of the internal circuit, so do not make contact between the '+' side of
the power supply terminal and the case.
When batteries are used as the power source, avoid short circuits, recharging, dismantling, and pressure.
Failure to observe this caution may result in the outbreak of fire, overheating and damage to the equipment.
Remove the batteries when the equipment is not to be used for a long period of time. Failure to observe this
caution may result in battery leaks and damage to the equipment.
Do not use this product in vehicles with the windows closed, in locations where it is subject to direct sunlight, or
in locations with extremely high humidity.
The product is neither waterproof nor splash proof. Ensure that it is not splashed with soot or water. Do not use
the equipment if water or other foreign matter has entered the case.
Do not drop the product or otherwise subject it to strong shocks.
Do not subject the equipment to condensation (including moving it from cold locations to locations with a
significant increase in temperature.)
Do not use the equipment in locations where it is likely to be affected by acid, alkalis, organic agents or corrosive
gas.
The GND for the product will also affect communication performance. If possible, ensure that the case GND and
the circuit GND are connected to a large GND pattern.
Warnings
Do not take apart or modify the equipment.
Do not remove the product label (the label attached to the upper surface of the product.) Using a product from
which the label has been removed is prohibited.
Circuit Design, Inc. All right reserved
No part of this document may be copied or distributed in part or in whole without the prior written
consent of Circuit Design, Inc.
Customers are advised to consult with Circuit Design sales representatives before ordering.
Circuit Design, Inc. believes the furnished information is accurate and reliable. However, Circuit Design,
Inc. reserves the right to make changes to this product without notice.

OG_TB-CDT-01_v12e 13 Circuit Design, Inc
OPERATION GUIDE
REVISION HISTORY
Version
Date
Description
Remark
1.0
Dec. 2012
The first issue
1.1
May. 2014
TB-CDT-TX-01 Board image updated
1.2
Sept. 2022
Updated to include operation with CDT-RX-03M
Correction on contents page
